DVD PLAYER
MODEL
DV-P313U
INSTRUCTION
MANUAL
Manual de instrucciones
Para obtener el mejor funcionamiento y
asegurar años de uso libre de problemas, lea
cuidadosamente este manual de instrucciones.
Instruction manual
To obtain the best performance and ensure years of
trouble-free use, please read this instruction manual
completely.
Mode d'emploi
Des performances optimales et un fonctionnement à
long terme seront assurés en appliquant les
présentes instructions après avoir entièrement lu ce
mode d'emploi.
FRANÇAIS ESPAÑOLENGLISH
HITACHI AMERICA, LTD.
HOME ELECTRONICS DIVISION
1855 Dornoch Court,
San Diego, CA92154-7225
Tel : 1-800-HITACHI
(1-800-448-2244)
HITACHI CANADA LTD.
DIGITAL MEDIA DIVISION
6740 Campobello Road, Mississauga,
Ontario L5N 2L8 CANADA
Tel: 1-800-HITACHI
(1-800-448-2244)
during the business hours
Monday - Friday EST 9:00am~7:00pm
Saturday EST 9:00am~5:00pm
durant les heures de hureau :
Lundi au Vedredi 9:00am~7:00pm (h.n.e.)
Samedi 9:00am~5:00pm (h.n.e.)
Hitachi has made every effort to assure you hours of trouble free operation from your unit. However, should you
require service, a network of Hitachi Authorized Service Facilities has been established in all 50 states and
Puerto Rico. Each facility will provide you with convenient and expedient assistance. Our service "Hotline"
operator will direct you to the Hitachi Authorized Service Facility nearest you . Just present proof of purchase
and/or delivery receipts to the Hitachi Authorized Service Facility and service will be rendered in accordance with
the terms of the limited warranty as stated on your warranty card or operating guide.
Should you have any questions regarding in-warranty service, operation or technical assistance, please contact:
TP12451 © Hitachi, Ltd. 2001
Printed in KOREA 01-H（HE）
To locate an authorized
HITACHI service facility in
the continental U.S.A
DIAL TOLL FREE
7 days a week,24 hours a day
1-800-448-2244
HITACHI
800
HIT HITACHIACHI
800
CAUTIONS
Caution: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
This product satisfies FCC regulations when shielded cables and connectors are used to
connect the unit to other equipment. To prevent electromagnetic interference with electric
appliances, such as radios and televisions, use shielded cables and connectors for
connections.
FCC NOTE (for U.S.A):
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures.
･ Reorient or relocate the receiving antenna.
･ Increase the separation between the equipment and receiver.
･ Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
･ Consult the dealer or an experienced radio/TV technician for help.
This class B digital apparatus meets all requirements of the Canadian Interference -Causing Equipment Regulations.
2
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates “
danger-
ous voltage
” inside the product
that presents a risk of electric
shock or personal injury.
This symbol indicates important
instructions accompanying the
product.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: DVD PLAYERS USE AN INVISIBLE LASER BEAM WHICH CAN
CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED.
BE SURE TO OPERATE PLAYER CORRECTLY AS INSTRUCTED.
CLASS 1 LASER PRODUCT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
ENGLISH
Precautions
3
CAUTION
THIS PRODUCT UTILIZES A LASER.USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN
COVER AND DO NOT REPAIR YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
Notes:
･ This unit can be used only where the power supply is AC 120V, 60Hz. It cannot be
used elsewhere.
･ This DVD player is designed and manufactured to respond to the Region Management
Information. If the Region number of a DVD disc does not correspond to the Region
number of this DVD player, this DVD player cannot play the disc.
･ This device is protected by U.S.patent numbers 4,631,603 and 4,577,216 and
4,819,098 and other intellectual property rights.The use of Macrovision's copy
protection technology in the device must be authorized by Macrovision and is intended
for home and other limited pay-per-view uses only, unless otherwise authorized in
writing by Macrovision.Reverse engineering or disassembly is prohibited.
WARNING
To reduce the risk
of fire or shock
hazard, do not
expose this DVD
player to rain or
moisture.
･ Before connecting other components to this player, be sure to turn them all off.
･ Do not move the player while a disc is being played, or the disc may be scratched or
broken, and the player's internal parts may be damaged.
･ Do not install the player on top of a heat producing device. When installing in a cabinet,
place the player below the amplifier or any other heat producing audio devices, as far as
possible (but in a dust free spot).
･ Do not put a flower vase filled with water or any small metal objects on the player.
･ Be careful not to put your hand into the disc tray.
･ Do not place anything other than the disc in the disc tray.
･ Exterior interference such as lightning and static electricity can affect normal operation
of this player. If this occurs, turn the player off and on again with the POWER button, or
disconnect and then reconnect the AC power cord to the AC power outlet.The player will
operate normally.
･ Be sure to remove the disc and turn off the player after use.
･ Disconnect the AC power cord from the AC outlet when you don't intend to use the
player for long periods of time.
･ Clean the disc by wiping in a straight line from the inside to the outside of the disc.
Be careful not to harm the disc because the data on these discs is highly vulnerable to the
environment.
･ Do not keep under direct sunlight.
･ Keep in a cool ventilated area.
･ Store vertically.
･ Keep in a clean protection jacket.
For safety reasons, be sure to disconnect the AC power cord from the AC outlet.
･ Do not use benzene, thinner, or other solvents for cleaning.
･ Wipe the cabinet with a soft cloth.
Handling Cautions
Disc Storage
Maintenance of Cabinet
ENGLISH
Precautions
DV-P313U-E-P1-2101.4.1010:45AMページ3
4
IMPORTANT SAFEGUARDS
ENGLISH
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a damp cloth. Unplug this apparatus from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
7) Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or groundig-type plug. A polarized
plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong.The wide blade or the
third prong are provided for your safety. When the provided plug does
not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lighting storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped. When the apparatus exhibits a distinct change in performance - this
indicates a need for service.
INSTALLATION
In addition to the careful attention devoted to quality standards in the manufacture of your DVD player/CD
recorder safety is a major factor in the design of every instrument. But safety is your responsibility too.
This page lists important information that will help to assure your enjoyment and proper use of a DVD
player/CD recorder and accessory equipment. Please read it carefully before operating your DVD player/CD
recorder and keep it in a handy place for future reference.
DV-P313U-E-P1-2101.4.1010:45AMページ4
5
ENGLISH
CAUTION:
7 Object and Liquid Entry -
Never push objects of any kind into this DVD
player/CD recorder through opening as they
may touch dangerous voltage points or shortout parts that could result in a fire or electric
shock.Never spill liquid of any kind on the DVD
player/CD recorder.
8 Safety Check - Upon completion
of any service or repairs to this DVD player/CD
recorder, ask the service technician to perform
safety checks recommended by the
manufacturer to determine that the DVD
player/CD recorder is in safe operating
condition.
9 Replacement Parts - When
replacement parts are required, have the
service technician verify that the replacements
he uses have the same safety characteristics
as the original parts. Use of replacements
specified by the DVD player/CD recorder
manufacturer can prevent fire, electric shock
or other hazards.
1 Power Sources - This DVD
player/CD recorder should be operated only
from the type of power source indicated on
the marking label. If you are not sure of the
type of power supply to your home, consult
your dealer or local power company.
2 Overloading - Do not overload
wall outlets and extension cords as this can
result in a risk of fire or electric shock.
Overloaded AC outlets and extension
cords are dangerous, and
so are frayed power cords,
damaged or cracked wire
insulation and broken
plugs. They may result in
a shock or fire hazard.
Periodically examine the
cord and have it replaced
by your service technician if appearance
indicates damage or deteriorated
insulation.service technician if appearance
indicates damage or deteriorated insulation.
3 Ventilation - Slots and
openings in the cabinet are provided
for ventilation to ensure reliable
operation of the DVD player/CD recorder
and to protect it from overheating. These
openings must not be blocked or
covered. The openings should never be
blocked by placing the DVD player/CD
recorder on a bed, sofa, rug, or other
similar surface. This DVD player/CD
recorder should never be placed near or
over a radiator or heat register. This
DVD player/CD recorder should not be
placed in a built-in installation such as
a bookcase or rack unless proper
ventilation is provided or the DVD
player/CD recorder manufacturer's
instructions have been followed.
4 Attachments - Do not use
attachments unless recommended by the
DVD player/CD recorder manufacturer as
they may cause hazards.
Caution: Maintain electr ical safety. Powerline
operated equipment or accessories
connected to this unit should bear the UL
listing mark or CSA certification mark on the
accessory itself and should not have been
modified so as to defeat the safety features.
This will help avoid any potential hazard from
electric shock or fire. If in doubt, contact
qualified service personnel.
5 Water and Moisture - Do not
use this DVD player/CD recorder near water.
For example, near a bath tub, wash bowl,
kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool, and the
like.
6 Accessories - Do not place this
DVD player /CD recorder on an unstable cart,
stand, tripod, bracket, or table. The DVD
player/CD recorder may fall, causing serious
injury to a child or adult, and serious damage
to the appliance. Use only with a cart, stand,
tripod, bracket, or table recommended by the
menufacturer, or sold with the DVD player/CD
recorder. Any mounting of the product should
follow the manufacturer's instructions, and
should use a mounting accessory
recommended by the manufacturer.
6A An appliance and car t combination
should be moved
with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and
cart combination to overturn.
DV-P313U-E-P1-2101.4.1010:45AMページ5
1
Open the battery cover
on the back of the
remote.
2
Insert two AA batteries.
Make sure that the
polarities (+ and -) are
aligned correctly.
3
Replace the battery
cover.
･ Check the polarity + - of the
batteries (Dry-Cell)
･ Check if the batteries are
drained.
･ Check if remote sensor is
blocked by obstacles.
･ Check if there is any
fluorescent lighting nearby.
Accessories
Remote Control
Batteries for
Remote Control
(AA Size)
Video/Audio Cable
Install Batteries in the
Remote
If remote doesn't operate
properly:
6
ENGLISH
Before You Start
Formation of condensation
Due to sharp changes in temperature and humidity, condensation may form if warm air
comes in contact with any cold parts inside the player.
･ When condensation forms inside the player, the player may not operate correctly. If this
occurs, leave the player at room temperature until the inside of the player becomes dry
and operational.
･ If condensation forms on a disc, wipe the disc with a soft and dry cloth by moving the cloth
from the center hole toward the outer edge.
DV-P313U-E-P1-2101.4.1010:45AMページ6
SETUP
CONNEC
TIONS
BASIC
FUNCTIONS
ADVANCED
FUNCTIONS
CHANGING
SETUP MENU
REFERENCE
7
Choosing a Connection
..................
........
21
･ Connection to an Audio System
...........
21
･ Connection to a TV
...............................
22
Playing a Disc
.........................................
23
Using the Search and Skip Functions
..........
25
Using Menu Screen on Disc for Playback
.......
26
Using Top Menu Screen on Disc to Play DVD
.....
27
Using the Display Function
....................
28
Repeat Playback
.....................................
29
Program Playback and Random Playback
..........
30
Using the Disc View Function
...............
31
Selecting the Audio Language
..............
32
Selecting the Subtitle Language
...........
33
Changing the Camera Angle
.................
34
Using the Bookmark Function
...............
35
Using the Zoom and 3D Sound Functions
....
36
Using the Setup Menu
.........................
37
Setting Up the Language Features
........
38
Setting Up the Parental Control
............
40
Setting Up the Audio Options
................
41
Setting Up the Display Options
..............
42
Troubleshooting Guide
.........................
44 Specifications
.....................................
45
Try to Play Disc Immediately
.....................
8
Identifying Menu Screen
..........................
10
General Features
....................................
12
Disc Type and Characteristics
................
13
Description
.............................................
14
･ Front Panel
............
.................
.............
14
･ Front Panel Display
..............................
15
･Tour of the Remote Contro
......
...
..........
.
16
･ Rear Panel
...........................................
.
20
ENGLISH
Table of Contents
DV-P313U-E-P1-2101.4.1010:45AMページ7
8
ENGLISH
Video/Audio Cable
COMPONENT VIDEO OUT
YPr
Pb
VIDEO OUT S-VIDEO OUT
MIXED AUDIO OUT
RL
OPTICAL COAXIAL
DIGITAL AUDIO OUT
S-VIDEO
Y,Pb ,Pr
VIDEO OUT
SELECT
AUDIOINVIDEO
RL
Connection to a TV
Try to Play Disc Immediately
DV-P313U-E-P1-2101.4.1010:45AMページ8
9
SETUP
ENGLISH
To Play
1
1
Press the POWER
button.
2
2
Press the
OPEN/CLOSE button.
･ The TRAY will come out.
3
3
Place a disc.
･ Place the disc along the guides with
the label side up.
4
4
Press the PLAY/PAUSE
button.
･ Playback will begin.
To terminate
1
1
Press the STOP button.
･ The playback will terminate.
2
2
Press the
OPEN/CLOSE button.
･ The TRAY will come out.
3
3
Take out the disc.
4
4
Press the POWER
button.
･ The tray will close and the power
will be off
.
POWER/STANDBY
POWER/STANDBY
or
or
or
or
or
or
Try to Play Disc Immediately
DV-P313U-E-P1-2101.4.1010:45AMページ9
10
ENGLISH
ENTER
RETURN
ENTER
RETURN
ENTER
RETURN
ENTER
RETURN
ENTER
RETURN
1 Player Menu English
2 Disc Menu English
3 Audio English
4 Subtitle Automatic
5 Parental Unlocked
6 Audio Options
7 Display Options
Set a disc (DVD, VCD or CD), and press the STOP button to set the player
to the stop mode.Then press the SETUP button on remote control.
Identifying Menu Screens
SETUP MENU
PLAYER MENU LANGUAGE
1 English
2 Français
3 Deutsch
4 Español
5 Italiano
6 Nederlands
DISC MENU LANGUAGE
1 English
2 Français
3 Deutsch
4 Español
5 Italiano
6 Nederlands
7 Others
AUDIO LANGUAGE
1 English
2 Français
3 Deutsch
4 Español
5 Italiano
6 Nederlands
7 Original
8 Others
SUBTITLE LANGUAGE
1 Automatic
2 English
3 Français
4 Deutsch
5 Español
6 Italiano
7 Nederlands
8 Others
PARENTAL CONTROL
1 Use Password No
37
38
38
39
39
40
DV-P313U-E-P1-2101.4.1010:45AMページ10
RETURN
ENTER
11
SETUP
ENGLISH
Identifying Menu Screens
DISPLAY OPTIONS
1 TV Aspect 4:3 L-Box
2 Still Mode Auto
3 Screen Messages On
4 Front Display Bright
5 Black Level Off
ENTER
RETURN
TV ASPECT
1 4:3 Letter Box
2 4:3 Pan-Scan
3 16:9 Wide
ENTER
RETURN
PARENTAL CONTROL
1 Use PasswordYes
2 Rating Level 1
3 Change Password
RATING LEVEL
Level 8 Adult
Level 7
Level 6
Level 5
Level 4
Level 3
Level 2
Level 1 Kids Safe
PRESS 0-9
RETURN
CHANGE PASSWORD
Enter New Password
_ _ _ _
PRESS 0-9
RETURN
CHANGE PASSWORD
Re-enter New Password
_ _ _ _
AUDIO OPTIONS
1 Digital Output PCM
2 DTS Off
3 Dynamic Compression Off
PRESS 0-9
RETURN
CREATE PASSWORD
Enter Password
_ _ _ _
PRESS 0-9
RETURN
CREATE PASSWORD
Re-enter Password
_ _ _ _
40
39
42
40
40
40
40
DV-P313U-E-P1-2101.4.1010:45AMページ11
RETURN
RETURN
ENTER
RETURN
ENTER
12
Excellent Sound
The Dolby Digital system
developed by Dolby Labs provides
crystal clear sound reproduction.
Screen
Video with MPEG-2 compression
technology. Both regular and
widescreen(16:9) pictures can be
viewed.
Slow Motion
An important scene can be viewed
in slow motion.
Program Playback
You can program Chapter/Track to
play in desired order.
Parental Control
The parental control allows users to
set the level necessary to prohibit
children from viewing harmful
movies such as those with violence,
adult subject matter, etc.
Various On-Screen Menu
Functions
You can select various
languages(Audio/Subtitle) and
screen angles while enjoying
movies.
Repeat
You can repeat a song or movie
simply by pressing the REPEAT
button.
POWER/STANDBY
DV-P313U
Copy protection
･ Many DVD discs are encoded with copy protection. Because of this, you should only
connect your DVD player directly to your TV,not to a VCR.Connecting to a VCR
results in a distorted picture from copy-protected DVD discs.
･ This product incorporates copyright protection technology that is protected by methods
claims of certain U.S.patents and other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended for home and other limited viewing
uses only unless otherwise authorized by Macrovision Corporation.Reverse engineering
or disassembly is prohibited.
ENGLISH
General Features
DV-P313U-E-P1-2101.4.1010:45AMページ12
13
This DVD player is capable of playing the following types of discs with the
corresponding logos:
*DO NOT play CD-ROM, CD-I, CD-R and DVD-ROM in this player!
(CDGs play audio only, not graphics.)
12 cm
8 cm
Single-sided
242 min.
Double-sided
484 min.
Single-sided
75 min.
Double-sided
150 min.
Audio
+
Video
Audio
+
Video
Audio
･ An LP is recorded as an
analog signal with more
distortion. CD is recorded
as a Digital Signal with
better audio quality, less
distortion and less
deterioration of audio
quality over time.
･ Video with CD sound,
VHS quality & MPEG-1
compression technology.
･ DVD contains excellent
sound and video due to
Dolby Digital and MPEG-2
system.
･ Various screen and audio
functions can be easily
selected through the onscreen menu.
VIDEO-CD
AUDIO-CD
12 cm
8 cm
74 min.
20 min.
12 cm
8 cm
74 min.
20 min.
Disc Types
(Logos)
Recording
Types
Disc Size
Max.
Playing
Time
Characteristics
DVD
DIGITAL
SOUND
STEREO
･ Playback
Region
Number
･ NTSC
broadcast
system in
U.S.A, Canada,
Korea, Japan,
etc.
･ Dolby
Digital
disc
･ Digital
Audio disc
･ Stereo
disc
･ DTS disc
NTSC
Disc Markings
Both the DVD player and the discs are coded by region.These regional codes must match
in order for the disc to play.If the codes do not match, the disc will not play.
The Region Number for this player is described on the rear panel of the player.
Playback Region Number
SETUP
ENGLISH
Disc Type and Characteristics
DV-P313U-E-P1-2101.4.1010:45AMページ13
POWER/STANDBY
14
POWER / STANDBY
･ When the unit is first plugged in, the indicator lights.When POWER/STANDBY is
pressed, the lamp goes out and the player is turned on.
DISC TRA Y
･ Press OPEN/CLOSE to open and close the disc tray.
DISPLAY
･ Operation indicators are displayed here.
OPEN/CLOSE
･ Press to open and close the disc tray.
(PLAY/PAUSE)
･ Begin or pause disc play.
(STOP)
･ Stops disc play.
(SKIP/SEARCH)
･ Use to skip a scene or music.
･ If this button is held down for approx. two seconds, it will switch to the search button:
Thereafter, each time the button is pressed, the search speed will switch to 2X, 4X,
8X, 16X, 32X, 128X, after which SKIP will be restored.
ENGLISH
Description-Front Panel
Front Panel Controls
DV-P313U-E-P1-2101.4.1010:45AMページ14
15
You can now select different viewing points of the scene recorded by different
cameras (Multi Angle).
Disc type indicators
Reverse playback / Pause / Forward playback
Lights when 3D Sound is turned on.
DVD :Title number
DVD :Chapter number.
Video/Audio CD :Track number
Repeat play mode
Linear PCM audio output
Dolby Digital audio output
DTS (Digital Theater System) audio output(Digital only)
MPEG-2 Audio output
Displays various messages concerning operations such as PLAY, STOP, LOAD,
RANDOM, ...
no DISC : No disc loaded.
OPEN :The disc tray is open.
LOAD : Player is loading disc information.
SETUP
ENGLISH
Front Panel Display
Front Panel Display
DV-P313U-E-P1-2101.4.1010:45AMページ15
STOP
PLAY/PAUSE
16
ENGLISH
Tour of the Remote Control
How to handle the remote control
･Operate the remote control within the following area, in a straight line from the signal
detecting eye of the player and an angle of 30º.
30
Approx. 7m(Approx. 23 feet)
30
30
30
DV-P313U-E-P1-2101.4.1010:45AMページ16
17
SETUP
ENGLISH
DVD POWER Button
･ Turns the player on and off.
NUMBER Buttons
REPEAT Button
･ Allows you to repeat play a title, chapter, track, or disc.
A-B REPEAT Button
･ Marks a segment to repeat between A and B.
SETUP Button
･ Brings up the DVD player's Setup menu.
MODE Button
･ Allows you to program a specific order.
SEARCH Buttons
･ Allows you to search forward/backward through a disc.
STOP Button
･ To stop playback.
SKIP Buttons
･ Skip the, Chapter, or Track.
MENU Button
･ Brings up the Menu on a disc.
TOP MENU Button
･ Brings up the Top Menu on a disc.
ENTER/DIRECTION Button (UP/DOWN or LEFT/RIGHT Button)
STEP Button
･ Advances playback one frame at a time.
AUDIO Button
･ Accesses various audio functions on a disc.
OPEN/CLOSE Button
･ To open or close the disc tray.
3D SOUND Button
･ To activate the 3D sound.
ZOOM Button
･ To magnify part of picture.
CLEAR Button
･ Removes menus or status displays from the screen.
BOOKMARK Button
･ To rapidly return to a location of disc.
PLAY/PAUSE Button
･ Begin/Pause disc play.
RETURN Button
･ Returns to a previous menu.
DISPLAY Button
･ Displays the current disc mode.
ANGLE Button
･ Accesses various camera angles on a disc.
SUBTITLE Button
･ Accesses various subtitles on a disc.
Tour of the Remote Control
DVD Function Buttons
DV-P313U-E-P1-2101.4.1010:45AMページ17
18
DVD POWER Button
Tour of the Remote Control
･Turns the player on
and off (p.9).
･Turns the player on
and off (p.9).
･Turns the player on
and off (p.9).
DVD VCD CD
･Allows you to repeat
play a Title, Chapter or
Disc (p.29).
･Allows you to repeat
play a Track, Disc or AB (p.29).
･Allows you to repeat
play a Track, Disc or AB (p.29).
･Allows you to program
a specific order or
random play (p.30).
･Allows you to program
a specific order (p.30).
･Allows you to program
a specific order (p.30).
･Brings up the Menu on
a disc. (p.32)
･Switches menu on or
off.(p.32)
(VCD 2.0)
REPEAT Button
MODE Button
MENU Button
ENTER/DIRECTION
Button (UP/DOWN or
LEFT/RIGHT Button)
･To stop playback (p.9)
.
･To stop playback (p.9).･To stop playback (p.9)
.
STOP Button
TOP MENU Button
SKIP Buttons
･Brings up the Top
Menu on a disc (p.27).
･Moves the cursor and
determines its position.
･Moves the cursor and
determines its position.
･Moves the cursor and
determines its position.
･To skip Chapters.
(p.25)
･To skip Tracks (p.25). ･To skip Tracks (p.25).
NUMBER Buttons
･Marks a segment to
repeat between A and
B (p.29).
･Marks a segment to
repeat between A and
B (p.29).
･Marks a segment to
repeat between A and
B (p.29).
A-B REPEAT Button
SETUP Button
･Brings up the DVD
player's Setup menu (p.
10).
･Brings up the DVD
player's Setup menu (p.
10).
･Brings up the DVD
player's Setup menu (p.
10).
SEARCH Buttons
･Allows you to search
forward/backward
through a disc (p.25).
(X2/X4/X8/X16/X32/X12
8)
･Allows you to search
forward/backward
through a disc (p.25).
(X4/X8)
･Allows you to search
forward/backward
through a disc (p.25).
(X2/X4/X8)
Buttons on remote control work in different ways for DVD, VCD and CD:
Refer to the following table for correct use.
･To use display
function, or input
program order (p.23).
･To select track directly,
use display function, or
input program order
(p.23). (VCD 2.0)
･To select track directly,
use display function, or
input program order
(p.23).
ENGLISH
DV-P313U-E-P1-2101.4.1010:45AMページ18
19
Tour of the Remote Control
･Advances playback
one frame at a time
(p.24).
･Advances playback
one frame at a time
(p.24).
･Returns to a previous
menu.
･Returns to a previous
menu.
･Accesses various
camera angles on a
disc (p.34).
RETURN Button
ANGLE Button
STEP Button
DVD VCD CD
SUBTITLE Button
BOOKMARK Button
OPEN/CLOSE Button
ZOOM Button
CLEAR Button
DISPLAY Button
AUDIO Button
PLAY/PAUSE Button
･Accesses various
subtitle on a disc
(p.33).
･To rapidly return to a
location of disc (p.35).
･To rapidly return to a
location of disc (p.35).
(Menu off mode)
･To open or close the
disc tray (p.9).
･To open or close the
disc tray (p.9).
･To open or close the
disc tray (p.9).
･To magnify part of
picture (p.36).
(X2/X4)
･To magnify part of
picture (p.36).
(X2)
･Removes menus or
status displays from
the screen.
･Removes menus or
status displays from
the screen.
･Removes menus or
status displays from
the screen.
･Displays the current
disc mode (p.28).
･Displays the current
disc mode (p.28).
･Displays the current
disc mode (p.28).
･Accesses various
audio functions on a
disc (p.32).
･Accesses various
audio functions on a
disc (p.32).
･Accesses various
audio functions on a
disc (p.32).
･Begin/Pause disc play
(p.9).
･Begin/Pause disc play
(p.9).
･Begin/Pause disc play
(p.9).
SETUP
･To activate the 3D
sound (p.36).
･To activate the 3D
sound (p.36).
･To activate the 3D
sound (p.36).
3D SOUND Button
ENGLISH
DV-P313U-E-P1-2101.4.1010:45AMページ19
20
ENGLISH
DIGITAL AUDIO OUT JACK
･ Use either an optical or coaxial digital
cable to connect to a compatible
Dolby Digital receiver. Use to connect
to an A/V Amplifier that contains a
Dolby Digital decoder or DTS
decoder.
MIXED AUDIO OUT JACKS
･ Connect to the Audio input jacks of
your television, audio/video receiver.
VIDEO OUT JACK
･ Use a video cable to connect one of
the jack to the Video input on your
television.
S-VIDEO OUT JACK
･ Use the S-Video cable to connect this
jack to the S-Video jack on your
television for a higher quality picture.
The S-Video must be selected in the
VIDEO OUT SELECT SWITCH.
COMPONENT VIDEO OUT JACKS
･ Use these jacks if you have a TV with
Component Video in jacks. These
jacks provide Pr, Pb and Y video .
Along with S-Video, Component Video
provides the best picture quality.The Y ,
Pb, Pr must be selected in the VIDEO
OUT SELECT SWITCH.
VIDEO OUT SELECT SWITCH
･ Use the switch to set video out.
･ If the Y, Pb or Pr is selected, the S-
Video may not work.
･ If the S-Video is selected, the Y, Pb or
Pr may not work.
Description-Rear Panel
Rear Panel
DV-P313U-E-P1-2101.4.1010:45AMページ20
DIGITAL AUDIO OUT
OPTICAL COAXIAL
MIXED AUDIO OUT
RL
VIDEO OUT S-VIDEO OUT
COMPONENT VIDEO OUT
Pb
S-VIDEO
YPr
VIDEO OUT
SELECT
Y,P b, P r
21
CONNEC
TIONS
The following show examples of connections commonly used to connect
the DVD player with a TV and other components.
･ Always turn off the DVD player, TV, and other components before you connect
or disconnect any cables.
･ Refer to owner's manual of the additional components you are connecting for
more information for those particular components.
Before Connection the DVD Player
Connection to an Audio System
Analog Audio Out
Amplifier with Dolby Digital Decoder
DTS Decoder
Digital Audio Input Jack
2ch Stereo Amplifier
Dolby Pro Logic Decoder
Audio Input Jacks
Digital Audio Out
AUDIO
DVD
･ Method 1 DVD Player + 2ch Stereo Amplifier or Dolby Pro Logic Decoder
･ Method 2 DVD Player + Amplifier with Dolby Digital Decoder/DTS Deco
der
Method 1
Method 2
OR
ENGLISH
MIXED AUDIO OUT
R
RL
L
OPTICAL COAXIAL
OPTICAL COAXIAL
DIGITAL AUDIO OUT
Choosing a Connection
Connection to an Audio System
DV-P313U-E-P1-2101.4.1010:45AMページ21
RL YPr Pb
COMPONENT VIDEO OUT
YPr
Pb
VIDEO OUT
S-VIDEO OUT
MIXED AUDIO OUT
RL
22
NOTES
･ If the VIDEO OUT SELECT SWITCH (on the rear panel) is set to Y, Pb or Pr, the S-Video
may not work.
･ If the VIDEO OUT SELECT SWITCH is set to S-Video, the Y, Pb or Pr may not work.
･ After correcting the switch, turn power off and then on again.
Connection to a TV
･ Method 1 DVD Player + TV with Video Input Jack
･ Method 2 DVD Player + TV with S-Video Input Jack
(If the S-Video is selected in the VIDEO OUT SELECT.)
･ Method 3 DVD Player + TV with Component Video Jacks
(If the Y, Pb or Pr is selected in the VIDEO OUT SELECT.)
TV (Normal, Widescreen, Projection, etc..)
Connection to a TV (For Video)
Analog Audio out
Good picture
Basic Audio
OR
OR
AV Cable
(included)
S-Video
Cable
(optional)
Video Cables
(optional)
Better
Best picture
Video out
S-Video out
Component Video out
DVD
TV
Method 1
Method 2
Method 3
ENGLISH
Choosing a Connection
DV-P313U-EP22-4501.4.1010:47AMページ22
NOTES
23
Before Playback
Playback
･ Turn on a TV and press the TV/VIDEO button to select
video mode.
･ Turn on your Audio System to select AUX, CD or DVD.
･ Refer to your AUDIO User's Manual.
After plugging in the player, the first time you
press the DVD POWER button, this screen
comes up :
If you want to select the language, press a NUMBER
button.(This screen will only appear the very first time
you plug in the player.)
1
1
Press the OPEN/CLOSE button.
The STANDBY indicator light goes out and the
tray opens.
2
2
Place a disc gently into the tray with
the disc's label facing up.
3
3
Press the PLAY/PAUSE button or
OPEN/CLOSE button to close the
disc tray.
When you stop disc play, the player remembers where you stopped, so when you press
PLAY again, it will pick up where you left off (unless the disc is removed, the STOP button is
pressed twice or the player is unplugged.)
RESUME function
BASIC
FUNCTIONS
･ If the player is left for an approximate 2 minutes in pause mode, it will stop.
･ The power is automatically turned off after approximately 30 minutes have elapsed in the
stop mode (auto power-off feature).
･ If the player is left in the stop mode for more than one minute without any user
interaction, a screensaver will be activated, and the TV screen will fade in and fade out
repeatedly. Press PLAY button to resume normal play.
･ When a CD is played back, the TV screen will be black.
･ This icon indicates an invalid button press.
ENGLISH
Playing a Disc
SELECT MENU LANGUAGE
Press 1 for English
Touche 2 pour Français
Drucken 3 fur Deutsch
Pulse 4 para Español
Premere 5 per Italiano
Toets 6 voor Nederlands
DV-P313U-EP22-4501.4.1010:47AMページ23
RETURN
ENTER
24
1
1
Stopping Playback
Press the STOP button in playback.
2
2
Removing Disc
Press the OPEN/CLOSE button.
3
3
Pausing Playback
Press the PLAY/PAUSE or STEP button on the
remote during playback.
- Screen stops, no sound.
- To resume again, press PLAY/PAUSE button
once again.
4
4
Step Motion Playback (Except CD)
Press the STEP button on the remote during
playback.
- Each time the button is pressed, a new frame
will appear.
- No sound is heard during STEP mode.
- Press PLAY/PAUSE to resume normal
playback.
(You can only perform step motion playback in
the forward direction.)
5
5
Slow Motion Playback (Except CD)
Press the FWD or REV SEARCH button on the
remote during PAUSE or STEP mode.
- By pressing, you can select slow motion
playback for 1/8, 1/4 or 1/2 of normal speed.
- No sound is heard during slow mode.
- Press PLAY/PAUSE to resume normal
playback.
- When playing a VCD, the reverse slow motion
playback will not work.
ENGLISH
Chapter 1
Chapter 2
Chapter 1
Chapter 2
DVD
Title 1
Title 2
CD,Video CD
Tra ck 1
Tra ck 2 Tra ck 3
Tra ck 4
Tra ck 5
■About Title, Chapter,and Trac k
In a DVD, the contents are divided in titles, and the titles are devided in
chapters.The contents in a Video CD or CD are divided in tracks.
DISC
DISC
NOTE
Several options are available during DVD playback.
Playing a Disc
DV-P313U-EP22-4501.4.1010:47AMページ24
25
NOTE
Searching through a Chapter or Track
Skipping T racks
During playback, you can search quickly through a Chapter or Track or use
the skip function to jump to the next selection.
1
1
Press the FWD SEARCH button or
REV SEARCH button on the remote
during PLAY mode.
･ Press the REVERSE or FORWARD SEARCH button on
the remote and press again to search at a faster
speed(2X/4X/8X/16X/32X/128X, in order) on DVD.
(If the FORWARD SEARCH button is pressed at the
128X speed, the mark will appear.)
･ Press the REVERSE or FORWARD SEARCH button on
the remote and press again to search at a faster
speed(4X/8X, in order) on VCD.(If the FORWARD
SEARCH button is pressed at the 8X speed, the
mark will appear.)
･ Press the REVERSE orFORWARD SEARCH button on
the remote and press again to search at a faster
speed(2X/4X/8X,in order) on CD.(If the FORWARD
SEARCH button is pressed at the 8X speed, the
mark will appear.)
･ To return to normal speed playback, press the PLAY/
PAUSE button.
･ While in search
(2X/4X/8X/16X/32X/128X)
on DVD or high-speed
playback on VCD, no
sound will be heard.
BASIC
FUNCTIONS
ENGLISH
Using the Search and Skip Functions
2
2
Press the NEXT SKIP or BACK
SKIP button during playback.
･ When playing a DVD, if you press the NEXT SKIP
button,it moves to next Chapter. If you press the BACK
SKIP button, it moves to the beginning of the Chapter.
One more press makes it move to the beginning of the
previous Chapter.
･ If a Track exceeds 15 minutes when playing a VCD and
you press NEXT SKIP button, it moves forward 5
minutes.If you press BACK SKIP button, it moves
backward 5 minutes.
･ When playing a VCD 2.0 in the MENU MODE or Track
View function, if you press NEXT SKIP button, it moves
to the next MENU or the next Track View display.If you
press BACK SKIP button, it moves to the previous
MENU or the previous Track View display.(See page 32.)
･ When playing a VCD 2.0 in MENU OFF mode, a VCD 1.1
or a CD,if you press NEXT SKIP button, it moves to
next Track.If you press BACK SKIP button, it moves to
the beginning of the Track.One more press makes it
move to the beginning of the previous Track.
DV-P313U-EP22-4501.4.1010:47AMページ25
26
ENGLISH
When Playing a DVD
When playing a VCD(version 2.0)
1
1
Press the MENU button.
- The Menu screen will appear.
- With some discs, the Menu screen will automatically
appear.
- The Menu screen varies depending on the discs.
2
2
Use the UP/DOWN/LEFT/RIGHT
button to select the desired item.
- With some DVDs, you can use the number buttons to
select the item.
3
3
Press the ENTER button.
- Play the disc, following the Menu.
1
1
Play a VCD(version 2.0)
- The Menu screen will appear.
2
2
Use the number buttons to select the
desired item.
- Simply pressing the number buttons will enter the item.
- With some VCDs, you can use the PLAY/PAUSE, SKIP
and RETURN buttons play the disc.
With some VCDs, the RETURN button operation may be
displayed using the mark.
- Press the RETURN button to return to the Menu screen
during play.
ON some DVD and VCD discs the Menu screen may be recorded.You can
use the Menu screen to select the item you want to play.
NOTES
･ With some DVDs, you may not be able to call the Menu screen by pressing the MENU
button :In such cases, press the TOP MENU button.
･ Some DVDs do not have any Menu or Top Menu.
･ When playing a VCD 1.1 or CD, the Menu screen will not appear.
･ If you play a VCD by displaying the Menu screen, the functions other than those
following the Menu will not work.
･ In VCD disc version 2.0, the MENU button works as a conversion switch between MENU
ON and MENU OFF modes.
Using Menu Screen on Disc for Playback
• item 1
• item 2
• item 3
SELECT
• item 1
• item 2
• item 3
DV-P313U-EP22-4501.4.1010:47AMページ26
27
BASIC
FUNCTIONS
ENGLISH
1
1
Press the TOP MENU button.
- The Top Menu screen will appear.
- The Top Menu screen varies according to the disc.
2
2
Use the UP/DOWN/LEFT/RIGHT
button to select the desired item.
- With some DVDs, you can use the number buttons to
select the item.
3
3
Press the ENTER button.
- Play the disc, following the Top Menu.
With some DVDs, several Titles are recorded and the Top Menu is
provided.Use the Top Menu screen to play such DVDs for convenience.
NOTES
･ Some discs may not have Top Menu.
･ Some discs may display the same screen even if the MENU button is pressed or the
TOP MENU button is pressed.
Using Top Menu Screen on Disc to Play DVD
• item 1
• item 2
• item 3
DV-P313U-EP22-4501.4.1010:47AMページ27
28
When Playing a DVD
When Playing a CD/VCD
1
1
During playback, press the DISPLAY
button on the remote.
- Current Title, Chapter number and elapsed time will be
displayed.
･ Use the LEFT/RIGHT button to select a Title or a
Chapter number.
Use the UP/DOWN button or Number buttons to enter a
different Title or Chapter number, then press the ENTER
button.
･ To enter the time from which you want to start, use the
LEFT/RIGHT button to select, then use the Number
buttons to enter the time.Then press the ENTER button.
2
2
Press the DISPLAY button on the remote
twice.
- Current Audio, Subtitle and volume control will appear.
- To make the screen disappear, press the DISPLAY
button again.
1
1
During playback, press the DISPLAY
button on the remote.
- Current Track number, elapsed time and volume control
will be displayed.
･ Use the LEFT/RIGHT button to select a Track.Use the
UP/DOWN button or Number buttons to enter a different
Track number and then press the ENTER button.
･ To enter the time from which you want to start, use the
LEFT/RIGHT button to select, then use the Number
buttons to enter the time.Then press the ENTER button.
- To make the screen disappear, press the DISPLAY
button again.
･ In VCD 2.0 mode (MENU ON mode), only the volume
control will appear on screen.
ENGLISH
If you want to obtain the information on the title, chapter, time, audio
configuration and subtitles in DVD play, press the PLAY button.To get
information on the track and time in VCD or CD play, also press DISPLAY.
Using the Display Function
NOTES
0:06:54
T:01
64
VCD
ENG 5.1 CH
ENG ON
64
0:06:54
C:04
T:01
DVD
･ If playback of DVD second
layer starts, a small dot (.)
will appear before the
letters DVD on the
information screen.
･
If the DISPLAY button is
pressed during playback of
DVD discs in order to switch
on-screen information on or
off, the picture and/or sound
may stop momentarily.
0:06:54
T:01
64
CD
NOTE
･ The on-screen information
will automatically switch off
if no button is operated for
approx.one minute.
DV-P313U-EP22-4501.4.1010:47AMページ28
29
NOTES
Using the REPEAT button
Repeat the current Track, Chapter, Title, a chosen section (A-B) or all the
disc (only VCD/CD).
1
1
Press the REPEAT button on the remote.
Repeat screen appears.
2
2
Select Chapter, Title or A-B using the
LEFT/RIGHT button.
- A-B Repeat
1 Press the REPEAT button. Select A-B on screen with
the LEFT/RIGHT button.
2 Press ENTER at the point where you want the repeat
play to start (A).The B is automatically highlighted.
3 Press ENTER at the point where you want the repeat
play to stop (B).
4 The A-B Repeat that you set plays until you turn off
Repeat.
3
3
Press ENTER.
4
4
To return to normal playback press
REPEAT again, then press the
LEFT/RIGHT button to select Off
and press ENTER.
･ DVD repeats playback by Chapter or Title, CD and VCD repeat playback by disc or Track.
･ Depending on the disc, the Repeat function may not work.
･ If the Track is completed before marking the end (B), the end of Track becomes (B)
automatically.
･ If the DVD title is completed before marking the end (B), playback will stop and the
marked start (A) will also be cleared.
･ If the DVD chapter is completed before marking the end (B), following chapter will be
played back, and the end (B) can be set.
･ When in VCD 2.0 mode (MENU ON mode), this function does not work.
BASIC
FUNCTIONS
VCD/CD
DVD
ENGLISH
Using the A-B REPEAT button
1
1
Press the A-B REPEAT button at the
point where you want repeat play to
start(A).
2
2
Press the A-B REPEAT button at the
point where you want repeat play to
stop(B).
- The A-B Repeat that you set will play untill you turn off
Repeat.
3
3
To return to normal playback press the
A-B REPEAT button again.
Repeat Playback
Off Chapter Title A-B
Off Track Disc A-B
DV-P313U-EP22-4501.4.1010:47AMページ29
30
NOTE
Program Playback (DVD/VCD/CD)
1
1
Press the MODE button.
2
2
Use the LEFT/RIGHT button to select
PROGRAM.Press the ENTER button.
3
3
Use the UP/DOWN/LEFT/RIGHT
button to select the first Chapter (or
Track) to add to program.Press the
ENTER button.
- The selected numbers appear in the Program Order box.
4
4
Press the PLAY/PAUSE button.
- The disc will be played back in programmed order.
Random Playback (DVD/VCD/CD)
1
1
Press the MODE button in the stop
mode.
2
2
Use the LEFT/RIGHT button to select
RANDOM. Press the ENTER button.
-The disc will be played back in random order.
･ Depending on the disc, the
Program or Random Playback
function may not work.
･ This function is not available
with VCD 2.0(MENU ON
mode).
･ To resume normal playback,
press the CLEAR button.
･ On DVD discs, programming
is possible only for the title
that has the largest number
of chapters.
DVD
VCD/CD
ENGLISH
Programmed play allows you to specify the playback order of titles,
chapters or tracks on a disk.This function is only possible when playback is
stopped.
Program Playback and Random Playback
PROGRAM 01
Chap.(T:01)
Program Order
01 02 03 04
05 06 07 08
09
-- -- --
-- -- -- --
-- -- -- --
01
PROGRAM 01
Track
Program Order
01 02 03 04
05 06 07 08
09
-- -- --
-- -- -- --
-- -- -- --
01
DV-P313U-EP22-4501.4.1010:47AMページ30
RETURN
RETURN
ENTER
ENTER
31
NOTES
T rack View (VCD)
Index View (VCD)
Displays the beginning view of each Track and
the Track number.
1
1
Press the TOP MENU button during
playback.
2
2
Press the UP/DOWN button to select
TRACK VIEW.Press the ENTER button.
3
3
Select the desired view by pressing the
UP/DOWN or LEFT/RIGHT
buttons.
4
4
Press the ENTER button.
Displays the equally divided 9 views of the
current playing Track.
1
1
Press the TOP MENU button during
playback.
2
2
Press UP/DOWN button to select
INDEX VIEW.Press the ENTER button.
3
3
Select the desired view by pressing
UP/DOWN or LEFT/RIGHT
buttons.
4
4
Press the ENTER button.
･ When in VCD 1.1 & 2.0 mode (MENU OFF mode), this function works.
･ In stop mode on VCD, press the TOP MENU button and the TRACK VIEW will be
displayed directly.
･ When pressing the TOP MENU on DVD;The disc's Top Menu will come up.
･ When pressing the TOP MENU on CD ; The unit enters the INTRO mode. INTRO
lets you listen to the beginning of each Track for about 10 seconds.
(example)
(example)
ADVANCED
FUNCTIONS
ENGLISH
You can directly access the desired music or video track without using the
menu.
Using the Disc View Function
TRACK VIEW
04
07
02
05
08
03
06
09
01
INDEX VIEW
04
07
02
05
08
03
06
09
01
1 Track Vie w
2 Index View
DISC VIEW
ENTER
DV-P313U-EP22-4501.4.1010:47AMページ31
32
NOTES
Using the AUDIO Button
Using the MENU Button
1
1
Press the AUDIO button.
2
2
Use the UP/DOWN button to select
the desired language on a DVD.
- The audio languages are represented by abbreviations.
3
3
Use the UP/DOWN button to select
STEREO, R CHANNEL or L CHANNEL.
(On VCD/CD)
When playing a DVD
1
1
Press the MENU button.
2
2
Use the UP/DOWN /LEFT/RIGHT
button to select AUDIO information.
3
3
Press the ENTER button.
4
4
Use the UP/DOWN /LEFT/RIGHT
button to select the desired language on
a DVD.
5
5
Press the ENTER button.
When playing a VCD
In disc version 2.0, the MENU button works as a
conversion switch between MENU ON and MENU OFF
mode.
When playing a VCD 1.1 or CD, the MENU button will not
work.
･ This function depends on
what languages are
encoded on the disc and
may not work with all
DVDs.
･ A DVD disc can contain
up to 8 Audio languages.
･
How to have the
same Audio language
come up whenever
you playback a DVD;
Refer to "Setting Up the
Language Features" on
page 38.
You can select a desired language quickly and easily with the AUDIO
button.
(example)
ENGLISH
Selecting the Audio Language
ENG DOLBY DIGITAL 5.1CH
STEREO
1 Audio
2 Subtitle
1 English
2 Français
NOTE
･ Subtitle languages are
displayed using
abbreviations.
(Examples) ENG: English
FRA: French
ESP: Spanish
DV-P313U-EP22-4501.4.1010:47AMページ32
33
NOTES
Using the SUBTITLE button
Using the MENU button
You can select a desired Subtitle quickly and easily with the SUBTITLE
button.
1
1
Press the SUBTITLE button.
2
2
Use the UP/DOWN button to select
the desired Subtitle language.
3
3
Use the LEFT/RIGHT button to
determine whether or not the Subtitle will
be displayed.
- Initially, the subtitle will not appear on screen.
- The Subtitle languages are represented by
abbreviations.
When playing a DVD
1
1
Press the MENU button.
2
2
Use the UP/DOWN /LEFT/RIGHT
button to select SUBTITLE information.
3
3
Press the ENTER button.
4
4
Use the UP/DOWN /LEFT/RIGHT
button to select the desired language.
5
5
Press the ENTER button.
When playing a VCD
In disc version 2.0, the MENU button works as a conversion
switch between MENU ON and MENU OFF mode.
When playing a VCD 1.1 or CD, the MENU button will not
work.
･ This function depends on
what languages are
encoded on the disc and
may not work with all
DVDs.
･ A DVD disc can contain up
to 32 Subtitle languages.
･
How to have the same
Subtitle language
come up whenever
you playback a DVD;
Refer to "Setting Up the
Language Features" on
page 38.
(example)
ADVANCED
FUNCTIONS
ENGLISH
Selecting the Subtitle Language
ENG Off
ENG On
1 Audio
2 Subtitle
1 English
2 Français
DV-P313U-EP22-4501.4.1010:47AMページ33
34
NOTES
Using the ANGLE button
When a DVD contains multiple angles of a particular scene, you can select
the Angle function.
Check to see if an 'ANGLE ( )' mark is
present at the upper right hand corner of the
screen.
1
1
When an 'ANGLE' mark is shown, press
the ANGLE button.
2
2
Use the UP/DOWN button to select
the desired screen Angle.Then press the
ENTER button.
- The ANGLE mark will reappear at the top right corner of
screen.
- To turn off the display, use the Setup Menu to choose
Display Options and specify Screen Messages “Off”.
･ This function is disc-dependent, and may not work with all DVDs.
･ This function does not work when a DVD has not been recorded with a multi-camera
angle system.
Press the DISPLAY button twice. Use the UP/DOWN button to select a suitable
volume.
･ Master Volume Control function lets you adjust the volume of the player's output. This is
useful for matching the player's output level to other equipment in your system.
･ When the DIGITAL OUTPUT is set to BITSTREAM in the SETUP MENU, the Volume
Control function will not work.
Using the Master Volume Control Function
(example)
ENGLISH
Changing the Camera Angle
4/4
DV-P313U-EP22-4501.4.1010:47AMページ34
35
NOTES
Using the Bookmark Function (DVD/VCD)
Recalling a Marked Scene
The Bookmark function lets you select parts of a DVD or VCD (MENU OFF
mode) so that you can quickly find the section at a later time.
1
1
During playback, press the
BOOKMARK button on the remote.
Then a marker will be displayed.
2
2
Use the LEFT/RIGHT button to
move to the desired bookmark icon.
3
3
When you reach the scene you want to
mark, press the ENTER button.The
icon will change to a number (1, 2, or
3).
4
4
Press the BOOKMARK button to turn
off the display.
1
1
During playback, press the BOOKMARK
button on the remote.
2
2
Use the LEFT/RIGHT button to
select a marked scene.
3
3
Press the PLAY/PAUSE button to
skip to the marked scene.
Clearing a Bookmark
1
1
During playback, press the
BOOKMARK button on the remote.
2
2
Use the LEFT/RIGHT button to
select the bookmark number you want
to delete.
3
3
Press the CLEAR button to delete a
bookmark number.
Press the BOOKMARK button to turn
off display.
･ Up to three scenes may
be marked at the same
time.
･ When in VCD 2.0 mode
(MENU ON mode), this
function does not work.
･ Depending on the disc,
the Bookmark function
may not work.
ADVANCED
FUNCTIONS
ENGLISH
Using the Bookmark Function
- - -
ENTER
1 - -
PLAY
CLEAR
DV-P313U-EP22-4501.4.1010:47AMページ35
36
NOTES
Using the Zoom Function (DVD/VCD)
Using the 3D Sound Function
1
1
During playback or pause mode, press
the ZOOM button on the remote.A
pointer will be displayed on screen.
2
2
Use the UP/DOWN or
LEFT/RIGHT button to select the
part of the screen you want to zoom.
3
3
Press the ENTER button.
- During DVD playback, press ENTER to zoom in
2X/4X/normal.
- During VCD playback, press ENTER to zoom in
2X/normal.
The simulated surround effect (SPATIALIZER
N-2-2) depends on the disc contents.If you
connect the unit to your stereo system, you
can enhance sound quality and produce a
greater surround effect.
This feature is useful when you are using the
DVD player with a two channel stereo through
the analog outputs.
(Discs which are recorded with LPCM or DTS
will not work.When the DIGITAL OUTPUT is
set to BITSTREAM in the Setup Menu, the
3D Sound function will not work.)
1
1
During playback, press the 3D button.
- The 3D Sound mark will be displayed on screen. (Be
sure the DIGITAL OUTPUT is set to PCM.)
2
2
Press the UP/DOWN button to turn
the Surround feature on or off.
･ 3D Sound is possible only
on discs recorded using
DOLBY SURROUND or
DOLBY DIGITAL.
However, some of these
discs do not contain rear
channel sound signals.
･ Depending on the disc,
the Zoom and Surround
function may not work.
ENGLISH
Using the Zoom and 3D Sound Functions
Off
DV-P313U-EP22-4501.4.1010:47AMページ36
3D
37
ADVANCED
FUNCTIONS
ENGLISH
NOTES
The Setup Menu lets you customize your DVD player by allowing you to
select various language preferences, set up a parental level, even adjust
the player to the type of television screen you have.
1
1
Press the SETUP button on the remote
in the stop mode.
Player Menu : Setup of the Display
Language (See page 38)
Use the Player preference menu to select the
language for the player's on-screen displays.
Disc Menu : Setup of the Menu Language
(See page 38)
Use the Menu preference menu to select the language
you want a D VD's disc menu to be displayed in.
Audio : Setup of the Audio Language (See page 39)
Use the Audio preference menu to select the
soundtrack language.
Subtitle : Setup of the Subtitle Language
(See page 39)
Use the Subtitle preference menu to select the
language the disc's Subtitles are to be displayed in.
Parental : Setup of the Parental Level
(See page 40)
Allows users to set the level necessary to prevent
children from viewing unsuitable movies such as
those with violence, X rating, etc.
Audio Options : Setup of the Audio Options (See
page 41)
Display Options : Setup of the Display Options
(See page 42)
Use to select which type of screen you want to
watch and several display options.
2
2
Use the UP/DOWN button on the
remote to access the different features.
3
3
Press the ENTER button to access the
sub features.
To make the Setup Menu disappear after setting up,
press the SETUP button again.
･Depending on the disc,
some Setup Menu
selections may not work.
･This menu screen will
disappear if there is no
operation for approx.two
minutes.
Using the Setup Menu
SETUP MENU
1 Player Menu English
2 Disc Menu English
3 Audio English
4 Subtitle Automatic
5 Parental Unlocked
6 Audio Options
7 Display Options
DV-P313U-EP22-4501.4.1010:47AMページ37
RETURN
ENTER
e.g
Using the Disc Menu Language
Using the Player Menu
If you set the Player Menu, Disc Menu, Audio and Subtitle language in
advance, it will come up automatically every time you watch a movie.
e.g
Setting up in ENGLISH.
1
1
Press the SETUP button when in stop
mode.
2
2
Use the UP/DOWN button to select
Player Menu.
3
3
Press the ENTER button.
4
4
Use the UP/DOWN button to select
'ENGLISH'.
5
5
Press the ENTER button.
- ENGLISH is selected and the screen returns to Setup
Menu.
- To make the Setup Menu disappear, press the RETURN
button.
This function changes the language only for
the text on the Disc Menu screens.
1
1
Press the SETUP button when in stop
mode.
2
2
Use the UP/DOWN button to select
Disc Menu.
3
3
Press the ENTER button.
4
4
Use the UP/DOWN button to select
'ENGLISH'.
- Select "OTHERS" if the language you want is not listed.
5
5
Press the ENTER button.
- ENGLISH is selected and the screen returns to Setup
Menu.
Setting up in ENGLISH.
38
ENGLISH
Setting Up the Language Features
SETUP MENU
1 Player Menu English
2 Disc Menu English
3 Audio English
4 Subtitle Automatic
5 Parental Unlocked
6 Audio Options
7 Display Options
PLAYER MENU LANGUAGE
1 English
2 Français
3 Deutsch
4 Español
5 Italiano
6 Nederlands
DISC MENU LANGUAGE
1 English
2 Français
3 Deutsch
4 Español
5 Italiano
6 Nederlands
7 Others
DV-P313U-EP22-4501.4.1010:47AMページ38
RETURN
RETURN
RETURN
ENTER
ENTER
ENTER
39
ENGLISH
CHANGING
SETUP MENU
NOTES
Using the Audio Language
Using the Subtitle Language
1
1
Press the SETUP button when in stop
mode.
2
2
Press the UP/DOWN button to select
Audio.
3
3
Press the ENTER button.
4
4
Press the UP/DOWN button to select
'ENGLISH'.
- Select "ORIGINAL" if you want the default soundtrack
language to be the original language the disc is recorded
in.
- Select "OTHERS" if the language you want is not listed.
5
5
Press the ENTER button.
- ENGLISH is selected and the screen returns to Setup
Menu.
1
1
Press the SETUP button when in stop
mode.
2
2
Use the UP/DOWN button to select
Subtitle.
3
3
Press the ENTER button.
4
4
Use the UP/DOWN button to select
'ENGLISH'.
- Select "AUTOMATIC" if you want the Subtitle language
to be the same as the language selected as the audio
preference.
- Select "OTHERS" if the language you want is not listed.
Some discs may not contain the language you
select as your initial language;in that case the disc will
use its original language setting.
5
5
Press the ENTER button.
- ENGLISH is selected and the screen returns to Setup
Menu.
･ If the selected language is
not recorded on the disc,
the original pre-recorded
language is selected.
･
Howto make the
current Menu
disappear and return to
Setup Menu during set
up;
Press RETURN button.
e.g
Setting up in ENGLISH.
e.g
Setting up in ENGLISH.
Setting Up the Language Features
AUDIO LANGUAGE
1 English
2 Français
3 Deutsch
4 Español
5 Italiano
6 Nederlands
7 Original
8 Others
SUBTITLE LANGUAGE
1 Automatic
2 English
3 Français
4 Deutsch
5 Español
6 Italiano
7 Nederlands
8 Others
DV-P313U-EP22-4501.4.1010:47AMページ39
RETURN
RETURN
ENTER
ENTER
The Parental Control function works in conjunction with DVDs that have
been assigned a rating - which helps you control the types of DVDs that
your family watches.There are up to 8 rating levels on a disc.
1
1
With no disc playing, press SETUP.
The Setup Menu screen appears.
2
2
Use UP/DOWN to select Parental.
Press ENTER.
The Parental Control
screen appears.
3
3
Use LEFT/RIGHT to select Yes if
you want to use a password.
Press
ENTER.The Enter Password screen
appears.
4
4
Enter your password.The Re-enter
Password screen appears to confirm
the password.
Enter your password
again.The Parental Control screen
appears.
5
5
About the Rating Level ;
The Rating Level will work only when
Use Password is set to Yes.To unlock
the player, use LEFT/RIGHT to
select No.Use UP/DOWN to select
Rating level.Press ENTER.
- Use UP/DOWN to select the level(e.g.Level 6) and
press ENTER.The disc that c o n t a i n s L evel 7 w i l l
now not play.
- To cancel the rating level, use LEFT/RIGHT to
select No in Use Password.
6
6
About the Change Password ;
- Use UP/DOWN to select Change Password.
The Change Password screen appears.
- Enter your new password.Re-enter the new
password again.
e.g
Setting up in LEVEL 6
NOTES
･
Howto make the SETUP MENU disappear or return to menu screen during setup;
Press RETURN button.
･
If you have f orgotten y our pass word, see F orgot Password in the Troubleshooting
Guide.
40
ENGLISH
Setting Up the Parental Control
PARENTAL CONTROL
1 Use Password No
CREATE PASSWORD
Enter Password
_ _ _ _
PARENTAL CONTROL
1 Use Password Yes
2 Rating Level 1
3 Change Password
RATING LEVEL
Level 8 Adult
Level 7
Level 6
Level 5
Level 4
Level 3
Level 2
Level 1 Kids Safe
DV-P313U-EP22-4501.4.1010:47AMページ40
RETURN
RETURN
RETURN
RETURN
ENTER
ENTER
ENTER
ENTER
41
ENGLISH
CHANGING
SETUP MENU
DIGITAL OUTPUT
PCM : Converts to PCM(2CH) 48kHz/16bit
audio.
Select PCM when using 3D sound.
BITSTREAM : Converts to Dolby
Digital BITSTREAM (5.1CH).
Select BITSTREAM when using
the Dolby Digital Audio Output.
NOTE :Be sure to select the correct Digital
Output.
DTS
ON : Outputs DTS BITSTREAM via digital
output only. Select DTS when connecting
to a DTS DECODER.
OFF : Doesn't output DTS signal.
DYNAMIC COMPRESSION
ON :To select dynamic compression.
OFF :To select the standard range.
1
1
Press the SETUP button when in stop
mode.
2
2
Use the UP/DOWN button to select A udio
Options.Then press the ENTER button.
3
3
Use the UP/DOWN button to select the
desired item.Then press the
LEFT/RIGHT button.
NOTES
1
2
1
2
1
2
･ If the selected language is not recorded on the disc, the original pre-recorded language is
selected.
･
Howto make the current Menu disappear and return to Setup Menu during set
up;
Press RETURN button.
Setting Up the Audio Options
AUDIO OPTIONS
1 Digital Output PCM
2 DTS Off
3 Dynamic Compression On
DV-P313U-EP22-4501.4.1010:47AMページ41
RETURN
ENTER
1
1
Press the SETUP button in stop mode.
2
2
Use the UP/DOWN button to select
Display Options.Then press the ENTER
button.
3
3
Use the UP/DOWN button to select
the desired item.Then press the ENTER
button or LEFT/RIGHT button.
TV ASPECT
Depending on the type of television you have, you
may want to adjust the screen setting (aspect ratio).
STILL MODE
Prevent picture shaking in still mode and display
small text clearer.
SCREEN MESSAGES
Use to turn on-screen messages on or off.
FRONT DISPLAY
Adjust the brightness of the unit's front panel display.
BLACK LEVEL
Adjust the brightness of screen.
4
4
Use the UP/DOWN button to select
the desired item. Press the
LEFT/RIGHT and then the ENTER
button.
TV ASPECT
4:3 LETTER BOX :
Select when you want to see the total 16:9 ratio
screen DVD supplies, even though you have a TV
with a 4:3 ratio screen.Black bars will appear at the
top and bottom of the screen.
4:3 PAN-SCAN :
Select this for conventional size TVs when you want
to see the central portion of the 16:9 screen.
(Extreme left and right side of movie picture will be
cut off.)
16:9 WIDE :
You can view the full 16:9 picture in your widescreen TV.
1
2
NOTE
･ Depending on the Disc, TV
Aspect selection may not
work.
42
ENGLISH
Setting Up the Display Options
1 TV Aspect 4:3 L-Box
2 Still Mode Auto
3 Screen Messages On
4 Front Display Auto Dim
5 Black Level Off
DISPLAY OPTIONS
3
DV-P313U-EP22-4501.4.1010:47AMページ42
RETURN
ENTER
43
ENGLISH
CHANGING
SETUP MENU
STILL MODE
FIELD : Select this feature when the screen shakes in
the AUTO mode.
FRAME : Select this feature when you want to see
small letters more clearly in the AUTO mode.
AUTO : When selecting AUTO, FIELD/FRAME mode
will be automatically converted.
SCREEN MESSAGES
Use this feature to turn the on-screen displays on or off
that appear in screen.
FRONT DISPLAY
BRIGHT : It makes the Front Panel Display bright.
DIM : It makes the Front Panel Display dim.
AUTO DIM : It makes the Front Panel Display dim
automatically when playing a DVD.
BLACK LEVEL
OFF:The screen appears dim.
On:The screen appears bright.
(Set to “OFF”at the factory.)
1
2
1
2
3
3
NOTES
･ Certain audio features of this product manufactured under a license from Desper
Products, Inc., Spatializer 3-D Stereo, Spatializer N-2-2 and the circle-in-square are
trademarks owned by Desper Products Inc.
･ Manufactured under license from Dolby Laboratories."Dolby", "Pro Logic" and the double-
D symbol are trademarks of Dolby Laboratories.Confidential unpublished works. 19921997 Dolby Laboratories Inc.All rights reserved.
･ DTS is a surround audio standard that offers 6 separate audio channels like the Dolby
Digital.To hear DTS sound, the DIGITAL AUDIO OUT must be connected to a DTS
compatible device.
R
c
Setting Up the Display Options
1
2
DV-P313U-EP22-4501.4.1010:47AMページ43
Before requesting service (troubleshooting)
No operations can be
performed with remote.
The screen ratio
cannot be changed.
No audio.
Playback mode differs
from the Setup Menu
selection.
Disc Menu doesn't
appear.
The icon appears
on screen.
Forgot password
If you experience other
problems.
5.1 channel sound is
not being reproduced.
Disc does not play.
･ Check the batteries in the remote. May need replacing.
･ Operate the remote control at a distance of no more than 20
feet.
･ Remove batteries and hold down one or more buttons for
several minutes to drain the microprocessor inside the
remote to reset it. Reinstall batteries and try remote again.
･ Ensure that the disc is installed with the label side facing up.
･ Check the region number of the DVD.
･ This player cannot play CD-ROMs, DVD-ROMs, CD-R, etc.
Insert a DVD, a VIDEO-CD or a CD.
･ 5.1 channel sound is reproduced only when the following
conditions are met. :
1)The DVD player is connected with the proper amplifier
2)The disc is recorded with 5.1 channel sound.
･ Check whether the disc being played has the "Dolby 5.1 ch"
mark on the outside.
･ Check if your audio system is connected and working properly.
･ The features or action cannot be completed at this time
because:
1.The DVD's software restricts it.
2. The DVD's software doesn't support the feature (e.g.,angles).
3.The feature is not available at the moment.
･ Check if the disc has a Menu.
･ Some of the functions selected in the Setup Menu may not
work properly if the disc is not encoded with the
corresponding function.
･ The Screen Ratio is fixed on your DVDs.
･ Make sure you have selected the correct Digital Output in
the Audio Options Menu.
･ Press power on from a cold start with no disc in the unit. Press
the STOP and PLAY buttons simultaneously on the front panel
for three seconds.The Select Menu Language display will
appear.Select the desired language button.Press the SETUP
button on the remote control to select the Parental Mode .The
Parental Mode is now unlock ed as indicated on the display.
Press the DOWN button to select P arental.Press ENTER and
the Create password will appear . You can no w set y our rating
level and Creat a new pass w ord.
･ Go to the contents and find the section of the instruction
book that contains the explanations regarding the current
problem, and follow the procedure once again.
･ If the problem still cannot be solved, please contact your
nearest authorized service center.
Action
Problem
Page
P6
P13
P21-22
P25-30
P33-38
P32-33
P38-44
P42-43
P41
P40
44
ENGLISH
Troubleshooting Guide
DV-P313U-EP22-4501.4.1010:47AMページ44
45
*: Nominal specification
2 Channel
*Frequency Response
*S/N Ratio
*Dynamic Range
*Total Harmonic Distortion
S-VIDEO
Composite Video
Component Video
VCD : 12 cm
CD : 8 cm
(COMPACT DISC)
CD : 12 cm
(COMPACT DISC)
DVD
(DIGIT AL VERSATILE DISC)
Operating T emper ature Range
Operating Humidity Range
Dimensions
Weight
Power Consumption
Power Requirements
AC 120 V, 60 Hz
15 W
2.7 kg
W 430 mm x D 240 mm x H 79mm
+5℃ to +35℃
10 % to 75 %
Reading Speed : 3.49 m/sec.
Approx.Play Time
(Single Sided, Single Layer Disc) :135 min.
Reading Speed : 1.2 to 1.4 m/sec.
Maximum Play Time : 74 min.
Reading Speed : 1.2 to 1.4 m/sec.
Maximum Play Time : 20 min.
Reading Speed : 1.2 to 1.4 m/sec.
Maximum Play Time : 74 min. (Video + Audio)
1 channel : 1.0 Vp-p (75 Ω load)
Y : 1.0 Vp-p (75 Ω load)
Pr : 0.70 Vp-p (75 Ω load)
Pb : 0.70 Vp-p (75 Ω load)
Luminance Signal : 1.0 Vp-p (75 Ω load)
Chrominance Signal : 0.286 Vp-p (75 Ω load)
L(1/L), R(2/R)
48 kHz Sampling : 4 Hz to 22 kHz
96 kHz Sampling : 4 Hz to 44 kHz
110 dB
100 dB
0.004 %
General
Disc
Video
Output
Audio
Output
･ Weight and dimensions are approximate.
ENGLISH
Specifications
DV-P313U-EP22-4501.4.1010:47AMページ45
Loading...
