FV306N4BC1
2
Safety and warning information_ __ _ _ _ _
Installing your new appliance_ _ _ _ _ _ _
Reversing the door _ _ _ _ _ _ _ _ _ _ _ _
Description of the appliance_ _ _ _ _ _ _ _
Display controls_ _ _ _ _ _ _ _ _ _ _ _ _ _
This appliance is in accordance with the following EU guidelines:
2014/35/EU,
and
2014/30/EU
2
8
9
12
13
and 2009/125/EC and EC.643/2009 and 2002/96/EC
For your safety and correct
usage, before installing and
first using the appliance, read
this user manual carefully,
including its hints and
warnings. To avoid
unnecessary mistakes and
accidents, it is important to
make sure that all people
using the appliance are
thoroughly familiar with its
operation and safety
features. Save these
instructions and be sure that
they remain with the
appliance if it is moved or
sold, so that anyone using it
throughout its life, will be
properly informed on its
usage and safety notices.
For the safety of life and
property, keep the
precautions of these user's
Using your appliance
Helpful hints and tips
Cleaning and care
Troubleshooting
Disposal of the appliance
_ _
_ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _
14
15
15
_
16
18
instructions as the
manufacturer is not
responsible for damages
caused by omission.
Safety for children and others
who are vulnerable people
This appliance can be used
by children aged from 8
years and above and
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
Keep all packaging away
3
from children as there is risk
of suffocation.
If you are discarding the
appliance, pull the plug out
of the socket, cut the
connection cable (as close
to the appliance as you can)
and remove the door to
prevent children playing
from suffering an electric
shock or from closing
themselves inside it.
If this appliance, featuring a
magnetic door seals, is to
replace an older appliance
having a spring lock (latch)
on the door or lid, be sure to
make the spring lock
unusable before you
discard the old appliance.
This will prevent it from
becoming a death trap for a
child.
General safety
This
WARNING —
appliance is intended
to be used in
and similar applications
such as
-staff kitchen areas in
shops, offices and other
working environments;
-farm houses and by
clients in hotels, motels
and other residential type
environments;
-bed and breakfast type
household
environments;
-catering and similar nonretail applications
WARNING — Do not
store explosive
substances such as
aerosol cans with a
flammable propellant in
this appliance.
WARNING — If the
supply cord is damaged,
it must be replaced by the
manufacturer, its service
agent or similarly
qualified persons in order
to avoid a hazard.
WARNING — Keep
ventilation openings, in
the appliance enclosure
or in the built-in structure,
clear of obstruction.
WARNING — Do not use
mechanical devices or
other means to
accelerate the defrosting
process, other than those
recommended by the
manufacturer.
WARNING — Do not
damage the refrigerant
circuit.
WARNING — Do not use
electrical appliances
inside the food storage
compartments of the
appliance, unless they
are of the type
recommended by the
manufacturer.
4
WARNING — The
refrigerant and insulation
blowing gas are
flammable. When
disposing of the
appliance, do so only at
an authorized waste
disposal centre. Do not
expose to flame.
Refrigerant
The refrigerant isobutene
(R600a) is contained
within the refrigerant
circuit of the appliance, a
natural gas with a high
level of environmental
compatibility, which is
nevertheless flammable.
During transportation and
installation of the
appliance, ensure that
none of the components
of the refrigerant circuit
becomes damaged.
The refrigerant (R600a) is
flammable.
Caution:risk of fire
If the refrigerant circuit
should be damaged:
-Avoid opening flames
and sources of ignition.
-Thoroughly ventilate the
room in which the
appliance is situated.
It is dangerous to alter the
specifications or modify
this product in any way.
Any damage to the cord
may cause a shortcircuit,
fire, and/or electric
shock.
Electrical safety
The power cord must not
1.
be lengthened.
2. Make sure that the power
plug is not or
damaged. A or
damaged power plug may
overheat and cause a fire.
3. Make sure that you can
access the main
appliance.
4. Do not pull the main
cable.
5. If the power plug socket
is loose, do not insert the
power plug. There is a risk
of electric shock or fire.
6.You must not operate the
appliance without the
interior lighting lamp cover.
7.The fridge is only applied
with power supply of single
phase alternating current of
220~240V/50Hz. If
fluctuation of voltage in the
district of user is so large
that the voltage exceeds the
above scope, for safety
sake, be sure to apply A.C.
Automatic voltage regulator
of more than 350W to the
fridge. The fridge must
crushed
crushed
plug of the
5
employ a special power
socket instead of common
one with other electric
appliances. Its plug must
match the socket with
ground wire.
Daily use
Do not store flammable
gass or liquids in the
appliance,There is a risk
of an explosion.
Do not operate any
electrical appliances in
the appliance(e.g.electric
ice cream makers,mixers
etc.).
When unplugging always
pull the plug from the
mains socket,do not pull
on the cable.
Do not place hot items
near the plastic
components of this
appliance.
Do not place food
products directly against
the air outlet on the rear
wall.
Store pre-packed frozen
food in accordance with
the frozen food
manufacture’s
instructions.
The appliances
manufactures storage
recommendations should
be strictly adhered
to.Refer to relrelevant
instructions for
storage.
Do not place carbonated
or fizzy drinks in the
freeze compartment as it
creates pressure on the
container,which may
cause it to
explode,resulting in
damage to the appliance.
Frozen food can cause
frost burns if consumed
straight from the freezer
compartment.
Do not place the
appliance in direct
sunlight.
Keep buring
candles,lamps and other
items with naked flames
away from the appliance
so that do not set the
appliance on fire.
The appliance is intended
for keeping food stuff
and/or beverages in
normal household as
explained in this
instruction booklet The
appliance is heavy.Care
should be taken when
moving it.
Do not remove nor touch
items from the freezer
compartment if your
hands are damp/wet,as
this could cause skin
abrasions or frost/freezer
burns.
Never use the base,
6
drawers, doors etc. to
stand on or as supports.
Frozen food must not be
refrozen once it has been
thawed out.
Do not consume ice
popsicles or ice cubes
straight from the freezer
as this can cause freezer
burn to the mouth
and lips.
caution!
Care and cleaning
Before maintenance, switch
off the appliance and
disconnect the mains plug
from the mains socket.
Do not clean the appliance
with metal objects, steam
cleaner, ethereal oils,
organic solvents or abrasive
cleansers.
Do not use sharp objects to
remove frost from the
appliance. Use a plastic
scraper.
Installation Important!
For electrical connection
carefully, follow the
instructions given in this
manual.
Unpack the appliance and
check if there are damages
on it. Do not connect the
appliance if it is damaged.
Report possible damages
immediately to the place
you bought it. In this case
retain packing.
It is advisable to wait at
least four hours before
connecting the appliance to
allow the oil to flow back in
the compressor.
Adequate air circulation
should be around the
appliance, lacking this leads
to overheating. To achieve
sufficient ventilation, follow
the instructions relevant to
installation.
Wherever possible the back
of the product should not be
too close to a wall to avoid
touching or catching warm
parts (compressor,
condenser) to prevent the
risk of a fire, follow the
instructions relevant to
installation.
The appliance must not be
locate close to radiators or
cookers.
Make sure that the mains
plug is accessible after the
installation of the appliance.
7
Service
Any electrical work required
to do the servicing of the
appliance should be carried
out by qualified electrician
or competent person.
This product must be
serviced by an authorized
Service Center, and only
genuine spare parts must
be used.
1)If the appliance is Frost
Free.
2)If the appliance contains
freezer compartment.
8
Installing your new appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
Ventilation of appliance
In order to improve efficiency
of the cooling system and
save energy, it is necessary to
maintain good ventilation around the
appliance for the dissipation of heat.
For this reason, sufficient clear space
Leveling of appliance
●
For suffi cient leveli ng an d air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. You can adjust
them manually by hand or by using a
suitable spanner.
●
To allow the door to self-close, tilt the
top backwards by about 10mm.
10mm
≤
sh ould be available around the
refrigerator.
Suggest :It is advisable for there to be
at least 75mm of space from the back
to the wall, at least 100mm from its
top,at last 100mm from its side to the
wall and a clear space in front to allow
the doors to open 135°. As shown in
following figures.
Installing the door handle
For the convenience of transportation,
the door handles are separat ely
provided in a plastic bag, you can
install the door handles as follows.
1. Lever the screw hole covers on the
side which you want to install the
handle of the door, and then put them
Note:
●
This appliance performs well within
the climate class from showed
in the table below.
It may not work properly if being left at
SN to T
a temperature above or below the
back to the plastic bag.
2. Take the handle match on the right
side of the door as the example,
keeping axes of screw holes in the
handle and the door in a line, as the
picture shows.
free zer doo r
indicated range for a long period.
Class
Extended
Temperate
Temperate
Subtropical
Tropical
●
Stand your appliance in a dry place to
Symbol
Ambient Temperature
range( )°C
SN
N
ST
T
+10 to +32
+16 to +32
+16 to +38
+16 to +43
scre w hole co ve
avoid high moisture.
●
Keep the appliance out of direct
sunlight， rain or frost. Stand the
appliance away from heat sources
such as stoves, fires or heaters.
3. Fix the handle with the screws
provided in the plastic bag. And then
install the handle covers
figure shows
.
hand le part
scre w
hand le cove r
as the above
9
The side at which the door opens can
be changed, from the left side (as
supplied) to the right side, if the
installation site requires.
Warning! When reversing the door, the
appliance must not be connected to the
mains. Ensure that the plug is removed
from the mains socket.
Tools you will need:
8mm socket wrench
Thin-blade screwdriver
Cross-shaped screwdriver
8mm wrench
No te : Before y ou start la y the
refrigerator on its back in order to
gain access to the base, you should
rest it on soft foam packaging or
similar material to avoid damaging
the backboard of the refrigerator. To
reverse the door, the following steps
are generally recommended.
1. Stand the refrigerator upright.
2. Remove part ① and part ② from
the refrigerator body, and then take
down part ③ on the door in the same
way. Remove the part screws ④ ,then
take off part ⑤ as the picture below.
③
① Upp er hing e cover
② Top cov er bloc k
④
Cov er plat e
③
④
Spe cial fl ange se lf-
⑤
tap ping sc rew
⑤
Upp er hing e part
Note: Please hold the freezer door by hand
during step 2 to prevent door dropping.
①
②
3. Take off the door ① and place it
on smooth surface with panel upwards.
Screw out the hinge axis ② (include
washer) as show figure Ⅱ and Ⅲ
， and then turn the upper hinge
fixed board ③ over as show figure
Ⅳ . Finally fix part ②on part ③ as
show figure Ⅴ and Ⅵ,then place it at
side for use.
Ⅰ
Ⅱ
①
②
Ⅳ
Ⅵ
Ⅲ
Ⅴ
③
4.Lever handle covers ① and loose
screws ② , remove the handle ③ as
show figure Ⅰ ,then place it at side
for use. Take the screw hole covers ④
down as show figure Ⅱ , and install
them in the right side as show figure
Ⅲ . Change handle to left, install it as
show figure Ⅳ . Detach door stopper
⑤ and limit block ⑥ and then install
door stopper and limit block to right as
show figure Ⅴ and Ⅵ.
Ⅰ
Ⅲ
Ⅴ
③
②
⑤
⑥
① Handle covers ② Screws
③ Handle ④ Screw ho le covers
⑤ Door stopper ⑥ Li mit block
⑦ Self-tapp ing screws
⑦
①
Ⅱ
④
Ⅳ
Ⅵ
7.Just remount to the step 5,change
part① to right and part② to left and
then fix them with screws④ . Finally
install part③.
8. Take off the part ①, place it at side
for use as show figure Ⅰ . Move the
freezer door to appropriate position,
adjust part ② and door, then fix part
② by screws as show figure Ⅱ .
(Please hold upper door by hand when
installing). Fix the part ③ as show
figure Ⅱ(which is in the plastic bag) .
Reverse part ① by 180°and install it
onto the left corner of the door as
show figure Ⅲ . Finally mount part ④
as show figure Ⅳ.( which was taken
down in step 2)
Ⅰ
①
Ⅱ
②
③
5. Place refrigerator flatwise, remove
part③ and then loose screws④ .
Remove part ② and part① as the
picture.
①
②
③
④
①
Le
ft
Lowe
r
pa
hinge
rt
② Front
foot
fixe
d
boar
③ Ad
just
ab
le
bottom fee
t pa
rt ④
ecial fl
sp
ange s
elf-ta
d
pp
ing screw
6. Screw out lower hinge axis, change
it to the near hole site as the picture
below, and then screw up and mount
washer as the picture below.
er
sh
wa
e axis
hing
k to t
he doo
ay
r.
Note: washer m
ic
st
Ⅲ
Ⅳ
④
9.Finally install part ① and part ②
(both of which are taken down in step
2) in the refrigerator body as the
picture below.
①
②
Description of the appliance
View of the appliance
1.
Upper cover of door
2. Corner cover
3. Flap cover
4. Handle(back)
5. Ice tray(inside)
6. Upper freezer drawer
7. Middle freezer drawer(huge box)
8. Freezer door
9. Lower freezer drawer
10. Freezer door seal
11. Adjustable bottom feet
12. Hinge cover
13. Block cover
14. Functional board part
15. Glass shelf
16. Shelf part(inside)
17. Cabinet
12
Note: Due to constant improvement of our products, your refrigerator may be
slightly different from this instruction manual, but its functions and using methods
remain the same. To get more space in the freezer, you can remove drawer(except
lower freezer drawer), installation bracket and integrative ice maker/twistable ice
tray.
Note: To get the best energy efficiency of this product, please place all shelves,
drawers and baskets on their original position as the illustration above.
13
Display controls
All functions and controls of the unit are
ac cessi ble f rom a cont rol panel
conveniently located on the roof
refrigerator body. A display circuit board
allows easy configuration of features
and settings in a simple and intuitive
manner.
Important!
When the refrigerator is energized, all
the pilot lights will turn on for 3 sec and
you will also heard a long sound of
“beep”. The display board consists of
four buttons and eight pilot lights. You
will heard a short sound of “beep”
when you press the button.
Caution! When you set a temperature,
you set an average temperature for the
whole refrigerator cabinet.
Temperature inside the compartment
may vary from the temperature values
displayed on the panel, depending on
how much food you store and where
you place them. Ambient temperature
may also affect the actual temperature
inside the appliance.
1. Temp
Press “Temp” button to set
freezer temperature between 14℃ and -24℃ as needed,
and the light of the comparable
t e m p e r a t u r e w i l l b e l i g h t e n
corresponding values according to the
following sequence.
-14℃
-16℃
-24℃ -22℃
-18℃
-20℃
2. Super
Super will quickly lower the
temperature within the freezer
so food will freeze faster.
Controlling the temperature
We recommend that when you start
your refrigerator for the first time, the
temperature for the refrigerator is set to
-18°C. If you want to change the
temperature, follow the instructions
below.
This feature also helps to keep the
vitamins and nutrition of fresh food for
longer period.
Press “Super” button to activate the
●
super freeze function. The light will
come on and the freezer temperature
setting displays -24℃.
● Super freeze automatically switches
off after 26 hours and the freezer
temperature will revert back to the
previous setting.
● When super freeze function is on,
you can switch off super freeze function
by pressing “Super” or “Temp” button,
then the freezer temperature setting or
function mode will revert back to the
previous setting.
14
3. Alarm
In case of alarm, “Alarm” icon
will light up and a buzzing
sound will start.
Press “Alarm” button to stop alarm and
buzzing then “Alarm” icon will turn off.
Caution! When the refrigerator is
turned on after a period of inactivity, the
Alarm may be activated. In this case,
press “Alarm” button to cancel it.
users of potential damage to stored
food. If a power failure occurs, for
example a blackout in your area of
residence while you are away, the
temperature alarm may be activated
when power is restored to be the unit.
4. Power
If you want to stop using it,
you can turn the appliance off
by pressing “Power” button.
Door Alarm
The alarm light on and a buzzing sound
indicate abnormal conditions, such as
accidentally a door left open.
●
Leaving the door of refrigerator open
for over 2 minutes will activate a door
alarm and buzzer. The buzzer will beep
3 times per minute for 10 minutes.
Closing the door cancels the door
alarm and buzzer.
●
To save energy, please avoid keeping
the door open for a long time when
using refrigerator. The door alarm can
also be cleared by closing the door.
Temperature alarm
This is an important feature that alerts
When the refrigerator is working, you
●
can switch the appl ian ce off by
pressing “Power” button for above 5
seconds, meanwhile the display panel
will be turned off.
Important! Do not store any food in the
fridge during this time. If you will not
use the refrigerator for a long time,
please pull the plug.
● When the appliance is power off, you
can switch th e appliance on by
pressing “Power” button for 1 second,
and the refrigerator returns to the
previous temperature setting.
Using your appliance
This s ection explains that how t o use the refrigerator features. We
recommend that you read through carefully before using the appliance.
Flap cover
●
You can turn the flap cover upwards
when you want to take out the food in
the top chamber.
●
Before you open or close the flap
cover, you must lift it to the guide track
first. Then, the flap cover can slide
along the guide track to the top or the
bottom.
Freezer Drawer
●
It is used to store food which
needs t o be frozen, including meat,
fish, ice cream, etc.
15
Helpful hints and tips
●
Energy saving tips
We recommend that you follow the tips
below to save energy.
●
Try to avoid keeping the door open
for long periods in order to conserve
energy.
●
Ensure the appliance is away from
any sources of heat. (Direct sunlight,
electric oven or cooker etc.)
●
Don't set the temperature colder than
necessary.
●
Don't store warm food or evaporating
liquid in the appliance.
●
Pl ace the applian ce in a w ell
ventilated, humidity free, room. Please
refer to Installing your new appliance
chapter.
●
If the diagram shows the correct
combination for the drawers, crisper
an d shel ve s, do n ot adjust t he
combination as this is designed to be
the most energy efficient configuration.
Hints for fresh food refrigeration
●
Do no t place hot food di rectly i nto
t h e r e f rige r a t o r , t he i n t e rnal
temperature will increase re sulting
in the comp ressor having to work
har der and w i ll con sum e mor e
energy.
●
Do cov er or w rap the foo d，
particularly if it has a strong flavor.
●
Place food prop erly so that a ir can
circulate freely around it.
Hints for freezing
●
When first starting-up or after a
period out of use, let the appliance run
at least 2 hours on the higher settings
before putting food in the compartment.
Prepare food in small portions to
enable it to be rapidly and completely
frozen and to make it possible to
subsequently thaw only the quantity
required.
●●
Wrap up the food in aluminum foil or
polyethylene food wraps which are
airtight.
●
Do not allow fresh, unfrozen food to
touch the food which is already frozen
to avoid temperature rise of the latter.
●
I c e d p r o d u c ts, i f c o n s u m e d
immediately after removal from the
freezer compartment, will probably
cause frost burns to the skin.
●
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
Hints for the storage of frozen food
●
Ensure that frozen food has been
stored correctly by the food retailer.
●
Once defrosted，food will deteriorate
rapidly and should not be re-frozen. Do
not exceed the storage period indicated
by the food manufacturer.
Switching off your appliance
If the appliance needs to be switched
off for an extended period, the following
steps should be taken prevent mould
on the appliance.
1. Remove all food.
2. Remove the power plug from the
mains socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
Cleaning and care Cleaning and care
For hygienic reasons the appliance (including exterior and interior accessories)
should be cleaned regularly at least every two months.
Caution! The appliance must not be connected to the mains during cleaning.
Danger of electrical shock! Before cleaning switch the appliance off and remove
the plug from the mains socket.
16
Exterior cleaningExterior cleaning
To maintain good appearance of your
appliance, you should clean it regularly.
-Wipe the digital panel and display
panel with a clean, soft cloth.
-Spray water onto the cleaning cloth
instead of spraying directly on the
surface of the appliance. This helps
ensure an even distribution of moisture
to the surface.
-Clean the doors, handles and cabinet
surfaces with a mild detergent and
then wiped dry with a soft cloth.
Caution!
-Don't use sharp objects as they are
likely to scratch the surface.
-Don't use Thinner, Car detergent,
Clorox, ethereal oil, abrasive cleansers
or organic solvent such as Benzene for
cleaning. They may d amage t he
surface of the appliance and may
cause fire.
Interior cleaning
You should clean the appliance interior
regularly. It will be easier to clean when
food stocks are low. Wipe the inside of
the fridge freezer with a weak solution
of bicarbonate of soda, and then rinse
with warm water using a wrung-out
sponge or cloth. Wipe completely dry
before replacing the shelves and
baskets.
Thoroughly dry all surfaces an d
removable parts.
Although this appliance automatically
defrosts, a layer of frost may occur on
the freezer compartment's interior walls
if the freezer door is opened frequently
or kept open too long. If the frost is too
thick, choose a time when the supply of
food stocks are low and proceed as
follows:
1 . R e move e x ist i n g f oo d a nd
ac cessori es bask ets, u np lug t he
appliance from the mains power and
appliance from the mains power and
leave the doors open. Ventilate the
room thoroughly to accelerate the
thawing process.
2. When defrosting is completed, clean
your freezer as described above.
Caution! Don't use sharp objects to
rem o ve fro st f rom t he fre e zer
compartment. Only after the interior is
completely dry should the appliance be
switched back on and plugged back
into the mains socket.
Door seal cleaning
Take care to keep door seals clean.
Sticky food and drinks can cause seals
to stick to the cabinet and tear when
you open the door. Wash seal with a
mild detergent and warm water. Rinse
and dry it thoroughly after cleaning.
Caution! Only after the door seals are
completely dry should the appliance be
powered on.
Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance
is not functioning correctly, you can carry out some easy checks before calling for
service, please see below. You can carry out some easy checks according to this
section before calling for service.
Warning! Don't try to repair the appliance yourself. If the problem persists after you
have made the checks mentioned below, contact a qualified electrician, authorized
service engineer or the shop where you purchased the product.
17
Problem
Appliance is not
working correctly
Odours from the
compartments
Noise from the
appliance
Possible cause & Solution
Check whether the power cord is plugged into the power
outlet properly.
Check whether the “Power” funtion is on by pressing the
“power” button for 1 second.
Check the fuse or circuit of your power supply, replace if
necessary.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
It is normal that the refrigerator is not operating during the
automatic defrost cycle, or for a short time after the
appliance is switched on to protect the compressor.
The interior may need to be cleaned.
Some food, containers or wrapping cause odours.
The sounds below are quite normal:
●
Compressor running noises.
●
Air movement noise from the small fan motor in the fridge
compartment or other compartments.
●
Gurgling sound similar to water boiling.
●
Popping noise during automatic defrosting.
●
Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may
need you to check and take action:
●
The cabinet is not level.
●
The back of appliance touches the wall.
●
Bottles or containers fallen or rolling.
The motor runs
continuously
A layer of frost
occurs in the
compartment
Temperature inside
is too warm
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
●
Temperature setting is set colder than necessary
●
Large quantity of warm food has recently been stored
within the appliance.
●
The temperature outside the appliance is too high.
●
Doors are kept open too long or too often.
●
After your installing the appliance or it has been switched
off for a long time.
Check that the air outlets are not blocked by food and
ensure food is placed within the appliance to allow sufficient
ventilation. Ensure that door is fully closed. To remove the
frost, please refer to cleaning and care chapter.
You may have left the doors open too long or too frequently;
or the doors are kept open by some obstacle; or the
appliance is located with insufficient clearance at the sides,
back and top.
18
Temperature inside
is too cold
Doors can't be
closed easily
Water drips on the
floor
Incre ase the temp erature by f ollowing the “Displa y
controls” chapter.
Check wh ether the top of the refri gerator is tilted ba ck
by 1 0-15mm to al low th e door s to self close, or if
something inside is preventing the doors from closing.
The wate r pan (l ocated at the r ear bottom of the
cabinet) may not be pro perly leveled, or the dra ining
spout （located underneath t he top of the c ompresso r
depot）may not b e properly positioned to di rect w ater
into this pan , or the wat er spout is blo cked. Yo u ma y
need to pull the refrigerator away fro m the wall to ch eck
the pan and spout.
Disposal of the appliance
It is pro hibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with t he recyc le symbol are recycla ble. Dis pose of the
packaging into a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the p ower cord and discard with the mains plug.
War ning! Re frigerators cont ain refr igerant and g ases in the insu lation.
Refrigerant and gases m ust be disp osed of profes sionally as they m ay cause
eye injuries or igniti on. En sure that tubing of the re frigeran t circ uit is not
damage prior to proper disposal.
Correct Disposal of this product
This symbol on the product or in its packing indicates that this
product may not be treated as household waste. Instead, it should
be taken to the appropriate waste collection point for the recycling of
electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by the inappropriate waste handling of this
product. For more detailed information about the recycling of this
product, please contact your local council your household waste
disposal service, or the shop where you purchased the product.
Loading...
