Hitachi L42V651, L47V651 User Manual

Page 1
LCD Flat Panel TELEVISION
Operating Guide for L47V651 & L42V651
IMPORTANT SAFETY INSTRUCTIONS.......................................................................................2-3
FIRST TIME USE ......................................................................................................................... 4-21
THE REMOTE CONTROL......................................................................................................... 22-37
ON-SCREEN DISPLAY ............................................................................................................ 38-61
USEFUL INFORMATION.......................................................................................................... 62-68
END USER LICENSE AGREEMENT FOR HITACHI DTV SOFTWARE................................137-145
INDEX............................................................................................................................................148
OPERATING GUIDE IN SPANISH .........................................................................................69-136
Page 2
Important Safety Instructions
NEC National Electric Code
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2
SAFETY YOUR HITACHI LCD FLAT PANEL TELEVISION
O performance, and ease of service of HitachiI
Flat Panel
Safety is also foremost in our minds in the design of these units. To help you operate these products properly, this section illustrates safety tips which will be of benefit to you. Please read it carefully and apply the knowledge you obtain from it to the proper operation of your Hitachi LCD Flat Panel television.
Please fill out your warranty card and mail it to Hitachi. This will enable Hitachi to notify you promptly in the improbable event that a safety problem should be discovered in your product model.
Follow all warnings and instructions marked on this LCD Flat Panel television.
POINTS YOU SHOULD KNOW ABOUT
ur reputation has been built on the quality,
televisions.
product’s enclosure that may be of a sufficient magnitude to constitute a risk of electric shock to a person.
literature accompanying the appliance.
READ BEFORE OPERATING EQUIPMENT
F
ollow all warnings and instructions marked on this
LCD Flat Panel television.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a 7
.
8. Do not install near any heat sources such as
9. Do not defeat the safety purpose of the polarized or
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of
uninsulated “dangerous voltage” within the
The exclamation point within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the
soft
dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding
LCD
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use the attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13.
Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15.Televisions are designed to comply with the
recommended safety standards for tilt and stability. Do not apply excessive pulling force to the front, or top, of the cabinet which could cause the product to overturn resulting in product damage and/or personal injury.
16.Follow instructions for wall, shelf or ceiling mounting as recommended by the manufacturer.
17. An outdoor antenna should not be located in the vicinity of overhead power lines or other electrical circuits.
18. If an outside antenna is connected to the receiver be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding for the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna discharge unit, connection to grounding electrodes and requirements for the grounding electrode.
Note to the CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-44 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
Page 3
Important Safety Instructions
Power
This LCD television is designed to operate on 120
volts 60 Hz, AC current. Insert the power cord into a 120 volt 60 Hz outlet. The mains plug is used as the disconnect device and shall remain readily operable.
To prevent electric shock, do not use the LCD television’s (polarized) plug with an extension cord, receptacle, or other outlet unless the blades and ground terminal can be fully inserted to prevent blade exposure.
Never connect the LCD television to 50 Hz, direct current, or anything other than the specified voltage.
Caution
unplug the LCD television and call your authorized dealer or service center.
Caution
Adjust only those controls that are covered in the instructions, as improper changes or modifications not expressly approved by Hitachi could void the user’s
warranty.
Warning
To reduce the risk of fire or electric shock, do not
The LCD television should not be exposed to
This apparatus shall be connected to a mains
source
Never remove the back cover of the LCD television as this can expose you to very high voltages and other hazards. If the television does not operate properly,
expose this apparatus to rain or moisture.
dripping or splashing and objects filled with liquids, such as vases, should not be placed on the television.
socket outlet with a protective earthing connection.
Public viewing of copyrighted material
Public viewing of programs broadcast by TV stations and cable companies, as well as programs from other sources, may require prior authorization from the broadcaster or owner of the video program material.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized, and is intended for home and other limited consumer uses only unless otherwise authorized. Reverse
engineering or disassembly is prohibited.
Note
T
his digital television is capable of receiving analog basic, digital basic cable television programming by direct connection to a cable system providing such programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator’s enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable company.
Note
There are no user serviceable parts inside the
LCD television.
Model and serial numbers are indicated on back side
and right side of the LCD television.
Lead/Mercury Notice
Hg
This pr
oduct contains lead and one or more non­replaceable mer or dispose of according to applicable recycling and disposal information, contact your local government agency or visit or www.epsc.ca (in Canada). For more information, call 1-800-HITACHI.
cury lamps. Do not put in trash. Recycle
laws. For product
www.eiae.org
(in USA)
3
Page 4
Accessories
Power Swivel Cable
Remote Control
1.5V batteries
Power Cord
For Canada models:
For optional accessories, please access our web site at: www.hitachi.ca/tv
Two “AA” size,
Remote Control Unit CLU-4374A
(Part No. HL02404).
Two "AA" size, 1.5V batteries.Power Cord (Part No. EV01841).
Power Swivel Cable (Part No. EW08434).
1.
Open the battery cover of the remote control by pushing down and sliding the back cover off.
2.
Insert two new “AA” size batteries for the remote contr
ol. When r
eplacing old batteries, push them towards the
springs and lift them out.
3. Match the batteries to the (+) and (-) marks in the battery compartment.
4.
Insert the bottom of the battery
, the (-) side, into the battery compartment first, push towards the springs and insert the top of the battery
, the (+) side, into place. Do not for
ce the
battery into the battery compartment.
5. Replace the cover.
Bottom View (Remote Control)
Lift up on tab to r
emove back cover.
REMOTE CONTROL BATTERY INSTALLATION AND REPLACEMENT
CAUTION: Do not insert batteries with ‘+’ and ‘-’ polarities reversed as this may cause the batteries to swell or rupture resulting in leakage.
For U.S. models:
For optional accessories, please access our web site at: www.hitachi.us/tv
Check to make sure you have the following accessories before disposing of the packing material.
First time use
CAUTION:
1. Ceiling mounting is not recommended. Mounting the panel on the ceiling does not provide adequate ventilation for the electronics or proper support for the front glass panel. This LCD television product is designed for a maximum tilting angle of 45 degrees from vertical.
2. The wall mount unit for the 47" & 42" models is WM07S. Please see page 7 for important information related to the wall mount. Wall Mount unit is an optional accessory (Not Included).
4
Page 5
How To Set Up Your New Hitachi
LCD
Television
To take measures to prevent the LCD Flat Panel Television from tipping over and prevent possible injury it is important to mount the unit in a stable and flat surface.
Securing to a Wall
1. Using metallic wire (two places) fasten the set to t
he clamping screw on the rear of the LCD Flat
Panel TV as shown below.
Wire
2. Keep the LCD television 4 inches away from the wall except when mounted using the wall mount bracket.
3. Secure the television to the wall as shown.
A
(a) Power Swivel
NOT
USED
B
(b) Power Swivel
USED
A B
12 in.
5 in.
42” 47”
12.5 cm
30 cm
* Please adjust the wire length to avoid touching the wall when turning the
TV
.
NOTES: 1. Do not block the ventilation holes of the
LCD Television. Blocking the ventilation holes might cause fire or defect.
2. In case of an abnormal symptom, unplug the AC cord.
3. If you purchased the wall mount bracket
option, please ask for professional installer. Do not install by yourself.
4. Install the unit at a proper area where it does
not expose anyone to any danger of hitting
themselves (for example their hands, head
or face, etc.) against the edge of the unit and cause personal injury.
5. If the Power Swivel feature will not be
ed, the LCD television should be
us secured to the wall as shown in fig. (a).
6. If the Power Swivel feature will be used,
the LCD television should be secured to the wall as shown in fig. (b).
Caution when moving the main unit
As this product is heavy, whenever it is moved, two
people are required to transport it safely. Whenever the
unit is moved it should be lifted forward using the top and base on both sides of the Television for stability.
When moving the Television, lift the handles , then support the bottom frame as shown below.
ANTENNA
U
nless your LCD Television is connected to a cable TV system or to a centralized antenna system, a good outdoor color TV antenna is recommended for best performance. However, if you are located in an exceptionally good signal area that is free from interference and multiple image ghosts, an indoor antenna may be sufficient.
LOCATION
Select an area where sunlight or bright indoor illumination will not fall directly on the picture screen. Also, be sure that the location selected allows a free flow of air to and from the perforated back cover of the set. In order to prevent an internal temperature increase, maintain a space of 10 cm (4 inches) from the sides/back of the Television, and 30 cm (12 inches) from the top of the television to the ceiling. To avoid cabinet warping, cabinet color changes, and increased chance of set failure, do not place the TV where temperatures can become excessively hot, for example, in direct sunlight or near a heating appliance, etc.
30 cm (12 inches)
10 cm (4 inches)
10 cm (4 inches)
CONNECT POWER SWIVEL CABLE
C
onnect one end of cable to the swivel slot of the LCD Rear Panel. Connect the other end to swivel slot of the Table Top Stand. For more detail information, please refer to next page installation instruction.
TURNING ANGLE
The maximum turning angle is 30° (left and right). Do
not place any objects on the path of the monitor when using the power swivel feature.
C
30°
30°
D
C D
9.1
in.
23.1 cm
10.2 in.
25.9 cm
14.05 in.
35.7 cm
15.
15 in.
38.5 cm
42"
47"
First time use
47” & 42 "
5
Page 6
How to set up your new H
itachi LCD
Television
First time use
AC CORD AND POWER SWIVEL CABLE INSTALLATION INSTRUCTION
he AC cord and power swivel cable provided with your new LCD Flat Panel Television need to be installed correctly
T to avoid their disconnection when rotating the TV on its Table top stand.
Located on the back of the TV are 2 plastic clamps to hold the AC cord and power swivel cable. Please follow
the instructions below.
Pa
ss the AC cord through Clamp #1 and connect
it to the TV. Pull on the clamp to tighten the AC cord to the TV.
Connect power swivel cable on one end to the swivel slot of the LCD Rear Panel. Connect the other end to the swivel slot of the Table Top Stand Base.
The AC cord, power swivel cable and the signal
cables can all be held together with Clamp #2.
Clamp #1 : Pass the AC cord through this clamp ;
then pull the clamp to tighten the AC
cord to the TV.
Swivel slot on the
LCD back panel.
la
mp #2: Use this clamp to hold the AC cord, power
C
AC CORD
Swivel slot on Table Top
Stand Base.
6
swivel connector and the signal cables.
Page 7
How to set up your new HITACHI
LCD
Television
SETTING FOR WALL MOUNTING
STEP
(1) :
Please locate the STAND METAL SUPPORTS on the back of the TV . These metals is use to hold the TV and the Base ; so it needs to remove 4 screws from the STAND METAL in order to separate the TV from the Base.
2 STAND METAL
SUPPORTS
First time use
Remove 4 screws
then remove the 2 metal
supports.
STEP (2)
Now please remove the 5 screws of the STAND metal from the TV, now the TV STAND can be separated from the TV. For dimensions of the WALL MOUNT assembly please refer to page 66.
:
STAND METAL
5 SCREWS
TV STAND BASE
For Model L47V651 & L42V651
CAUTION- T
NOTE: U
his LCD Flat Panel for use only with Hitachi WM07S Wall Mount. Use with other
Wall Mount is capable of resulting in instability causing possible injury.
se the specified WALL MOUNT unit for the LCD TV depending on the size of your TV.
Please access our web site at: www.hitachi.us/tv (US) or www.hitachi.ca/tv (CAN) for recommended accessories for your TV.
7
Page 8
How to set up your new HITACHI
VIEWING
The best picture is seen by sitting directly in front of the TV and about 10 to 18 feet from the screen.
LCD
Television
During daylight hours, reflections from outside light
R
S
may appear on the screen. If so, drapes or screens can be used to reduce the reflection or the TV can be located in a different section of the room.
4" Minimum
80
BEST HORIZONTAL
If the TV’s audio output will be connected to a Hi-Fi
First time use
performance will be obtained by placing the speakers equidistant from each side of the receiver
system’s external speakers, the best audio
cabinet and as close as possible to the height of
4" Minimum
5'
10'
VIEWING ANGLE
80
15' 20'
the picture screen center. For best stereo separation, place the external speakers at least four feet from the side of the TV, place the surround
L
S
speakers to the side or behind the viewing area. Differences in room sizes and acoustical environments will require some experimentation with speaker placement for best performance.
ANTENNA CONNECTIONS TO REAR JACK PANEL
VHF
(75-Ohm) antenna/CATV (Cable TV)
When using a 75-Ohm coaxial cable system, connect CATV coaxial cable to the AIR/CABLE (75-Ohm) terminal. Or if you have an antenna, connect the coaxial cable to the same AIR/CABLE terminal.
AIR / CABLE
To CATV cable
VHF (300-Ohm) antenna/UHF antenna
When using a 300-Ohm twin lead from an outdoor antenna, connect the VHF or UHF antenna leads to screws of the VHF or UHF adapter. Plug the adapter
To outdoor antenna
or
into the antenna terminal on the TV.
AIR / CABLE
When both VHF and UHF antennas are connected
Attach an optional antenna cable mixer to the TV antenna terminal, and connect the cables to the antenna mixer. Consult your dealer or service store for the antenna mixer.
To UHF antenna
AIR / CABLE
Antenna Mixer
To outdoor VHF or UHF antenna
To outdoor antenna or CATV system
NOTE: Connecting
8
a 300-Ohm twin lead connector may cause interference. Using a 75-Ohm coaxial
cable is recommended.
Page 9
Hook-up Cables and Connectors
AUDIO OUT
3.8mm STEREO MINI-PLUG
2 RCA TYPE PLUGS
Cable
Cable
Cable
Power Swivel Cable (Provided)
This cable is used to connect the swivel stand to the rear panel of the
LCD
Television.
Most video/audio connections between components can be made with shielded video and audio cables that have p
hono connectors. For best performance, video cables should use 75-Ohm coaxial shielded wire. Cables can be purchased from most stores that sell audio/video products. Below are illustrations and names of common connectors. Before purchasing any cables, be sure of the output and input connector types required by the various components and the length of each cable.
First time use
300-Ohm Twin Lead
T
his outdoor antenna cable must be connected to an
antenna adapter (300-Ohm to 75-Ohm).
Phono or RCA
Used on all standard video and audio cables which connect to inputs and outputs located on the
television’s rear jack panel and side control panel.
“F” Type 75-Ohm Coaxial Antenna
For connecting RF signals (antenna or cable TV) to the antenna jack on the television.
S-Video (Super Video)
This connector is used on camcorders, VCRs and laser­disc players with an S-Video feature in place of the standard video cable to produce a high quality picture.
Optical Cable
This cable is used to connect to an audio amplifier with an Optical Audio In jack. Use this cable for the best sound quality.
HDMI Cable
This cable is used to connect your external devices such as Set-Top-Boxes or DVD players equipped with an HDMI output connection to the TV’s HDMI input.
Stereo Cable (3.8mm plug to 3.5mm plug)
Used on all standard video and audio cable which connect to inputs and outputs located on the rear jack
panel and side control panel.
9
Page 10
Quick Reference Remote Control Buttons and Functions
I
n addition to controlling all of the functions on your HITACHI LCD TV, the new remote control is designed to
operate different types of devices, such as, DVD Players, CBL (Cable Boxes), set-top-boxes, satellite receivers,
and VCRs. The remote control must be programmed to control the chosen device. Please see pages 22-37 for a
complete description of all features and programming of the Remote Control.
(TV, DVD, SAT/CBL,PVR/VCR)
Tur
ns the selected device on and o.
Turns on or blinks to show remote control mode w hen the SO URCE ACCESS buttons are pressed.
First time use
Toggles picture mode settings between DAY and NIGHT mode.
(TV,DVD,SAT/CBL,PVR/VCR)
Accesses the OSD menu system.
Accesses the INPUTS menu system.
CURSOR PAD/SELECT BUTTON
(TV, DVD, SAT/CBL,PVR/VCR)
The Cursor Pad is used as a cursor to navigate through the OSD and INPUT menu systems. The Select button is used to Select/Activate highlighted menu items.
Closed Caption (CC) BUTTON
Press to show and change the Closed Caption mode.
Accesses the program guide of other devices.
Increase up and decrease down to adjust the audio level of your TV.
R
educes the audio level to 50% if pressed
once, and to complete mute if pressed twice. Press it a third time to restore audio level.
Used to manually enter the TV channel, and used for numeric entry when navigating through the the OSD, INPUTS.
The (-) button is used when the remote is in Set-Top-Box (STB) mode or when the TV uses a digital input.
(TV, DVD, SAT/CBL, PVR/VCR)
POWER BUTTON
MODE INDICATOR
DAY/NIGHT BUTTON
MENU BUTTON
INPUTS BUTTON
GUIDE BUTTON (SAT/CBL, PVR)
VOLUME BUTTONS
MUTE BUTTON (TV)
NUMERIC BUTTONS
(TV)
(TV)
(TV)
(TV )
(-) BUTTON
(TV,STB)
SOURCE ACCESS BUTTONS
(TV, DVD, PVR/VCR, SAT/CBL)
Changes the mode of the Universal Remote Control to control the device selected.
PAUSE BUTTON (PVR/VCR, DVD)
Press to pause other devices when the remote is in DVD, PVR/VCR mode.
DVD/VCR CONTROL BUTTONS (DVD, PVR/VCR)
Controls the functions of your VCR and DVD.
ASPECT BUTTON (TV)
Changes the aspect ratio of the TV.
EXIT BUTTON (TV, SAT/CBL, PVR/VCR)
Exits out of the OSD, INPUTS menu systems if their menu is displayed.
PIP CONTROL BUTTON
(TV)
Press to show and change the Picture-in-Picture mode.
FAVORITE CHANNEL (FAV CH) button (TV)
Press to enter/access Favorite Channel (FAV CH) mode.
(Favorite channel is only available for TV mode.)
INFO BUTTON (TV, STB, CBL, PVR)
Displays various information on the screen, such as channel information.
CHANNEL UP & DOWN BUTTONS (TV, CBL, STB, PVR/VCR)
Changes up or down the channel.
LAST CHANNEL BUTTON
(TV, SAT/CBL, PVR)
Switches between the current and last channel viewed.
ENTER BUTTON
TV, VCR, SAT/CBL)
(
Press to use as SELECT feature.
LEGEND TV – Television PVR – Video Recorder/Player CBL – Cable Box DVD – Digital Video Disc Player SAT – Satellite
VCR – Videocassete Recorder
NOTES: 1. The TV’s remote control sensor is located on the right bottom portion of the TV screen. To
control TV functions, please point the remote control directly at the remote control sensor for best results.
2. VCR precode is included in the PVR mode.
10
Page 11
Side Panel Controls
FRONT VIEW
PHOTO INPUT
SIDE PANEL CONTROLS
First time use
SIDE
POWER button
Press this button to turn the LCD Television
ON/OFF. It can also be turned ON/OFF by remote
control. The “MAIN POWER” can only be turn OFF by unplugging the power cord from the outlet.
After this button is pressed to turn ON the set, the function of this button will not be available for a short period of time until the picture appears on the TV screen.
NOTE: When the TV is unplugged, the clock will
stop and may eventually reset itself.
MENU/SELECT button
This button allows you to enter the MENU, making it possible to set TV features to your preference without using the remote. This button also serves as the SELECT button when in MENU mode.
HDMI-FRONT
Use the side HDMI input for external devices such a
s Set-Top-Boxes or DVD players equipped with an
HDMI output connection (see page 14 for reference).
INPUT/EXIT button
Press this button to access the INPUT menu. Press again to exit the MENU mode.
CHANNEL selector
Press these buttons until the desired channel appears in the top right corner of the TV screen. These buttons also serve as the cursor down () and up () buttons when in MENU mode.
VOLUME level
Press these buttons to adjust the sound level. The volume level will be displayed on the TV screen. These buttons also serve as the cursor left () and right () buttons when in MENU mode.
Upgrade Card
This card slot is for future software upgrades. H
itachi will notify you if a software upgrade is required for your TV. In order to receive written notification, please complete and return your warranty card.
SD
CARD PHOTO INPUT
To view digital still pictures, please insert an card in to the card slot with pictures taken on a Digital camera, to view them on the TV screen.
SD/MMC
11
Page 12
Side Panel Controls
POWER light indicator
T
o
turn the TV ON, press the power button located on the right side of the TV set. A red stand-by indicator lamp located on the lower right corner of the front bezel is illuminated. The LCD TV is now ready for remote ON/OFF operation.
Indicating Lamp
R/C sensor
First time use
Indicating Lamp Power Status Operating
Off
Lights
Red
Lights
Blue
Lights
Orange
Blinking
Blue
REMOTE CONTROL sensor
Point
your remote at this area when selecting
channels, adjusting volume, etc.
INPUT- FRONT JACKS
INPUT- FRONT provide composite Video jacks for connecting equipment with this capability,
such as a DVD player or Camcorders.
OFF. When the TV set is unplugged from AC line.
OFF
.
(Stand-by)
On
Off
(Power Saving)
When the TV set is plugged to the AC line.
TV POWER is ON ; picture is shown.
TV POWER is ON with no signal input
except antenna (no sync. signal).
On When TV receives the IR signal from R/C.
NOTES: 1
12
. Your HITACHI LCD TV will appear to be turned OFF (lights orange) if there is no video input
when INPUT : 1, 2, 3, Front and HDMI 1, 2 , Front. Check the Power Light to make sure the TV
is turned off or in Stand-by mode (lights red) when not in use.
2. Remote Control can not turn ON/OFF the “MAIN POWER” of the TV.
Page 13
Rear Panel Connections
Antenna
To switch between Cable and Air input, go to the Channel Manager option to change the signal source CABLE or AIR.
Audio/Video Inputs 1, 2 and 3
By using the INPUTS button, the CURSOR PAD ( and ), and the SELECT button or CURSOR PAD of the remote control, you can select each video source. Use the audio and video inputs to connect external devices, such as VCRs, camcorders, laserdisc players, DVD players etc. (if you have mono sound, insert the audio cable into the left audio jack).
Input
First time use
MONITOR OUT & AUDIO OUT
These jacks provide fixed audio and video signals (CABLE/AIR or INPUTS ) which are used for recording. Use the S-VIDEO output for high quality video output. Component signal to Input 2 and 3, and HDMI inputs will not have monitor output.
Optical Out (Digital Audio)
This jack provides Digital Audio Output for your audio device that is Dolby
® Digital and PCM
compatible, such as an audio amplifier.
OTE: *Manufactured under license from Dolby
N
L
aboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
S-VIDEO Input 1
Input 1 provide S-VIDEO (Super Video) jacks for connecting equipment with S-VIDEO output capability.
OTE: 1. You may use VIDEO or S-VIDEO inputs to
N
c
onnect to INPUT 1 , but only one of
these inputs may be used at a time.
2. S-VIDEO output may be used for
recording, only when the input is of S-VIDEO type.
HDMI 1, 2 (High Definition Multimedia
Interface) ABOUT HDMI – HDMI is the
next-generation all digital interface for consumer electronics. HDMI enables the secure distribution of uncompressed high-definition video and multi­channel audio in a single cable. Because digital television (DTV) signals remain in digital format, HDMI assures that pristine high-definition images retain the highest video quality from the source all the way to your television screen.
Use the HDMI input for your external devices such as Set-Top-Boxes or DVD players equipped with an HDMI output connection.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
OTE: 1. The HDMI input is not intended for use
N
with
personal computers.
2. Only DTV formats such as 1080p, 1080i, 720p, 480i and 480p are available for HDMI input.
Component: Y-P
BPR Inputs
INPUTS 2 and 3 provide Y-PBPR jacks for
connecting equipment with this capability, such as a DVD player or Set Top Box. You may use composite video signal for both inputs.
OTE: 1. Do not connect composite VIDEO and
N
S
-VIDEO to INPUT 1 at the same time.
S-VIDEO has priority over VIDEO input.
2. Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TV’s P input and the components R-Y output to the TV’s P
3
Your component outputs may be labeled
.
R input.
Y-CBCR. In this case, connect the component CB output to the TV’s PB input and the component CR output to the TV’s PR input.
4. It may be necessary to adjust TINT to obtain optimum picture quality when using the Y-PBPR inputs (see page 40).
5. To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-P
BPR jacks and HDMI
Input.
6. INPUT 2 , and 3 (Y/VIDEO) can be used for composite video and component video input.
For Special AV control use only.
For Factory use only.
Power Swivel Connector
Connect from here the Power Swivel cable (provided) to the Table Top Stand Base swivel slot.
B
13
Page 14
First time use
Connecting External Video Sources
The SIDE panel jacks are provided as a convenience to allow you to easily connect HDMI or DVI signals f
rom a DVD, Set Top Box , Video Game as shown in the following examples (When connecting DVI signal it will
need to connect the audio output into the side Audio Input jacks) :
A) Connecting HDMI signal.
SIDE INPUT PANEL
Note : Special device cables will be
according to the own device specifications.
PHOT
O INPUT
B) Connecting DVI signal.
SIDE INPUT PANEL
PHOTO INPUT
Back of
HDTV Set-Top-Box or DVD Player
DVI to HDMI
Cable
OUTPUT CAPABILITY
DVD , Set Top Box,
Video Game Console.
DIGITALOUTPUT
HDMI DIGIT
AL
AUDIO OUTPUT
R
L
Note : Special device cables will be
according to the own device specifications.
DVI DIGITAL
OUTPUT CAPABILITY
DVD , Set Top Box,
Video Game Console.
NOTE: 1. Completely insert connection cord plugs when connecting to side panel jacks.
played back picture may be abnormal.
14
If you do not, the
Page 15
Connecting External Video Sources
The exact arrangement you use to connect the VCR, camcorder, laserdisc player, DVD player, or HDTVSet Top Box to your LCD TV is dependent on the model and features of each component. Check the owner’s manual of each component for the location of video and audio inputs and outputs.
The following connection diagrams are offered as suggestions. However, you may need to modify them to accommodate your particular assortment of components and features. For best performance, video and audio cables should be made from coaxial shielded wire.
Before Operating External Video Source
Connect an external source to one of the INPUT terminals, then press the INPUTS button to show the
INPUTS menu. Use the CURSOR PAD ( and ) to select the Input of your choice. Then press the SELECT button or the CURSOR PAD to confirm your choice (see page 25).
HDMI 2 HDMI-Front
Cable
Air /
Input 1
Move SEL Sel.
Input 2
specifications.
Note : Special device cables will be
according to the own device
Video Game
Video Camera
COMPOSITE VIDEO
OUTPUT CAPABILITY
DVD , Video Game
Console.
OUTPUT
R L
Video
L/Mon o input jack .
Note : For Monoaural devices, please
connect Audio signal cable into
PHOTO INPUT
The SIDE panel jacks are provided as a convenience to allow you to easily connect a camcorder , DVD, Video Game
and a VCR as shown in the following examples:
SIDE INPUT PANEL
First time use
NOTE:1. Completely insert connection cord plugs when connecting to side panel jacks. If you do not, the
played back picture may be abnormal.
15
Page 16
Rear Panel Connections
First time use
DVD Player
Y
P
B
OUTPUT
/C
P
B
/C
L R
R
OUTPUT CAPABILITY
AUDIO OUT
R
DIGITAL
DIGITAL OUTPUT
DVI
to
HDMI
HDMI DIGITAL
OUTPUT CAP
HDMI OUTPUT
ABILITY
HDMI
to
HDMI
Optional
S-VIDEO
VCR #2
V L R
INPUT
Y PB P
OUTPUT
L R
R
HDTV Set-Top Box
NOTE: Cables are optional, except when specified.
16
Optional
S-VIDEO
OUTPUT
V L R
VCR #1
Outside
Antenna
or
Cable TV coaxial cable
ANT
IN
2-Way signal splitter
Page 17
Tips on Rear Panel Connections
• S-VIDEO, Y-PBPR, or HDMI connections are provided for high performance laserdisc players, VCRs etc. that
h
ave this feature. Use these connections in place of the standard video connection if your device has this
feature.
• If your device has only one audio output (mono sound), connect it to the left audio jack on (L/(MONO)) the Rear Panel.
• Refer to the operating guide of your other electronic equipment for additional information on connecting your hook-up cables.
• A single VCR can be used for VCR #1 and VCR #2, but note that a VCR cannot record its own video or line
output (INPUT: 1 in the example on page 16). Refer to your VCR operating guide for more information on
line input-output connections.
• Connect only 1 component (VCR, DVD player, camcorder, etc.) to each input jack.
• COMPONENT: Y-P DVD players and set-top-boxes. Use these connections in place of the standard video connection if your device has this feature.
• Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TV’s PBinput and the components R-Y output to the TV’s PRinput.
• Your component outputs may be labeled Y-C TV’s PBinput and the components CRoutput to the TV’s PRinput.
• It may be necessary to adjust TINT to obtain optimum picture quality when using the Y-PBPRinputs. (See
page 40).
• To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-PBPR and HDMI input jacks.
Input HDMI 1, HDMI 2 or HDMI FRONT can accept HDMI signal.
• S-VIDEO monitor output may be used for recording only when the input is of S-VIDEO type.
(Input 2 & 3) connections are provided for high performance components, such as
BPR
. In this case, connect the components CBoutput to the
BCR
First time use
When using a HDMI input from a Set-Top-Box, it is recommended to use a 1080p, 1080i or 720p input signal.
When HDMI input a 1080p signal, it is recommended that the length of the cable be less than 5 meters.
INSTALLATION RECOMMENDATION:
1. Video signals fed through a VCR may be affected by copyright protection systems and the picture
will be distorted on the television.
2. Connecting the television directly to the Audio /Video output of a Set-Top-Box will assure a more
normal picture.
17
Page 18
Connecting External Video Sources
CONNECTING A VIDEO AND STEREO AUDIO
SOURCE TO INPUT1 ~ INPUT-FRONT
1.
Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack, as shown on the Rear Panel to the right.
2. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT (AUDIO/R) jack.
First time use
3. Connect the cable from the AUDIO OUT L of the VCR or the laserdisc player to the INPUT (AUDIO/L) jack.
4. Press the INPUTS button, then select INPUT 1 2,3 or Front from the INPUTS menu to view the program from the VCR or laserdisc player.
5. Select CABLE or AIR from the INPUTS menu to return to the last channel tuned.
Cable or Air signal
Back of
VCR
Video
VCR
OUTPUT
NOTE: 1.
Completely
insert the connection cord plugs when connecting to rear panel jacks. The picture and
sound that is played back will be abnormal if the connection is loose.
2. A single VCR can be used for VCR #1 and VCR #2 (see page 16) but note that a VCR cannot record
its own video or line output. Refer to your VCR operating guide for more information on line input­output connections.
. When INPUT 2 or 3 are used, it is necessary to connect the video output of the device to the
3
Y/VIDEO input jack of the TV .
CONNECTING AN S-VIDEO AND STEREO AUDIO SOURCE TO INPUT 1
1.
Connect the cable from the S-VIDEO OUT of the S-VHS VCR or the laserdisc player to the INPUT (S-VIDEO) jack, as shown on the Rear Panel to the right.
2. Connect the cable from the AUDIO OUT R of
the VCR or the laserdisc player to the INPUT (AUDIO/R) jack.
3. Connect the cable from the AUDIO OUT L of
the VCR or the laserdisc player to the INPUT (AUDIO/L) jack.
4. Press the INPUTS button, then select INPUT 1
from the INPUTS menu to view the program from the VCR or laserdisc player.
5. Select CABLE or AIR from the INPUTS menu
to return to the last channel tuned.
NOTE: 1.
Completely
insert the connection cord plugs when connecting to rear panel jacks. The picture and
sound that is played back will be abnormal if the connection is loose.
2. A single VCR can be used for VCR #1 and VCR #2 (see page 16), but note that a VCR cannot record
its own video or line output. Refer to your VCR operating guide for more information on line input­output connections.
18
Cable or
Air signal
Back of VCR or
Laserdisc Player
Video
R L
S-VIDEO
OUTPUT
VCR or Laserdisc Player
Page 19
Connecting External Video Sources
CONNECTING A COMPONENT SOURCE WITH HDMI OR DVI CAPABILITY TO HDMI 1, HDMI 2 OR HDMI FRONT
1
. Connect the HDMI or DVI to HDMI connection
cable from the output of the HDTV set top box or DVD player to the HDMI input as shown on the Rear panel below.
2. With DVI output, connect the cable from the AUDIO OUT R of the HDTV set top box or DVD player to the INPUT (AUDIO/R) jack as shown on the Rear Panel below.
3. With DVI output, connect the cable from the AUDIO OUT L of the HDTV set top box or DVD player to the INPUT (AUDIO/L) jack as shown on the Rear Panel below.
4. Press the INPUTS button, then select HDMI 1, 2 or FRONT to view the program from the HDTV SET TOP BOX or DVD player.
5. Select CABLE or AIR from the INPUTS menu
to return to the last channel viewed.
HDMI input
or
HDMI C
able
DIGITAL OUTPUT
Back of HD
TV Set-Top-Boxor
DVD Player
NOTE: 1
. Completely insert the connection cord
plugs when connecting to rear panel jacks. The picture and sound that is played back will be abnormal if the connection is loose.
2. The HDMI input on HDMI 1 , 2 and FRONT contains the copy protection system called High-bandwidth Digital Content Protection (HDCP). HDCP is a cryptographic system that encrypts video signals when using HDMI connections to prevent illegal
copying of video contents.
3. HDMI is not a “NETWORK” technology. It establishes a one-way point-to-point
connection for delivery of uncompressed
video to a display.
4.
The connected digital output device controls the HDMI interface so proper set-up of device user settings determines final
video appearance.
5. When using a DVI to HDMI cable, connect the Audio Out L and R cables at the same INPUT
(1 , 2 or Front) as your HDMI INPUT(1 , 2 or Front). (For HDMI-FRONT see page 14 for reference).
First time use
HDTV Set-Top-Box or DVD Player
DVI to HDMI Input
Back of HDTV Set-Top-Box or DVD Player
OUTPUT
L R
HDTV Set-Top-Box or DVD Player
DIGITAL OUTPUT
DVI to HDMI
Cable
CABLE
or
Air signal
or
CABLE
or
Air signal
19
Page 20
Connecting External Audio/Video Devices
CONNECTING A COMPONENT AND STEREO AUDIO SOURCE TO INPUT 2 or 3 :
Y-PBPR.
1. Connect the cable from the Y OUT of the Laserdisc/DVD player or HDTV set top box to the INPUT (Y) jack, as shown on the Rear panel below.
NOTE: 1
. Completely insert the connection cord
plugs when connecting to rear panel jacks. The picture and sound that is played back will be abnormal if the connection is loose.
2. See page 17 for tips on REAR PANEL
2. Connect the cable from the PB/CBOUT or B-
CONNECTIONS.
Y OUT of the Laserdisc/DVD player or HDTV set top box to the INPUT (PB)jack.
First time use
3. Connect the cable from the PR/CROUT or R­Y OUT of the Laserdisc/DVD player or HDTV set top box to the INPUT (PR) jack.
4. Connect the cable from the AUDIO OUT R of the Laserdisc/DVD player or HDTV set top box to the INPUT (AUDIO/R) jack.
5. Connect the cable from the AUDIO OUT L of the Laserdisc/DVD player or HDTV set top box to the INPUT (AUDIO/L) jack.
6. Press the INPUTS button, then select INPUT 2 or 3
from the INPUTS menu to view the program from the Laserdisc/DVD player or HDTV set top box.
7. Select CABLE, AIR to return to the last channel tuned.
20
CABLE
or
Air signal
AUDIO
R
Back of DVD Player
OUTPUT
L
PR/CR
VIDEO
DVD Player
PB/CB Y
OR
OUTPUT
L
R Y P B P
HDTV Set-Top Box
R
Page 21
Connecting External Audio/Video Devices
CONNECTING A VIDEO AND MONAURAL AUDIO SOURCE TO INPUT 1 ~ FRONT INPUT
1.
Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack, as shown on the Rear Panel on the right.
2. Connect the cable from the AUDIO OUT of the VCR or the laserdisc player to the INPUT (MONO)/L(AUDIO) jack.
3. Press the INPUTS button, then select INPUT 1 2,3 or Front from the INPUTS menu to view the program from the VCR or the laserdisc player.
First time use
4.
Select CABLE or AIR from the INPUTS menu
to return to the previous channel.
(For INPUT FRONT please see page 15 for reference).
CONNECTING AN EXTERNAL AUDIO AMPLIFIER
T
o monitor the audio level of the LCD TV to an external audio amplifier, connect the system as shown on the right. The “OPTICAL OUT” from the
Rear Panel is a fixed output. The Volume of the
amplifier is controlled by the amplifier, not by the LCD Television. The OPTICAL OUT terminal
outputs all audio sources with Optical IN capability.
1. Connect an optical cable from the Optical out to
the Optical input of a separate Stereo System Amplifier as shown on the Rear Panel on the right.
CONNECTING MONITOR OUT
The MONITOR OUT terminal outputs video and
dio of CABLE/AIR and INPUTS 1, 2, 3 and Front.
u
a It does not output component and HDMI video.
CABLE or Air signal
CABLE
or
Air signal
Back of
VCR
VIDEOOUT AUDIO OUT
OUTPUT
VCR
Stereo System Amplifier
OPTICAL
Stereo System Amplifier
or DVD Player
IN
1. Connecting S-Video: Connect the cable from the S-VIDEO OUT of the Rear Panel to the INPUT (S-VIDEO) jack, of the VCR or Laserdisk player.
Connecting Video: Connect the cable from the VIDEO INPUT of the VCR or the laserdisc player to the VIDEO out jack on the TV Rear Panel.
2. Connect the cable from the AUDIO IN R of the VCR or the laserdisc player to the OUTPUT (AUDIO/R) jack on the TV Rear Panel.
3. Connect the cable from the AUDIO IN L of the VCR or the laserdisc player to the OUTPUT (AUDIO/L) jack on the TV Rear Panel.
NOTE: W
hen making video connections, connect S-Video only or Video only. If both are connected, S-Video
priority.
takes
CABLE
or
Air signal
Optional
R L V
S-VIDEO
INPUT
VCR or other external
components
21
Page 22
The Remote Control
In addition to controlling all the functions on your HITACHI LCD TV, the new remote control is designed to operate different types of VCRs, cable
boxes, set-top-boxes, satellite receivers, DVD players, and other audio/video equipment with one touch. Basic operation keys are grouped together in one
area.
To operate your LCD TV, select TV by pressing the Source button of the Source Select on the remote. The TV mode indicator will blink, indicating that the remote will now control your television.
To operate your VCR/PVR (Personal Video Recorder), select PVR/VCR by pressing the Source button of the Source Select on the remote. The PVR/VCR mode indicator will blink, indicating that the remote will now control your VCR/PVR (see page 34 for instructions on how to program the remote to control your VCR/PVR).
To operate your cable box, select SAT/CBL by pressing the Source button of the Source Select on the remote. The SAT/CBL mode indicator will blink, indicating that the remote will now control your cable box (see page 31 for instructions on how to program the remote to control your cable box).
To operate your set-top-box or satellite receiver select SAT/CBL by pressing the Source button of the Source Select on the remote. The SAT/CBL mode indicator will blink, indicating that the remote will now control your set-top-box or satellite receiver (see page 32 for instructions on how to program the remote to control your set-top-box or satellite receiver).
To operate your DVD player, select DVD by pressing the Source button of the Source Select on the remote. The DVD mode indicator will blink, indicating that the remote will now control your DVD Player (see page 33 for instructions on how to program the remote to control your DVD player).
The Remote Control
22
Page 23
How to Use the Remote to Control Your TV
POWER button
Press this button to turn the TV set on or off when
the remote is in TV mode. (See page 22 for instructions on how to set the remote control to TV mode).
 
19
 
 
 
 
MODE Indicator
Turns on or blinks three times to show remote control
mode.
SOURCE SELECT button
Press this button to select remote control mode.
PAUSE
Pr
Press the EXIT button to return the picture to motion. Press the PAUSE button repeatedly to cycle through the three different freeze modes (see
page 30).
button
ess the PAUSE button to freeze the picture.
Freeze
The Remote Control
Fr
1
8
DA
Y/NIGHT
Press this button to toggle between Day (Normal), Day (Dynamic) and Night picture mode settings. Select DAY for day time viewing with more brightness and contrast to compete with room light. Select NIGHT for night time viewing with less brightness and contrast for a more detailed picture (see page 40 for settings changes).
button
eeze
Freeze
Fr
Freeze
eeze
NOTE: For automatic DAY/NIGHT picture mode settings,
see pag
e 54.
23
Page 24
How to Use the Remote to Control Your TV
IMAGE INPUT
IMAGE INPUT
IMAGE INPUT
IMAGE INPUT
1
2
16:9 STANDARD 2
Use this aspect mode to display 16:9 sources like HDTV and DVD’s preserving the original 16:9 aspect ratio showing 100% of the size.
ASPECT button
Press this button to quickly change the picture format ASPECT ratio. Depending on the input signal format received, the picture format ratio allows you to adjust the images through the following options.
Antenna-Analog Channel
S-Video/Video Input
(Auto Aspect: Off)
HDMI-480i/480p Input (Auto Aspect: Off)
Component-480i/480p Input (Auto Aspect: Off)
Note: Please see Appendix A
on page 146-147.
Antenna-Digital Channel (4:3)
S-Video/Video 4:3/Letter
Input (Auto Aspect: On)
HDMI-480i/480p 4:3/
Letter Input (Auto Aspect: On)
Component-480i/480p 4:3/
Letter Input (Auto Aspect: On)
Note: Please see Appendix A
on page 146-147.
S-Video/Video 16:9 Input
(Auto Aspect: On)
HDMI-480i/480p 16:9 Input
(Auto Aspect: On)
Component-480i/480p
16:9 Input (Auto Aspect: On)
Note: Please see Appendix A
on page 146-147.
Antenna-Digital Channel (16:9)
HDMI-720p/1080i/1080p Input
Component-720p/1080i
Input
Note: Please see Appendix A
on page 146-147.
NOTE: 1. The Aspect Style in all video inputs have independent Aspect Style setting.
2. Vertical position adjustments are directly available when you choose 4:3 EXPANDED/ZOOM1/ZOOM2 or 16:9 ZOOM aspect style (see also page 42).
4:3 STANDARD
Use this aspect mode to display conventional (4:3) images. Side panels (gray areas) are placed to the left and right of the image to preserve the original aspect ratio of the source.
4:3 EXPANDED
Use this aspect mode to display conventional (4:3) sources by linearly increasing image expansion from the center towards the edges of the display area in order to fill it.
4:3 ZOOM1/ZOOM2
Use these aspect modes to zoom in on conventional (4:3) sources.
16:9 STANDARD 1
Use this aspect mode to display 16:9 sources like
HDTV and DVD’s preserving the original 16:9 aspect ratio showing 95% of the size.
16:9 ZOOM
Use this aspect to Zoom-in once while in 16:9 aspect.
3. When displaying 16:9 STANDARD 2 it may appear lines at the edge of the picture this is normal operation of the TV.
1
18
The Remote Control
24
Page 25
How to Use the Remote to Control Your TV
NOTE: 1. Press the INFO button again or the EXIT
button to return to normal viewing.
2. The Aspect setting will not be shown if the channel is locked.
S-IN: 1
480i 3:17PM
Auto
DIGITAL CHANNELS
Digital Closed Caption This icon will appear only when receiving a Digital Broadcast with
Closed Captioning.
Show Name Air 8
3:00PM-
3:30PM KXYZ-HD
ST TV-G 480i 3:17PM
Auto STEREO
Program Run Time
Program Information
Broadcast
Rating
Picture Format
Audio
Broadcast
Main Picture Source and channel indication
Broadcast channel identication Clock
Closed
Caption setting
Audio Source
Selection
ANALOG CHANNELS
Show Name Air 15-1
3:00PM-
3:30M KPBS-HD
ST 1080i 3:17PM
Auto
Program Run Time
Program Information
Broadcast
Rating
Picture Format
Audio
Broadcast
Main Picture Source and channel indication
Broadcast channel identication Clock
Closed
Caption setting
DTvCC TV-G
REGION 5
Alternate
Rating
Program Description
(Press INFO again for a more detailed description)
When a Component Video: Y-PbPr
Input is
connected to INPUT 3
Input Signal
Format
Y-PBPR: 3
480i 3:17PM
Auto
When an S-VIDEO Input is connected
to INPUT 1
MENU button
The MENU button will start the On-Screen Display.
EXIT button
This button will exit all On-Screen Displays.
INPUTS button
When the remote control is in TV mode, press this button to access the INPUTS menu. Use the CURSOR and SELECT buttons to scroll and select the inputs that are being used. Pressing the INPUTS button repeatedly will also cycle through the Inputs menu items. Then press the SELECT button to select.
INPUT 1 Select to choose INPUT 1. INPUT 2 Select to choose INPUT 2. INPUT 3 Select to choose INPUT 3.
INPUT- FRONT Select to choose side INPUT . HDMI 1 Select to choose HDMI 1 INPUT. HDMI 2 Select to choose HDMI 2 INPUT.
HDMI-Front
Photo Input
Input 2
Air / Cable
Move SEL Select
Input 1
HDMI- FRONT Select to choose side HDMI INPUT.
AIR/CABLE Select between Air or Cable signal.
CURSOR buttons/SELECT button
All the On-Screen Display features can be set or adjusted by using the CURSOR buttons and the SELECT button, except for numeric entries. Press the CURSOR buttons toward desired direction and press the SELECT button to select.
PICTURE-IN-PICTURE button
See separate section on pages 29-30 for a more detail description.
CLOSED CAPTIONS (CC) button
Use this button to display the dialogue, narration, and/or sound effects of a television program or home
GUIDE button
[Cable Box (CBL), Satellite Receiver (SAT)/ Set-Top-Box (STB) mode only]
The use of this button is only applicable when the
remote control is in (CBL) and (SAT/STB) mode.
video which are displayed on the TV screen when available. Your local TV program guide denotes these programs as or .
PHOTO INPUT Select to access your pictures from a
digital camera, MMC/SD Flash memory or memory card connected to the Photo
Input in the side panel of the LCD
TV (see pages 26-27).
INFO button
Press this button when you want to check the channel being received, the picture source, if
the channel has stereo (ST) or second audio program (SAP), the time, CHANNEL ID and if the TIMER is set.
A
D
Analog Channel
Digital channel
Press this button to access the Channel Guide of the (CBL), and (SAT/STB).
The Remote Control
25
Page 26
How to Use the Remote to Contr
HDMI 1 HDMI-Front
Photo Input
Input 1 Move SEL Sel.
Air / Cable
No. 02/08 06/13/05 2048x1536 DSC00467
Rotate Slideshow
Picture No.
Date
Resolution
File Name
ol Your TV
PHOTO INPUT
This feature is useful for viewing digital still pictures from your digital camera, MMC/SD memory cards using the Photo Input in the side panel of the TV.
1. Press the I
NPUTS button to cycle through the INPUTS selections until the PHOTO INPUT is selected. Press the SELECT button or CURSOR PAD 왘.
2. Press the CURSOR PAD 왗 or 왘 to access the
next or previous photo.
SEL
Next
The Remote Control
3. Press the SELECT button to view THUMBNAIL.
Thumbnail [0-9] Jump
4. Use the CURSOR PAD buttons , , or and the SELECT button to navigate and select individual chosen photos.
5. Press the picture number to jump from picture to picture.
6. Press the INFO button to access PHOTO Input menu and to view Photo information.
7. Press the CURSOR PAD or and the
SELECT button to navigate and select the PHOTO Input menu.
NOTES: 1.
The maximum number of digital Photos that can be displayed is 999.
2. Press INFO button to show Picture Numbers in Thumbnail view, plus other information in individual photos.
3. The screen may show “Input device not detected” if the MMC/SD memory card is not inserted.
Please Enter
Picture Number
--
26
Page 27
How to Use the Remote to Control Your TV
ROTATE
S
elect this menu item to rotate selected photos
either clockwise (CURSOR PAD ) and counterclockwise (CURSOR PAD ).
SLIDESHOW
Select this menu item to start a slideshow of the digital photos. While the Interval sub menu is highlighted, press the SELECT button to cycle through the interval time from 5, 10 and 30 seconds. Press the SELECT button to stop on a chosen picture of the slideshow. After 30 seconds, the slideshow will resume or press the SELECT button again to continue with the slideshow.
Rotate Slideshow
Rotate
Start
Interval 5sec
The Remote Control
NOTES: 1
. Automatic contrast reduction also applies during SLIDESHOW, then press any button to
continue.
2. Photo file names modified on a computer should be 8 characters (Ex. ABCD1234.jpg). 1st character: letters; 2nd to 4th: letters or numbers; 5th to 8th: numbers. Photo files should be first placed on a sub directory name with 8 characters (Ex. 123ABCDE). 1st to 3rd: number; 4th to 8th: letters. The sub directory then should be placed on a main directory with a “dcim” file name format.
3. Supported image types are up to 3072 x 2304; JPEG format should conform with DCF Standard (Design rule for Camera File System).
4. This TV set displays only digital pictures from digital cameras which meet DCF Standard. Pictures that were copied, edited or modified on a computer may not be displayed on the TV set.
27
Page 28
How to Use the Remote to Control Your TV
VOLUME (VOL), MUTE button
Press the VOLUME button (or 왔) until you obtain the desired sound level.
To reduce the sound to one half of normal volume (SOFT MUTE) to answer the telephone, etc., press the MUTE button. Press the MUTE button again to turn the sound off completely (MUTE). To restore the sound, press the MUTE button one more time, or VOL UP (
왖).
C
l
osed Captioning will display automatically when
MUTE/SOFT MUTE is on and Closed Caption is set to AUTO (see page 59).
When the TV power is turned off at a volume level 31 or greater, the volume level will default to 30 when the TV is turned on. However, if it is set to a level 30 or less, the volume level will be at the level it was set when the TV is turned on.
CHANNEL SELECTOR/FAVORITE CHANNEL
(FAV CH)/ENTER buttons
The CHANNEL SELECTOR b
uttons are used to
select channels, lock access code, etc. Use the CHANNEL SELECTOR buttons to enter one, two, or three numbers to select channels. Enter 0 first for channels 1 to 9, or simply press the single digit channel you wish to tune then press the ENTER button for the TV to tune. Channel selection may also be performed by CHANNEL (CH) UP (
) or
CHANNEL (CH)
DOWN (
왔).
Pr
ess the FAV CH button to switch to Favorite
(FAV) channel mode. You will know you are in Favorite Channel mode when (FAV) is displayed and the displayed channel is GREEN. Press it again to return to your regular tuned channels. You can add any channel to your Favorite channel list by pressing and holding down the FAV CH button until the displayed channel turns from WHITE to highlighted GREEN. You can also delete a channel from your favorite channel list by pressing and holding down the FAV CH button until the displayed channel turns highlighted GREEN to WHITE.
(-) DASH button
LAST CHANNEL button
Press this button to toggle between the current and last channel viewed.
RECORD button
Press to record programs when the remote is in PVR/VCR mode.
Cable 6
FAV Cable 6
Cable 6
Volume 8
Soft Mute 8
Mute 8
1
8
19
Use the (-) DASH button with the CHANNEL SELECTOR buttons to enter Digital Channels that have subchannel numbers indicated by (-) DASH
(example 15-1).
1
7
The Remote Control
28
Page 29
SWAP
Main Picture
Sub Picture
To select between main picture and PIP sub picture, use the CURSOR PAD button the remote. The Orange highlighted channel display will move with every press
of the CURSOR PAD buttons.
The Picture-in-Picture feature is convenient when you want to watch more than one program at the same time.You can watch a TV program while viewing other programs from any of the video inputs.
Use connection at right to view VCR program as a sub picture while viewing another program as main picture (CABLE/AIR Digital channel).
Picture-In-Picture (PIP)
PIP Specifications Table
Digital Channel (Air or Cable)
1080i 720p 480p 480p 480i 480i 1080i 720p 480p 480p 480i 480i
16x9 16x9 16x9 4x3 16x9 4x3 16x9
1080p(*)
16x9 16x9 16x9 4x3 16x9 4x3
Component Composite S-IN H
DMI
Digital Channel
(Air or Cable)
Sub Picture
Main Picture
Component/Composite/S-lN/HDMI
SPLIT
PIP
Mode
1080i 16x9
- - - - - -
720p 16x9
- - - - - -
480p 16x9
- - - - - -
480p 4x3
- - - - - -
480i 16x9
- - - - - -
480i 4x3
- - - - - -
1080i 16x9
720p 16x9 480p 16x9 480p 4x3
Yes Yes Yes Yes Yes Yes
Ye
s Yes Yes Yes Yes Yes
1080p (*) 16x9
Yes Yes Yes Yes Yes Yes
480i 16x9 480i 4x3
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
-
-
-
-
-
-
-
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
Yes
Yes
Yes
Yes
Yes
Yes
(*) HDMI Input only
SPLIT mode PIP displays the main picture and
NOTE:
1. In SPLIT mode, press t
he CURSOR PAD ( or ) to enable the sub-picture sound.
CABLE or
AIR
Back of
VCR
OUTPUT
VCR
VIDEO OUT AUDIO OUT
Your HITACHI LCD TV incorporates one Tuner technology This feature allows you to view Digital Channels and Video inputs on both the main picture and sub picture simultaneously, with separate control. Analog channels cannot be viewed in PIP mode. Please see table below for PIP availability.
PIP button
designed for improved viewing enjoyment
Press the PIP button and a sub-picture will appear in SPLIT mode. To change back to normal viewing press the EXIT button.
The Remote Control
SPLIT MODE PICTURE-IN-PICTURE
subpicture evenly on the screen.
29
Page 30
How to Use the Remote to Control Your TV
Hot Springs Clay Mask
C/O John Doe
Run-Spa Retreat
P.O. Box 55512
Any Town, USA 98765
Check or
Money Order Only
1-800-555-1212
SPLIT FREEZE
Press the PAUSE button to freeze the picture you are currently viewing (only the right sub-picture will freeze). Press the EXIT button to return to normal viewing.
Main Picture
Sub Picture
STROBE FREEZE
Press the PAUSE button to freeze three frames of the picture you are currently viewing (only the 3 sub-pictures will freeze). Press the EXIT button to return to normal viewing. This feature is useful for viewing a moving picture that has many details, for example, a close play in a sporting event or a golf swing.
PAUSE button
Press the PAUSE button repeatedly to toggle between FREEZE modes (Main Freeze, SPLIT and STROBE). This is convenient when trying to write down the address for a mail order company, recording statistics for a sporting event, etc. To return the picture to motion, press the EXIT button.
NOTE: 1. The default FREEZE mode is the MAIN
freeze followed by the SPLIT freeze and then the STROBE freeze. The last FREEZE mode you selected before you pressed the EXIT button will be the one that comes up after pressing the PAUSE button again.
2. Each freeze frame in Strobe Freeze is delayed about 0.1 (1/10) second.
Freeze
Freeze
Freeze
Freeze
Freeze
Picture-In-Picture (PIP)
The Remote Control
MAIN FREEZE
P
ress the PAUSE button to freeze one frame of the
picture you are currently viewing and the frozen frame will show in the Main Picture. Press the EXIT button to return to normal viewing. This feature is useful for freezing a picture frame with addresses.
30
Page 31
The Remote Control for Cable Box Functions
OPERATING THE PRECODED FUNCTION FOR YOUR CABLE BOX.
T
his remote is designed to operate different types of cable boxes. You must first program the remote to match the remote system of your cable box (refer to
pages 36-37 for pre-codes).
1. Turn ON your cable box.
2. To switch to Cable (CBL) pre-coded mode, use the
SOURCE SELECT button on the remote control to position the LED light to the corresponding selection SAT/CBL.
3. Hold down the SOURCE SELECT button on the
remote and enter the four digit preset code that matches your cable box as shown on pages 36-37. Release the SOURCE SELECT button. The indicator light will flash 3 times if the code was accepted.
4. Aim the remote at the cable box and press the
POWER button. The remote will turn off your cable box when the correct four digit preset code is entered. When this occurs, the remote control is programmed for your cable box. If the cable box does not turn off, try a different four digit preset code.
5. The remote will now control your Cable box.
NOTE: 1. If your cable box cannot be operated after
performing the above procedures, your cable box code has not been precoded into the remote.
2. In the unlikely event that your cable box cannot be operated after performing the above procedures, please consult your cable box operating guide.
3. The remote control will remember the codes you have programmed until the batteries are removed fro m th e remote control. After replacing the batteries repeat the entire programming procedure as stated above.
 
PRECODED CABLE BOX buttons
These buttons transmit the chosen precoded cable
codes :
-Power
-Menu
-Exit
-Guide
EXCLUSIVE TV buttons
These buttons are for operating the TV :
-Day/Night
-Aspect
-PIP
-Pause
MY CABLE BOX CODE IS:
-Cursor & Select
-Info
-Channel Up & Down
-Last CH
-CC
-Vol Up & Down
-Mute
-Number PAD
-Enter
-Inputs (only if programmed, refer to page 35)
The Remote Control
NOTE: Refer
for operation of the buttons exclusively for the Cable Box.
to instruction manual of the Cable Box
31
Page 32
The Remote Control for Set-Top-Box/Satellite Receiver
How to Use the Remote to Control Your TV
OPERATING THE PRECODED FUNCTION FOR YOUR SET-TOP-BOX/SATELLITE RECEIVER.
T
his remote is designed to operate different types of set-top-box/satellite systems. You must first program the remote to match the remote system of your set-
top-box/satellite systems (refer to pages 36-37 for pre-
codes).
Functions
1. Turn ON your set-top-box/satellite systems.
2. To switch to set-top-box/satellite (SAT) pre-coded
mode, use the SOURCE SELECT button on the remote control to position the LED light to the corresponding selection SAT/CBL.
3. Hold down the SOURCE SELECT button on the
remote and enter the four digit preset code that matches your set- top-box/satellite receiver as shown on page 36-37. Release the SOURCE SELECT button. The indicator light will flash 3 times if the code was accepted.
4. Aim the remote at the set-top-box/satellite receiver
The Remote Control
and press the POWER button. The remote will turn off your set-top-box/satellite receiver when the correct four digit preset code is entered. When this occurs, the remote control is programmed for your set-top-box/satellite receiver. If the set-top­box/satellite receiver does not turn off, try a different four digit preset code.
5. The remote will now control your set-top-box/
satellite receiver.
NOTE: 1. If your set-top-box/satellite receiver
cannot be operated after performing the above procedures, your set-top-box/ satellite receiver code has not been precoded into the remote.
2. In the unlikely event that your set-top­box/satellite receiver cannot be operated after performing the above procedures, please consult your set-top-box/satellite receiver operating guide.
3. The remote control will remember the codes you have programmed until the bat teries are removed from the remote control. After replacing the batteries repeat the entire programming procedure as stated above.
PRECODED SET-TOP-BOX/SATELLITE
RECEIVER buttons
These buttons transmit the chosen pre-coded
set-top-box/satellite codes :
-Power
-Menu
-Exit
-Guide
EXCLUSIVE TV buttons
These buttons are for operating the TV :
-Day/Night
-Aspect
-PIP
MY Satellite RECEIVER/ SET-TOP-BOX CODE IS:
-Cursor & Select
-Info
-Channel Up & Down
-Last CH
-CC
-Vol Up & Down
-Pause
-Number PAD
-Enter, Dash
-Mute
-Inputs (Only if
programmed, refer
to page 35).
32
NOTE: Refer to instruction manual of the Set-Top-
Box/Satellite Receiver for operation of the buttons exclusively for the Set-Top­Box/Satellite Receiver.
Page 33
The Remote Control for DVD Functions
OPERATING THE PRECODED FUNCTION FOR YOUR DVD PLAYER.
T
his remote is designed to operate different types of DVD players. You must first program the remote to match the remote system of your DVD player (refer to
pages 36-37 for pre-codes).
1. Turn ON your DVD player.
2. To switch to DVD pre-coded mode, use the
SOURCE SELECT button on the remote control to position the LED light to the corresponding selection DVD.
3. Hold down the SOURCE SELECT button on the
remote and enter the four digit preset code that matches your DVD player, as shown on pages 36-37. Release the SOURCE SELECT button. The indicator light will flash 3 times if the code was accepted.
4. Aim the remote at the DVD player and press the
POWER button. The remote will turn off your DVD player when the correct four digit preset code is entered. When this occurs, the remote control is programmed for your DVD player. If the DVD player does not turn off, try a different four digit preset code.
The Remote Control
5. The remote will now control your DVD player.
NOTE: 1. If your DVD player cannot be operated
after performing the above procedures, your DVD player code has not been precoded into the remote.
2. In the unlikely event that your DVD player cannot be operated after performing the above procedures, please consult your DVD player operating guide.
3. The remote control will remember the codes you have programmed until the batteries are removed from the remote control. After replacing the batteries repeat the entire programming procedure as stated above.
PRECODED DVD Buttons
These buttons transmit the chosen precoded
DVD codes :
-Power
-Menu
-Info
-Cursor & Select
EXCLUSIVE TV Buttons
These buttons are for operating the TV :
-Day/Night
-Aspect
-PIP
-Exit
MY DVD PLAYER CODE IS:
-Number PAD
-Play, Stop, Pause, RWD, FWD, Skip RWD,
Skip FWD.
-CC
-Vol Up & Down
-Mute
-Inputs (Only if programmed, refer t
o page 35)
NOTE: Refer
for operation of the buttons exclusively for the DVD Player.
to instruction manual of the DVD Player
33
Page 34
How to Use the Remote to Control Your TV
The Remote for VCR/PVR Functions
OPERATING THE PRECODED FUNCTION FOR YOUR VCR/PVR (Personal Video Recorder).
T
his remote is designed to operate different types of VCRs/PVRs. You must first program the remote to match the remote system of your VCR/PVR (refer to
pages 36-37 for pre-codes).
1. Turn ON your VCR/PVR.
2. To switch to VCR/PVR pre-coded mode, use the
SOURCE SELECT button on the remote control to position the LED light to the corresponding selection PVR/VCR.
3. Hold down the SOURCE SELECT button on the
remote and enter the four digit preset code that matches your VCR/PVR, as shown on pages 36-37. Release the SOURCE SELECT button. The indicator light will flash 3 times if the code was accepted.
4. Aim the remote at the VCR/PVR and press the
POWER button. The remote will turn off your PVR
The Remote Control
when the correct four digit preset code is entered. When this occurs, the remote control is programmed for your VCR/PVR. If the VCR/PVR does not turn off, try a different four digit preset code.
5. The remote will now control your VCR/PVR.
 
NOTE: 1. If your VCR/PVR cannot be operated after
performing the above procedures, your VCR/PVR code has not been precoded into the remote.
2. In the unlikely event that your VCR/PVR cannot be operated after performing the above procedures, please consult your VCR/PVR operating guide.
3. The remote control will remember the codes you have programmed until the batteries ar e removed from the remote control. After replacing the batteries repeat the entire programming procedure as stated above.
PRECODED VCR/PVR Buttons
These buttons transmit the chosen precoded VCR/PVR codes :
-Power
-Menu
-Exit
-Info
-Record -RWD
EXCLUSIVE TV Buttons
These buttons are for operating the TV :
-Day/Night
-Aspect
-PIP
MY VCR/PVR CODE IS:
-Cursor & Select
-Channel Up & Down
-Number PAD
-Last CH
-CC
-Vol Up & Down
-Mute
-Enter
-Dash (-)
-Play,Pause,Stop
-FWD,Skip FWD
-Inputs (only if programmed, refer to page 35)
34
NOTE: Refer
for operation of the buttons exclusively for the VCR/PVR.
to instruction manual of the VCR/PVR
Page 35
How to Use the SOURCE
INPUT ACCESS
T
his optional feature allows the user of the remote
control to setup it’s SOURCE SELECT button to access
the specified input of the TV. Setup for this feature is applicable to the remote control’s normal mode only and
only applies to the DVD, PVR/VCR and SAT/CBL modes.
1. Select the desired device mode (DVD, PVR/VCR,
SAT/CBL) by using your SOURCE SELECT button to position the LED indicator to the corresponding
selection.
SELECT Button
, , 
, , 
2. Hold down the SOURCE SELECT button on the remote and enter the four digit preset code that matches your device as shown on pages 36-37.
3. Then enter the assigned input number (1-7) that the device is related to (refer below to Table 1).
4. Release the SOURCE SELECT button.
5. If done correctly, the device LED indicator will blink 3 times to confirm proper setup.
6. The remote will now control the desired device.
7. Pressing the INPUTS button will now access the
video input of the desired device.
SETUP EXAMPLE (Hitachi DVD with precode 0573 connected to INPUT 1 of the TV)
Select DVD mode by using your SOURCE SELECT
button to position the LED indicator to DVD.
Hold down the SOURCE SELECT button and
press the numbers 0, 5, 7 and 3.
Then press the number 1 for the assigned input
number of the DVD player.
Table 1
INPUT
INPUT 1 1 INPUT 2 2 INPUT 3 3 INPUT- FRONT 4
DMI 1 5
H H
DMI 2 6
HDMI- FRONT 7
ASSIGNMENT NUMBER
The Remote Control
Release SOURCE SELECT button.
If done correctly, the device LED indicator will blink
3 times to confirm proper setup.
The remote will now control the DVD player.
Press the INPUTS button to instantly access the
video input of your DVD on Input 1.
NOTE: 1. This feature is optional
2. Assigned input numbers can be used more than once if applicable.
35
Page 36
A
BC ........................ 0003,0008, 0011 GOI.................................0775, 1775 1278 Panasonic ..................... 1062,0035,0162, 0225,
A
mericast ................ 0899 Goodmans .....................1246 Daytron ......................... 0020 0616,1035, 1162,1262
A
mino ......................1602 Hisense ..........................1535 Dell ................................1972 Penney .......................... 0035,0037, 0240,0042,
Bell South ............... 0899 Hitachi ........................... 0819,1250 Denon ........................... 0042 0038,1035,1237
Clearmaster ............ 0883 HTS ...............................0775, 1775 DirecTV ......................... 0739 Pentax ...........................0042,0065, 0105
ClearMax ................ 0883 Hughes Network System 1142,0749,1749,1442 Durabrand ..................... 0039,0038 Philco ............................ 0035,0479
Coolmax ................. 0883 iLo...................................1535 Dynatech ....................... 0000 Philips ........................... 0035,0081,0062, 0618,
Digeo ...................... 1187 JVC.................................0775,1775 Electrohome ..................0037 0739,1081,1181
Director ................... 0476 LG ..................................1226,1414 Electrophonic ................ 0037 Pilot ............................... 0037
General Instrument.. 0476,0810,0276,0003, Magnavox ......................0724,0722 Emerex ..........................0032 Pioneer ......................... 0067
0011
Memorex ....................... 0724 Emerson ........................0037,0184, 0000,0121, Polk Audio ..................... 0081
GoldStar...................0144 Mitsubishi ...................... 0749 0043,0209,0002,0278, Portland .........................0020
Hamlin .....................0009, 0273 Motorola ........................ 0869 0061,0208,
0479,0561, Presidian ........................1593
Hitachi ..................... 0011,1421 NEC ...............................1270 0593,1278,1479, 1593, Profitronic ...................... 0240
i3 Micro ....................1602 Next Level .....................0869 Fisher ............................ 0047,0104 Proscan ......................... 0060,0202,0760, 0761
Jerrold ..................... 0476,0810, 0276,0003 Pace ..............................0887 Fuji ................................ 0035,0033 1060
0012,0011
Panasonic ..................... 0247,0701 Funai ............................. 0000,0593,1593 Protec ............................0072
Memorex ................. 0000 Paysat ........................... 0724 Garrard ......................... 0000 Pulsar ............................ 0039
Motorola .................. 1376,0476, 0810,0276 Philips ............................1142,0749, 1749,0724, Gateway ........................ 1972 Quarter .......................... 0046
1187,1254, 1106 1076,0722, 0099,1442 GE ................................. 0060,0035, 0240,0065, Quartz ........................... 0046
Multitech ..................0883 Proscan .........................0392,0566 0202,0760, 0761,0807, Quasar .......................... 0035,0162,1035, 1162
MultiVision ...............0012 Proton ............................1535 1035,1060 RadioShack .................. 0000, 1037
Myrio ........................1602 RadioShack ...................0869 Go Video ....................... 0432,0526 Radix ............................. 0037
Pace ........................1877, 0237,0008 RCA ...............................0566,0855, 0143,1392 GoldStar ........................ 0037,0038,1237 Randex ..........................0037
Panasonic ............... 0000,0107 Samsung .......................1377,1276, 1108,1109, Gradiente ...................... 0000 RCA ...............................0060,0240, 0042,0149,
Paragon ...................0000 1442, 1609 Harley Davidson ............0000 0065,0105, 0106,0202,
Philips ......................1305,0317 Sanyo ............................ 1219 Harman/Kardon .............0081,0038 0760,0761,0807, 0880,
Pioneer ....................1877,0877, 0144,0533 SKY ...............................0856 Harwood ........................0072 1035,1060
Pulsar.......................0000 Sony .............................. 0639,1639,1640 Headquarter .................. 0046 Realistic .........................0035,0037,0048, 0047,
Quasar..................... 0000 Star Choice ...................0869 Hewlett Packard............. 1972 0000,0104, 0046,0062
RadioShack .............0883 Tivo ............................... 1142,1442 HI-Q ...............................0047 ReplayTV ...................... 0614,0616
RCA .........................1256 Toshiba ......................... 0749,1749,0790,1285 Hitachi ...........................0000, 0042,0041,0065, Ricavision ...................... 1972
Regal .......................0279,0273 UltimateTV .................... 1392, 1640 0089,0105,0543, 0544 Runco ............................ 0039
Rembrandt .............. 0011 Uniden ...........................0724,0722 Howard Computers ....... 1972 Samsung .......................0240,0045, 0739,1014
Runco ..................... 0000 US Digital .......................1535 HP .................................1972 Sanky ............................ 0048,0039
Samsung .................0144 USDTV ...........................1535 Hughes Network System.0042,0739 Sansui ........................... 0000,0067,0209,0041,
Scientific Atlanta ......1877,0877,0477, 0008 Voom .............................0869 Humax .......................... 0739 0271,0479, 1479
Sejin ........................ 1602 Zenith ............................ 0856,1856 Hush ..............................1972 Sanyo ............................ 0047,0240, 0104,0046,
Signature................. 0011 iBUYPOWER .................1972 0159
Sony ........................1006 DBS/PVR Codes Jensen .......................... 0041 Scott .............................. 0184,0045,0121,0043
Starcom .................. 0003 Combo BRAND JVC ............................... 0067,0041,0008 Sears .............................0035,0037, 0047,0000,
Supercable ..............0276 DirecTV ..........................1377,0392,0639, 1142, KEC ...............................0037, 0278 0042,0104,0046, 0105,
Supermax ................0883 1076,0099, 1392,1442, Kenwood ....................... 0067,0041,0038 1237
Thomson ................. 1256 1640 KLH ............................... 0072 Sharp .............................0048,0062,0807, 0848
Tocom ..................... 0012 Dish Network System ....1505, 0775 Kodak ............................0035,0037 Shintom ......................... 0072
Torx .........................0003 Dishpro ..........................1505,0775 LG ................................. 1037 Shogun ..........................0240
Toshiba ................... 0000 Echostar ........................1505,0775 Linksys .......................... 1972 Singer ............................0072
Tristar ......................0883 Expressvu ..................... 0775 Lloyd's ........................... 0000,0208 Sonic Blue ..................... 0614,0616
V2 ............................0883 Hughes Network System..1142,1442 Logik ............................. 0072 Sony ..............................0035,0032, 0033,0000,
Viewmaster ............. 0883 Motorola ........................0869 LXI ................................ 0037 0636,1032,
1232,1972
Vision ...................... 0883 Philips ............................1142,1442 Magnasonic .................. 0593,1278 Stack 9 .......................... 0009,1972
Vortex View .............0883 Proscan ......................... 0392 Magnavox ..................... 0035,0039,0081, 0000, STS ............................... 0042
Zenith ...................... 0000,0525, 0899 RCA ...............................1392 0149,0563, 0593,1593, Sylvania .........................0035, 0081,0000,0043,
Samsung .......................1442 1781 0593, 1593,1781
Cable/PVR Codes
Sony ..............................0639,1640 Magnin .......................... 0240 Symphonic .................... 0000,0593,1593
Combo BRAND
Star Choice ................... 0869 Marantz ......................... 0035,0081 Systemax ...................... 1972
A
mericast ................ 0899
Marta .............................0037 Tagar Systems .............. 1972
Digeo ....................... 1187
VCR BRAND Codes Matsushita .................... 0035, 0162,1162 Tatung ........................... 0041
General Instrument ..0810
ABS ...............................1972 Media Center PC .......... 1972 Teac .............................. 0000,0041
Jerrold ..................... 0810
Admiral ..........................0048,0209 MEI ............................... 0035 Technics ........................0035,0162
Motorola .................. 1376,0810,1187,1106
Adventura ..................... 0000 Memorex ...................... 0035,0162,0037, 0048, Teknika ..........................0035,0037,0000
Pace ........................ 1877,0237
Aiko ............................... 0278 0039,0047, 0240,0000, Thomas ......................... 0000
Pioneer .................... 1877,0877
Aiwa .............................. 0037,0000,0124, 0307 0104,0209, 0046,0307, Tivo ............................... 0618,0636, 0739,1996
RCA ......................... 1256
Akai ............................... 0041,0061,0106,0175 0479,1037, 1162,1237 TMK .............................. 0240,0208
Scientific Atlanta ...... 1877,0877
Alienware ...................... 1972 1262 Toshiba ......................... 0045, 0043,0845,1008,
Sony ........................ 1006
America Action ..............0278 MGA ............................. 0240,0043, 0061 1145,1972, 1996
Supercable .............. 0276
American High .............. 0035 MGN Technology ......... 0240 Totevision ......................0037,0240
Thomson ................. 1256
Asha ..............................0240 Microsoft ...................... 1972 Touch .............................1972
Zenith ...................... 0899
Audiovox ....................... 0037,0278 Mind ............................. 1972 Unitech ..........................0240
Beaumark ..................... 0240 Minolta .......................... 0042,0105 Vecto
r
0045
SATELLITE BRAND Codes Bell & Howell .................0104 Mitsubishi ...................... 0067,0043,0061, 0807 Vector Research ............0038
(Set Top Box) Broksonic ...................... 0184,0121,0209, 0002 Motorola ........................ 0035,0048 Video Concepts .............0045, 0061
A
lphaStar ................. 0772 0479, 1479 MTC .............................. 0240,0000 Videomagic ....................0037
Chaparral ................. 0216 Calix .............................. 0037 Multitech ....................... 0000, 0072 Videosonic .................... 0240
Crossdigital .............. 1109 Canon ........................... 0035 NEC .............................. 0104,0067, 0041,0038 Viewsonic ......................1972
DirecTV .................... 1377,0392,0566,0639, Capehart ....................... 0020 Nikko ............................ 0037 Villain .............................0000
1639,1142, 0247,0749,
Carver ........................... 0081 Niveus Media ................ 1972 Voodoo ..........................1972
1749,0724, 0819,1856, CCE .............................. 0072, 0278 Noblex .......................... 0240 Wards ............................0060, 0035,0048,0047,
1076,1108,
0099,1109,
Citizen ........................... 0037,0278,1278 Northgate ...................... 1972 0081, 0240,0000,0042,
1414,1442, 1609,1392, Colt ............................... 0072 Olympus ....................... 0035 0072,0149,0062, 0760
1640 Craig ............................. 0037, 0047,0240,0072 Onkyo ........................... 0222 White Westinghouse ..... 0209,0072
Dish Network System1505, 1005,0775,1775 0271 Optimus ........................ 1062, 0162,0037,0048, XR-1000 ........................0035, 0000,0072
Dishpro 1505,1005, 0775,1775 Curtis Mathes ................0060, 0035,0162,0041 0104,0432,0593, 1048, Yamaha ......................... 0038
Echostar 1505,1005, 0775,1775 0760, 1035 1162,
1262 Zenith ............................ 0039,
0033,0000, 0209,
Expressvu 0775, 1775 Cybernex .......................0240 Optonica ....................... 0062 0479, 1139,
1479
GE 0566 CyberPower .................. 1972 Orion ............................. 0184,0209, 0002,0479 ZT Group .......................1972
Remote Control Codes
Cable BRAND Codes General Instrument ........0869 Daewoo .........................0045
The Remote Control
, 0278, 0020, 0561 1479
36
Page 37
Remote Control Codes
DBS/PVR Combo BRAND ESA 0821,1268 1431
Hughes Network Systems 0739 Fisher 0670,1919 Sova 1122
Philips 0739 Funai 0675,1268,1334 Sungale 1074 Samsung 0739 Gateway 1073,1077,1158 Superscan 0821
PVR BRAND Codes Go Video 0744,0715,0741,0783, Sylvania 0675,0821,1268 ABS 1972 0833,0869,1044,1075, Symphonic 0675,0821 Alienware 1972 1099,1144,1158,1304, Teac 0758,0790,0809 CyberPower 1972 1730 Technics 0490,0703 Dell 1972 Go Vision 1071,1072 Technosonic 0730 DirecTV 0739 GoldStar 0741 Techwood 0692 Gateway 1972 GPX 0699,0769 Terapin 1031 Hewlett Packard 1972 Greenhill 0717 Theta Digital 0571 Howard Computers 1972 Harman/Kardon 0582,0702 Toshiba 0503,0695,1045,1154 HP 1972 Hitachi 0573,0664,1247,1919 Tredex 0799,0800,0803,0804
Hughes Network Systems 0739 Hiteker 0672 TYT 0705
Humax 0739 iLo 1348 Urban Concepts 0503 Hush 1972 Initial 0717 US Logic 0839 iBUYPOWER 1972 Insignia 1268 Venturer 0790 Linksys 1972 Integra 0627 Vizio 1064,1226 Media Center PC 1972 JBL 0702 Xbox 0522 Microsoft 1972 Jensen 1016 Yamaha 0490,0539,0545 Mind 1972 JSI 1423 Zenith 05 Niveus Media 1972 JVC 0558,0623,0867,1164 Zoece 1265 Northgate 1972 jWin 1049,1051 Panasonic 0616 Kawasaki 0790 DVD-R Codes Philips 0618,0739 Kenwood 0490,0534,0682,0737 Accurian 1416 RCA 0880 KLH 0717,0790,1020,1149 Apex Digital 1056 ReplayTV 0614,0616 1261 Aspire Digital 1168 Samsung 0739 Konka 0711,0719,0720,0721 Coby 1086 Sonic Blue 0614,0616 Koss 0651,0896,1423 CyberHome 1129 Sony 0636,1972 Landel 0826 Funai 0675,1334 Stack 9 0009,1972 Lasonic 0798,1173 Gateway 1073,1158 Systemax 1972 Lenoxx 1127 Go Video 0741,1158,1304,1730 Tagar Systems 1972 LG 0591,0741,0801,0869 iLo 1348 Tivo 0618,0636, 0739 LiteOn 1058,1158,1416,1440 JVC 1164 Toshiba 1008,1972,1996 Loewe 0511 LG 0741 Touch 1972 Magnavox 0503,0539,0646,0675, LiteOn 1158,1416,1440 Viewsonic 1972 0821,1268 Magnavox 0646,0675 Voodoo 1972 Malata 0782,1159 Panasonic 0490 ZT Group 1972 Marantz 0539 Philips 0646
DVD BRAND Codes Mintek 0839,0717 RCA 0522
Accurian 1072,1416 Momitsu 1082 Sensory Science 1158 Advent 1016 NAD 0741 Sharp 0675 Aiwa 0641 Akai 0695 ,0770,0899, Nesa 0717 Sylvania 0675 Alco 0790 Next Base 0826 Zenith 0741 Allegro 0869 NexxTech 1402 Amphion Media Works 0872 Norcent 1003,0872,1107,1265 AMW 0872 Apex Digital 0672,0717,0755,
Arrgo 1023 Philco 0690,0733,0790,0862, Aspire Digital 1168,1407 1855,2000 Audiologic 0736, Audiovox 0790,1041,1071, 0854,1260,1267,1354
Axion 1071,1072 Polaroid 1020,1061,1086 B & K 0655,0662 Polk Audio 0539 Blaupunkt 0717 Portland 0770 Blue Parade 0571 Presidian 0675,1072 Broksonic 0695,0868 Prima 1016
Cambridge Soundworks 0690 Proscan 0522
Cinea 0831 ProVision 0778 CineVision 0876,0833,0869 Qwestar 0651 Citizen 1277 RCA 0522,0571,0717,0790, Coby 0778,0852,1086,1107 0822,1022,1132,1193
Craig 0831 Rotel 0623 Curtis Mathes 1087 Rowa 0823 CyberHome 0816,0874,1023,1024 Sampo 0698,0752
Daewoo 0784,0705,0833,
Denon 0490,0634 Sanyo 0670,0695,0873,1919 Desay 1407 Sensory Science 1158 Disney 0675,1270 Sharp 0630,0675,0752,1256 Dual 1068,1085 Sharper Image 1117 Durabrand 1127 Sherwood 0633,0770,1043,1077 DVD2000 0521 Shinsonic 0533,0839 Emerson 0591,0675,0821,1268 Sonic Blue 0869,1099
Codes Enterprise 0591 Sony 0533,1533,0864,1033,
GE 0522,0815,0717 SVA 0860,1105
03,0591,0741,0869
Memorex 0695,0831,1270 Pioneer 0631 Microsoft 0522 Polaroid 1086
Mitsubishi 1521,0521 Samsung 0490
NEC 0785 Sony 1033,1431
1089
Onkyo 0503,0627,0792
OptoMedia Electronics 0896
0795,0796,0797 1004,1020,1056 Panasonic 049 1100 1462,1490,1762
1121,1122 Pioneer 0525,0571,0631,0632
1165,1177,1351 Rio 0869
1117,1129,
1169,1172,1234,
0794
Oritron 0651
,0830 ,1061
Philips 0503,0539,0646,0675,
1072
Samsung 049
0869
Sansui 0695
1242
1044,1075
0,0632,0703,1362,
0,0573,0820,0899,
The Remote Control
37
Page 38
Video
Picture Mode Select between 3 picture modes;
Day Dynamic, Day Normal and Night.
Contrast Adjust contrast.
Brightness Adjust brightness.
Color Adjust color.
Tint Adjust tint.
Sharpness Adjust sharpness.
ColorTemperature Set this to High for less intense
color with more blue, set to Medium for natural color, set to Standard for standard colors or Black and White
Black Enhancement Enhance picture brightness in
light scenes.
Contrast Mode Use this function to choose
between two Contrast Mode
settings.
Noise Reduction Reduces conspicuous noise in
the picture.
for more reddish color.
MPEG NR Reduces mosquito noise in
the picture.
Back Light Adjust back light.
This part of the screen shows which selections are available.
different features on your HITACHI LCD TV.
On-Scr
een Display
This part of the screen shows which
Remote
Control buttons to use.
Channel Manager
Setup
Timers
Locks
Audio
Video
Move SEL Select
Power Swivel
1. Press MENU on the remote control to display the
2. Use the CURSOR PAD (buttons ,,and )
3. Press EXIT on the remote control to quickly exit
different features on your HITACHI LCD TV.
and highlight a different feature of the On-Screen Display menu. Press the SELECT button to select.
from a menu.
NOTE: The On Screen Display (O
On-Screen Display
purposes only, therefore; doesn't reflect the actual apearance of the OSD of your HITACHI LCD TV.
38
SD) for the different submenus shown in next pages are for illustration
Auto Movie Mode Turn On/Off the 3:2 Pulldown
detection feature.
Auto Color The AUTO COLOR function
a
utomatically monitors and adjusts the color to maintain constant color levels even after a program or channel changes. It also maintains natural flesh tones while preserving fidelity of background colors.
Black Side Panel Set the gray side bars On/Off
w
hen watching 4:3 signals in
standard mode.
Aspect Choose the picture for mat
aspect ratio.
Reset Video Settings Choose to Reset Video Settings
factory settings.
to
Page 39
39
Timers
Channel Manager
On-Screen Display
Treble Adjust the treble. Bass Adjust the bass. Balance Adjust the balance.
Audio Source Select between three Audio
Sources.
Internal Speakers Select internal or external
speakers.
Auto Noise Cancel Eliminates the noise between
stations.
Perfect Volume Adjust volume in fixed setting
Loudness Adjust Loudness.
Language Select Language options if
available. Digital Output Select Optical Output options. DRC Select Dynamic Range
Compression to ON or OFF.
NOTE: The Language, Digital Output, and the
Dynamic Range Compression feature of the Audio OSD are only available for Digital channels.
Auto Channel Scan Set Auto Channel Scan. Channel List Set Channel List.
Change Access Code Change Lock access code. Engage Lock Choose to lock channel,
and/or Front panel. Movie Ratings Block various types of movies
and video types based on
motion picture ratings. TV Ratings Block various types of movies
and television programming
based on a parental guide
ratings. Canadian Ratings (ENG)
Block various types of movies
and television programming
based on the Canadian ratings
system. Canadian Ratings (FRN)
Block various types of movies
and television programming
based on the Canadian French
ratings system.
Set the Clock Set Clock Settings. Set Sleep Timer Set Sleep Timer intervals
(30 min. intervals, 00:30-3:00).
Set Day/Night Timer Set Day/Night picture mode
settings.
Set Event Timer Set viewing reservation for TV
programs.
Set The Menu Options Choose English, French, or
Spanish text and Background.
Set The Power Saving Automatic Power saving
features.
Set The Inputs
Label Video Inputs, VCR, DVD,
etc.
Set The Closed Captions Feature to display dialogue/text.
Reset The Software Select to upgrade TV software
Select The Quick Select the TV Quick Start Up
Start Option Option.
NOTE: 1. The Signal Meter feature of the Channel
Manager OSD is only available for Digital channels.
Audio
Surround Select Surround settings (Off,
Wide, Normal)
Bass Boost Select Bass Boost option ON or OFF.
Signal Meter Access Signal Meter.
On-Screen Display
Unlocked Power Swivel enabled. Control
the motorized Table Top Stand
Locked Power Swivel disabled.
Power Swivel
Lip Sync Synchronizes audio with video signal
on digital and analog sources.
Locks
Region 5 Ratings system for DTV
Signal
to block various types of programs.
Setup
2. Power Swivel feature is only available when
Table Top Stand is connected.
and to Reset TV settings.
between stations.
Page 40
40
Video
Select VIDEO to adjust picture settings and improve picture quality. You can independently customize each of the Video Inputs to your preference to increase viewing performance and pleasure depending upon the video program being viewed. If RESET is selected, only the selected input will reset to initial conditions.
Picture Mode
Use this function to choose from automatic picture settings to optimize your TV’s performance.
1. Use the CURSOR buttons
or to highlight and
se
lect PICTURE MODE settings (Day-Normal,
2. Then press the SELECT button to set the mode and return to the Video menu or press EXIT to quit menu.
3. There are 3 Picture Modes available for the customer Day (Dynamic) , Day (Normal) and Night mode. Day (Dynamic) is the original factory preset mode , this
can be changed by adjusting any video setting to your desire conditions. Day ( Normal ) can be used as a second video setting for daytime viewing. Night is set to watch programing during nigthtime.
1. Use the CURSOR PAD
or to highlight the function to be adjusted.
2. Pr
ess the SELECT button or the CURSOR PAD to select the function settings.
3. Pr
ess the CURSOR PAD or to adjust the function.
4. Press MENU to return to main menu.
5. Press EXIT to quit menu.
Contrast
Use this function to change the contrast between black and white levels in the picture.
Brightness
Use this function to adjust overall picture brightness.
Color
Use this function to adjust the level of color in the picture.
Tint
Use this function to adjust flesh tones so they appear natural.
Sharpness
Use this function to adjust the amount of fine detail in the picture.
Back Light
Day-Dynamic or Night).
Contrast 100%
Next/Prev Change
SEL Return
Video
Black Enhancement
Color Temperature
Back Light
Sharpness
Tint
Color
Brightness
Contrast
Picture Mode Day (Dynamic)
100% 50% 62%
50% igh High
Picture Mode Day (Dynamic)
Cable
Next/Prev Select
SEL Return
Move SEL Select
On-Screen Display
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move
SEL Select
Power Swivel
OR
Use this function to change the back light of the LCD panel, this will increase or decrease the brightness of the LCD panel but not the brightness of the video signal.
Black Enhancement
Color Temperature
Back Light
Sharpness
Tint
Color
Brightness
Contrast
Picture Mode Day (Dynamic)
100% 50% 62%
50%
High
High
Video
Cable
Move SEL Select
OR
100%
Page 41
Video
Color Temperature
S
et this to High for cooler color with more blue, set to Medium for more natural color, set to Standard for accurate
color or set to Black/White for more reddish color.
Black Enhancement
Use this function to enhance the shadow detail in dark scenes using the settings off, low, middle and high.
NOTE: 1. If CONTRAST is selected, you are adjusting CONTRAST. The additional menu items BRIGHTNESS,
COLOR, TINT, and SHARPNESS can be selected and adjusted in the same manner.
2. It may be necessary to adjust TINT to obtain optimum picture quality when using the COMPONENT VIDEO Y-P
3. CABLE and AIR share a Video setting. Also, each of the video inputs have their own independent settings.
Contrast Mode
Use this function to choose between 2 Contrast Mode settings. Set to DYNAMIC for darker images more in the level of Black, set to NORMAL for a balanced White to Black level.
Noise Reduction
The NOISE REDUCTION function automatically reduces conspicuous noise in the picture without degrading picture quality. Set NOISE REDUCTION to OFF if the TV experiences picture blocking.
MPEG NR
T
he MPEG NR (Noise Reduction) function automatically reduces mosquito noise in the picture without degrading
picture quality. Set MPEG NR to OFF if the TV experiences picture block noise.
BPR input jacks.
Auto Movie Mode
The AUTO MOVIE MODE function turn ON or OFF the 3:2 PULLDOWN DETECTION SPECIAL FEATURE.
Theatrical movies are shot on film at 24 frames or still pictures per second, instead of 30 frames or 60 fields like video. When film is transferred to video for television viewing, the disparity between the two frame rates must be reconciled. This involves a process known as 3:2 pulldown.
When AUTO MOVIE MODE is turned ON from the VIDEO menu, your Hitachi LCD Television will activate the circuitry for this special feature to improve video performance when watching film based sources.
Auto Color
T
he AUTO COLOR function automatically monitors and adjusts the color to maintain constant color levels even after
a program or channel changes. It also maintains natural flesh tones while preserving fidelity of background colors.
NOTE: When receiving Antenna Digital Channel, using Component or HDMI input, Auto Color will not be
available (grayed out).
Black Side Panel
The BLACK SIDE PANEL function turns the gray side
bars from gray to black when watching 4:3 signals in Standard mode.
1. Press the CURSOR PAD or to set to ON or OFF.
Black Side Panel Off
Next/Prev On/Off
SEL Return
Video
2. Press EXIT to PANEL to return to the previous menu.
quit menu or select SET BLACK SIDE
On-Screen Display
Black Side Panel On
NOTE: This setting return to Off automatically after TV power On/Off.
Next/Prev On/Off
SEL Return
41
Page 42
Reset Video Settings
Aspect
Black Side Panel
Auto Color
Auto Movie Mode Off
MPEG NR Off
Noise Reduction Low
Contrast Mode Dynamic
Off Off
Video
Cable
Move SEL Return
Black Enhancement High
On-Screen Display
OR
OR
Video
Aspect
Use this function to select the Picture Format Aspect Ratio.
Auto Aspect
Video
Aspect
Auto Aspect : On Mode 16:9 Vertical Position : 0
Move SEL Return
Standard1
Automatically adjust the Aspect Ratio depending on the input signal to fill the screen.
Mode
Manually select the Aspect Ratio.
Vertical Position
This function allows you to change the vertical position when aspect style is either 4:3 EXPANDED/ZOOM1/ZOOM2 or 16:9 ZOOM. For example, it will be useful for
centering the picture area at both the top and bottom of the picture with 480i//480p signal. Adjustable range is -10 (video center is toward bottom of screen) to +10 (video is toward top of screen).
1. Use the CURSOR PAD or to to select menu item.
2.
Press the CURSOR PAD or to adjust the function.
3. Press the EXIT to quit the MENU, or select ASPECT to return to the main menu.
NOTE: 1
. Vertical Position will not be available in 4:3 Standard and 16:9 Standard modes.
2. Vertical Position setting returns to "0" automatically after TV power On/Off.
Reset Video Settings
This function allows you to Reset the V
ideo Menu Settings of the present input and return it to the Day-Dynamic
VIDEO mode.
1. Use CURSOR PAD , to highlight functions.
2. Press the SELECT button or CURSOR PAD to
select Reset Video Settings.
3. Use the CURSOR PAD to access at the Reset
softkey.
4. Press the SELECT button to Reset the Video
Settings.
You can customize each of the Video Inputs to your preference to increase viewing performance and pleasure, depending upon the video program being viewed. If RESET is selected, only the selected Input will reset to the initial conditions as explained above.
If RESET is selected in Input 1, only Input 1 will return to factory conditions.
Video
Reset Video
Select “Reset ” to return to Video menu settings on this Input to the original factory settings.
Reset
SEL Re
Move
turn
42
Page 43
Audio
Normal Surround: : Provides the surround effect by locating two or more speakers to the rear of the listener.
Off : turns off the surround sound effect.
or 왔 왗 or
5 channel contents with ordinary stereo contents.
Surround
Surround sound is the concept of expanding the spatial imaging of audio from one dimension ( Mono/Left-Right) to two or three dimensions. This is often done to create a more realistic audio environment.
1.- Use CURSOR PAD to highlight surround option.
2.- Use CURSOR PAD to select Off, Normal or Wide.
Wide Surround : Reproduce much better quality 5 channel sound signals from ordinary stereo contents comparing with
normal surround technology. Wide surround enable users to enjoy sound playback in wide surround virtual area like
Bass Boost
This function allows to enhance the low frequency audio performance of your speaker system.
Move SEL Return
Perfect Volume
Auto Noise Cancel
Internal Speakers
Audio Source
Bass Boost
Surround
Balance
Bass
Of f
Off
On
Stereo
Off
Off
L R
50%
50%
Audio
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move
SEL Select
Power Swivel
Treble
On-Screen Display
OR
Select AUDIO to adjust the TV to your preference and to improve the sound quality.
1. Press CURSOR PAD or to select menu item.
2. Press CURSOR PAD or to adjust the function.
3. Press EXIT to quit the MENU, or select AUDIO to
return to the main menu.
NOTE: If TREBLE is selected you are adjusting
treble. The additional menu items BASS and BALANCE can be selected and adjusted in the same manner.
Treble
This function controls the high frequency audio to all speakers.
Bass
This function controls the low frequency audio to all speakers.
Balance
This function will control the left to right balance of the LCD TV internal speakers.
Audio
43
Page 44
Audio
NOTE: 1.- The DRC control affects only Dolby®Digital
signals decoded internally by the TV.
2.- DRC does not affect the Dolby Digital bitstream available at the digital audio output.
Move SEL Select
Perfect Volume
Auto Noise Cancel
Internal Speakers
Audio Source
Bass Boost
Surround
Balance
Bass
Off
Off
On
Stereo
Off
Off
L R
50%
50%
Audio
Move SEL Select
Lip Sync
DRC
Digital Output
Language
Loudness
Perfect Volume
Auto Noise Cancel
Internal Speakers
Audio Source
Off
Off
Off
On
Stereo
0
On
Dolby Digital
1 [Unknown]
Audio
Treble
On-Screen Display
OR
Lip Sync
Selecting this feature will allow you to synchronize the audio with the picture signal on a digital or analog source. Use the CURSOR PAD or to synchronize the picture and the audio signal. The default value is set to 0.
Audio Source
Multi-Channel used when receiving a weak stereo broadcast or SECOND AUDIO PROG (SAP) which may be a secondary language, weather report, etc.
Internal Speakers
This function is useful when setting up the external speakers.
Television Sound will allow you to select STEREO (a stereo broadcast), MONO (monaural sound)
ON Select
this feature if using the internal speakers only.
TV as Center Select this feature when setting up external speakers from a separate stereo system.
The TV’
s speakers will work as the center speaker.
OFF Select
this feature if you prefer to use only speakers from a separate stereo system.
Auto Noise Cancel
This function eliminates the noise between stations. If a channel is tuned and is noisy, this function will automatically eliminate the audio for that channel.
Perfect Volume
This function will automatically adjust volume so each channel and input has the same average volume level.
Loudness
Set this function to ON to emphasize bass and treble at low volume levels.
Language
Some programs transmit more than one DTV language option. Most will have English as a default language. The language function will allow you to select up to 4 language options (if available).
Digital Output
This function allows you to select between Dolby
® Digital and PCM. This setting will be fed into optical output.
Dolby®Digital - Select this feature if the TV is connected to an amplifier/receiver with a Dolby®Digital only decoder; it will provide six independent soundtrack channels through the optical output jack (Digital Audio).
NOTE: *Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
PCM - Select this feature if the TV is connected to an amplifier/receiver with a PCM only decoder; it will provide two independent soundtrack channels through the optical output jack (Digital Audio).
DRC
Dynamic Range Compression - Use this function to compress the range of sound volume. By compressing the range of sound volume, it is possible not only to suppress the output of loud sound at night but also to
raise the volume of low sound. The default setting is ON.
Use the CURSOR PAD or to select the chosen options.
N
OTE: The functions Language, Digital Output and DRC
a
re only available when viewing digital programs.
Use the functions at right if your TV is connected to an amplifier/receiver with optical digital input with Dolby
®
Digital or PCM decoder capabilities.
44
Page 45
On-Screen Display
Channel Manager
Select CHANNEL MANAGER to set your Antenna options, run Auto Channel Scan, Check Signal Meter and Set Channel List.
1. Press CURSOR PAD ,to highlight functions.
2. Press the SELECT button or CURSOR PAD to
select.
Signal Meter
Select SIGNAL METER when using an indoor or outdoor antenna. This feature will show the signal strength and peak values of the Antenna signal to help you adjust your antenna to optimize signal reception.
Use the CURSOR PADS and the SELECT button to highlight and select CLOSE to exit.
NOTE: The Signal Meter will not be available (grayed
out) when watching analog channels.
Auto Channel Scan
This feature will automatically store active Analog and Digital channels in Auto Channel Scan memory.
Channel Manager
1. Use the CU
RSOR buttons to highlight AIR,
CABLE (1) or CABLE(2) source.
2. Press the CURSOR buttons or to highlight the START or RESET option.
3. Press the SELECT button to select.
or
NOTE:
1. If certain channels are poor or not possible
in cable(1) mode, set cable source to cable(2)
by using the CURSOR buttons or .
Move SEL Select
Channel List
Auto Channel Scan
Signal Meter
Channel Manager
Auto Channel Scan
Channel Manager
Move SEL Return
Source Air
Start Reset
Auto Channel Scan
Move SEL Select
Channel List
Auto Channel Scan
Signal Meter
Move SEL Return
Signal Meter
Channel Manager
Channel 3 - 1 Strength 91 Peak 91 SNR 10
Close
Move SEL Select
Channel List
Auto Channel Scan
Signal Meter
Channel Manager
45
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move SEL Select
Power Swivel
Channel Manager
OR
OR
OR
Page 46
Channel Manager
Move SEL Select
Channel List
Auto Channel Scan
Signal Meter
Channel Manager
Channel Manager
Channel List
Notice: United States federal law requires broadcasters to stop transmitting analog (non-digital) television signals after February 17, 2009.
Accordingly, this TV's analog tuner will not be capable of receiving over-the-air analog television broadcasts after such analog broadcasts are no longer available.
After February 17, 2009, this TV's analog tuner will continue to work with compatible cable and satellite TV systems, gaming consoles, VCRs, DVD players and other similar products.
Both before and after February 17, 2009, this TV's digital tuner will receive available over-the-air digital television broadcasts using an antenna and other digital television broadcasts using compatible cable, satellite or other digital television system connections.
Please review this Owner's Guide for further information regarding such connections.
On-Screen Display
OR
Channel List
T
his function allows you to review which channels are
labeled (ID), which have been added to CHANNEL MEMORY (SCAN), which are protected by LOCK and
which are your FAVORITE (FAV) CHANNELS.
1. Use the CURSOR PAD to navigate the Channel List.
2. Press the SELECT button to select ON or OFF on the SCAN and LOCK columns.
3. To select LOCK column, input the access code. (Default access code: 0000)
4. Press the FAV button to set or remove the FAVORITE settings.
5. Press the EXIT button to return to normal viewing.
FAV CH# Scan Lock ID
3-1 On
4 On Off ------­5 On Off ------­6 On Off ------­7 On Off ------­8 On Off ------­9 On Off -------
10 On Off -------
No Info. --:-- AM
Move Return
Off -------
INFO Detail
-
--:-- AM
NOTE: 1. The Channel List cannot be updated by only changing the cable source. Auto Channel Scan must
be performed for the Channel List to be updated.
46
Page 47
Locks
This function will block out the picture and sound of the selected channel or video input.
The code to enter the Locks feature is a four digit access code number. The factory preset code is 0000. Use the NUMBER buttons to enter the access code.
1. Use the CURSOR PAD
왖, 왔 to highlight the
desired function in the
LOCKS menu.
2. Press the SELECT button to select.
Change Access Code
1. To change the ACCESS CODE NUMBER, select CHANGE ACCESS CODE to change the factory
preset code (0000) to your preference.
If you forget your ACCESS CODE NUMBER, use the factory code 7777 to erase your key number. This will reset the access code number back to the factory preset (0000).
2. Enter a new four digit number.
3. Press EXIT to quit the menu.
Engage Lock
When ENGAGE LOCK is selected, SET CHANNEL LOCK and SET FRONT PANEL LOCK can be set individually.
When SET CHANNEL LOCK is turned on, the picture and sound for the chosen channel will be blocked out.
When FRONT PANEL LOCK is turned on, all buttons on the Front Panel will be deactivated, except the POWER button.
When MOVIE RATINGS is selected, you can block various types of movies and video tapes based on motion
picture ratings (see page 48).
When TV RATINGS is selected, various types of television programming based on a parental guide ratings will be
blocked (see page 49).
Use CANADIAN RATINGS to block various types of movies and television programs based on the two rating
systems used in Canada that you feel may be inappropriate due to its content (see pages
50-51).
Locks
NOTE:
Us
e REGION 5 to block various types of movies and television programs based on ratings systems used in U.S. that
you feel may be inappropriate due to its content (see page 52).
The REGION 5 option will operate for Digital Channels only.
47
Please Enter Access Code
Access Code
- - - -
[#Keys] Enter Code
Move SEL Select
Region 5
Canadian Ratings (Frn)
Canadian Ratings (Eng)
TV Ratings
Movie Ratings
Engage Lock
Change Access Code
Locks
On-Screen Display
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move
SEL Select
Power Swivel
0
0
0
000
OR
Page 48
Locks
Move SEL Select
Region 5
Canadian Ratings (Frn)
Canadian Ratings (Eng)
TV Ratings
Movie Ratings
Engage Lock
Change Access Code
Locks
Locks
Movie Ratings
On-Screen Display
OR
Movie Ratings
U
se Movie Ratings to prevent viewing of any movie that
you feel may be inappropriate due to its content.
1. Use the CURSOR PAD
왖, 왔 to select the
MOVIE RATING category that you want to block.
2. Press SELECT to block the MOVIE RATING that you
have selected. Once rating is selected, for example PG-13, all movies rated PG-13 and higher (R, NC-17,
and X) will be blocked.
3. Press EXIT to quit the menu or select MOVIE
RATING
to return to the previous menu.
Motion Picture Ratings Table
NOT RATED Contains
no rating. Not Rated (NR) and Not Applicable (NA) programs. Movie has not
been rated or ratings do not apply. G General PG Par PG-13 Par R Restricted. NC-17 No X Adults
audiences. All ages admitted. ental guidance suggested. Some material may not be suitable for children. ents strongly cautioned. Some material may be inappropriate for children under 13.
Under 17 requires accompanying parent or adult guardian.
one 17 and under admitted.
only
Status
Not Rated G PG PG-13 R NC-17 X
Move SEL Return
NOTE: 1.
A movie rating is dependent upon the movie that is viewed. If the movie does not carry a rating, the TV will not block it.
2. Blocking NOT RATED programs may block emergency programming, sports, news, public service announcements, religious programs and weather.
48
Page 49
Locks
Move SEL Select
Region 5
Canadian Ratings (Frn)
Canadian Ratings (Eng)
TV Ratings
Movie Ratings
Engage Lock
Change Access Code
Locks
Locks
TV Ratings
49
On-Screen Display
OR
TV
Ratings
Use TV RATINGS to prevent the viewing of any TV program that you feel may be inappropriate due to its content.
1. Use the CURSOR PAD , to select the
TV RATING category that you want to block.
2. Press SELECT to block the TV RATING that you
have selected.
3. Press EXIT to quit the menu or select TV RATING
to return to the previous menu.
TV Parental Guide Ratings Table
TV-Y All
TV-Y7 D
TV-G G
TV-PG P
TV-14 P
TV-MA M
FV Fantasy V V S Sexual L Adult D Sexually
children. The themes and elements in this program are specifically designed for a very
young audience, including children from ages 2-6.
irected to older children. Themes and elements in this program may include mild
physical or comedic violence, or may frighten children under the age of 7.
eneral audience. It contains little or no violence, no strong language, and little or no
sexual dialogue or situations.
arental guidance suggested. The program may contain infrequent coarse language,
limited violence, some suggestive sexual dialogue and situations.
arents strongly cautioned. This program may contain sophisticated themes, intense
sexual situation, more intense violence and intensely suggestive dialogue.
ature audiences only. This program may contain mature themes, indecent language,
graphic violence, and explicit sexual content.
Violence
iolence
Situation
Language
Suggestive Dialogue
Status D
TV-Y
TV-Y7 TV-G TV-PG TV-14 TV-MA
Move SEL Return
Sub Rating
L S V FV
NOTE: 1.
If you Block TV-14D, you will still permit TV-MA programs; If you block TV-14V, you will automatically block TV-MAV programs, but you will still permit TV-MALS programs. This means that the TV will block violence in TV-14 and higher (TV-MA), but not language and sex.
2. TV program ratings are dependent on the broadcaster. If the program is not rated, the TV will not block it.
Page 50
Locks
Move SEL Select
Region 5
Canadian Ratings (Frn)
Canadian Ratings (Eng)
TV Ratings
Movie Ratings
Engage Lock
Change Access Code
Locks
On-Screen Display
OR
Canadian Ratings (Eng)
Use CANADIAN
RATINGS (ENG) to block any type of
movie and television program in Canada that you feel might be inappropriate in its content.
1. Use the CURSOR PAD , to select the
CANADIAN RATINGS (ENG) category that you
want to block.
2. Press SELECT to block the CANADIAN RATINGS (ENG) that you have selected. Once rating is selected, for example C8+, all movies and television programs rated C8+ and higher (G,PG, 14+ and 18+) will be blocked automatically.
3. Press EXIT to quit the menu or select CANADIAN RATINGS (ENG) to return to the previous menu.
Locks
Canadian Ratings (Eng)
Status
C C8+ G PG 14+ 18+
Move SEL Return
Canadian Ratings English Table
C Pr
ogramming intended for children under age 8 - Violence Guidelines; Careful attention is paid to themes, which could threaten children’s sense of security and well-being. There will be no realistic scenes of violence. Depictions of aggressive behaviour will be infrequent and limited to portrayals that are clearly imaginary, comedic or unrealistic in nature. Other Content Guidelines: There will be no offensive language, nudity or sexual content.
C8+ Pr
ogramming generally considered acceptable for children 8 years and over to watch on their own - Violence Guidelines: Violence will not be portrayed as the preferred, acceptable, or only way to resolve conflict; or encourage children to imitate dangerous acts which they may see on television. Any realistic depictions of violence will be infrequent, discreet, of low intensity and will show the consequences of the acts. Other Content Guidelines: There will be no profanity, nudity or sexual content.
G General
Audience - Violence Guidelines: Will contain very little violence, either physical or verbal or emotional. Will be sensitive to themes which could frighten a younger child, will not depict realistic scenes of violence which minimize or gloss over the effects of violent acts. Other Content Guidelines: There may be some inoffensive slang, no profanity and no nudity.
PG Par
ental Guidance - Programming intended for a general audience but which may not be suitable for younger children. Parents may consider some content inappropriate for unsupervised viewing by children ages 8-13. Violence Guidelines: Depictions of conflict and/or aggression will be limited and moderate; may include physical, fantasy, or supernatural violence. Other Content Guidelines: May contain infrequent mild profanity, or mildly suggestive language. Could also contain brief scenes of nudity.
14+ Pr
ogramming contains themes or content which may not be suitable for viewers under the age of 14 - Parents are strongly cautioned to exercise discretion in permitting viewing by pre-teens and early teens. Violence Guidelines: May contain intense scenes of violence. Could deal with mature themes and societal issues in a realistic fashion. Other Content Guidelines: May contain scenes of nudity and/or sexual activity. There could be frequent use of profanity.
18+ Adult
- Violence Guidelines: May contain violence integral to the development of the plot, character or theme, intended for adult audiences. Other Content Guidelines: May contain graphic language and explicit portrayals of nudity and/or sex.
50
Page 51
Locks
Move SEL Select
Region 5
Canadian Ratings (Frn)
Canadian Ratings (Eng)
TV Ratings
Movie Ratings
Engage Lock
Change Access Code
Locks
Canadian Ratings (Frn)
Move SEL Return
Status
G 8 ans + 13 ans + 16 ans + 18 ans +
Locks
On-Screen Display
OR
Canadian
Ratings (Frn)
Use CANADIAN RATINGS (FRN) to block Canadian French programs according to various program ratings that you feel might be inappropriate in its content.
1. Use the CURSOR PAD , to select the
CANADIAN RATINGS (FRN) category that you
want to block.
2. Press SELECT to block the CANADIAN RATINGS (FRN) that you have selected. Once rating is selected, for example 8 ANS+, all movies and television programs rated 8 ANS+ and higher will be blocked automatically.
3. Press EXIT to quit the menu or select CANADIAN RATINGS (FRN) to return to the previous menu.
Canadian Ratings French Chart
G General
- Programming intended for audiences of all ages. Contains no violence, or the violence content is minimal or is depicted appropriately with humor or caricature or in an unrealistic manner.
8 ans + 8
+ General - Not recommended for young children - Programming intended for a broad audience but contains light or occasional violence that could disturb young children. Viewing with an adult is therefore recommended for young children (under the age of 8) who cannot differentiate between real and imaginary portrayals.
13 ans + Pr
ogramming may not be suitable for children under the age of 13 - Contains either a few violent scenes or one or more sufficiently violent scenes to affect them. Viewing with an adult is therefore strongly recommended for children under 13.
16 ans + Pr
ogramming is not suitable for children under the age of 16 - Contains frequent scenes of violence or intense violence.
18 ans + P
rogramming restricted to adults - Contains constant violence or scenes of extreme
violence.
51
Page 52
Locks
INFO
Status CATEGORY NAME (1 / 10)
:
: : :[ ]
Move SEL View Block
Region 5
Locks
TV-Y
T
V-Y7
12345678 ABCDEFJH
Directed to older children. Themes and elements in this program may incl ude mild physical or comedic violence, or may frighten children under the age of 7.
Move SEL View Block
TV-Y TV-Y7 12345678 ABCDEFJH
:
: : :[ ]
Status CATEGORY NAME (1 / 10)
Fig. (1)
Move SEL Select
Region 5
Canadian Ratings (Frn)
Canadian Ratings (Eng)
TV Ratings
Movie Ratings
Engage Lock
Change Access Code
Locks
Locks
Region 5
D
On-Screen Display
OR
OR
Region 5
U
se Region 5 Ratings to prevent viewing of any movie or
program that you feel may be inappropriate due to its content. This feature will operate only for ATSC Digital signal.
In order to set the R channel received must include Region 5 Ratings data To see if the channel has Region 5 Ratings, press the INFO key on the R/C. See fig. (1) for reference.
Once the TV has received Region 5 Ratings data, the Region 5 option in the lock menu will display the data.
1.
Use the CURSOR buttons or to select the
REGION 5 category that you want to block.
2.
Press SELECT to block the REGION 5 that you have selected. Once rating is selected, for example PG-13, all movies rated PG-13 and higher (R, NC-17 and X) will be blocked.
3.
Press EXIT to quit the menu or select REGION 5 to return to the previous menu.
egion 5 Ratings the ATSC Digital
Receiving
Audio Language
(Digital CH)
/Receiving BTSC
(
Analog CH )
Receiving
Rating Broadcast
Alternate Ratings
Closed Caption Mode
Pro
gram Title
Program Title. . . . . . . . Cable 888-001
11:30AM 11:55AM REGION Multi DTVCC CF-18 ans+ 1080i 10:35 AM
Program Time
5 KDEF-DT
MA03:11otuA
Receiving Digital Closed Caption
Event Timer
Source
CH ID/Input ID
Current Time
Receiving Signal Format
Alternate Ratings (Example Only) :
G General PG Par PG-13 Par R Restricted. NC-17 No X Adults
audiences. All ages admitted. ental guidance suggested. Some material may not be suitable for children. ents strongly cautioned. Some material may be inappropriate for children under 13.
Under 17 requires accompanying parent or adult guardian.
one 17 and under admitted.
only
Y Adults only
52
Page 53
Select TIMERS to set your Clock, Sleep Timer, Event Timer and Day/Night Timer.
1. Use the CURSOR buttons
or to highlight the
function to be adjusted.
2. Press the SELECT button to select.
Set The Clock
The Clock must be adjusted before you can use the SET EVENT TIMER or DAY/NIGHT TIMER feature.
1. Use the CURSOR PAD
왗,왘,왖,왔 to highlight
the chosen TIME ZONE s
ettings.
2.
Press the SELECT button to select. If you observe daylight savings, use CURSOR PAD to highlight
DAYLIGHT SAVING CORRECTION and press the SELECT button to select.
3. Use the CURSOR PAD ,,, to highlight
th
e CURRENT TIME (hour and minute), AM or PM,
MONTH, DAY, and YEAR.
4. Use the CURSOR PAD
왖, 왔 to adjust settings.
5. Press the SELECT button to set the TIME AND DATE.
6. Press EXIT to quit the menu or select SET THE CLOCK to return to the previous menu.
NOTE: 1. When AUTOMATICALLY ADJUST CLOCK FOR DAYLIGHT SAVING CHANGES is checked
, the
TV will automatically calculate the clock adjustment for Daylight Saving.
2. The TV counts electrical pulses for regulating the TIMERS. When the power cord is unplugged then
plugged quickly the clock is stopped momentarily and the TIME indication will become slow.
Timers
Timers
53
Set The Clock
Timers
Move SEL Return
Time Zone : PST Date : Jan. 1 2007 Time : 10 : 25 AM
Move SEL Select
Set Day/Night Timer
Set Sleep Timer
Set The Clock
Timers
Not Set
0:00
-- : -- AM PST
Set Event Timer
Not Set
Automatically adjust clock for daylight savings changes.
On-Screen Display
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move SEL Select
Power Swivel
OR
OR
Page 54
Timers
Move SEL Select
Set Day/Night Timer
Set Sleep Timer
Set The Clock
Timers
Not Set
0:00
10 : 25 AM PST
Set Event Timer
Not Set
Move SEL Select
Set Day/Night Timer
Set Sleep Timer 0:00
Set The Clock
Timers
Not Set
10 : 25 AM PST
Set Day/Night Timer
Timers
Move SEL Return
Day (Normal) Mode On : 06:00 AM Day (Dynamic) Mode On : 02:00 PM
Set Event Timer Not Set
Move SEL Select
Set Day/Night Timer
Set Sleep Timer 0:30
Set The Clock
Timers
Not Set
10 : 25 AM PST
Set Event Timer Not Set
Night Mode On : 06:00 PM
NOTE: The Sleep Timer info will show for 1 minute
before the TV turns off.
On-Screen Display
OR
Set
Sleep Timer
Select this feature to set your SLEEP TIMER from 30 minutes to 3 hours (30 minute increments).
1. Press the CURSOR PAD
Timer from 0:00, 0:30, 1:00, 1:30, 2:00, 2:30 and
3:00.
repeatedly to set your
Set Day/Night Timer
Select this feature to activate and set your TV’s DAY/NIGHT PICTURE MODE automatically. This feature is not available until the clock is set.
1. Use the CURSOR PADS to highlight SET DAY/ NIGHT TIMER settings.
2. Press the SELECT button to select the option.
3. Use the CURSOR PADS to select DAY NORMAL
MODE ON and to set it’s TIMER.
4. Use the CURSOR PADS to select DAY DYNAMIC
MODE ON and to set it’s TIMER.
5. Use the CURSOR PADS to select NIGHT MODE ON and to set it's TIMER.
6. Press EXIT to quit the menu or select SET DAY/
NIGHT TIMER to return to the previous menu.
54
Page 55
Timers
Set Event Timer
Timers
Move SEL Return
Event1 : -- : -- AM -
-- : -- AM Jan. 1 2007
Cable ------- Event2 : -- : -- AM
-
-- : -- AM Jan. 1 2007
Cable ------- Event3 : -- : -- AM
-
-- : -- AM Jan. 1 2007
Cable ------- Event4 : -- : -- AM -
-- : -- AM Jan. 1 2007
Cable -------
Set Event Timer
Timers
Move SEL Return
Event1 : -- : -- AM -
-- : -- AM Jan. 1 2007
Cable ------- Event2 : -- : -- AM
-
-- : -- AM Jan. 1 2007
Cable ------- Event3 :
-- : -- AM
-
-- : -- AM Jan. 1 2007
Cable ------- Event4 : -- : -- AM
-
-- : -- AM Jan. 1 2007
Cable -------
Move SEL Select
Set Day/Night Timer
Set Sleep Timer
Set The Clock
Timers
Not Set
0:30
10 : 25 AM PST
Set Event Timer
Not Set
Please Set Clock First
On-Screen Display
OR
3. Use the CURSOR PAD
왘, 왖 or to highlight and
2. Use the CURSOR PAD
왘, 왖 or to highlight and
Set Event Timer
T
his function will automatically operate the LCD TV
viewing reservation of a program. If the clock is not set, you can not use this function and the screen at right will appear. The message on the screen will disappear after 3 seconds, then the screen automatically goes to the
clock setup mode (see page 53).
1. Use the CURSOR PAD
, to highlight EVENT 1
EVENT 2, EVENT 3, EVENT 4 and then press the SELECT button to select.
select START TIME HOUR/MINUTE.
select START TIME AM/PM.
4. Use the CURSOR PAD
왘, 왖 or to highlight and
select FINISH TIME HOUR/MINUTE.
5. Use the CURSOR PAD
왘, 왖 or to highlight and
select FINISH TIME AM/PM.
6. Use the CURSOR PAD
7. Use the CURSOR PAD
CURSOR PAD
to select DAILY, WEEKLY -
to highlight the MONTH.
to select a MONTH or
SUNDAY TO MONDAY. Use the CURSOR PAD to return to MONTH.
8. Use the CURSOR PAD select the DA
Y of the MONTH.
9. Use the CURSOR PAD
왘, 왖 or to highlight and
왘, 왖 or to highlight and
select the YEAR.
10. Use the CURSOR PAD ,or or NUMBER
buttons to set the channel the TV will tune into.
,
11.
A ✔ in the box means the Event is enabled.
NOTE: 1. When the INFO button is pressed, the Event Timer Icon will only display the current date ON/OFF timer .
. The OFF TIMER will only activate if the TV was turned on by the ON TIMER, and any menu operations
2
(includes channel selection) were not made after this time. If you change the channel or operate the menu after the ON TIMER has been activated , the OFF
CAUTION: Do not use your TV as a deterrent when away from home by using the ON and OFF T
TIMER will deactivate.
IMERS.
For safety, the TV should be turned off when you are away from home.
55
Page 56
56
Setup
Select SETUP when setting your TV up for the first time.
1. Use the CURSOR PAD
or to select
the sub-menu of your choice.
2. Press the SELECT button to select.
Set The Menu Options
Setup the Language and background of the Menu OSD.
Set The Language
This feature will allow you to select any one of three different languages for all on-screen displays.
1. Use the CURSOR PAD or to select the
language
of
your choice.
2. Press EXIT to quit menu or select SET THE MENU
OPTIONS to return to previous menu.
Setup
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
Setup The Menu Options
Setup
Move SEL Return
Set The Langua ge : En glish Set The Menu Bac kground : Shad ed
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
On-Screen Display
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move
SEL Select
Power Swivel
OR
OR
OR
Page 57
Setup
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
On-Screen Display
OR
1. Use CURSOR PAD or to highlight SET THE
PAD 왗 or to select shaded or solid.
1. Press the CURSOR buttons
or to select the
modes
Max, Med or Min.
Use this feature to have the TV turned OFF automatically when a video signal is not detected for
about 12 seconds.
1. Press the CURSOR buttons
or to highlight
Y
es
or No.
NOTE: This feature works only for INPUT 1, 2, 3, Front and HDMI 1, 2, Front.
Move SEL Return
The Menu Background
Set
This function allows you to choose from two menu backgrounds.
MENU BACKGROUND option. Use the CURSOR
2. Select SOLID for a black background (no picture can be seen behind menu screen), select SHADED and a light background is visible.
3. Press EXIT to quit menu or select SET THE MENU
OPTIONS to return to the previous menu.
Setup
Setup The Menu Options
Set The Langua ge : Set The Menu Bac kground : Sha ded
Move SEL Return
Englis h
Set The Power Saving
This feature helps to increase the lamp life.
Image Power
Use this feature to have the save energy by changeing back light level in three modes: Max, Med and Min.
Automatic Power Saving
Setup
Set The Power Saving
Image Power Max
Automatic Power Saving
Yes
No
57
Page 58
Setup
Set The Inputs
Setup
Move SEL Return
Input1 :
****
Input2 :
****
Input3 :
****
Input-Front :
****
Auto Link : Off
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
HDMI1 :
****
HDMI2 :
****
HDMI-Front :
****
On-Screen Display
OR
1. Use the CURSOR PAD 왖 or 왔 to highlight the AUTO LINK option
and
or to change between the Off and Auto.
NOTA: The inputs labeled Gray Out(Skip) or Hide(Skip)
are disabled in the INPUTS selection.
Set The Inputs
U
se this feature to give a name to any of the video
inputs.
1. Press the CURSOR PAD
왖, 왔 to highlight the video
inputs.
. Press the CURSOR PAD
2
왗, 왘 to select your
choices.
INPUT 3 Auto Link
Use this function to automatically turn the TV on and tune to INPUT 3 when it detects a video signal to INPUT 3.
Auto
When AUTO is selected, the TV will turn on and switch to INPUT 3 automatically, when the INPUT 3 input device is turned on. This is convenient when you want to watch a movie with your VCR, laserdisc player, or DVD player.
Off
Select OFF to disable this function.
2. Press EXIT to quit menu or select SET THE INPUTS to return to previous menu.
NOTE: 1. Once the TV has been turned on using the AUTO LINK feature, it must be reset before AUTO LINK
is used again. To do this, turn your VCR, laserdisc, or DVD player OFF. This feature is now reset and will turn on your TV as described above.
2. If no remote control button is pressed after the TV is turned on by AUTO LINK, the TV will
automatically turn off after three hours.
58
Page 59
Setup
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
Digital
Set The Closed Captions
Setup
Move SEL Return
Caption Display : Off
Analog Mode : Captions
Channel : 1
Language : 1(Unknown)
Font : Default
H i t a c h i Size : Standard
Style : Standard
Digital
On-Screen Display
OR
OR
Set The Closed
Captions
Closed Captions are the dialogue, narration, and/or sound effects of a television program or home video which are displayed on the TV screen. Your local TV program guide denotes these programs as or .
1. Use the CURSOR PAD
왗, 왘, 왖 and 왔 to highlight
and select the function to change.
2. Press EXIT to quit menu or select SET THE CLOSED CAPTIONS to return to the previous menu.
Caption Display:
ON/OFF will turn the display on or off. AUTO will turn the display on when
Mute/Soft Mute is on.
Analog Captions:
Set CAPTIONS for Analog programs. This function will help choose and set available mode and channel.
Caption Mode:
CAPTIONS is for the program you are viewing. TEXT is for additional information such as news reports or a TV program guide. This information covers
the entire screen and viewing the TV program is not possible. Text may not be available with every program.
Channel:
1 is used for the primary language (usually English). 2 is sometimes used for a second language (may vary by region). 3 is sometimes used for a third language (may vary by region). 4 is sometimes used for a fourth language (may vary by region).
Setup
Set The Closed Captions
Caption Display :
Analog Mode : Captions
Channel : 1
Font : Default H i t a c h i Size : Standard Style : Standard
Move SEL
Language : 1(Unknown)
Return
Off
Digital Captions
Set captions for digital programs. This function will help choose and set available language, font, size and style of digital captions.
1. Use the CURSOR PAD
and
desired DIGITAL CAPTIONS feature.
select
왗, 왘, 왖 or 왔 to highlight
2. Press EXIT to quit menu or select SET CLOSED CAPTION to return to the previous menu.
NOTE: 1. Some types of digital closed captions will not work with this TV.
2. Caption Display will not work when viewing a 480p, 720p, or 1080i input via the
COMPONENT: Y-P
Digital Captions Font Style are sometimes different from the Font Style of Analog Captions.
3. Closed Caption and Digital Captions availability and content depends on the broadcaster. Closed
4.
BPR inputs.
Caption is available when Closed Caption icon is displayed on screen.
5.
Digital Captions
l
anguage will not be available (grayed out) when using analog channels.
59
Page 60
Setup
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
Move SEL Select
Reset The Software
Select The Quick Start Option
Set The Closed Captions
Set The Inputs
Set The Power Saving
Setup The Menu Options
Setup
On-Screen Display
OR
OR
NOTE: 1. If YES is selected, ALL TV MENU SETTINGS will be reset to the original factory settings on all modes
during the power cord is unplugged once or the POWER button is pressed for 5 seconds .
2. When the Quick Start Option has been set to ON , the option of Reset TV Settings will not operate
unless the power cord is unplugged once or the POWER button is pressed for 5 seconds.
5 seconds.
Se
lect The Quick Start Option
This feature will select QUICK START UP options. Set this feature to ON to have the TV tune channels (both Analog and Digital) quickly when first turning the TV on. Set this feature to OFF to save electricity. Selecting ON for the QUICK START UP feature will activate the TV tuners circuits when the TV is in “standby mode” which is commonly referred to as “off”. This will allow you to quickly tune to channels when first turning the TV on. Digital signals often change and this feature will monitor any changes and prepare the television to quickly present a picture. A small amount of electricity is used to continually monitor signals when this feature is selected.
Reset The Software
This feature shows software information and easy u
pgrade procedure. This function allows the TV software
to be upgraded by using a flash card (MMC/SD CARD). If a future software upgrade is required for your TV, HITACHI will notify and provide you with a flash card. In order to receive written notification and the flash card, please complete and return the warranty card.
1. Insert MMC/SD CARD.
Setup
SelectThe Quick Start Option
Select ON to have the TV tune channels quickly at 1st turn on.
Select OFF to save electricity
Of
Move SEL
f On
Select
2. Press the CURSOR PAD UPGRADE
NOW.
3. Press the SELECT button to select and start upgrading.
4. Unplug the power cord or press the POWER button for 5 seconds when the UPGRADE is complete.
NOTE:
Any power interruption during the upgrade process will cancel the upgrade. When this
or to highlight
Setup
Reset The Software
MMC Software Upgrade : Vxxxx.xxxx
Please Insert MMC card before upgrading.
Reset TV Settings
(Select "Yes" to return all settings to the factory default after main power OFF/ON.)
Move SEL
Upgrade Now
No Yes
Return
happens, repeat the upgrade procedure.
Reset TV Settings
T
his function allows you to Reset all TV Settings to the original factory settings on all modes during the next
power off/on.
1. Use CURSOR PAD , to highlight functions.
2. Press the SELECT button or CURSOR PAD to select Reset the Software Menu.
3. Use the CURSOR PAD to access the Reset TV settings option.
4. Select the "YES" option to Reset ALL the TV functions and unplug the power cord or press the POWER button for
60
Page 61
61
On-Screen Display
Power Swivel
Power Swivel
This feature controls the motorized stand. It allows
the customer to turn the LCD Television left or right using the remote control. This feature is only available when the Table Top Stand is connected (see page 6).
1. Use the CURSOR PAD
or to unlock or lock
the Power
Swivel. Exit the OSD menu system before controlling the motorized stand.
2. Press the CURSOR PAD
to rotate the TV to
the
right.
3. Press the CURSOR PAD
to rotate the TV to
the left.
4. Release the CURSOR PAD to stop rotation.
NOTE: 1. The Power Swivel has a maximum turning angle of 30° (left and right).
2. Do not place any objects in the path of the LCD television when using the power swivel feature.
3. Before using the power swivel, please make sure that the path of the LCD television is clear of any fingers, hands or any other body parts to avoid causing injury.
Power Swivel
Sele ct
SEL Retur n
Lock ed
Setup
Timers
Channel Manager Locks
Audio
Vid eo
Move SEL Select
Power Swivel
OR
Page 62
Equipment
SYMPTOMS
CHECK THESE ITEMS AND
TRY THESE ADJUSTMENTS
No Picture, no sound
Sound OK, picture poor
Picture OK, sound poor
Picture blurred
Lines or streaks in picture
Poor reception on some channels
Picture rolls vertically
No color
Poor color
 
   
 
   
   
   
   
   
   
   
Be
s
u
re external connectio
n is corre
c
t
Be sure
p
ower cord is plugged in
Be sure TV is switched''ON"
Try a
nother channel (station trouble)
Check antenna connections (ba
ck
of TV)
Check antenn
a
for brok
en lead-in
wire
Check for lo
c
al interfe
rence
Check outside
antenna
Adjust Contrast control
Adjust Brightn
ess control
Adjust Color control
Adjust Tint control
Adjust Volume control
Useful Information
Care and Troubleshooting
DO
Dust
the screen and cabinet with a soft cloth.
Clean the screen with a soft cloth moistened in warm water and dry with a soft cloth. A mild soap may be used if the screen is extremely dirty.
Place your LCD Television away from extreme heat,
humidity, and extremely dusty places.
Remove the plug from the wall outlet if your LCD
Television will not be used for a long period of time, for instance, when you go on vacation.
DO NOT
Do
not clean your screen with strong cleaners, polishes
or a chemically treated cloth.
Do not place rubber or vinyl products or cellophane
tape on your LCD Television.
Avoid repeatedly touching the screen.
Do not subject the remote control to shocks such as dropping it on the floor, etc. This may cause damage to the precision parts.
Avoid placing the remote control in a high humidity place or getting it wet. Do not leave it on or near a heater. Excessive heat or moisture may cause the unit to fail.
When the batteries run down, remote control operation will become erratic or become unresponsive. Replace the old batteries with two new “AA” size batteries. Do not use an old battery with a new battery.
Exposing the screen to direct sunlight for a long period
of time or heat may cause damage to the LCD
screen.
TROUBLESHOOTING
Y
our HITACHI LCD Television incorporates advanced power surge protection technology designed to protect
against component or circuit damage due to external or internal voltage power surges.
IF YOUR TELEVISION SHOULD APPEAR TO HAVE A LOSS OF POWER, PLEASE FOLLOW THIS PROCEDURE:
1. Press the POWER
BUTTON (ON/OFF
SWITCH) once.
2. If there is still no power, wait 30 seconds and press the POWER BUTTON again.
3. If there is still no power, unplug the power cord from the wall. Wait 30 seconds and plug the power cord back in. Press the POWER BUTTON again.
This protective technology should provide for years of lasting entertainment from your HITACHI LCD Television.
62
Page 63
Reception Problems
IGNITION NOISE:
B
lack spots or horizontal streaks may appear, picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps, electrical drills, and other electrical appliances.
GHOSTS:
G
hosts are caused by the television signal following two paths. One is the direct path and the other is reflected from tall buildings, hills or some other objects. Changing the direction or position of the antenna may improve reception. Ghosting may also be caused by defects in the antenna system such as unshielded leads or connecting several sets to the same antenna without using multiple antenna couplers.
SNOW:
I
f your receiver is located in the fringe area of a television station where the signal is weak, your picture may be marred by the appearance of small dots. When the signal is extremely weak, it may be necessary to install a special antenna to improve the picture.
RADIO FREQUENCY INTERFERENCE:
T
he interference produces moving ripples or diagonal streaks, and in some
cases, causes loss of contrast in the picture.
• PREVENTION OF AN OBSTACLE TO RADIO RECEIVERS
This television has been designed pursuant to the FCC class B Rules. This is to prevent a problem to Radio receivers. If this television causes a problem to Radio receivers, then take the following steps:
- Keep the television away from Radio.
- Adjust Radio antennas in order for the television not to receive interference.
- The antenna cable of Radio should be kept away from the television.
- Use a coaxial cable for antenna. You can check if this television influences Radio receivers by turning off all other equipment other than the television. If you find a problem receiving Radio when using the television, check the instructions mentioned above.
BLOCK NOISE (DIGITAL INPUT):
F
uzzy blocks may appear in some area or the whole area of the screen. This is usually caused by interference from automobile ignition systems, neon lamps, electrical drills, ghosting of the image and weak signals.
BLACK SCREEN:
W
hen using an antenna, weak signals will display a black screen. It may be
necessary to upgrade your antenna.
Useful Informationl
NOTE: T
he TV set can generate sound distortion in external devices such as a radio. Please separate radio
equipment from the TV set to a considerable distance.
63
Page 64
Useful Information
64
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
FCC Information
This device complies with part15 of the FCC Rules.Operation is subject to the following two conditions : (1) This device may not cause harmful interference and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that are not
expressly approved by Hitachi America ,Ltd. Home Electronics Division may void the user’s authority to
Cables
Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC Rules and Regulations.
Any cables that are supplied with the system must be replaced with identical cables in order to assure compliance with FCC rules. Order Hitachi spares as replacement cables.
Useful Info
AGENCY REGULATORY INFORMATION
o
p
erate the equipment.
This LCD Television receiver will display television closed captioning, ( or ), in accordance with
paragraph 15.119 and 15.122 of the FCC rules.
Note
Cable Compatible Television Apparatus- Tèlèvision câblocompatible, Canada.
INDUSTRY CANADA AGENCY REGULATORY INFORMATION
Page 65
Multiple Screen Fill Modes
㪚㪦㪧㪰㪩㪠㪞㪟㪫㩷㪺㩷㪈㪐㪐㪐㪄㪉㪇㪇㩷㪤㪦㪥㪫㪘㪭㪠㪪㪫㪘㩷㪪㪦㪝㪫㪮㪘㪩㪜㪃㩷㪠㪥㪚㪅㩷㪘㪣㪣㩷㪩㪠㪞㪟㪫㪪㩷㪩㪜㪪㪜㪩㪭㪜㪛㪅
(4:3 Standard/4:3 Expanded/4:3 Zoom 1/
4:3 Zoom 2/16:9 Standard1/Standard2/16:9 Zoom)1
4MB 10-bit
3D Y/C Comb Filter
Power Consumption
Average Power : . . . . . . . . . . . . . . . L47V651 - 303 W
Maximum Power : . . . . . . . . L47V651 - 303 W, 2.55 A
Antenna input impedance . . . . . . . . . . . . . . . .75 Ohm
Channel coverage . . . . . . . . . . . . . . . . . . . . . . . 191ch.
VHF-Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 ~ 13
UHF-Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 ~ 69
CATV Mid Band
Video:
. . . . . . . . . . . . . . . . . . . . . . A-5 •~
New 1080P Full HD LCD Display Panel
A-1
Power Swivel cable
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-I
Super•Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . J-W
Hyper•Band . . . . . . . . . . . . . . . . . . . . . . . W+1 - W+28
Ultra Band . . . . . . . . . . . . . . . . . . . . . . . W+29 - W+94
Video . . . . . . . . . . . . . . . . . . . . . . . . 1.0Vp-p, 75 Ohm
S-Video
Luminance (Y) . . . . . . . . . . . . . . . . . 1.0Vp-p, 75 Ohm
Chrominance (C) . . . . . . . . . . . . . 0.286Vp-p, 75 Ohm
Component Video
Luminance (Y) . . . . . . . . . . . . . . . . . 1.0Vp-p, 75 Ohm
Chrominance (PB/PR) . . . . . . . . . . . 0.7Vp-p, 75 Ohm
Audio input Impedance . . . . . . . . . . . . . . . . 270k Ohm
Average input level . . . . . . . . . . . . . . . . . . . 470mVrms
HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (19 PIN)
Outputs:
Video1.0Vp-p. 75 Ohm
Audio . . . . . . . . . . . . . . . . . . . . . . .470mV
rms, 1k Ohm
Optical Out (Digital Audio) . . . . . .1 Optical Connector
Audio:
MTS Stereo/SAP Bass Boost
20W Soft Mute (50%)
Supplied Accessories:
Remote Control
Batteries (AA) 6'
AC Power cord cable
Power Swivel Table Top Stand (assembled)
Lip Sy nc control
Optional Accessories:
For U.S. Models: Please access our website:
www.hitachi.us/tv
INPUTS/OUTPUTS
Wideband Component Y, Pb,Pr . . . . . . . . . . . . . . . . 2
Composite Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Antenna (RF)Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Audio Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Monitor Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Optical Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Upgrade Card Slot . . . . . . . . . . . . . . . . . . . . . . . . . . 1
HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
RS232C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SPECIFICATIONS
Pixel Pitch:
F
C
C class: . . . . . . . . . . . . B for Consumer Use
Features and Specifications
For Canada Models: Please access our website:
www.hitachi.ca/tv
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . L42V651 - 215 W
. . . . . . . . . . . . . . . . . . . . . . . L42V651 - 215 W, 1.85 A
L42V651. . . . 0.4845(horiz.) x 0.4845(vert.) mm.
L47V651. . . . 0.5415(horiz.) x 0.5415(vert.) mm.
Operation Temperature . . . . . . . . . . . . . . . 41°F a 95°F
Swivel Output . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Photo Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features:
New Easy-to-Use On-Scr Language)
Region 5 (Downloadable V-Chip) Preprogrammed Remote Control
Power Management: ON/OFF via signal detection Picture Enhancement Input Signal Identification HDMI (High Definition Multimedia Interface)(High Bandwidth Digital Content Protection V1.1 Compatible)
C
losed Captions (Analog and Digital)
Sleep and Event Timer
1920 x 1080 Display Resolution
IPS (In Plane Switching Technology)
Wide Viewing Angle: More than 178°
Color Temperature Presets: High, Medium,
Standard and Black/White.
Picture Modes :Day(Normal), Day(Dynamic) and Night
Inputs:
Power Input . . . . . . . . . . . . . . . . . . . . .AC 120V, 60Hz
Television System . . . . . . . . . . . . . . . NTSC Standard
Technology
ATSC Standard (8 VSB, 64-QAM, 256-QAM)
een Menu Contr
ol (3
Surround Sound
Power Requirements . . . . . . 108-132VAC, 60Hz
1
Screen mode availability varies by input format
HDTV Televisions display HDTV only when an HDTV source is available. All specifications, weights, and dimensions are subject to change without
prior notice. Please access www.hitachi.us/tv for detailed specifications and dimensions for custom installations.
UltraVision Digital is a registered trademark of Hitachi Home Electronics (America), Inc.
Interface LLC.
*Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia
are trademarks or registered trademarks of HDMI Licensing
Useful Informationl
65
Page 66
Set Dimensions
47 Inch Models (Includes Table Top Stand) Weight (lbs./kg): 74.3/33.7
42 Inch Models (Includes Table Top Stand) Weight (lbs./kg): 61.3/27.8
Useful Information
Units
47"
Inches 11-1/16 14-1/4 45-5/16 41-5/16 23
mm
Units
42"
Inches 10
mm
Rear
View, Use as Reference for Wall Mount Bracket
C
B
A
281.05 362.26 1151.30 1050 584.82 1039
B
A
13-3/16 41 36-13/16 20
253.56 334.77 1041.70 934.5 523 930.20
D E
C
D
F
40-15/16 23-7/16 1
F
E
-9/16 36-5/8 20-3/4 14-1/2 12-7/16 26-15/16 29-1/4 2-5/16 5-7/16 4-1/2 4-7/16 4-1/2 24-13/16 11 6-11/16 4-5/16
H
G
.68 595 399.40 346.60 746 805 59.10 138.70 114.70 112.08 114.18 630 280
G
527 368.40 315.60 684 743 59.10 138.70 114.70 112.10 114.18 630 280
I
J
5-3/4 13-5/8 29-3/8 31-11/16 2-5/16 5-7/16 4-1/2 4-7/16 4-1/2 24-13/16 11 6-11/16 4-5/16
H
I
J
L
K
L
K
N
M
M
O
P
Q
N
O
P
Q
S
R
169.80 110.20
S
R
169.80 110.20
T
T
66
Page 67
Service Hotline
To locate an authorized HITACHI
service
facility in the continental
U.S.A. and Canada,
DIAL TOLL FREE
7 days a week, 24 hours a day
1-800-HITACHI
(1-800-448-2244)
Hitachi
ACHI AMERICA, L
HIT
HOME
HITACHI has made every effort to assure you hours of trouble free operation from your unit. However, should you require service, a network of HITACHI Authorized Service Facilities has been established in all 50 states and Puerto Rico. Each facility will provide you with convenient and expedient assistance. Our service hotline operator will direct you to the HITACHI
Authorized Service Facility nearest you. Just present proof of purchase and/or delivery receipts to the Hitachi Authorized Service Facility, and service will be rendered in accordance with the terms of the limited warranty as stated on your warranty card or operating guide.
Should you have any questions regarding warranty, service, operation, or technical assistance, please contact:
Hitachi America, LTD. Home Electronics Division 900 Hitachi Way Chula Vista, CA 91914-3556
ELECTRONICS DIVISION
TD.
HITACHI CANADA, LTD. DIGITAL MEDIA DIVISION
S
hould you have any questions regarding warranty, service, operation, or technical assistance, please contact:
In Canada: 1-800-HITACHI (1-800-448-2244)
Monday – Friday (EST).........................9:00am – 7:00pm
Saturday (EST) .....................................9:00am – 5:00pm
Pour de plus amples renseignements sur le service durant la période couverte par la garantie, sur le fonctionnement ou pour de l’assistance technique communiquez avec:
Au Canada: 1-800-HITACHI (1-800-448-2244)
Lundi - Vendredi L’EST ........................9:00am – 7:00pm
Samedi L’EST.......................................9:00am – 5:00pm
HITACHI CANADA, LTD. 1-2495 Meadowpine Blvd. Mississauga, Ontario L5N 6C3
Useful Informationl
67
Page 68
Service Information
When you call HITACHI SERVICE HOTLINE they will require some information related t
o the TV MODEL NAME and SERIAL # in order to give you the proper support. This information is located on the back of the TV and also on the RIGHT SIDE of your TV set. Please follow the next steps to find this information and then provide to SERVICE.
Look on the right side of the TV.
Locate the LABEL where it shows the information related to MODEL NAME and SERIAL #.
H
ITACHI Service Department will require this information in order to give you the proper support regarding your questions.
Useful Information
68
Page 69
TELEVISOR de LCD Pantalla Plana
Guía
de funcionamiento para
L47V651 y L42V651
INSTRUCCIONES IMPORTANTES DE SEGURIDAD............................................................ 70-71
USO POR PRIMERA VEZ ..................................................................................................... 72-89
EL CONTROL REMOTO ...................................................................................................... 90-105
MENÚ EN PANTALLA ........................................................................................................... 106-129
INFORMACIÓN ÚTIL ....................................................................................................... 130-136
Page 70
Instrucciones Importantes de Seguridad
70
PUNTOS DE SEGURIDAD QUE USTED DEBE SABER
SOBRE SU TELEVISOR DE LCD
HITACHI
Nuestra reputación se ha formado en base a la calidad, desempeño y facilidad de servicio de los televisores de LCD pantalla plana Hitachi.
La seguridad está en primer lugar en nuestra mente al diseñar estas unidades. Para ayudarlo a operar estos productos en forma apropiada, esta sección ilustra datos de seguridad que serán de beneficio para usted. Léalos cuidadosamente y aplique los conocimientos adquiridos para operar con propiedad su televisor de LCD pantalla plana Hitachi.
Complete su tarjeta de garantía y envíela por correo a Hitachi. Esto le permitirá a Hitachi notificarlo rápidamente en el caso improbable de que se descubra un problema de seguridad en el modelo de su televisor.
Siga todas las advertencias e instrucciones marcadas en este televisor de LCD pantalla plana.
PRECAUCIÓN
RIESGO DE DESCARGA
ELÉCTRICA NO ABRIR
AVISO: PARA REDUCIR EL RIESGO DE DESCARGA ELÉCTRICA, NO
RETIRE LA CUBIERTA NI EL PANEL POSTERIOR. EN EL INTERIOR
DEL APARATO NO EXISTEN PARTES QUE DEBAN SER REPARA­DAS POR EL USUARIO. SOLICITE SERVICIO O REPARACIÓN
A PERSONAL CALIFICADO.
El símbolo del rayo dentro de un triángulo equilátero tiene por finalidad alertar al usuario acerca de la presencia de voltaje peligroso (sin aislamiento) en el interior del producto, que puede tener la intensidad suficiente como para considerar un riesgo de descarga eléctrica.
El signo de exclamación dentro de un triángulo equilátero tiene por finalidad alertar al usuario de instrucciones importantes de operación y mantenimiento (servicio) en la literatura que acompaña a este aparato.
10. Proteja el cable de alimentación para que no se p
ise ni esté retorcido, especialmente en las clavijas, los receptáculos y el punto por el que sale del aparato.
11. Utilice únicamente los accesorios especificados por el fabricante.
12. Utilice únicamente el carro, mueble, tripie,
soporte o mesa especificado por el fabricante o de venta con el aparato. Si utiliza un carro, tenga cuidado al mover el
aparato para evitar que se caiga y provoque lesiones personales.
13. Desconecte el equipo durante tormentas eléctricas o cuando no lo vaya a utilizar durante periodos prolongados.
14. Para tareas de mantenimiento, diríjase a personal calificado. Será necesario recurrir a tareas de mantenimiento si el aparato sufre daños de cualquier tipo, si el cable de alimentación o la clavija están dañados, si ha caído líquido u otros objetos en el aparato o si éste ha sido expuesto a la lluvia o humedad, si no funciona con normalidad o se ha caído.
15. Los televisores están diseñados para cumplir con los estándares de seguridad recomendados para inclinación y estabilidad. No aplique fuerza excesiva a la parte superior o frontal de gabinete que pudiera hacer que el televisor se caiga causando daño del producto y/o daño personal.
16. Siga las instrucciones de montaje en la pared, estante o techo según lo recomendado por el fabricante.
17. Una antena exterior no deberá ser instalada en la cercanía de líneas de alimentación externas ni de otros circuitos de iluminación eléctrica.
18. Si se conecta una antena externa ó sistema de cable a la unidad, cerciórese de que el sistema de antena ó cable está conectado a tierra para darle protección contra sobretensión y acumulación de carga estática. La Sección 810 del Código Nacional de Electricidad, ANSI/NFPA 70-1984, proporciona información con respecto a como poner a tierra el mástil apropiadamente y la estructura de sostenimiento, al poner a tierra el alambre de entrada a una unidad de descarga de la antena, tamaño de los conectores para poner a tierra, localidad de la unidad de descarga de antena, conexión de los electrodos a tierra y los requisitos para el electrodo que pone a tierra.
LEA ANTES DE HACER FUNCIONAR EL EQUIPO
Siga
todas las advertencias e instrucciones indicadas en
este televisor de LCD pantalla plana.
1. Lea estas instrucciones.
2. Conserve las instrucciones.
3. Tomar en cuenta todos los avisos.
4. Siga todas las instrucciones.
5. No utilice este aparato cerca del agua.
6. Limpie el equipo con un paño seco y suave.
7. No bloquee las rendijas de ventilación. Instale el equipo según las instrucciones del fabricante.
8. No lo instale cerca de fuentes de calor, como radiadores, registros de calor, hornos o demás aparatos (incluidos amplificadores) que produzcan calor.
9. No altere la función de seguridad de la clavija de tipo conexión a tierra. La clavija de tipo conexión a tierra tiene dos terminales y una tercera terminal de conexión a tierra. La tercera terminal se incluye para su seguridad. Si la clavija suministrada no encaja en la toma, póngase en contacto con un electricista para que cambie el receptáculo (enchufe).
NEC - CODIGO NACIONAL DE ELECTRICIDAD
ABRAZADERA
DE TIERRA
EQUIPO DE SERVICIO ELECTRICO
ABRAZADERAS DE TIERRA
ALAMBRE DE ENTRADA DE LA ANTENA
UNIDAD DE DESCARGA DE LA ANTENA (NEC, SECCION 810-20)
CONDUCTORES DE PUESTA A TIERRA (NEC, SECCION 810-21)
SERVICIO DE ALIMENTACION DE SISTEMA ELECTRODO DE PUESTA A TIERRA (NEC ART 250, PARTE H)
Nota para el instalador del sistema CATV. Este recordatorio se provee para llamar la atención del instalador de sistema CATV hacia el Artículo 820-44 de la NEC que brinda guías para una puesta a tierra apropiada y en particular, especifica que la tierra del cable debe conectarse al sistema de tierra del edificio, tan próximo a la entrada de cable como sea más práctico.
Page 71
Instrucciones Importantes de Seguridad
Fuente de energía
Este televisor de LCD esta diseñado para operar con corriente CA, 120 voltios 60 Hz. Inserte el cable de electricidad en un tomacorriente de 120 voltios a 60 Hz. La clavija se utiliza como dispositivo de desconexión y continua estando disponible.
Para impedir descarga eléctrica, no utilice la clavija (polarizada) del televisor de LCD con una extensión, receptáculo u otro enchufe a menos que los terminales y el terminal de tierra puedan insertarse completamente para evitar que la terminal este expuesta.
Nunca conecte el televisor de LCD a 50 Hz, corriente directa o cualquier otro voltaje que no sea el especificado.
Precaución
Nunca quite la tapa trasera del televisor de LCD ya que puede exponerlo a voltajes muy altos y a otros peligros. Si el televisor no funciona en forma apropiada, desenchufe el televisor de LCD y llame a su distribuidor
o centro de servicio autorizado.
Precaución
Ajuste solamente los controles que se incluyen en las instrucciones, ya que cambios inapropiados o modificaciones que no estén expresamente aprobadas por Hitachi podrían anular la garantía.
Advertencia
• Para reducir el riesgo de fuego o shock eléctrico, no exponga el aparato a lluvia o humedad.
•El televisor de LCD no se debe exponer a filtrado o salpicado de líquidos y a objetos con líquidos, tales como floreros que no se deben colocar sobre el televisor.
• Este aparato se debe conectar a la red de electricidad con una conexión de protección a tierra.
Visión pública de material con derechos de autor
L
a visión pública de programas transmitidos por estaciones de televisión o compañías de cable, así como programas de otras fuentes, puede requerir autorización previa del difusor o propietario del material de programa de video.
Este producto incorpora la tecnología de protección de derechos de autor, que está protegida por demandas de métodos de ciertas patentes de EE.UU. y otros derechos de propiedad intelectual. El uso de la tecnología
de protección con derechos de autor debe ser autorizada, y es solo para uso en el hogar u otros usos limitados al consumidor a menos que sea autorizado. Está prohibida la ingeniería inversa o el desmontaje.
Nota
Este televisor digital es capaz de recibir programación básica análoga, básica digital de televisión por cable, mediante la conexión directa a un sistema de cable que provea tal programación. Ciertos
servicios de cable digital interactivos tales como video-on-demand (sobre pedido), una guía de programas mejorada del operador de cable y servicios de transmisión de datos por televisión pueden requerir el uso de un decodificador. Para mayor información llame a su compañía de cable local.
Nota
• No existen partes remplazables por el usuario dentro
del televisor de LCD.
• Los números de serie y modelo se indican en la parte
posterior y el lado derecho del televisor de LCD.
Aviso sobre el Plomo y Mercurio
Hg
Este producto contiene plomo y una o más lámparas irremplazables de mer o disponer de acuerdo a las leyes aplicables mación de reciclaje y desecho , contactar a su agencia local de gobierno o visitar la página de internet www.eiae.org (en EE.UU.) ó www.epsc.ca (in Canadá). PARA MAYOR INFORMACIÓN, LLAME AL 1-800-HITACHI.
curio. No tirar en la basura. Reciclar
. Para infor-
71
Page 72
Accesorios
Cable para
Control Remoto
tipo “AA” 1.5V
Cable de energía
Dos baterías
Base Giratoria
Uso por primera vez
Para modelos de U.S.A. : Para accessorios opcionales, visitar nuestro sitio de internet : www.hitachi.us/tv
Asegurarse de que tiene los siguientes accesorios antes de desechar el material de empaque.
Para modelos de Canadá :
Para
accesorios opcionales, visitar nuestro sitio de internet : www.hitachi.ca/tv
PRECAUCIÓN: 1. El montaje en el techo no es recomendable. Montar el panel en el techo no provee
la
adecuada ventilación a lo electrónico ó el apropiado soporte al panel frontal de vidrio. Este televisor de LCD está diseñado para una inclinación máxima de 45° en vertical.
2. La base para la pared para los modelos 42" y 47" es WM07S. Favor de ver la página 75 para información importante relacionada con la base de la pared. La base es
un accesorio opcional (No está Incluida).
Control Remoto CLU-4374A
(No. Parte HL02404 )
Dos baterias tipo "AA" , 1.5V.
Cable de energía (No. Parte EV01841).
Cable para Base Giratoria (No. Parte EW08434).
INSTALACIÓN Y REMPLAZO DE LAS BATERIAS DEL CONTROL REMOTO
1.
Abrir la cubierta de las baterias del control remotopresionando la pestaña para quitar la cubierta.
2.
Colocar dos baterias tipo “AA” para el control remoto resortes y luego sacarlas.
3. Coincidir las marcas de las baterias (+) y (-) con las marcas del compartimiento.
4. Insertar la parte inferior de la batería, el lado (-) neg, en el compar­timiento primero , luego empujar hacia los resortes e insertar la parte superior de la batería forzar la batería dentro del compartimiento.
5. Colocar de nuevo la cubierta.
PRECAUCIÓN : No coloque la baterias con la polaridad ‘+’ y ‘-’ invertidas esto puede causar que las baterias se derramen dentro del compartimiento.
, el lado (+) pos, en su lugar. No
. Al r
emplazar las baterias, empujar hacia los
Vista Posterior (Control Remoto)
Presionar la pestaña para quitar la cubierta
.
72
Page 73
Uso por primera vez
47" y 42"
30 cm (12 pulgadas)
10 cm (4 pulgadas)
10 cm (4 pulgadas)
Asegurando a una pared
1. Use el cable metálico (dos posiciones) y amarre
el televisor de LCD al tornillo sujetador en la parte posterior como se muestra abajo.
* Favor de ajustar la longitud del cable para evitar
que
la TV toque la pared al girarla.
Cable
Cómo colocar su nuevo televisor de LCD HITACHI
Como tomar medidas para evitar que el televisor de LCD se incline e impedir posibles daños, es importante montar la unidad en una superficie estable y lisa.
NOTAS: 1. No bloquee los ranuras de ventilación del
televisor de LCD. El bloqueo de agujeros de ventilación podría causar fuego o defectos.
2. En caso de un síntoma anormal, desenchufe el cable de CA.
3. Si compró el soporte de montaje a la pared, solicite un instalador profesional. No lo instale por su cuenta.
4. Instale la unidad en un área apropiada donde
no se exponga a nadie al peligro de golpearse
(por ejemplo, manos cabeza o cara) contra el
borde de la unidad y causar daño personal.
2. Mantenga el televisor de LCD a 4 pulgadas
(10 cm) de la pared excepto cuando lo monta usando un soporte de montaje a la pared.
3. Asegure el televisor a la pared como se muestra en la fig.
Precaución
al mover la unidad principal
Como
este producto es pesado, para moverlo, se requieren dos personas para transportarlo con seguridad. Cada vez que se mueva la unidad debe levantarse hacia adelante usando la parte superior y la base a ambos lados del televisor para lograr estabilidad. Cuando mueva el televisor,
levante de las agarraderas que sostienen la estructura luego tomar de la parte superior como se muestra :
73
A
(a) Sin Usar
Base Giratoria
(b) Usando
Base Giratoria
B
Cable Cable
ANTENA
A menos que su televisor de LC
D esté conectado a
un sistema de televisión por cable o a un sistema de antena externa, se recomienda una buena antena de televisión color para mejor rendimiento. Sin embargo, si se encuentra en un área con señal excepcionalmente buena sin interferencia y sin fantasmas en la imagen, una antena interior puede ser suficiente.
UBICACI
Ó
N
Seleccione un área donde la iluminación interior o la
luz solar no se diriján directamente sobre la pantalla. También asegúrese de que la ubicación seleccionada permite un flujo libre de aire hacia y desde la tapa posterior del equipo. Para evitar el aumento de temperatura interna, mantenga un espacio de 4 pulgadas (10 cm) desde los lados y la parte posterior del televisor, y 30 cm (12 pulgadas) desde la parte superior del televisor al techo. Para evitar deformaciones del gabinete, cambios en el color del gabinete y mayor oportunidad de falla en el equipo, no coloque el televisor donde las temperaturas puedan volverse excesivamente cálidas por ejemplo, a la luz solar o cerca de un calefactor, etc.
CONEXIÓN DE CABLE PARA BASE GIRATORIA
Conecte un extremo del cable al conector "SWIVEL" de
la parte posterior del televisor de LCD. Conecte el otro extremo del cable al conector en la base giratoria. Para ver información más a detalle, por favor vea la instrucción de instalación en la página siguiente.
ANGULO DE ROTACIÓN
El
máximo angulo de rotación es 30° (Izq. y Der.). No colocar objetos en el paso del televisor al usar la base giratoria.
C
D
30°
30°
A B
5 in.
12.5 cm
12 in.
30 cm
42” 47”
5. Si la base giratoria no va a ser usada,
el televisor LCD debe ser sujetado a la
pared como se muestra en la fig. (a).
6. Si la base giratoria va a ser usada, el Te­visor LCD debe ser sujetado a la pared como se muestra en la fig. (b).
C D
9.1 in.
14.05 in.
23.1 cm
35.7 cm
42"
10.2 in.
15.15 in.
25.9 cm
38.5 cm
47"
Page 74
Pasar el cable de AC a través del sujetador #1 y
Los cables de señal, el cable de AC y para la base giratoria pueden ser sujetados con el sujetador #2.
Cable de AC
Sujetador #2: Usar para sujetar el cable de AC
con el resto de cables usados en el
Sujetador #1 : Pasar el cable de AC a través de este
s
u
jetador primero; luego jalar el extremo
para sujetar el cable al televisor.
INSTRUCCIÓN DE COMO COLOCAR EL CABLE DE AC Y EL CABLE DE LA BASE GIRATORIA
El cable de AC y el cable de la base giratoria que vienen incluidos en su nuevo Televisor de LCD necesitan ser ensamblados correctamente para evitar que se desconecte al girar el Televisor con su base. En el televisor existen 2 sujetadores de plástico localizados en la parte posterior del Televisor para
conectarlo al televisor. Jalar el extremo del sujetador para sujetar el cable de AC con el televisor.
televisor.
s
ujetar el cable de AC y el cable de la base giratoria . Favor de seguir las siguientes intrucciones.
Conector "Swivel" en
C
onector "Swivel" en la
Base Giratoria.
Conecte un extremo del cable de la base giratoria al conector "SWIVEL" de la parte posterior del televisor de LCD. Conecte el otro extremo del cable al conector en la base giratoria.
la parte posterior
Cómo
colocar su nuevo televisor de LCD Hitachi
Uso por primera vez
74
del televisor de LCD.
Page 75
Uso por primera vez
BASE del TELEVISOR
Cómo colocar su nuevo televisor de LCD Hitachi
Quitar los 4 tornillos y luego
remover los 2 soportes de
metal.
CONFIGURACIÓN PARA MONTAJE EN LA PARED
PASO (1) :
Localizar los soportes de metal de la BASE en la parte posterior del televisor. Estos metales son usados para sostener el televisor y la base; se tienen que quitar 4 tornillos de los soportes para separar el televisor y la base.
2 Sportes METAL de la BASE
PASO (2):
A
ora hay que quitar los 5 tornillos del metal de la BASE del Televisor , ahora la BASE puede ser separada del Televisor.
h
Para dimensiones del ensamble en la PARED referirse a la página 134.
METAL de la BASE
5 Tornillos
Para el Modelo L47V651 y L42V651
PRECAUCIÓN - Este televisor de LCD solo puede usar la base para la pared WM07S de Hitachi. Al usar otra
base puede causar inestabilidad en el televisor provocando posibles heridas personales.
NOTA: U
se la base para pared (WALL MOUNT) para el Televisor de LCD de acuerdo al tamaño.
Visite nuestro sitio de internet: www.hitachi.us/tv para accesorios de su Televisor.
75
Page 76
Uso por primera vez
Cómo colocar su nuevo televisor de LCD Hitachi
AIR / CABLE
AIR / CABLE
or
VISIÓN
La mejor posición para ver la imagen es en frente del televisor y de 10 a 18 pies lejos de la pantalla.
Durante las horas del día, las reflexiones o reflejos de luz externa pueden aparecer en la pantalla. Si esto sucede, pueden ser usadas cortinas para reducir el reflejo o la TV puede cambiarse de lugar en el cuarto.
Si el audio del televisor es conectado a las bocinas de un sistema de alta fidelidad (Hi-Fi), la mejor calidad de audio se obtendrá al colocar las bocinas equidistantes a los lados del receptor y los más cerca posible a la altura del centro de la imagen. Para una mejor separación de audio (stereo), coloque las bocinas por lo menos 4 pies de los lados del Televisor, coloque las bocinas traseras (surround speakers) a lado o detrás del angulo de visión. Diferencias en tamaño de los cuartos y ambientes acústicos requieren alguna experimentación con la colocación de las bocinas para una mejor calidad de
CONEXIONES DE ANTENA EN EL
PANEL POSTERIOR
Antena VHF (75-Ohm) /CATV (Cable TV)
Al usar un sistema de cable coaxial 75-Ohm, conectar el cable coaxial de señal CATV a la terminal AIR/CABLE (75-Ohm) . O si tiene una antena, conectar al cable coaxial a la misma terminal AIR/CABLE.
VHF (300-Ohm) antenna/UHF antenna
Al usar un cable plano de 300-Ohm de una antena externa, conectar los cables de la antena VHF ó UHF a los tornillos del adaptador VHF ó UHF. Insertar el adaptador a la terminal de antena en el TV.
Al usar ambas antenas VHF y UHF conectadas
Usar un mezclador de cable/antena opcional conectado a la terminal de antena, y conectar los cables al mezclador. Consultar con su distribuidor o centro de servicio por los mezcladores de antena.
Al cable de señal CATV
A
la antena externa
A la antena externa VHF ó antena UHF
A la antena externa ó sistema de CATV
A la antena
UHF
Mezclador de Antena
AIR / CABLE
NOTA: Al conectar un cable plano de 300-Ohm puede causar interferencia. Es más recomendable usar un
cable coaxial de 75-Ohm.
audio.
80
80
4" Minimo
4" Minimo
MEJOR ANGULO DE
VISIÓN HORIZONTAL
5'
10'
15' 20'
S
S
R
L
76
Page 77
Uso por primera vez
Cables y Conectores
TERMINAL DE AUDÍFONO 3.8mm SALIDA DE AUDIO ESTÉREO
2 Terminales
tipo PHONO ó RCA
plano 300-Ohm doble hilo
Este cable de antena externa debe ser conectado a un adaptador de antena (300-Ohm a 75-Ohm).
Usado en todos los cables de video y audio estándar los cuales conectan las entradas y salidas localizados en la parte posterior y panel de control lateral del televisor.
Cable Coaxial tipo “F” a 75-Ohm
Para conectar señales de RF (antena ó cable TV) a la terminal de antena en el televisor.
Cable S-Video (Super Video)
Este conector es usado en videocámaras, VCRs y repro­ductores de laser con la opción S-Video en lugar del cable de video estándar para producir una imagen de alta calidad.
Cable Óptico
Este cable es usado para conectar a un amplificador de audio con entrada de Audio Optica. Usar este cable para la mejor calidad de sonido.
Cable HDMI
Este cable es usado para conectar sus equipos externos como Set-Top-Boxes ó reproductores de DVD equipados con salida HDMI conectada a la entrada HDMI del Televisor.
Cable Estéreo (Terminal audifono 3.8mm a 3.5mm )
Usado en todos los cables de audio y video estándar que conectan las entradas y salidas localizadas en la parte posterior o en el panel de control lateral del televisor.
La mayoría de las conexiones de audio/video entre equipos puede hacerse con cables blindados de audio y video que tienen conectores RCA. Para una mejor calidad, los cables de video deben ser coaxiales blindados de 75-Ohm. Los cables pueden ser comprados en la mayoría de las tiendas que vendan productos de audio/video. Enseguida unas ilustraciones y nombres de conectores. Antes de comprar cualquier cable, asegúrese de los tipos de conectores de salida y entrada requeridos por los diferentes tipos de equipos y el largo de cada cable.
Cable
Cable Phono ó RCA
Cable de la Base Giratoria (Incluído)
Este cable se usa para conectar la base giratoria al panel posterior del Televisor de LCD.
77
Page 78
Uso por primera vez
Guía Rápida para las Funciones del Control Remoto
Además de controlar todas la funciones de su Televisor de LCD Hitachi, el nuevo control remoto es diseñado para operar diferente tipos de equipos, tales como, reproductores de DVD, CBL (Cajas de Cable), set-top-boxes, receptores de satélite, y VCRs. El control remoto debe ser programado para controlar el equipo deseado. Ver páginas 90-105 para una completa descripción de todas las opciones y como programar el Control Remoto.
2. El código de la VCR está incluido en el modo de PVR.
SIGNIFICADO
TV – Televisión PVR – Grabadora Personal de Video CBL – Caja de Cable DVD – Reproductor de Disco Digital de Video (DVD) SAT – Satélite
BOTÓN de Encendido (POWER)
(TV, DVD, SAT/CBL,PVR/VCR)
Enciende ó apaga el equipo elegido.
BOTÓN DE LOS EQUIPOS (SOURCE ACCESS)
(TV, DVD, PVR/VCR, SAT/CBL)
Cambia el modo del Control Remoto Universal para controlar el equipo elegido.
BOTONES DEL DVD/VCR (DVD, PVR/VCR)
Controlan las funciones de su VCR y DVD.
BOTÓN DIA/NOCHE (DAY/NIGHT)
(TV)
Cambia entre los modos de imagen Día (DAY) y Noche (NIGHT).
BOTÓN DEL ASPECTO ó FORMATO (ASPECT)
(TV)
Cambia la relación de aspecto o formato de la imagen
BOTÓN DE CONTROL DEL PIP (Picture-in-Picture))
(TV)
Presionar para mostrar el modo del PIP.
BOTÓN de MENU
(TV,DVD,SAT/CBL,PVR/VCR)
Accesa el menú en pantalla (OSD menu).
BOTÓN (-)
(TV,STB)
El botón (-) es usado al estar el control remoto en modo Set-Top-Box (STB) ó cuando el TV usa un canal digital (HD).
BOTONES NUMÉRICOS
(TV, DVD, SAT/CBL, PVR/VCR)
Usados para poner manualmente el el canal en el Televisor, y usados para poner números dentro de la navegación del menú en pantalla (OSD).
BOTÓN de la GUÍA
(SAT/CBL, PVR)
Accesa la guía de programación de canales de
otros equipos.
BOTÓN PARA SALIR (EXIT)
(TV, SAT/CBL, PVR/VCR)
Sale de algún sistema de menú OSD ó INPUTS si es que el menú es desplegado.
BOTÓN de Canal Anterior (LAST CH)
(TV, SAT/CBL, PVR)
C
a
mbia entre el canal actual y el último canal visto
BOTÓN ENTER
Pr
esionar para usarlo como la opción SELECT.
(TV, VCR, SAT/CBL)
BOTÓN de Información (INFO)
(TV, STB, CBL, PVR)
Despliega varia información en la imagen tal como información del canal, horario, entrada, etc.
BOTONES DE CANALES ARRIBA & ABAJO (TV, CBL, STB, PVR/VCR)
Cambia hacia arriba ó abajo los canales.
BOTONES CURSOR/SELECT
(TV, DVD, SAT/CBL,PVR/VCR)
Los botones CURSORES son usados para navegar el cursor dentro del menú en pantalla y las entradas (INPUTS), y el botón SELECT es usado para Elegir/Activar la opción marcada.
BOTONES DE VOLUMEN
(TV )
Ajusta el nivel de audio de su Televisor, ya sea incrementando ( ) ó reduciendo ( ).
BOTÓN DE PAUSA (TV, PVR/VCR, DVD)
Presionar para mostrar y cambiar el modo Freeze del TV. También se usa para pausar otros equipos al estar el
BOTÓN de Entradas (INPUTS)
(TV)
Accesa el menú de Entradas (INPUTS).
INDICADOR DEL MODO
Enciende ó parpadea para mostrar el modo en el que está el Control Remoto al ser presionado el botón SOURCE SELECT.
BOTÓN CC (Subtítulos)
(TV)
BOTÓN de Volumen Bajo (MUTE)(TV)
Reduce el nivel de audio a 50% si se presiona una vez, y se apagará por completo si se presiona
dos veces. Presionar una tercera vez más para restaurar el nivel de audio.
BOTÓN DE CANALES FAVORITOS (FAV CH)(TV)
Presionar para entrar/accesar el modo de canales favoritos (FAV CH). (Los canales favoritos solo operan
en modo TV).
Presionar para mostrar y cambiar el modo de subtítulos (Closed Caption).
anteriomente.
NOTAS : 1.
EL sensor de control remoto del TV está localizado en la parte inferior derecha de la pantalla.
para controlar las funciones del TV, Apunte el control remoto directamente al sensor de control remoto para mejor resultado.
VCR – Reproductor de Videocassete
control remoto en modo DVD ó PVR/VCR.
en la TV.
78
Page 79
Uso por primera vez
Controles del Panel Lateral
Botón MENU/SELECT
Este botón permite entrar al MENU, haciendo posible configurar las opciones del Televisor a su preferencia sin usar el control remoto. Este botón también sirve como el botón SELECT al estar en modo de MENU.
HDMI-FRONT (Lateral)
Usar esta entrada HDMI para equipos externos como S
et-Top-Boxes ó DVD equipados con conexión de
salida HDMI (ver página 82 para referencia).
Botón de entradas y salir INPUT/EXIT
Presionar este botón para accesar a las entradas. Presionar de nuevo para salir del modo de MENU.
()
(왖)
(왗)
()
Selector de Canales
Presionar estos botones hasta que el canal deseado aparezca en la esquina superior derecha de la imagen. Estos botones también sirven como los cursores abajo y arriba al estar en el MENU.
Nivel de VOLUMEN
Tarjeta de Actualización de Software (Upgrade Card)
Está opción es para mejoras futuras de software. Hitachi le notificará si una actualización de software es requerida a su Televisor. Para poder recibir una notificación por escrito, favor de llenar y enviar la tarjeta de garantía.
Presionar estos botones para ajustar el nivel de sonido.
El nivel de volumen será desplegado en la imagen. Estos botones también sirven como los cursores izquierda y derecha al estar en el MENU.
VISTA FRONTAL
CONTROLES
LATERALES
 
Botón lateral de encendido (POWER)
Presionar este botón para encender ó apagar el televisor de LCD. También puede ser encendido ó apagado con el control remoto . La energía del TV solo se puede quitar desconectando la clavija.
NOTA: Al ser desconectado el Televisor, el reloj se de-
tendrá y se puede restablecer eventualmente.
Luego de presionar este botón para encender el set, la
función de este botón no estará disponible por un corto tiempo hasta que la imagen aparezca en la pantalla del Televisor.
PHOTO INPUT
Entrada de Fotos (SD CARD PHOTO INPUT)
Es
tá entrada también sirve para ver fotografías tomadas con una camara digital, solo insertar la tarjeta tipo SD en la ranura para ver sus fotos.
79
Page 80
Uso por primera vez
Controles del Panel Frontal
Sensor de CONTROL REMOTO (R/C)
Ap
untar su control remoto en está area al elegir
canales, ajustando volumen, etc.
Terminales de Entrada Lateral (INPUT-FRONT)
Está entrada provee terminales de video compuesto para conectar equipo con está capacidad, tales como reproductores de DVD ó Videocamaras.
Luz Indicadora de Encendido (POWER LED)
Para encender el Televisor, presionar el botón localizado en el lado derecho del Televisor de LCD. Una luz indicadora roja se encenderá en la esquina inferior derecha del marco del Televisor. El Televisor de LCD esta listo para la operación del control remoto ON/OFF.
NOTAS: 1. El Televisor de LCD HITACHI podrá aparentar estar apagado (Indicador Naranja) si no hay señal de
entrada en INPUT : 1, 2, 3 ,FRONT y HDMI 1,2 y FRONT. Verificar la luz indicadora para asegurarse de que
el TV está apagado ó está en modo de espera (Stand-by) (Indicador Rojo) al no estar en uso el Televisor.
2. El Control Remoto no puede encender o apagar la Alimentación Principal (CA) del Televisor.
Luz Indicadora
Sensor R/C
Luz Indicadora Estado Operación
OFF
. El televisor está desconectado.
El televisor está conectado listo para ser
(Stand-by) encendido.
On
Botón de encendido ON ; pero sin señal
deentradaexceptoantena(sinseñalde sincronía).
Off
Enciende
Rojo
OFF.
Enciende
Azul
Botón de encendido ON;se veimagen.
Enciende
Naranja
Off
(Ahorrodeenergía)
On
Parpadea
Azul
Al recibir la señal del Control remoto cada
vez que se presione una tecla.
80
Page 81
Uso por primera vez
Conexiones del Panel Posterior
Entrada de Antena
Para cambiar entre la señal Cable y Aérea, ir a la opción de Organizar Canales (Channel Manager) para cambiar el tipo de señal CABLE ó Aérea.
Entradas de Audio/Video 1, 2 y 3
Al usar el botón INPUTS , los CURSORES ( y ), y el botón SELECT ó el CURSOR derecho del control remoto, se puede elegir cada entrada de video. Usar las entradas de audio y video para conec­tar equipos externos, tales VCRs, video cámaras, reproductores de DVD, etc. (Si tiene sonido monoaural, insertar el cable de audio en la terminal izquierda de audio).
Salida de MONITOR y Salida de Audio
Estas terminales proveen audio fijo, además señales de video (Cable/Aérea ó INPUTS) las cuales son usadas para grabación. Usar la salida S-Video para una mejor calidad de video. Señal de componente en las entradas 2 y 3, y las entradas HDMI no tendrán salida de monitor.
Salida óptica (Audio Digital)
Esta terminal provee Salida de Audio Digital para su equipo de audio que es compatible con Dolby® Digital y PCM, tal como un amplificador de audio.
NOTA: *Fabricado bajo licencia de Dolby
Laboratories. “Dolby” y el símbolo doble-D son marcas registradas de Dolby Laboratories.
Entrada S-VIDEO 1
La entrada 1 provee una terminal S-VIDEO (Super Video) para conectar equipo con capacidad de salida S-VIDEO.
NOTA: 1. Se pueden usar la entradas VIDEO ó S-VIDEO
para conectar en INPUT 1, pero solo una de estas entradas puede usarse a la vez.
2. La salida S-VIDEO puede usarse para grabación, solo cuando la entrada es del tipo S-VIDEO.
Entradas HDMI 1, 2 (High Definition Multimedia
Interface)
Acerca del HDMI – HDMI es la nueva-generación de interface digital para equipos electrónicos. El HDMI permite la segura distribución de video de alta definición sin comprimir y múltiples canales de audio en un solo cable. Porque las señales digitales de TV (DTV) permanecen en formato digital, el HDMI asegura que las imagenes de alta-definición mantengan la mas alta calidad de video desde un equipo a la pantalla de su Televisor.
Usar la entradaHDMIpara conectar equipos externos tales como Set-Top-Boxes ó reproductores de DVD equipados con conexión de salida HDMI .
HDMI, el logotipo HDMI y el nombre High-Definition Multimedia Interface son marcas registradas de
la compañía HDMI Licensing LLC.
NOTA: 1. La entrada HDMI no esta diseñada para
usarse con computadoras personales.
2. Solo formatos DTV tales como 1080p,1080i, 720p, 480i y 480p están disponibles para la entrada HDMI.
Entrada por Componente: Y-P
BPR Inputs
Las entradas 2 y 3 proveen terminales Y-PBPR para conectar equipos con esta capacidad, tales como reproductores de DVD ó Set Top Box. Se puede usar señal de video compuesto para ambas entradas.
NOTA:1. No conectar VIDEO compuesto y S-VIDEO
en la entrada INPUT 1 al mismo tiempo. S-VIDEO tiene prioridad sobre la entrada de VIDEO.
2. Las salidas por componente de su equipo pue­den llamarse Y, B-Y, y R-Y. En este caso, conectar la salida por componente B-Y a la entrada P
B
del TV y la salida por componente R-Y a la entrada
P
R del televisor.
3
. Las salidas por componente de su equipo pue-
den llamarse Y-CBCR. En este caso, conectar la salida por componente CB a la entrada PB del TV y la salida por componente CR a la entrada PR.
4. Puede ser necesario ajustar el TINTE para obtener una óptima calidad de imagen al usar la entradas Y-PBPR (ver pag. 108).
5. Para evitar faltas sobre el derecho de autor, la salida MONITOR OUT será anormal, al usar las terminales Y-PBPR y la entrada HDMI.
6. La entradas 2 y 3 (Y/VIDEO) pueden ser usadas para video compuesto y entrada de video por componente.
Para control Especial de AV solamente.
Para uso en la fábrica solamente.
Para Cable de Base Giratoria (Swivel)
Conecte el cable para la base giratoria de aquí al
conector localizado en la base giratoria (incluída).
81
Page 82
Uso por primera vez
Conectando Equipos de Video Externos
Las entradas en el panel LATERAL se proveen para su conveniencia permitiendole la fácil conexión de señales HDMI o DVI de un DVD, Set Top Box y Video Juego como se muestra en los siguientes ejemplos: (Al conectar
Parte posterior del
HD
TV Set-Top-Box ó
Reproductor de DVD
Equipo con Capacidad de Salida DIGITAL HDMI DVD , Set Top Box, Consola de Video Juegos.
CONTROLES DEL PANEL LATERAL
Equipo con Capacidad de Salida DIGITAL DVI DVD , Set Top Box, Consola de Video Juegos.
señales DVI será necesario conectar la salida de audio a las entradas de audio LATERALES del Televisor) :
A) Conectando señal HDMI.
B) Conectando señal DVI.
CONTROLES DEL PANEL LATERAL
pecificaciones del equipo.
Nota :Cables especiales de los equi-
pos serán de acuerdo a las es-
NOTA: I
nserte completamente los conectores cuando conecte las entradas del panel lateral. De no hacerlo, la
imagen
desplegada puede ser anormal.
pecificaciones del equipo.
N
ota : Cables especiales de los equi-
pos serán de acuerdo a las es-
AUDIO OUTPUT
R L
DVI á HDMI
Cable
DIGITALOUTPUT
PHOTO INPUT
PHOTO INPUT
82
Page 83
Uso por primera vez
Conectando Equipos de Video Externos
Las terminales Laterales se proveen para su conveniencia permitiendole la fácil conexión de una Cámara de Video, un DVD, Video Juego, VCR y una Cámara Digital como se muestra en los siguientes ejemplos:
NOTA: Inserte completamente los conectores cuando conecte las entradas del panel lateral. De no hacerlo, la
imagen desplegada puede ser anormal.
CONTROLES DEL PANEL LATERAL
Video Juego
Video Cámara
Eq
uipo con Capacidad de Salida Video Compuesto Reproductor de DVD Consola de Video Juegos.
especificaciones del equipo.
Nota : Los cables especiales de los
equipos deben ser de acuerdo a las
HDMI 2 HDMI-Frontal
Aérea/Cable
Entrada1
Mover
SEL
Elegir
Entrada 2
El acomodo exacto que usted use para conectar el VCR,
videocámara, reproductor de discos láser, DVD o Set Top Box HDTV para su televisión depende del modelo y funciones de cada componente. Revise el manual operativo de cada componente para la ubicación de entradas y salidas de audio y video.
Los siguientes diagramas de conexión se ofrecen como sugerencia. Sin embargo, usted tal vez tenga que modificarlos para ajustarse a su combinación particular de componentes y funciones. Para mejor desempeño, los cables de video y audio deben ser coaxiales y blindados.
Antes de Operar Equipos Externos de Video
Conecte un equipo externo a la terminal de ENTRADA, después presione el botón INPUTS para mostrar el Menú de ENTRADAS. Use los CURSORES ( y ) para seleccionar la Entrada de su preferencia. Entonces
presione el botón SELECT o el CURSOR para confirmar su elección (ver pag. 93).
OUTPUT
R L
Video
audio en la entrada L/Mono.
Nota : Para dispositivos monoaurales
favor de conectar el cable de
PHOTO INPUT
83
Page 84
Conexiones
Uso por primera vez
NOTA: Los Cables son opcionales, excepto cuando se especifica.
Equipo con Capacidad
de Salida Digital HDMI
HDMI OUTPUT
HDMI
a
HDMI
VCR #1
TV por Cable TV (Cable coaxial)
Divisor de señal 2-Vías
Antena Externa
ANT
IN
OUTPUT
S-VIDEO
V L R
Equipo con Capacidad
de Salida Digital DVI
DIGITAL OUTPUT
OUTPUT
Y PB P
R
L R
HDTV Set-Top Box
Reproductor de DVD
DVI
a
HDMI
AUDIO OUT
OUTPUT
Y P
R
/C
R
L R
VCR #2
V L R
INPUT
S-VIDEO
Opcional
Op
cional
ó
B
/C
B
P
del Panel Posterior
84
Page 85
Uso por primera vez
85
Consejos sobre las Conexiones del Panel Posterior
Las conexiones S-VIDEO, Y-PBPR, ó HDMI se proveen para equipos de alta fidelidad tales como DVD's, VCR's etc. que cuenten con esta opción. Use estas conexiones en lugar de una conexión de video estándar si su dispositivo cuenta con esta opción.
Si su dispositivo tiene solamente una salida de audio (monoaural), conéctelo al canal izquierdo(L/MONO) en el panel posterior de la televisión.
Consulte el manual de operación de sus otros equipos electrónicos para información adicional sobre como instalar sus cables de entrada/salida.
Una sola VCR puede ser usada para VCR #1 y VCR #2, pero recuerde que un VCR no puede grabar su propio video o línea de salida (INPUT: 1 en el ejemplo de la página 84). Consulte la guía de operación de su VCR para más información en las conexiones de entrada y salida.
Conecte solamente 1 equipo (VCR, Reproductor de DVD, videocámara, etc.) a cada terminal de entrada.
Las conexiones por COMPONENTE Y-P
BPR (ENTRADAS 2 y 3) se proveen para equipos de alta fidelidad
tales como DVD's y Set Top Box's. Use estas conexiones en lugar de una conexión de video estándar si su dispositivo tiene esta opción
Las salidas por componente de su equipo pueden llamarse Y, B-Y, and R-Y. En este caso, conectar la salida por componente B-Y a la entrada PB del TV y la salida por componente R-Y a la entrada PR del televisor.
Las salidas por componente de su equipo pueden llamarse Y, CBCR. En este caso, conectar la salida por componente CB a la entrada PB del TV y la salida por componente CR a la entrada PR del televisor.
Puede ser necesario ajustar el TINTE para obtener una óptima calidad de imagen al usar la entradas Y-PBPR (ver página 108).
Para asegurarse de no infringir las leyes sobre derechos de autor, la Salida de Monitor será anormal, cuando se usen las entradas Y-PBPR y las entradas HDMI.
Las entradas HDMI 1, HDMI 2 ó HDMI FRONTAL pueden recibir señales de HDMI.
La Salida de Monitor S-VIDEO puede ser usada para grabar unicamente cuando la entrada sea S-VIDEO.
Al usar la entrada HDMI desde un Set-Top-Box,se recomienda usar una señal de entrada 1080p,1080i o 720p.
RECOMENDACIONES PARA LA INSTALACIÓN:
1. Las Señales de Video que pasan a través de una VCR pudieran ser afectadas por el sistema de proteccion de derechos de autor y la imagen aparecerá distorsionada en la televisión.
2. Al conectar la televisión directamente a las salidas de Audio/Video de un Set-Top-Box se asegura una mejor calidad de imagen.
Al conectar una señal de 1080p por HDMI se recomienda que la longitud del cable de HDMI sea menor de 5 metros.
Page 86
Uso por primera vez
86
Conectando Equipos de Video Externos
Parte posterior
de
la VCR
CONECTANDO UNA FUENTE DE VIDEO Y AUDIO ESTEREO A LAS ENTRADAS 1 ~ FRONTAL
1. Conecte el cable de la salida de video (VIDEO OUT) del VCR o del Reproductor de Laserdisc a la entrada de video(VIDEO/Y) como se muestra en el Panel Posterior.
2. Conecte el cable de la salida de audio derecha (AUDIO OUT R) del VCR o Reproductor de Laserdisc a la entrada de audio derecha (AUDIO/R).
3. Conecte el cable de la salida de audio izquierda (AUDIO OUT L) del VCR o Reproductor de Laserdisc a la entrada de audio izquierda(AUDIO/L).
4. Presione el botón INPUTS, entonces seleccione la ENTRADA 1~ FRONTAL del Menú de Entradas para ver el programa de su VCR o Reproductor de Laserdisc.
5. Seleccione la señal CABLE o AEREA en el Menú
de Entradas para regresar al último canal sintonizado.
NOTA: 1
. Inserte completamente los conectores al hacer las conexiones del panel posterior. La imagen y el
sonido
que se está reproduciendo será anormal si la conexión está floja.
2. Una sola VCR puede ser usada para VCR #1 y VCR #2, (ver página 84) pero recuerde que una VCR no puede grabar su propio video o línea de salida. Consulte la guía de operación de su VCR para más información en las conexiones de entrada y salida.
3. Cuando se usen las ENTRADAS 2 ó 3, es necesario conectar la salida de video del dispositivo a la terminal de entrada Y/VIDEO del Televisor.
CONECTANDO SEÑAL S-VIDEO Y AUDIO ESTEREO
OUTPUT
VCR
Video
VCR ó Laserdisc
OUTPUT
S-VIDEO
Video
R L
DE UN EQUIPO A LA ENTRADA (INPUT 1)
Parte posterior de VCR ó
Laserdisc
C
able ó
Señal Aérea
Cable ó
Señal Aérea
1. Conecte el cable de la salida de video S-VIDEO del VCR S-VHS o Reproductor de Laserdisc a la entrada S-VIDEO de la TV, como se muestra en
el Panel Posterior .
2. Conecte el cable de la salida de audio derecha (AUDIO OUT R) del VCR o Reproductor de Laserdisc a la entrada de audio derecha (AUDIO/R)
3. Conecte el cable de la salida de audio izquierda (AUDIO OUT L) del VCR o Reproductor de Laserdisc a la entrada de audio izquierda (AUDIO/L)
4. Presione el botón INPUTS, entonces seleccione la ENTRADA 1 del Menú de Entradas para ver el programa de su VCR o Reproductor de Laserdisc.
5. Seleccione CABLE o AÉREA en el Menú de Entradas para regresar al último canal sintonizado.
NOTA :1
.Inserte completamente los conectores al hacer las conexiones del panel posterior. La imagen y el
sonido
que se esta reproduciendo será anormal si la conexion está floja.
2.Un solo VCR puede ser usado para VCR #1 y VCR #2, (
ver página 84) pero recuerde que un VCR no puede grabar su propio video o línea de salida. Consulte la guía de operación de su VCR para más información en las conexiones de entrada y salida.
Page 87
Uso por primera vez
87
CONECTANDO UN EQUIPO CON SALIDA HDMI
HDTV Set-Top-Box ó Reproductor de DVD
Cable HDMI
SALIDA DIGITAL
Parte posterior del
H
D
TV Set-Top-Box ó
Reproductor de DVD
O DVI A LAS ENTRADAS HDMI 1, 2 Ó FRONTAL
1.
Conecte el conector HDMI o el adaptador
DVI/HDMI de la salida del Set Top Box HDTV o Reproductor de DVD a la entrada HDMI tal como se muestra en la parte de abajo.
2. Al usar salida DVI, conecte el cable de la salida de audio derecha(AUDIO OUT R) del Set Top Box HDTV o DVD a la entrada derecha(AUDIO IN/R) tal como se muestra en la parte de abajo.
3. Al usar salida DVI, conecte el cable de la salida de audio izquierda(AUDIO OUT L) del Set Top Box HDTV o DVD a la entrada izquierda(AUDIO IN/L) tal como se muestra en la parte de abajo.
4. Presione el botón INPUTS, entonces seleccione HDMI 1, HDMI 2 o HDMI-FRONTAL para ver el programa del Set Top Box HDTV o el Reproductor de DVD.
5. Seleccione CABLE o AÉREA en el Menú de
Entradas para regresar al último canal sintonizado.
NOTA:1
. Inserte completamente los conectores al
hacer las conexiones del panel posterior. La imagen y el sonido que se esta reprodu­ciendo será anormal si la conexion está floja.
2. Las entradas HDMI en HDMI 1, HDMI 2 y HDMI­FRONTAL contienen el sistema de protección contra copiado llamado High-bandwidth Digital Content Protection(HDCP). El HDCP es un sistema que codifica las señales de video cuando se usan conexiones HDMI, para prevenir el copiado ilegal de la información de video.
3. HDMI no es una tecnologia de “RED”, e
s
tablece una conección punto-a-punto en un solo sentido para la entrega de video no comprimido en una pantalla.
4. El dispositivo digital conectado controla la interface HDMI, por lo tanto la configuración adecuada de las opciones de usuario del equipo determinan la resolución final del video.
5. Al usar un adaptador DVI a HDMI, conecte los cables de salida de audio Audio Out L y R a la misma HDMI (1 , 2 ó FRONTAL) que conectó el cable HDMI. (Para HDMI-FRONTAL favor de consultar la página 82).
Conectando Equipos de Video Externos
or
L R
OUTPUT
DIGITAL OUTPUT
DVI a HDMI
Cable
Parte posterior del
HDTV Set-Top-Box ó Reproductor
Entrada HDMI
Entrada DVI a HDMI
CABLE
ó
Señal Aérea
HDTV Set-Top-Box ó Reproductor de DVD
CABLE
ó
Señal Aérea
or
de DVD.
Page 88
Uso por primera vez
88
Conectando Equipos de Video Externos
CONECTANDO UN EQUIPO CON SALIDA DE COMPONENTE Y DE AUDIO EN LAS ENTRADAS 2 ó 3 : Y-PBPR.
1. Conecte el cable de la salida Y del reproductor Laserdisc/Reproductor de DVD ó HDTV set top box a la entrada (Y), como se muestra en el panel posterior de la figura.
2. Conecte el cable de la salida P
B/CB ó B-Y
d
el Laserdisc/Reproductor de DVD ó HDTV
set top box a la entrada PB del TV.
3.
Conecte el cable de la salida PR/CR ó R-Y
OUT del Laserdisc/Reproductor DVD ó HDTV set top box a la entrada PR del TV.
4. Conecte el cable de la salida de audio derecha (AUDIO OUT R) del Set Top Box HDTV o DVD a la entrada de audio derecha(AUDIO/R).
5. Conecte el cable de la salida de audio izquierda (AUDIO OUT L) del Set Top Box HDTV o DVD a la entrada de audio izquierda(AUDIO/L).
6. Presione el botón INPUTS, entonces seleccione la ENTRADA 2 ó 3 del Menú de Entradas para para ver el programa del Set Top Box HDTV o el Reproductor de DVD/Laserdisc.
7. Seleccione CABLE ó AÉREA en el Menú de Entradaspara regresar al último canal sintonizado.
NOTA: 1
. Inserte completamente los conectores al
h
acer las conexiones del panel posterior.
La imagen y el sonido que se está reproduciendo
será anormal si la conexión está floja.
2. Ver pág. 85 para sugerencias sobre las
CONEXIONES DEL PANEL POSTERIOR.
OUTPUT
Reproductor de DVD
Ó
Parte posterior del Reproductor de DVD
OUTPUT
L R Y P
B P
R
Set-Top Box de Alta Definición
PR/CR
PB/CB Y
VIDEO
R
AUDIO
CABLE
ó
Señal Aérea
L
Page 89
Uso por primera vez
89
Conectando Equipos de Video Externos
CONECTANDO UN EQUIPO DE VIDEO Y AUDIO
MONAURAL A LAS ENTRADAS 1, 2, 3 ó FRONTAL
1. Conectar el cable de la salida de video(VIDEO OUT) del VCR o del Reproductor de DVD a la entrada de video(VIDEO/Y) como se muestra en el Panel Posterior de la derecha.
2. Conectar el cable de la salida de audio(AUDIO OUT) de su VCR o Reproductor de DVD a la entrada (MONO)/AUDIO IN L) de su TV .
3. Presione el botón INPUTS, entonces seleccione la ENTRADA 1,2,3 ó Frontal del Menú de Entradas para ver el programa de su VCR o Reproductor DVD.
4. Seleccione CABLE o AÉREA en el Menú de Entradas para regresar al último canal sintonizado.
CONECTANDO UN AMPLIFICADOR DE AUDIO EXTERNO
Para controlar el nivel de audio del TV de LCD con un amplificador externo de audio, conectar el sistema como se muestra en la derecha. La salida “OPTICAL OUT” del panel posterior es una salida fija. El Volumen del amplificador es controlado por el amplificador, no por el televisor de LCD. La terminal OPTICAL OUT se puede conectar a todo equipo con Entrada Óptica.
1. Conectar un cable óptico desde la salida Optical out a
la entrada Óptica de un sistema de sonido ó Amplificador como se muestra en el Panel poste­rior como la figura de la derecha.
(Para la ENTRADA FRONTAL consultar la página 83).
Sistema de Amplificador
NOTA: Al hacer conexiones de video, conectar solo S-Video ó solo Video. Si ambas son conectadas, el S-Video
tiene prioridad.
VCR ú otros equipos
externos
INPUT
S-VIDEO
R L V
Opcional
CABLE
ó
Señal Aérea
CABLE
ó
Señal Aérea
Parte posterior del
VCR
CONEXIÓN DE
LA SALIDA DE MONITOR
La Salida de Monitor (Monitor Out) proporciona audio y video de las señales CABLE/AÉREA y las Entradas 1, 2, 3, y Frontal. No proporciona Video por Componente ó HDMI.
1. Conexión de S-Video:
Conect
ar el cable de la salida S-VIDEO del
Panel Posterior a la entrada S-VIDEO del VCR.
Conexión de Video: Conectar el cable de la salida VIDEO del Panel Posterior a la entrada VIDEO del VCR.
2. Conectar el cable de la entrada AUDIO IN R del
VCR a la salida AUDIO/R del Panel Posterior del Televisor.
3. Conectar el cable de la entrada AUDIO IN L del
VCR a la salida
AUDIO/L del Panel Posterior del
Televisor.
OUTPUT
VCR
VIDEOOUT AUDIO OUT
CABLE ó Señal Aérea
OPTICAL
IN
Sistema de Amplificador
ó reproductor de DVD
Page 90
El Control Remoto
Además de controlar todas las funciones de su TV Plasma HITACHI, el nuevo control remoto está diseñado para operar diferentes tipos de VCRs, receptores de cable, receptores satelitales, reproductores DVD, y otros equipos de audio/video con solo apretar un botón. Todas las teclas de operación básicas están agrupadas en una sola área.
Para operar su TV Plasma, seleccione T
V
presionando el botón del Source Select en el remoto. El indicador del modo TV parpadeará, indicando que el control remoto está listo para operar su televisor.
Para operar su receptor de cable, seleccione SAT/CBL presionando el botón del Source Select en el remoto. El indicador del modo SAT/CBL parpadeará, indicando que el control remoto está listo para operar su receptor de cable. (Vea las instrucciones en la pág. 99 para programar el control remoto y operar su receptor de
Para operar su STB (Set-top-box) o receptor satelital, seleccione SAT/CBL presionando el botón del Source Select en el remoto. El indicador del modo SAT/CBL parpadeará, indicando que el control remoto está listo para operar su STB. Si usted tiene un receptor satelital, use también este botón para programar su receptor satelital.(Vea las instrucciones en la pág. 100 para programar el control remoto y operar su STB o
Para operar su reproductor DVD, seleccione DVD presionando el botón del Source Select en el remoto. El indicador del modo DVD parpadeará, indicando que el control remoto está listo para operar su reproductor DVD. ( Vea las instrucciones en la pág. 101 para programar el control remoto y operar su reproductor
Para operar su VCR/PVR (Grabadora de Video Personal), seleccione PVR/VCR presionando el botón del Source Select en el remoto. El indicador del modo PVR/VCR parpadeará, indicando que el control remoto está listo para operar su VCR/PVR. (Vea las instrucciones en la pág. 102 para programar el control remoto y operar su VCR/PVR).
cable).
r
eceptor satelital).
DVD).
El Control Remoto
90
Page 91
Como Utilizar el Control Remoto de su TV
Botón de encendido/apagado (POWER)
Presione este botón para encender o apagar el televisor cuando el remoto este en modo TV. (Ver página 90 para las instrucciones de como programar el control remoto en modo TV).
 
19
Indicadores de MODO
Enciende o parpadea tres veces para mostrar el modo del control remoto.
Botón SOURCE SELECT
P
resione este botón para seleccionar el modo del control
remoto.
Botón de PAUSA
Presione el botón de PAUSA para congelar la imagen. Presione el botón EXIT para descongelar la imagen.
Presione el botón de PAUSA repetidamente para pasar através de los tres modos diferentes de congelamiento (FREEZE) (ver pág. 98).
 
El Control Remoto
1
8
Freeze
Fr
eeze
Freeze
Fr
Freeze
eeze
Botón DIA/NOCHE (DAY/NIGHT)
Presione este botón para cambiar entre las configuraciones de modo de imagen Día(Normal), Día(Dinámico) y Noche. Seleccione los modos de Día para ver durante el día con mayor brillo y contraste para competir con la luz interior del cuarto. Seleccione Noche para ver durante la noche con menor brillo y contraste para una imagen más detallada (ver pág. 108 para cambiar la configuración).
N
OTA: Para la configuración automática del modo
imagen DIA/NOCHE, ver pág. 122.
de
91
Page 92
Como Utilizar el Control Remoto de su TV
16:9 ZOOM
16:9 ESTÁNDAR1
4:3 ZOOM2
3. Cuando se despliegue el modo 16:9 ESTÁNDAR 2, pueden aparecer líneas en las orillas de la imagen,
considere que esto es una operación normal del televisor.
IMAGEN DE ENTRADA
IMAGEN DE ENTRADA
IMAGEN DE ENTRADA
IMAGEN DE ENTRADA
las imágenes através de las siguientes opciones:
4
:3 ESTÁNDAR
4:
:3 ZOOM1
16:9 ESTÁNDAR1 16:9 ZOOM
4:3 ESTÁNDAR
4:3 EXPANDIDO
4:3 ZOOM2 4:3 ZOOM1
16:9 ESTÁNDAR1 16:9 ESTÁNDAR2
4:3 EXPANDIDO 16:9 ZOOM
Nota : Favor de ver el apéndice A
en la página 146-147.
Nota : Favor de ver el apéndice A
en la página 146-147.
Nota : Favor de ver el apéndice A
en la página 146-147.
Nota : Favor de ver el apéndice A
en la página 146-147.
Botón de ASPECTO (ASPECT)
P
resione este botón para cambiar rápidamente la relación de aspecto del formato de la imagen. Dependiendo
del formato de la señal de entrada recibida, la relación de aspecto del formato de imagen le permite a usted ajustar
4:3 ESTÁNDAR
Use este modo de aspecto para desplegar imágenes (4:3) convencionales. Se colocan paneles laterales (áreas grises) en la izquierda yderecha de la imagen para conservar la relación de aspecto original de la fuente.
4:3 EXPANDIDO
Use este modo de aspecto para desplegar imágenes (4:3) convencionales incrementando linealmente la expansión de la imagen del centro hacia las orillas del área de despliegue con el próposito de llenarla.
• Canal de Antena-Analógica
• Entrada S-Video/Video (Formato Automático: Off)
• Entrada HDMI- 480i/480p
(Formato Automático: Off)
• Entrada Componente- 480i/480p
El Control Remoto
(Formato Automático: Off)
4:3 ZOOM1/ZOOM2
Use estos modos de aspecto para aumentar las imágenes de fuentes (4:3) convencionales.
16:9 ESTÁNDAR 1
Use este modo de aspecto para desplegar fuentes 16:9 como HDTV y DVD’s conservando la relación de aspecto original 16:9 mostrando el 95% del tamaño.
16:9 ESTÁ
NDAR 2
Use este modo de aspecto para desplegar fuentes
16:9 como HDTV y DVD’s conservando la relación de aspecto original 16:9 mostrando el 100% del tamaño.
16:9 ZOOM
Use este modo para aumentar la imagen en el aspecto 16:9.
• Canal de Antena-Digital (4:3)
• S-Video/Video 4:3/Entrada Letter(Formato Automático: On)
• HDMI-480i/480p 4:3/Entrada Letter (Formato Automático: On)
• Componente-480i/480p 4:3/ Entrada Letter (Formato Automático: On)
• Entrada S-Video/Video 16:9 (Formato Automático: On)
• Entrada 16:9 HDMI- 480i/480p (Formato Automático: On)
• Entrada 16:9 Componente­480i/480p (Formato Automático: On)
• Canal de Antena-Digital (16:9)
• Entrada HDMI- 720p/1080i/1080p
• Entrada Componente-720p/ 1080i
N
OTA: 1. El modo de Aspecto en todas
2. Los ajustes de Posición Vertical están disponibles directamente cuando usted elige los modos de aspecto
4:3 EXPANDIDO/ZOOM1/ZOOM2 ó 16:9 ZOOM (ver también pág.110).
9
2
las entradas de video tienen configuración independiente.
Page 93
93
El Control Remoto
Botón MENU
El botón MENU desplegará el Menú en Pantalla.
Botón EXIT
Este botón lo sacará de todos los menús en pantalla.
Botón de entradas (INPUTS)
Cuando el control remoto está en el modo TV, presione este botón para accesar al menú de ENTRADAS. Use los CURSORES y el botón SELECT para elegir las entradas que están siendo usadas. El presionar repetidamente el botón de ENTRADAS lo llevará através de todas las opciones del menú de entradas. Luego presione el botón SELECT para seleccionar.
HDMI-Frontal
Fotos
Entrada 2
Aérea / Cable
Mover SEL Elegir
Entrada 1
AEREA/CABLE Se
leccione entre la señal Aérea o de Cable.
Botones CURSOR/SELECT
Todas las funciones del Menú en pantalla pueden ser configurados o ajustados utilizando los CURSORES, excepto los valores númericos. Los CURSORES resaltarán, ajustarán y configurarán diversas funciones. Presione el CURSOR de la dirección deseada y
Botón PICTURE-IN-PICTURE (PIP)
Vea la sección separada en las páginas 97-98 para una descripción más detallada.
Presione este botón para desplegar los subtítulos en la pantalla cuando estén disponibles por el
Botón de GUIA (GUIDE)
Presione este botón para accesar la Guía de Canales del cable ( CBL) y receptor satelital o alta definición (SAT/STB) en el modo ( CBL)(SAT/STB).
programa de TV. En Canales Analógicos, presione
el botón CC una y otra vez, para ir através de los modos de Subtítulos y para desactivar los Subtítulos.
FOTOS Seleccione para accesar sus fotos de una
unidad SD/MMC o tarjeta de memoria SD/MMC que este conectada en la entrada
de Fotos lateral de la TV LCD (ver págs.
Botón INFO
Presione este botón cuando usted desee consultar el canal recibido, el origen o fuente de la imagen,
si el canal tiene estereo (ST) o programa secundario de audio (SAP), la hora, el nombre del canal o si el tiempo de auto apagado está activado.
presione el botón SELECT para seleccionar o elegir.
Botón de Subtítulos (Closed Captions-CC)
ENTRADA2
Seleccione para ir a la Entrada 2.
ENTRADA3
Seleccione para ir a la Entrada 3.
ENTRADA-FRONTAL
Seleccione para ir a la Entrada Lateral.
HDMI1
Seleccione para ir a la entrada HDMI 1.
HDMI-FRONTAL
Seleccione para ir a la entrada HDMI Lateral.
ENTRADA1
Seleccione para ir a la Entrada 1.
HDMI2
Seleccione para ir a la entrada HDMI 2.
94-95).
S-IN: 1
480i 3:17PM
Auto
CANALES DIGITALES
Subtítulos Digitales
Este ícono aparecerá solamente cuando
se reciba una transmisión Digital que incluya Subtítulos.
Show Name Air 8
3:00PM-
3:30PM KXYZ-HD
ST TV-G 480i 3:17PM
Auto STEREO
Duración del programa
Información del programa
Clasificación del programa
Formato de la Imagen
Tipo de
Audio
Fuente Imagen Principal y # de canal
Identificación de canal transmitido
Reloj
Configuración de Subtítulos
Selección de
Fuente de Audio
CANALES ANALÓGICOS
Show Name Air 15-1
3:00PM- 3:30PM KPBS-HD
ST 1080i 3:17PM
Auto
Duración del programa
Información del programa
Clasificación del programa
Formato de la Imagen
Tipo de
Audio
Fuente Imagen Principal y # de canal
Identificación de canal transmitido Reloj
Configuración
de Subtítulos
DTvCC TV-G
ALT U.S.
Clasificación
Región 5
Descripción del programa
(Presione INFO otra vez para una información
Cuando se conecta Video Componente:
Señal Y-PbPr
conectada a la ENTRADA 3
Formato de la
Señal de entrada
Cuando se conecta una señal S-VIDEO
a la ENTRADA 1
más detallada)
N
OTA: 1. Presionar el botón INFO otra vez ó el botón
EXIT pare regresar al la imagen normal.
2. La configuración del Aspecto no será mostrada si el canal está bloqueado.
Y-PBPR: 3
480i 3:17PM
Auto
D
A
Canal Analógico
Canal Digital
Como Utilizar el Control Remoto de su TV
Page 94
Como Utilizar el Control Remoto de su TV
HDMI 1 HDMI- Frontal Fotos
Entrada 1 Mover SEL Elegir
Aérea/Cable
Siguiente
SEL Muestra [0-9] Saltar
Elegir Número
de Fotografía
--
No. 02/08 06/13/05 2048x1536 DSC00467
Rotar Presentación
Número de Foto
Fecha
Resolución
Nombre del Archivo
NOTAS: 1. El número máximo de fotos digitales que pueden ser desplegadas es de 999.
2. Presione el botón INFO para mostrar los números de fotos en tamaño muestra, además de otra
información de las fotos individuales.
3. La pantalla puede mostrar el mensaje “Dispositivo de entrada no detectado” si la tarjeta de memoria MMC/SD no ha sido introducida
FOTOS
Esta función es útil para ver imágenes digitales fijas de su unidad SD o tarjeta de memoria SD usando la entrada de Fotos en el panel lateral de su televisor.
1. Presione el botón de E
NTRADAS (INPUTS)
para navegar através de las diferentes ENTRADAS hasta seleccionar FOTOS. Luego, presione el botón SELECT o el CURSOR .
2. Presione los CURSORES o para accesar
a la foto siguiente o a la foto anterior.
El Control Remoto
3. Presione el botón SELECT para ver las muestras.
4. Use los CURSORES 왖,왔,왗 o y seleccione el botón SELECT para navegar y seleccionar individualmente las fotos de su elección.
5. Presione el número de fotografía para saltar de imagen a imagen.
6. Presione el botón INFO para accesar al menú de FOTOS y ver la información de la fotografía.
7. Presione los CURSORES o y el botón SELECT para navegar y seleccionar el menú de FOTOS.
9
4
Page 95
Como Utilizar el Control Remoto de su TV
ROTAR
S
eleccione esta opción del menú para rotar las fotos en
dirección de las manecillas del reloj (CURSOR ) y en dirección inversa a las manecillas del reloj (CURSOR 왗).
PRESENTACIÓN
Seleccione esta opción del menú para iniciar una presentación de las fotos digitales. Mientras el submenú del Intervalo está resaltado, presione el botón SELECT para cambiar el tiempo de intervalo desde 5, 10 y 30
segs. Presione el botón SELECT para parar en una foto elegida de la presentación. Despúes de 30 segundos, la presentación continuará o presione el botón
SELECT otra vez para continuar con la presentación.
Rotar Presentación Iniciar
Rotar
Intervalo 5
El Control Remoto
seg
NOTAS: 1. Durante la P
presione luego cualquier botón
2. Los nombres modificados de los archivos de fotos deben ser de 8 caracteres (Ej. ABCD1234.jpg). 1er. caracter: letras; 2do al 4to: letras o números; 5to al 8vo.: números. Los archivos de fotos deben er colocados primeramente en el nombre de un subdirectorio con 8 caracteres (Ej. 123ABCDE). 1er al 3ro: números; 4to al 8vo.: letras. El subdirectorio luego debe ser colocado en un directorio principal con un nombre de archivo de formato “dcim” .
3. Los tipos de imágenes soportadas son de hasta 3072 x 2304; el formato JPEG deberá estar conforme con el Estándar DCF (Regla de Diseño para el Sistema de Archivos de Cámara).
4. Este televisor despliega solamente imágenes digitales de cámaras digitales que cumplen el estándar DCF.
Las Imágenes que son copiadas, editadas o modificadas en una computadora pueden ser no desplegadas en el televisor.
RESENTACIÓN también funciona la Reducción Automática de contraste, para continuar
95
Page 96
Cable 6
FAV Cable 6
Cable 6
Volume 8
Soft Mute 8
Mute 8
1
8
19
1
7
Botón de VOLUMEN (VOL), Botón MUTE
Use el botón VOL UP () or VOL DOWN () hasta obtener el nivel de sonido deseado.
Para reducir el sonido a la mitad del volumen normal (SOFT MUTE) para contestar el teléfono, etc., presione el botón MUTE. Presione el botón MUTE un vez más para apagar el sonido completamente (MUTE). Para encender el sonido, presione el botón MUTE una vez más o el botón VOL UP (왖).
Los Subtítulos serán desplegados automáticamente cuando las funciones MUTE/SOFT MUTE estén activas y los Subtítulos estén en modo AUTO (ver pág. 127).
Cuando el televisor sea apagado a un nivel de volumen de 31 o más, el nivel de volumen por default será de 30 cuando el televisor sea encendido. Sin embargo, si el nivel está en 30 o menos, este nivel de volumen se mantendrá cuando el televisor sea encendido.
Botones del SELECTOR DE CANAL/ CANALES
Los botones del SELECTOR DE CANALES son usados para seleccionar canales, ingresar código de
CANALES para ingresar uno, dos, o tres números para
acceso, etc. Use los botones del SELECTOR DE
seleccionar los canales. Ingrese primero el número “0” para canales del 1 al 9, o simplemente presione el único dígito del canal que se desea sintonizar y presione el botón ENTER para que la TV lo sintonice. Para Canales Digitales, use los botones del SELECTOR DE CANALES con el botón del GUIÓN (-). La selección de canales también puede ser realizada con el botón CH UP (
) o CH DOWN
( ).
Botón de GUIÓN (-)
Use el botón de GUIÓN (-) junto con los de
SELECCIÓN DE CANALES para sintonizar Canales
Digitales que tienen números de subcanal indicados con un (-) GUIÓN (ejemplo: 15-1).
Botón de GRABACIÓN (RECORD)
Presione este botón para grabar programas cuando el control remoto está en modo PVR/VCR.
FAVORITOS (FAV CH) y ENTER.
Presione el botón CANALES FAVORITOS (FAV CH) para cambiar al modo de canal favorito (FAV). Usted sabrá cuando está en el modo de Canal Favorito cuando (FAV) es desplegado y el # de canal desplegado está VERDE. Presione otra vez para regresar y sintonizar a sus canales regulares. Usted puede agregar cualquier canal a su Lista de Canales Favoritos presionando y manteniendo presionado el botón FAV CH hasta que el # de canal desplegado cambie de BLANCO a VERDE RESALTADO. Tambié n puede borrar un canal de su lista de canales favoritos presionando y manteniendo presionado el botón FAV CH hasta que el # de canal desplegado cambie de VERDE RESALTADO a BLANCO.
Presione este botón para cambiar entre el canal actual y el último canal visto.
Botón de ÚLTIMO CANAL (LAST CH)
Como Utilizar el Control Remoto de su TV
El Control Remoto
96
Page 97
Picture-In-Pictur
SWAP
Imagen Principal
Sub-Imagen
CABLE ó
AÉREA
Parte trasera
de un VCR
OUTPUT
VCR
VIDEO OUT AUDIO OUT
Tabla de especificaciones del PIP
Canal Digital (Aéreo ó Cable)
1080i 720p 480p 480p 480i 480i 1080i 720p 480p 480p 480i 480i
16x9 16x9 16x9 4x3 16x9 4x3 16x9
1080p(*)
16x9 16x9 16x9 4x3 16x9 4x3
Componente Compuesto S-IN HDMI
Canal Digital
(Aéreo ó Cable)
Sub Imagen
Imagen Principal
Componente/Compuesto/S-lN/HDMI
DIVIDIDO
(
SPLIT)
PIP
Modo
1080i 16x9
- - - - - -
720p 16x9
- - - - - -
480p 16x9
- - - - - -
480p 4x3
- - - - - -
480i 16x9
- - - - - -
480i 4x3
- - - - - -
1080i 16x9
720p 16x9 480p 16x9 480p 4x3
1080p (*) 16x9
480i 16x9 48
0i 4x3
Sí Sí
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
-
-
-
-
-
-
-
(*) Solo entrada HDMI
Su televisor Plasma HI
TACHI tiene incorporada una
tecnología de sintonizador diseñada para obtener una imagen mejorada que usted disfrutará. Esta función le permite poder ver simultáneamente Canales Digitales y Entradas de Video tanto en la imagen principal como sub-imagen con un control separado. Los Canales
Analógicos no pueden ser vistos en el modo PIP. Para la disponibilidad en el modo PIP, favor de ver la tabla
Para seleccionar entre la imagen principal y la sub-imagen PIP use los CURSORES del control remoto. El canal con despliegue de color verde se moverá con cada presión
de los CURSORES.
La función PIP (Picture-in-Picture) es conveniente cuando usted desea ver más de un programa al mismo tiempo. Usted puede ver un programa de TV mientras ve otros programas de cualquiera de las entradas de video.
Use la conexión que se muestra a la derecha para
ver un programa de VCR como sub-imagen mientras ve otro en la imagen principal (Canal Digital de
Botón PIP
Presione el botón PIP y aparecerá una sub-imagen en el modo SPLIT. Presione el botón EXIT
para regresar a la vista normal.
en la parte de abajo.
señal
CABLE/AEREA ).
e (PIP)
El Control Remoto
NOTA: 1. En el modo PIP SPLIT, presione los CURSOR
ES ( Wo X ) para habilitar el sonido de la subimagen.
97
Page 98
Picture-In-Pictur
Imagen Principal
Sub-imagen
NOTA: 1. El modo FREEZE predeterminado es imagen
PRINCIPAL congelada, seguido de imagen
congelada DIVIDIDA y después por PASOS. El último modo de FREEZE que se seleccionó antes de presionar el botón EXIT será el que aparezca al presionar el botón PAUSE de nuevo.
2. Cada cuadro de imagen congelado en el modo por pasos está retardado 0.1 (1/10) segundos.
(MAIN FREEZE)
(SPLIT FREEZE)
IMAGEN CONGELADA POR PASOS
Presione el botón PAUSE para congelar tres cuadros de la imagen que usted está viendo (solamente 3 sub-imágenes se congelarán). Presione el botón EXIT para regresar a la vista normal. Esta función es útil para ver imágenes en movimiento que tienen muchos detalles, por ejemplo, una jugada de cerca en un evento deportivo o en un tiro de golf.
(STROBE FREEZE)
que contienen datos de direcciones o teléfonos.
Freeze
Freeze
Freeze
Freeze
Freeze
Hot Springs Clay Mask
C/O John Doe
Run-Spa Retreat
P.O. Box 55512
Any Town, USA 98765
Check or
Money Order Only
1-800-555-1212
El Control Remoto
e (PIP)
Botón
Presione el botón PAUSE repetidamente para cambiar entre modos de congelamiento (FREEZE) (Freeze principal, modo dividido y modo por pasos). Esta función es conveniente cuando se desea escribir la dirección de una compañía de orden por correo, tomar estadísticas de algún evento deportivo, etc. Para volver a la imagen en movimiento, presione el botón EXIT.
de PAUSA (PAUSE)
IMAGEN CONGELADA DIVIDIDA
P
resione el botón PAUSE para congelar la imagen
que usted está viendo (solamente la sub-imagen derecha se congelará). Presione el botón EXIT para regresar a la vista normal.
l
IMAGEN PRINCIPAL CONGELADA
P
resione el botón PAUSE para congelar un cuadro
de la imagen que usted está viendo, el cuadro congelado será mostrado en la imagen principal. Presione el botón EXIT para regresar a la vista normal. Esta función es útil para congelar cuadros de imagen
98
Page 99
El Control Remoto para controlar un receptor de Cable
OPERACION DE LAS FUNCIONES PREGRABADAS PARA SU RECEPTOR DE CABLE.
Este control remoto está diseñado para operar diferentes tipos d
e receptores de cable. Usted debe primero programar el
control remoto para ser compatible con el sistema remoto de su receptor de cable (consulte las páginas 104-105 para ver la lista de códigos).
1. Encienda su receptor de cable.
2. Para cambiar al modo de Cable (CBL), utilice el botón SOURCE SELECT en el control remoto para posicionar la la luz del LED en la selección correspondiente SAT/CBL.
3. Mantenga presionado el botón SOURCE SELECT en el remoto e ingrese el código de cuatro dígitos preestablecido que coincide con su receptor, como se muestra en las páginas 104-105. Suelte el botón SOURCE SELECT. La luz indicadora parpadeará tres veces si el código fue aceptado.
4. Apunte el control remoto hacia el receptor de cable y presione el botón POWER. El control apagará su receptor de cable cuando ingrese el código preestablecido de cuatro dígitos correcto. Cuando esto ocurre, el control remoto ya está programado para su receptor. Si su receptor no se apaga, intente un código de cuatro dígitos preestablecido diferente.
5. El control remoto ahora controlará su receptor de cable.
OTA: 1. Si su receptor no puede ser operado después
N
d
e realizar los procedimientos anteriores, el código de su receptor no ha sido pregrabado en el control remoto.
2. En el caso improbable de que su receptor no pueda ser operado después de realizar los procedimientos anteriores, por favor consulte su guía de operación del receptor.
3. El control remoto recordará los códigos que usted haya programado hasta que se remuevan las baterías del control remoto. Después de reemplazar las baterías, repita el procedimiento
completo de programación como se describe
arriba.
OTA: Consulte la guía de operación del receptor de cable
N
 
Botones
Estos botones transmiten los códigos pregrabados al receptor de cable programado :
-Power
-Men
-Exit
-Guide
Botones EXCLUSIVOS DE TV
Estos botones son para operar solamente el TV :
-Day/Night
-Aspect
-PIP
-Pausa
EL CÓDIGO DE MI RECEPTOR DE CABLE
ES:
p
ara la operación de los botones exclusivos para el
receptor de cable.
PREGRABADOS DEL RECEPTOR
-Cursor/Select
u
-Info
-Selector de Canales
-Last CH
-CC
-Volumen
-Mute
-Inputs (Solo si
es programado, ver pág. 103)
-Números
-Enter
El Control Remoto
9
9
Page 100
El Control Remoto para controlar un STB*/Receptor Satelital
OPERACION DE LAS FUNCIONES PREGRABADAS PARA
SU STB/RECEPTOR SATELITAL.
Este control remoto está diseñado para operar diferentes tipos de STB/receptores satelitales. Usted debe primero programar el control remoto para ser compatible con el sistema remoto de su receptor de satélite (consulte las páginas 104-105 para ver la lista de códigos).
1. Encienda su STB/Receptor Satelital.
2. Para cambiar al modo de STB/Receptor Satelital (SAT), utilice el botón SOURCE SELECT en el control remoto para posicionar la luz del LED en la selección correspondiente SAT/CBL .
3. Mantenga presionado el botón SOURCE SELECT en el remoto e ingrese el código de cuatro dígitos preestablecido que coincide con su STB/receptor Satelital, como se muestra en las páginas 104-105. Suelte el botón SOURCE SELECT. La luz indicadora parpadeará tres veces si el código fue aceptado.
4. Apunte el control remoto hacia el STB/receptor Satelital y presione el botón POWER. El control apagará su STB/
El Control Remoto
receptor Satelital cuando ingrese el código preestablecido de cuatro dígitos correcto. Cuando esto ocurre, el control remoto ya está programado para su STB/receptor Satelital. Si su STB/ receptor Satelital no se apaga, intente un código de cuatro dígitos preestablecido diferente.
5. El control remoto ahora controlará su receptor de cable.
NOTA: 1. Si su STB/Receptor Satelital no puede ser
o
perado después de realizar los procedimientos anteriores, el código de su STB/Receptor Satelital no ha sido pregrabado en el control remoto.
2. En el caso improbable de que su convertidor no pueda ser operado después de realizar los procedimientos anteriores, por favor consulte su guía de operación del convertidor.
3. El control remoto recordará los códigos que usted haya programado hasta que se remuevan las baterías del control remoto. Después de reemplazar las baterías, repita el procedimiento
completo de programación como se describe
arriba.
Botones PREGRABADOS DEL STB/
RECEPTOR SATELITAL).
Estos botones transmiten los códigos pregrabados al STB/Receptor Satelital programado:
-Power
-Men
-Exit
-Guide
Botones EXCLUSIVOS DE TV
Estos botones son para operar solamente el TV :
-Day/Night
-Aspect
-PIP
EL CÓDIGO DE MI STB/RECEPTOR SATELITAL ES:
-Cursor/Select
u
-Info
-Selector de Canales
-Last CH
-CC
-Volumen
-Mute
-Números, Guión
-Enter
-Inputs (Solo si es pro- gramado, ver pág.103).
-Pausa
100
OTA: Consulte la guía de operación del STB/Receptor
N
S
atelital para la operación de los botones
exclusivos para el STB/Receptor Satelital.
Loading...
