Hitachi HOME-1 User Manual

Projector

HOME-1

User's Manual - Operating Guide

Thank you for purchasing this projector.

WARNING Before using, read the "User's Manual - Safety Guide" and
these manuals to ensure correct usage through understanding. After reading,

store them in a safe place for future reference.

NOTE

• The manufacturer assumes no responsibility for any errors that may appear in this manual.

• The reproduction, transmission or use of this document or contents is not permitted without
express written authority.

TRADEMARK ACKNOWLEDGMENT :

• VGA and XGA are registered trademarks of the International Business Machines Corporation.

• Apple and Mac are registered trademarks of Apple Computer, Inc.

• VESA and SVGA are trademarks of the Video Electronics Standard Association.

• Windows is a registered trademark of Microsoft Corporation.
All other trademarks are the property of their respective owners.

• The information in this manual is subject to change without notice.

1

Projector Features

This multimedia projector is used to project various computer signals as well as
NTSC / PAL / SECAM video signals onto a screen. Little space is required for
installation and large images can easily be realized.

Ultra High Brightness

●

Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly
efficient optical system.

Whisper Mode Equipped

●

Special mode is available for reducing projector noise to achieve quieter operation.

User Memory Function

●

This projector can memorize 4 settings by MY MEMORY function.

Optical Lens Shift

●

The lens of this projector can be shifted horizontally and vertically. When you want to finely adjust the
picture position, use the picture shift dials.

Keystone Distortion Correction

●

Quick correction of distorted images electrically.

Preparation

Please see the “Contents Of Package” of the “User’s Manual – Quick Guide”.
Your projector should come with the items shown there. Contact your dealer
anything is missing.

NOTE

sure to use the original packing material. Use special caution for the lens part.

2

• Keep the original packing material for future reshipment. For moving the projector, be

Contents

Projector Features
Preparation
Part Names

The Projector ………………………4
Fastening The Lens Cap …………4
The Remote Control ………………6

Setting Up

Arrangement ………………………7
Adjusting The Projector’s
Elevator ……………………………8

Using The Picture Shift Dials ……8

Connecting Your Devices…………9
Connecting Power Supply ………11

Remote Control

Putting Batteries …………………12
Operating The Remote Control…13

Power ON/OFF

Turning On The Power …………14
Selecting An Input Signal ………15
Turning Off The Power …………16

Operating

Adjusting The Volume …………17
Temporarily Muting The Sound…17
Using The Automatic
Adjustment Feature………………18
Correcting Keystone
Distortions…………………………18
Signal Searching …………………19
Selecting The Aspect Ratio ……19
Temporarily Blanking
The Screen ………………………19
Selecting The Gamma Mode……20
Recalling Your Adjustments ……20

…………………………………………………………

……………………………………………………

……………………………………
……………………………………………………
……………………………………………………

…………………………………………

…………………………………………

12

14

17

2

Multifunctional Settings
2
4

7

Using The Menu Functions ……21
MAIN Menu ………………………22
PICTURE-1 Menu ………………23
PICTURE-2 Menu ………………25
INPUT Menu ……………………26
AUTO Menu ………………………28
SCREEN Menu …………………29
OPTION Menu ……………………30

Lamp

Air Filter

Other Care

Troubleshooting

Specifications

TECHNICAL

………………………………………………………………

Replacing The Lamp ……………32

…………………………………………………………

Caring For The Air Filter…………33
Replacing The Air Filter …………34

Caring For The Inside
Of The Projector …………………35
Caring For The Lens ……………35
Caring For The Cabinet
And Remote Control ……………35

Related Messages ………………36
Regarding
The Indicator Lamps ……………38
Phenomena That May Easily Be
Mistaken For Machine Defects …40
Warranty And After-Service ……41

……………………

……………………………………………………

……………………………………

…………………………………………

21

31

33

35

36

42

3

Part Names

The Projector

Zoom ring

Focus ring

Lens

(The picture is

projected from

here.)

15

15

35

Indicates the corresponding
reference page

8

Lens cap

14

Projector (Front/Right)

Elevator feet

8

Fastening The Lens Cap

To avoid losing, please fasten the lens cap to the projector using the strap.

Fix the strap to the strap ring of lens

1

cap, as the right drawing.

Lens cap Strap ring Strap

33

Air filter cover

(An air filter is
inside.)

Picture shift dial

8

(horizontal)

Picture shift dial

8

(vertical)

Remote sensor

13

Elevator button

Pull

Put one piece of the strap into the

2

groove on rivet, as the right drawing.

Strap Rivet

Push the rivet into the strap hole.

3

Strap
hole

Push in

(Bottom side)

Rivet

4

Part Names (continued)

The Projector (continued)

INPUT button

toggles between the signal
ports.

COMPUTER VIDEO

COMPONENT VIDEO

STANDBY/ON
button

prepares for turning the
power on/off. Refer to the
section “Power ON/OFF”.

15

S-VIDEO

14

AUDIO R port

L port

(from a video equipment)

AUDIO port

10

(from a computer)

14

POWER indicator

tells the state of power supply.
Refer to the section “Power
ON/OFF”.

POWER

STANDBY/ON

INPUT

10

10

TEMP

MENU

38

TEMP indicator

lights or blinks when any
problem about internal
temperature has happened.

LAMP indicator

38

lights or blinks when any
problem about the lamp has

LAMP

happened.

MENU buttons

21

operate the menu function.

S-VIDEO port

VIDEO port

Ports cover

10

10

10

COMPONENT VIDEO - Y

COMPONENT VIDEO - C

COMPONENT VIDEO - CR/PR

10

B/PB

10

10

Projector (Rear/Left)

11

14

AC inlet

10

COMPUTER port

10

Power switch

CONTROL
port

5

Part Names (continued)

The Remote Control

S-VIDEO button

15

selects the input signal
of S-VIDEO port.

SEARCH button

19

searches for an input
signal between the
following signal ports of
COMPUTER, VIDEO,
S-VIDEO and
COMPONENT VIDEO.

VIDEO button

15

selects the input signal of
VIDEO port.

COMPUTER button

selects the input signal of
COMPUTER port.

WIDE button

19

toggles between the
modes for aspect ratio.

AUTO button

18

executes automatic
adjustment.

CINEMA, DYNAMIC,
NORMAL, CUSTOM

20

buttons

select each of gamma
mode.

15

SEARCH

SRC

VIDEO

VSVC

COMPUTER

PC

AT

CINEMA

CIN

M1

KEYSTONE

ESC RESET

E

OFF

COMPONENTS-VIDEO

WIDEAUTO

BLANK

WID

DYNAMIC

NORMAL

DYN

NOR CUS

MYMEMORY

M2 M3 M4

ENTER

ENT

CUSTOM

ON

VOLUME

MUTE

MENU

16

OFF button

prepares for turning the
power off.

14

ON button

prepares for turning the
power on.

15

COMPONENT
button

selects the input signal of
COMPONENT port.

17

VOLUME button

turns on/off the VOLUME
mode.
In the VOLUME mode,

To adjust the volume,

use the cursor

/

buttons.

19

BLANK button

blanks the screen
temporarily.

17

MUTE button

mutes/restores the sound.

20

M1, M2, M3, M4
buttons

call the setting data on
each memory.

KEYSTONE button

turns on/off the KEYSTONE
mode.
In the KEYSTONE mode,

To adjust the
keystone,

use the cursor

/

buttons.

ESC button

21

returns to the previous
display at the menu
functions.

6

18

21

ENTER button

proceeds to the next
operation at the menu
functions.

,,,

21

(Cursor) buttons

works for adjusting or
menu controlling.

21

MENU button

opens/closes the menu.

21

RESET button

cancels the adjustment in
progress.
* The adjustments of the
volume etc. are not reset.

Setting Up

Arrangement

WARNING • Install the projector in a suitable environment according to

instructions of the “User’s Manual – Safety Guide” and this manual.

• The power outlet should be close to the projector and easily accessible.

Refer to the illustrations and tables below to determine the screen size and projection
distance.

The values shown in the table are calculated for a full size screen:854×480
(a):Distance from the projector to the screen (±10%)
(b):Distance from the lens center to the top of the screen (±10%)

Reference for
the 16:9 aspect ratio

Screen

(b)

(a)

Reference for
the 4:3 aspect ratio

Screen

(b)

(a)

Screen
size

Side View

Side View

Screen
size

Screen Size [type (m)]

30 (0.8) 29(0.7) 60(1.5) 15(37)
40 (1.0) 40(1.0) 81(2.1) 20(50)
50 (1.3) 50(1.3) 102(2.6) 25(62)
60 (1.5) 60(1.5) 122(3.1) 29(75)
70 (1.8) 71(1.8) 143(3.6) 34(87)
80 (2.0) 81(2.1) 163(4.2) 39(100)

90 (2.3) 91(2.3) 184(4.7) 44(112)
100 (2.5) 101(2.6) 205(5.2) 49(125)
120 (3.0) 122(3.1) 246(6.2) 59(149)
150 (3.8) 153(3.9) 308(7.8) 74(187)
200 (5.1) 204(5.2)
250 (6.4) 256(6.5)
300 (7.6) 307(7.8)

Screen Size [type (m)]

30 (0.8) 36(0.9) 74(1.9) 18(46)

40 (1.0) 49(1.2) 99(2.5) 24(61)

50 (1.3) 62(1.6) 125(3.2) 30(76)

60 (1.5) 74(1.9) 150(3.8) 36(91)

70 (1.8) 87(2.2) 175(4.4) 42(107)

80 (2.0) 99(2.5) 200(5.1) 48(122)

90 (2.3) 112(2.8) 225(5.7) 54(137)
100 (2.5) 124(3.2) 251(6.4) 60(152)
120 (3.0) 150(3.8) 301(7.6) 72(183)
150 (3.8) 187(4.8) 377(9.6) 90(229)
200 (5.1) 250(6.4)
250 (6.4) 313(8.0)
300 (7.6) 376(9.5)

(a) [type (m)]
Min. Max.

411(10.4)
513(13.0)
616(15.7)

(a) [type (m)]
Min. Max.

503(12.8)
629(16.0)
755(19.2)

(b)

[type (cm)]

98(249)
123(311)
147(374)

(b)

[type (cm)]

120(305)
150(381)
180(457)

7

2

1

Setting Up (continued)

Adjusting The Projector's Elevator

CAUTION •
projector might crash down, overturn, smash your fingers and possibly result in
malfunction. To prevent damaging the projector and injuring yourself, ALWAYS HOLD
THE PROJECTOR whenever using the elevator buttons to adjust the elevator feet.

You can use the elevator feet to make adjustments if the surface on which you need to set
the projector is uneven or if you otherwise need to adjust the angle of projection. The
adjustment range of the elevator feet is 0 to 9 degrees.

Press and hold in the elevator buttons.

1

Raise or lower the projector to the

2

desired height and then release the

If you press the elevator buttons without holding the projector, the

elevator buttons.

When you release the elevator buttons, the elevator
feet will lock into position.

As necessary, you can also finely

3

adjust the height of the projector by

Elevator feet

Elevator buttons

twisting the elevator feet by hand.

Using The Picture Shift Dials

The lens of this projector can be shifted horizontally and vertically. When you want to
finely adjust the picture position, use the picture shift dials.

Using the horizontal picture shift dial shifts the picture to right or left.
Using the vertical picture shift dial shifts the picture upward or downward.

Horizontal picture shift dial

1

Vertical picture shift dial

2

NOTE

to the center.

• Do not attach anything other than specified options (such as an optional conversion
lens) to the screw thread. For details, please ask your dealer.

• Generally, better quality of a picture is available when the lens shift is set

7.5:2.5
to

2.5:7.5

10:0

to

0:10

8

Setting Up (continued)

Connecting Your Devices

WARNING • Incorrect connecting could result in fire or electrical shock.
Whenever attempting to connect other devices to the projector, please thoroughly read
the "User's Manual - Safety Guide", this manual and the manual of each device to be
connected.

CAUTION

Attempting to connect a live device to the projector may generate extremely loud
noises or other abnormalities that may result in malfunction and/or damage to the
device and/or projector.

ATTENTION

connection may result in malfunction and/or damage to the device and/or projector.
Refer to the section “TECHNICAL” of this manual for the pin assignment of connectors
and RS-232C communication data.

• Some cables have to be used with core set. Use the accessory cable or a
designated-type cable for the connection. For cables that have a core only at one end,
connect the core to the projector.

• Secure the screws on the connectors and tighten.

• Whenever attempting to connect a laptop computer to the projector, be sure to

activate the laptop’s RGB external image output (set the laptop to CRT display or to
simultaneous LCD and CRT display). For details on how this is done, please refer to the
instruction manual of the corresponding laptop computer.

• TURN OFF ALL DEVICES prior to connecting them to the projector.

• Make sure that you connect devices to the correct port. Incorrect

NOTE

• This projector is compatible with VESA DDC 1/2B. Plug-and-Play can be achieved by
connecting this projector to computers that are VESA DDC (display data channel)
compatible. Please take advantage of this function by connecting the accessory RGB
cable to the COMPUTER port (DDC 1/2B compatible). Plug-and-Play may not work
properly if any other type of connection is attempted.

• Plug-and-Play is a system composed of the computer, its operating system and
peripheral equipment (i.e. display devices).

• Please use the standard drivers in your computer as this projector is a Plug-and-Play
monitor.

NOTE

these modes will not be possible with this projector.

• For some COMPUTER input modes, the optional Mac adapter is necessary.

• When the image resolution is changed on a computer, depending on an input,

automatic adjust function may take some time and may not be completed. In this case,
you may not be able to see a check box to select “Yes/No” for the new resolution on
Windows. Then the resolution will go back to the original. It might be recommended to
use other CRT or TFT monitors to change the resolution.

About Plug-and-Play Capability

• Some computers may have multiple display screen modes. Use of some of

9

S-VIDEO

AUDIO

Y
COMPONENT VIDEO

C

B/PB CR/PR

COMPUTER

CONTROL

S-VIDEO

AUDIO

Y
COMPONENT VIDEO

C

B/PB CR/PR

COMPUTER

CONTROL

S-VIDEO

AUDIO

Y
COMPONENT VIDEO

C

B/PB CR/PR

COMPUTER

CONTROL

S-VIDEO

AUDIO

Y
COMPONENT VIDEO

C

B/PB CR/PR

COMPUTER

CONTROL

S-VIDEO

AUDIO

Y
COMPONENT VIDEO

C

B/PB CR/PR

COMPUTER

CONTROL

S-VIDEO

AUDIO

Y
COMPONENT VIDEO

C

B/PB CR/PR

COMPUTER

CONTROL

2

2

1

3

4

4

5

6

5

6

5

10

6

5

6

7

8

9

7

8

9

1

L-AUDIO-R

VIDEO

L-AUDIO-R

VIDEO

L-AUDIO-R

VIDEO

L-AUDIO-R

VIDEO

L-AUDIO-R

VIDEO

L-AUDIO-R

VIDEO

Setting Up (continued)

Please refer to the following for connecting your devices.
See the rear of the projector and open the ports cover.
You can see the ports.

Connecting to a computer

RGB out RGB cable (D-sub 15 pin)

Audio out Audio cable (Stereo mini)

RS-232C port RS-232C cable

Connecting to a DVD/VCR player

Video out
Audio out (L) Audio/Video cable
Audio out (R)

If using a SCART RGB input,

Video
AUDIO-L
AUDIO-R SCART SCART cable

G out port
B
R

If using a S-video input,

S-video out port S-video cable
Audio out (L) Audio cable
Audio out (R)

1
2

3

4
5

6

4
5
6
7
8
9

10
5
6

If using a component input,

Component (Y) out
Component (CB
Component (C
Audio out (L) Audio cable
Audio out (R)

If using a component input from
COMPUTER port,

Component (Y) out
Component (C
Component (C
Audio out Audio cable(Stereo mini)

10

/PB) out Component cable

R/PR) out

B/PB) out Component cable
R/PR) out (with D-sub 15 pin)

7
8

9
5

6

1

2

Setting Up (continued)

Connecting Power Supply

WARNING • Please use extra caution when connecting the power cord as
incorrect or faulty connections may result in FIRE and/or ELECTRICAL SHOCK. Please
adhere to the “User’s manual – Safety Guide” and the following.

• Only plug the power cord into outlets rated for use with the power cord’s specified
voltage range.

• Only use the power cord that came with the projector. If it is damaged, contact your
dealer to newly get correct one.

• Never modify the power cord. Never attempt to defeat the ground connection of the
three-pronged plug.

• Make sure that you firmly connect the power cord to the projector and wall outlet.

Connect the connector of the

1

power cord to the AC inlet of the
projector.

Firmly plug the power cord’s plug

2

into the outlet.

1

AC Inlet

1

Power cord

Connector Side

11

Remote Control

Putting Batteries

CAUTION Always handle the batteries with care and use them only as directed.
Improper use may result in battery cracking or leakage, which could result in fire, injury
and/or pollution of the surrounding environment.

• Keep the battery away from children and pets.

• Be sure to use only the batteries specified for use with the remote control. Do not mix

new batteries with used ones.

• When inserting batteries, verify that the plus and minus terminals are aligned correctly
(as indicated in the remote control).

• When you dispose the battery, you should obey the law in the relative area or country.

Remove the

1

battery cover.

Slide back and
remove the battery
cover in the direction
of the arrow.

Insert the

2

batteries.

Align and insert the two
AA batteries according to
their plus and minus
terminals (as indicated in
the remote control).

Close the

3

battery cover.

Replace the battery
cover in the direction
of the arrow and
snap it back into
place.

12

30° 30°

approximately
3 meters

Remote Control (continued)

Operating The Remote Control

ATTENTION • Do not drop or otherwise expose the remote control to physical
impact.

• Do not get the remote control wet or place it on wet objects. Doing so may result in
malfunction.

• Remove the batteries from the remote control and store them in a safe place if you
won’t be using the remote control for an extended period.

• Replace the batteries whenever the remote control starts to malfunction.

• When strong lights, such as direct sunlight or light from an extremely close range

(such as from an inverter fluorescent lamp), hit the projector’s remote sensor, the
remote control may cause to function. Adjust the direction of the projector to keep light
from directly hitting the projector’s remote sensor.

• The remote control works with the projector’s remote
sensor.

• The range of the remote sensor is 3 meters with a 60­degree range (30 degrees to the left and right of the
remote sensor).

Also a remote signal reflected in the screen etc. may be
available. If it is difficult to send a remote signal to the
sensor directly, please try.

• Since the remote control uses infrared light to send
signals to the projector (Class1 LED), be sure to use the
remote control in an area free from obstacles that could
block the remote control’s output signal to the projector.

Remote sensor

13

Power ON/OFF

SEARCH

SRC

VIDEO

VSVC

PC

VOLUME

COMPUTER

COMPONENTS-VIDEO

OFF

ON

Turning On The Power

WARNING • When the power is ON, a strong light is emitted. Do not look into the

lens or vents of the projector.

NOTE

• Turn the power on/off in right order. Please power on the projector before

the connected devices. Power off the projector after the connected devices.

Make sure that the power cord is

1

firmly and correctly connected to the

POWER indicator

projector and outlet.

INPUT

STANDBY/ON

When the lens cap is attached, remove

2

the lens cap.

STANDBY/ON button

Set the power switch to [ | ] (ON).

3

Power switch (ON position)

The POWER indicator will light orange.

Press the STANDBY/ON button of the

4

projector or the ON button of the

Power switch

remote control.

The projector lamp will light up and the POWER
indicator will begin blinking green.
According to a setup, the projector lamp may light
up and the POWER indicator may begin blinking
green, without pressing this button.
When the power is completely on, the indicator will
stop blinking and light green.

ON button

POWER

TEMP

MENU

LAMP

14

Power ON/OFF (continued)

Selecting An Input Signal

Using the projector’s control button

1

Press the INPUT button.

As illustrated below, each time you press the INPUT
button, the projector switches between its input signal
ports. Select the signal you wish to project.

COMPUTER VIDEO S-VIDEO

COMPONENT VIDEO

Using the remote control

Press the COMPUTER, VIDEO, S-VIDEO
or COMPONENT button according to an
input to choose.

INPUT

STANDBY/ON

INPUT button

S-VIDEO button

VIDEO button

SEARCH

SRC

VIDEO

VSVC

COMPUTER

PC

COMPUTER button

COMPONENT button

POWER

OFF

COMPONENTS-VIDEO

VOLUME

TEMP

LAMP

MENU

ON

Use the zoom ring to adjust the screen

2

size.

Use the focus ring to focus the picture.

3

Focus ring

Zoom ring

15

STANDBY/ON

INPUT

POWER

LAMP

TEMP

MENU

Power ON/OFF (continued)

SEARCH

SRC

VIDEO

VSVC

PC

VOLUME

COMPUTER

COMPONENTS-VIDEO

OFF

ON

Turning Off The Power

NOTE

• Turn the power on/off in right order. Please power on the projector before

the connected devices. Power off the projector after the connected devices.

Press the STANDBY/ON button of the

1

projector or the OFF button of the
remote control.

The message “Power off?” will appear on the screen
for approximately 5 seconds.

POWER indicator

Press the STANDBY/ON button or the

2

OFF button again while “Power off?”
the message is visible.

The projector lamp will go off, and the POWER
indicator will begin blinking orange.
Then the POWER indicator will stop blinking and light
to solid orange when the lamp cooling is complete.

Switch the power switch to [O] (OFF).

3

Power switch (OFF position)

The POWER indicator will go off.

Attached the lens cap.

4

STANDBY/ON button

Power switch

OFF button

16

Operating

16

VOLUME

VOLUME

MUTE

Adjusting The Volume

Press the VOLUME button.

1

SEARCH

COMPUTER

CINEMA

KEYSTONE

OFF

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

PC

WIDEAUTO

BLANK

WID

AT

DYNAMIC

NORMAL

DYN

NOR CUS

CIN

MYMEMORY

M1

M2 M3 M4

ENTER

ENT

ESC RESET

E

ON

VOLUME

MUTE

CUSTOM

MENU

As illustrated on the right, a dialog will
appear on the screen to aid you in adjusting
the volume.

Use the

2

volume.

Press the VOLUME button again to close the dialog and
complete this operation.
(Even if you don't do anything, the dialog will
automatically disappear after a few seconds.)

VOLUME

/

buttons to adjust the

Press this to increase the volume
Press this to decrease the volume

VOLUME

16

Temporarily Muting The Sound

Press the MUTE button.

1

Press the MUTE button.
As illustrated on the right, a dialog will appear on the
screen indicating that you have muted the sound.
(If you don't do anything, the dialog will automatically
disappear after a few seconds.)
Press the MUTE or VOLUME button again to restore the
sound.

SEARCH

COMPUTER

CINEMA

KEYSTONE

OFF

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

PC

WIDEAUTO

BLANK

WID

AT

DYNAMIC

NORMAL

DYN

NOR CUS

CIN

MYMEMORY

M1

M2 M3 M4

ENTER

ENT

ESC RESET

E

ON

VOLUME

MUTE

CUSTOM

MENU

VOLUME

MUTE

16

17

Operating (continued)

Using The Automatic Adjustment Feature

AUTO

SEARCH

COMPUTER

CINEMA

KEYSTONE

OFF

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

PC

WIDEAUTO

BLANK

AT

WID

DYNAMIC

NORMAL

CIN

DYN

NOR CUS

MYMEMORY

M1

M2 M3 M4

ENTER

ENT

ESC RESET

E

ON

VOLUME

MUTE

CUSTOM

MENU

Press the AUTO button.

1

Automatic Adjustment for RGB Input

Horizontal position (H POSITION), vertical position (V POSITION),
clock phase (H PHASE) and horizontal size (H SIZE) are
automatically adjusted.
Make sure that the application window is set to its maximum size
prior to attempting to use this feature. Dark pictures may still be
incorrectly adjusted. Use a bright screen when adjusting.

Automatic Adjustment for Video Input

The signal type best suited for the respective input signal is
selected automatically.
This feature is available only if VIDEO is set to AUTO in the INPUT
menu.

NOTE

• The automatic adjustment operation requires approximately 10 seconds.

Also, please note that it may not function correctly with some input.

Correcting Keystone Distortions

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

COMPUTER

PC

WIDEAUTO

BLANK

WID

AT

CINEMA

DYNAMIC

NORMAL

DYN

NOR CUS

CIN

MYMEMORY

M2 M3 M4

M1

KEYSTONE

ENTER

ENT

ESC RESET

E

NOTE

• When the WIDE is selected under the ASPECT item of the MAIN menu, this

VOLUME

MUTE

CUSTOM

MENU

Press the KEYSTONE button.

1

As illustrated on the right, a dialog will appear on
the screen to aid you in correcting the distortion.

KEYSTONE

Use the

2

Press the KEYSTONE button again to close the dialog

,

buttons to correct distortion.

and complete this operation. (Even if you don't do
anything, the dialog will automatically disappear after
a few seconds.)

adjustment is ignored.

• The correcting keystone distortions function may not be work well with some types of
input signals.

• The adjustable range for correcting keystone distortions will vary with the type of
input signal.

KEYSTONE

+0

18

4:3 16:9 15:9 32:15
4:3 16:9 WIDE MOVIE-1 MOVIE-2

Operating (continued)

Signal Searching

Press the SEARCH button.

1

SEARCH

COMPUTER

CINEMAATDYNAMIC NORMAL

OFF

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

PC

WIDEAUTO

BLANK

WID

ON

VOLUME

MUTE

CUSTOM

Cycle through input signals, displaying the images of retrieved signals. If
no signal is found, returns to the signal that was selected before the search
was begun.

COMPUTER VIDEO S-VIDEO

SEARCH

COMPONENT VIDEO

NOTE

• May not function properly with some input signals.

• The signal searching function takes about 10 seconds to display an image.

Selecting The Aspect Ratio

Press the WIDE button.

1

COMPUTER input

• At a COMPUTER input, selecting an aspect ratio may display the
message “SYNC IS OUT OF RANGE”. In this case, please select one of
other aspect ratios.

VIDEO, S-VIDEO, COMPONENT VIDEO input

• At a COMPONENT VIDEO input of 16:9 Hi-Vision of 1125i

SEARCH

COMPUTER

CINEMA

KEYSTONE

OFF

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

PC

WIDEAUTO

BLANK

WID

AT

DYNAMIC

NORMAL

DYN

NOR CUS

CIN

MYMEMORY

M2 M3 M4

M1

ENTER

ENT

ESC RESET

E

ON

VOLUME

MUTE

CUSTOM

MENU

(1035i/1080i)/750p, only 16:9 can be selected.

Temporarily Blanking The Screen

PC

AT

CINEMA

CIN

M1

KEYSTONE

WIDEAUTO

BLANK

WID

DYNAMIC

NORMAL

DYN

NOR CUS

MYMEMORY

M2 M3 M4

MUTE

CUSTOM

MENU

Press the BLANK button.

1

The input signal screen is shut off, and a blank screen appears. You can
set the blank screen using the menu (from the SCREEN menu,
select BLANK).
Press the BLANK button again to remove the blank screen,
and return to the input signal screen.

WIDE

BLANK

NOTE

• The temporarily blanking function will automatically finish if a button of the remote control

except the , , , , ENTER, ESC, RESET or ON button is pressed, or if a button of

projector is pressed, or if there is a change in the input signal’s state.

19

Operating (continued)

CO U

SRC

Selecting The Gamma Mode

PC

AT

CINEMA

CIN

M1

KEYSTONE

WIDEAUTO

BLANK

WID

DYNAMIC

NORMAL

DYN

NOR CUS

MYMEMORY

M2 M3 M4

ENTER

ENT

MUTE

CUSTOM

MENU

Press the CINEMA, DYNAMIC, NORMAL or

1

CUSTOM button according to a mode to
choose.

This projector has the 4 modes called the CINEMA,
DYNAMIC, NORMAL and CUSTOM.

Recalling Your Adjustments

VIDEO

VSVC

COMPUTER

PC

WIDEAUTO

WID

AT

CINEMA

DYNAMIC

DYN

CIN

MYMEMORY

M1

M2 M3 M4

KEYSTONE

ENTER

COMPONENTS-VIDEO

BLANK

NORMAL

NOR CUS

ENT

VOLUME

MUTE

CUSTOM

MENU

Press the M1, M2, M3 or M4 button to recall

1

a setting.

This projector can memorize 4 settings by the MY MEMORY
function of the PICTURE-1 menu.
Pressing the M1, M2, M3 or M4 button calls the setting of
the memory whose number corresponds, if it is memorized.
It is the same function as selecting the LOAD1, LOAD2,
LOAD3 or LOAD4 under the MY MEMORY item of the
PICTURE-1 menu. Please refer to the description of MY
MEMORY item of the section “PICTURE-1 Menu”.

20

Multifunctional Settings

Using The Menu Functions

This projector has the following menus: MAIN, PICTURE-1, PICTURE-2, INPUT, AUTO,
SCREEN, OPTION. Each of these menus is operated using the same methods. The basic
operations of these menus are as follows.

Press the MENU

SEARCH

COMPUTER

CINEMA

KEYSTONE

OFF

SRC

VIDEO

COMPONENTS-VIDEO

VSVC

PC

WIDEAUTO

BLANK

WID

AT

DYNAMIC

NORMAL

DYN

NOR CUS

CIN

MYMEMORY

M1

M2 M3 M4

ENTER

ENT

ESC RESET

E

ON

VOLUME

MUTE

CUSTOM

MENU

MENU

RESETESC

1

button.

The menu display
appears on the screen.

Use the

2

buttons to select
a menu , then
press the or
ENTER button.

The display of the
selected menu
appears.

ENTER

Use the

3

then press the or ENTER button.

/

buttons to select an item,

The operation display of the selected item appears.

4

Use the

/

buttons to operate the item.

When you want to reset the adjustment, press the RESET
button during the operation. Note that the items whose
functions are performed simultaneously with operating (ex.
LANGUAGE, WHISPER, H PHASE etc.) are not reset.
When you want to return to the previous display, press the

or ESC button.

[ex. Adjusting
VOLUME]

1. Press the MENU
button.

2.

/

Use the /
buttons to select
the OPTION, then
press the or
ENTER button.

3.Use the /

buttons to select
the VOLUME,
then press the

or ENTER

button.

4.Use the /

buttons to adjust
the VOLUME.

Press the MENU button, or do not perform

5

any operation for several seconds

.

The menu display disappears and your operation finishes.

5.Press the MENU

button.

21

Multifunctional Settings (continued)

MAIN Menu

With the MAIN menu, the items shown in the table below can be
performed.
Perform each operation in accordance with the instructions in the
table below.

Item Description

Adjust the Keystone (Vertical) Distortion:

Upper in the data ⇔ Lower in the data

• The adjustable range of this function will vary with the type of input signal. At
some signals, this function may not work well.

• When the V:INVERT or the H&V:INVERT is selected under the MIRROR item, if

KEYSTONE

BRIGHT

CONTRAST

ASPECT

WHISPER

MIRROR

LANGUAGE

RESET

the projector screen is inclined or if the projector is angled downward, this
function may not work correctly.

• When the WIDE is selected under the ASPECT item of the MAIN menu, this
adjustment is ignored.

• When the zoom adjustment is set to the TELE side, this correction may be
excessive. This function should be used with zoom set to WIDE whenever
possible.

Adjust Brightness: Light ⇔ Dark

Adjust Contrast: Strong ⇔ Weak

Select an Aspect Ratio
At a COMPUTER input:

4:3 ⇔ 16:9 ⇔ 15:9 ⇔ 32:15

• At a COMPUTER input, selecting an aspect ratio may display the message
“SYNC IS OUT OF RANGE”. In this case, please select one of other aspect

ratios.

At a VIDEO input, a S-VIDEO input or a COMPONENT VIDEO input:

4:3 ⇔ 16:9 ⇔ WIDE ⇔ MOVIE-1 ⇔ MOVIE-2

• At a COMPONENT VIDEO input of 16:9 Hi-Vision of 1125i(1035i/1080i)/750p,
only 16:9 can be selected.

Select the Whisper Mode:

NORMAL ⇔ WHISPER

• When the WHISPER is selected, acoustic noise and screen brightness are
reduced.

Select a Mirror Status:

NORMAL ⇔ H:INVERT ⇔ V:INVERT ⇔ H&V:INVERT

Select a Menu Language:

ENGLISH ⇔ FRANÇAIS ⇔ DEUTSCH ⇔ ESPAÑOL
⇒ ITALIANO ⇔ NORSK ⇔ NEDERLANDS
⇒ 日本語 ⇔ PORTUGUÊS ⇔

中文 ⇔

⇒ SVENSKA ⇔⇔SUOMI ⇔ POLSKI

Reset the MAIN Menu Items:

Selecting the EXECUTE performs this function.

EXECUTE CANCEL

⇒

• The items of the MAIN menu are collectively returned to the initial setting.
Note that the items WHISPER and LANGUAGE are not reset.

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

KEYSTONE
BRIGHT
CONTRAST
ASPECT
WHISPER
MIRROR
LANGUAGE
[Language]

⇒

⇒

+0
+0
+0
4:3
NORMAL
NORMAL
ENGLISH

⇒

22

Multifunctional Settings (continued)

MENU
MAIN

PICTURE - 1 Menu

With the PICTURE-1 menu, the items shown in the table below can be
performed.
Perform each operation in accordance with the instructions in the table below.

Item Description

Select a Gamma Mode:

NORMAL ⇔ CINEMA ⇔ DYNAMIC ⇔ CUSTOM

• Selecting the COSTOM and then pressing the or the ENTER button calls
the CUSTOM menu.

CUSTOM Menu

Selecting one from the following and then pressing the or the ENTER
button performs each function.

GAMMA ⇔ COLOR TEMP ⇔ R ⇔ G ⇔ B

• The R, G and B can be selected only when the USER is selected under the
COLOR TEMP.

GAMMA

CUSTOM

GAMMA

CUSTOM

COLOR TEMP

CUSTOM

R

CUSTOM

G

CUSTOM

B

Adjust the Gamma Data:

Up ⇔ Down

Select a Color Temperature Mode:

HIGH ⇔ MIDDLE ⇔ LOW ⇔ USER

Adjust the Red Color Level for the USER mode of the
COLOR TEMP:

Strong ⇔ Weak

Adjust the Green Color Level for the USER mode of the
COLOR TEMP:

Strong ⇔ Weak

Adjust the Blue Color Level for the USER mode of the
COLOR TEMP:

Strong ⇔ Weak

PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

GAMMA
COLOR BAL R
COLOR BAL G
COLOR BAL B
SHARPNESS
COLOR
TINT
MY MEMORY

NORMAL
+0
+0
+0
+0
+0
+0
SAVE1

COLOR BAL R

COLOR BAL G

COLOR BAL B

SHARPNESS

COLOR

TINT

Adjust the Red Color Balance: Strong ⇔ Weak

Adjust the Green Color Balance: Strong ⇔ Weak

Adjust the Blue Color Balance: Strong ⇔ Weak

Adjust the Whole Sharpness: Clear ⇔ Soft

• This is a function for video inputs. This item can’t be selected only at
COMPUTER inputs.

Adjust COLOR : Strong ⇔ Weak

• This is a function for video inputs. This item can’t be selected only at
COMPUTER inputs including SCART RGB inputs.

• It is unavailable to deepen colors on SECAM signal input. (The adjustment
bar position and value in menu box are changeable but no effect.)

Adjust the Tint: Green ⇔ Red

• This is a function for video inputs. This item can’t be selected only at
COMPUTER inputs including SCART RGB inputs.

23

Multifunctional Settings (continued)

PICTURE - 1 Menu (continued)

Item Description

Load/Save a Setting:

Selecting one from the following and then pressing the or the ENTER
button performs each function.

LOAD1 ⇔ LOAD2 ⇔ LOAD3 ⇔ LOAD4
⇒ SAVE1 ⇔ SAVE2 ⇔ SAVE3 ⇔ SAVE4

• This projector has 4 memories called M1, M2, M3 and M4 for settings.

MY MEMORY

RESET

Performing the SAVE1, SAVE2, SAVE3 or SAVE4 puts the current setting data
on the memory whose number corresponds. Performing the LOAD1, LOAD2,
LOAD3 or LOAD4 calls the data of memory whose number corresponds, and
adjusts the picture automatically depending on the data.

• The LOAD1, LOAD2, LOAD3 or LOAD4 cannot be selected when there is no
memory whose number corresponds.

• At a different signal input from the signal that was being inputted when the
setting was memorized, the picture may not be adjusted correctly.

Reset the PICTURE-1 Menu Items:

Selecting the EXECUTE performs this function.

EXECUTE CANCEL

• The items of the PICTURE-1 menu are collectively returned to the initial
setting. Note that the items MY MEMORY and CUSTOM - GAMMA are not
reset.

⇒

⇒

24

Multifunctional Settings (continued)

PICTURE - 2 Menu

With the PICTURE-2 menu, the items shown in the table below can
be performed.
Perform each operation in accordance with the instructions in the
table below.

Item Description

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

V POSITION
H POSITION
H PHASE
H SIZE
OVER SCAN
RESET

20
142
31
1344
95

V POSITION

H POSITION

H PHASE

H SIZE

OVER SCAN

RESET

Adjust the Vertical Position: Up ⇔ Down

• This item can be selected only at a COMPUTER input.

Adjust the Horizontal Position: Left ⇔ Right

• This item can be selected only at a COMPUTER input.

Adjust the Horizontal Phase (to eliminate flicker) :

Right ⇔ Left

• This item can be selected only at a COMPUTER input or a COMPONENT
VIDEO input.

Adjust the Horizontal Size: Large ⇔ Small

• When this adjustment is excessive, the picture may not be displayed
correctly. In such a case, please press the RESET button during selection of
this item to reset the H SIZE.

• This item can be selected only at a COMPUTER input.

Adjust the Over-scan Ratio:

Large ⇔ Small

• This item can be selected only at a VIDEO input, a S-VIDEO input or a
COMPONENT VIDEO input.

• When this adjustment is too large, a certain degradation may appear at the
frame area of the picture. In such a case, please adjust small.

Reset the PICTURE-2 Menu Items:

Selecting the EXECUTE performs this function.

EXECUTE CANCEL

⇒

• The items of the PICTURE-2 menu are collectively returned to the initial
setting. Note that the H PHASE item is not reset.

25

Multifunctional Settings (continued)

INPUT Menu

With the INPUT menu, the items shown in the table below can be
performed.
Perform each operation in accordance with the instructions in the
table below.

Item Description

Select a Color Space Mode:

AUTO ⇔ RGB ⇔ SMPTE240 ⇔ REC709 ⇔ REC601

• This item can be selected only at a COMPUTER input or a COMPONENT

COLOR SPACE

COMPONENT

VIDEO

FRAME LOCK

3D-YCS

VIDEO input.

• When the AUTO is selected, the optimum mode is automatically selected.
However, it may not work well at some signals. In such a case, select the
SMPTE240 or REC709 for HDTV signal.

Select a Function of COMPONENT VIDEO Jacks:

COMPONENT ⇔ SCART RGB

• When the SCART RGB is selected, the COMPONENT VIDEO jacks function
as ports for a RGB input with a SCART cable. Refer to the section “Signal
Connectors” of “TECHNICAL”.

Select a Signal Type Mode:

AUTO ⇔ NTSC ⇔ PAL ⇔ SECAM

⇒

NTSC 4.43 ⇔ M-PAL ⇔ N-PAL

• This item performs only at a VIDEO input or a S-VIDEO input. For a
COMPONENT VIDEO input, although this item is ineffective, the signal type is
identified automatically even if the AUTO is not selected.

• Selecting the AUTO automatically selects the optimum mode. However, it
may not work well at a PAL60 signal and some other signals. If the picture
becomes unstable (ex. a irregular picture, color lack), please select the mode
depending on the input signal.

• The AUTO operation requires approximately 10 seconds.

Select the Frame Lock Mode:

TURN ON ⇔ TURN OFF

• This function performs only at a COMPUTER input with vertical frequency of
48 to 72 Hz.

• When the TURN ON is selected, a moving picture is displayed more
smoothly.

• This function may cause a certain degradation of the picture. In such a case,
please select the TURN OFF.

Select a 3D-YCS mode:

STILL IMAGE ⇔ NORMAL ⇔ TURN OFF

• This function performs only at a VIDEO input of NTSC 3.58.

• NORMAL is the mode for images with a lot of motions like movies, and STILL

IMAGE is the mode for images with few motions or completely still ones like
slides.

• When this function performs, the VIDEO NR function is ineffective.

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

COLOR SPACE
COMPONENT
VIDEO
FRAME LOCK
3D-YCS
VIDEO NR
PROGRESSIVE
INFORMATION

AUTO
COMPONENT
AUTO
TURN ON
NORMAL
LOW
TURN OFF

⇒

26

Multifunctional Settings (continued)

INPUT Menu (continued)

Item Description

Select a Noise Reduction Mode:

HIGH ⇔ MIDDLE ⇔ LOW

• This function performs only at a VIDEO input or a S-VIDEO input. At a VIDEO
input of NTSC 3.58, this function performs only when the TURN OFF is

VIDEO NR

PROGRESSIVE

INFORMATION

S2-ASPECT

RESET

selected under the 3D-YCS.

• When the HIGH, the MIDDLE or the LOW is selected, the noise on screen is
reduced according to each mode.

• When this function is excessive, it may cause a certain degradation of the
picture.

Select the Progressive Mode:

TV ⇔ FILM ⇔ TURN OFF

• This function performs only at an interlaced signal of a VIDEO input, a S­VIDEO input or a COMPONENT VIDEO input of 525i or 625i signal. The FILM
mode is adaptable to the 3-2 Pull-Down system to the conversion.

• When the TV or FILM is selected, the screen image will be crisper. But it may
cause a certain defect (for example, jagged line) of the picture at a quick
moving object. In such a case, please select the TURN OFF, even though the
screen image may lose the crisp.

• This function may cause a certain degradation of the picture. In such a case,
please select the TURN OFF.

Display the Information:

Pressing the or the ENTER button performs this function.

• Use this function when you want the information about the current input (ex.
the resolution and the vertical frequency at a COMPUTER input, the signal
type of a video input) and setting states of the COMPONENT, the VIDEO and
the FLAME LOCK.

Select the S2-ASPECT Mode:

TURN ON ⇔ TURN OFF

• This function performs only at a S-VIDEO input.

• When the TURN ON is selected, an S2-Video signal can be identified and the

optimum aspect ratio is automatically selected.

• When the ASPECT button of the remote control is used or the ASPECT item of
the MAIN menu is operated, the S2-ASPECT mode will be switched to the
TURN OFF automatically.

Reset the INPUT Menu Items:

Selecting the EXECUTE performs this function.

EXECUTE CANCEL

• The items of the INPUT menu are collectively returned to the initial setting.
Note that the INFORMATION item is not reset.

⇒

27

Multifunctional Settings (continued)

AUTO Menu

With the AUTO menu, the items shown in the table below can be
performed.
Perform each operation in accordance with the instructions in the
table below.

Item Description

Automatically Adjust the Picture:

Pressing the or the ENTER button performs this function.

At a COMPUTER input:

• V POSITION, H POSITION, H PHASE and HSIZE are automatically adjusted.
Please use this function with the maximum window size.

At a VIDEO input or S-VIDEO input:

• This function performs only when the AUTO is selected under the VIDEO item

ADJUST

POWER OFF

SEARCH

RESET

of the INPUT menu. For a COMPONENT VIDEO input, although this function is
ineffective, the signal type is identified automatically even if the AUTO is not
selected.

• This function automatically selects the optimum mode for the input signal.
However, it may not work well at a PAL60 signal and some other signals. If
the picture becomes unstable (ex. irregular picture, color lack), please use
the function of VIDEO of the INPUT menu.

• The operation of this function requires approximately 10 seconds. Also,
please note that it may not function correctly with some input.

Set the Automatically Power Off Timer:

Long (Max. 99 minutes.) ⇔ Short (Min. 0 minute =DISABLE)

• This function performs only when the time is set to 1 to 99.

• When the set time passes without a valid signal (there is no signal, or the

signal is out of specifications), the projector lamp automatically goes off, and
the POWER indicator begins blinking. Please refer to the section “Turning
OFF The Power” of “Power ON/OFF” about the turning off.

Automatically Signal Search:

TURN ON ⇔ TURN OFF

• If the TURN ON is selected under this item when no signal input is detected,
the projector begins searching for an input signal. When an input signal is
detected the projector will cease searching and the picture will appear.

• The priority of a search is as follows:

COMPUTER → VIDEO → S-VIDEO → COMPONENT VIDEO

→

• If the projector is unstable to find an input signal at any of its ports, it will
return to the state it was in prior to the search.

Reset the AUTO Menu Items:

Selecting the EXECUTE performs this function.

EXECUTE CANCEL

⇒

• The items of the AUTO menu are collectively returned to the initial setting.
Note that the item ADJUST is not reset.

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

ADJUST
POWER OFF
SEARCH
RESET

0 min
TURN ON

28

Multifunctional Settings (continued)

SCREEN Menu

With the SCREEN menu, the items shown in the table below can be
performed.
Perform each operation in accordance with the instructions in the
table below.

Item Description

Select a Blank Screen Color:

BLANK

START UP

BLUE

• The blank screen of selected color is displayed by pressing the BLANK
button. Please refer to the section “Temporarily Blanking The Screen” of
“Operating” about the screen blanking.

Select the Start Up Screen:

TURN ON

• If the TURN ON is selected when there is no signal or the detected signal is
out of specifications, the blank screen is displayed.

Adjust a Menu Position:

Pressing the or ENTER button start adjusting,

Up

⇔

WHITE

⇔

⇔

TURN OFF

BLACK

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

BLANK
START UP
MENU POSITION
MESSAGE
RESET

BLACK
TURN ON

TURN ON

MENU POSITION

MESSAGE

RESET

Left Right

Down

• The button does not finish this item. When you want to return to the

previous display, please press the ESC button.

Select the Message Mode:

TURN ON

⇔

TURN OFF

• When the TURN OFF is selected, the following message functions are
disabled:

The message of “AUTO IN PROGRESS”
The message of “NO INPUT IS DETECTED”
The message of “SYNC IS OUT OF RANGE”
The message while being searched for an input signal, “Searching …..”
The message when an input signal is detected, “Detecting …..”
The indication of the input signal by input change.

Reset the SCREEN Menu Items:

Selecting the EXECUTE performs this function.

EXECUTE CANCEL

⇒

• The items of the SCREEN menu are collectively returned to the initial setting.

29

Multifunctional Settings (continued)

OPTION Menu

With the OPTION menu, the items shown in the table below can be
performed.
Perform each operation in accordance with the instructions in the
table below.

Item Description

VOLUME

LAMP TIME

FILTER TIME

Adjust Volume: High ⇔ Low

To begin the operation of this item, please press the button of the
projector or the RESET button of the remote control for 3 seconds.

Reset the Lamp Timer:

Selecting the RESET performs this function.

RESET CANCEL

⇒

• The numerical value of four digits shown on this menu is the projector use
time since the last RESET operation of this item. The value is reset to 0 at the
same time the RESET is selected.

• The value of this function is used to display the message of “CHANGE THE
LAMP”. So this function must be performed only immediately after replacing
the lamp.

Do not perform this function unless you have replaced the lamp. Perform this
function every time the lamp is replaced. Incorrect performing of this function
causes incorrect operation of the message function.

• Please see to the section “Lamp” about replacing the lamp.

To begin the operation of this item, please press the button of the
projector or the RESET button of the remote control for 3 seconds.

Reset the Filter Timer:

Selecting the RESET performs this function.

RESET CANCEL

⇒

• The numerical value of four digits shown on this menu is the projector use
time since the last RESET operation of this item. The value is reset to 0 at the
same time the RESET is selected.

• The value of this function is used to display the message of “CLEAN THE AIR
FILTER”. So this function must be performed only immediately after cleaning
or replacing the air filter.

Do not perform this function unless you have cleaned or replaced the air filter.
Perform this function every time the air filter is cleaned or replaced. Incorrect
performing of this function causes incorrect operation of the message
function.

• Please see to the section “Air Filter” about cleaning and replacing the air
filter.

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION

: SELECT

VOLUME
LAMP TIME
FILTER TIME

16
1234h
21h

30

Lamp

WARNING

The projector uses a high-pressure mercury glass lamp. The lamp can break with a
loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time.

Note that each lamp has a different lifetime, and some may burst or burn out soon after
you start using them. In addition, when the bulb bursts, it is possible for shards of
glass to fly into the lamp housing, and for gas containing mercury to escape from the
projector’s vent holes.

• If the lamp should break (it will make a loud bang when it does), unplug the power
cord from the outlet, and make sure to request a replacement lamp from your local
dealer. Note that shards of glass could damage the projector’s internals, or cause
injury during handling, so please do not try to clean the projector or replace the lamp
yourself.

• If the lamp should break (it will make a loud bang when it does), ventilate the room
well, and make sure not to breathe the gas that comes out of the projector vents, or
get it in your eyes or mouth.

• Do not open the lamp cover while the projector is suspended from above. This is
dangerous, since if the lamp’s bulb has broken, the shards will fall out when the cover
is opened. In addition, working in high places is dangerous, so ask your local dealer
to have the lamp replaced even if the bulb is not broken

• If the indicators or a message prompts you to replace the lamp (see the section
“Related Messages” and “Regarding the indicator Lamps”), replace the lamp as soon

as possible. Using the lamp for long periods of time, or past the replacement date,
could cause it to burst. Do not use old (used) lamps; this is a cause of breakage.

• If the lamp breaks soon after the first time it is used, it is possible that there are
electrical problems elsewhere besides the lamp. If this happens, contact your local
dealer or a service representative.

• Use the lamp of the specified type only.Type number: DT00611

• Handle with care: jolting or scratching could cause the lamp bulb to burst during use.

• Before replacing the lamp, make sure the power switch is off and the power cable is

not plugged in, then wait at least 45 minutes for the lamp to cool sufficiently. Handling
the lamp while hot can cause burns, as well as damaging the lamp.

• Do not use the projector with the lamp cover removed. At the lamp replacing, make
sure that the screws are screwed in firmly. Loose screws could result in damage or
injury.

• Obey local ordinances when disposing of used lamps. In most cases, it is possible to
dispose of used bulbs in the same manner as used glass bottles, but in some cases,
bulbs are sorted separately.

HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE

(sold separately)

31

Lamp (continued)

Replacing The Lamp

WARNING • Please carefully read the “User’s Manual - Safety Guide”.
CAUTION

• When you replace the lamp, please replace also the air filter. The air filter may be
attached when you buy a replacement lamp for this projector. Please ask your dealer.

If the indicators or a message prompts you to replace the lamp, replace the lamp as soon
as possible. Using the lamp for long periods of time, or past the replacement date, could
cause it to burst. If the projector is mounted on the ceiling, or if the lamp has broken, do
not try to clean the projector or replace the lamp yourself.

Turn off the projector, and unplug the power cord. Allow the lamp

1

bulb to cool for at least 45 minutes.

Contact your local dealer to prepare a new lamp. Tell the dealer

2

your lamp type number. If the projector is mounted on the ceiling,
or if the lamp has broken, also ask the dealer to replace the lamp.

In the case of replacement by yourself,

After making sure that the projector

3

has cooled adequately, slowly flip
over the projector, so that the bottom
is facing up.

Unscrew the screw of the lamp cover,

4

then slide and take the lamp cover up.

• Do not reset the lamp timer without replacing the lamp.

Lamp cover

Screw

32

Unscrew the 2 screws, and slowly

5

pick up the lamp by the handles.

Insert the new lamp, and tighten the 2

6

screws firmly to lock it in place.

Slide the lamp cover into place, and tighten the screw of the lamp

7

cover firmly.

Slowly turn the projector so that the top is facing up.

8

Turn on the projector, and reset the lamp timer. When the lamp has

9

been replaced after the message of “THE POWER WILL TURN OFF
AFTER 0hr.” is displayed, complete the following operation within
10 minutes of switching power on.

(1) While the projector running, press the MENU button to open the menu.
(2) Choose the “OPTION” on the menu using the

or ENTER button.

(3) Choose the “LAMP TIME” using the

of projector or the RESET button of remote control for 3 seconds.

(4) Choose the “RESET” using the button.

button, then press and hold the button

/

Handles

Screws

button, then press the button

/

Air Filter

WARNING • Please carefully read the “User’s Manual - Safety Guide”.

• Before replacing the air filter, make sure the power switch is off and the power cable

is not plugged in.

• Use the air filter of the specified type only. Type number:

• Do not use the projector with the air filter and filter cover removed. The use without

the air filter could result in damage.

CAUTION

• If the air filter becomes clogged by dust or the like, internal temperature rises and
could cause malfunction. The power is automatically turned off in order to prevent the
projector from overheating internally.

• When you replace the lamp, please replace also the air filter. The air filter may be
attached when you buy a replacement lamp for this projector. Please ask your dealer.

• Do not reset the filter timer without cleaning or replacing the air filter.

Caring For The Air Filter

The air filter should be cleaned about every 100 hours. If the indicators or a message
prompts you to clean the air filter (see the section “Related Messages” and “Regarding
The Indicator Lamps”), clean the air filter as soon as possible. If the air filter becomes
clogged by dust or the like, internal temperature rises and could cause malfunction.

Turn off the projector, and unplug the power cord.

1

NJ08312 (sold separately)

Apply a vacuum cleaner to

2

the top of the filter cover to

Filter Cover

clean the air filter.

Reset the filter timer.

3

(1) Turn on the projector. While the projector running, press the MENU button to

open the menu.

(2) Choose the “OPTION” on the menu using the

button or ENTER button.

(3) Choose the “FILTER TIME” using the

button of projector or the RESET button of remote control for 3 seconds.

(4) Choose the “RESET” using the button.

/

button, then press the

/

button, then press and hold the

33

Air Filter (continued)

Replacing The Air Filter

If the soiling will not come off the air filter, or it becomes damaged, then it needs to be
replaced. Please replace the air filter as soon as possible.

Turn off the projector, and unplug the power cord.

1

Contact your local dealer to prepare a

2

new air filter. Tell the dealer your air
filter type number.

After making sure that the projector

3

has cooled adequately, remove the
filter cover. Hold the release buttons of
the filter cover, while pulling up it.

Hold the release buttons of the air

4

filter, while pulling down it.

Insert a new air filter, and replace the filter cover.

5

Reset the filter timer.

6

(1) Turn on the projector. While the projector running, press the MENU button to

open the menu.

(2) Choose the “OPTION” on the menu using the

button or ENTER button.

(3) Choose the “FILTER TIME” using the

button of projector or the RESET button of remote control for 3 seconds.

(4) Choose the “RESET” using the button.

/

button, then press the

/

button, then press and hold the

Filter cover

Release buttons

Release buttons

Air filter

34

Other Care

WARNING • Please carefully read the “User’s Manual - Safety Guide”.

• Before replacing the air filter, make sure the power switch is off and the power cable

is not plugged in.

ATTENTION

including benzene and paint thinner.

• Do not use aerosols or sprays.

• Do not polish or wipe with hard objects.

Caring For The Inside Of The Projector

In order to ensure the safe use of your projector, please have it cleaned and inspected by
your local dealer about once every 2 years. Never try to care for the inside of the unit
yourself. Doing so is dangerous.

Caring For The Lens

Turn off the projector, and unplug the

1

power cord.

Lightly wipe the lens with a

2

commercially available lens-cleaning
wipe. Do not touch the lens directly
with your hand.

• Do not use cleaners or chemicals other than those listed below,

Lens

Caring For The Cabinet And Remote Control

Turn off the projector, and unplug the power cord.

1

Wipe lightly with gauze or a soft cloth.

2

If soiling is severe, dip soft cloth in water or a neutral cleaner dilute in water, and
wipe lightly after wringing well. Then, wipe lightly with a soft, dry cloth.

35

Troubleshooting

Related Messages

When the unit's power is ON, messages such as those shown below may be displayed.
When any such message is displayed on the screen, please respond as described
below. If the same message is displayed after the treatment, or if a message other than
the following appears, please contact your dealer or service company.

Message Description

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

THE POWER WILL TURN OFF

AFTER ** hr.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

THE POWER WILL TURN OFF

AFTER 0 hr.

NO INPUT IS DETECTED

ON ***

SYNC IS OUT OF RANGE

ON *** *****kHz *****Hz

fH fV

CHECK THE AIR FLOW

Lamp usage time is approaching 2000 hours. (*2)
Preparation of a new lamp, and an early lamp change is
recommended. After you have changed the lamp, please be
sure to reset the lamp timer.

(*1)

Lamp usage time is approaching 2000 hours. (*2)
A lamp change within ** hours is recommended. When lamp
usage reaches 2000 hours, the power will automatically be
turned OFF. Please change the lamp by referring to the “Lamp”
section of this manual. After you have changed the lamp,
please be sure to reset the lamp timer.

(*1)

As lamp use has reached 2000 hours (*2), the power will soon
be automatically turned OFF.
Please immediately turn the power off, and change the lamp by
referring to the “Lamp” section of this manual. After you have
changed the lamp, please be sure to reset the lamp timer.

There is no input signal.
Please confirm the signal input connection, and the status of the
signal source.

The horizontal or vertical wavelength of the inputted signal is
outside of the response parameters of this unit.
Please confirm the specs for this unit or the signal source
specs.

The internal portion temperature is rising.
Please turn the power OFF, and allow the unit to cool down at
least 20 minutes. After having confirmed the following items,
please turn the power ON again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?

NOTE

(*1) • Although this message will be automatically disappeared after around 3 minutes, it will be reappeared

every time the power is turned ON.

(*2) • Lamps have a finite product life. Lamps are characterized by the fact that, after long hours of usage, a lamp will no
longer light up, or the lamp will break or burst, etc. This unit is equipped with an automatic shut-down function, such that
the power will automatically be turned OFF when lamp usage time has reached 2,000 hours. Please be aware, however,
that among lamp types, there are major differences in product lifetimes; a lamp may thus fail to light even prior to the

functioning of the automatic shut-down function of this unit.

36

Troubleshooting (continued)

Related Messages

Message Description

CLEAN THE AIR FILTER

POWER OFF FIRST,

THEN CLEAN THE AIR FILTER.

AFTER CLEANING THE AIR

RESET THE FILTER TIMER.

ATTENTION • The transparent area of filter cover and the dust-detecting window
should be cleaned for normal operation of the optical dust detecting system. Please
pay attention not to remain fiber or fragment of cloth inside the duct.

1

2

FILTER,

Turn off the projector, and unplug the
power cord.

After making sure that the projector
has cooled adequately, remove the

(continued)

A note of precaution when cleaning the air filter.
Please immediately turn the power OFF, and clean or change
the air filter by referring to the “Air Filter” section of this manual.
After you have cleaned or changed the air filter, please be sure
to reset the filter timer.
If the same message is displayed after the treatment, please
clean the transparent area of filter cover and the dust-detecting
window, according to the following.

Filter cover

filter cover.

Hold the release buttons of the filter cover, while
pulling up it.

Wipe the transparent area of the filter

3

cover by using a swab or a soft cloth.

Release buttons

Filter cover

Remove the air filter.

4

Hold the release buttons of the air filter, while pulling
down it.

Wipe the dust-detecting window by

5

using a soft cloth.

Replace the air filter and filter cover.

6

Transparent area

Release buttons

Air filter

Dust detecting window

(Rear side)

(Bottom side)

37

Troubleshooting (continued)

Regarding The Indicator Lamps

ATTENTION • When the interior portion has become overheated, or when the lamp
cover has not been properly fixed (attached), for safety purposes, the power source
may be automatically turned off, and the indicator lamps may also be turned off. In
such a case, press the “○” (OFF) side of the power switch, and wait at least 45
minutes. After the unit has sufficiently cooled down, please make confirmation of the
attachment state of the lamp and lamp cover, and then turn the power on again.

Lighting and flashing of the POWER indicator, the LAMP indicator, and the TEMP indicator
have the meanings as described in the table below. Please respond in accordance with the
instructions within the table. If the same indication is displayed after the treatment, or if an
indication other than the following is displayed, please contact your dealer or service
company.

POWER

indicator

Lighting in

orange

Flashing in

green

Lighting in

green

Flashing in

orange

Blinking in

red

Lighting or

blinking in

red

LAMP

indicator

Turned off Turned off

Turned off Turned off The unit is warming up. Please wait.

Turned off Turned off

Turned off Turned off The unit is cooling down. Please wait.

- -

Lighting in

red

TEMP

indicator

Turned off

Description

The unit is in a standby state. Please refer to the “Power
ON/OFF” section of this manual.

The unit is in an ON state. Ordinary operations may be
performed.

The unit is cooling down. A certain error has been detected.
Wait until the POWER indicator has finished flashing, and then
perform the proper response measure using the item
descriptions below as reference.

The projector lamp does not light, and/or there is a possibility
that the interior portion has become heated. Turn the power
OFF and wait at least 20 minutes. After the unit has sufficiently
cooled down, please make confirmation of the following items,
and then turn the power ON again. If the same indication is
displayed, please change the lamp.

• Is there blockage of the air passage aperture?

• Is the air filter is dirty?

• Does the peripheral temperature exceed 35°C?

38

Troubleshooting (continued)

Regarding The Indicator Lamps

POWER

indicator

Lighting or

blinking in

red

Lighting or

blinking in

red

Lighting in

green

Lighting in

green

LAMP

indicator

Turned off

Turned off

TEMP

indicator

Blinking in

red

Lighting in

red

Alternative blinking in

the red

Simultaneous blinking

in red

The cooling fan is not operating. Turn the power OFF and wait
at least 20 minutes. After the unit has sufficiently cooled down,
please make confirmation of the following item, and then
resent the power to ON.

• Is there no foreign matter caught in the cooling fan?

There is a possibility that the interior portion has become
heated. Turn the power OFF and wait at least 20 minutes.
After the unit has sufficiently cooled down, please make
confirmation of the following item, and then resent the power
to ON.

• Is there blockage of the air passage aperture?

• Is the air filter is dirty?

• Does the peripheral temperature exceed 35°C?

There is a possibility that the interior portion has become
overcooled. Please use the unit within the usage temperature
parameters (0°C to 35°C). After the treatment, resent the
power to ON.

It is time to clean the air filter, or there is no air filter. Please
immediately turn the power OFF, and clean or change the air
filter by referring to the “Air Filter” section of this manual. After
you have cleaned or changed the air filter, please be sure to
reset the filter timer. After the treatment, resent the power to
ON.

(continued)

Description

39

Troubleshooting (continued)

Phenomena That May Easily Be Mistaken For Machine Defects

WARNING • Please carefully read the “User’s Manual - Safety Guide”.

Never use the projector if abnormal operations such as smoke, strange odor, excessive
sound, damaged casing or elements or cables, penetration of liquids or foreign matter,
etc. should occur.

NOTE

• Although bright spots or dark spots may appear on the screen, this is a

unique characteristic of liquid crystal displays, and such do not constitute or imply a

machine defect.

Before requesting repair, please check in accordance with the following chart. If the
situation cannot be corrected, then contact your dealer.

Phenomenon

Power does not
come ON.

Neither sounds
nor pictures are
outputted.

Pictures are
displayed,
but no sounds
are heard.

Sounds are
heard,
but no pictures
are displayed.

Cases not involving a machine defect,

and Items to be confirmed

The main power source is not ON.

Turn on the main power.

The electrical power cord is not plugged in.

Correctly connect the power cord.

The main power source has been interrupted during operation,
such as by a power outage (blackout), etc.

Be sure to press the “○” (power OFF) side of the main power switch,
and leave this OFF for at least 20 minutes. After the unit has
sufficiently cooled down, turn ON the power source.

The lamp has not been properly fixed.

Turn the power OFF and wait at least 45 minutes. After the unit has
sufficiently cooled down, please make confirmation of the attachment
state of the lamp and lamp cover, and then turn the power ON again.

The input changeover settings are mismatched.

Select the input signal, and correct the settings.

No signal is being inputted.

Correctly connect the connection cables.

The electrical wiring to this unit is not correctly connected.

Correctly connect the connection cables.

The volume setting has been set at (or adjusted to) an
extremely low level.

Adjust the VOLUME setting to a higher level.

The MUTE mode is the current setting.

Press the MUTE button to release (change) the MUTE mode setting.

The electrical wiring to this unit is not correctly connected.

Correctly connect the connection cables.

The brightness setting has been set at (or adjusted to) an
extremely low level.

Adjust the BRIGHT setting to a brighter level.

The lens cap has not been removed.

Remove the lens cap.

Reference

pages

11,14

14

32

15

10

10

17

17

10

22

4,14

40

Troubleshooting (continued)

Phenomena That May Easily Be Mistaken For Machine Defects

Phenomenon

Colors have a
faded- out
appearance, or
Color tone is poor.

Pictures appear
dark.

Pictures appear
blurry.

Color settings are not correctly adjusted.

Perform picture adjustments by changing the COLOR BAL R,
COLOR BAL G, COLOR BAL B, COLOR, and/or the TINT settings,
etc.

The brightness setting and/or contrast setting has not been
properly adjusted.

Perform picture adjustments by changing the BRIGHT and/or
CONTRAST settings, etc.

The WHISPER mode is the current setting.

Change (by releasing) from the WHISPER mode.

Lamp is approaching the end of its product lifetime.

Exchange the old lamp with a new lamp.

Either the FOCUS setting or the H PHASE is not properly
adjusted.

Adjust the focus and the H PHASE setting.

The lens is dirty or misty.

Clean the lens.

Cases not involving a machine defect,

and Items to be confirmed

(continued)

Reference

pages

23

22

31,32

15,25

35

Warranty And After-Service

If a problem occurs with the equipment, first refer to the “Troubleshooting” section of this
manual, and run through the suggested checks. If this does not resolve the problem
contact your dealer or service company. They will tell you what warranty condition is
applied.

41

Specifications

Item Specification

Product name Liquid crystal projector

Liquid
crystal
panel

Lens Zoom lens F=1.6 ~ 2.8 f=14.2 ~ 28.4 mm
Lamp 130W UHB
Speaker 1.0W
Power supply AC100 ~ 120V, 2.4A / AC220 ~ 240V, 1.1A
Power consumption 220W
Temperature range 0 ~ 35°C (Operating)
Size 350 (W) x 121 (H) x 285 (D) mm (Not including protruding parts)
Weight (mass) 3.6 kg

Ports

Optional Parts

Panel size 1.4 cm (0.55 type)
Drive system TFT active matrix
Pixels 409,920 pixels (854 horizontal x 480 vertical)

RGB Input Ports

COMPUTER....................1

VIDEO Input Ports

VIDEO ............................1

S-VIDEO ........................1

AUDIO Ports

AUDIO ............................1

AUDIO R, L.....................1

CONTROL Ports

CONTROL ....................1

COMPONENT VIDEO

(CR/PR, CB/PB, Y) ............1

Lamp: DT00611 Air Filter: NJ08312
For others, consult your dealer.

42

NOTE

• This specifications are subject to change without notice.

350

285

95

51

140

89

121

TECHNICAL

1

2

4

3

TECHNICAL

Signal Connectors

VIDEO

2

AUDIO

COMPUTER

1

11 12 13 14 15

12345

AUDIO

2

(interlocked port)

CONTROL

3

54321

VIDEO

4

AUDIO L, R
(interlocked

// )

COMPONENT VIDEO

Y, C

87

R/PR

C

9

S-VIDEO

10

L-AUDIO-R

6

10

S-VIDEO

4

5
8

7

Y

C

B/PB CR/PR

COMPONENT VIDEO

1

COMPUTER

9

Port Specification

Video signal: RGB separate, Analog, 0.7 Vp-p, 75 Ω terminator (positive)
H/V. sync. signal:TTL level (positive/negative)
Composite sync. signal: TTL level
D-sub 15-pin shrink jack

9876

9874

B/PB,

10

1

6789

65

10

No. Signal No. Signal No. Signal

1 Video input Red 6 Ground Red 11 ­2 Video input Green 7 Ground Green 12 SDA (DDC)

3 Video input Blue 8 Ground Blue 13
4 - 9 Ground 14 Vertical sync

5 Ground 10 - 15 SCL (DDC)

200 mVrms, 50 kΩ (max. 3.0 Vp-p), Stereo mini jack

D-sub 9-pin plug

No. Signal No. Signal No. Signal

1 - 4 - 7 RTS
2 RD 5 Ground 8 CTS
3 TD 6 - 9 -

1.0 Vp-p, 75 Ω terminator, RCA jack

200 mVrms, 50 kΩ (max. 3.0 Vp-p), RCA jack

Y signal: 1.0 Vp-p, 75 Ω terminator

B/PB signal: 0.7 Vp-p, 75 Ω terminator

C

/PR signal: 0.7 Vp-p, 75 Ω terminator

R

C

Mini Din 4-pin jack

No. Signal

Color signal: 0.286 Vp-p (NTSC, burst), 75 Ω terminator

1

Color signal: 0.300 Vp-p (PAL/SECAM, burst), 75 Ω terminator
2 Brightness signal: 1.0 Vp-p, 75 Ω terminator
3 Ground
4 Ground

3

CONTROL

H. sync./Composite

sync.

1

Example Of Computer Signal

NOTE

Resolution

H ××V

720 × 400
640 × 480
640 × 480
640 × 480
640 × 480
640 × 480
800 × 600
800 × 600
800 × 600
800 × 600
800 × 600
832 × 624

848 x 480 29.8 60.0 VESA W VGA (60Hz)
1024 × 768
1024 × 768
1024 × 768
1280 × 960

1280 × 1024

• Some computers may have multiple display screen modes. Use of some

fH (kHz) fV (Hz) Rating Signal mode

37.9 85.0 VESA TEXT

31.5 59.9 VESA VGA (60Hz)

35.0 66.7 Mac13"mode

37.9 72.8 VESA VGA (72Hz)

37.5 75.0 VESA VGA (75Hz)

43.3 85.0 VESA VGA (85Hz)

35.2 56.3 VESA SVGA (56Hz)

37.9 60.3 VESA SVGA (60Hz)

48.1 72.2 VESA SVGA (72Hz)

46.9 75.0 VESA SVGA (75Hz)

53.7 85.1 VESA SVGA (85Hz)

49.7 74.5 Mac16"mode

48.4 60.0 VESA XGA (60Hz)

56.5 70.1 VESA XGA (70Hz)

60.0 75.0 VESA XGA (75Hz)

60.0 60.0 VESA SXGA (60Hz)

64.0 60.0 VESA SXGA (60Hz)

of these modes will not be possible with this projector.

• Be sure to check jack type, signal level, timing and resolution before connecting this

projector to a computer.

• Depending on the input signal, full-size display may not be possible in some cases.

Refer to the number of display pixels above.

• Although the projector can display signals with resolution up to UXGA (1,600 x

1,200), the signal will be converted to the projector’s panel resolution before being
displayed. The best display performance will be achieved if the resolutions of the
input signal and projector panel are identical.

• The image may not be displayed correctly when the input sync. signal is “Composite

Sync.” or “Sync. on G”.

• Automatically adjustment may not function correctly with some input signals.

• When the image resolution is changed on a computer, depending on an input,

automatic adjust function may take some time and may not be completed. In this
case, you may not be able to see a check box to select “Yes/No” for the new
resolution on Windows. Then the resolution will go back to the original. It might be
recommended to use other CRT or TFT monitors to change the resolution.

2

Initial Set Signals

DATA

HSYNC

DATA

VSYNC

The following signals are used for the initial settings.
The signal timing of some computer models may be different. In such case, refer to
adjust the V.POSIT and H.POSIT of the menu.

Back porch b

Front porch d

Display interval c

Sync a

Computer /

Signal

Horizontal signal timing (µs)

a b c d

TEXT 2.0 3.0 20.3 1.0

VGA (60Hz) 3.8 1.9 25.4 0.6

Mac 13"mode 2.1 3.2 21.2 2.1

VGA (72Hz) 1.3 3.8 20.3 1.0
VGA (75Hz) 2.0 3.8 20.3 0.5

VGA (85Hz) 1.6 2.2 17.8 1.6
SVGA (56Hz) 2.0 3.6 22.2 0.7
SVGA (60Hz) 3.2 2.2 20.0 1.0
SVGA (72Hz) 2.4 1.3 16.0 1.1
SVGA (75Hz) 1.6 3.2 16.2 0.3
SVGA (85Hz) 1.1 2.7 14.2 0.6

Mac 16"mode 1.1 3.9 14.5 0.6

848 x 480 (60Hz) 2.8 3.3 26.9 0.5

XGA (60Hz) 2.1 2.5 15.8 0.4

XGA (70Hz) 1.8 1.9 13.7 0.3

XGA (75Hz) 1.2 2.2 13.0 0.2

1280×960 (60Hz)
1280×1024 (60Hz)

1.0 2.9 11.9 0.9

1.0 2.3 11.9 0.4

Back porch b

Front porch d

Display interval c

Sync a

Computer /

Signal

Vertical signal timimg (lines)

a b c d

TEXT 3 42 400 1

VGA (60Hz) 2 33 480 10

Mac 13"mode 3 39 480 3

VGA (72Hz) 3 28 480 9
VGA (75Hz) 3 16 480 1

VGA (85Hz) 3 25 480 1
SVGA (56Hz) 2 22 600 1
SVGA (60Hz) 4 23 600 1
SVGA (72Hz) 6 23 600 37
SVGA (75Hz) 3 21 600 1
SVGA (85Hz) 3 27 600 1
Mac 16"mode 3 39 624 1

848 x 480 (60Hz) 3 13 480 1

XGA (60Hz) 6 29 768 3

XGA (70Hz) 6 29 768 3

XGA (75Hz) 3 28 768 1

1280×960 (60Hz)
1280×1024 (60Hz)

3 36 960 1
3 38 1024 1

3

RS-232C Communication

1
2
3
4
5
6
7
8
9

RD
TD

GND

CTS

RTS

1
2
3
4
5
6
7
8
9

CD
RD
TD
DTR
GND
DSR
RTS
DTS
RI

6789

54321

9876

12345

6789

54321

9876

12345

Connecting The Cable

(1)

Turn off the projector and the computer power supplies.

(2) Connect the CONTROL port of the projector with a RS-232C port of the computer by a RS-

232C cable. Use the cable that fulfills the specification shown in the following figure.

(3) Turn on the computer power supply and after the computer has started up, turn on the

projector power supply.

Projector RS-232C cross cable Computer

CONTROL

port

⇔⇔

D-sub 9-pin

plug

Communications Setting

19200bps, 8N1

1. Protocol

Consist of header (7 bytes) + command data (6 bytes).

2. Header

BE + EF + 03 + 06 + 00 + CRC_low + CRC_high
CRC_low : Lower byte of CRC flag for command data
CRC_high : Upper byte of CRC flag for command data

3 Command data

Command Data Chart

byte_0 byte_1 byte_2 byte_3 byte_4 byte_5

Action Type Setting code

low high low high low high

D-sub 9-pin

jack

D-sub 9-pin

jack

RS-232C port

D-sub 9-pin

plug

Action (byte_0 - 1)

4

Action Classification Content

1 SET Change setting to desired value.
2 GET Read projector internal setup value.
4 INCREMENT Increment setup value by 1.
5 DECREMENT Decrement setup value by 1.
6 EXECUTE Run a command.

RS-232C Communication

(continued)

Requesting projector status (Get command)

(1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2
bytes)+‘00H’+‘00H’) from the computer to the projector.
(2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.

Changing the projector settings (Set command)

(1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) +
setting code (2 bytes)) from the computer to the projector.
(2) The projector changes the setting based on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.

Using the projector default settings (Reset Command)

(1) The computer sends the default setting code Header + Command data (‘06H’+‘00H’+
type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector changes the specified setting to the default value.
(3) The projector returns the response code ‘06H’ to the computer.

Increasing the projector setting value (Increment command)

(1) The computer sends the increment code Header + Command data (‘04H’+‘00H’+
type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector in creases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.

Decreasing the projector setting value (Decrement command)

(1) The computer sends the decrement code Header + Command data (‘05H’+‘00H’+
type (2 bytes) +‘00H’ + ‘00H’) to the projector.
(2) The projector decreases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.

When the projector cannot understand the received command

When the projector cannot understand the received command, the error code ‘15H’ is
sent back to the computer.
Sometimes the projector cannot properly receive the command. In such a case, the
command is not executed and the error code ‘15H’ is sent back to the computer. If this
error code is returned, send the same command again.

When the projector cannot execute the received command.

When the projector cannot execute the received command, the error code ‘1cH’ +
‘xxxxH’ is sent back to the computer. When the data length is greater than indicated by
the data length code, the projector ignore the excess data code.
Conversely when the data length is shorter than indicated by the data length code, an
error code will be returned to the computer.

NOTE

undefined command or data.

• Operation cannot be guaranteed when the projector receives an

• Provide an interval of at least 40ms between the response code and any other code.

• The projector outputs test data when the power supply is switched ON, and when the

lamp is lit. Ignore this data.

• Commands are not accepted during warm-up.

5

RS-232C Communication

(continued)

Command Data Chart

Names Operation type Header

Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00

Keystone

Keystone Reset Execute BE EF 03 06 00 08 D0 06 00 0C 70 00 00

Brightness

Brightness Reset Execute BE EF 03 06 00 58 D3 06 00 00 70 00 00

Contrast

Contrast Reset Execute BE EF 03 06 00 A4 D2 06 00 01 70 00 00

Aspect

Whisper

Mirror

Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00

Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00

Get BE EF 03 06 00 89 D2 02 00 03 20 00 00

Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00

Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00

Get BE EF 03 06 00 FD D3 02 00 04 20 00 00

Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00

Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00

4:3 BE EF 03 06 00 9E D0 01 00 08 20 00 00
16:9 BE EF 03 06 00 0E D1 01 00 08 20 01 00
15:9 BE EF 03 06 00 6E D0 01 00 08 20 03 00

Set

Set

Set

32:15 BE EF 03 06 00 5E D2 01 00 08 20 04 00

WIDE BE EF 03 06 00 CE D3 01 00 08 20 05 00
MOVIE-1 BE EF 03 06 00 3E D3 01 00 08 20 06 00
MOVIE-2 BE EF 03 06 00 AE D2 01 00 08 20 07 00
Get BE EF 03 06 00 AD D0 02 00 08 20 00 00
NORMAL BE EF 03 06 00 3B 23 01 00 00 33 00 00

WHISPER BE EF 03 06 00 AB 22 01 00 00 33 01 00

Get BE EF 03 06 00 08 23 02 00 00 33 00 00

Normal BE EF 03 06 00 C7 D2 01 00 01 30 00 00
H Inverse BE EF 03 06 00 57 D3 01 00 01 30 01 00
V lnverse BE EF 03 06 00 A7 D3 01 00 01 30 02 00

H&V Inverse BE EF 03 06 00 37 D2 01 00 01 30 03 00

Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00

CRC Action Type Setting code

Command data

6

RS-232C Communication

(continued)

Command Data Chart

Names Operation type Header

English BE EF 03 06 00 F7 D3 01 00 05 30 00 00

FRANÇAIS

Deutsch BE EF 03 06 00 97 D2 01 00 05 30 02 00

ESPAÑOL BE EF 03 06 00 07 D3 01 00 05 30 03 00

Italiano BE EF 03 06 00 37 D1 01 00 05 30 04 00

Nederlands

Set

Language

Gamma

Custom Gamma

Custom

Color Temp

Custom User R

Custom User G

PORTUGUÊS

SVENSKA BE EF 03 06 00 C7 D4 01 00 05 30 0B 00

SUOMI BE EF 03 06 00 67 D7 01 00 05 30 0D 00

POLSKI BE EF 03 06 00 97 D7 01 00 05 30 0E 00

Get BE EF 03 06 00 C4 D3 02 00 05 30 00 00

NORMAL BE EF 03 06 00 C7 F0 01 00 A1 30 00 00

CINEMA BE EF 03 06 00 57 F1 01 00 A1 30 01 00

Set

DYNAMIC BE EF 03 06 00 A7 F1 01 00 A1 30 02 00

CUSTOM BE EF 03 06 00 07 FD 01 00 A1 30 10 00

Get BE EF 03 06 00 F4 F0 02 00 A1 30 00 00
Get BE EF 03 06 00 08 F1 02 00 A3 30 00 00

Increment BE EF 03 06 00 6E F1 04 00 A3 30 00 00

Decrement BE EF 03 06 00 BF F0 05 00 A3 30 00 00

Set

MIDDLE BE EF 03 06 00 9B F4 01 00 B0 30 02 00

Get BE EF 03 06 00 C8 F5 02 00 B0 30 00 00

Set

Get BE EF 03 06 00 34 F4 02 00 B1 30 00 00

Set

Get BE EF 03 06 00 70 F4 02 00 B2 30 00 00

(continued)

BE EF 03 06 00 67 D2 01 00 05 30 01 00

Norsk BE EF 03 06 00 A7 D0 01 00 05 30 05 00

BE EF 03 06 00 57 D0 01 00 05 30 06 00
BE EF 03 06 00 C7 D1 01 00 05 30 07 00

日本語

中文

USER BE EF 03 06 00 3B F8 01 00 B0 30 10 00

HIGH BE EF 03 06 00 0B F5 01 00 B0 30 03 00

LOW BE EF 03 06 00 6B F4 01 00 B0 30 01 00

50 BE EF 03 06 00 57 F7 01 00 B1 30 05 00
60 BE EF 03 06 00 C7 F6 01 00 B1 30 04 00
70 BE EF 03 06 00 F7 F4 01 00 B1 30 03 00

80 BE EF 03 06 00 67 F5 01 00 B1 30 02 00
90 BE EF 03 06 00 97 F5 01 00 B1 30 01 00

100 BE EF 03 06 00 07 F4 01 00 B1 30 00 00

50 BE EF 03 06 00 13 F7 01 00 B2 30 05 00
60 BE EF 03 06 00 83 F6 01 00 B2 30 04 00
70 BE EF 03 06 00 B3 F4 01 00 B2 30 03 00
80 BE EF 03 06 00 23 F5 01 00 B2 30 02 00
90 BE EF 03 06 00 D3 F5 01 00 B2 30 01 00

100 BE EF 03 06 00 43 F4 01 00 B2 30 00 00

BE EF 03 06 00 37 D4 01 00 05 30 08 00
BE EF 03 06 00 A7 D5 01 00 05 30 09 00
BE EF 03 06 00 57 D5 01 00 05 30 0A 00

BE EF 03 06 00 F7 D6 01 00 05 30 0C 00

Command data

CRC Action Type Setting code

7

RS-232C Communication

(continued)

Command Data Chart

Names Operation type Header

Custom User B

Color Balance R

Color Balance R

Reset

Color Balance G

Color Balance G

Reset

Color Balance B

Color Balance B

Reset

Sharpness

Sharpness Reset Execute BE EF 03 06 00 C4 D0 06 00 09 70 00 00

Color

Color Reset Execute BE EF 03 06 00 80 D0 06 00 0A 70 00 00

Tint

Tint Reset Execute BE EF 03 06 00 7C D1 06 00 0B 70 00 00

My Memory Load

My Memory Save

Set

Get BE EF 03 06 00 8C F5 02 00 B3 30 00 00

Get BE EF 03 06 00 01 D2 02 00 05 20 00 00

Increment BE EF 03 06 00 67 D2 04 00 05 20 00 00

Decrement BE EF 03 06 00 B6 D3 05 00 05 20 00 00

Execute BE EF 03 06 00 94 D3 06 00 05 70 00 00

Get BE EF 03 06 00 B5 D7 02 00 12 20 00 00

Increment BE EF 03 06 00 D3 D7 04 00 12 20 00 00

Decrement BE EF 03 06 00 02 D6 05 00 12 20 00 00

Execute BE EF 03 06 00 04 DB 06 00 29 70 00 00

Get BE EF 03 06 00 45 D2 02 00 06 20 00 00

Increment BE EF 03 06 00 23 D2 04 00 06 20 00 00

Decrement BE EF 03 06 00 F2 D3 05 00 06 20 00 00

Execute BE EF 03 06 00 D0 D3 06 00 06 70 00 00

Get BE EF 03 06 00 F1 72 02 00 01 22 00 00

Increment BE EF 03 06 00 97 72 04 00 01 22 00 00

Decrement BE EF 03 06 00 46 73 05 00 01 22 00 00

Get BE EF 03 06 00 B5 72 02 00 02 22 00 00

Increment BE EF 03 06 00 D3 72 04 00 02 22 00 00

Decrement BE EF 03 06 00 02 73 05 00 02 22 00 00

Get BE EF 03 06 00 49 73 02 00 03 22 00 00

Increment BE EF 03 06 00 2F 73 04 00 03 22 00 00

Decrement BE EF 03 06 00 FE 72 05 00 03 22 00 00

Set

Set

(continued)

Command data

CRC Action Type Setting code
50 BE EF 03 06 00 EF F6 01 00 B3 30 05 00
60 BE EF 03 06 00 7F F7 01 00 B3 30 04 00
70 BE EF 03 06 00 4F F5 01 00 B3 30 03 00
80 BE EF 03 06 00 DF F4 01 00 B3 30 02 00
90 BE EF 03 06 00 2F F4 01 00 B3 30 01 00

100 BE EF 03 06 00 BF F5 01 00 B3 30 00 00

1 BE EF 03 06 00 0E D7 01 00 14 20 00 00
2 BE EF 03 06 00 9E D6 01 00 14 20 00 01
3 BE EF 03 06 00 6E D6 01 00 14 20 02 00
4 BE EF 03 06 00 FE D7 01 00 14 20 03 00
1
2
3
4

BE EF 03 06 00 F2 D6 01 00 15 20 00 00
BE EF 03 06 00 62 D7 01 00 15 20 01 00
BE EF 03 06 00 92 D7 01 00 15 20 02 00
BE EF 03 06 00 02 D6 01 00 15 20 03 00

8

RS-232C Communication

(continued)

Command Data Chart

Names Operation type Header

Get BE EF 03 06 00 0D 83 02 00 00 21 00 00

V Position

V Position Reset Execute BE EF 03 06 00 E0 D2 06 00 02 70 00 00

H Position

H Position Reset Execute BE EF 03 06 00 1C D3 06 00 03 70 00 00

H Phase

H Size

H Size Reset Execute BE EF 03 06 00 68 D2 06 00 04 70 00 00

Over Scan

Over Scan Reset Execute BE EF 03 06 00 EC D9 06 00 27 70 00 00

Color Space

Component

Video Format

Frame Lock

3D-YCS

Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00

Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00

Get BE EF 03 06 00 F1 82 02 00 01 21 00 00

Increment BE EF 03 06 00 97 82 04 00 01 21 00 00

Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00

Get BE EF 03 06 00 49 83 02 00 03 21 00 00

Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00

Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00

Get BE EF 03 06 00 B5 82 02 00 02 21 00 00

Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00

Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00

Get BE EF 03 06 00 91 70 02 00 09 22 00 00

Increment BE EF 03 06 00 F7 70 04 00 09 22 00 00

Decrement BE EF 03 06 00 26 71 05 00 09 22 00 00

Set

SMPTE240 BE EF 03 06 00 6E 73 01 00 04 22 02 00

REC709 BE EF 03 06 00 FE 72 01 00 04 22 03 00
REC601 BE EF 03 06 00 CE 70 01 00 04 22 04 00

Get BE EF 03 06 00 3D 72 02 00 04 22 00 00

COMPONENT BE EF 03 06 00 4A D7 01 00 17 20 00 00

Set

SCART RGB BE EF 03 06 00 DA D6 01 00 17 20 01 00

Get BE EF 03 06 00 79 D7 02 00 17 20 00 00

SECAM BE EF 03 06 00 6E 75 01 00 00 22 09 00

Set

NTSC 4.43 BE EF 03 06 00 5E 72 01 00 00 22 02 00

M-PAL BE EF 03 06 00 FE 74 01 00 00 22 08 00

Get BE EF 03 06 00 0D 73 02 00 00 22 00 00

TURN OFF BE EF 03 06 00 CB D6 01 00 14 30 00 00

Set

TURN ON BE EF 03 06 00 5B D7 01 00 14 30 01 00

Get BE EF 03 06 00 F8 D6 02 00 14 30 00 00

TURN OFF BE EF 03 06 00 E6 70 01 00 0A 22 00 00

Set

NORMAL BE EF 03 06 00 76 71 01 00 0A 22 01 00

STILL IMAGE BE EF 03 06 00 86 71 01 00 0A 22 02 00

Get BE EF 03 06 00 D5 70 02 00 0A 22 00 00

(continued)

Command data

CRC Action Type Setting code

AUTO BE EF 03 06 00 0E 72 01 00 04 22 00 00

RGB BE EF 03 06 00 9E 73 01 00 04 22 01 00

AUTO BE EF 03 06 00 9E 75 01 00 00 22 0A 00

NTSC BE EF 03 06 00 FE 71 01 00 00 22 04 00

PAL BE EF 03 06 00 6E 70 01 00 00 22 05 00

N-PAL BE EF 03 06 00 0E 71 01 00 00 22 07 00

9

RS-232C Communication

(continued)

Command Data Chart

Names Operation type Header

Set

Video NR

Progressive

S2-Aspect

Auto Adjust Execute BE EF 03 06 00 91 D0 06 00 0A 20 00 00

Auto off

Auto Search

Blank Color

Blank on/off

Startup

Menu Position V

Menu Position V

Reset

Menu Position H

Menu Position H

Reset

Message

MIDDLE BE EF 03 06 00 D6 72 01 00 06 22 02 00

Get BE EF 03 06 00 85 73 02 00 06 22 00 00

Turn off BE EF 03 06 00 4A 72 01 00 07 22 00 00

Set

Get BE EF 03 06 00 79 72 02 00 07 22 00 00

TURN OFF BE EF 03 06 00 1A 71 01 00 0B 22 00 00

Set

TURN ON BE EF 03 06 00 8A 70 01 00 0B 22 01 00

Get BE EF 03 06 00 29 71 01 00 0B 22 00 00

Get BE EF 03 06 00 08 86 02 00 10 31 00 00

Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00

Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00

TURN OFF BE EF 03 06 00 B6 D6 01 00 16 20 00 00

Set

TURN ON BE EF 03 06 00 26 D7 01 00 16 20 01 00

Get BE EF 03 06 00 85 D6 02 00 16 20 00 00

Set

Get BE EF 03 06 00 08 D3 02 00 00 30 00 00

TURN OFF BE EF 03 06 00 FB D8 01 00 20 30 00 00

Set

TURN ON BE EF 03 06 00 6B D9 01 00 20 30 01 00

Get BE EF 03 06 00 C8 D8 02 00 20 30 00 00

TURN ON BE EF 03 06 00 0B D2 01 00 04 30 00 00

Set

TURN OFF BE EF 03 06 00 9B D3 01 00 04 30 01 00

Get BE EF 03 06 00 38 D2 02 00 04 30 00 00
Get BE EF 03 06 00 40 D7 02 00 16 30 00 00

Increment BE EF 03 06 00 26 D7 04 00 16 30 00 00

Decrement BE EF 03 06 00 F7 D6 05 00 16 30 00 00

Execute BE EF 03 06 00 A8 C7 06 00 44 70 00 00

Get BE EF 03 06 00 04 D7 02 00 15 30 00 00

Increment BE EF 03 06 00 62 D7 04 00 15 30 00 00

Decrement BE EF 03 06 00 B3 D6 05 00 15 30 00 00

Execute BE EF 03 06 00 DC C6 06 00 43 70 00 00

TURN OFF BE EF 03 06 00 8F D6 01 00 17 30 00 00

Set

TURN ON BE EF 03 06 00 1F D7 01 00 17 30 01 00

Get BE EF 03 06 00 BC D6 02 00 17 30 00 00

(continued)

Command data

CRC Action Type Setting code

LOW BE EF 03 06 00 26 72 01 00 06 22 01 00

HIGH BE EF 03 06 00 46 73 01 00 06 22 03 00

TV BE EF 03 06 00 DA 73 01 00 07 22 01 00

Film BE EF 03 06 00 2A 73 01 00 07 22 02 00

Blue BE EF 03 06 00 CB D3 01 00 00 30 03 00
White BE EF 03 06 00 6B D0 01 00 00 30 05 00
Black BE EF 03 06 00 9B D0 01 00 00 30 06 00

10

RS-232C Communication

(continued)

Command Data Chart

Names Operation type Header

Get BE EF 03 06 00 31 D3 02 00 01 20 00 00

Volume

MUTE

Lamp Time Get BE EF 03 06 00 C2 FF 02 00 90 10 00 00

Lamp Time Reset Execute BE EF 03 06 00 58 DC 06 00 30 70 00 00

Filter Time Get BE EF 03 06 00 C2 F0 02 00 A0 10 00 00

Filter Time Reset Execute BE EF 03 06 00 98 C6 06 00 40 70 00 00

Magnify

Freeze

Power

Input Source

Increment BE EF 03 06 00 57 D3 04 00 01 20 00 00

Decrement BE EF 03 06 00 86 D2 05 00 01 20 00 00

TURN ON BE EF 03 06 00 46 D3 01 00 02 20 00 00

Set

TURN OFF BE EF 03 06 00 D6 D2 01 00 02 20 01 00

Get BE EF 03 06 00 75 D3 02 00 02 20 00 00

Get BE EF 03 06 00 7C D2 02 00 07 30 00 00

Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00

Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00

Set

Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00

TURN OFF BE EF 03 06 00 2A D3 01 00 00 60 00 00

Set

TURN ON BE EF 03 06 00 BA D2 01 00 00 60 01 00

Get

COMPUTER BE EF 03 06 00 FE D2 01 00 00 20 00 00

Set

S-Video BE EF 03 06 00 9E D3 01 00 00 20 02 00

Component BE EF 03 06 00 AE D1 01 00 00 20 05 00

Get BE EF 03 06 00 CD D2 02 00 00 20 00 00

(continued)

Command data

CRC Action Type Setting code

Normal BE EF 03 06 00 83 D2 01 00 02 30 00 00
Freeze BE EF 03 06 00 13 D3 01 00 02 30 01 00

BE EF 03 06 00 19 D3 02 00 00 60 00 00

(Example Return)

00 00 01 00 02 00
(Off) (On) (Cool down)

Video BE EF 03 06 00 6E D3 01 00 00 20 01 00

BE EF 03 06 00 D9 D8 02 00 20 60 00 00

Error Status Get

(Example of Return)

00 00 01 00 02 00 03 00

(Normal) (Cover-error) (Fan-error) (Lamp-error)

04 00 05 00 06 00 07 00 08 00 09 00

(Temp-error) (Air flow- (Lamp- (Cool-error) (Filter-Error) (Filter-

error) Time-over) Missing)

11
