Hitachi 50HK6T74U, 65HK6T64U Instruction manual

Download

Contents

Support ...................................................................7

Environmental Information......................................8

Features .................................................................8

Accessories Included..............................................8

Standby Notications .............................................. 8

TV Control & Operation .......................................... 9

Inserting the Batteries into the Remote .................. 9

Connect Power ...................................................... 9

Antenna Connection ............................................... 9

Notication ............................................................10

Disposal information ............................................. 10

Specication ......................................................... 11

Remote Control ....................................................12

Connections..........................................................13

Switching On/Off ...................................................14

First Time Installation............................................14

Media Playback via USB Input ............................. 14

Media Browser Menu............................................15

FollowMe TV (if available) ....................................15

CEC and CEC RC Passthrough ........................... 15

TV Menu Contents................................................16

General TV Operation ..........................................20

Using the Channel List .........................................20

Conguring Parental Settings ............................... 20

Electronic Programme Guide (EPG) ....................20

Digital Teletext ......................................................21

Software Upgrade.................................................21

Troubleshooting & Tips .........................................22

To Program Your SKY Remote For Your TV .........22

PC Input Typical Display Modes ...........................23

AV and HDMI Signal Compatibility .......................23

Supported Video File Formats for USB Mode ......24

Supported Picture File Formats for USB Mode .... 24

Supported Audio File Formats for USB Mode ......25

Supported DVI Resolutions .................................. 26

Internet Portal .......................................................30

Freeview Play Platform.........................................30

Integrated Catch-Up Services ..............................31

Internet Browser ................................................... 31

DVB-T functionality information ............................34

Internet Portal functionality information ................ 34

Guarantee.............................................................35

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 1 -

Important safety precautions

The lightning ash with arrowhead symbol,

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO

Don’t operate your TV in extreme ambient

conditions as this may cause damage to your TV.

NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Note: Follow the on screen instructions for operating the related features.

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated “dangerous voltage” within the product’s

enclosure that may be of sufcient magnitude

to constitute a risk of electric shock of persons. The exclamation point within an equilateral

triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

IMPORTANT - Please read these instructions fully before installing or operating

Preparation

Place the device on a solid even surface. For

ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, do not place any objects on top of the set.

Use this device in moderate climates. Operation temperature and operation humidity:

0ºC up to 40ºC, 85% rel. humidity max. (not blocking

ventilation openings).

Intended Use

This device is used to receive and display TV pro grammmes. The different connection options make an additional expansion of the reception and display sources possible (various external devices). This device is only suitable for dry interior use. This appliance is intended solely for private domestic use and may not be used for industrial and commercial purposes. We

exclude liability in principle, if the device is not used as intended, or unauthorized modications have been

made. To operate your TV in extreme ambient conditions may cause the damage of the device.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instructions concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

Children may not recognize dangers. The swallowing of batteries can be fatal. Keep batteries always out of reach of small children. If a battery is swallowed, seek immediate medical attention.

Keep the packaging lms out of reach of children,

there is a risk of suffocation.

Use this TV set at an altitude of less than 2000 meters

above the sea level, in dry locations and in regions

with moderate or tropical climates.

English - 2 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

To avoid danger of suffocation, keep plastic bags out of the reach of the babies, children and domestic

animals. Carefully attach the stand to the TV. If the stand is

provided with screws, tighten the screws rmly to

prevent the TV from tilting. Do not over-tighten the screws and mount the stand rubbers properly.

**************

Please read the following recommended safety precautions carefully for your safety.

SOME DO’S AND DON’TS ON THE SAFE USE OF EQUIPMENT

This equipment has been designed and manufactured

to meet international safety standards but, like any electrical equipment, care must be taken if you are

to obtain the best results and safety is to be assured. ************** DO read the operating instructions before you attempt

to use the equipment. DO ensure that all electrical connections (including

the mains plug, extension leads and inter-connections

between the pieces of equipment) are properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug before making or changing connections.

DO consult your dealer if you are ever in doubt about

the installation, operation or safety of your equipment.

DO be careful with glass panels or doors on equipment.

DO route the mains lead so that it is not likely to be

walked on, crushed, chafed, or subjected to excessive

wear and tear or heat. **************

DON’T remove any xed cover as this may expose

dangerous voltages.

DON’T obstruct the ventilation openings of the

equipment with items such as newspapers, tablecloths, curtains, etc. Overheating will cause damage and

shorten the life of the equipment. DON’T allow electrical equipment to be exposed to

dripping or splashing, or objects lled with liquids, such as vases, to be placed on the equipment.

DON’T place hot objects or naked ame sources such as lighted candles or nightlights on, or close to

equipment. High temperatures can melt plastic and

lead to res. DON’T use makeshift stands and NEVER x legs with

wood screws - to ensure complete safety always t

the manufacturer’s approved stand or legs with the

xings provided according to the instructions.

DON’T listen to headphones at high volume, as such

use can permanently damage your hearing. DON’T leave equipment switched on when it is

unattended unless it is specically stated that it is

designed for unattended operation or has a stand-by

mode. Switch off using the switch, on the equipment

and make sure that your family know how to do this.

Special arrangements may need to be made for inrm

or handicapped people. DON’T continue to operate the equipment if you are in

any doubt about it working normally, or if it is damaged in any way - switch off, withdraw the mains plug and

consult your dealer.

ABOVE ALL

--- NEVER let anyone especially children push anything into holes, slots or any other opening in the case - this could result in a fatal electrical shock;

--- NEVER guess or take chances with electrical equipment of any kind

--- It is better to be safe than sorry!

Power source

• The TV should be operated only from a 220-240 V

AC, 50 Hz outlet.

WARNING: Do not leave your TV in standby or

operating mode when you leave your house.

Positioning the TV

• For ventilation, please leave a clear space of at least

10cm all around the TV.

• Do not block the ventilation openings.

• Do not place the TV on sloping or unstable surfaces,

the TV may tip over.

• To prevent damage to the TV, do not place any

objects on top of the TV.

Power cord and plug

• Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the power cord by the plug. Do not pull the plug by

holding its neck, as this could result in damage to the

plug. Do not unplug the appliance by pulling from the power cord and never touch the power cord with wet hands as this could cause a short circuit or electric shock. Never make a knot in the cord or tie it with other cords. The power cords should be placed in such a way that they are not likely to be stepped on.

A damaged power cord can cause re or give you an

electric shock. When it is damaged and needs to be

replaced, it should be done by qualied personnel.

• This TV receiver is supplied with a moulded mains

plug. The mains plug must not be cut off, as it may contain a special radio interference lter, the removal

of which could lead to impaired performance. If you

wish to extend the lead, obtain an appropriate safety

approved extension lead or consult your dealer.

• Observe the manufacturers instructions when connecting extension leads to the set. Check the

fuse rating on the new plug; this should be tted with

a 5 Amp fuse which conforms to either ASTA or BSI

(BS1362) approvals, these are easily identiable by

either the

ASA

or symbols. If you are in any doubt

about the installation of an extension lead, please

consult a competent electrician.

Moisture and Water

• Do not use this TV in a humid or damp place (avoid

bathrooms, the sink in the kitchen, and near the

washing machine).

• Do not expose this TV to rain or water.

• Do not place objects lled with liquids, such as

ower vases, on top of the TV. Avoid from dripping

or splashing.

• If any solid object or liquid falls into the cabinet, unplug the TV and have it checked by qualied

personnel before operating it any further.

Ventilation

• The slots and openings on the TV set are intended for ventilation and to ensure reliable operation.

• To prevent overheating, these openings must not be

blocked or covered in anyway.

Heat sources and Flames

• Do not expose the TV to direct sunlight or other heat sources.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 3 -

• The TV should not be placed near to open ames

and sources of intense heat such as an electric heater.

• Ensure that no open ame sources, such as lit candles, are placed on top of the TV.

Headphone Volume

• Excessive sound pressure from earphones and headphones can cause hearing loss,

please take care.

Wall Mounting (optional)

• To prevent injury, this TV must be securely attached to

the wall in accordance with the installation instructions (if the option is available).

LCD Screen

• Occasionally, a few non-active pixels may appear on the screen as a xed blue, green or red point.

Please note that this does not affect the performance of your product.

• Take care not to scratch the screen with ngernails or other hard objects.

Cleaning

• Before cleaning, unplug the TV from the wall socket.

• Do not use liquid or aerosol cleaners. Only use a

soft, dry cloth.

Batteries

WARNING: Incorrect installation of batteries

may cause battery leakage and corrosion, resulting in damage to the remote control.

• Do not mix old and new batteries, or batteries of different

types.

• Do not dispose of batteries in a re.

• Do not dispose of batteries with

normal household waste, take to a

local recycling centre.

CAUTION: Insert the batteries / rechargeable batteries in the correct polarity. Don´t try to recharge non rechargeable batteries and under

no circumstances throw them into re. Danger of

explosion. Do not use unequal batteries (old and new, Alkaline and carbon, etc.) simultaneously. If you will not use the device for a long time, remove the batteries and store the device in a dry and dust free place. Improper use of batteries may cause an explosion or leakage. If the batteries have leaked, use gloves and clean the appliance thoroughly with a dry cloth! Batteries should not be exposed to heat, such

as sunshine, re or the like.

Replacement Parts

When replacement parts are required, make sure that the service technician has used replacement parts, which are specied by the manufacturer or have the same specications as the original one. Unauthorised substitutions may result in re, electrical shock or other hazards.

Taking out of service and storing

Unplug the TV from the mains and pack the TV in an appropriate cardboard box. Remove the batteries from the remote control and pack the remote control with the TV set.

NOTE: The TV set should be stored in a dry and

dust-free room.

Connection to a Television Distribution System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the building installation through the mains connection or through other apparatus with a connection to protective earthing-and to a television distribution system using

coaxial cable, may in some circumstances create a re hazard.

Connection to a cable distribution system has therefore to be provided through a device providing electrical isolation below a certain frequency range

(galvanic isolator, see EN 60728-11).

CAUTION

Do not put your ngers in the middle between the TV and stand, especially when you carry the TV, as they may be injured.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 4 -

WARNING

Do not ingest the battery, Chemical Burn Hazard

This product or the accessories supplied with the product may contain a coin/button cell battery. If

the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can

lead to death. Keep new and used batteries away from children. If the battery compartment does not close secu-

rely, stop using the product and keep it away from

children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.

WARNING

Never place a television set in unstable or inclined

locations. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple pre-

cautions such as;

• Using cabinets or stands recommended by the manufacturer of the television set.

• Only using furniture that can safely support the television set.

• Ensuring the television set is not overhanging the edge of the supporting furniture.

• Not placing the television set on tall furniture (for example, cupboards or bookcases) without

anchoring both the furniture and the television set to a suitable support.

• Not standing the television set on cloth or other materials placed between the television and supporting furniture.

• Educating children about the dangers of climbing on furniture to reach the television set or its controls. If your existing television set is being

retained and relocated, the same considerations

as above should be applied.

WALL MOUNTING WARNINGS

• Read the instructions before mounting your TV on the wall.

• The wall mount kit is optional. You can obtain from your local dealer, if not supplied with your TV.

• Do not install the TV on a ceiling or on an inclined

wall.

• Use the specied wall mounting screws and other

accessories.

• Tighten the wall mounting screws rmly to prevent

the TV from fall. Do not over-tighten the screws.

WARNING

Apparatus connected to the protective earthing of the building installation through the MAINS connection or through other apparatus with a connection to protective earthing – and to a television distri-

bution system using coaxial cable, may in some circumstances create a re hazard. Connection to

a television distribution system has therefore to be provided through a device providing electrical isolation below a certain frequency range (galvanic

isolator, see EN 60728-11)

Symbols in this Instruction Book

The following symbols are used in the Instruction Book as a marker for restrictions and precautions and safety instructions. Note such information for security reasons.

WARNING

If you do not pay attention to such a marked warning, it can cause serious injury or death. Note these warnings strictly, in order to ensure a safe operation.

CAUTION

Such a precaution is marked, you should take up or note, to avoid injury or property damage. Note these instructions strictly, in order to ensure a safe operation.

IMPORTANT

Warnings on the appliance and restrictions are displayed like this. Read this information strictly in order to operate the system correctly and avoid damage.

NOTE

Information about the operation and additional explanations are marked like this. To be aware of such information is recommended to ensure that the functions can be used optimally.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 5 -

Markings on the Product

The following symbols are used on the product as a marker for restrictions and precautions and safety instructions. Each explanation shall be considered where the product bears related marking only. Note such information for security reasons.

Class II Equipment: This appliance is designed in such a way that it does not require a safety connection to electrical earth.

Class II Equipment With Functional Earthing: This appliance is designed in such

a way that it does not require a safety

connection to electrical earth, the earth connection is

used for functional purposes.

Protective Earth Connection: The marked terminal is intended for connection of the protective earthing conductor associated with

the supply wiring.

Hazardous Live Terminal: The marked

terminal(s) is/are hazardous live under normal

operating conditions.

Caution, See Operating Instructions: The marked area(s) contain(s) user replaceable

coin or button cell batteries.

Class 1 Laser Product:

CLASS 1 LASER PRODUCT

This product contains Class 1 laser source that is safe under reasonably foreseeable conditions of operation.

The illustrations and the OSD in this operation manual are for explanation purposes and may vary slightly from the actual operations.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 6 -

Support

Technical experts are available 7 days a week

• Simple help and advice on setting up your digital equipment (image).

• Guidance on connecting other devices to your television such as a DVD player, Sky, home cinema system or a games console.

• Order spare parts, including that lost remote control.

• Any other technical issues you may need assistance with.

Call us today: 0345 604 0105

Local call rates applies*

Lines open 9am-8pm Monday to Saturday and 10am-4pm Sunday

*Calls to Argos enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tariff. Mobile and other providers costs may vary, see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from customer service

centres maybe recorded and monitored. Calls from Republic of Ireland will attract international call charges.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 7 -

Environmental Information

This television is designed to be environment friendly.

To reduce energy consumption, you can follow these

steps: If you set the Energy Saving to Minimum, Medium,

Maximum or Auto the TV will reduce the energy consumption accordingly. If you like to set the

Backlight to a xed value set as Custom and adjust

the Backlight (located under the Energy Saving setting) manually using Left or Right buttons on the remote. Set as Off to turn this setting off.

Note: Available Energy Saving options may differ depending on the selected Mode in the Picture menu.

The Energy Saving settings can be found in the Picture menu. Note that some picture settings will

be unavailable to be changed. If pressed Right button while Auto option is selected or

Left button while Custom option is selected, “Screen will be off in 15 seconds.” message will be displayed on the screen. Select Proceed and press OK to turn the screen off immediately. If you don’t press any button, the screen will be off in 15 seconds. Press any button on the remote or on the TV to turn the screen on again.

Note: Screen Off option is not available if the Mode is set to Game.

When the TV is not in use, please switch off or

disconnect the TV from the mains plug. This will also reduce energy consumption.

Features

• TV supports Ultra HD (Ultra High Denition - also

known as 4K) which provides resolution of 3840 x 2160 (4K:2K). It equals 4 times the resolution of Full HD TV by doubling the pixel count of the Full HD TV

both horizontally and vertically. Ultra HD contents are supported from HDMI, USB inputs and over DVB-T2

and DVB-S2 broadcasts.

• Remote controlled colour TV

• Fully integrated digital terrestrial TV (DVB-T-T2)

• HDMI inputs to connect other devices with HDMI

sockets

• USB input

• OSD menu system

• Scart socket for external devices (such as DVD

Players, PVR, video games, etc.)

• Stereo sound system

• Teletext

• Headphone connection

• Automatic programming system

• Manual tuning

• Automatic power down after up to eight hours.

• Sleep timer

• Child lock

• Automatic sound mute when no transmission.

• NTSC playback

• AVL (Automatic Volume Limiting)

• PLL (Frequency Search)

• PC input

• Game Mode (Optional)

• Picture off function

• Ethernet (LAN) for Internet connectivity and service

• 802.11 a/b/g/n built in WIFI Support

• Audio Video Sharing

Accessories Included

• Remote Control

• Batteries: 2 x AAA

• Instruction Book

• Quick Start Guide

Standby Notications

If the TV does not receive any input signal (e.g. from an aerial or HDMI source) for 5 minutes, it will go

into standby. When you next switch-on, the following

message will be displayed: “TV switched to stand-by

mode automatically because there was no signal for a long time.” Press OK to continue.

If the TV is on and it isn’t being operated for a while

it will go into standby. When you next switch-on, the

following message will be displayed. “TV switched to

stand-by mode automatically because no operation was made for a long time.” Press OK to continue.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 8 -

TV Control & Operation

P+

V+

V-

P-

The joystick allows you to control the Volume /

Programme / Source and Standby-On functions of the TV.

Note: The position of the joystick may differ depending on

the model.

To change volume: Increase the volume by pushing

the joystick right. Decrease the volume by pushing the joystick left.

To change channel: Scroll through the stored

channels by pushing the joystick up or down.

To change source: Press the centre of the joystick in, the sources list will appear on the screen. Scroll through the available sources by pushing the joystick

up or down.

To turn the TV off: Press the centre of the joystick in and hold it down for a few seconds, the TV will turn

into standby mode.

To turn on the TV: Press the centre of the joystick in, the TV will turn on.

Note: Main menu OSD cannot be displayed via control button.

Operation with the Remote Control

Press the Menu button on your remote control to display main menu screen. Use the directional buttons to select a menu tab and press OK to enter. Use the directional buttons again to select or set an item. Press

Return/Back or Menu button to quit a menu screen.

Input Selection

Once you have connected external systems to your TV, you can switch to different input sources. Press the Source button on your remote control consecutively to select the different sources.

Changing Channels and Volume

You can change the channel and adjust the volume

by using the Volume +/- and Programme +/- buttons on the remote.

Inserting the Batteries into the Remote

Remove the back cover to reveal the battery compartment. Insert two size AAA batteries. Make sure the (+) and (-) signs match (observe correct polarity). Do not mix old and new batteries. Replace only with same or equivalent type. Place the cover back on.

Connect Power

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz socket. After unpacking, allow

the TV set to reach the ambient room temperature before you connect the set to the mains. Plug the power cable to the mains socket outlet.

Antenna Connection

Connect the aerial plug to the AERIAL INPUT (ANTTV) socket located on the rear bottom side of the TV.

Rear bottom side of the TV

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 9 -

Notication

TRADEMARK ACKNOWLEDGMENT

The terms HDMI and High-Definition Multimedia

Interface, and the HDMI Logo are trademarks or

registered trademarks of HDMI Licensing LLC in the United States and other countries.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

YouTube and the YouTube logo are trademarks of Google Inc.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a trademark of DTS, Inc.© DTS, Inc.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, DTS-HD, the Symbol, & DTS or DTS-HD

and the Symbol together are registered trademarks of

Disposal information

Instructions for waste disposal:

Packaging and packaging aids are recyclable and should

principally be recycled. Packaging materials, such as foil bag, must be kept away from children. Batteries, including those which are heavy metal-free, should not be disposed

of with household waste. Please dispose of used battery in an environment friendly manner. Find out about the legal regulations which apply in your area.

Don’t try to recharge batteries. Danger of explosion. Replace batteries only with the same or equivalent type.

Information for Users in European Union Countries

The mark shown on the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries as unsorted

municipal waste, but use the return and

collection systems available. If the batteries or accumulators included with this equipment

display the chemical symbol Hg, Cd, or Pb,

then it means that the battery has a heavy

metal content of more than 0.0005% Mercury, or more than 0.002% Cadmium or more than,

0.004% Lead.

This product contains technology subject to certain

intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is prohibited without the appropriate license(s) from Microsoft.

Content owners use Microsoft PlayReady™ content access technology to protect their intellectual

property, including copyrighted content. This device

uses PlayReady technology to access PlayReadyprotected content and/or WMDRM-protected content. If the device fails to properly enforce restrictions on

content usage, content owners may require Microsoft

to revoke the device’s ability to consume PlayReadyprotected content. Revocation should not affect unprotected content or content protected by other content access technologies. Content owners may require you to upgrade PlayReady to access their

content. If you decline an upgrade, you will not be able

to access content that requires the upgrade.

English - 10 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Specication

TV Broadcasting

Receiving Channels

Digital Reception

Number of Preset Channels

Channel Indicator On Screen Display

RF Aerial Input 75 Ohm (unbalanced)

Operating Voltage 220-240V AC, 50Hz.

Audio DTS TruSurround HD

Audio Output Power (WRMS.) (10% THD)

Power Consumption (W) 135W

Weight (kg) 11,90

TV Dimensions DxLxH (with foot) (mm)

TV Dimensions DxLxH (without foot) (mm)

Display 50”

Operation temperature and operation humidity

PAL BG/I/DK/LL’ SECAM BG/DK

VHF (BAND I/III) - UHF (BAND U) - HYPERBAND

Fully integrated digital terrestrial-cable TV (DVB-T-C) (DVB-T2 compliant)

1.000

2x10W

274 x 1134 x 722

60/91 x 1134 x 670

0ºC up to 40ºC, 85%

humidity max

Wireless LAN Transmitter Specications

Frequency Ranges

2400 - 2483,5 MHz (CH1-CH13) < 100 mW

5150 - 5250 MHz (CH36 - CH48) < 200 mW

5250 - 5350 MHz (CH52 - CH64) < 200 mW

5470 - 5725 MHz (CH100 - CH140) < 200 mW

Country Restrictions

This device is intended for home and ofce use in

all EU countries (and other countries following the relevant EU directive) without any limitation except for the countries mentioned below.

Country Restriction

Bulgaria

France In-door use only for 2454-2483.5 MHz

Italy

Greece

Luxembourg

Norway

Russian Federation

General authorization required for outdoor

use and public service

If used outside of own premises, general authorization is required

In-door use only for 5470 MHz to 5725 MHz band

General authorization required for network

and service supply(not for spectrum) Radio transmission is prohibited for the

geographical area within a radius of 20 km from the centre of Ny-Ålesund

In-door use only

The requirements for any country may change at any time. It’s recommended that user checks with local authorities for the current status of their national reg-

ulations for both 2.4 GHz and 5 GHz wireless LAN’s.

Max Output Power

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 11 -

Remote Control

1. Standby: Switches On / Off the TV

2. TV: Displays channel list / Switches to TV Source

3. Volume +/-

4. Menu: Displays TV menu

5. OK: Conrms user selections, holds the page (in TXT

mode), views channel list (DTV mode)

6. Back/Return: Returns to previous screen, opens index

page (in TXT mode)

7. Internet: Opens the portal page, where you can reach

many web based applications

8. YouTube: Launches the YouTube application.

9. Freeview Play: Connects to the Freeview Play platform

where you can access available catch-up TV services

10. Coloured Buttons: Follow the on-screen instructions for coloured button functions

11. Language: Displays and changes audio/subtitle

language (digital TV, where available)

12. Rapid reverse: Moves frames backwards in media such as movies

13. Pause: Pauses the media being played

14. No function

15. Play: Starts to play selected media

16. Stop: Stops the media being played

17. Rapid advance: Moves frames forward in media such

as movies

18. Subtitles: Turns subtitles on and off (where available)

19. Screen: Changes the aspect ratio of the screen

20. Text: Displays teletext (where available), press again

to superimpose the teletext over a normal broadcast picture (mix)

21. Media browser: Opens the media browsing screen

22. EPG (Electronic programme guide): Displays the

electronic programme guide

23. Exit: Closes and exits from displayed menus or returns to previous screen

24. Directional buttons: Helps navigate menus, content etc. and displays the subpages in TXT mode when

pressed Right or Left

25. Quick Menu: Displays a list of menus for quick access

26. Info: Displays information about on-screen content,

shows hidden information (reveal - in TXT mode)

27. Programme +/-

28. Mute: Completely turns off the volume of the TV

29. Source: Shows all available broadcast and content

sources

30. Numeric buttons: Switches the channel, enters a

number or a letter in the text box on the screen.

31. Netix: Launches the Netix application, if this feature

is supported by your TV

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 12 -

Connections

ideo

Connector Type Cables Device

Scart

Connection

(back)

YPBPR

YPbPr Video

Connection

/ V

AUDIO IN

SPDIF

BACK AV

/ Video

HEADPHONE

LAN

(back)

HDMI

Connection

(bottom&side)

VGA

Connection

(bottom)

PC/YPbPr/

Back AV

Audio

Connection

(back)

SPDIF

(Optical Out)

Connection

(bottom)

Back AV

(Audio/Video)

Connection

(back)

Headphone Connection

(side)

USB

Connection (back&side)

Connection

(side)

Ethernet

Connection

(bottom)

Subwoofer

Connection

(back)

YPbPr Connection Cable

YPbPr/PC Audio Cable

Audio Video Cable

LAN / Ethernet Cable

CAM

module

NOTE: When connecting a device via the YPbPr or Back AV input, you must use the connection cables to enable connection. See the illustrations

on the left side. | To enable PC/YPbPr audio, you will need to use the Back Audio inputs with a YPbPr/PC audio cable for audio connection. | If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.| When receiving DTV channels (Mpeg4 H.264) or while in Media Browser mode, output will not be available via the scart socket. | When using the wall mounting kit (available from third party in the market, if not supplied), we recommend that you plug all your cables into the back of the TV before mounting on the wall. | Insert or remove the CI module only when the TV is SWITCHED OFF. You should refer to the module instruction manual for details of the settings. | The USB

2.0 inputs on the back side and on the left side of the TV support devices up to 500mA. Connecting devices that have current value above 500mA may damage your TV. If available, for the optional USB 3.0 input on the left side of the TV, which will be positioned above the other USB input, this limit value is 1A. | By connecting an HDMI cable to your TV, you have to use only a shielded (high grade) HDMI cable with

ferrites to guarantee a sufcient

immunity and emission against parasitic frequency radiation. And make sure to use a High-Speed HDMI cable that can transmit

high denition signals, such as

4K contents, for trouble-free transmission.

If you want to connect a

device to the TV, make

sure that both the TV and the device are turned off before making any connection.

After the connection is done, you

can turn on the units and use them.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 13 -

Switching On/Off

To Switch the TV On

Connect the power cord to a power source such as a

wall socket (220-240V AC, 50 Hz).

To switch on the TV from standby mode either:

• Press the Standby button, Programme +/- or a numeric button on the remote control.

• Press the centre of the joystick on the TV in or push

it up/down until the TV comes on from standby.

To Switch the TV Off

Press the Standby button on the remote control or

press the centre of the joystick on the TV in and hold it down for a few seconds, the TV will switch into

standby mode.

To power down the TV completely, unplug the power cord from the mains socket.

Note: When the TV is switched into standby mode, the standby LED can blink to indicate that features such as Standby Search, Over Air Download or Timer is active. The LED can also blink when you switch on the TV from standby mode.

First Time Installation

When turned on for the first time, the language

selection screen is displayed. Select the desired language and press OK.

On the next screen, set your preferences using the

directional buttons.

Note: Depending on the Country selection you may be asked

to set and conrm a PIN at this point. The selected PIN cannot be 0000. You have to enter it if you are asked to enter a PIN

for any menu operation later.

About Selecting Broadcast Type

Digital Aerial: If Digital Aerial broadcast search

option is turned on, the TV will search for digital

terrestrial broadcasts after other initial settings are completed.

Additionally you can set a broadcast type as your favourite one. Priority will be given to the selected broadcast type during the search process and the channels of it will be listed on the top of the Channel List. When nished, press OK to continue.

You can activate Store Mode option at this point.

This option will congure your TV’s settings for store

environment and depending on the TV model being

used, the supported features of it may be displayed

on the top of the screen as an info banner. This option is intended only for store use. It is recommended to select Home Mode for home use. This option will be available in Settings>More menu and can be turned off/on later.

Press OK button on the remote control to continue and the Network/Internet Settings menu will be

displayed, if you conrm the previously displayed

English - 14 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

message asking whether you want to do the network settings. Please refer to Connectivity section to

congure a wired or a wireless connection. After the

settings are completed press OK button to continue. To skip to the next step without doing anything select No and press the OK button when the message is displayed asking whether you want to do the network settings.

On the next screen you need to agree to the terms and conditions of Freeview Play to make use of the related services. Scroll the page to read the entire text using the up/down directional buttons or Programme +/- buttons. Highlight Yes and press OK on the remote to conrm and proceed. Highlight No and press OK to proceed without conrmation. For further requirements for Freeview Play services refer to the Freeview Play Platform section.

After the initial settings are completed TV will start to search for available broadcasts of the selected broadcast types.

After all the available stations are stored, scan results

will be displayed. Press OK to continue. The Edit Channel List menu will be displayed next. You can

edit the channel list according to your preferences or press the Menu button to quit and watch TV.

While the search continues a message may appear,

asking whether you want to sort channels according to the LCN(*). Select Yes and press OK to conrm.

(*) LCN is the Logical Channel Number system that organizes available broadcasts in accordance with a recognizable

channel number sequence (if available).

Note: Do not turn off the TV while initializing first time installation. Note that, some options may not be available

depending on the country selection.

Media Playback via USB Input

You can connect 2.5” and 3.5” inch (hdd with external power supply) external hard disk drives or USB memory stick to your TV by using the USB inputs of the TV.

IMPORTANT! Back up the les on your storage devices

before connecting them to the TV. Manufacturer will

not be responsible for any le damage or data loss.

Certain types of USB devices (e.g. MP3 Players) or USB hard disk drives/memory sticks may not be compatible with this TV. The TV supports FAT32 and NTFS disk formatting.

Wait a little while before each plugging and unplugging

as the player may still be reading les. Failure to do

so may cause physical damage to the USB player and the USB device itself. Do not pull out your drive

while playing a le.

You can use USB hubs with your TV’s USB inputs. External power supplied USB hubs are recommended in such a case.

It is recommended to use the TV’s USB input(s)

directly, if you are going to connect a USB hard disk.

Note: When viewing image les the Media Browser menu can only display 1000 image les stored on the connected

USB device.

Media Browser Menu

You can play photo, music and movie les stored on a

USB disk by connecting it to your TV. Connect a USB disk to one of the USB inputs located on the side of the TV. Pressing the Menu button while in the Media

Browser mode will access the Picture, Sound and Settings menu options. Pressing the Menu button

again will exit from this screen. You can set your Media Browser preferences by using the Settings menu.

Loop/Shufe Mode Operation

Start playback with the Play button and activate

Start playback with the OK button and activate

Start playback with the Play button and activate

Start playback with the Play button and activate ,

All les in the list will be

continuously played in original order

The same le will be played

continuously (repeat)

All les in the list will be

played once in random order

All les in the list will be

continuously played in the same random order.

FollowMe TV (if available)

With your mobile device you can stream the current broadcast from your smart TV using the FollowMe TV feature. Install the appropriate Smart Centre application to your mobile device. Start the application. For further information on using this feature refer to the instructions of the application you use.

Note: This application may not be compatible with all mobile devices. Both of the devices must be connected to the same network.

CEC and CEC RC Passthrough

This function allows to control the CEC-enabled

devices, that are connected through HDMI ports by

using the remote control of the TV. The CEC option in the Settings>More menu should

be set as Enabled at rst. Press the Source button and select the HDMI input of the connected CEC device from the Sources List menu. When new CEC

source device is connected, it will be listed in source

menu with its own name instead of the connected

HDMI ports name(such as DVD Player, Recorder

1 etc.). The TV remote is automatically able to perform the

main functions after the connected HDMI source has been selected.

To terminate this operation and control the TV via

the remote again, press Quick Menu button on the remote, highlight the CEC RC Passthrough and

set as Off by pressing Left or Right button. This feature can also be enabled or disabled under the

Settings>More menu.

English - 15 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

The TV supports also ARC(Audio Return Channel) feature. This feature is an audio link meant to replace other cables between the TV and the audio system (A/V receiver or speaker system).

When ARC is active, TV does not mute its other audio

outputs automatically. So you need to decrease TV

volume to zero manually, if you want to hear audio

from connected audio device only (same as other optical or co-axial digital audio outputs). If you want

to change connected device’s volume level, you

should select that device from the source list. In that case volume control keys are directed to connected audio device.

Note: ARC is supported only via the HDMI3 input.

System Audio Control

Allows an Audio Amplier/Receiver to be used with

the TV. The volume can be controlled using the remote control of the TV. To activate this feature set the Speakers option in the Settings>More menu as Amplier. The TV speakers will be muted and the sound of the watched source will be provided from the connected sound system.

Note: The audio device should support System Audio Control feature and CEC option should be set as Enabled.

TV Menu Contents

Picture Menu Contents

PC Position

Autoposition

Reset

You can change the picture mode to suit your preference or requirements. Picture mode

Mode

Contrast

Brightness

Sharpness

Colour

Energy Saving

Backlight

Advanced Settings

Dynamic Contrast

Noise Reduction

Colour Temp

White Point

Picture Zoom

Film Mode

Skin Tone

Colour Shift

HDMI Full Range

H Position

V Position

Dot Clock

Phase

While in VGA (PC) mode, some items in Picture menu will be unavailable. Instead, VGA mode settings will be added to the Picture Settings while in PC mode.

can be set to one of these options: Cinema, Game (optional), Sports, Dynamic and Natural.

Adjusts the light and dark values on the screen.

Adjusts the brightness values on the screen.

Sets the sharpness value for the objects displayed on the screen.

Sets the colour value, adjusting the colours.

For setting the Energy Saving to Custom, Minimum, Medium, Maximum, Auto, Screen Off or Off.

Note: Available options may differ depending on the selected Mode.

This setting controls the backlight level. The backlight function will be inactive if the Energy Saving is set to an option other then Custom.

You can change the dynamic contrast ratio to desired value.

If the signal is weak and the picture is noisy, use the Noise Reduction setting to reduce the amount of noise.

Sets the desired colour temperature value. Cool, Normal, Warm and Custom options are available.

If the Colour Temp option is set as Custom, this setting will be available. Increase the ‘warmth’ or ‘coolness’ of the picture by pressing Left or Right buttons.

Sets the desired image size format.

Films are recorded at a different number of frames per second to normal television programmes.

Turn this feature on when you are watching lms to see the fast motion scenes clearly.

Skin tone can be changed between -5 and 5.

Adjust the desired colour tone.

While watching from a HDMI source, this feature will be visible. You can use this feature to

enhance blackness in the picture.

Appears only when the input source is set to VGA/PC.

Automatically optimizes the display. Press OK to optimize.

This item shifts the image horizontally to the right hand side or left hand side of the screen.

This item shifts the image vertically towards the top or bottom of the screen.

Dot Clock adjustments correct the interference that appear as vertical banding in dot

intensive presentations like spreadsheets or paragraphs or text in smaller fonts.

Depending on the input source(computer etc.) you may see a hazy or noisy picture on the

screen. You can use phase to get a clearer picture by trial and error.

Resets the picture settings to factory default settings (except Game mode).

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 16 -

Sound Menu Contents

Volume

Equalizer

Balance

Headphone

Sound Mode

AVL (Automatic Volume Limiting)

Headphone/Lineout

Dynamic Bass

DTS TruSurround HD

Digital Out

Adjusts the volume level.

Selects the equalizer mode. Custom settings can be made only when in User mode.

Adjusts whether the sound comes from the left or right speaker.

Sets headphone volume. Please ensure before using headphones that the headphone volume is set to a low

level, to prevent damage to your hearing.

You can select a sound mode (If the viewed channel supports).

Sets the sound to obtain xed output level between programmes.

When you connect an external amplier to your TV using the headphone jack, you

can select this option as Lineout. If you have connected headphones to the TV, set this option as Headphone.

Please ensure before using headphones that this menu item is set to Headphone. If it is set to Lineout, the output from the headphone socket will be set to maximum which could damage your hearing.

Enables or disables the Dynamic Bass.

Enables or disables the DTS TruSurround HD.

Sets digital out audio type.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 17 -

Settings Menu Contents

Conditional Access

Hard of Hearing

If this feature is supported by your TV, you can view your ESN(*) number and deactivate

Upgrade

Version

Language

Parental

Timers

Date/Time

Sources

Network/Internet Settings

Accessibility

Audio Description

Controls conditional access modules when available.

You may set a different language depending on the broadcaster and the country.

Enter correct password to change parental settings. You can easily adjust Menu Lock, Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or change the Default CICAM PIN using the related options.

Note: Some menu options may not be available depending on the country selection in the First Time Installation. Default PIN can be set to 0000 or 1234. If you have dened the PIN(is requested depending on

the country selection) during the First Time Installation use the PIN that you have dened.

Sets sleep timer to turn off the TV after a certain time. Sets timers for selected programmes.

Sets date and time.

Enables or disables selected source options. There are Regular, Enhanced and Disabled options available for HDMI sources. Regular and Enhanced options are affecting the colour settings of the selected HDMI source. To be able to watch 4K images from an HDMI source related source setting should be set as Enhanced if the connected device is HDMI 2.0 compatible. Set as Regular if the connected device is HDMI 1.4 compatible. Set acoordingly or disable the related HDMI source by setting as Disabled.

Displays network/internet settings.

Displays accessibility options of the TV.

Enables any special feature sent from the broadcaster.

A narration track will be played for the blind or visually impaired audience. Press OK to see all available Audio Description menu options. This feature is available only if the broadcaster supports it.

Netix

Menu Timeout

Software

Application

Subtitle Mode

Auto TV OFF

Store Mode

Audio Video Sharing

Netix.

(*) ESN number is an unique ID number for Netix, created especially to identify your TV.

Displays other setting options of the TV.

Changes timeout duration for menu screens.

Ensures that your TV has the latest rmware. Press OK to see the menu options.

Displays current software version.

This option is used to select which subtitle mode will be on the screen (DVB subtitle / Teletext subtitle) if both is available. Default value is DVB subtitle. This feature is available only for the country option of Norway.

Sets the desired time for the TV to automatically go into standby mode when not being operated. This option can be set from 1 to 8 hours in steps of 1 hour. You can also disable this option by setting as Off.

Select this mode for store display purposes. Whilst Store Mode is enabled, some items in the TV menu may not be available.

Audio Video Sharing feature allows you to share les stored on your smartphone or tablet pc. If you have a compatible smartphone or tablet pc and the appropriate software is installed,

you can share/play photos on your TV. See instructions of your sharing software for more information. Audio Video Sharing mode will not be available with internet portal feature.

English - 18 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Power Up Mode

Virtual Remote

Installation Menu Contents

CEC

CEC Auto Power On

Speakers

This setting congures the power up mode preference. Last State and Standby options are available.

Enable or disable the virtual remote feature.

With this setting you can enable and disable CEC functionality completely. Press Left or Right button to enable or disable the feature.

This function allows the connected HDMI-CEC compatible device to turn on the TV and switch to its input source automatically. Press Left or Right button to enable or disable the feature.

To hear the TV audio from the connected compatible audio device set as Amplier. You can use the remote control of the TV to control the volume of the audio device.

Automatic channel scan (Retune)

Manual channel scan

Network channel scan

First time installation

Displays automatic tuning options. Digital Aerial: Searches and stores aerial DVB stations.

This feature can be used for direct broadcast entry.

Searches for the linked channels in the broadcast system. Digital Aerial: Searches for aerial network channels.

Deletes all stored channels and settings, resets TV to factory settings.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 19 -

General TV Operation

Using the Channel List

The TV sorts all stored stations in the Channel List.

You can edit this channel list, set favourites or set

active stations to be listed by using the Channel List options. Press the OK/TV button to open the Channel

List. You can lter the listed channels by pressing the Blue button or open the Edit Channel List menu by

pressing the Green button in order to make advanced changes in the current list.

Managing the Favourite Lists

You can create four different lists of your favourite channels. Enter the Channel List in the main menu or press the Green button while the Channel List is displayed on the screen in order to open the Edit Channel List menu. Select the desired channel on the list. You can make multiple choices by pressing the Yellow button. Then press the OK button to open the Channel Edit Options menu and select Add/ Remove Favourites option. Press the OK button again. Set the desired list option to On. The selected channel/s will be added to the list. In order to remove a channel or channels from a favourite list follow the same steps and set the desired list option to Off.

You can use the Filter function in the Edit Channel

List menu to lter the channels in the Channel list

permanently according to your preferences. Using this

Filter option, you can set one of your four favourite lists to be displayed everytime the Channel list is

opened. The ltering function in the Channel list menu will only lter the currently displayed Channel list in order to nd a channel and tune in to it. This

changes will not remain the next time the Channel list is opened.

Conguring Parental Settings

The Parental Settings menu options can be used to

prohibit users from viewing of certain programmes,

channels and using of menus. These settings are located in the Settings>Parental menu.

To display parental lock menu options, a PIN number

should be entered. After coding the correct PIN

number, Parental Settings menu will be displayed. Menu Lock: This setting enables or disables access

to all menus or installation menus of the TV. Guidance: This setting enables or disables access

some of the MHEG applications. Disabled applications can be released by entering the right PIN.

Internet Lock: If this option is set to ON, the open browser application in the portal will be disabled. Set to OFF to release the application again.

Set PIN: Denes a new PIN number. Default CICAM PIN: This option will appear as greyed

out if no CI module is inserted into the CI slot of the

English - 20 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

TV. You can change the default PIN of the CI CAM using this option.

Note: Default PIN can be set to 0000 or 1234. If you have defined the PIN(is requested depending on the country selection) during the First Time Installation use the PIN that you have dened.

Some options may not be available depending on the country selection in the First Time Installation.

Electronic Programme Guide (EPG)

Some channels send information about their broadcast schedules. Press the Epg button to view the Programme Guide menu.

There are 3 different types of schedule layouts

available, Timeline Schedule, List Schedule and Now/Next Schedule. To switch between them follow

the instructions on the bottom of the screen.

Timeline Schedule

Zoom (Yellow button): Press the Yellow button to

see events in a wider time interval.

Filter (Blue button): Views ltering options. Select Genre (Subtitles button): Displays Select Genre menu. Using this feature, you can search the

programme guide database in accordance with the genre. Info available in the programme guide will be searched and results matching your criteria will be highlighted.

Options (OK button): Displays event options. Event Details (Info button): Displays detailed

information about selected programmes. Next/Prev Day (Programme +/- buttons): Displays the programmes of previous or next day.

Search (Text button): Displays Guide Search menu. Now (Swap button): Displays current event of the

highlighted channel.

List Schedule(*)

(*) In this layout option, only the events of the highlighted channel will be listed.

Prev. Time Slice (Red button): Displays the programmes of previous time slice. Next/Prev Day (Programme +/- buttons): Displays the programmes of previous or next day. Event Details (Info button): Displays detailed information about selected programmes.

Filter (Text button): Views ltering options. Next Time Slice (Green button): Displays the

programmes of next time slice.

Options (OK button): Displays event options.

Now/Next Schedule

Navigate (Directional buttons): Press the Directional buttons to navigate through the channels

and programmes.

Options (OK button): Displays event options. Event Details (Info button): Displays detailed

information about selected programmes.

Filter (Blue button): Views ltering options.

Programme Options

Use the directional buttons to highlight a programme and press OK button to display Event Options menu. The following options are available.

Select Channel: Using this option, you can switch to

the selected channel. Set Timer on Event / Delete Timer on Event: After

you have selected a programme in the EPG menu,

press the OK button. Select Set Timer on Event option and press the OK button. You can set a timer

for future programmes. To cancel an already set timer,

highlight that programme and press the OK button. Then select Delete Timer on Event option. The timer will be cancelled.

Notes: You cannot switch to any other channel while there is an active timer on the current channel.

It is not possible to set timer for two or more individual events at the same time interval.

Integrated Catch-Up Services

You can enjoy Freeview Play catch-up TV services

that work directly through the electronic programme guide(EPG). Whilst you are on a channel use the directional buttons to scroll back in time through the timeline-based EPG. You will see contents from last few days. Available catch-up contents may change according to broadcasters and will be marked with a play icon. Highlight the content you want to play back and press the OK button.

Make sure that your TV is connected to your home network in order to use the catch-up services. For further information regarding this matter and other requirements for Freeview Play services refer to the

Connectivity and Freeview Play Platform sections.

Digital Teletext

Press the Text button to view digital teletext information.

Operate it with the coloured buttons, cursor buttons

and the OK button. The operation method may differ depending on the contents of the digital teletext. Follow the instructions displayed on the digital teletext screen. When the Text button is pressed again, the TV returns to television broadcast.

BBC Connected Red Button (CRB)

While watching BBC channels, press the Red button to access digital TV services provided by the BBC. Under the tab ‘Featured’ highlight Connected Red Button and press OK to start the service. On the opening page you

can access to BBC’s main services such as BBC iPlayer, BBC News, BBC Sport and many others. There are

also links to the home pages of the related applications available. Use the navigation buttons on the TV’s remote control to move through the application. Press Exit button to close and exit.

Software Upgrade

Your TV is capable of nding and updating the rmware

automatically via the broadcast signal or via Internet.

Software upgrade search via user interface

On the main menu select Settings and then More. Navigate to Software upgrade and press the OK button. In Upgrade options menu select Scan for upgrade and press OK button to check for a new software upgrade.

If a new upgrade is found, it starts to download

the upgrade. After the download is completed confirm the question asking about rebooting the TV by pressing the OK to continue with the reboot operation.

3 AM search and upgrade mode

Your TV will search for new upgrades at 3:00 o’clock if Automatic scanning option in the Upgrade options menu is set to Enabled and if the TV is connected to an aerial signal or to Internet. If a new software is

found and downloaded successfully, it will be installed

at the next power on.

Note: Do not unplug the power cord while led is blinking during the reboot process. If the TV fails to come on after the upgrade, unplug, wait for two minutes then plug it back in.

Firmware Update via the Internet

Note: Connect TV to the internet (via WiFi or Ethernet) Manual Download (Pull)

1. Press Menu on your remote control and continue through to System → Settings → More… → Software Upgrade → Scan for Upgrade

2. The TV will download and run the upgrade automatically

3. Please make sure to keep your TV on for the duration of the upgrade – do not power off!

4. During the upgrade, the picture will turn off

but don’t worry as this means the update has

started. The standby light will ash slowly at rst

to download and then fast as the upgrade starts.

5. After the download is complete, your TV will reboot and show a pop-up screen of how to launch the Freeview Play portal via your remote control

6. Press EXIT to leave the pop-up screen, then press

FPlay button on the remote control to bring up the Freeview Play Manufacturer T&Cs

7. The Freeview Play Manufacturer T&Cs will appear

8. Press Page Up to scroll through the T&Cs quicker;

you must accept the T&Cs in order for Freeview Play to work.

9. After accepting the T&Cs, you will be able to access Freeview Play and enjoy everything it

has to offer.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 21 -

Automatic Download (Push)

1. Turn your TV on, a pop-up menu about the

upgrade will show after 10 - 20 minutes

2. Press OK to start upgrading your TV

3. Please make sure to keep your TV on for the

duration of the upgrade – do not power off!

4. During the upgrade, the picture will turn off

but don’t worry as this means the update has

started. The standby light will ash slowly at rst

to download and then fast as the upgrade starts.

5. After the download is complete, your TV will

reboot and show a pop-up screen of how to launch the Freeview Play portal via your remote control

6. Press EXIT rst and then FPlay button on the

remote control to bring up the Freeview Play Manufacturer T&Cs

7. The Freeview Play Manufacturer T&Cs will appear

8. Press Page Up to scroll through the T&Cs quicker;

you must accept the T&Cs in order for Freeview Play to work.

9. After accepting the T&Cs, you will be able to access Freeview Play and enjoy everything it

has to offer.

Troubleshooting & Tips

Tv will not turn on

Make sure the power cord is plugged in securely to wall outlet. Check if batteries are exhausted. Press the Power button on the TV.

Poor picture

• Check if you have selected the correct TV system.

• Low signal level can cause picture distortion. Please

check antenna access.

• Check if you have entered the correct channel

frequency if you have done manual tuning.

• The picture quality may degrade when two devices

are connected to the TV at the same time. In such

a case, disconnect one of the devices.

No picture

• This means your TV is not receiving any transmission.

Make sure the correct source has been selected.

• Is the antenna connected properly?

• Is the antenna cable damaged?

• Are suitable plugs used to connect the antenna?

• If you are in doubt, consult your dealer.

No sound

• Check if the TV is muted. Press the Mute button or

increase the volume to check.

• Sound may be coming from only one speaker. Check

the balance settings from Sound menu.

Remote control - no operation

• The batteries may be exhausted. Replace the batteries.

Input sources - can not be selected

• If you cannot select an input source, it is possible

that no device is connected. If not;

• Check the AV cables and connections if you are trying to switch to the input source dedicated to the connected device.

To Program Your SKY Remote For Your TV

1. Make sure your SKY box is connected to your TV

2. Turn your TV and SKY box on

3. Press TV on your SKY remote control handset

4. Hold down SELECT and the RED button together

for about two seconds, until the red light on the

SKY remote blinks twice.

5. Key in 1177 on your SKY remote. The light on the

SKY remote should blink twice

6. Press the STANDBY button on your SKY remote

control. Your TV should now switch off.

7. Press SELECT again. The light on your SKY

remote control should now blink twice

You should now be able to control some basic functions on your TV from your SKY remote control

(e.g. volume up/down, programme up/down).

*If this number does not work, please go to SKY website to

nd the alternative number to operate the TV.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 22 -

PC Input Typical Display Modes

Source

Supported Signals

Available

The following table is an illustration of some of the typical video display modes. Your TV may not support all resolutions.

Index Resolution Frequency

1 640x350 85Hz 2 640x480 60Hz 3 640x480 72Hz 4 640x480 75Hz 5 800x600 56Hz 6 800x600 60Hz 7 800x600 72Hz 8 800x600 75Hz

9 1024x768 60Hz 10 1024x768 70Hz 11 1024x768 75Hz 12 1024x768 85Hz 13 1152x864 75Hz 14 1280x768 60Hz 15 1280x768 75Hz 16 1280x960 60Hz 17 1280x960 75Hz 18 1280x1024 60Hz 19 1280x1024 75Hz 20 1360x768 60Hz 21 1366x768 60Hz 22 1400x1050 59Hz 23 1400x1050 60Hz 24 1400x1050 75Hz 25 1440x900 60Hz 26 1440x900 75Hz 27 1600x1200 60Hz 28 1680x1050 59Hz 29 1680x1050 60Hz 30 1920x1080 60Hz

AV and HDMI Signal Compatibility

PAL O

EXT

(SCART)

SECAM O NTSC4.43 O NTSC3.58 RGB 50/60 O PAL O

Back AV

SECAM O NTSC4.43 O NTSC3.58 O 480i, 480p 60Hz O

YPbPr

576i, 576p 50Hz O 720p 50Hz,60Hz O 1080i 50Hz,60Hz O 480i 60Hz O 480p 60Hz O 576i, 576p 50Hz O 720p 50Hz,60Hz O 1080i 50Hz,60Hz O

24Hz, 25Hz,

1080p

HDMI

30Hz, 50Hz, 60Hz

24Hz, 25Hz,

3840x2160p

30Hz,

50Hz, 60Hz

24Hz, 25Hz,

4096x2160p

30Hz,

50Hz, 60Hz

(X: Not Available, O: Available)

In some cases a signal on the TV may not be displayed properly. The problem may be an inconsistency with

standards from the source equipment (DVD, Set-top box, etc. ). If you do experience such a problem please

contact your dealer and also the manufacturer of the source equipment.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 23 -

Supported Video File Formats for USB Mode

Video Codec Resolution Bit Rate Container

MPEG1/2

MPEG4

XviD MP4 (.mp4, .mov), AVI (.avi), MKV (.mkv), ASF (.asf)

Sorenson H.263 FLV (.v), AVI (.avi), SWF(.swf) H.263 MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv)

H.264

Motion JPEG 720P@30fps 10Mbps

VP8 1080P@30fps 20Mbps MKV (.mkv), WebM (.webm)

HEVC 4K2K@60fps 160Mbps

VP9 4K2K@30fps 100Mbps MKV (.mkv), WebM (.webm)

1080Px2@30fps,

1080P@60fps

3840x2160@30fps,

1080P@60fps

40Mbps

135Mbps

MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf)

MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf)

FLV (.v), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), MPEG transport stream (.ts, .trp, .tp), ASF (.asf), AVI (.avi), MKV (.mkv)

AVI (.avi), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov), MKV (.mkv),

ASF (.asf)

MP4 (.mp4, .mov), MKV (.mkv), MPEG transport stream (.ts, .trp,

.tp)

Supported Picture File Formats for USB Mode

Image Photo Resolution (width x height) Remark

JPEG

PNG

Base-line 15360x8640 Progressive 1024x768 non-interlace 9600x6400 interlace 1200x800

The limit for max resolution depends on

DRAM size

BMP 9600x6400

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 24 -

Supported Audio File Formats for USB Mode

Audio Codec Sample rate Bit Rate Container

MPEG1/2 Layer1 16KHz ~ 48KHz

MPEG1/2 Layer2 16KHz ~ 48KHz

MPEG1/2 Layer3 16KHz ~ 48KHz

AC3

EAC3

AAC, HEAAC 8KHz ~ 48KHz

WMA 8KHz ~ 48KHz

WMA 10 Pro M0 48KHz < 192kbps WMA 10 Pro M1 48KHz < 384kbps WMA 10 Pro M2 96KHz < 768kbps

32KHz, 44.1KHz, 48KHz

G711 A/mu-law 8KHz

8KHz, 11.025KHz,

LBR (cook)

22.05KHz,

44.1KHz

32Kbps ~

448Kbps

8Kbps ~

384Kbps

8Kbps ~

320Kbps

32Kbps ~

640Kbps

32Kbps ~ 6

Mbps

128bps ~

320Kbps

64Kbps ~

128Kbps

6Kbps ~

128Kbps

MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), WAV (.wav)

MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), FLV (.v), WAV (.wav), SWF (.swf)

AC3 (.ac3), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG)

EAC3 (.ec3), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG)

AAC (.aac), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), FLV (.v), RM (.ra)

ASF (.wma, .asf), AVI (.avi), Matroska (.mkv, .mka)

WAV (.wav), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a)

RM (.ra)

FLAC 8KHz~96KHz < 1.6Mbps Matroska (.mkv, .mka)

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 25 -

Supported DVI Resolutions

When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not

supplied), you can refer to the following resolution information.

56Hz 60Hz 66Hz 70Hz 72Hz 75Hz

640x480

800x600

1024x768

1280x768

1280x960

1360x768

1366x768

1280x1024

1400x1050

1600x900

þ þ þ

þ þ

þ þ þ

þ þ

þ þ þ

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 26 -

Connectivity

Wired Connectivity

To Connect to a Wired Network

• You must have a modem/router connected to an active broadband connection.

• Connect your PC to your modem/router. This can be a wired or wireless connection.

• Connect your TV to your modem/router via an ethernet cable. There is a LAN port at the rear (back) of your TV.

Broadband ISP connection

LAN (ethernet) cable

LAN input on the rear side of the TV

• To access and play shared les, you must select the

Media Browser. Press the Menu button and select Media Browser. Press OK to continue. Select the

desired le type and press OK. You must always use the Media Browser screen to access and play

shared network les.

• PC/HDD/Media Player or any other devices that are

compatible should be used with a wired connection for higher playback quality.

To congure wired settings please refer to the

Network/Internet Settings section in the Settings Menu.

• You might be able to connect your TV to your LAN depending on your network’s conguration. In such a case, use an ethernet cable to connect your TV

directly to the network wall outlet.

Conguring Wired Device Settings

Network Type

The Network Type can be selected as Wired Device, Wireless Device or Disabled, in accordance with the active connection to the TV set. Select this as Wired Device if you are connecting via an ethernet.

Internet Speed Test

Highlight Internet Speed Test and press the OK but- ton. TV will check the internet connection bandwidth and display the result when complete.

Advanced Settings

Highlight Advanced Settings and press the OK button. On the next screen you can change the IP and DNS settings of the TV. Highlight the desired one and press Left or Right button to change the setting from Automatic to Manual. Now you can enter the Manual IP and / or Manual DNS values. Select the related item in the drop down menu and enter the new values using the numeric buttons of the remote. Press the OK button to save settings when complete.

Wireless Connectivity

To Connect to a Wireless Network

The TV cannot connect to the networks with a hidden

SSID. To make your modem’s SSID visible, you should

change your SSID settings via the modem’s software.

To Connect to a wireless LAN, you should perform the following steps:

• To congure your wireless settings please refer

to the Network/Internet Settings section in the Settings Menu.

Broadband ISP connection

network

wall socket

A Wireless-N router (IEEE 802.11a/b/g/n) with

simultaneous 2.4 and 5 GHz bands is designed to increase bandwidth. These are optimized for smoother and faster HD video streaming, le transfers and

wireless gaming.

LAN input on the rear side of the TV

English - 27 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

• Use a LAN connection for quicker file sharing between other devices like computers.

• The frequency and channel differ depending on the area.

• The transmission speed differs depending on the

distance and number of obstructions between the

transmission products, the conguration of these products, the radio wave conditions, the line trafc

and the products that you use. The transmission may also be cut off or may get disconnected depending

on the radio wave conditions, DECT phones or any

other WiFi 11b appliances. The standard values of the transmission speed are the theoretical maximum values for the wireless standards. They are not the actual speeds of data transmission.

• The location where the transmission is most effective differs depending on the usage environment.

• The Wireless feature of the TV supports 802.11 a,b,g

& n type modems. It is highly recommended that you should use the IEEE 802.11n communication protocol in order to avoid any possible problems while watching videos.

• You must change your modem’s SSID when there are any other modems around with the same SSID. You can encounter connection problems otherwise. Use a wired connection if you experience problems with a wireless connection.

Conguring Wireless Device Settings

Open the Network/Internet Settings menu and select Network Type as Wireless Device to start connection

process. The TV will scan the wireless networks automatically.

A list of available networks will be displayed. Please select your desired network from the list.

Note: If the modem supports N mode, you should set N

mode settings.

If the selected network is protected with a password,

please enter the correct key by using the virtual keyboard. You can use this keyboard via the directional

buttons and the OK button on the remote control. Wait until the IP address is shown on the screen. This means that the connection is now established.

To disconnect from a wireless network, highlight

Network Type and press Left or Right buttons to set as Disabled.

Highlight Internet Speed Test and press the OK button to check your internet connection speed. Highlight Advanced Settings and press the OK button to open the advanced setting menu. Use directional and numeric buttons to set. Press the OK button to save settings when complete.

Other Information

The status of the connection will be displayed as Connected or Not Connected and the current IP

address, if a connection is established.

Connecting to your mobile device via WiFi

• If your mobile device has WiFi feature, you can connect it to your TV via a router, in order to access the content in your device. For this, your mobile device must have

an appropriate sharing software.

• Connect to your router following the steps stated above in the Wireless Connectivity section.

• Afterwards, engage your mobile device with the router

and then activate the sharing software on your mobile

device. Then, select les that you want to share with

your TV.

• If the connection is established correctly, you will be able to access the shared les from your mobile device

via the Media Browser of your TV.

• Enter the Media Browser menu and the playback device selection OSD will be displayed. Select your mobile device and press the OK button to continue.

• If available, you can download a virtual remote

controller application from the server of your mobile device application provider.

Note: This feature may not be supported on all mobile

devices.

Wireless Display

Wireless Display is a standard for streaming video and sound content by Wi-Fi Alliance. This feature provides the ability to use your TV as wireless display device.

Using with mobile devices

There are different standards which enable sharing of

screens including graphical, video and audio content

between your mobile device and TV. Then press the Source button on the remote and

switch to Wireless Display source. A screen appears stating that the TV is ready for

connection. Open the sharing application on your mobile device.

These applications are named differently for each

brand, please refer to the instruction manual of your

mobile device for detailed information. Scan for devices. After you select your TV and

connect, the screen of your device will be displayed

on your TV.

Note: This feature can be used only if the mobile device supports this feature. Scanning and connecting processes differ according to the programme you use. Android based mobile devices should have the software version V4.2.2 and above.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 28 -

Connectivity Troubleshooting

Wireless Network Not Available

• Ensure that any rewalls of your network allow the

TV wireless connection.

• Try searching for wireless networks again, using the

Network/Internet Settings menu screen.

If the wireless network does not function properly, try

using the wired network in your home. Refer to the Wired Connectivity section for more information on the process.

If the TV does not function using the wired connection,

check the modem (router). If the router does not

have a problem, check the internet connection of

your modem.

Connection is Slow

See the instruction book of your wireless modem to

get information on the internal service area, connection speed, signal quality and other settings. You need to

have a high speed connection for your modem.

Distruption during playback or slow reactions

You could try the following in such a case: Keep at least three meters distance from microwave

ovens, mobile telephones, bluetooth devices or any

other Wi-Fi compatible devices. Try changing the active channel on the WLAN router.

Internet Connection Not Available / Audio Video Sharing Not Working

If the MAC address (a unique identier number) of your PC or modem has been permanently registered,

it is possible that your TV might not connect to

the internet. In such a case, the MAC address is

authenticated each time when you connect to the

internet. This is a precaution against unauthorized access. Since your TV has its own MAC address,

your internet service provider cannot validate the MAC

address of your TV. For this reason, your TV cannot

connect to the internet. Contact your internet service provider and request information on how to connect

a different device, such as your TV, to the internet.

It is also possible that the connection may not be available due to a firewall problem. If you think

this causes your problem, contact your internet service provider. A rewall might be the reason of a

connectivity and discovery problem while using the TV in Audio Video Sharing mode or while browsing via Audio Video Sharing feature.

Invalid Domain

Ensure that you have already logged on to your PC

with an authorized username/password and also ensure that your domain is active, prior to sharing any les in your media server program on your PC. If

the domain is invalid, this might cause problems while browsing les in Audio Video Sharing mode.

Using Audio Video Sharing Network Service

Audio Video Sharing feature uses a standard that eases the viewing process of digital electronics and makes them more convenient to use on a home network.

This standard allows you to view and play photos, music

and videos stored in the media server connected to your home network.

1. Server Software Installation

The Audio Video Sharing feature cannot be used if the server programme is not installed onto your PC or if the required media server software is not installed onto the companion device. Please prepare your PC with a proper server programme.

2. Connect to a Wired or Wireless Network

See the Wired/Wireless Connectivity chapters for

detailed conguration information.

3. Play Shared Files via Media Browser

Select Media Browser by using the directional buttons from the main menu and press OK. The media browser will then be displayed.

Audio Video Sharing

Audio Video Sharing support is only available in the Media Browser Folder mode. To enable folder mode, go to the Settings tab in the main media browser screen and press OK. Highlight View Style and set to Folder using the Left or Right butt ons. Select the desired media type and press OK.

If sharing congurations are set properly, Device Selection screen will be displayed after selecting the

desired media type. If available networks are found,

they will be listed on this screen. Select media server or network that you want to connect to using the Up or Down buttons and press OK. If you want to refresh

the device list, press the Green button. You can press Menu to exit.

If you select the media type as Videos and choose a device from the selection menu. Then select the

folder with video les in it on the next screen and all the available video les will be listed.

To play other media types from this screen, you can go

back to main Media Browser screen and select the media type as desired and then perform the network selection again. Or press the Blue button to switch to next media type quickly without changing the network. Refer to the Media Browser menu section for further

information on le playback.

Subtitle les do not work if you watch videos from

your network through Audio Video Sharing feature.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 29 -

You can connect only one television to the same

network. If a problem occurs with the network, please

switch your television off at the wall socket and back

on again. Trick mode and jump are not supported with

the Audio Video Sharing feature.

Note: There may be some PC’s which may not be able to

utilize the Audio Video Sharing feature due to administrator and security settings (such as business PC’s).

Internet Portal

HINT: A broadband internet connection is required

for high quality viewing. For 4K video streaming,

a minimum 25Mb/s internet connection speed is required – For an example of the requirements for streaming 4K content you may find more information on the Netflix website (https://help. netflix.com/en/node/13444). When you start to stream video content via the internet the quality of your connection will be analysed and the full HD or

4K quality may take a short time to be realised, or

in the event of a slow connection not be possible. You should check your internet capabilities with your internet provider if you are at all unsure. You must set the country option accordingly in the First Time Installation for proper operation of the internet portal.

Portal feature adds your TV a feature that allows you to connect a server on the Internet and view the content provided by this server over your Internet connection.

Portal feature allows you to view the music, video, clip or web content with dened short-cuts. Whether you

can view this content without interruption depends on the connection speed provided by your internet service provider.

Press the Internet button on your remote control to open internet portal page. You will see icons of the available applications and services on the portal screen. Use the directional buttons on your remote to select the desired one. You may view the desired content by pressing OK after selecting. Press Back/ Return button to return back to the previous screen.

Moreover, you can access some features using the short-cut feature dened for the coloured or numeric

buttons of your remote. Press the Exit button to quit the Internet portal mode.

PIP Window (depending on portal service)

Current source content will be displayed in the PIP

window, if you switch to portal mode while on any

active source. If you switch to portal mode while watching TV

channels, current programme will be displayed in

the PIP window. You can change channels using Programme +/- buttons.

Notes:

Possible application dependent problems may be caused by the content service provider.

Portal service content and the interface may be changed at any time without prior notice.

Third party internet services may change, be discontinued or restricted at any time.

iPlayer Application

You can access BBC iPlayer using your TV. Select BBC iPlayer application among the portal options.

Press the OK button on your remote control to start the BBC iPlayer application.

Note: Broadband internet connection (minumum 2mbps) is required for high quality viewing.

Playing a Programme via iPlayer

Select a programme and press OK button. The programme playback will begin.

You can press the Pause button to pause playback. Press the Play button to resume the playback.

Use the Stop button to stop the playback. Press the Exit button to exit iPlayer. Press the Return

/Back button for going back to the previous screen.

Note: “Episode is unavailable” message may be displayed on the screen if a problem occurs during the playback.

Searching a Programme

Highlight the Search tab using the navigation buttons and press the OK button. Use the virtual keyboard to type the letters. Select letters and press the OK button. When nished, highlight Search option and press the OK button.

Freeview Play Platform

Note: Before attempting to connect to the Freeview

Play platform, make also sure that BBC and ITV

channels are installed. Otherwise connecting to the platform will not be available.

Freeview Play platform provides integrated catch-up TV services. Simply press the Freeview Play button on your remote control to connect to the Freeview Play platform.

You will have to agree to the terms and conditions

for Freeview Play services rst if you did not agree

them during the First Time Installation. Highlight Yes and press OK on the remote to conrm and proceed.

Integrated TV Player applications will be displayed. Select one and press the OK button. Then select a content that you want to play back and press the OK button to watch.

Catch-up contents can also be accessed and played back directly from the TV Guide. Refer to the section Electronic Programme Guide (EPG) for more information.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 30 -

Integrated Catch-Up Services

Note: Before connecting to the Freeview Play

platform, make sure that you follow the steps below,

otherwise you will not be able to access the Freeview Play platform:

• Connect aerial to the back of TV and carry out digital channel scan

• Connect TV to the internet (via WiFi or Ethernet)

• Accept the T&Cs to enable Freeview Play services

• A minimum broadband speed of 2Mbps is required

to watch catch up and on demand services

This will count towards any monthly broadband data allowance. Only selected channels provide 7-day catch up.

Without the Aerial and internet connection you will not be able to access the Freeview Play platform.

Accessing Freeview Play catch-up TV services

1. Freeview Play via the Electronic Programme

Guide (EPG)

Simply scroll backwards in your programme guide to access Freeview Play. Available catch-up content will be marked with a Play icon. Highlight the content and press the OK button and select playback option.

Note: The content available on EPG is driven by TV channels themselves and will only display if the channel content is available. When you select a

programme, Freeview Play will directly launch the

catch up service. If you wish to watch Demand 5 on

Freeview Play, please use the other options listed

below to access the catch up service.

3. Freeview Play via the TV’s Smart Portal

Bring up the Smart Portal on your TV, Freeview Play will be one of the applications displayed on the rst

page. Once the Freeview play app is selected it will direct you to the same Freeview play portal seen

above, where you can choose what programme you’d

like to watch.

Internet Browser

To use the internet browser, enter the portal rst. Then

launch the Internet application on the portal.

(*) The appearance of the internet browser logo may change

In the initial screen of the browser, the thumbnails of the predened (if any) links to web sites available will

be displayed as Speed Dial options along with the Edit Speed Dial and the Add to Speed Dial options.

To navigate the web browser, use the directional

buttons on the remote or a connected mouse. To see

the browser options bar, move the cursor to the top of

the page or press the Back/Return button. History, Tabs and Bookmarks options and the browser bar

which contains previous/next buttons, the refresh button, the adress/search bar, the Speed Dial and

the Opera buttons are available.

2. Freeview Play via the ‘FPlay button’

Click Freeview Play button on your remote control.

This will bring up the Freeview Play portal, where

you can choose the channel and programme to watch with ease.

English - 31 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

To add a desired website to the Speed Dial list for

quick access, move the cursor to the top of the page

or press the Back/Return button. The browser bar will appear. Highlight the Speed Dial - button and press the OK button. Then select Add to Speed Dial option and press the OK button. Fill in the blanks for Name and Address, highlight OK and press the OK button to add. Whilst you are on the site you wish to add to the Speed Dial list, highlight the Opera- button and press the OK button. Then highlight Add

to Speed Dial option in the submenu and press the OK button again. Name and Address will be lled

automatically according to the site you are visiting. Highlight OK and press the OK button to add.

You can also use the Opera menu options to manage the browser. Highlight the Opera- button and press the OK button to see available page specic and general options.

There are various ways to search or visit websites using the web browser.

Enter the address of a website(URL) into the search/

address bar and highlight the Submit button on the virtual keyboard and press the OK button to visit the site.

Enter keyword/s into the search/address bar and

highlight the Submit button on the virtual keyboard and press the OK button to start a search for the related websites.

Highlight a Speed Dial thumbnail and press the OK

button to visit the related website.

Your TV is compatible with USB mice. Plug your mouse or wireless mouse adaptor into the USB input of your TV for easier and quicker navigation.

Some web pages include ash content. These are not

supported by the browser. Your TV does not support any download processes

from the internet via the browser. All sites on the internet might not be supportted.

According to the site; content problems may occur. In some circumstances video contents might not be able to be played.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 32 -

Smart Centre

Smart Centre is a mobile application running on iOS

and Android platforms. With your tablet or phone,

you can easily stream your favourite live shows and programmes from your smart TV. Also; you can launch

your portal applications, use your tablet as a remote control for your TV and share media les.

Note: Being able to use all functions of this application depends on the features of your TV.

Getting Started

To use Smart Centre features, connections have to

be done properly. To get connected to your network

wirelessly, plug in the Wi-Fi dongle to one of the USB ports if your TV doesn’t have internal wi feature. To be able to use internet based features, your modem/

router must be connected to the internet.

IMPORTANT: Make sure the TV and mobile device are connected to the same network.

For media sharing feature Audio Video Sharing option should be enabled(if available). Press the Menu button on the remote, select Settings>More menu and press OK. Highlight Audio Video Sharing and change as Enabled. Your TV is ready to connect to your mobile device now. Install the Smart Centre application onto your mobile device.

Start the smart centre application. If all connections

are congured properly, you will see your TV’s name

on your mobile device. If your TV’s name doesn’t

appear on the list, wait a while and tap on the Refresh

widget. Select your TV from the list.

Mobile Device screen

On the main screen you can nd tabs to access

various features. The application retrieves actual channel list from TV

rst when it starts.

MY CHANNELS: The programmes of first four channels from the channel list retrieved from the TV are shown. You can change the listed channels. Press on the channel thumbnail and hold. A list of channels will be displayed and you can choose your desired channel to be replaced.

TV: You can watch content through the TV tab. In this mode you can navigate through the channel list retrieved from your TV and click on thumbnails to view the detail pages.

EPG: You can view the broadcast schedules of selected channel lists through this tab. You can also navigate through channels by pressing on the selected channel on the EPG grid. Please note that updating / refreshing the EPG information may take a while depending on your network and web service quality.

Note: Internet connection is required for WEB based EPG informations.

English - 33 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

PORTAL: This tab displays the Portal applications in scrollable view. Unless FollowMeTV (if available) is

active, the selected application will be displayed on

your TV screen.

Note: Internet connection is required. This tab is enabled if a portal page is in use.

SETTINGS: Congure the application to your liking.

You can change;

Auto-lock (Only in IOS): The screen of the device automatically turns off after a certain amount of

time. Default is off, which means the screen will

always stay on. Auto-enable FollowMeTV: FollowMeTV function (if

available) will start automatically when this setting is enabled. Default is disabled.

Auto-connection to TV: When enabled, your

mobile device will automatically connect to last connected TV and skips the TV search screen.

Change TV (Only in IOS): Shows the currently connected TV. You can press on this setting to go to the “TV search” screen and change to a different TV.

Edit custom channel list: You can edit your custom channel list using this setting.

Choose channel list source: You can choose the channel list source to be used in the application. The options are “TV List” and “Custom List”. Additionally you can activate “Remember my choice” option to set the selected channel list source as a constant choice. In this case if the selected source is available it will be used in the application.

Version No: Displays the current version of the application.

Detail Page

To open detail page tap on a programme. On the detail page screen you can get detailed information

of the programmes you select. There are “Details”, “Cast&Crew” and “Videos” tabs to nd on this page.

DETAILS: This tab provides summary and information about the selected programme. Also there are links to facebook and twitter pages of the programme selected.

CAST&CREW: Shows all the people contributed to the current programme.

VIDEOS: Provides videos on Youtube related to the selected programme.

Note: For some functions an internet connection may be required.

FollowMe TV Feature (if available)

Tap on the FOLLOW ME TV widget located at the bottom left of the screen of your mobile device to change the layout for FollowMe TV feature.

Tap the play icon to start streaming of the content from the TV to your mobile device. Available if your device is in your routers operation range.

Mirror Mode

This mode of FollowMe TV feature is enabled by deafult and allows streaming the content from any other selected TV sources and Media Browser.

Notes:

Note that only digital(DVB-T/C/S) SD and HD channels are

supported.

Multilanguage audio support and subtitle on/off features are not functional.

The streaming performance may change depending on the quality of your connection.

Media Share Page

To access the Media Share widget tap on the Uparrow on the bottom left side of the screen.

If the Media Share widget is pressed, a screen is displayed where you can select the media le type to

share with your TV.

Note: Not all image le formats are supported. This function

will not work if Audio Video Sharing feature is not supported.

Portal Launcher

To access the Portal Launcher( ) widget tap on the Up-arrow on the bottom left side of the screen.

You can access the portal page by tapping on the Portal Launcher widget.

Note: Internet connection is required. This function will not work if a portal page is not in use.

Smart Remote Feature

You can use your mobile device as a remote control for your TV once it has connected to the TV. To use smart remote’s full features tap on the Up-arrow on the bottom left side of the screen.

Voice Recognation

You can tap on the Microphone( ) widget and

manage your application, giving voice commands such as “Portal!”, “Volume Up/Down!”, “Programme

Up/Down!”.

Note: This feature is only for android based devices available.

Keyboard Page

The keyboard page can be opened in two ways; by pressing the Keyboard( ) widget on the application screen or automatically by receiving a command from the TV.

Requirements

1. Smart TV

2. Network connection

3. Mobile Device based on Android or iOS

platform (Android OS 4.0 or higher; IOS 6 or higher version)

4. Smart Centre app.(to be found on online application stores based on Android and iOS platforms)

5. Router modem

6. USB storage device in FAT32 format (required

for PVR feature, if available)

Notes:

For Android devices, Normal(mdpi), Large(hdpi) and Extra Large(xhdpi) screen sizes are supported. Devices with 3” or smaller screen sizes are not supported.

For iOS devices, all screen sizes are supported.

User interface of the Smart Centre application is subject to change according to version installed on your device.

DVB-T functionality information

This DVB receiver is only suitable for use in the country which it was designed to be used in.

Although this DVB receiver conforms to the latest DVB

specications at the time of manufacture, we cannot

guarantee compatibility with future DVB transmissions due to changes that may be implemented in broadcast signals and technologies.

Some digital television functions may not be available in all countries.

We continually strive to improve our products;

therefore, specications may change without prior

notice.

For advice on where to purchase accessories,

please contact the store where you purchased your equipment.

Internet Portal functionality information

The content and services available through the SmarTVue portal are provided by third-party providers

and may be altered, suspended or discontinued at any

time without notice. Hitachi is not responsible for any of the content or

services and does not warrant the availability of or access to such content or services.

For information on a particular service or on any

content, please visit the service/content provider’s website. If you have any questions concerning, or problems with, any content or services then please

contact the relevant service/content provider directly. Hitachi is not responsible for providing customer service in relation to content or services and accepts no liability in this regard.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 34 -

Guarantee

Product Guarantee

This product is guaranteed against manufacturing defects for a period of

Year

This product is guaranteed for twelve months from the date of original purchase.

Any defect that arises due to faulty materials or workmanship will either be replaced,

refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.

The guarantee is subject to the following provisions:

• The guarantee does not cover accidental damage, misuse, cabinet parts, knobs

or consumable items.

• The product must be correctly installed and operated in accordance with the

instructions contained in this manual.

• It must be used solely for domestic purpose.

• The guarantee will be rendered invalided if the product is re-sold or has been

damaged by inexpert repair.

• Specifications are subject to change without notice.

• The manufacturer disclaims any liability for the incidental or consequential damages.

• The guarantee is in addition to, and does not diminish your statutory or legal rights.

• In the event of a problem with the product with in the guarantee period call the

Customer Helpline:

0345 604 0105

Guarantor: Argos Ltd

489 - 499 Avebury Boulevard

Central Milton Keynes

MK9 2NW

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 35 -

Product che

Commercial Brand: HITACHI

Product No. 10109546

Model No. 50HK6T74U

Energy eciency class A+

Visible screen size

(diagonal,approx.) (inch/cm)

On mode average power

consumpon (Wa)

Annual energy consumpon

(kWh/annum)

Standby power consumpon

(Wa)

O mode power consumpon

(Wa)

Display resoluon (px) 3840 x 2160

50 inches / 127 cm

103 kWh

71 W

0,5 W

0 W

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 36 -

2017

HITACHI

50HK6T74U

103

127 50

50382361

*50382361*

Standby Power Consumption (approx.) 0,5 W Screen Resolution 3840 x 2160

Hereby, HITACHI Europe Ltd., declares that the radio equipment type TV is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://estadoc.hitachi.eu/estadoc/index.htm Hitachi Europe Ltd. Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire. SL6 8YA. UK

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 37 -

A B C D E

English

VESA WALL MOUNT MEASUREMENTS

Hole Pattern Sizes (mm)

Screw Sizes Length (X)

Thread (Y)

Deutsch

MASSANGABE N FÜR VESA- WANDMONTAGE Lochmustergröß en (mm)

Schraubengröß en

Länge (X) Gewinde (Y )

Français

DIMENSIONS DU SUPPORT DE FI XATION MURALE VESA Dimensions des modèles de trous de montage (mm)

Dimensions des vis

Longueur (X) Filetage (Y)

Italiano

Misurazioni installazione a parete VESA Dimensioni schema foro (mm)

Dimensioni vite

Lunghezza (X) Filettatura (Y)

Português

MEDIÇÕES DE MONTAGEM MURAL VESA Dimensões do molde de furação (mm)

Tama nhos do para fuso

Comprimento (X) Rosca (Y)

Español

MEDIDAS DEL MONTAJE DE PARED VESA

Tama ños de patró n para agujero (mm)

Tama ños de tornillo

Longitud (X) Rosca (Y)

Türkçe

VESA DUVARA MON TAJ APARATI ÖLÇÜLE Rİ Açılacak Delik Ölç üleri (mm)

Vida Ölçüleri

Uzunluk (X) Yüzey (Y)

Eλληvικ

ΔΙΑΣΤΑΣΕΙΣ ΒΑΣΗΣ ΤΟΙΧΟΥ VESA

Μεγέθη σχήματος οπών (mm)

Μεγέθη βιδών

Μήκος (X) Σπείρωμα (Y)

Polski

WYMIARY DO MONTAŻU NAŚCIENNEGO VESA Rozmiary szablonu otworów (mm)

Rozmiary wkrętó w

Długość (mm) Gwint (Y )

čeština

ROZMĚRY DRŽÁKU NA ZEĎ VESA Rozměry velikosti děr (mm)

Rozměry šro ubů

Délka (X) Závit (Y)

Magyar

VESA FALI TARTÓ MÉRETEK Lyukak méretének nagysága(mm)

Csavar méret

Hossz (X) Menet (Y)

Română

MĂSURĂTORI SUPORT PERETE VESA

Dimensiuni tipar gaură (mm)

Dimensiuni şuruburi

Lungime (X) Filet (Y)

Svenska

VESA VÄGGMON TERINGSMÅTT Hålmönsterstorlear (mm)

Skruvstorlekar

Längd (X) Tråd (Y)

Nederlands

VESA WANDMONTAGE METINGEN

Grootte booropening (mm)

Schroefgroote

Lengte (X) Draad (Y )

Suomi

VESA-SEIN ÄASENNUKSE N MITAT Reikäkuvion ko ot (mm)

Ruuvinko ot

Pituus (x) Kierre (Y)

Norsk

VESA VEGGMONTERIN GSMÅL Hullmønster størrelser (mm)

Skruestørrelser

Lengde (x) Tråd (Y )

Dansk

VESA VÆGMONTERI NGS-MÅL Hulmønster-størrelser (mm)

Skruestørrelser

Længde(X) Tråd (Y)

Русский

РАЗМЕРЫ НАСТЕННОГО КРЕПЛЕНИЯ VESA Размеры системы отверстий

Размеры винтов

Длина(Х) Резьба (Y)

беларуская

ПАМЕРЫ НАС ЦЕННАГА МАЦАВАННЯ VE SA Памеры сістэмы адтулін

Памеры вінтоў

Даўжыня (X) Разьба (Y)

македонски

МЕРКИ ЗА МОНТИРАЊЕ НА ЅИД ЗА „ВЕСА“ Шема на големини на дупката (мм)

Големина на шрафот

Должина (Х)

Навој (Y)

український

РОЗМІРИ НАСТІННОГО КРІПЛЕННЯ VESA Відстан ь між кріпильними отворами, мм

Розміри гвинтів

Довжина (X) Д іаметр різьби (Y)

Srpski

DIMENZIJE VESA ZIDNOG NOSAČA Dimenzije šablona za bušenje

Dimenzije zavrtnjeva

Dužina (X) Navo j (Y)

Slovenčina

ROZMERY DRŽIAKA NA STENU VESA Rozmery veľkosti dier (mm)

Rozmery skrutiek

Dĺžka (X) Závit (Y)

Slovenščina

MERE STENSKEGA NOSILCA VESA Velikosti vzo rca lukenj (mm)

Velikosti vijakov

Dolžina (X) Navoj (Y )

Hrvatski

VESA MJERE ZIDNOG DRŽAČA Veličine uzorka otvora (mm)

Veličine vijka

Dužina (X) Navo ji (Y)

Bosanski

DIMENZIJE VESA ZIDNOG NOSAČA Dimenzije šablona za bušenje

Dimenzije vijaka

Dužina (X) Navo j (Y)

Български

РАЗМЕРИ ЗА КОМПЛЕКТ ЗА МОНТАЖ НА СТЕНА VESA

Размери на отвора (mm)

Размер на болта

Дължинаt (X) Резба (Y)

Lietuvių

VESA TVIRTINIMO PRIE SIENOS MATAVIMAI Angos šablono dydis (mm)

Varžtų dydis

Ilgis (X) Sriegis (Y)

Latviešu

VESA SIENAS ST IPRINĀJUMA IZMĒRI Caurumu šablo na izmērs (mm)

Skrūvju izmēri

Garums (X) Vītne (Y)

Eesti

VESA SEINALE KINNITAMISE MÕÕDUD Kruvi suuruse mõõt (mm)

Kruvi suurus

Kõrgus(x) Keere (Y)

Shqip

PËRMASAT E NJËSISË SË MONTIMIT NË MUR VESA

Madhësitë modele të vrimave (mm)

Madhësitë e vidhave

Gjatësia (X) Filetimi (Y)

يبرع

 VESA      )(

 

 )X(  )Y(

תירבע

      VESA     )"(

 

 )X(  )Y(

یسراف

    VESA     ) (

  

 )X(  )Y(

VESA WALL MOUNT MEASUREMENTS

Hole Paern

Sizes (mm)

W H

200 200

C Screw Sizes

D Length (X)

min. (mm) 10

max. (mm) 13

E Thread (Y) M6

English - 38 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Hitachi 50HK6T74U, 65HK6T64U Instruction manual

Specifications and Main Features

Frequently Asked Questions

User Manual
