Hitachi DESKSTAR Version 1.2 Partitioning and Formatting Guide
Partitioning and Formatting Guide
Version 1.2
Date 05-15-2006
Partitioning and Formatting Guide
This guide is designed to explain how to setup your drive with the correct
partition and format for your operating system. This guide will go over partitioning
and formatting drives in the following operating systems:
Windows 2000/XP Install Page 03
Windows 2000/XP Disk Management Page 07
Macintosh OS X Page 11
Linux Page 15
Windows 9.x and DOS Page 18
Macintosh OS 8.x and 9.x Page 21
This guide makes the assumption that the drive is properly installed in the system
and is being detected by the BIOS or controller card. If you need assistance
installing a drive, please view our Installation Guides at the following URL:
http://www.hitachigst.com/hdd/support/instgde.htm
For further assistance you may also contact one of our Technical Support
Centers:
http://www.hitachigst.com/hdd/support/sources/tsc.htm
All information is provided by Hitachi Global Storage Technologies on an "AS IS" basis only.
Hitachi makes no representations or warranties, whether express or implied, regarding the
information, including the warranty of non-infringement and non-interference and the implied
warranty or terms of merchantability, and fitness or use for a particular purpose.
Use of information that is provided by Hitachi is at the recipient's own risk. Hitachi provides no
assurances that any reported problems may be resolved with the use of any information that
Hitachi provides. By furnishing information, Hitachi does not grant any licenses to any copyrights,
trademarks, patents or any other intellectual property rights.
Any trademarks and product or brand names referenced in this document are the property of their
respective owners. Please consult your Hitachi product manuals for complete trademark
information.
Any references to third parties are provided as reference only and are not recommendations of
any products by Hitachi GST. Hitachi GST makes no warranty, implied or otherwise, regarding
the performance or reliability of these companies or products.
Hitachi Global Storage Technologies Partitioning and Formatting Guide version 1.2
2
Windows 2000/XP hard drive setup during
installation
To begin the installation of Windows 2000 / XP, you will need to insert the
bootable Windows CD into the CD drive. If you are installing from floppies, insert
the first floppy into drive A:. Turn the system on.
One of the first things you will see during the installation process is “Press F6 if
you need to install additional drivers…” The message only appears for 6 seconds
before the installation continues. You will need to press F6 to load additional
drivers if you are using a SCSI controller card, a SATA controller card, or a RAID
controller card that is not natively supported by Windows. Check with your
controller card manufacturer for the latest drivers.
*Wording on screenshots may differ slightly between Windows 2000 and XP.
Press "S" to specify the driver for the controller card.
Hitachi Global Storage Technologies Partitioning and Formatting Guide version 1.2
3
You are now presented with 3 options. For the purpose of this guide, press
Enter.
Before you can install the operating system you must press F8 and agree to the
license agreement.
In order to install an operating system, you will need a partition on which to
install. If a partition does not already exist, you must create one. To do this,
highlight the "Unpartitioned Space" and press "C", for Create.
Hitachi Global Storage Technologies Partitioning and Formatting Guide version 1.2
4
Enter the capacity you want for the new partition and press Enter. If you want to
use the entire space of the drive, press Enter without making any changes.
You will now be brought back to the screen which previously showed the
"Unpartitioned Space" taking up the whole drive. Now, it shows it as Partition1
[New <RAW>] (this means it has not yet been formatted). To continue with the
installation process and format the drive, highlight the new partition and press
Enter.
Hitachi Global Storage Technologies Partitioning and Formatting Guide version 1.2
5
You will be given format options for the partition: NTFS, NTFS (Quick), FAT, and
FAT (Quick). Only Windows XP gives the Quick format options. If the partition is
larger than 32GB's, you must choose NTFS.
*WARNING* Formatting will delete all data from the drive
The installation will now begin formatting the drive to your specifications.
Depending on the size of the partition, this could take anywhere from 2 minutes
to over an hour to format.
*Note: For drives larger than 137GB you will need Service Pack 3 for Windows
2000, Service Pack 1 for Windows XP, or a controller driver that supports 48 bit
addressing to format the full capacity during installation. Once the OS is installed, you may update the OS to the latest Service Pack and then partition the
remainder of the drive through Disk Management.
Hitachi Global Storage Technologies Partitioning and Formatting Guide version 1.2
6
Windows 2000/XP hard drive setup through Disk
Management
A hard drive must contain at least one formatted partition before it is usable. You
can use the Windows 2000/XP Disk Management tool to set up volumes or
partitions on your hard disk. With Disk Management, you can create and delete
partitions; format volumes using a FAT, FAT32, or NTFS file system; and setup
more advanced disk subsystems. You can perform most disk-related tasks
without the need to restart your computer as most configuration changes take
effect immediately upon committing the changes.
You should not attempt to make any changes to a partition from which the
operating system was booted, the system files are located, or the active paging
(swap) file is located.
To start Disk Management
1. Select Start, point to Settings, and then select Control Panel.
2. Open Administrative Tools, and then open Computer Management.
3. Alternatively, select Start, right click on My Computer and select Manage.
4. In the console tree, select Disk Management.
Note: You must be logged on as an Administrator or a member of the
Administrators group in order to use the Disk Management utility.
Hitachi Global Storage Technologies Partitioning and Formatting Guide version 1.2
