Hisense HB200M User Manual

Mini Bluetooth Headset

MODEL:HB200M

User Guide

2

3

Thank You 3
Safety Guidelines 3-5
Introducing the HB200M 5-6
What Your Headset Can Do 6
Specifications 7

GET TING STARTED 7
Turning Your Headset On & OFF 7-8
Pairing it with Your Phone 7-8
Wear It How You Like It 9
Left or Right Ear Use 9
Adjusting Earplug 10
Wearing the Headset as a Pendant 10
Charging your Hea dse t 11
Answer a Call 12
End a Call 12
Make a Call 12
R eject a Call* 12
A c t i v a t e Voice Dialing* 12
Redial Last Number* 12
A d j u s t Sound and Volume 13
C a l l Waiting and Placing a Call on Hold* 13

What the Lights Mean 14
Using the HB200M with Two Mobile Phones 15
Troubleshooting 16
Taking Care of Your Headset 17
Glossary 17-18

Thank You

Thank you for purchasing the Hisense HB200M Bluetooth®
Headset. We hope you enjoy it! This instruction manual will
get you started and ready to make the most of your headset.

WARNING!

Headsets are capable of delivering sounds at loud
volumes and high pitched tones. Exposure to such
sounds can result in permanent hearing loss or damage.
The volume level may vary based on conditions such
as the phone you are using, its reception and volume
settings, and the environment. Please read the safety
guidelines below prior to using this headset.

Safety Guidelines

1. Prior to using this product follow these steps:
Before putting on the headset, turn the volume

control to its lowest level, put the headset on,
and then slowly adjust the volume control to a
comfortable level.

2. During the use of this product:
Keep the volume at the lowest level possible and
avoid using the headset in noisy environments
where you may be inclined to turn up the volume.
If increased volume is necessary, adjust the volume

Table of Contents

4

5

control slowly, and if you experience any discomfort
or ringing in your ears, immediately discontinue use
and consult a physician.

With continued use at high volume, your ears may
become accustomed to the sound level, which may
result in permanent damage to your hearing without
any noticeable discomfort.

Using the headset while operating a motor vehicle,
motorcycle, watercraf t or bicycle may be dangerous,
and is illegal in some jurisdictions. Check your local
laws. Use caution while using your headset when
you are engaging in any activity that requires your
full attention. While engaging in any such activity,
removing the headset from your ear area or turning
off your headset will keep you from being distracted,
so as to avoid accident or injury.

3. Keep out of reach of children:
The plastic bags the product and its parts are

wrapped in are not toys for children. The bags
themselves or the many small parts they contain
may cause choking if ingested.

4. Never try to dismantle the product yourself. None of the
internal components can be replaced or repaired by
users.

Only authorized dealers or ser vice centers may open
the product. If any parts of your product require

replacement for any reason, including normal wear
and tear or breakage, contact your dealer.

Avoid exposing the product to rain or other liquids.
Dispose of the product according to local standards and
regulations.
Do not use the Headset in environments where there is a
danger of ignition of flammable gases.

The headset is equipped with a magnetic pendant.

The magnet in the pendant can harm other
electronic devices. handle the magnetic pendant
with care and keep away from electronic devices
such as speakers, TV, LCD screens Etc.

Introducing the HB200M

Microphone1.
Multi-Function Button (MFB)2.
Pairing Button – press and hold for 5 sec to put •
headset into pairing mode
Answer/End Button

•

Press to turn headset on (blue and red lights flash •
for 1sec)
Press and hold to turn headset off (blue and red

•

lights flash for 1sec and then power will shut down)
Press to answer or end a call

•

LED Light 3.
Charging Socket4.

6

7

Speaker5.
Ear Hook6.

What Your Headset Can Do

Your Hisense HB200S lets you do the following:

Answer

• Calls

End

• Calls

Reject

• Calls*

Voice

• Dialing*

Last

• Number Redialing*

Call

• Waiting*

Put

• Call on Hold*

* Phone Dependent

Specifications

Up to 5.5 • Hours talk time/Standby Time up to 150
hours

Rechargeable battery with charging option from AC

•

power supply or PC via USB cable
Weight: 7.5 gr.

•

Operating range up to 10 meters (approx. 33 feet)•
Headset and hands-free Bluetooth profiles•
Bluetooth • Specification (see glossary) version 2.1

GETTING STARTED

The Hisense HB200M is easy to operate.

Turning your headset on and off

To turn on your headset press and hold the MFB for 5
seconds. Release the button when the indicator lights
flash (both blue and red lights) once.

Note: blue led light indicates that the headset is connected
to a mobile phone. When the headset is powered on but is
not connected to any Bluetooth device, the red indiction
light will keep on flashing.

1

2

3

4

5

6

8

9

To turn off your headset, press and hold the MFB for 5
seconds. Release when the indicator lights flash once
(both red and blue lights) and then off again together
with an indication tone

The MFB (multi function button) on the headset performs
different functions depending on how long you press it.

Pairing with Your Phone or Other Device

Before using your Hisense HB200M, you need to pair it
with your mobile phone.

1. Make sure that the headset is turned off

2. Hold the headset’s MFB for 8 seconds till the blue

and red indication light flash alternatively, meaning
that the headset has entered into pairing mode.

3. Activate Bluetooth function of the mobile phone to

search for Bluetooth devices (please refer to the
phone’s manual).

4. Set your Bluetooth phone to ‘discover’ the Hisense

HB200M.
follow your phone’s instruction guide. This usually
involves going to a ‘setup,’ ‘connect’ or ‘Bluetooth’
menu on your phone and selecting the option to
‘discover’ or ‘add’ a Bluetooth device.
* (See example from a typical mobile phone).

5. Your phone will find the Hisense HB200M.

6. Your phone will then ask if you want to pair with it.
Accept by pressing ‘Yes’ or ‘OK’ on the phone and
confirm with the passkey or PIN = 0000 (4 zeros).
Your phone will confirm when pairing is complete.

In case of unsuccessful pairing, repeat steps 1 to 6.

Wear It How You Like It

Left or Right Ear Use

The Hisense HB200M is ready to wear on your right ear. If
you prefer the lef t, gently remove the ear hook and rotate
to fit left ear.

10

11

Adjusting the Ear Bud

1. The in-ear bud is assembled by default. You can
change different ear bud sizes according.

2. Rotate the in-ear bud clockwise or counter clockwise
about 45 degrees to remove the ear bud, then replace
with desired ear bud.

Wearing the Headset as a Pendant

Use the supplied magnetic clip, you can attach the headset
using the metal part around the charging socket, it will
connect easily to the magnet of the pendant.

Charging
Socket

Port

CAUTION

The Magnetic Clip is delicate and doesn’t hold the
headset tight. Handle with Care!! Do not use the
Magnetic Clip for sport or other activities that can
cause the headset to fall down.

STRONG MAGNET!

It can be harmful to pacemaker wearers and others
with medical implants. Stay clear! Keep tools and
other metal objects away. To avoid damage, keep
magnetic media such as memory disks/chips,
credit cards and tapes away.

Charging Your Headset

Make sure that your Hisense
HB200S headset is fully charged
before first use. Use the AC adaptor
to charge from a power socket, or
charge directly from your PC with
the USB cable provided.
Connect your headset to the AC
adaptor or USB cable After connecting to the power
source. The red LED light will blink twice and then solid
red, your headset is charging. After charging ends the
LED color will turn from red to solid blue.

Clip

Charging

Port

12

13

How to…

Answer a Call

Press the MFB on your headset to answer a call.

End a Call

Press the MFB to end an active call.

Make a Call

When you make a call from your mobile phone, the call
will (subject to phone settings) automatically transfer to
your headset. If your phone does not allow this feature,
press on the Hisense HB200M’s MFB to transfer the call
to the headset.

Reject a Call*

Press the MFB for approximately 2 seconds when the
phone rings to reject an incoming call. Depending on your
phone settings, the person who called you will either be
forwarded to your voice mail or hear a busy signal.

Activate Voice Dialing*

Press the MFB once. Wait for the beep and then
announce the name you wish to call
For best results, record the voice-dialing tag through your
headset. Please consult your phone’s user manual for
more information about using this feature.

Redial Last Number*

Press the MFB twice when the headset is on and not in use.

Adjust Sound and Volume

Volume adjustment can be done by the volume control
in your mobile phone, we canceled the volume button on
the headset In order to reduce the size of the HB200M.

Call Waiting and Placing a Call on Hold*

This lets you put a call on hold during a conversation and
answer a waiting call.
Press the MFB twice to put the active call on hold and
answer the waiting call.
Press the MFB twice to switch between the two calls.
Press the MFB to end the active conversation.

Functions marked with * are dependent on your phone

supporting these features.
Check your phone’s user manual for further information.

14

15

What the Lights Mean

Using the HB200M with 2 Mobile Phones

Hisense HB200M is capable of having two mobile phones
connected to the headset at the same time. This will give
you the freedom of having only one headset to operate
both your mobile phones and the operation of the func­tions in the headset functions as described above.

How to pair a second mobile phone

Turn off Bluetooth function of the first connected

1.

phone temporarilyץ
Launch the pairing steps (the same pairing steps as

2.

in the first phone) for the second mobile phone;
After the second phone is paired, turn of f the

3.

Bluetooth headset, then turn on the first paired
phone’s Bluetooth function.
Restart the headset.

4. The headset will connect to

both phones automatically.

NOTE: Last Number Redial will dial the number from

the last outgoing call, independent of the mobile
phones, and the Voice Dialing function only will
work on the last paired mobile phone.

What you see What does this

mean about your
headset

When
headset is
connected
to charger

Red light flashes
twice and then
on continuously

Charging

Solid Blue Charging

completed

When
headset
is not
connected
to charger

Red and Blue
light flashes
alternativly

Pairing

Blue light flashes
3 times quickly

Connected or
standby

Red light flashes
3 times quickly

Awaiting for
connection

In connection or
standby mode,
red light flashes
3 times quickly

Low battery aler t

16

17

Troubleshooting

I hear crackling noises

For the best audio quality, always wear your headset on
the same side of the body as your mobile phone.

I cannot hear anything in my headset

Increase the volume on the mobile phone.
Ensure that the headset is paired with the phone.
Make sure that the phone is connected to the headset – if
it does not either connect from the phone’s Bluetooth menu
or by pressing the MFB, follow the pairing procedure.

I have pairing problems even though my phone indicates
otherwise

You may have deleted your headset pairing connection in
your mobile phone.
Follow the pairing instructions in page 8.

Will the Hisense HB200M work with other Bluetooth
equipment?

The Hisense HB200M is designed to work with Bluetooth
mobile phones. It can also work with other Bluetooth
devices that are compliant with Bluetooth version 2.1
and support a headset and/or hands-free profile.

Taking Care of Your Headset

Always store the Hisense HB200M with the power •
off and safely protected.

Avoid storage at extreme temperatures (above

•

45°C/113°F – including direct sunlight – or below

-10°C/14°F). This can shor ten battery life and may
affect operation. High temperatures may also de­grade performance.

Do not expose the Hisense HB200M to rain or other

•

liquids.

Glossary

Bluetooth

The Bluetooth® trademark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Hisense
is under license. Other trademarks and trade names are
those of their respective owners.

1 . Bluetooth is a radio technology that connects

devices, such as mobile phones and headsets,
without wires or cords over a short distance (approx.
30 feet). Get more information at www.bluetooth.com.

2. Bluetooth profiles are the different ways that
Bluetooth devices communicate with other devices.

18

19

Bluetooth phones support either the headset profile,
the hands-free profile or both. In order to support
a certain profile, a phone manufacturer must
implement cer tain mandatory features within the
phone’s software.

3. Pairing creates a unique and encr ypted link between
two Bluetooth devices and lets them communicate
with each other. Bluetooth devices will not work if
the devices have not been paired successfully.

4. Passkey or PIN is a code that you enter on your
mobile phone to pair it with your Hisense HB200M.
This makes your phone and the Hisense HB200M
recognize each other and automatically work
together.

5. Standby mode is when the Hisense HB200M is
passively waiting for a call. When you ‘end’ a call
on your mobile phone, the headset goes into
standby mode.

Dispose of the product according to local standards and
regulations or local laws.
