SFL 14A
SFL 18A
SFL 36A
English en
Français fr
Español es
1
2
3
4
5
SFL 14A
SFL 18A
SFL 36A
en English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
fr Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
es Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a is a
prerequisite for safe, trouble-free handling and use of the product.
• Observe the safety instructions and warnings in this documentation and
on the product.
• Always keep the operating instructions with the product and make sure
that the operating instructions are with the product when it is given to
other persons.
1.2 Explanation of signs used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the
product. The following signal words are used in combination with a symbol:
DANGER! Draws attention to imminent danger that will lead to serious personal injury or fatality.
WARNING! Draws attention to a potential hazard that could lead to
serious personal injury or fatality.
CAUTION! Draws attention to a potentially dangerous situation that
could lead to minor personal injury or damage to the equipment or
other property.
1.2.2 Symbols
The following symbols are used in the documentation:
Read the operating instructions before use
General warning
Instructions for use and other useful information
1.2.3 Symbols on the product
The following symbols are used on the product:
Do not look directly into the light source.
1.2.4 Drawings in the illustrations
The illustrations in these operating instructions are intended to promote a
better understanding and may deviate from the actual version of the product.
These numbers refer to the corresponding illustrations found at the
beginning of these operating instructions.
1
The numbering in the illustrations reflects the order of the steps
shown in the illustration and may deviate from the numbering of the
steps/operations described in the text.
Item reference numbers are used in the overview illustration and
refer to the numbers used in the product overview section.
1.3 Product information
Hilti products are designed for professional use and may be operated, ser-
viced and maintained only by trained, authorized personnel. This personnel
must be informed of any particular hazards that may be encountered. The
product and its ancillary equipment may present hazards when used incorrectly by untrained personnel or when used not as directed.
The type designation and serial number are printed on the type identification
plate.
▶ Write down the serial number in the table below. You will be required to
state the product details when contacting Hilti Service or your local Hilti
organization to enquire about the product.
Product information
Cordless lamp SFL 14-A | SFL 18-A |
Generation 01
Serial no.
We reserve the right to make changes. Errors excepted.
2 Safety
2.1 Safety instructions
NOTE In addition to the information relevant to safety given in each of the
sections of these operating instructions, the following points must be strictly
observed at all times.
2.1.1 Careful handling and use
▶ Use the product only when it is in technically faultless condition.
▶ Never tamper with or modify the product in any way.
▶ Keep the product out of reach of children.
▶ Do not use the product where there is a risk of fire or explosion.
▶ Replace the complete cordless lamp when the light source has reached
the end of its life. The light source in this cordless lamp is not replaceable.
2.1.2 Use and care of battery-powered appliances
▶ Observe the special guidelines applicable to the transport, storage and
use of Li-ion batteries.
▶ Check that the appliance is switched off before inserting the battery.
2
SFL 36-A
▶ Do not expose batteries to high temperatures, direct sunlight or fire.
▶ Do not disassemble, squash or incinerate batteries and do not subject
them to temperatures over 80°C (176°F).
▶ Do not attempt to charge or continue to use damaged batteries.
▶ If the battery is too hot to touch it may be defective. In this case, place
the appliance in a non-flammable location, well away from flammable
materials, where it can be kept under observation and allowed to cool
down. Contact Hilti Service after the battery has cooled down.
▶ Use only the specified batteries in the product.
3 Description
3.1 Overview of the product 1
Reflector
@
Lamp body
;
Control knob
=
3.2 Intended use
The product described is a cordless lamp. It is designed to be used
to illuminate areas of jobsites. The product may be used only in a dry
environment.
▶ Use this product only with Hilti Liion batteries of the B 14, B 18 and B 36
series.
▶ Use only Hilti battery chargers of the C4/36 series for charging these
batteries.
3.3 Items supplied
Cordless lamp, operating instructions.
Other system products approved for use with this product can be found at
your local Hilti Center or online at: www.hilti.com
3.4 State of charge display
The charge state of the Liion battery is displayed after pressing one of the
two battery release buttons lightly (press only until slight resistance is felt).
Status Meaning
4 LEDs light. • Charge state: 75 % to 100 %
3 LEDs light. • Charge state: 50 % to 75 %
2 LEDs light. • Charge state: 25 % to 50 %
1 LED lights. • Charge state: 10 % to 25 %
1 LED blinks. • Charge state: < 10 %
On/off switch
%
Strap attachment point
&
Battery
(
3
Note
If the battery charge state LEDs blink, please refer to the information
given in the Troubleshooting section.
4 Technical data
SFL 14A SFL 18A SFL 36A
Voltage
14.4 V 21.6 V 36.0 V
5 Operation
5.1 Inserting the battery
CAUTION
Electrical hazard. Dirty contacts may cause a short circuit.
▶ Before inserting the battery, check to ensure that the battery terminals
and the contacts on the product are free from foreign objects.
CAUTION
Risk of injury. If the battery is not fitted correctly it may drop out and fall.
▶ Check that the battery is securely seated in the product so that
it cannot drop out and fall, thereby presenting a hazard to other
persons.
▶ Fit the battery and check that the battery is securely seated in the
appliance.
5.2 Removing the battery 2
SFL 14A
1. Press the release button at the rear of the battery.
2. Pull the battery out of the product to the rear.
5.3 Removing the battery 3
SFL 18A
1. Press both release buttons.
2. Pull the battery out of the product to the rear.
4
5.4 Removing the battery 4
SFL 36A
1. Press both release buttons.
2. Pull the battery out of the product to the rear.
5.5 Switching on and off
▶ Press the on/off switch.
5.6 Rotating the lamp head
CAUTION
Risk of damage to the eyes (the retina). Looking directly into the lamp
presents a risk of damage to the eyes (the retina).
▶ Do not direct the lamp at yourself or at anyone else.
▶ Do not, under any circumstances, look into the lamp.
▶ Rotate the lamp head into a suitable position.
Note
The lamp head can be rotated in only one direction. Take care to
avoid forcing the lamp head past the end stop.
5.7 Rotating the lamp head to the storage and transport position 5
▶ Rotate the lamphead by turning the knob, overcoming the slight resistance
of the position in which it engages, until the reflector is pointing towards
the battery.
◁ The lamp switches off automatically and can then be stored or trans-
ported.
Note
The lamp cannot be switched on when in the storage position. To
switch back on, rotate the lamp head until the reflector is facing
upwards and then switch the lamp on.
6 Care
6.1 Care of the product
WARNING
Danger of electric shock! Improper repairs to electrical components
may lead to serious injuries including burns.
▶ Repairs to the electrical section of the tool or appliance may be
carried out only by trained electrical specialists.
5
Note
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Center or online at: www.hilti.com
▶ Keep the product, especially its grip surfaces, clean and free from oil and
grease. Do not use cleaning agents containing silicone.
▶ Do not allow foreign objects to enter the interior of the product.
▶ Clean the outer surfaces of the appliance with a damp cloth at regular
intervals.
▶ Do not use a spray system, pressure jet washer or running water for
cleaning as this may negatively affect the electrical safety of the appliance.
6.2 Care of Liion batteries
▶ Do not allow moisture to enter the interior.
▶ Keep the battery clean and free from oil and grease.
▶ Clean the outer surfaces with a slightly damp cloth at regular intervals. Do
not use cleaning agents containing silicone.
▶ To achieve maximum battery life, stop drawing power from the battery as
soon as a significant drop in the performance of the appliance is noticed.
▶ Charge the batteries using the Hilti chargers approved for use with Li-ion
batteries.
7 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable
to remedy the problem by yourself, please contact Hilti Service.
Trouble or fault Possible cause Action to be taken
The battery runs
down more quickly
than usual.
The battery doesn’t
engage with an audible double click.
1 LED blinks.
The appliance does-
n’t work.
Battery condition is not
optimal.
The retaining lugs on the
battery are dirty.
Low battery. ▶ Change the battery
The battery is too hot or
too cold.
▶ Replace the battery or
have it tested by Hilti
Service.
▶ Clean the retaining
lugs and push the
battery in until it
engages.
and charge the empty
battery.
▶ Allow the battery to
cool down or warm
up slowly to room
temperature.
6
8 Disposal
WARNING
Risk of injury. Hazards presented by improper disposal.
▶ Improper disposal of the equipment may have the following conse-
quences: The burning of plastic components generates toxic fumes
which may present a health hazard. Batteries may explode if damaged or exposed to very high temperatures, causing poisoning,
burns, acid burns or environmental pollution. Careless disposal may
permit unauthorized and improper use of the equipment. This may
result in serious personal injury, injury to third parties and pollution of
the environment.
▶ Dispose of defective batteries right away. Keep them out of reach of
children. Do not disassemble or incinerate the batteries.
▶ Batteries that have reached the end of their life must be disposed of
in accordance with national regulations or returned to Hilti.
Most of the materials from which Hilti tools and appliances are manufactured can be recycled. The materials must be correctly separated before
they can be recycled. In many countries, your old tools, machines or appliances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti
representative for further information.
9 Manufacturer’s warranty
▶ Please contact your local Hilti representative if you have questions about
the warranty conditions.
7
Hilti = registered trademark of Hilti Corp., Schaan
Pos. 3 | 20160429
