Hilti SFC 14-A, 18-A User Manual

SFC 14-A/ SFC 18-A
Operating instructions en Mode d’emploi fr Manual de instrucciones es
ETL listed to US and Canadian safetystandards
Homologué ETL (conformeauxnormes de sécurité américaines et
Produtohomologado de accordo com as normasde segurança
canadiennes)
canadienses
americanas e canadianas
1
SFC 18-A
SFC 14-A
2
3
4
5
6
7
8
9
ORIGINAL OPERATING INSTRUCTIONS
SFC 14A / SFC 18A cordless drill / driver
It is essential that the operating instruc­tions are read before the power tool is op­erated for the first time.
Always keep these operating instructions together with the power tool.
Ensure that the operating instructions are with the power tool when it is given to other persons.
Contents Page
1. General information 1
2. Description 2
3. Insert tools, accessories 4
4. Technical data 4
5. Safety instructions 5
6. Before use 8
7. Operation 9
8. Care and maintenance 10
9. Troubleshooting 11
10. Disposal 12
11. Manufacturer’s warranty - tools 12
1 These numbers refer to the corresponding illustra­tions. The illustrations can be found on the fold-out cover pages. Keep these pages open while studying the operating instructions. In these operating instructions, the designation “power tool” always refers to the SFC 18-A or SFC 14-A cordless drill / driver, with battery fitted.
Parts, operating controls and indicators 1
@
Keyless chuck
;
Torque and drilling mode setting ring
=
Control switch (with electronic speed control)
%
Forward / reverse switch
&
2-speed gear selector switch
(
Lamp
)
Grip
+
Release buttons with additional function (charge status display activation)
§
Charge status and fault display (Li-ion battery)
/
Belt hook (optional)
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that could lead to slight personal injury or damage to the equipment or other property.
NOTE
Draws attention to an instruction or other useful information.
1.2 Explanation of the pictograms and other information
Warning signs
General warning
Warning: electricity
Warning:
caustic
substances
en
Obligation signs
Wear eye
protection
Wear a hard
hat
Wear ear
protection
Wear
protective
gloves
Wear breathing protection
Symbols
Read the
operating
instructions
before use
Volts Direct current Rated speed
under no load
Revolutions
per minute
Drilling without
hammering
Return waste
material for
recycling.
Location of identification data on the power tool
The type designation can be found on the type iden­tification plate at the base of the power tool and the serial number on the side of the casing. Make a note of this data in your operating instructions and always refer to it when making an enquiry to your Hilti representative or service department.
Type:
Generation: 01
Serial no.:
2. Description
2.1 Use of the product as directed
The SFC 18A or SFC 14A is a hand-held, cordless drill / driver for driving and removing screws and for drilling in steel, wood and plastic. Working on materials hazardous to the health (e.g. asbestos) is not permissible. Do not use the battery as a power source for other unspecified appliances. Modification of the power tool or tampering with its parts is not permissible. To avoid the risk of injury, use only genuine Hilti accessories and insert tools. Observe the information printed in the operating instructions concerning operation, care and maintenance. The power tool is designed for professional use and may be operated, serviced and maintained only by trained, authorized personnel. This personnel must be informed of any special hazards that may be encountered. The power tool and its ancillary equipment may present hazards when used incorrectly by untrained personnel or when used not as directed. The working environment may be as follows: construction site, workshop, renovation, conversion or new construction.
2.2 Chuck
Quick-release chuck
1
2
SFC14_A_SFC18_A_P3B_24_02_2011.qxd 25.2.2011 13:27 Uhr Se
en
2.3 Switches
Control switch with electronic speed control 2-speed gear selector switch Forward / reverse selector switch with transport lock Torque and drilling mode setting ring
2.4 Grips
Vibration-absorbing grip
2.5 Lubrication
Grease lubrication
2.6 The items supplied include (toolbox versions):
1 Power tool 1 Operating instructions 1 Hilti toolbox
2.7 The items supplied include (cardboard box versions):
1 Power tool 1 Operating instructions
2.8 Additional items required for operating the tool
B 18/1.6 Li-ion, B 18/2.6 Li-ion, B 14/1.6 Li-ion or B 14/3.3 Li-ion battery with C 4/36, C 4/36ACS or C 4/36ACS TPS charger.
2.9 Li-ion battery charge status and overheating indicator
LEDs light constantly LEDs blink Charge status C
LED 1,2,3,4
-
C 75 %
LED 1,2,3
-
50 % C < 75 %
LED 1,2
-
25 % C < 50 %
LED 1
-
10 % C < 25 %
-
LED 1
C < 10 %
-
LED 1 Battery overheated
2.10 Overload and overheating protection
The power tool is equipped with an electronic protection system to prevent overloading and overheating. The power tool switches itself off automatically in the event of overloading and overheating. After releasing the control switch, the power tool may not restart immediately when the switch is pressed again (while the power tool is cooling down).
3. Insert tools, accessories
Bit holder
S-BH 50 Charger for Li-ion batteries C 4/36 Charger for Li-ion batteries C 4/36ACS Charger for Li-ion batteries C 4/36-ACS TPS Battery B 18/1.6 Liion Battery B 18/2.6 Liion Battery B 14/1.6 Liion Battery B 14/3.3 Liion Belt hook (optional)
Keyless chuck clamping range 1.5…13 mm ({೑ೢ೧ ...½") Drilling diameter range in wood (soft)
1.5…20 mm ({೑ೢ೧ ... u೑೥ ") Drilling diameter range in wood (hard) 1.5…12 mm ({೑ೢ೧ ...½") Drilling diameter range in metal 1.5…10 mm ({೑ೢ೧ ... u೑೩") Wood screws (max. length 80 mm (3")) 3…6 mm ({೑೩ ...¼") Screws in plastic anchors (max. length 120 mm
(4.5"))
Max. 8 mm (max. u೑೩")
4. Technical data
Right of technical changes reserved.
Power tool SFC 14A SFC 18A
Rated voltage (DC voltage)
14.4 V 21.6V
Weight of power tool
1.5 kg (3.31 lb) 1.7 kg (3.75 lb)
Dimensions (L x W x H with B 14/1.6 or B 18/1.6)
192 mm (7.56") x 80 mm (3.15") x 225 mm (8.86")
202 mm (7.95") x 92 mm
(3.62") x 234 mm (9.21") 1st gear speed (with B 14/3.3 or B 18/2.6)
0…500/min 0…600/min
2nd gear speed (with B 14/3.3 or B 18/2.6)
0…1,700/min 0…1,800/min
Torque with tool set to drilling symbol (soft/flexible joint)
Max. 24 Nm (Max. 18 lb/ft) Max. 28 Nm (Max. 21 lb/ft)
Torque range (15 settings)
1.5…10 Nm (1…7 lb/ft) 1.5…10 Nm (1…7 lb/ft)
Battery B14/1.6 B14/3.3 B18/1.6 B18/2.6
Rated voltage 14.4 V 14.4 V 21.6 V 21.6 V Capacity
1.6 Ah 3.3 Ah 1.6 Ah 2.6 Ah Energy content 23.04 Wh 47.52 Wh 34.56 Wh 56.16 Wh Weight 0.36 kg (0.79 lb) 0.60 kg (1.32 lb) 0.48kg (1.06 lb) 0.78 kg (1.72 lb) Temperature mon­itoring
Yes Yes Yes Yes
Type of cell
Lithium-ion Lithium-ion Lithium-ion Lithium-ion
3
4
SFC14_A_SFC18_A_P3B_24_02_2011.qxd 25.2.2011 13:27 Uhr Se
en
Battery B14/1.6 B14/3.3 B18/1.6 B18/2.6
No. of cells
48612
5. Safety instructions
NOTE
The safety rules in section 5.1 contain all general safety rules for power tools which, in accordance with the applicable standards, require to be listed in the operating instructions. Accordingly, some of the rules listed may not be relevant to this tool.
5.1 General power tool safety warnings
a)
WARNING
Read all safety warnings and instructions. Fail-
ure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
5.1.1 Work area safety
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while oper-
ating a power tool. Distractions can cause you to lose control.
5.1.2 Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and refrigerators. Thereisan increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
5.1.3 Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the offposition before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e)
Do not overreach. Keep proper footing and bal­ance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away frommoving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
5.1.4 Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool before making any adjustments, changing ac­cessories, or storing power tools. Such preven-
tive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordancewiththeseinstructions taking into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5.1.5 Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically desig-
nated battery packs. Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery, avoid contact. If contact ac­cidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irrita­tion or burns.
5.1.6 Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of the power
tool is maintained.
5.2 Additional safety instructions
5.2.1 Personal safety
a) Hold power tool by insulated gripping surfaces,
when performing an operation where the fas­tener may contact hidden wiring. Fasteners con-
tacting a "live" wiremaymakeexposed metal parts of the power tool "live" and could give the operator an electric shock.
b) Wear ear protectors. Exposuretonoise can cause
hearing loss.
c) Use auxiliary handle(s), if supplied with the
tool. Loss of control can cause personal injury.
d) Always hold the power tool securely with both
hands on the grips provided. Keep the grips dry, clean and free from oil and grease.
e) Improve the blood circulation in your fingers by
relaxing your hands and exercising your fingers during breaks between working.
f) Avoid touching rotating parts. Switch the power
tool on only after bringing it into position at the workpiece. Touching rotating parts, especially
rotating insert tools, may lead to injury.
g) Activate the safety lock (forward / reverseswitch
in the middle position) before storing or trans­porting the power tool.
h) The power tool is not intended for use by chil-
dren, by debilitated persons or those who have received no instruction or training.
i) Children must be instructed not to play with the
power tool.
j) WARNING: Some dust created by grinding,
sanding, cutting and drilling contains chem­icals known to cause cancer, birth defects, infertility or other reproductive harm; or seri­ous and permanent respiratory or other injury.
5
6
SFC14_A_SFC18_A_P3B_24_02_2011.qxd 25.2.2011 13:27 Uhr Se
en
Some examples of these chemicals are: lead from lead-based paints, crystalline silica from bricks, concrete and other masonry products and natural stone, arsenic and chromium from chemically­treated lumber. Your risk from these exposures varies, depending on how often you do this type of work. To reduce exposure to these chemicals,
the operator and bystanders should work in a well-ventilated area, work with approved safety equipment, such as respiratory protection ap­propriate for the type of dust generated, and designed to filter out microscopic particles and direct dust away from the face and body. Avoid prolonged contact with dust. Wear protective clothing and wash exposed areas with soap and water. Allowing dust to get into your mouth,
eyes, or to remain on your skin may promote absorption of harmful chemicals.
5.2.2 Electric tool use and care
a) Secure the workpiece. Use clamps or a vice
to secure the workpiece. The workpiece is thus
held more securely than by hand and both hands remain free to operate the power tool.
b) Check that the insert tools used are compatible
with the chuck system and that they are secured in the chuck correctly.
5.2.3 Battery tool use and care
a) Ensure the switch is in the off position before
inserting the battery pack. Inserting the battery
pack into a lamp that is switched on may dazzle you.
b) Do not expose batteries to high temperatures or
fire. This presents a risk of explosion.
c) Do not disassemble, squash or incinerate bat-
teries and do not subject them to temperatures over 80°C. A risk of fire, explosion or injury
through contact with caustic substances may otherwise result.
d) Avoid ingress of dampness.Dampness may
cause a short circuit resulting in a risk of burning injury or fire.
e) Do not use batteries other than those approved
for use with the applicable power tool or appli­ance. Use of other batteries or use of the battery
for purposes for which it is not intended presents a risk of fire and explosion.
f) Observe the special instructions applicable to
the transport, storage and use of Li-ion batter­ies.
g) Remove the battery before storing or transport-
ing the power tool.
h) Avoid short-circuiting the battery. Check that the
terminals on the battery and in the power tool are free from foreign objects before inserting the battery in the power tool. Short circuiting the
battery terminals presents a risk of fire, explosion and chemical burns.
i) Do not charge or continue to use damaged bat-
teries (e.g. batteries with cracks, broken parts, bent or pushed-in and/or pulled-out contacts).
j) If the battery gets too hot to touch, this may indi-
cate that it is faulty. Place the tool at a location
where there is no riskofcausinga fire (at least 3 meters away from flammable materials), where it can be kept under observation and allowed to cool. Contact Hilti Service after the battery has been allowed to cool.
5.2.4 Electrical safety
Before beginning work, check the working area (e.g. using a metal detector) to ensure that no concealed electric cables or gas and water pipes are present. External metal parts of the power tool
may become live, for example, when an electric cable is damaged accidentally. This presents a serious risk of electric shock.
5.2.5 Work area
a) Ensure that the workplace is well lit. b) Ensure that the workplace is well ventilated.
Exposure to dust at a poorly ventilated workplace may result in damage to the health.
5.2.6 Personal protective equipment
The user and any other persons in the vicinity must wear ANSI Z87.1-approved eye protection, a hard hat, ear protection, protective gloves and breathing protection while the machine is in use.
6. Before use
6.1 Battery use and care
NOTE
Battery performance drops at low temperatures. Use a battery only when it has been fully charged. This ensures that maximum battery capacity is available. Change to the second battery as soon as a drop in performance is noticed. Recharge the battery imme­diately so that it is ready for reuse.
Store the battery in a cool, dry place. Never store the battery where it is exposed to direct sunlight or sources of heat, e.g. on heaters / radiators or behind a motor vehicle windscreen.Batteriesthat have reached the end of their life must be disposed of safely and correctly to avoid environmental pollution.
6.2 Charging the battery
DANGER Use only the Hilti batteries and Hilti chargers listed under “Accessories”.
6.2.1 Charging a new battery for the first time
Charge the battery fully before using it for the first time.
6.2.2 Charging a previously used battery
Ensure that the outer surfaces of the battery are clean and dry before inserting it in the corresponding charger. Read the operating instructions for the charger for further information about the charging procedure. Li-ion batteries are ready for use at any time, even when only partly charged. Charging progress is in­dicated by the LED display (see charger operating instructions).
6.3 Fitting the battery
CAUTION Before fitting the battery, check that the power tool is switched off and that the safety lock is engaged (forward/reverse switchinthe middle position). Use only the Hilti batteries approved for use with this power tool.
CAUTION Check that the terminals on the battery and in the power tool are free from foreign objects before inserting the battery in the power tool.
1. Push the battery into the power tool from the rear as far as it will go and until it is heard to engage with a double click.
2. CAUTION A falling battery may present a risk
of injury to yourself or others.
Check that the battery is seated securely in the power tool.
6.4 Removing the battery 2
1. Press one or both release buttons.
2. Pull the battery out of the power tool toward the rear.
6.5 Transport and storage of battery packs
Pull the battery pack out of the locked position (work­ing position)and move it into thefirstlatching position (transport position). If you disconnect a battery pack from the power tool for transport or storage, make sure that the contacts of the battery pack are not short-circuited. Remove loose metal parts such as screws, nails, clamps, loose screw bits, wires or metal swarf from the case, toolbox or transport container, or prevent these parts from coming into contact with the battery packs. Observe national and international transport regula­tions when shipping battery packs (transportation by road, rail, sea or air).
7
8
SFC14_A_SFC18_A_P3B_24_02_2011.qxd 25.2.2011 13:27 Uhr Se
en
6.6 Belt hook 3
CAUTION Check that the belt hook is fitted securely before beginning work.
The belt hook allows the power tool to be attached to a belt worn by the operator. The belt hook can also be fitted to the other side of the power tool for use by left-handed persons.
1. Pull the battery out of the tool.
2. Fit the mounting plate into the guides provided.
3. Secure the belt hook with the two screws.
7. Operation
CAUTION The tool may get hot during use. Wear protective gloves.
CAUTION When drilling and screwdriving, the grip of the tool may be deflected laterally (the tool tends to pivot about its own axis).
CAUTION To avoid injuries caused by the insert tool, wear protective gloves when changing insert tools.
7.1 Setting forward or reverse rotation 4
NOTE
The forward / reverse switch is used to select the direction of rotation of the drive spindle. An interlock prevents switching while the motor is running. The control switch is locked when the forward / reverse switch is in the middle position. Push the forward / reverse switch to the right (power tool heldinworking direction) to select forward rotation. Push the forward / reverse switch to the left (power tool held in working direction) to select reverse rotation.
7.2 Speed selection using the 2-speed gear switch 5
NOTE
The mechanical 2-speed gear switch can be used to select the speed range required. Speed with fully­charged battery: SFC 14A: 1st gear: 0500 /min., 2nd gear: 01700 /min. SFC 18A: 1st gear: 0600 /min., 2nd gear: 01800 /min.
7.3 Switching on / off
Speed of rotation can be controlled smoothly up to maximum speed by pressing the control switch slowly.
7.4 Fitting the drill bit
1. Set the forward / reverse switch to the middle position or remove the battery from the power tool.
2. Check that the connection end of the drill bit is clean. Clean the connection end if necessary.
3. Insert the drill bit in the keyless chuck and then turn the chuck firmly by hand until several clicks are heard.
4. Check that the drill bit is held securely.
7.5 Removing the drill bit
1. Set the forward / reverse switch to the middle position or remove the battery from the power tool.
2. Open the keyless chuck.
3. Pull the insert tool out of the chuck.
7.6 Drilling
CAUTION Use clamps or a vice to secure the workpiece. The workpiece is thus held more securely than by hand and both hands remain free to operate the power tool.
1. Turn the torque and operating mode setting ring to the drilling symbol.
2. Move the forward / reverse switch to the “For­ward” position.
7.7 Screwdriving
7.7.1 Fitting the bit holder / bit
1. Set the forward / reverse switch to the middle position or remove the battery from the power tool.
2. Open the quick-release chuck.
3. Insert the bit adapter in the keyless chuck and then turn the chuck firmly by hand until tight.
4. Check that the bit adapter is held securely (check by pulling).
5. Fit the bit in the bit holder.
7.7.2 Screwdriving
1. Select the torque function on the setting ring for torque and drilling.
2. Set the forward / reverse switch to the desired direction of rotation.
7.7.3 Removing the bit / bit holder
1. Set the forward / reverse switch to the middle position or remove the battery from the power tool.
2. Remove the bit from the bit holder.
3. Open the keyless chuck.
4. Remove the bit adapter.
7.8 Reading the charge status LED display on Liion batteries 6
NOTE
The chargestatus can not be indicatedwhilethe power tool is in operation. LED 1 blinks when the battery is fully discharged or when it is too hot (temperature above 80°C). The battery must then be inserted in the charger.
The Li-ion battery features a charge status LED dis­play. The chargestatusisindicated by the LEDs on the battery during charging (please refer to the operating instructions for the charger). When the battery is not in use, pressing one of the battery release buttons or inserting the battery into the power tool causes the battery charge status to be displayed by the four LEDs for three seconds.
8. Care and maintenance
CAUTION Before beginning cleaning, remove the battery from the power tool in order to prevent unintentional starting.
8.1 Care of insert tools
Clean off dirt and dust deposits adhering to the insert tools and protect them from corrosion by wiping the insert tools from time to time with an oil-soaked rag.
8.2 Care of the power tool
CAUTION Keep the power tool, especially its grip surfaces, clean and free from oil and grease. Do not use cleaning agents which contain silicone.
The outer casing of the power tool is made from impact-resistant plastic. Sections ofthegripare made from a synthetic rubber material. Never operate the power tool when the ventilation slots are blocked. Clean the ventilation slots carefully using a dry brush. Do not permit foreign objects to enter the interior of the power tool. Clean the outside of the power tool at regular intervals with a slightly
damp cloth. Do not use a spray, steam pressure cleaning equipment or running water for cleaning. This may negatively affect the electrical safety of the power tool.
8.3 Care of the Li-ion battery
Avoid entrance of moisture. Charge the battery fully before using it for the first time. In order to achieve maximum battery life, stop dis­charging the battery as soon as a significant drop in performance is noticed.
NOTE
If use of the power tool continues, battery discharge is stopped automatically (indicated by LED 1 blinking) before the battery cells suffer damage.
Charge the battery with the Hilti charger approved for use with Li-ion batteries.
NOTE
- A conditioning charge (as is required with NiCd or NiMH batteries) is not necessary.
- Interruption of the charging procedure has no neg­ative effect on battery life.
9
10
SFC14_A_SFC18_A_P3B_24_02_2011.qxd 25.2.2011 13:27 Uhr Se
en
- Charging can be started at any time with no negative effect on battery life. There is no memory effect (as with NiCd or NiMH batteries).
- For best results, batteries should be stored fully charged in acooldryplace. Avoid charging the battery in places subject to high ambient temperatures (e.g. at a window) as this has an adverse effect on battery life and increases the rate of self-discharge.
- If the battery no longer reaches full charge, it may have lost capacity due to aging or overstressing. It is possible to continue working with a battery in this condition but it should be replaced in good time.
8.4 Maintenance
WARNING Repairs to the electrical section of the power tool may be carried out only by trained electrical spe­cialists.
Check all external parts of the power tool for damage at regular intervals and check that all controls operate faultlessly. Do not operate the power tool if parts are damaged or when the controls do not function faultlessly. If necessary, the power tool should be repaired by Hilti Service.
8.5 Checking the power tool after care and
maintenance
After carrying out care and maintenance work on the power tool, check that all protective and safety devices are fitted and that they function faultlessly.
9. Troubleshooting
Fault Possible cause Remedy
The power tool doesn’t run.
The battery is discharged or fitted incorrectly.
The battery must be heard to en­gage with a double click or, respec­tively, needs to be charged.
Electrical fault. Remove the battery from the power
tool and contact Hilti Service. The power tool doesn’t run and 1 LED blinks.
The battery is discharged.
Change the battery and recharge
the discharged battery.
The battery is too hot or too cold. Bring the battery to the recom-
mended working temperature. The on / off switch can’t be pressed, i.e. the switch is locked.
The forward / reverse switch is in the middle position (transport lock engaged).
Push the forward / reverse switch
to the left or right.
The battery runs down more quickly than usual.
Battery condition is not optimal. Have battery condition diagnosed
by Hilti Service or replace with a
new battery. The battery doesn’t engage with an audible double click.
The retaining lugs on the battery are dirty.
Clean the retaining lugs and check
that the battery engages securely.
Contact Hilti Service if the problem
persists. LED 1 blinks The battery is discharged.
Charge the battery.
The power tool has been overloaded (application limits exceeded).
Use the right power tool for the job
(don’t use a low-powered tool for
heavy work).
10. Disposal
CAUTION
Improper disposal of the equipment may have serious consequences: The burning of plastic components generates toxic fumes which may present a health hazard. Batteries may explode if damaged or exposed to very high temperatures, causing poisoning, burns, acid burns or environmental pollution. Careless disposal may permit unauthorized and improper use of the equipment. This may result in serious personal injury, injury to third parties and pollution of the environment.
CAUTION
Dispose of defective batteries without delay. Keep them out of reach of children. Do not attempt to open or dismantle batteries and do not dispose of them by incineration.
CAUTION
Dispose of the batteries in accordance with national regulations or return them to Hilti.
Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements for taking back your old power tools or appliances for recycling. Please ask your Hilti customer service department or Hilti representative for further information.
11. Manufacturer’s warranty - tools
Hilti warrants that the tool supplied is free of defects in material and workmanship. This warranty is valid so long as the tool is operated and handled correctly, cleaned and serviced properly and in accordance with the Hilti Operating Instructions, and the technical system is maintained. This means that only original Hilti consumables, components and spare parts may be used in the tool.
This warranty provides the free-of-charge repair or replacement of defective parts only over the entire lifespan of the tool. Parts requiring repair or replace­ment as a result of normal wear and tear are not covered by this warranty.
Additional claimsare excluded, unless stringent na­tional rules prohibit such exclusion. In particular, Hilti is not obligated for direct, indirect, inciden­tal or consequential damages, losses or expenses in connection with, or by reason of, the use of, or inability to use the tool for any purpose. Im­plied warranties of merchantability or fitness for a particular purpose are specifically excluded.
For repair or replacement, send the tool or related parts immediately upon discovery of the defect to the address of the local Hilti marketing organization provided.
This constitutes Hilti’s entire obligation with regard to warranty and supersedes all prior or contempo­raneous comments and oral or written agreements concerning warranties.
11
12
SFC14_A_SFC18_A_P3B_24_02_2011.qxd 25.2.2011 13:27 Uhr Se
Hilti Corporation
LI-9494 Schaan Tel.:+423/2342111 Fax:+423/ 2342965 www.hilti.com
Hilti = registeredtrademark of Hilti Corp., Schaan W 3912 1110 00-Pos. 3 1 Printed in China © 2010 Right of technicaland programme changes reserved S. E. & O.
440882 / A
*440882*
440882
Loading...
