Page 1
2m Depth
Greenhouse Kit
with Misting System
1 of 8
User Guide
Page 2
Overview
Before you Star t
Check the pack contents before attempting construction.
Location and Positioning
The seedlings in your greenhouse want an outdoor full-sun to part-sun position all year
round, depending on the climate of your location. Where possible, the greenhouse
should be positioned in a sheltered location protected from direct winds. Avoid very
windy positions and spots where the frame may stand in water for long periods.
Propagating from
Seed in a Greenhouse
#SMARTGARDENER Blog Post
2 of 8
www.holmanindustries.com.au/
propagating-from-seed-in-a-greenhouse/
Page 3
Package Contents
Greenhouse Frame Misting System
1
2
3
4
5
6
7
8
9
×3
×45
×40
×24
×8
×12
×12
×4
×1
A
B
C
D
E
F
G
×4
×12
×4
×6
×30
×2
×2
10
11
12
13
14
15
16
17
×5
×12
×2
×3
×1
×6
×1
×1
3 of 8
Page 4
Assembly
Frame Assembly
A
5
5
B
A
6
E
D
6
E
7
7
D
4
G
6
6
2
E
6
6
2
E
1
7
G
5
F
5
5
Assemble frame
as shown. Metal
tubes
plastic par ts
①‑⑤
push into
Ⓐ‑Ⓖ
and shelves⑥ sit on
F
3
3
7
2
6
E
2
E
D
4
5
A
2
1
D
5
2
6
2
6
6
2
6
2
7
2
7
E
2
3
E
E
3
E
E
6
3
7
D
E
2
7
E
the horizontal tubes.
Start with the base and
work upwards. Tools
are not required–hand
assembly is suitable.
We suggest wearing
protective gloves
during assembly.
7
Before covering the
frame, use the frame
pegs⑦ to fasten down
the assembled frame.
4 of 8
When assembled,
check the frame is
tightly pushed together
in all directions.
Page 5
Assembly (continued)
Misting System Connection
Connect up the black poly pipe⑩ using the
elbow⑬ and joiners⑫ to fit around the frame.
Trim the last piece of poly pipe as needed and
place the end cap⑭ onto the top end of the
poly pipe and the snap-on connector⑯ to
the bottom end as shown below. Attach your
garden hose to the snap-on connector.
11
11
Attach the poly pipe along the width of the top central
beam and adjoining vertical corner poles with clips⑪.
To insert the sprayers⑮, punch six holes along the top
length of poly pipe with the supplied punch⑰. Twist
the yellow end of the sprays into the punched holes.
11 11
11 11
11 11
11
17
14
12
15
11
11 11
11
13
16
1010
13
12
13
10
10
10
16
to Gard en Hos e
5 of 8
Page 6
Assembly (continued)
Covering the Frame
Unzip the cover⑨ door before fitting to the assembled
frame. Failure to do so may cause damage to the
cover. Secure the cover to the frame with the ties
attached to the inside of the cover. For ease of
access, the doorway can be rolled and tied up.
Fasten Down the Greenhouse
Ground stakes with guy ropes⑧ are provided to secure the cover to the ground, along with pegs⑦ for
securing the frame. Lower corner angle points on the cover can also be used for extra security.
Unzip b efore
covering!
We recommend t wo people for this
step to avo id dam age to th e cover
6 of 8
TIE POINT
8
9
TIE POINT
8
TIE POINT
8
Page 7
Maintenance
Cleaning and Storage
Wash off heav y dirt or dust deposits and remove bird droppings with soapy water. The cover
may be removed from the whole structure, disassembled and stored when not in use.
CAUTION
Ensure the greenhouse is secured to the ground with pegs or weights. Ensure weight is placed evenly on
shelves to avoid the possibility of the greenhouse tipping over. Ensure all poles and fittings are securely
assembled prior to use. The method of securing will depend on the ground surface. The greenhouse
should not be left out in windy conditions if it has not been secured to the ground. During extreme weather
conditions or high winds, ensure the greenhouse is moved to a sheltered area and ensure it is secured
to the ground using appropriate methods. The greenhouse should be disassembled when not in use.
Maximum loading: 10kg for each shelf.
7 of 8
Page 8
Thanks for being a
#SMARTGARDENER
We really appreciate having you as a customer, and would like to say thank you for choosing us.
We hope you are happy with our product and if you have a moment to leave a
review, we would like to hear your feedback on the Product Review website.
Should you have any questions about this product or its operation please call customer service on 1300 716 188.
www.productreview.com.au then search for our product name
8 of 8
Head Office/Service
11 Walters Drive, Osborne Park WA 6017
Ph: +61 8 9416 9999 Fax: +61 8 9416 9920
service@holmanindustries.com.au
www.holmanindustries.com.au
Copyright © 2019 Holman Industries
