CHEMTRONICS



Technical Data Sheet

IPA

Presaturated Wipes

PRODUCT DESCRIPTION

IPA Presaturated Wipes remove solder paste,
inks and other contaminants. These highly
effective cleaning wipes are ideal for all
general cleaning applications. IPA
Presaturated Wipes are well suited for touch­up cleaning of automatic printer stencils and
cleaning of semi-automatic printer stencils
during and at the end of production runs.

IPA Presaturated Wipes contain ultra-pure
Electronics Grade IPA. The wipes are
available in a C-fold wipe contained in a
convenient dispensing box or in a tub.

 Plastic Safe
 Lint free
 RoHS Compliant
 Flammable
 Regular Cleaning Strength
 California - CARB Electronics Cleaner

75% Compliant

TYPICAL APPLICATIONS

IPA Presaturated Wipes are engineered for
cleaning:

 Screens & Stencils
 Fiber Optics & Connectors
 Cables
 Hard-line Coax Cable
 Metal & Fiber Optic Cable Splices
 PC Boards
 Control Systems

TDS# SIP100P

TYPICAL PRODUCT DATA AND
PHYSICAL PROPERTIES
Boiling Point

174 F Initial

Evaporation Rate (butyl acetate=1) <1
Flash Point (TCC) 68º F
Specific Gravity 0.88
Vapor Pressure @68F 198 mm Hg
Odor

Mild Alcohol

Solubility in Water Soluble
Kauri-Butanol (KB) Number 56
VOC* Content:

CARB 70 %

SCAQMD 616 g/L
Federal 70 %

RoHS Compliant

Shelflife 2 years

*Volatile Organic Compound (VOC) information is calculated on a
weight basis using the VOC definition of California Air Resources
Board (CARB) Consumer Product Regulations, South Coast Air
Quality Management District (SCAQMD) Rule 102 and the Federal
definition published in 40 CFR 51.100(s).

COMPATIBILITY
IPA Presaturated Wipes are generally
compatible with most materials. As with any
chemical product, component compatibility
must be determined on a non-critical area
prior to use.

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]

USAGE INSTRUCTIONS
For industrial use only.

Read MSDS carefully prior to use.

SIP100P tub directions:

Remove top of container and peel foil seal
from top of tub. Pull the first wipe from
center of roll and feed it through the opening
in the lid. Replace lid and pull first wipe from
the tub and separate at perforation. Keep
container closed to prevent wipes from drying
out.

IPA100B box directions:

Open box and remove wipes from pouch
found inside box. Pull wipes as needed from
the box and close box between uses to
prevent wipes from drying out.

Cleaning directions:

General cleaning: Wipe surfaces thoroughly
to remove contaminants. When removing
heavy soils, use a clean wipe for final wipe
down.

Stencil cleaning: Wipe away residual solder
paste until surface is thoroughly cleaned.
Repeat with a clean wipe to remove any trace
contaminants.

TECHNICAL & APPLICATION
ASSISTANCE

ITW Chemtronics



provides a technical
hotline to answer your technical and
application related questions. The toll free
number is: 1-800-TECH-401.

AVAILABILITY
SIP100P Presaturated Wipes (100/tub)
IPA100B C-Fold Wipes (100/box)

ENVIRONMENTAL IMPACT DATA

HCFC-141b
HCFC-225

None
None

HFC
nPB

None
None

Hydrochlorofluorocarbons (HCFCs) are regulated
under the Montreal Protocol as Class II ozone
depleting substances. HCFC-141b is no longer
produced in the US under this legislation. HCFC­225 is planned for production phase-out in 2015.
Hydrofluorocarbons (HFCs) are not currently
regulated.
EPA has listed n-propyl bromide (nPB) as an
acceptable alternative to ozone depleting substances
in metal, precision, and electronics cleaning under
Section 612 of the Clean Air Act.

NOTE:

This information is believed to be accurate. It is
intended for professional end users having the skills
to evaluate and use the data properly.
ITW CHEMTRONICS does not guarantee the
accuracy of the data and assumes no liability in
connection with damages incurred while using it.

Chemtronics is a registered trademark of ITW Chemtronics.
All rights reserved.

MANUFACTURED BY:

ITW CHEMTRONICS
8125 COBB CENTER DRIVE
KENNESAW, GA 30152
1-770-424-4888

REV. F (02/08)
