Hitachi 50UX57B, 60UX57B User Manual

PROJECTION COLOR TV

50UX57B 60UX57B

OPERATING GUIDE

IMPORTANT SAFEGUARDS 2-4

FIRST TIME USE 5-18

THE GENIUS REMOTE CONTROL

ULTRATEC BIT-MAP ON-SCREEN DISPLAY

USEFUL INFORMATION INDEX 59-63

31-58

19-30

VIDEO AUDIO

THEATER INFO

CUSTOMSET UP

IMPORTANT

Follow all warnings and instructions marked on this projection television.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of a sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PROJECTION TELEVISION TO RAIN OR MOISTURE.

NOTE: • There are no user serviceable parts inside the television.

• Model and serial numbers are indicated on back side of the television.

• This television is not intended for use in a computer room.

POWER SOURCE

This projection television is designed to operate on 120 volts 60Hz, AC current. Insert power cord into a 120 volt 60Hz outlet.

TO PREVENT ELECTRIC SHOCK, DO NOT USE THE TELEVISION’S (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES AND GROUND TERMINAL CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

NEVER CONNECT THE TELEVISION TO 50HZ, DIRECT CURRENT, OR ANYTHING OTHER THAN THE SPECIFIED VOLTAGE.

CAUTION: Never remove the back cover of the television as this can expose you to very high voltages and other haz-

ards. If the television does not operate properly, unplug the television and call your authorized dealer or service shop.

NOTE: This television receiver will display television closed captioning, ( or ), in accordance with

paragraph 15.119 of the FCC rules.

CAUTION:

Adjust only those controls that are covered in the instructions, as improper changes or modifications not expressly approved by HITACHI could void the user’s authority to operate the TV.

MODIFICATIONS:

The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hitachi America, Ltd. Home Electronics Division may void the user’s authority to operate the equipment.

SAFETY TIPS

1. This television set is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other.) This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

2. When the power cord or plug is damaged or frayed, unplug the television from the wall outlet and refer servicing to qualified service personnel.

3. Do not overload wall outlets and extension cords as this can result in fire or electric shock.

4. Do not allow anything to rest on or roll over the power cord, and do not place the television where the power cord is subject to traffic or abuse. This may result in a shock or fire hazard.

5. Do not attempt to service the television yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

6. Never push objects of any kind into the television’s cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television.

7. If the television has been dropped or the cabinet has been damaged, unplug the television from the wall outlet and refer servicing to qualified service personnel.

8. If liquid has been spilled into the television set, unplug it from the wall outlet and refer service to qualified service personnel.

9. Do not subject your television to impact of any kind. Be careful not to damage the picture tube surface.

IMPORTANT SAFEGUARDS

CAUTION: • Read all of these instructions. SAFETY POINTS YOU SHOULD KNOW ABOUT

• Save these instructions for later use. YOUR HITACHI PROJECTION TELEVISION

• Follow all warnings and instructions marked

on the television.

Our reputation has been built on the quality, performance, and ease of service of HITACHI televisions.

Safety is also foremost in our minds in the design of these units. To help you operate these products properly, this section illustrates safety tips which will be of benefit to you. Please read it carefully and apply the knowledge you obtain from it to the proper operation of your HITACHI television.

Please fill out your warranty card and mail it to HITACHI. This will enable HITACHI to notify you promptly in the improbable event that a safety problem should be discovered in your product model.

NO!

Coins

NO!

HELP

10. Unplug the television from the wall outlet before cleaning. Use a damp cloth for cleaning. Do not use liquid or aerosol cleaners.

11-1. Do not place the television on an

unstable cart, stand, or table. The television may fall, causing serious injury to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the manufacturer, or sold with the television. Wall or shelf mounting should follow the manufacturer’s instructions, and should use a mounting kit approved by the manufacturer.

11-2. An appliance and cart combination

should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

FOR YOUR PERSONAL SAFETY

14. Avoid dusty places. Accumulated dust inside the chassis may cause failure of the television when high humidity persists.

15. The television has slots or openings in the cabinet for ventilation purposes which provide reliable operation of the receiver and protect the television from overheating. These openings must not be blocked or covered.

• Never cover the slots or openings with cloth or other material.

12. Do not use the television near water, for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc.

• Never expose the television to rain or water. If the set has been exposed to rain or water, unplug television from wall outlet and refer to qualified service personnel.

13. Choose a place where light (artificial or sunlight) does not shine directly on the screen.

NO!

TOO

HOT!

PROTECTION AND LOCATION OF YOUR TELEVISION

• Never block the bottom ventilation slots of the television by placing it on a bed, sofa, rug, etc.

• Never place the television near or over a radiator or heat register.

• Never place the television in a built-in enclosure unless proper ventilation is provided.

SAFETY TIPS

PICTURE CAUTIONS

Picture Burn Prevention

• Continuous on-screen displays such as video games, stock market quotations, computer generated graphics, and other fixed (non-moving) patterns can cause permanent damage to projection television receivers. Such “PATTERN BURNS” constitute misuse and are NOT COVERED by your HITACHI Factory Warranty.

• When using Picture-in-Picture function, the sub-picture should not be left permanently in one corner of the screen or a “PATTERN BURN” may develop over a long period of time.

Public Viewing of Copyrighted Material

Public viewing of programs broadcast by TV stations and cable companies, as well as programs from other sources, may require prior authorization from the broadcaster or owner of the video program material.

PROTECTION AND LOCATION OF YOUR TELEVISION

16-1. If an outside antenna is connected

to the television, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, NFPA No. 70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit connection to grounding electrode, and requirements for the grounding electrode.

16-2. Note to CATV system installer:

(Only for television with CATV reception). This reminder is provided to call the CATV system installer’s attention to Article 82040 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

17. An outside antenna system should not be located in the vicinity of overhead power lines or other electrical lights or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

18. For added protection for the television during a lightning storm, or when it is unused for long periods of time, unplug it from the wall outlet and disconnect antenna. This will prevent damage due to lightning and power-line surges.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS.

19. This television should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply at your home, consult your dealer or local power company. For televisions designed to operate from battery power, refer to the operating instructions.

20. If the television does not operate normally by following the operating instructions, unplug the television from the wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified service technician to restore the television to normal operation.

OPERATION OF YOUR TELEVISION

Use Proper Voltage

21. If your television is to remain unused for a period of time, (such as when going on a holiday), turn the television OFF and unplug it from the wall outlet.

22. If you are unable to restore normal operation by following the detailed procedure in your operating instructions, do not attempt any further adjustments. Unplug the television and call your dealer or service technician.

IF THE TELEVISION DOES NOT OPERATE PROPERLY

23. Whenever the television is damaged or fails, or if there is a distinct change in performance that indicates a need for service, unplug the television and have it checked by a qualified service technician.

24. It is normal for some televisions to make occasional snapping or popping sounds, particularly when being turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your dealer or service technician.

25. Do not use attachments not recommended by the television manufacturer as they may cause hazards.

FOR SERVICING AND MODIFICATION

26. If replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

27. Upon completion of any service or repairs to the television, ask the service technician to perform routine safety checks to determine that the television is in safe operating condition.

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

GROUNDING CONDUCTORS

POWER SERVICE GROUNDING ELECTRODE SYSTEM

NEC NATIONAL ELECTRICAL CODE

(NEC ART 250 PART H)

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

No !

Service

Snap

Pop

Snap

ask me!

ACCESSORIES

Check to make sure you have the following accessories before disposing of the packing material.

MUTE

SLEEP

INPUT

CLU-615MP

RECALL

REC

C.S.

L I G H T

INFO

GUIDE

EXIT

SVCS

SCHED

SELECT

TV/CABLE/SAT

VCR

AUDIO

LST-CH

VOL

PIP CH FRZ

PIP SWAP

MOVE

CABLE

SAT

POWER

HELP

FAV CH

1. Remote Control Unit CLU-615MP (Part No. HL00715).

2. Two “AA” size, 1.5V batteries (For Remote Control Unit).

REMOTE CONTROL BATTERY INSTALLATION AND REPLACEMENT

1. Open the battery cover of the remote control by pushing the notched part of the cover with your fingers and pulling the cover off.

2. Insert two new “AA” size batteries for the remote control. When replacing old batteries, push them towards the springs and lift them out.

3. Match the batteries to the (+) and (-) marks in the battery compartment.

4. Replace the cover.

BOTTOM VIEW

Lift up on tab to remove back cover.

HOW TO SET UP YOUR NEW HITACHI PROJECTION TV

CAUTION: Magnetic fields, such as those of external speakers, may cause the picture to distort if they are placed too

close to the television. Move the magnetic field source away from the television until there is no picture distortion.

ANTENNA

Unless your TV is connected to a cable TV system or to a centralized antenna system, a good outdoor color TV antenna is recommended for best performance. However, if you are located in an exceptionally good signal area that is free from interference and multiple image ghosts, an indoor antenna may be sufficient.

LOCATION

Select an area where sunlight or bright indoor illumination will not fall directly on the picture screen. Also, be sure that the location selected allows a free flow of air to and from the perforated back cover of the set. To avoid cabinet warping, cabinet color changes, and increased chance of set failure, do not place the TV where temperatures can become excessively hot, for example, in direct sunlight or near a heating appliance, etc.

VIEWING

The major benefit of the HITACHI Projection Television is its large viewing screen. To see this large screen at its best, test various locations in the room to find the optimum spot for viewing.

The best picture is seen by sitting directly in front of the TV and about 10 to 18 feet from the screen. Picture brightness decreases as the viewer moves to the left and right of the receiver.

During daylight hours, reflections from outside light may appear on the screen. If so, drapes or screens can be used to reduce the reflection or the TV can be located in a different section of the room.

If the TV’s audio output will be connected to a Hi-Fi system’s external speakers, the best audio performance will be obtained by placing the speakers equidistant from each side of the receiver cabinet and as close as possible to the height of the picture screen center. For best stereo separation, place the external speakers at least four feet from the side of the TV, place the surround speakers to the side or behind the viewing area. Differences in room sizes and acoustical environments will require some experimentation with speaker placement for best performance.

4' MINIMUM

BEST

VERTICAL VIEWING

ANGLE

15'

4' MINIMUM

20'

10'

20'

BEST HORIZONTAL

10'

VIEWING ANGLE

15'

20'

HOOK-UP CABLES AND CONNECTORS

Most video/audio connections between components can be made with shielded video and audio cables that have phono connectors. For best performance, video cables should use 75-Ohm coaxial shielded wire. Cables can be purchased from most stores that sell audio/video products. Below are illustrations and names of common connectors. Before purchasing any cables, be sure of the output and input connector types required by the various components and the length of each cable.

300-Ohm Twin Lead Connector

This outdoor antenna cable must be connected to an antenna adapter (300-Ohm to 75-Ohm).

Phono Connector

Used on all standard video and audio cables which connect to inputs and outputs located on the television’s rear jack panel and front control panel.

''F'' Type 75-Ohm Coaxial Antenna Connector

For connecting RF signals (antenna or cable TV) to the antenna jack on the television.

S-Video (Super Video) Connector

This connector is used on camcorders, VCRs, and laserdisc players with an S-Video feature in place of the standard video cable to produce a high quality picture.

ANTENNA CONNECTIONS TO REAR JACK PANEL

VHF (75-Ohm) antenna/CATV (Cable TV)

When using a 75-Ohm coaxial cable system, connect the outdoor antenna or CATV coaxial cable to the ANT A (75-Ohm) terminal. If you have a second antenna or cable TV system, connect the coaxial cable to the ANT B terminal.

VHF (300-Ohm) antenna/UHF antenna

When using a 300-Ohm twin lead from an outdoor antenna, connect the VHF or UHF antenna leads to screws of the VHF or UHF adapter. Plug the adapter into the antenna terminal on the TV.

When both VHF and UHF antennas are connected

Attach an optional antenna cable mixer to the TV antenna terminal, and connect the cables to the antenna mixer. Consult your dealer or service store for the antenna mixer.

T o

o outdoor antenna r CATV cable

To second antenna or cable system

To outdoor VHF or UHF antenna

To UHF Antenna

ANT A/ANT B

Antenna mixer

To outdoor antenna or CATV system

SOUND RETRIEVAL SYSTEM

VOL+VOL-

CH+

CH-

VOL+VOL-

CH+

CH-

MAGIC FOCUS

POWER

INPUT

EXIT

     

  10

Push open door and pull forward and down.

PUSH

POWER

INPUT

EXIT

FRONT PANEL CONTROLS

NOTE: Your HITACHI Projection TV will appear to be turned OFF if there is no video input when VIDEO: 1, 2, or 3 is selected.

Check the Power Light to make sure the TV is turned off when not in use.

To see an auto-demonstration of the on-screen displays with HELP text displayed, press and hold the POWER button on the TV set for approximately five seconds. Press the POWER button on the TV again to end the auto-demonstration.

FRONT VIEW

 MENU button

This button allows you to enter the MENU, making it possible to set TV features to your preference without using the remote.

 INPUT/EXIT button

Press this button to select the current antenna source, VIDEO: 1, 2, 3, or alternate antenna source. Your selection is shown in the top right corner of the screen. This button also serves as the EXIT button when in MENU mode.

 CHANNEL selector

Press these buttons until the desired channel appears in the top right corner of the TV screen. These buttons also serve as the cursor down () and up () buttons when in MENU mode.

 VOLUME level

Press these buttons for your desired sound level. The volume level will be displayed on the TV screen. These buttons also serve as the cursor left () and right () buttons when in MENU mode.

 POWER button

Press this button to turn the TV on or off.

쏐

(

)

쏐

(

)

FRONT PANEL CONTROLS

 POWER light

You will see a red light when the TV is turned on.

 AI (Artificial Intelligence) sensor

The Artificial Intelligence sensor will make automatic picture adjustments depending on the amount of light in the room to give the best picture. (See page 50.)

 REMOTE CONTROL sensor

Point your remote at this area when selecting channels, adjusting volume, etc.

 MAGIC FOCUS

Use this button to adjust your picture quality to optimum performance. (See page 40.)

 FRONT INPUT JACKS (for VIDEO: 3)

Use these audio/video jacks for a quick hook-up from a camcorder or VCR to instantly view your favorite show or new recording. Press the INPUT button until VIDEO: 3 appears in the top right corner of the TV screen. If you have mono sound, insert the audio cable into the left channel jack.

FRONT PANEL JACKS AND CONNECTIONS

The front panel jacks are provided as a convenience to allow you to easily connect a camcorder or VCR as shown in the following examples:

NOTE: Completely insert connection cord plugs when connecting to front panel jacks. If you do not, the played back picture

may be abnormal. If you have a S-VHS VCR, use the S-INPUT cable in place of the standard video cable. If you have a mono VCR, insert the audio cable into the left channel jack of your TV.

MAGIC FOCUS

OUTPUT

V L R

S-VHS

Back of VCR

S-INPUT

(Optional, see note)

INPUT 3

AUDIO

S-VIDEO

VIDEO L/MONO R

INPUT

OUTPUT

REAR PANEL JACKS

 Antenna Input/Output

The remote control allows you to switch between two separate 75-Ohm RF antenna inputs, ANT A and ANT B. ANT A input can be displayed as a main picture or sub-picture. ANT B can only be displayed as a main picture. (ANT B cannot be displayed as a sub-picture.) The antenna output labeled “TO CONVERTER” allows the ANT A connection to pass directly to a different source such as a cable box, when ANT B is displayed as a main picture.

 Audio/Video Inputs 1, 2

The INPUT button will step through each video source and antenna source input each time it is pressed. Use the audio and video inputs to connect external devices, such as VCRs, camcorders, laserdisc players, DVD players etc. (If you have mono sound, insert the audio cable into the left channel jack.)

 Monitor Out

These jacks provide fixed audio and video signals which are used for recording.

 Wireless Out

These jacks provide variable audio output to a set of wireless speakers. They can also be used for another stereo system amplifier. With this connection, the audio can be controlled by the television’s main volume and also by an independent volume feature found in the THEATER-WIRELESS SOUND menu.

 Audio to HI-FI

These jacks provide variable audio output to a separate stereo amplifier. With this connection, the audio to the stereo can be controlled by the television’s main volume.

 S-Video Inputs 1 and 2

Inputs 1 and 2 provide S-Video (Super Video) jacks for connecting equipment with S-Video output capability.

 Component: Y-C

bCr

Input 2

Input 2 provides Y-C

bCr

jacks for connecting equipment with this capability, such as a DVD player.















REAR SPEAKER

8Ω ONLY

SP. MATRIX SURROUND

EXT.





WIRELESS OUT

MONITOR

OUT

AUDIO

TO Hi-Fi

INPUT 2

INPUT 1

AUDIO

(MONO)

AUDIO

(MONO)

AUDIO

S-VIDEO

VIDEO

ANT A

TO CONVERTER

ANT B

COMPONENT

Y Cb Cr

NOTE:

DO NOT connect standard VIDEO or S-VIDEO to Input 2 when using Y-CbCrinput.

When using the Y-CbCrinput jacks, connect your components audio output to the TV’s Input 2 Left and Right Audio input jacks.

Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TV’s Cb input and the components R-Y output to the TV’s Cr input.

It may be nessary to adjust TINT or turn AUTO COLOR-ON to obtain optimum picture quality when using the Y-CbCr inputs. (See pages 49 and 50)

To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-CbCrjacks.

When using the Y-CbCr jacks, Input 2 will be viewed as a blank PIP sub-picture. (See page 24.)

NOTE: You may use VIDEO, S-VIDEO, or COMPONENT: Y-CbCrinputs to connect to Input 2, but note that only one of these

may be used at a time.

REAR PANEL CONNECTIONS

Typical full feature setup. Follow connections that pertain to your personal entertainment system.

OUTPUT

V L R

S-VIDEO

OUTPUT

V L R

S-VHS

ANT

OUTPUT

WIRELESS OUT

MONITOR

OUT

AUDIO

TO Hi-Fi

INPUT 2

INPUT 1

AUDIO

(MONO)

AUDIO

(MONO)

AUDIO

S-VIDEO

VIDEO

ANT A

TO CONVERTER

ANT B

COMPONENT

Y Cb Cr

INPUT

OUTPUT

Y Cb Cr

L R

DVD Player, Laserdisc player, etc.

See tips on page 13

INPUT

V L R

Cable TV Box

Optional, see tips on page 13

Laserdisc player, VCR, camcorder, etc.

VCR #1

VCR #2

Wirelss

Speaker

Wireless Speaker

Tr ansmitter

Wireless

Speaker

Stereo System Amplifier

Outside antenna or cable TV coaxial cable

2-Way signal splitter

TIPS ON REAR PANEL CONNECTIONS

S-Video connections are provided for high performance laserdisc players, VCRs etc. that have this feature. Use these connections in place of the standard video connection if your device has this feature.

If your device has only one audio output (mono sound), connect it to the left audio jack on the television.

Refer to the operating guide of your other electronic equipment for additional information on connecting your hook-up cables.

A single VCR can be used for VCR #1 and VCR #2, but note that a VCR cannot record its own video or line output (INPUT: 1 in the example on page 12.) Refer to your VCR operating guide for more information on line input-output connections.

You may use VIDEO, S-VIDEO, or COMPONENT: Y-CbCrinputs to connect to Input 2, but note that only one of these may be used at a time.

Connect only 1 component to each input jack.

COMPONENT: Y-CbCr connections are provided for high performance components, such as DVD players. Use these connections in place of the standard video connection if your device has this feature.

When using the Y-CbCrinput jacks, connect your components audio output to the TV’s Input 2 Left and Right Audio input jacks.

Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y ouput to the TV’s Cb input and the components R-Y output to the TV’s Cr input.

It may be necessary to adjust TINT or turn AUTO COLOR-ON to obtain optimum picture quality when using the Y-CbCrinputs. (See pages 49 and 50.)

To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-CbCrjacks.

When using the Y-CbCrjacks, Input 2 will be viewed as a blank PIP sub-picture. (See page 24.)

EXTERNAL CONNECTIONS

CONNECTING EXTERNAL AUDIO AMPLIFIER

To control the audio level of an external audio amplifier with the remote control, connect the system as shown below.

NOTE: To prevent damage to the speaker and distorted sound, set the volume control of the audio amplifier lower and adjust

the sound using the remote control of the TV set.

(REAR OF TV SET)

AUDIO TO HI-FI TERMINAL

AUDIO

TO HI-FI

TO AUDIO INPUT TERMINAL OF EXTERNAL AMPLIFIER

EXTERNAL SPEAKERS

AUDIO AMPLIFIER

EXTERNAL SPEAKERS

CONNECTING EXTERNAL VIDEO SOURCES

The exact arrangement you use to connect the VCR, camcorder, laserdisc player, and DVD player to your TV set is dependent on the model and features of each component. Check the owner’s manual of each component for the location of video and audio inputs and outputs.

The following connection diagrams are offered as suggestions. However, you may need to modify them to accommodate your particular assortment of components and features. For best performance, video and audio cables should be made from coaxial shielded wire.

Before Operating External Video Source

The input mode is changed every time the INPUT button is pressed as shown below. Connect an external source to the INPUT terminal, then press the INPUT button as necessary to view the input source. (See page 23.)

NOTE: When the TV is set to VIDEO and a video signal is not received from the VIDEO INPUT JACK on the jack panel of the

TV (i.e., VCR/laserdisc player, etc. is not connected or the video device is OFF), the set will appear to be OFF.

CONNECTING A MONAURAL AUDIO VCR OR LASERDISC PLAYER

1. Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack on the TV set below.

2. Connect the cable from the AUDIO OUT of the VCR or the laserdisc player to the INPUT (MONO)/L(AUDIO) jack.

3. Press the INPUT button to view the program from the VCR or the laserdisc player. The VIDEO mode disappears automatically after approximately eight seconds.

4. Press the INPUT button to return to the previous channel.

VCR

INPUT MODE SELECTION ORDER

(Antenna)

(Input)

VIDEO

VCR

TV INPUT

ERMINAL

S-VIDEO

VIDEO

(MONO)

AUDIO

INPUT

AUD I O OUTVIDEO OUT

CONNECTING EXTERNAL VIDEO SOURCES

NOTE: Completely insert the connection cord plugs when connecting to rear panel jacks. The picture that is played back will be

abnormal if the connection is loose.

If you have an S-VHS VCR, use the S-INPUT cable in place of the standard video cable.

A single VCR can be used for VCR #1 and VCR #2, but note that a VCR cannot record its own video or line output. (INPUT: 1 in example on page 12.) Refer to your VCR operating guide for more information on line input-output connections.

CONNECTING A STEREO VCR OR STEREO LASERDISC PLAYER

1. Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack on the TV set below.

2. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT(AUDIO/R) jack.

3. Connect the cable from the AUDIO OUT L of the VCR or the laserdisc player to the INPUT(AUDIO/L) jack.

4. Press the INPUT button to view the program from the VCR or laserdisc player. The mode VIDEO disappears automatically after approximately eight seconds.

5. Press the INPUT button to return to the previous channel.

S-VHS V L R

OUTPUT

BACK OF VCR

HITACHI MODEL

or similar model

TV INPUT

TERMINAL

INPUT 1

(MONO)

AUDIO

VIDEO

S-VIDEO 1

S-VIDEO

INPUT

Optional, see tips on page 13

CONNECTING EXTERNAL VIDEO SOURCES

CONNECTING A STEREO LASERDISC PLAYER OR DVD PLAYER TO INPUT 2.

1. Connect the cable from the Y OUT of the Laserdisc or the DVD player to the INPUT 2 (Y) jack as shown on the TV set below.

2. Connect the cable from the Cb OUT or B-Y OUT of the Laserdisc or the DVD player to the INPUT 2 (Cb) jack, as shown on the TV

set below.

3. Connect the cable from the Cr OUT or R-Y OUT of the Laserdisc or the DVD player to the INPUT 2 (Cr) jack, as shown on the TV

set below.

4. Connect the cable from the AUDIO OUT R of the Laserdisc or DVD player to the INPUT 2 (AUDIO/R) jack.

5. Connect the cable from the AUDIO OUT L of the Laserdisc or DVD player to the INPUT 2 (AUDIO/L) jack.

6. Press the INPUT button until VIDEO:2 appears, to view the program from the Laserdisc or DVD player. The mode VIDEO:2 disappears automatically after approximately eight seconds.

7. Press the INPUT button to return to the previous channel.

NOTE: Completely insert the connection cord plugs when connecting to rear panel jacks. The picture that is played back will be

abnormal if the connection is loose.

See page 13 for tips on REAR PANEL CONNECTIONS.

INPUT 2

TV INPUT 2

TERMINAL

(MONO)

VIDEO

S-VIDEO

AUDIO

Y Cb Cr

COMPONENT

BACK OF DVD PLAYER

HITACHI MODEL

or similar model

Y Cb Cr

R L

AUDIO

VIDEO

OUTPUT

AUDIO SYSTEM SETUP

Match the numbers below to the diagrams for speaker placement. (See page 54 for SRS functions.)

 The television’s internal speakers.

 These speakers are connected to a separate audio amplifier. Use the AUDIO TO HI-FI output on the TV.  These speakers are controlled by a wireless speaker transmitter. Use the WIRELESS OUT output on the TV.





L R

IN TRANSMITTER FOR WIRELESS SPEAKERS



L R

STEREO SYSTEM AMPLIFIER

L R

OUT

 

REQUIRED OPTIONAL EFFECT

FEATURE CONNECTION CONNECTION

Exciting and realistic 3D sound experience

ON    from just two speakers.

OFF    Receive mono and stereo sound.

SRS

)

(

쏐

THE GENIUS REMOTE CONTROL (CLU-615MP)

 MULTI-PAGE select switch

This selects the button layout of the multi-page section of the remote control.

 MULTI-PAGE buttons

These buttons change functions as shown on page 20.

 LIGHT button

When you are in a dark room, press this button on the side of the remote to light up the buttons shown in . The light will stay on for about eight seconds if the light button is not pressed again. These buttons will not appear to light if the room is too bright.

In addition to controlling all the functions on your HITACHI Projection TV, the remote control is designed to operate different types of VCRs, CATV (cable TV)/satellite converters, and audio equipment with one touch. Basic operation keys are grouped together in one area. All other controls are separated from them and arranged in MULTI-PAGE sections, with a display that can be switched to cover any of the three pages. Functions are arranged and properly categorized into windows, making operation simple when multiple functions are to be controlled.

To operate your TV, slide the MULTI-PAGE select switch on the side of the remote to TV/CABLE/SAT mode. Press the TV button and the remote will now control your television.

To operate your cable box, slide the MULTI-PAGE select switch on the side of the remote to TV/CABLE/SAT mode. Press the CABLE button and the remote will now control your cable box. (See page 28 for instructions on how to program the remote to control your cable box.)

To operate your satellite box, slide the MULTI-PAGE select switch on the side of the remote to TV/CABLE/SAT mode. Press the SAT button and the remote will now control your satellite box. (See page 28 for instructions on how to program the remote to control your satellite box.)

To operate your VCR, slide the MULTI-PAGE select switch on the side of the remote to VCR mode. The remote will now control your VCR. (See page 27 for instructions on how to program the remote to control your VCR.)

To operate your audio equipment, slide the MULTI-PAGE select switch on the side of the remote to AUDIO mode. Press the button which corresponds to the component you would like to control (AMP, CD, TAPE). The remote will now control your audio equipment. (See page 29 for instructions on how to program the remote to control your audio equipment.)

MUTE

SLEEP

INPUT

CLU-615MP

RECALL

REC

FAV CH

C.S.

I G H T

INFO

GUIDE

EXIT

SVCS

SCHED

SELECT

TV/CABLE/SAT

VCR

AUDIO

LST-CH

VOL

PIP CH

HELP

FRZ

PIP SWAP

MOVE

CABLE

SAT

POWER









MULTI-PAGE WINDOWS

POWER

SELECT SWITCH

TV/CABLE/SAT

VCR

AUDIO

REC

STOP

PAUSE

AMP

C D

TAPE

TV/CABLE/SAT

VCR

AUDIO

PIP CH

HELP

FRZ

PIP SWAP

MOVE

CABLE

SAT

POWER

SELECT SWITCH

When TV/CABLE/SAT is set.

POWER

SELECT SWITCH

When VCR is set.

When AUDIO is set.

TV/CABLE/SAT

VCR

AUDIO

SLOW

PROG.

TV/VCR

REC

STOP PAUSE

+ 44 hidden pages
