Hitachi Power Tools

ELECTRIC TOOL PARTS LIST

LIST NO. E104

IMPACT DRILL
Model DV 16V

1

17

18

19

2

3

20

21

2003 • 12 •10

(E1)

3

4

5

6

7

8

9

10

11

12

13

14

15

16

22

23

24

31

32

501

502

33

34

35

36

37

38

39

40

41

25

26

27

28

29

30

42

43

503

PARTS

ITEM

CODE NO.

NO.

1 995-344

DESCRIPTION REMARKS

FLAT HD. SCREW (A) (LEFT HAND) M6X25

2 987-576 CHUCK WRENCH FOR 13VLB-D,13VLR-D 1

* 3 322-357

DRILL CHUCK 13VLRH-N (W/O CHUCK WRENCH)

* 3 DRILL CHUCK 13VLRB-D 1

4 948-001 RETAINING RING FOR D32 HOLE 1
5 971-654 DUST SEAL 1
6 322-515 DISTANCE RING 1
7 322-513 SPINDLE 1
8 322-514 SPRING 1

9 600-2VV BALL BEARING 6002VVCMPS2L 1
10 306-664 TAPPING SCREW (W/FLANGE) D4X40 2
11 939-544

RETAINING RING FOR D15 SHAFT (10 PCS.)
12 322-516 TAPPING SCREW (W/FLANGE) D4X55 2
13 322-512 GEAR COVER 1
14 322-511 NEEDLE (B) 1
15 317-482 GEAR 1
16 959-150 STEEL BALL D6.35 (10 PCS.) 1
17 322-509 INNER COVER 1
18 608-DDM BALL BEARING 608DDC2PS2L 1
19 322-510 CHANGE LEVER 1

* 20 360-626C ARMATURE 110V 1
* 20 360-626U ARMATURE ASS’Y 120V 1 INCLUD. 18, 24
* 20 360-626E ARMATURE 220V-240V 1

21 322-508 FAN GUIDE 1
22 950-515 TAPPING SCREW D4X50 2

* 23 340-573C STATOR 110V 1
* 23 340-573D STATOR 120V 1
* 23 340-573E STATOR 220V-230V 1
* 23 340-573F STATOR 240V 1

24 608-VVM BALL BEARING 608VVC2PS2L 1
25 321-622 HOUSING 1
26 NAME PLATE 1

* 27 322-517 CHOKE COIL (BROWN) 220V-240V 1 EXCEPT FOR USA, CAN
* 27 322-518 CHOKE COIL (BROWN) 110V 1 FOR GBR (110V)
* 28 321-630 INTERNAL WIRE (BROWN) 100L 1 FOR USA, CAN
* 29 321-634 CHOKE COIL (BLUE) 110V-240V 1 EXCEPT FOR USA, CAN
* 29 322-519 CHOKE COIL (BLUE) 110V 1 FOR GBR (110V)
* 30 321-631 INTERNAL WIRE (BLUE) 55L 1 FOR USA, CAN

31 301-653

TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 3

32 321-629 HANDLE COVER 1
33 321-632 SWITCH (1P PILLAR TYPE) 1
34 321-628 PUSHING BUTTON 1
35 999-041 CARBON BRUSH (1 PAIR) 2
36 955-203 BRUSH HOLDER 2
37 HITACHI LABEL 1

* 38 994-273 NOISE SUPPRESSOR 1 EXCEPT FOR USA, CAN
* 39 992-635 EARTH TERMINAL 1 FOR NOISE SUPPRESSOR

40 984-750 TAPPING SCREW (W/FLANGE) D4X16 2
41 937-631 CORD CLIP 1
42 953-327 CORD ARMOR D8.8 1

* 43 500-247Z CORD 1 (CORD ARMOR D8.8)

--- 2 ---

ALTERNATIVE PARTS

*

NO.

USED

1

1

INCLUD. 2 SUPPLIED WITH ITEM NO.601

1

DV 16V

12 -- 03
