HMC Electronics ES1629 User Manual

PRODUCT DESCRIPTION

Kontact Restorer® New & Improved!
Cleaner Lubricant is specially engineered to
clean, lubricate and protect connectors in one
easy step. This nonflammable
cleaner/lubricant will clean contact surfaces
and provide a long-lasting protective film
that protects the contact from corrosion.
 Same great features as original,
without HCFC-141b

 Nonflammable
 Deep penetrating aerosol spray
 Minimizes friction and metal wear
 Protects metal contacts from carbon

build-up

 May be used on energized equipment
 Cleans and lubricates hard to reach areas

TYPICAL APPLICATIONS
Kontact Restorer

®

New & Improved!

Cleaner Lubricant effectively cleans:

 Circuit Breakers
 Contact Breaker Points
 Distribution Panels
 Intersurface Connectors
 Motors and Generators
 Plugs and Sockets
 Potentiometers
 Relay Contacts
 Solenoids
 Switching Devices

TYPICAL PRODUCT DATA AND
PHYSICAL PROPERTIES

Boiling Point

156° F (Initial)

Evaporation Rate
(butyl acetate=1)

>1

Flash Point (TCC)

None

Specific Gravity

1.35

Vapor Pressure @68°F 112 mmHg
Appearance Clear, colorless liquid
Odor

Mild

Solubility in Water

Negligible

Dielectric Breakdown
(ASTM D-877)

23.5 kV

Kauri-Butanol
(KB) Number

125

Shelflife 5 years
RoHS/WEEE

Status

COMPATIBILITY

New & Improved Kontact Restorer® is generally
compatible with most materials used in electrical
and electronic assemblies, except acrylics, ABS
resins, polycarbonates and polystyrenes. With
any chemical solvent/component compatibility
must be determined on a non-critical area prior
to use.

TDS # 1629

CHEMTRONICS

®

Technical Data Sheet

Kontact Restorer® New & Improved!

Cleaner Lubricant

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]

Material Compatibility

ABS Non-Compatible
Buna-N Fair
EPDM Fair
Graphite Excellent
HDPE Excellent
LDPE Excellent
Lexan™

Fair
Neoprene Fair
Nylon™ 66

Excellent
Cross-Linked PE Excellent
Polypropylene Excellent
Polystyrene Non-Compatible
PVC Excellent
Silicone Rubber Poor
Teflon™

Excellent
Viton™

Fair

Performance

Grease Removal per gram solvent (mg)

Kontact Restorer
New & Improved!

15.46

HFC-based Cleaner

0.50.5

Grease & Lubricating Oil Removal per gram
solvent (mg)

Kontact Restorer
New & Improved!

22.523.

823.8

HFC-based Cleaner

0.50.5

USAGE INSTRUCTIONS

For commercial use only.
Read MSDS carefully prior to use.
Spray 4-6 inches from surface to be
lubricated or protected. For precise
application use attached extension tube.
Collect run-off for proper disposal.

AVAILABILITY
ES1629 12 oz. Aerosol

TECHNICAL & APPLICATION
ASSISTANCE

ITW Chemtronics

®

provides a technical
hotline to answer your technical and
application related questions. The toll free
number is: 1-800-TECH-401

.

ENVIRONMENTAL IMPACT DATA

ENVIRONMENTAL IMPACT DATA

CFC 0.0% VOC 87.0%
HCFC– 141b
HCFC-225

0.0%

0.0%

HFC

nPB

10.0%

87.0%

CFC, HCFC-225, HCFC-141b, VOC, HFC, and nPB
percentages shown are the content by weight.

NOTE:

This information is believed to be accurate. It is
intended for professional end users having the skills
to evaluate and use the data properly. ITW
CHEMTRONICS® does not guarantee the accuracy
of the data and assumes no liability in connection
with damages incurred while using it.

MANUFACTURED BY:

ITW CHEMTRONICS
8125 COBB CENTER DRIVE
KENNESAW, GA 30152
1-770-424-4888

REV. B (06/06)

DISTRIBUTED BY:

Documentation Provided By HMC Electronics

33 Springdale Ave. Canton, MA 02021

http://www.hmcelectronics.com

[phone]
