Hisense HR6WC36D, HR6WC58D User Manual

CONTENTS

Safety information 1

3lenaplortnoC
3noitarepO
5ecnanetniaM

Customer service and spare parts 6

SAFETY INFORMATION

It is most important that this instruction
book should be retained with the appliance
for future reference. Should the appliance
be sold or transferred to to another owner,
or should you move house and leave the
appliance, always ensure that the book is
supplied with the appliance in order that
the new owner can be acquainted with
the functioning of the appliance and the
relevant warnings.

If this appliance featuring magnetic
door seals is to replace an older
appliance having a spring lock (latch)
on the door or lid, be sure to make
that spring lock unusable before
you discard the old appliance. This
will prevent it from becoming a
death-trap for a child.

These warning are provided in the interest
of safety. You must read them carefully
before installing or using the appliance.

General Safety

The appliance is designed exclusively for
domestic use. The appliance is intended
to be used exclusively for the storage of
the wine as explained in this instruction
booklet.

WARNING

Risk of injury due to broken glass! In case
of transport at an altitude of over 1100m
the glass panes of the door may break. The
door may break. The fragments have sharp
edges and may cause serious injury. Take
appropriate protective action.
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use

Electrical connection 6

6noitallatsnI

01...fiodottahW

Environmental concerns 10

of the appliance by a person responsible
for their safety. Children should be
supervised to ensure that they do not
play with the appliance.
It is dangerous to alter the specifications
or modify this product in any way.
Before any cleaning or maintenance
work is carried out, be sure to switch off
and unplug the appliance.
This appliance is heavy. Care should be
taken when moving it.
Take utmost care when handling
your appliance so as not to cause
any damages to the cooling unit with
consequent possible fluid leakages.
The appliance must not be located close
to radiators or gas cookers.
Avoid prolonged exposure of the
appliance to direct sunlight.
There must be adequate ventilation
round the the appliance and any damage
to the refrigerant circuit must be avoided.
Do not use other electrical appliances
(suchas ice cream makers) inside of
refrigerant appliance.

Do not store explosive substances such

propellant in this appliance.
This appliance is intended to be used in

household and similar applications such as

other working environments;

-farm houses and by clients in hotels,
motels and other residential type
environments;

-bed and breakfast type environments;

-catering and similar non-retail applications.
Keep burning candles,lamps and other items

Service/Repair

Any electrical work required to install this
appliance should be carried out by a

1

qualified electrician or competent person.
This product should be serviced by an
authorized Service Center, and only
genuine spare parts should be used.
Under no circumstances should you
attempt to repair the appliance yourself.
Repairs carried out by inexperienced
persons may cause injury or more
serious malfunctioning. Refer to your
local Service Centre, and always insist on
genuine spare parts.
This appliance contains hydrocarbons
in its cooling unit; maintenance and
recharging must therefore only be carried
out by authorized technicians.

Use

The domestic wine refrigerator is
designed to be used specifically for the
storage of potable wine only.
Best performance is obtained with
ambient temperature as follows:

Climate

For an ambient
temperature

0
1
2
3
4
5

6
7

20°C
16°C
22°C

25°C
30°C
27°C

40°C
35°C

Relative
humidity

50
80
65
60
55
70

40
75

The class of your appliance is shown on
its rating plate.
Warning: when the ambient temperature
is not included within the range indicated
for the class of this appliance, the
following instructions must be observed:
when the ambient temperature rises
up the maximum level, the storage
temperature in the refrigerator cannot
be guaranteed, it is advisable to use the
food stored as soon as possible.
Do not put hot pot on the plastic parts of
the appliance.
Do not store flammable gas and liquid
in the appliance, because they may
explode.
Do not place wine directly against the rear
wall of compartment.
The appliance’s manufactures storage
recommendations should be strictly

adhered to. Refer to relevant instructions.
The inner lining of the appliance has
channels through which the refrigerant
passes. Should the channels be
punctured the unit would be damaged
beyond repair. DO NOT USE SHARP
INSTRUMENTS to scrape of frost or ice.
Frost may be removed by using a scraper.
Under no circumstances should be solid
ice be forced off the liner. Solid ice should
be allowed to thaw when defrosting the
appliance.

Installation
Important: For electrical connection

carefully follow the instructions given in
specific paragraphs.

Unpack the appliance and check if there
are damages on it. Do not connect
the appliance if it is damaged. Report
possible damages immediately to the
place you bought it. In that case retain
packing.
During normal operation, the compressor
and/or condenser at the back of the
appliance heat up considerably. For
safety reasons, minimum ventilation must
be as shown in the instructions.

Attention: keep ventilation openings
clear of obstruction.

Care must be taken to ensure that
the appliance does not stand on the
electrical supply cable.
Important: if the supply cord is
damaged, it must be replaced by a
special cord or assembly available from
the manufacture or its service agent.
If the appliance is transported
horizontally, it is possible that the oil
contained in the compressor flows in the
refrigerant circuit. It is advisable to wait
at least two hours before connecting the
appliance to allow the oil to flow back in
the compressor.
There are working parts in this product
which heat up. Always ensure that there
is adequate ventilation as a failure to
do this will result in component failure
and possible loss. See installation
instructions.
Parts which heat up should not be
exposed. Wherever possible the back of
the product should be against a wall.

2

Environment Protection

This appliance does not contain gasses which
could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The
appliance shall not be discarded together with
the urban refuse and rubbish. The insulation
foam contains flammable gasses: the
appliance shall be disposed according to the
applicable regulations to obtain from your local
authorities. Avoid damaging the cooling unit,
especially at the rear near the heat exchanger.
The materials used on this appliance marked
by the symbol

are recyclable.

CONTROL PANEL

A B C D E

A

Temperature circle key of upper zone

B

Temperature circle key of lower zone

C

Display

D

E

Light On/Off key

Use

Cleaning the interior

Before using the appliance for the first
time, wash the interior and all internal
accessories with lukewarm water and
some neutral soap so as to remove the
typical smell of a brand-new product, and
then dry naturally and thoroughly.

Do not use detergents or abrasive
powders, as these will damage the

Display

A B

1 2 3 2 3 1

A

Display of upper zone

B

Display of lower zone

1

Wine storage type

2

Temperature indicator

3

OPERATION

After inserting the plug in the socket, the
wine refrigerator will run immediately.

Temperature regulation

Press “
temperature of upper zone.

Press “
temperature of lower zone.

The correct position must in any case be
determined bearing in mind that the inside
temperature depends on these factors:

” key to cyclically regulate the

” key to cyclically regulate the

Room temperature
How often the door is opened
The quantity of bottles stored
The position of the appliance

Use

Wine arrangement

Please place the wine bottles as shown
below.

HR6WC36D HR6WC58D

3

Keep the wine in the dark. The door is in

anti-UV darkened triple glass to protect the
wine from the light in case the refrigerator is
located in well-lit place.

Lay the bottles down in such a way that
the corks do not dry.

Avoid switching the appliance light
on too often or for too long. Wine keeps

better in dark.

Handle the bottles with care, to avoid
agitating the wine.

Follow the recommendations and
advice received at the time of purchase
or given in the technical documentation
regarding the quality, duration and optimum
storage temperature of the wine.

Storage advice

The storage time for wine depends on
ageing, the type of grapes, alcoholic
content and level of fructose and tannin
contained in it. At the time of purchase,
check if the wine is already aged or if it will
improve over time.

Recommended storage temperature:

– For champagne and sparkling wines,

–

– For rose and light red wines, between 12

Bottle “Light On”

Bottles can be illuminated in different ways.

1. The interior light will be on automatically
for 5 minutes when the wine refrigerator
is powered on.

2. The interior light can be turned on or off
by pressing the light On/Off key.

3. Interior light will be switched on
immediately when the door is open.
And it will be off automatically after the
door has been open for ten minutes.

4. Interior light will be switched off after the
door is close for 5 minutes.

°F/°C exchange

The temperature can exchanged from °F

Switching off

Switch the power point off and unplug
the wine cooler.

Inside accessories Shelves

The shelves can be removed for cleaning.

Bottle
shelves

–

When placing various bottles on top of
each other, make sure they do not touch

the refrigerator cooling plate.

HR6WC36D

Bottle
shelves

HR6WC58D

4
