English - 1 -

Important safety precautions

The lightning ash with arrowhead symbol,

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO

NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

Don’t operate your TV in extreme ambient

conditions as this may cause damage to your TV.

Note: Follow the on screen instructions for operating the related
features.

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated
“dangerous voltage” within the product’s

enclosure that may be of sufcient magnitude

to constitute a risk of electric shock of persons.
The exclamation point within an equilateral

triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.

IMPORTANT - Please read these instructions fully before installing or operating

Preparation

Place the device on a solid even surface. For

ventilation, leave a free space of at least 10 cm all

around the set. To prevent any fault and unsafe

situations, do not place any objects on top of the set.

Use this device in moderate climates.
Operation temperature and operation humidity:

0ºC up to 40ºC, 85% rel. humidity max. (not blocking

ventilation openings).

Intended Use

This device is used to receive and display TV
programmmes. The different connection options make
an additional expansion of the reception and display
sources possible (various external devices). This device
is only suitable for dry interior use. This appliance is
intended solely for private domestic use and may not be
used for industrial and commercial purposes. We exclude

liability in principle, if the device is not used as intended, or
unauthorized modications have been made. To operate

your TV in extreme ambient conditions may cause the
damage of the device.

This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instructions concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.

Children may not recognize dangers. The
swallowing of batteries can be fatal. Keep batteries
always out of reach of small children. If a battery
is swallowed, seek immediate medical attention.

Keep the packaging lms out of reach of children,

there is a risk of suffocation.

Use this TV set at an altitude of less than 2000 meters

above the sea level, in dry locations and in regions with

To avoid danger of suffocation, keep plastic bags out of
the reach of the babies, children and domestic animals.

Carefully attach the stand to the TV. If the stand is

provided with screws, tighten the screws rmly to

prevent the TV from tilting. Do not over-tighten the
screws and mount the stand rubbers properly.

**************

Please read the following recommended safety
precautions carefully for your safety.

SOME DO’S AND DON’TS ON THE SAFE USE OF
EQUIPMENT

This equipment has been designed and manufactured

to meet international safety standards but, like any
electrical equipment, care must be taken if you are

to obtain the best results and safety is to be assured.
**************
DO read the operating instructions before you attempt

to use the equipment.
DO ensure that all electrical connections (including

the mains plug, extension leads and inter-connections

between the pieces of equipment) are properly made
and in accordance with the manufacturer’s instructions.
Switch off and withdraw the mains plug before making
or changing connections.

DO consult your dealer if you are ever in doubt about

the installation, operation or safety of your equipment.

DO be careful with glass panels or doors on equipment.
DO route the mains lead so that it is not likely to be

walked on, crushed, chafed, or subjected to excessive

wear and tear or heat.
**************

DON’T remove any xed cover as this may expose

dangerous voltages.
DON’T obstruct the ventilation openings of the

equipment with items such as newspapers, tablecloths,

moderate or tropical climates.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

2

curtains, etc. Overheating will cause damage and

shorten the life of the equipment.
DON’T allow electrical equipment to be exposed to

dripping or splashing, or objects lled with liquids, such
as vases, to be placed on the equipment.

DON’T place hot objects or naked ame sources
such as lighted candles or nightlights on, or close to

equipment. High temperatures can melt plastic and

lead to res.
DON’T use makeshift stands and NEVER x legs with

wood screws - to ensure complete safety always t the
manufacturer’s approved stand or legs with the xings

provided according to the instructions.

DON’T listen to headphones at high volume, as such

use can permanently damage your hearing.
DON’T leave equipment switched on when it is

unattended unless it is specically stated that it is

designed for unattended operation or has a stand-by

mode. Switch off using the switch, on the equipment

and make sure that your family know how to do this.

Special arrangements may need to be made for inrm

or handicapped people.
DON’T continue to operate the equipment if you are in

any doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and

consult your dealer.

ABOVE ALL

--- NEVER let anyone especially children push
anything into holes, slots or any other opening
in the case - this could result in a fatal electrical
shock;

--- NEVER guess or take chances with electrical
equipment of any kind

--- It is better to be safe than sorry!

Power source

• The TV should be operated only from a 220-240 V

AC, 50 Hz outlet.

WARNING: Do not leave your TV in standby or

operating mode when you leave your house.

Positioning the TV

• For ventilation, please leave a clear space of at least

10cm all around the TV.

• Do not place the TV on sloping or unstable surfaces,

the TV may tip over.

• To prevent damage to the TV, do not place any

objects on top of the TV.

Power cord and plug

• Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle
the power cord by the plug. Do not pull the plug by

holding its neck, as this could result in damage to the

plug. Do not unplug the appliance by pulling from the
power cord and never touch the power cord with wet
hands as this could cause a short circuit or electric
shock. Never make a knot in the cord or tie it with
other cords. The power cords should be placed in
such a way that they are not likely to be stepped on.

A damaged power cord can cause re or give you an

electric shock. When it is damaged and needs to be

replaced, it should be done by qualied personnel.

• This TV receiver is supplied with a moulded mains

plug. The mains plug must not be cut off, as it may
contain a special radio interference lter, the removal

of which could lead to impaired performance. If you

wish to extend the lead, obtain an appropriate safety

approved extension lead or consult your dealer.

• Observe the manufacturers instructions when
connecting extension leads to the set. Check the

fuse rating on the new plug; this should be tted with

a 5 Amp fuse which conforms to either ASTA or BSI

(BS1362) approvals, these are easily identiable by

either the

about the installation of an extension lead, please

consult a competent electrician.

ASA

or symbols. If you are in any doubt

Moisture and Water

• Do not use this TV in a humid or damp place (avoid

bathrooms, the sink in the kitchen, and near the

washing machine).

• Do not expose this TV to rain or water.

• Do not place objects lled with liquids, such as

ower vases, on top of the TV. Avoid from dripping

or splashing.

• If any solid object or liquid falls into the cabinet,
unplug the TV and have it checked by qualied

personnel before operating it any further.

Ventilation

• The slots and openings on the TV set are intended for
ventilation and to ensure reliable operation.

• To prevent overheating, these openings must not be

blocked or covered in anyway.

Heat sources and Flames

• Do not expose the TV to direct sunlight or other
heat sources.

• Do not block the ventilation openings.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 3 -

• The TV should not be placed near to open ames

and sources of intense heat such as an electric
heater.

• Ensure that no open ame sources, such
as lit candles, are placed on top of the TV.

Headphone Volume

• Excessive sound pressure from earphones
and headphones can cause hearing loss,

please take care.

Wall Mounting (optional)

• To prevent injury, this TV must be securely attached to

the wall in accordance with the installation instructions
(if the option is available).

LCD Screen

• Occasionally, a few non-active pixels may appear
on the screen as a xed blue, green or red point.

Please note that this does not affect the performance
of your product.

• Take care not to scratch the screen with ngernails
or other hard objects.

Cleaning

• Before cleaning, unplug the TV from the wall socket.

• Do not use liquid or aerosol cleaners. Only use a

soft, dry cloth.

Batteries

WARNING: Incorrect installation of batteries

may cause battery leakage and corrosion, resulting
in damage to the remote control.

• Do not mix old and new batteries, or batteries of different

types.

• Do not dispose of batteries in a re.

• Do not dispose of batteries with normal

household waste, take to a local

recycling centre.

CAUTION: Insert the batteries /
rechargeable batteries in the correct polarity. Don´t
try to recharge non rechargeable batteries and under

no circumstances throw them into re. Danger of

explosion. Do not use unequal batteries (old and new,
Alkaline and carbon, etc.) simultaneously. If you will not
use the device for a long time, remove the batteries and
store the device in a dry and dust free place. Improper
use of batteries may cause an explosion or leakage.
If the batteries have leaked, use gloves and clean
the appliance thoroughly with a dry cloth! Batteries
should not be exposed to heat, such as sunshine,

re or the like.

which are specied by the manufacturer or have the
same specications as the original one. Unauthorised
substitutions may result in re, electrical shock or

other hazards.

Taking out of service and storing

Unplug the TV from the mains and pack the TV in
an appropriate cardboard box. Remove the batteries
from the remote control and pack the remote control
with the TV set.

NOTE: The TV set should be stored in a dry and

dust-free room.

Connection to a Television Distribution
System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protective
earthing-and to a television distribution system using

coaxial cable, may in some circumstances create a
re hazard.

Connection to a cable distribution system has therefore
to be provided through a device providing electrical
isolation below a certain frequency range (galvanic

isolator, see EN 60728-11).

CAUTION

Do not put your ngers in the middle between the TV
and stand, especially when you carry the TV, as they
may be injured.

Replacement Parts

When replacement parts are required, make sure that
the service technician has used replacement parts,

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 4 -

WARNING

Do not ingest the battery, Chemical Burn Hazard

This product or the accessories supplied with the
product may contain a coin/button cell battery. If

the coin/button cell battery is swallowed, it can ca­use severe internal burns in just 2 hours and can

lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close secu-

rely, stop using the product and keep it away from

children.
If you think batteries might have been swallowed or

placed inside any part of the body, seek immediate

medical attention.

WARNING

Never place a television set in unstable or inclined

locations. A television set may fall, causing serious
personal injury or death. Many injuries, particularly
to children, can be avoided by taking simple preca-

utions such as;

• Using cabinets or stands recommended by the
manufacturer of the television set.

• Only using furniture that can safely support the
television set.

• Ensuring the television set is not overhanging the
edge of the supporting furniture.

• Not placing the television set on tall furniture
(for example, cupboards or bookcases) without

anchoring both the furniture and the television set
to a suitable support.

• Not standing the television set on cloth or other
materials placed between the television and
supporting furniture.

• Educating children about the dangers of climbing
on furniture to reach the television set or its
controls. If your existing television set is being

retained and relocated, the same considerations

as above should be applied.

WALL MOUNTING WARNINGS

• Read the instructions before mounting your TV
on the wall.

• The wall mount kit is optional. You can obtain from
your local dealer, if not supplied with your TV.

• Do not install the TV on a ceiling or on an inclined

wall.

• Use the specied wall mounting screws and other

accessories.

• Tighten the wall mounting screws rmly to prevent

the TV from fall. Do not over-tighten the screws.

WARNING

Apparatus connected to the protective earthing of
the building installation through the MAINS conne­ction or through other apparatus with a connection
to protective earthing – and to a television distri-

bution system using coaxial cable, may in some
circumstances create a re hazard. Connection

to a television distribution system has therefore to
be provided through a device providing electrical
isolation below a certain frequency range (galvanic

isolator, see EN 60728-11)

Symbols in this Instruction Book

The following symbols are used in the Instruction
Book as a marker for restrictions and precautions
and safety instructions. Note such information for
security reasons.

WARNING

If you do not pay attention to such a marked warning, it
can cause serious injury or death. Note these warnings
strictly, in order to ensure a safe operation.

CAUTION

Such a precaution is marked, you should take up or
note, to avoid injury or property damage. Note these
instructions strictly, in order to ensure a safe operation.

IMPORTANT

Warnings on the appliance and restrictions are
displayed like this. Read this information strictly in order
to operate the system correctly and avoid damage.

NOTE

Information about the operation and additional
explanations are marked like this. To be aware of
such information is recommended to ensure that the
functions can be used optimally.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 5 -

Markings on the Product

The following symbols are used on the product as a
marker for restrictions and precautions and safety
instructions. Each explanation shall be considered
where the product bears related marking only. Note
such information for security reasons.

Class II Equipment: This appliance is
designed in such a way that it does not require
a safety connection to electrical earth.

Class II Equipment With Functional
Earthing: This appliance is designed in such

a way that it does not require a safety

connection to electrical earth, the earth

connection is used for functional purposes.

Protective Earth Connection: The marked
terminal is intended for connection of the
protective earthing conductor associated with

the supply wiring.

Hazardous Live Terminal: The marked
terminal(s) is/are hazardous live under normal
operating conditions.

Caution, See Operating Instructions: The
marked area(s) contain(s) user replaceable

i

coin or button cell batteries.

Class 1 Laser Product:

CLASS 1
LASER PRODUCT

This product contains
Class 1 laser source that
is safe under reasonably
foreseeable conditions of
operation.

The illustrations and the OSD in this operation manual
are for explanation purposes and may vary slightly from
the actual operations.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 6 -

Support

Technical experts are available 7 days a week

• Simple help and advice on setting up your
digital equipment (image).

• Guidance on connecting other devices to your
television such as a DVD player, Sky, home
cinema system or a games console.

• Order spare parts, including that lost remote
control.

• Any other technical issues you may need
assistance with.

Call us today: 0 345 604 0105

Local call rates applies*

Lines open 9am-8pm Monday to Saturday and 10am-4pm Sunday

*Calls to Argos enquiry lines may attract a charge and set up fee from residential
lines depending on your call plan/tariff. Mobile and other providers costs may vary,
see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from customer service

centres maybe recorded and monitored. Calls from Republic of Ireland will attract
international call charges.

For online detailed guides and further assistance please use the link below

https://www.argos-support.co.uk/7907302)

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 7 -

Environmental Information

This television is designed to be environment friendly.

To reduce energy consumption, you can follow these

steps:
If you set the Energy Saving to Minimum, Medium,

Maximum or Auto the TV will reduce the energy
consumption accordingly. If you like to set the

Backlight to a xed value set as Custom and adjust

the Backlight (located under the Energy Saving
setting) manually using Left or Right buttons on the
remote. Set as Off to turn this setting off.

Note: Available Energy Saving options may differ depending
on the selected Mode in the Picture menu.

The Energy Saving settings can be found in the
Picture menu. Note that some picture settings will be

unavailable to be changed.
If pressed Right button while Auto option is selected or

Left button while Custom option is selected, “Screen
will be off in 15 seconds.” message will be displayed
on the screen. Select Proceed and press OK to turn
the screen off immediately. If you don’t press any
button, the screen will be off in 15 seconds. Press
any button on the remote or on the TV to turn the
screen on again.

Note: Screen Off option is not available if the Mode is set
to Game.

When the TV is not in use, please switch off or

disconnect the TV from the mains plug. This will also

• PC input

• Game Mode (Optional)

• Picture off function

• Ethernet (LAN) for Internet connectivity and service

• 802.11 a/b/g/n built in WIFI Support

• Audio Video Sharing

Accessories Included

• Remote Control

• Batteries: 2 x AAA

• Instruction Book

• Quick Start Guide

• Side AV Connection Cable

Standby Notications

If the TV does not receive any input signal (e.g. from
an aerial or HDMI source) for 3 minutes, it will go

into standby. When you next switch-on, the following

message will be displayed: “TV switched to stand-by

mode automatically because there was no signal
for a long time.” Press OK to continue.

If the TV is on and it isn’t being operated for a while

it will go into standby. When you next switch-on, the

following message will be displayed. “TV switched to

stand-by mode automatically because no operation
was made for a long time.” Press OK to continue.

TV Control Switch & Operation

reduce energy consumption.

Features

• Remote controlled colour TV

• Fully integrated digital terrestrial TV (DVB-T-T2)

• HDMI inputs to connect other devices with HDMI

sockets

• USB input

• OSD menu system

• Scart socket for external devices (such as DVD

Players, PVR, video games, etc.)

• Stereo sound system

• Teletext

• Headphone connection

• Automatic programming system

• Manual tuning

• Automatic power down after up to eight hours.

• Sleep timer

• Child lock

• Automatic sound mute when no transmission.

• NTSC playback

• AVL (Automatic Volume Limiting)

• PLL (Frequency Search)

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

1. Up direction

2. Down direction

3. Volume / Info / Sources List selection and

Standby-On switch

The Control button allows you to control the Volume
/ Programme / Source and Standby-On functions of
the TV.

To change volume: Increase the volume by pushing
the button up. Decrease the volume by pushing the
button down.

To change channel: Press the middle of the button,

the information banner will appear on the screen.
Scroll through the stored channels by pushing the
button up or down.

English - 8 -

To change source: Press the middle of the button

twice(for the second time in total), the source list will

appear on the screen. Scroll through the available
sources by pushing the button up or down.

To turn the TV off: Press the middle of the button

down and hold it down for a few seconds, the TV will

turn into standby mode.
Notes:

• If you turn the TV off, this circle starts again beginning

with the volume setting.

• Main menu OSD cannot be displayed via control
button.

Operation with the Remote Control

Press the Menu button on your remote control to
display main menu screen. Use the directional buttons
to select a menu tab and press OK to enter. Use the
directional buttons again to select or set an item. Press

Return/Back or Menu button to quit a menu screen.

Input Selection

Once you have connected external systems to your
TV, you can switch to different input sources. Press the
Source button on your remote control consecutively
to select the different sources.

Changing Channels and Volume

You can change the channel and adjust the volume

by using the Volume +/- and Programme +/- buttons
on the remote.

Inserting the Batteries into the Remote

Lift the cover on the back of the remote gently. Insert
two AAA batteries. Make sure the (+) and (-) signs
match (observe correct polarity). Place the cover
back on.

License Notication

The terms HDMI and HDMI High-Denition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator,

Inc. in the United States and other countries.

Manufactured under license from Dolby Laboratories.

Dolby, Dolby Audio and the double-D symbol are

trademarks of Dolby Laboratories.
YouTube and the YouTube logo are trademarks of

Google Inc.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and DTS
TruSurround is a trademark of DTS, Inc.© DTS, Inc.

All Rights Reserved.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and DTS

2.0+Digital Out is a trademark of DTS, Inc.© DTS, Inc.

All Rights Reserved.

This product contains technology subject to certain

intellectual property rights of Microsoft. Use or
distribution of this technology outside of this product
is prohibited without the appropriate license(s) from

Connect Power

IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket. After unpacking, allow the

TV set to reach the ambient room temperature before
you connect the set to the mains. Plug the power cable
to the mains socket outlet.

Antenna Connection

Connect the aerial plug to the AERIAL INPUT (ANT)
socket located on the back of the TV.

Microsoft.
Content owners use Microsoft PlayReady™ content

access technology to protect their intellectual property,

including copyrighted content. This device uses
PlayReady technology to access PlayReady-protected
content and/or WMDRM-protected content. If the
device fails to properly enforce restrictions on content

usage, content owners may require Microsoft to revoke

the device’s ability to consume PlayReady-protected
content. Revocation should not affect unprotected
content or content protected by other content access
technologies. Content owners may require you to
upgrade PlayReady to access their content. If you

decline an upgrade, you will not be able to access

content that requires the upgrade.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 9 -

Disposal information

Instructions for waste disposal:

Packaging and packaging aids are recyclable and should

principally be recycled. Packaging materials, such as foil
bag, must be kept away from children. Batteries, including
those which are heavy metal-free, should not be disposed

of with household waste. Please dispose of used battery
in an environment friendly manner. Find out about the
legal regulations which apply in your area.

Don’t try to recharge batteries. Danger of explosion.
Replace batteries only with the same or equivalent type.

Information for Users in European Union Countries

The mark shown on the right is in compliance
with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE).
The mark indicates the requirement NOT
to dispose the equipment including any
spent or discarded batteries as unsorted

municipal waste, but use the return and

collection systems available. If the batteries
or accumulators included with this equipment

display the chemical symbol Hg, Cd, or Pb,

then it means that the battery has a heavy

metal content of more than 0.0005% Mercury,
or more than 0.002% Cadmium or more than,

0.004% Lead.

Specication

TV Broadcasting

Receiving Channels

Digital Reception

Number of Preset
Channels

Channel Indicator On Screen Display

RF Aerial Input 75 Ohm (unbalanced)

Operating Voltage 220-240V AC, 50Hz.

Audio DTS TruSurround

Audio Output Power
(WRMS.) (10% THD)

Power Consumption (W) 140

Networked Standby (W) < 3

Weight (Kg) 14,50

TV Dimensions DxLxH
(with foot) (mm)

TV Dimensions DxLxH
(without foot) (mm)

Display 55”

Operation temperature
and operation humidity

PAL BG/I/DK
SECAM BG/DK

VHF (BAND I/III) - UHF
(BAND U) - HYPERBAND

Fully integrated digital
terrestrial-TV
(DVB-T2)

1 000

2 x 8

276 x 1248 x 787

63/96 x 1248 x 741

0ºC up to 40ºC, 85%

humidity max

Wireless LAN Transmitter Specications

Frequency Ranges Max Output Power

2400 - 2483,5 MHz (CH1-CH13) < 100 mW

5150 - 5250 MHz (CH36 - CH48) < 200 mW

5250 - 5350 MHz (CH52 - CH64) < 200 mW

5470 - 5725 MHz (CH100 ­CH140)

Country Restrictions

This device is intended for home and ofce use in all

EU countries (and other countries following the rele­vant EU directive) without any limitation except for the
countries mentioned below.

Country Restriction

Bulgaria

France In-door use only for 2454-2483.5 MHz

Italy

Greece

Luxembourg

Norway

Russian Fed­eration

General authorization required for outdoor
use and public service

If used outside of own premises, general

authorization is required
In-door use only for 5470 MHz to 5725

MHz band
General authorization required for network

and service supply(not for spectrum)
Radio transmission is prohibited for the

geographical area within a radius of 20 km
from the centre of Ny-Ålesund

In-door use only

The requirements for any country may change at any
time. It’s recommended that user checks with local
authorities for the current status of their national reg­ulations for both 2.4 GHz and 5 GHz wireless LAN’s.

< 200 mW

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 10 -

Remote Control

(*) MY BUTTON:

This button may have a default function depending on the
model. However you can set a special function to this button

by pressing on it for ve seconds when on a desired source
or channel. A conrmation message will be displayed on

the screen. Now the MY BUTTON is associated with the
selected function.

Note that if you perform First Time Installation, MY BUTTON
will return to its default function.

1. Source: Shows all available broadcast and content
sources

2. Netix: Launches the Netix application.

3. YouTube: Launches the YouTube application

4. Play: Starts to play selected media

5. No Function

6. Rapid reverse: Moves frames backwards in media

such as movies

7. Language: Displays and changes audio/subtitle
language (digital TV, where available)

8. Red button

9. Green button

10. Numeric buttons: Switches the channel, enters a

number or a letter in the text box on the screen

11. TV: Switches to TV Source

12. Menu: Displays TV menu

13. Internet: Opens the portal page, where you can reach

many web based applications

14. Volume +/-

15. Back/Return: Returns to previous screen, opens index

page (in TXT mode)

16. Favourites: Displays user specied favourite channels

17. Screen: Changes the aspect ratio of the screen

18. My button 1 (*)

19. Media browser: Opens the media browsing screen

20. Text: Displays teletext (where available), press again

to superimpose the teletext over a normal broadcast
picture (mix)

21. EPG (Electronic programme guide): Displays the
electronic programme guide

22. Mute: Completely turns off the volume of the TV

23. Info: Displays information about on-screen content

24. Exit: Closes and exits from displayed menus or returns

to previous screen

25. OK: Conrms user selections, holds the page (in TXT
mode), views channel list (DTV mode)

26. Programme + / -

27. Directional buttons: Helps navigate menus, content etc.

and displays the subpages in TXT mode when pressed
Right or Left

28. Quick Menu: Displays a list of menus for quick access

29. Swap: Quickly cycles between previous and current

channels or sources

30. Yellow button

31. Blue button

32. Subtitles: Turns subtitles on and off (where available)

33. Rapid advance: Moves frames forward in media such

as movies

34. Stop: Stops the media being played

35. Pause: Pauses the media being played

36. Freeview Play: Connects to the Freeview Play platform

where you can access available catch-up TV services

37. Standby: Switches On / Off the TV

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 11 -

Connections

Connector Type Cables Device

Scart

Connection

(back)

VGA

Connection

(back)

SIDE AV

SPDIF

SIDE AV

HEADPHONE

YPBPR

PC/YPbPr

Audio

Connection

(side)

HDMI

Connection

(back)

SPDIF

(Optical Out)

Connection

(back)

Side AV

(Audio/Video)

Connection

(side)

Headphone
Connection

(side)

YPbPr Video

Connection

(back)

USB

Connection

(side)

Side Audio/Video

Connection Cable

Side Audio/Video

Connection Cable

PC to YPbPr Connection Cable

YPbPr/PC Audio

Cable

Audio/Video

Cable

See the illustrations on the l eft
side. You can use YPbPr to VGA
cable to enable YPbPr signal via
VGA input. You cannot use VGA
and YPbPr at the same time. To

enable PC/YPbPr audio, you will

need to use the Side AV input
with a YPbPr/PC audio cable
for audio connection, using
the Side AV connection cable’s
RED and WHITE inputs. If an
external device is connected via

the SCART socket, the TV will

automatically switch to EXT1
mode. When receiving DTV
channels (Mpeg4 H.264) or while

in Media Browser mode, output

will not be available via the scart
socket. When using the wall
mounting kit (available from a

third party in the market, if not
sup plied ), we recommend that

you plug all your cables into the
back of the TV before mounting
on the wall. Insert or remove the
CI module only when the TV is
SWITCHED OFF. You should refer
to the module instruction manual
for details of the settings. The

USB input of your TV supports

devices up to 500mA. Connecting
devices that have current value
above 500mA may damage your
TV. When connecting equipment

using a HDMI cable to your TV,

to guarantee sufcient immunity
against parasitic frequency

radiation, you have to use a high

speed shielded (high grade) HDMI
cable with ferrites.

CI

Connection

(side)

LAN

If you want to connect a device to the TV, make sure that both the TV and the device are turned off before making
any connection. After the connection is done, you can turn on the units and use them.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Ethernet

Connection

(back)

LAN / Ethernet Cable

English - 12 -

CAM

module

Switching On/Off

To Switch the TV On

Connect the power cord to a power source such as a

wall socket (220-240V AC, 50 Hz).

To switch on the TV from standby mode either:

• Press the “ ” button, Programme +/- or a numeric
button on the remote control.

• Press the the middle of side function switch on the
TV in.

To Switch the TV Off

Press the “ ” button on the remote control or press
the middle of the side function switch on the TV in and

hold it down for a few seconds, the TV will switch into

standby mode.

To power down the TV completely, unplug the
power cord from the mains socket.

Note: When the TV is switched into standby mode, the standby
LED can blink to indicate that features such as Standby
Search, Over Air Download or Timer is active. The LED can
also blink when you switch on the TV from standby mode.

First Time Installation

When turned on for the first time, the language

selection screen is displayed. Select the desired
language and press OK.

On the next screen, set your preferences using the

directional buttons.

Note: Depending on the Country selection you may be asked

to set and conrm a PIN at this point. The selected PIN cannot
be 0000. You have to enter it if you are asked to enter a PIN

for any menu operation later.

About Selecting Broadcast Type

Digital Aerial: If Digital Aerial broadcast search

option is turned on, the TV will search for digital

terrestrial broadcasts after other initial settings are
completed.

Additionally you can set a broadcast type as your
favourite one. Priority will be given to the selected
broadcast type during the search process and the
channels of it will be listed on the top of the Channel
List. When nished, press OK to continue.

You can activate Store Mode option at this point.

This option will congure your TV’s settings for store

environment and depending on the TV model being

used, the supported features of it may be displayed on

the top of the screen as an info banner. This option is
intended only for store use. It is recommended to select
Home Mode for home use. This option will be available
in Settings>More menu and can be turned off/on later.

Depending on the model of your TV and the country
selection Privacy Settings menu may appear at
this point. Using this menu you can set your privacy
privileges. Highlight a feature and use Left and Right
directional buttons to enable or disable. Read the

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

related explanations displayed on the screen for
each highlighted feature before making any changes.
You can use Programme +/- buttons to scroll up
and down to read the entire text. You will be able to
change your preferences at any time later from the

Settings>Privacy Settings menu. If the Internet
Connection option is disabled Network/Internet
Settings screen will be skipped and not displayed.

Press OK button on the remote control to continue and
the Network/Internet Settings menu will be displayed,

if you conrm the previously displayed message asking

whether you want to do the network settings. Please
refer to Connectivity section to congure a wired or a
wireless connection. After the settings are completed
press OK button to continue. To skip to the next step
without doing anything select No and press the OK
button when the message is displayed asking whether
you want to do the network settings.

On the next screen you need to agree to the terms
and conditions of Freeview Play to make use of the
related services. Scroll the page to read the entire text
using the up/down directional buttons or Programme
+/- buttons. Highlight Yes and press OK on the remote

to conrm and proceed. Highlight No and press OK to
proceed without conrmation. For further requirements

for Freeview Play services refer to the Freeview Play
Platform section.

After the initial settings are completed TV will start
to search for available broadcasts of the selected
broadcast types.

After all the available stations are stored, scan results

will be displayed. Press OK to continue. The Edit
Channel List menu will be displayed next. You can

edit the channel list according to your preferences or
press the Menu button to quit and watch TV.

While the search continues a message may appear,

asking whether you want to sort channels according
to the LCN(*). Select Yes and press OK to conrm.

(*) LCN is the Logical Channel Number system that organizes
available broadcasts in accordance with a recognizable

channel number sequence (if available).

Note: Do not turn off the TV while initializing first time
installation. Note that, some options may not be available

depending on the country selection.

Media Playback via USB Input

You can connect 2.5” and 3.5” inch (hdd with external power
supply) external hard disk drives or USB memory stick to your
TV by using the USB inputs of the TV.

IMPORTANT! Back up the les on your storage devices

before connecting them to the TV. Manufacturer will

not be responsible for any le damage or data loss.

Certain types of USB devices (e.g. MP3 Players)
or USB hard disk drives/memory sticks may not be
compatible with this TV. The TV supports FAT32 and
NTFS disk formatting.

Wait a little while before each plugging and unplugging

as the player may still be reading les. Failure to do

English - 13 -

so may cause physical damage to the USB player
and the USB device itself. Do not pull out your drive

while playing a le.

You can use USB hubs with your TV’s USB inputs.
External power supplied USB hubs are recommended
in such a case.

It is recommended to use the TV’s USB input(s)

directly, if you are going to connect a USB hard disk.

Note: When viewing image les the Media Browser menu
can only display 1000 image les stored on the connected

USB device.

Media Browser Menu

You can play photo, music and movie les stored on a

USB disk by connecting it to your TV. Connect a USB
disk to one of the USB inputs located on the side of
the TV. Pressing the Menu button while in the Media

Browser mode will access the Picture, Sound and
Settings menu options. Pressing the Menu button
again will exit from this screen. You can set your Media
Browser preferences by using the Settings menu.

Loop/Shufe Mode Operation

Start playback with the Play
button and activate

Start playback with the OK
button and activate

Start playback with the Play
button and activate

Start playback with the Play
button and activate ,

All les in the list will be

continuously played in original
order

The same le will be played

continuously (repeat)

All les in the list will be played

once in random order

All les in the list will be

continuously played in the same
random order.

FollowMe TV (if available)

With your mobile device you can stream the current
broadcast from your smart TV using the FollowMe
TV feature. Install the appropriate Smart Center
application to your mobile device. Start the application.
For further information on using this feature refer to
the instructions of the application you use.

Note: This application may not be compatible with all mobile
devices. HD channels are not supported and both of the
devices must be connected to the same network.

CEC and CEC RC Passthrough

This function allows to control the CEC-enabled

devices, that are connected through HDMI ports by

using the remote control of the TV.
The CEC option in the Settings>More menu should be

set as Enabled at rst. Press the Source button and
select the HDMI input of the connected CEC device
from the Sources List menu. When new CEC source

device is connected, it will be listed in source menu

with its own name instead of the connected HDMI ports

name(such as DVD Player, Recorder 1 etc.).

The TV remote is automatically able to perform the
main functions after the connected HDMI source has
been selected.

To terminate this operation and control the TV via the

remote again, press Quick Menu button on the remote,

highlight the CEC RC Passthrough and set as Off by
pressing Left or Right button. This feature can also be
enabled or disabled under the Settings>More menu.

The TV supports also ARC(Audio Return Channel)
feature. This feature is an audio link meant to replace
other cables between the TV and the audio system
(A/V receiver or speaker system).

When ARC is active, TV does not mute its other audio

outputs automatically. So you need to decrease TV

volume to zero manually, if you want to hear audio from

connected audio device only (same as other optical or
co-axial digital audio outputs). If you want to change

connected device’s volume level, you should select

that device from the source list. In that case volume
control keys are directed to connected audio device.

Note: ARC is supported only via the HDMI1 input.

System Audio Control

Allows an Audio Amplier/Receiver to be used with

the TV. The volume can be controlled using the
remote control of the TV. To activate this feature set
the Speakers option in the Settings>More menu as
Amplier. The TV speakers will be muted and the
sound of the watched source will be provided from the
connected sound system.

Note: The audio device should support System Audio Control
feature and CEC option should be set as Enabled.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 14 -

TV Menu Contents

Picture Menu Contents

Sharpness

Reset

Mode

Contrast Adjusts the light and dark values on the screen.

Brightness Adjusts the brightness values on the screen.

Colour Sets the colour value, adjusting the colours.

Energy Saving

Backlight

Advanced Settings

Dynamic Contrast You can change the dynamic contrast ratio to desired value.

Noise Reduction

Colour Temp

White Point

Picture Zoom Sets the desired image size format.

Film Mode

Skin Tone Skin tone can be changed between -5 and 5.

Colour Shift Adjust the desired colour tone.

HDMI Full Range

PC Position Appears only when the input source is set to VGA/PC.

Autoposition Automatically optimizes the display. Press OK to optimize.

H Position This item shifts the image horizontally to the right hand side or left hand side of the screen.

V Position This item shifts the image vertically towards the top or bottom of the screen.

Dot Clock

Phase

While in VGA (PC) mode, some items in Picture menu will be unavailable. Instead, VGA mode settings will be added to the Picture Settings
while in PC mode.

You can change the picture mode to suit your preference or requirements. Picture mode can be
set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural.

Sets the sharpness value for the objects displayed on the screen.

For setting the Energy Saving to Custom, Minimum, Medium, Maximum, Auto, Screen
Off or Off.

Note: Available options may differ depending on the selected Mode.

This setting controls the backlight level. The backlight function will be inactive if the Energy
Saving is set to an option other then Custom.

If the signal is weak and the picture is noisy, use the Noise Reduction setting to reduce the
amount of noise.

Sets the desired colour temperature value. Cool, Normal, Warm and Custom options are
available.

If the Colour Temp option is set as Custom, this setting will be available. Increase the
‘warmth’ or ‘coolness’ of the picture by pressing Left or Right buttons.

Films are recorded at a different number of frames per second to normal television programmes.

Turn this feature on when you are watching lms to see the fast motion scenes clearly.

While watching from a HDMI source, this feature will be visible. You can use this feature to

enhance blackness in the picture.

Dot Clock adjustments correct the interference that appear as vertical banding in dot

intensive presentations like spreadsheets or paragraphs or text in smaller fonts.

Depending on the input source(computer etc.) you may see a hazy or noisy picture on the
screen. You can use phase to get a clearer picture by trial and error.

Resets the picture settings to factory default settings (except Game mode).

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 15 -

Sound Menu Contents

Volume Adjusts the volume level.

Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode.

Balance Adjusts whether the sound comes from the left or right speaker.

Headphone

Sound Mode You can select a sound mode (If the viewed channel supports).

AVL (Automatic Volume
Limiting)

Headphone/Lineout

Dynamic Bass Enables or disables the Dynamic Bass.

DTS TruSurround Enables or disables the DTS TruSurround.

Digital Out Sets digital out audio type.

Sets headphone volume.

Please ensure before using headphones that the headphone volume is set to a low level, to

prevent damage to your hearing.

Sets the sound to obtain xed output level between programmes.

When you connect an external amplier to your TV using the headphone jack, you can

select this option as Lineout. If you have connected headphones to the TV, set this option
as Headphone.

Please ensure before using headphones that this menu item is set to Headphone. If it is
set to Lineout, the output from the headphone socket will be set to maximum which could
damage your hearing.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 16 -

Settings Menu Contents

Conditional Access Controls conditional access modules when available.

Language You may set a different language depending on the broadcaster and the country.

Privacy Settings (*)

Parental

Timers Sets sleep timer to turn off the TV after a certain time. Sets timers for selected programmes.

Date/Time Sets date and time.

Sources Enables or disables selected source options.

Network/Internet
Settings

Accessibility Displays accessibility options of the TV.

Hard of Hearing Enables any special feature sent from the broadcaster.

Audio Description

Netix

More Displays other setting options of the TV.

Menu Timeout Changes timeout duration for menu screens.

Standby LED If set as Off the standby LED will not light up when the TV is in standby mode.

Software Upgrade Ensures that your TV has the latest rmware. Press OK to see the menu options.

Application Version Displays current software version.

Subtitle Mode

Auto TV OFF

Store Mode

Audio Video
Sharing

Manage your privacy privileges for smart TV related applications. Press OK to enter the menu
and set according to your preferences.

Enter correct password to change parental settings. You can easily adjust Menu Lock,
Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or
change the Default CICAM PIN using the related options.

Note: Some menu options may not be available depending on the country selection in the
First Time Installation. Default PIN can be set to 0000 or 1234. If you have dened the

PIN(is requested depending on the country selection) during the First Time Installation use
the PIN that you have dened.

Displays network/internet settings.

A narration track will be played for the blind or visually impaired audience. Press OK to
see all available Audio Description menu options. This feature is available only if the
broadcaster supports it.

You can view your ESN(*) number and deactivate Netix.

(*) ESN number is an unique ID number for Netix, created especially to identify your TV.

This option is used to select which subtitle mode will be on the screen (DVB subtitle / Teletext
subtitle) if both is available. Default value is DVB subtitle. This feature is available only for the
country option of Norway.

Sets the desired time for the TV to automatically go into standby mode when not being
operated. This option can be set from 1 to 8 hours in steps of 1 hour. You can also disable
this option by setting as Off.

Select this mode for store display purposes. Whilst Store Mode is enabled, some items in
the TV menu may not be available.

Audio Video Sharing feature allows you to share les stored on your smartphone or tablet pc. If
you have a compatible smartphone or tabl et pc and the appropriate software is installed, you can

share/play photos on your TV. See instructions of your sharing software for more information. Audio
Video Sharing mode will not be available with internet portal feature.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 17 -

Power Up Mode

Virtual Remote Enable or disable the virtual remote feature.

CEC

CEC Auto Power On

Speakers

Show All Cookies (*) Displays all saved cookies.

Delete All Cookies (*) Deletes all saved cookies.

OSS Displays Open Source Software license information.

(*) These features may not be available depending on the model of your TV and the selected country in the First Time Installation.

This setting congures the power up mode preference. Last State and Standby options are
available.

With this setting you can enable and disable CEC functionality completely. Press Left or
Right button to enable or disable the feature.

This function allows the connected HDMI-CEC compatible device to turn on the TV and switch
to its input source automatically. Press Left or Right button to enable or disable the feature.

To hear the TV audio from the connected compatible audio device set as Amplier. You can
use the remote control of the TV to control the volume of the audio device.

Installation Menu Contents

Automatic
channel scan
(Retune)

Manual channel
scan

Network
channel scan

First time
installation

Displays automatic tuning options. Digital Aerial: Searches and stores aerial DVB stations.

This feature can be used for direct broadcast entry.

Searches for the linked channels in the broadcast system. Digital Aerial: Searches for aerial
network channels. Digital Cable: Searches for cable network channels.

Deletes all stored channels and settings, resets TV to factory settings.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 18 -

General TV Operation

Using the Channel List

The TV sorts all stored stations in the Channel List.

You can edit this channel list, set favourites or set

active stations to be listed by using the Channel List
options. Press the OK/TV button to open the Channel

List. You can lter the listed channels by pressing the
Blue button or open the Edit Channel List menu by

pressing the Green button in order to make advanced
changes in the current list.

Managing the Favourite Lists

You can create four different lists of your favourite
channels. Enter the Channel List in the main menu
or press the Green button while the Channel List
is displayed on the screen in order to open the Edit
Channel List menu. Select the desired channel on the
list. You can make multiple choices by pressing the

Yellow button. Then press the OK button to open the
Channel Edit Options menu and select Add/Remove
Favourites option. Press the OK button again. Set the

desired list option to On. The selected channel/s will
be added to the list. In order to remove a channel or
channels from a favourite list follow the same steps
and set the desired list option to Off.

You can use the Filter function in the Edit Channel

List menu to lter the channels in the Channel list

permanently according to your preferences. Using this

Filter option, you can set one of your four favourite lists
to be displayed everytime the Channel list is opened.

The ltering function in the Channel list menu will only
lter the currently displayed Channel list in order to
nd a channel and tune in to it. These changes will

not remain the next time the Channel list is opened if
you don’t save them. To save the changes on the list
press the Red button after ltering while the Channel
list is displayed on the screen.

Conguring Parental Settings

The Parental Settings menu options can be used to

prohibit users from viewing of certain programmes,

channels and using of menus. These settings are
located in the Settings>Parental menu.

To display parental lock menu options, a PIN number

should be entered. After coding the correct PIN

number, Parental Settings menu will be displayed.
Menu Lock: This setting enables or disables access

to all menus or installation menus of the TV.
Guidance: This setting enables or disables access

some of the MHEG applications. Disabled applications
can be released by entering the right PIN.

Set PIN: Denes a new PIN number.
Default CICAM PIN: This option will appear as greyed

out if no CI module is inserted into the CI slot of the

TV. You can change the default PIN of the CI CAM
using this option.

Note: Default PIN can be set to 0000 or 1234. If you have
defined the PIN(is requested depending on the country
selection) during the First Time Installation use the PIN that
you have dened.

Some options may not be available depending on the model
and/or on the country selection in the First Time Installation.

Electronic Programme Guide (EPG)

Some channels send information about their broadcast
schedules. Press the Epg button to view the
Programme Guide menu.

There are 3 different types of schedule layouts

available, Timeline Schedule, List Schedule and
Now/Next Schedule. To switch between them follow

the instructions on the bottom of the screen.

Timeline Schedule

Zoom (Yellow button): Press the Yellow button to

see events in a wider time interval.

Filter (Blue button): Views ltering options.
Select Genre (Subtitles button): Displays Select
Genre menu. Using this feature, you can search the

programme guide database in accordance with the
genre. Info available in the programme guide will be
searched and results matching your criteria will be
highlighted.

Options (OK button): Displays event options.
Event Details (Info button): Displays detailed

information about selected events.
Next/Prev Day (Programme +/- buttons): Displays
the events of previous or next day.

Search (Text button): Displays Guide Search menu.
Now (Red button): Displays current event of the

highlighted channel.

List Schedule(*)

(*) In this layout option, only the events of the highlighted
channel will be listed.

Prev. Time Slice (Red button): Displays the events
of previous time slice.
Next/Prev Day (Programme +/- buttons): Displays
the events of previous or next day.
Event Details (Info button): Displays detailed
information about selected events.

Filter (Text button): Views ltering options.
Next Time Slice (Green button): Displays the events

of next time slice.

Options (OK button): Displays event options.

Now/Next Schedule

Navigate (Directional buttons): Press the Directional
buttons to navigate through the channels and events.
Options (OK button): Displays event options.
Event Details (Info button): Displays detailed

information about selected events.

Filter (Blue button): Views ltering options.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 19 -

Event Options

Use the directional buttons to highlight an event and
press OK button to display Event Options menu. The
following options are available.

Select Channel: Using this option, you can switch to

the selected channel.
Set Timer on Event / Delete Timer on Event: After

you have selected an event in the EPG menu, press the

OK button. Select Set Timer on Event option and press
the OK button. You can set a timer for future events.

To cancel an already set timer, highlight that event and

press the OK button. Then select Delete Timer on Event
option. The timer will be cancelled.

Notes: You cannot switch to any other channel or source while
there is an active timer on the current channel.

It is not possible to set timer for two or more individual events
at the same time interval.

Integrated Catch-Up Services

You can enjoy Freeview Play catch-up TV services

that work directly through the electronic programme
guide(EPG). Whilst you are on a channel use the
directional buttons to scroll back in time through the
timeline-based EPG. You will see contents from last
few days. Available catch-up contents may change
according to broadcasters and will be marked with a
play icon. Highlight the content you want to play back
and press the OK button.

Make sure that your TV is connected to your home
network in order to use the catch-up services. For
further information regarding this matter and other
requirements for Freeview Play services refer to the

Connectivity and Freeview Play Platform sections.

Teletext Services

Press the Text button to enter. Press again to activate

mix mode, which allows you to see the teletext page

and the TV broadcast at the same time. Press once

more to exit. If available, sections in the teletext pages

will become colour-coded and can be selected by
pressing the coloured buttons. Follow the instructions
displayed on the screen.

Digital Teletext

Press the Text button to view digital teletext information.

Operate it with the coloured buttons, cursor buttons

and the OK button. The operation method may differ
depending on the contents of the digital teletext. Follow
the instructions displayed on the digital teletext screen.

When the Text button is pressed again, the TV returns

to television broadcast.

BBC Red Button+ (RB+)

While watching BBC channels, press the Red button

to access Red Button+ services provided by the BBC.
On the opening page you can access to BBC’s main

services such as BBC iPlayer, BBC News, BBC Sport

navigation buttons on the TV’s remote control to
move through the application. Press Exit button to
close and exit.

Software Upgrade

Your TV is capable of nding and updating the rmware

automatically via the broadcast signal or via Internet.

Software upgrade search via user interface

On the main menu select Settings and then More.
Navigate to Software upgrade and press the OK
button. In Upgrade options menu select Scan for
upgrade and press OK button to check for a new
software upgrade.

If a new upgrade is found, it starts to download

the upgrade. After the download is completed
confirm the question asking about rebooting the
TV by pressing the OK to continue with the reboot
operation.

3 AM search and upgrade mode

Your TV will search for new upgrades at 3:00 o’clock if
Automatic scanning option in the Upgrade options
menu is set to Enabled and if the TV is connected
to an aerial signal or to Internet. If a new software is

found and downloaded successfully, it will be installed

at the next power on.

Note: Do not unplug the power cord while led is blinking during

the reboot process. If the TV fails to come on after the upgrade,
unplug, wait for two minutes then plug it back in.

Troubleshooting & Tips

Tv will not turn on

Make sure the power cord is plugged in securely to
wall outlet. Check if batteries are exhausted. Press the
Power button on the TV.

Poor picture

• Check if you have selected the correct TV system.

• Low signal level can cause picture distortion. Please

check antenna access.

• Check if you have entered the correct channel
frequency if you have done manual tuning.

• The picture quality may degrade when two devices
are connected to the TV at the same time. In such a

case, disconnect one of the devices.

No picture

• This means your TV is not receiving any transmission.
Make sure the correct source has been selected.

• Is the antenna connected properly?

• Is the antenna cable damaged?

• Are suitable plugs used to connect the antenna?

• If you are in doubt, consult your dealer.

and many others. There are also links to the home
pages of the related applications available. Use the

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 20 -

No sound

• Check if the TV is muted. Press the Mute button or
increase the volume to check.

• Sound may be coming from only one speaker. Check
the balance settings from Sound menu.

Remote control - no operation

• The batteries may be exhausted. Replace the
batteries.

Input sources - can not be selected

• If you cannot select an input source, it is possible

that no device is connected. If not;

• Check the AV cables and connections if you are
trying to switch to the input source dedicated to the
connected device.

To Program Your SKY Remote For Your TV

1. Make sure your SKY box is connected to your TV

2. Turn your TV and SKY box on

3. Press TV on your SKY remote control handset

4. Hold down SELECT and the RED button together

for about two seconds, until the red light on the

SKY remote blinks twice.

5. Key in 1177 on your SKY remote. The light on the
SKY remote should blink twice

6. Press the STANDBY button on your SKY remote
control. Your TV should now switch off.

7. Press SELECT again. The light on your SKY
remote control should now blink twice

You should now be able to control some basic functions
on your TV from your SKY remote control (e.g. volume

up/down, programme up/down).

*If this number does not work, please go to SKY website to

nd the alternative number to operate the TV.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 21 -

PC Input Typical Display Modes

The following table is an illustration of some of the
typical video display modes. Your TV may not support
all resolutions.

Index Resolution Frequency

1 640x480 60Hz

2 640x480 75Hz

3 800x600 56Hz

4 800x600 60Hz

5 800x600 72Hz

6 800x600 75Hz

7 1024x768 60Hz

8 1024x768 70Hz

9 1024x768 75Hz

10 1152x864 75Hz

11 1280x768 60Hz

12 1360x768 60Hz

13 1280x960 60Hz

14 1280x1024 60Hz

15 1280x1024 75Hz

16 1400x1050 60Hz

17 1440x900 60Hz

18 1440x900 75Hz

19 1920x1080 60Hz

AV and HDMI Signal Compatibility

Source Supported Signals Available

PAL O

EXT

(SCART)

SECAM O

NTSC4.43 O

NTSC3.58 O

RGB 50/60 O

PAL O

Side AV

SECAM O

NTSC4.43 O

NTSC3.58 O

480i, 480p 60Hz O

YPbPr

576i, 576p 50Hz O

720p 50Hz,60Hz O

1080i 50Hz,60Hz O

480i, 480p 60Hz O

576i, 576p 50Hz O

720p 50Hz,60Hz O

HDMI

1080i 50Hz,60Hz O

1080p

24Hz, 25Hz,
30Hz, 50Hz,

60Hz

O

(X: Not Available, O: Available)

In some cases a signal on the TV may not be displayed
properly. The problem may be an inconsistency with

standards from the source equipment (DVD, Set-top
box, etc. ). If you do experience such a problem please

contact your dealer and also the manufacturer of the
source equipment.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 22 -

Supported Video File Formats for USB Mode

Extension Video Codec Max. Resolution & Frame Rate & Bit Rate

.mpg, .mpeg, .dat, .vob

.ts, .trp, .m2ts

.avi MPEG1/2, MPEG4, H.264, MJPEG

.mp4, .m4a, .m4v, .mov, .qt,
.3gp, .3g2, .3gpp

.mkv MPEG 1/2, MPEG4, H.264

.v Sorenson Sp, MPEG4, H.264

.ogm, .ogg MPEG1/2, MPEG4

.asf, .wmv MPEG4, WMV3, VC1

.rm, .rmvb RV30, RV40

.webm VP9, VP8

.mp4, .mov, .3gpp, .3gp,
MPEG transport stream,
.ts,.trp, .tp, .mkv

MPEG1/2, H.264, VC1

MPEG1/2, H.263, MPEG4, H.264

HEVC/H.265

H.264: 1080Px2@30fps - 50Mbps, 1080P@60fps -
50Mbps Other: 1080P@60fps - 50Mbps

Supported Picture File Formats for USB Mode

Extension Specication Resolution (width x height)

.jpg, .jpeg

.bmp

.gif

.png

.tiff, .tif Tagged image le format

.webp

Baseline 8192 x 8192

Progressive 3000 x 3000

RGB 1/4/8/16/24/32 bit

RLE 4/8 bit

87a

89a (Only 1 picture at animation format)

Grayscale, 24/32 bit per pixel

Interlace format

Progressive

Lossy compression VP8 key frame version number support 0~3

Lossless compression

8192 x 8192

Supported Audio File Formats for USB Mode

Extension Format

.mp3 .mp3
.ac3 .ac3
.aac .AAC
.wma .WMA
.amr .AMR-NB, .AMR-WB
.wav . MPEG La, .AAC, .PCM
.ac . FLAC

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 23 -

Supported Subtitle File Formats for USB Mode

External Subtitles

Extension Specication

.ssa SubStation Alpha

.ass Advanced SubStation Alpha

.srt Subripper

.sub Micro DVD / SubViewer

.sub + .idx VOBSub

.txt Micro DVD / TMPlayer / MPL2

.mpl MPL2

.smi Sami

.jss JACOSUB

.ttml TTML

.txt / .sub DVDSUBTITLE

.lrc -

Internal Subtitles

Extension

.mkv VOBSub
.mkv ASS / SSA / TEXT
.dat, .mpg, .mpeg, .vob DVD Subtitle
.mp4 DVD Subtitle, TEXT

Specication

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 24 -

Supported DVI Resolutions

When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not

supplied), you can refer to the following resolution information.

56Hz 60Hz 66Hz 70Hz 72Hz 75Hz

640x400

640x480

800x600

832x624

1024x768

1152x864

1152x870
1280x768
1360x768
1280x960

1280x1024

1400x1050

1440x900

1600x1200

1680x1050
1920x1080

þ þ þ þ

þ þ þ þ þ

þ þ þ þ þ

þ þ þ

þ þ

þ

þ þ

þ þ

þ þ

þ þ

þ

þ

þ

þ

þ

þ

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 25 -

Connectivity

Wired Connectivity

To Connect to a Wired Network

• You must have a modem/router connected to an
active broadband connection.

• Connect your TV to your modem/router via an
ethernet cable. There is a LAN port at the rear (back)
of your TV.

Broadband ISP connection

LAN (ethernet) cable

LAN input on the rear
side of the TV

To congure wired settings please refer to the

Network/Internet Settings section in the Settings
Menu.

• You might be able to connect your TV to your LAN
depending on your network’s conguration. In such
a case, use an ethernet cable to connect your TV

directly to the network wall outlet.

network

wall socket

LAN input on the rear
side of the TV

Conguring Wired Device Settings

Network Type

The Network Type can be selected as Wired Device,
Wireless Device or Disabled, in accordance with the
active connection to the TV set. Select this as Wired
Device if you are connecting via an ethernet cable.

Internet Speed Test

Highlight Internet Speed Test and press the OK but-
ton. TV will check the internet connection bandwidth
and display the result when complete.

Advanced Settings

Highlight Advanced Settings and press the OK
button. On the next screen you can change the IP and
DNS settings of the TV. Highlight the desired one and
press Left or Right button to change the setting from

Automatic to Manual. Now you can enter the Manual
IP and / or Manual DNS values. Select the related item

in the drop down menu and enter the new values using
the numeric buttons of the remote. Press the OK button
to save settings when complete.

Wireless Connectivity

To Connect to a Wireless Network

The TV cannot connect to the networks with a hidden

SSID. To make your modem’s SSID visible, you should

change your SSID settings via the modem’s software.

Broadband
ISP
connection

A Wireless-N router (IEEE 802.11a/b/g/n) with
simultaneous 2.4 and 5 GHz bands is designed to
increase bandwidth. These are optimized for smoother

and faster HD video streaming, le transfers and

wireless gaming.

• The frequency and channel differ depending on
the area.

• The transmission speed differs depending on the
distance and number of obstructions between the

transmission products, the conguration of these
products, the radio wave conditions, the line trafc

and the products that you use. The transmission may
also be cut off or may get disconnected depending

on the radio wave conditions, DECT phones or any

other WiFi 11b appliances. The standard values of
the transmission speed are the theoretical maximum
values for the wireless standards. They are not the
actual speeds of data transmission.

• The location where the transmission is most effective
differs depending on the usage environment.

• The Wireless feature of the TV supports 802.11 a,b,g

& n type modems. It is highly recommended that you
should use the IEEE 802.11n communication protocol
in order to avoid any possible problems while watching
videos.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 26 -

• You must change your modem’s SSID when there are
any other modems around with the same SSID. You
can encounter connection problems otherwise. Use a
wired connection if you experience problems with a
wireless connection.

Conguring Wireless Device Settings

Open the Network/Internet Settings menu and select
Network Type as Wireless Device to start connection

process.
The TV will scan the wireless networks automatically.

A list of available networks will be displayed. Please
select your desired network from the list.

Note: If the modem supports N mode, you should set N

mode settings.

If the selected network is protected with a password,

please enter the correct key by using the virtual keyboard.
You can use this keyboard via the directional buttons and

the OK button on the remote control.
Wait until the IP address is shown on the screen.
This means that the connection is now established. To

disconnect from a wireless network, highlight Network
Type and press Left or Right buttons to set as
Disabled.

Highlight Internet Speed Test and press the OK button
to check your internet connection speed. Highlight
Advanced Settings and press the OK button to open
the advanced setting menu. Use directional and numeric
buttons to set. Press the OK button to save settings
when complete.

Other Information

The status of the connection will be displayed as
Connected or Not Connected and the current IP

address, if a connection is established.

Connecting to your mobile device via WiFi

• If your mobile device has WiFi feature, you can connect
it to your TV via a router, in order to access the content
in your device. For this, your mobile device must have

an appropriate sharing software.

• Connect to your router following the steps stated above
in the Wireless Connectivity section.

• Afterwards, engage your mobile device with the router and

then activate the sharing software on your mobile devic e.

Then, select les that you want to share with your TV.

• If the connection is established correctly, you will be
able to access the shared les from your mobile device

via the Media Browser of your TV.

• Enter the Media Browser menu and the playback
device selection OSD will be displayed. Select your
mobile device and press the OK button to continue.

• If available, you can download a virtual remote

controller application from the server of your mobile
device application provider.

Note: This feature may not be supported on all mobile

devices.

Wake ON

Wake-on-LAN (WoL) and Wake-on-Wireless LAN
(WoWLAN) are standards that allow a device to be
turned on or woken up by a network message. The
message is sent to the device by a program executed
on a remote device connected to the same local area

network, such as a smartphone.

Your TV is WoL and WoWLAN compatible. To enable
this feature set the Wake On option in the Network/
Internet Settings menu as On. It is necessary that

both the device, from which the network message will
be sent to the TV, and the TV are connected to the

same network. Wake On feature is only supported for
Android OS devices and can only be used via YouTube

and Netix applications.

In order to use this feature the TV and the remote
device should be connected at least once while the TV

is on. If the TV is powered off, the connection should be
reestablished, the next time it is switched on. Otherwise
this feature will be unavailable. This does not apply,

when the TV is switched into the standby mode.

The performance of some devices in the market, may

vary due to the software architecture. In order to use

Wake On feature with a better performance, please
make sure that your device has latest rmware version.

Wireless Display

Wireless Display is a standard for streaming video and
sound content by Wi-Fi Alliance. This feature provides
the ability to use your TV as wireless display device.

Using with mobile devices

There are different standards which enable sharing of

screens including graphical, video and audio content

between your mobile device and TV.

Plug the wireless USB dongle to TV rst, if the TV

doesn’t have internal WiFi feature.
Then press the Source button on the remote and

switch to Wireless Display source.
A screen appears stating that the TV is ready for

connection.
Open the sharing application on your mobile device.

These applications are named differently for each

brand, please refer to the instruction manual of your

mobile device for detailed information.

Scan for devices. After you select your TV and connect,

the screen of your device will be displayed on your TV.

Note: This feature can be used only if the mobile device
supports this feature. Scanning and connecting processes
differ according to the programme you use. Android based

mobile devices should have the software version V4.2.2

and above.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 27 -

Connectivity Troubleshooting

Wireless Network Not Available

• Ensure that any rewalls of your network allow the

TV wireless connection.

• Try searching for wireless networks again, using the

Network/Internet Settings menu screen.

If the wireless network does not function properly, try

using the wired network in your home. Refer to the
Wired Connectivity section for more information on
the process.

If the TV does not function using the wired connection,

check the modem (router). If the router does not have a

problem, check the internet connection of your modem.

Connection is Slow

See the instruction book of your wireless modem to

get information on the internal service area, connection
speed, signal quality and other settings. You need to have

a high speed connection for your modem.

Disruption during playback or slow reactions

You could try the following in such a case:
Keep at least three meters distance from microwave

ovens, mobile telephones, bluetooth devices or any

other Wi-Fi compatible devices. Try changing the active
channel on the WLAN router.

Internet Connection Not Available / Audio Video
Sharing Not Working

If the MAC address (a unique identier number) of your
PC or modem has been permanently registered, it is

possible that your TV might not connect to the internet.

In such a case, the MAC address is authenticated

each time when you connect to the internet. This is a
precaution against unauthorized access. Since your

TV has its own MAC address, your internet service

provider cannot validate the MAC address of your TV.

For this reason, your TV cannot connect to the internet.

Contact your internet service provider and request

information on how to connect a different device, such
as your TV, to the internet.

It is also possible that the connection may not be

available due to a rewall problem. If you think this
causes your problem, contact your internet service
provider. A rewall might be the reason of a connectivity

and discovery problem while using the TV in Audio
Video Sharing mode or while browsing via Audio Video
Sharing feature.

Invalid Domain

Ensure that you have already logged on to your PC with
an authorized username/password and also ensure

that your domain is active, prior to sharing any les in

your media server program on your PC. If the domain

is invalid, this might cause problems while browsing
les in Audio Video Sharing mode.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 28 -

Using Audio Video Sharing Network Service

Audio Video Sha ring feature uses a standard that eases
the viewing process of digital electronics and makes them
more convenient to use on a home network.

This standard allows you to view and play photos, music

and videos stored in the media server connected to your
home network.

1. Server Software Installation

The Audio Video Sharing feature cannot be used if the
server programme is not installed onto your PC or if
the required media server software is not installed onto
the companion device. Please prepare your PC with a
proper server programme.

2. Connect to a Wired or Wireless Network

See the Wired/Wireless Connectivity chapters for

detailed conguration information.

3. Play Shared Files via Media Bro wser

Select Media Browser by using the directional buttons
from the main menu and press OK. The media browser
will then be displayed.

Audio Video Sharing

Select the desired media type on the main media browser
menu and press OK. If sharing congurations are set
properly, Device Selection screen will be displayed
after selecting the desired media type. If available

networks are found, they will be listed on this screen.

Select media server or network that you want to
connect to using the Up or Down buttons and press

OK. If you want to refresh the device list, press the
Green button. You can press Menu to exit.

If you select the media type as Videos and choose
a device from the selection menu. Then select the

folder with video les in it on the next screen and all
the available video les will be listed.

To play other media types from this screen, you can go

back to main Media Browser screen and select the
media type as desired and then perform the network
selection again. Or press the Blue button to switch to
next media type quickly without changing the network.
Refer to the Media Browser menu section for further

information on le playback.

If a problem occurs with the network, please switch

your television off at the wall socket and back on again.
Trick mode and jump are not supported with the Audio
Video Sharing feature.

PC/HDD/Media Player or any other devices that are
compatible should be used with a wired connection for
higher playback quality.

Use a LAN connection for quicker le sharing between

other devices like computers.

Note: There may be some PC’s which may not be able to
utilize the Audio Video Sharing feature due to administrator
and security settings (such as business PC’s).

Internet Portal

HINT: A broadband internet connection is required

for high quality viewing. You must set the country
option accordingly in the First Time Installation
for proper operation of the internet portal.

Portal feature adds your TV a feature that allows you to
connect a server on the Internet and view the content
provided by this server over your Internet connection.

Portal feature allows you to view the music, video, clip
or web content with dened short-cuts. Whether you

can view this content without interruption depends
on the connection speed provided by your internet
service provider.

Press the Internet button on your remote control
to open internet portal page. You will see icons of
the available applications and services on the portal
screen. Use the directional buttons on your remote
to select the desired one. You may view the desired
content by pressing OK after selecting. Press Back/
Return button to return back to the previous screen.

Moreover, you can access some features using the
short-cut feature dened for the coloured or numeric

buttons of your remote.
Press the Exit button to quit the Internet portal mode.

PIP Window (depending on portal service)

Current source content will be displayed in the PIP

window, if you switch to portal mode while on any

active source.
If you switch to portal mode while watching TV

channels, current programme will be displayed in the

PIP window.

Notes:

Possible application dependent problems may be caused by

the content service provider.

Portal service content and the interface may be changed at

any time without prior notice.

Third party internet services may change, be discontinued or
restricted at any time.

iPlayer Application

You can access BBC iPlayer using your TV. Select BBC
iPlayer application among the portal options.

Press the OK button on your remote control to start
the BBC iPlayer application.

Note: Broadband internet connection (minumum 2mbps) is
required for high quality viewing.

Playing a Programme via iPlayer

Select a programme and press OK button. The
programme playback will begin.

You can press the Pause button to pause playback.
Press the Play button to resume the playback.

Use the Stop button to stop the playback.

Press the Exit button to exit iPlayer. Press the Return
/Back button for going back to the previous screen.

Note: “Episode is unavailable” message may be displayed
on the screen if a problem occurs during the playback.

Searching a Programme

Highlight the Search tab using the navigation buttons
and press the OK button. Use the virtual keyboard to
type the letters. Select letters and press the OK button.
The results will be listed below. Highlight the desired
one and wait until the related videos appear. Select
one among the videos using the directional buttons and
press the OK button to start the playback.

Note: There are also some other BBC applications such as

Sport and News available on the portal.

Freeview Play Platform

Freeview Play platform provides catch-up TV and
On Demand services. Simply press the Freeview
Play button on your remote control to connect to the
Freeview Play platform.

The Freeview Play platform can also be accessed from
the main menu or internet portal. Press Menu button
and select Internet. Then highlight Freeview Play and
press the OK button. Or open the internet portal of the
TV and select the Freeview Play among available
applications. Then press the OK button.

You will have to agree to the terms and conditions for

Freeview Play services rst if you did not agree them

during the First Time Installation. Highlight Yes and
press OK on the remote to conrm and proceed.

Integrated TV Player applications will be displayed.
Select one and press the OK button. Then select a
content that you want to play back and press the OK
button to watch.

Catch-up contents can also be accessed and played
back directly from the TV Guide. Refer to the section
Electronic Programme Guide (EPG) for more
information.

Requirements

The Freeview Play services may only be used if the

following requirements are fullled:

• Connecting the TV to the internet. A minimum broad-

band speed of 2Mbps is required for proper operation
of catch up and on demand services.

• Agreeing to the terms and conditions of Freeview
Play

Note: Freeview Play platform usage will count towards any

monthly broadband data allowance. Only selected channels
provide 7-day catch up.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 29 -

Integrated Catch-Up Services

Note: Before connecting to the Freeview Play platform,

make sure that you follow the steps below, otherwise

you will not be able to access the Freeview Play
platform:

• Connect aerial to the back of TV and carry out digital
channel scan

• Connect TV to the internet (via WiFi or Ethernet)

• Accept the T&Cs to enable Freeview Play services

• A minimum broadband speed of 2Mbps is required

to watch catch up and on demand services

This will count towards any monthly broadband data
allowance. Only selected channels provide 7-day
catch up.

Without the Aerial and internet connection you will not
be able to access the Freeview Play platform.

3. Freeview Play via the TV’s Smart Portal

Bring up the Smart Portal on your TV, Freeview Play
will be one of the applications displayed on the rst

page. Once the Freeview play app is selected it will
direct you to the same Freeview play portal seen

above, where you can choose what programme you’d

like to watch.

Accessing Freeview Play catch-up TV
services

1. Freeview Play via the Electronic Programme

Guide (EPG)

Simply scroll backwards in your programme guide
to access Freeview Play. Available catch-up content
will be marked with a Play icon. Highlight the content
and press the OK button and select playback option.

Note: The content available on EPG is driven by

TV channels themselves and will only display if the
channel content is available. When you select a

programme, Freeview Play will directly launch the

catch up service. If you wish to watch Demand 5 on

Freeview Play, please use the other options listed

below to access the catch up service.

2. Freeview Play via the ‘FPlay button’

Click Freeview Play button on your remote control.

This will bring up the Freeview Play portal, where you

can choose the channel and programme to watch
with ease.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 30 -

Internet Browser

To use the internet browser, enter the portal rst. Then

launch the Internet application on the portal.

(*) The appearance of the internet browser logo may change

In the initial screen of the browser, the thumbnails of
the predened (if any) links to web sites available will

be displayed as Speed Dial options along with the
Edit Speed Dial and the Add to Speed Dial options.

To navigate the web browser, use the directional

buttons on the remote or a connected mouse. To see

the browser options bar, move the cursor to the top of

the page or press the Back/Return button. History,
Tabs and Bookmarks options and the browser bar

which contains previous/next buttons, the refresh
button, the adress/search bar, the Speed Dial and the

Opera buttons are available.
To add a desired website to the Speed Dial list for

quick access, move the cursor to the top of the page

or press the Back/Return button. The browser bar will
appear. Highlight the Speed Dial - button and press
the OK button. Then select Add to Speed Dial option
and press the OK button. Fill in the blanks for Name
and Address, highlight OK and press the OK button
to add. Whilst you are on the site you wish to add to
the Speed Dial list, highlight the Opera- button and
press the OK button. Then highlight Add to Speed

Dial option in the submenu and press the OK button
again. Name and Address will be lled automatically
according to the site you are visiting. Highlight OK and
press the OK button to add.

You can also use the Opera menu options to manage
the browser. Highlight the Opera- button and press
the OK button to see available page specic and
general options.

There are various ways to search or visit websites
using the web browser.

Enter the address of a website(URL) into the search/

address bar and highlight the Submit button on the
virtual keyboard and press the OK button to visit the
site.

Enter keyword/s into the search/address bar and

highlight the Submit button on the virtual keyboard
and press the OK button to start a search for the
related websites.

Highlight a Speed Dial thumbnail and press the OK

button to visit the related website.

Your TV is compatible with USB mice. Plug your mouse
or wireless mouse adaptor into the USB input of your
TV for easier and quicker navigation.

Some web pages include ash content. These are not

supported by the browser.
Your TV does not support any download processes

from the internet via the browser.
All sites on the internet might not be supportted.

According to the site; content problems may occur.
In some circumstances video contents might not be
able to be played.

Smart Center

Smart Center is a mobile application running on iOS

and Android platforms. With your tablet or phone,

you can easily stream your favourite live shows and
programmes from your smart TV. Also; you can launch

your portal applications, use your tablet as a remote
control for your TV and share media les.

Note: Being able to use all functions of this application
depends on the features of your TV.

Getting Started

To use Smart Center features, connections have to

be done properly. To get connected to your network

wirelessly, plug in the Wi-Fi dongle to one of the USB
ports if your TV doesn’t have internal wi feature. To
be able to use internet based features, your modem/

router must be connected to the internet.

IMPORTANT: Make sure the TV and mobile device
are connected to the same network.

For media sharing feature Audio Video Sharing option
should be enabled(if available). Press the Menu button

on the remote, select Settings>More menu and press
OK. Highlight Audio Video Sharing and change as

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Enabled. Your TV is ready to connect to your mobile
device now.
Install the Smart Center application onto your mobile
device.

Start the smart center application. If all connections are

congured properly, you will see your TV’s name on

your mobile device. If your TV’s name doesn’t appear
on the list, wait a while and tap on the Refresh widget.
Select your TV from the list.

Mobile Device screen

On the main screen you can find tabs to access
various features.

The application retrieves actual channel list from TV

rst when it starts.

MY CHANNELS: The programmes of first four
channels from the channel list retrieved from the TV
are shown. You can change the listed channels. Press
on the channel thumbnail and hold. A list of channels
will be displayed and you can choose your desired
channel to be replaced.

TV: You can watch content through the TV tab. In
this mode you can navigate through the channel list
retrieved from your TV and click on thumbnails to view
the detail pages.

RECORDINGS: You can view your active recordings(if
available) and reminders through this tab. To delete

any item, simply press on the delete icon found on

each row.
EPG: You can view the broadcast schedules of

selected channel lists through this tab. You can also
navigate through channels by pressing on the selected
channel on the EPG grid. Please note that updating
/ refreshing the EPG information may take a while
depending on your network and web service quality.

Note: Internet connection is required for WEB based EPG

informations.

PORTAL: This tab displays the Portal applications in
scrollable view. Unless FollowMeTV (if available) is

active, the selected application will be displayed on

your TV screen.

Note: Internet connection is required. This tab is enabled if a
portal page is in use.

SETTINGS: Congure the application to your liking.

You can change;

Auto-lock (Only in IOS): The screen of the device
automatically turns off after a certain amount of

time. Default is off, which means the screen will

always stay on.
Auto-enable FollowMeTV: FollowMeTV function (if

available) will start automatically when this setting
is enabled. Default is disabled.

Auto-connection to TV: When enabled, your

mobile device will automatically connect to last
connected TV and skips the TV search screen.

English - 31 -

Change TV (Only in IOS): Shows the currently

connected TV. You can press on this setting to go to
the “TV search” screen and change to a different TV.

Edit custom channel list: You can edit your custom
channel list using this setting.

Choose channel list source: You can choose the
channel list source to be used in the application. The
options are “TV List” and “Custom List”. Additionally
you can activate “Remember my choice” option to
set the selected channel list source as a constant
choice. In this case if the selected source is available
it will be used in the application.

Version No: Displays the current version of the
application.

Detail Page

To open detail page tap on a programme. On the
detail page screen you can get detailed information

of the programmes you select. There are “Details”,
“Cast&Crew” and “Videos” tabs to nd on this page.

DETAILS: This tab provides summary and information
about the selected programme. Also there are links to
facebook and twitter pages of the programme selected.

CAST&CREW: Shows all the people contributed to
the current programme.

VIDEOS: Provides videos on Youtube related to the
selected programme.

Note: For some functions an internet connection may be
required.

FollowMe TV Feature (if available)

Tap on the FOLLOW ME TV widget located at the
bottom left of the screen of your mobile device to
change the layout for FollowMe TV feature.

Tap the play icon to start streaming of the content from
the TV to your mobile device. Available if your device
is in your routers operation range.

Notes:

Note that only digital(DVB-T/C/S) SD channels are supported.

Multilanguage audio support and subtitle on/off features are
not functional.

The streaming performance may change depending on the
quality of your connection.

Media Share Page

To access the Media Share widget tap on the Up­arrow on the bottom left side of the screen.

If the Media Share widget is pressed, a screen is
displayed where you can select the media le type to

share with your TV.

Note: Not all image le formats are supported. This function

will not work if Audio Video Sharing feature is not supported.

Portal Launcher

To access the Portal Launcher( ) widget tap on
the Up-arrow on the bottom left side of the screen.

You can access the portal page by tapping on the
Portal Launcher widget.

Note: Internet connection is required. This function will not
work if a portal page is not in use.

Smart Remote Feature

You can use your mobile device as a remote control
for your TV once it has connected to the TV. To use
smart remote’s full features tap on the Up-arrow on
the bottom left side of the screen.

Voice Recognation

You can tap on the Microphone( ) widget and

manage your application, giving voice commands
such as “Portal!”, “Volume Up/Down!”, “Programme

Up/Down!”.

Note: This feature is only for android based devices available.

Keyboard Page

The keyboard page can be opened in two ways; by
pressing the Keyboard( ) widget on the application
screen or automatically by receiving a command
from the TV.

Requirements

1. Smart TV

2. Network connection

3. Mobile Device based on Android or iOS platform

(Android OS 4.0 or higher; IOS 6 or higher version)

4. Smart Center app.(to be found on online
application stores based on Android and iOS
platforms)

5. Router modem

6. USB storage device in FAT32 format (required for

PVR feature, if available)

Notes:

For Android devices, Normal(mdpi), Large(hdpi) and Extra
Large(xhdpi) screen sizes are supported. Devices with 3” or
smaller screen sizes are not supported.

For iOS devices, all screen sizes are supported.

User interface of the Smart Center application is subject to
change according to version installed on your device.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 32 -

DVB-T functionality information

This DVB receiver is only suitable for use in the country
which it was designed to be used in.

Although this DVB receiver conforms to the latest DVB

specications at the time of manufacture, we cannot

guarantee compatibility with future DVB transmissions
due to changes that may be implemented in broadcast
signals and technologies.

Some digital television functions may not be available
in all countries.

We continually strive to improve our products;

therefore, specications may change without prior

notice.

For advice on where to purchase accessories,

please contact the store where you purchased your
equipment.

Internet Portal functionality information

The content and services available through the
SmarTVue portal are provided by third-party providers

and may be altered, suspended or discontinued at any

time without notice.

Hitachi is not responsible for any of the content or
services and does not warrant the availability of or
access to such content or services.

For information on a particular service or on any

content, please visit the service/content provider’s
website. If you have any questions concerning, or
problems with, any content or services then please

contact the relevant service/content provider directly.
Hitachi is not responsible for providing customer
service in relation to content or services and accepts

no liability in this regard.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 33 -

Guarantee

Product Guarantee

This product is guaranteed against manufacturing defects for a period of

Year

This product is guaranteed for twelve months from the date of original purchase.

Any defect that arises due to faulty materials or workmanship will either be replaced,

refunded or repaired free of charge where possible during this period by the dealer
from whom you purchased the unit.

The guarantee is subject to the following provisions:

• The guarantee does not cover accidental damage, misuse, cabinet parts, knobs

or consumable items.

• The product must be correctly installed and operated in accordance with the

instructions contained in this manual.

• It must be used solely for domestic purpose.

• The guarantee will be rendered invalided if the product is re-sold or has been

damaged by inexpert repair.

• Specifications are subject to change without notice.

• The manufacturer disclaims any liability for the incidental or consequential damages.

• The guarantee is in addition to, and does not diminish your statutory or legal rights.

• In the event of a problem with the product with in the guarantee period call the

Customer Helpline:0345 604 0105

Guarantor: Argos Ltd

489 - 499 Avebury Boulevard

Central Milton Keynes

MK9 2NW

For online detailed guides and further assistance please use the link below

https://www.argos-support.co.uk/7907302)

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 34 -

Product che

Commercial Brand: HITACHI

Product No. 10113569

Model No. 55HB16T72U

Energy eciency class

Visible screen size

(diagonal,approx.) (inch/cm)

On mode average power

consumpon (Wa)

Annual energy consumpon

(kWh/annum)

Standby power consumpon

(Wa)

O mode power consumpon

(Wa)

Display resoluon (px) 1920x1080

55 inches / 140 cm

A++

60 W

87 kWh

0,5 W

0 W

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 35 -

2017

HITACHI

55HB16T72U

87

60

140 55

50423255

*50423255*

Standby Power Consumption (approx.) 0,5 W
Screen Resolution

Hereby, HITACHI Europe Ltd., declares that the radio equipment type TV is in compliance
with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at

1920x1080

the following internet address: https://estadoc.hitachi.eu/estadoc/index.htm
Hitachi Europe Ltd. Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire.
SL6 8YA. UK

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 36 -

VESA WALL MOUNT MEASUREMENTS

W

H

A B C D E

English VESA WALL MOUNT M EASUREMENTS

Hole Pattern Sizes (mm)

Thread (Y)

Deutsch MASSANGABEN FÜR VESA-WANDMO NTAGE Lochmustergröß en (mm)

Länge (X) Ge winde (Y)

Français DIMENSI ONS DU SUPPORT D E FIXATION MUR ALE VESA Dimensions des modèles de trous de montage (mm)

Longueur (X) Filetage (Y)

Italiano Misurazioni installazione a parete VESA Dimensioni schema foro (mm)

Lunghezza (X) Filettatura (Y)

Português MEDIÇÕES DE MONTAGEM MURAL VESA Dimensões do molde de furação (mm)

Compriment o (X) Rosca (Y)

Español MEDIDAS DEL MONTAJE DE PARED VESA

Tamaño s de patrón pa ra agujero (mm)

Longitud (X) Rosca (Y)

Türkçe VESA DUVAR A MONTAJ APARAT I ÖLÇÜL ERİ Açılacak Delik Ölçüleri (mm)

Uzunluk (X) Yüzey (Y )

Eλληvικ ΔΙΑΣΤΑΣΕ ΙΣ ΒΑΣΗΣ ΤΟΙΧΟΥ VESA

Μεγέθη σχήματος οπών (mm)

Μήκος (X) Σπείρωμα (Y)

Polski WYMIARY DO MONTAŻU NAŚCIENNEGO VESA Rozmiary szablonu otworów (mm)

Długość (mm) Gwint (Y)

čeština ROZMĚRY DRŽÁKU NA ZEĎ VESA Rozměry velikosti děr (mm)

Délka (X) Závit (Y)

Magyar VESA FALI TARTÓ MÉRETEK Lyukak méretének nagysága(mm)

Hossz (X) Menet (Y)

Română MĂSURĂTORI SUPORT PERETE VESA

Dimensiuni tipa r gaură (mm)

Lungime (X) Filet (Y)

Svenska VESA VÄGGMO NTERIN GSMÅTT Hålmönsterstorlear (mm)

Längd (X) Trå d (Y)

Nederlands VESA WANDMONTAGE METINGEN

Grootte booropening (mm)

Lengte (X) Dra ad (Y)

Suomi VE SA-SEINÄASE NNUKSEN MITAT Reikäkuvi on koot (mm)

Pituus (x) Kierre (Y)

Norsk VESA VE GGMONTERIN GSMÅL Hullmønster størrelser (mm)

Lengde (x) Tråd (Y )

Dansk VE SA VÆGMONTE RINGS-MÅL Hulmønster-størrelser (mm)

Længde(X) Trå d (Y)

Русский РАЗМЕРЫ НАСТЕННОГО КРЕПЛЕНИЯ VESA Размеры системы отверстий

Длина(Х) Резьба (Y)

беларуская ПАМЕРЫ НАСЦЕ ННАГА МАЦАВАННЯ VE SA Памеры сістэмы адтулін

Даўжыня (X) Разьба (Y)

македонски

МЕРКИ ЗА МОНТИРАЊЕ НА ЅИД ЗА „ВЕСА“ Шема на големини на дупката (мм)

Должина (Х)

Навој (Y)

український РОЗ МІРИ НАСТІННОГО КРІ ПЛЕННЯ VESA Відстань між кріпильними о творами, мм

Довжина (X) Ді аметр різьби (Y)

Srpski DIMENZIJ E VESA ZIDNOG NOSAČA Dimenzije ša blona za bušenj e

Dužina (X) Na voj (Y)

Slovenčina ROZMERY DRŽIAKA NA STENU VESA Rozmery veľkosti dier (mm)

Dĺžka (X) Závit (Y)

Slovenščina

MERE STENSKEGA NOSILCA VESA Ve likosti vzorca lukenj (mm)

Dolžina (X) N avoj (Y)

Hrvatski VESA MJERE ZIDNOG DRŽAČA Veličine uzorka otvora (mm)

Dužina (X) Na voji (Y)

Bosanski DIMENZIJ E VESA ZIDNOG NOSAČA Dimenzije ša blona za buše nje

Dužina (X) Na voj (Y)

Български РАЗМЕ РИ ЗА КОМПЛЕ КТ ЗА МОНТАЖ НА С ТЕНА VESA

Размери на отвора (mm)

Дължинаt (X) Резба (Y)

Lietuvių VESA TVIRTINIMO PRIE SIENOS MATAVIMAI Ango s šablono dydis (mm)

Ilgis (X) Sriegis (Y )

Latviešu VESA SI ENAS STIPR INĀJUMA I ZMĒRI Ca urumu šablona i zmērs (mm)

Garums (X) Vītne (Y)

Eesti VESA SEINALE KINNITAMISE MÕÕDUD Kruvi s uuruse mõõt (mm)

Kõrgus(x) Keere (Y)

Shqip PËRMASAT E NJËSISË SË MONTIMIT NË MUR VESA

Madhësitë modele të vrimave (mm)

Gjatësia (X) Filetimi (Y)

يبرع   VESA         )(

 )X(  )Y(

תירבע        VESA    )"(

 )X(  )Y(

یسراف       VESA     )  (

  

 )X(  )Y(

A

B

Hole Paern

Sizes (mm)

W H

400 200

C Screw Sizes

D Length (X)

min. (mm) 10

max. (mm) 13

E Thread (Y) M6

Screw Sizes Length (X)

Schraubengrö ßen

Dimensions des vis
Dimensioni vite
Tamanho s do paraf uso

Tamaño s de tornillo

Vida Ölçüleri
Μεγέθη β ιδών
Rozmiary wkręt ów
Rozměry š roubů
Csavar méret
Dimensiuni şuruburi

Skruvstorlekar
Schroefgroote
Ruuvinkoo t

Skruestørrelser
Skruestørrelser
Размеры винтов
Памеры вінтоў
Големина на шрафот
Розміри гвинтів

Dimenzije zavrtnjeva
Rozmery skrutiek
Velikosti vijakov

Veličine vijka

Dimenzije vijaka

Размер на болта
Varžtų dydis
Skrūvju izmēri

Kruvi suurus

Madhësitë e vidhave

  

  

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 37 -
