HD-TVI Speed Dome User Manual

HD-TVI Speed Dome

User Manual

UD03862B

HD-TVI Speed Dome User Manual

User Manual

© 2016 Hangzhou Hikvision Digital Technology Co., Ltd. This user manual is intended for users of HD-TVI Speed Dome. It includes instructions on how to use the Product. The software embodied in the Product is governed by the user license agreement covering that Product.

About this Manual

This Manual is subject to domestic and international copyright protection. Hangzhou Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.

Trademarks

and other Hikvision marks are the property of Hikvision and are registered

trademarks or the subject of applications for the same by Hikvision and/or its affiliates. Other trademarks mentioned in this manual are the properties of their respective owners. No right of license is given to use such trademarks without express permission.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL. HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR USE OF THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.

Support

Should you have any questions, please do not hesitate to contact your local dealer. Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer.

HD-TVI Speed Dome User Manual

iii

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2014/35/EU, the EMC Directive 2014/30/EU, the

RoHS Directive 2011/65/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info.

03028001061202

HD-TVI Speed Dome User Manual

Warnings Follow these safeguards to

prevent serious injury or death.

Cautions Follow these precautions to

prevent potential injury or material damage.

Safety Instruction

These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss.

The precaution measure is divided into ‘Warnings’ and ‘Cautions’:

Warnings: Serious injury or death may be caused if any of these warnings are neglected.

Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.

Warnings:

 Adopt the power adapter which can meet the safety extra low voltage (SELV) standard. Refer to

the specification manual for the standard of power adapter and the power consumption cannot be less than the required value.

 Do not connect several devices to one power adapter as an adapter overload may cause

over-heating and can be a fire hazard.

 When the product is installed on a wall or ceiling, the device should be firmly fixed.  To reduce the risk of fire or electrical shock, do not expose the indoor used product to rain or

moisture.

 This installation should be made by a qualified service person and should conform to all the local

codes.

 Install blackouts equipment into the power supply circuit for convenient supply interruption.  If the product does not work properly, please contact your dealer or the nearest service center.

Never attempt to disassemble the product yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

HD-TVI Speed Dome User Manual

Cautions:

 Make sure the power supply voltage is correct before using the product.  Do not drop the product or subject it to physical shock. Do not install the product on vibratory

surface or places.

 Do not expose it to high electromagnetic radiating environment.  Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can

cause fatal damage to the product.

 The sensor may be burned out by a laser beam, so when any laser equipment is being used,

make sure that the surface of the sensor not be exposed to the laser beam.

 Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise fire or

electrical shock will occur. Refer to the Specification for the details of operating temperature.

 To avoid heat accumulation, good ventilation is required for a proper operating environment.  While shipping, the product should be packed in its original packing.  Use the provided glove when open up the product cover. Do not touch the product cover with

fingers directly, because the acidic sweat of the fingers may erode the surface coating of the

product cover.

 Use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use

alkaline detergents.

 Improper use or replacement of the battery may result in hazard of explosion. Please use the

manufacturer recommended battery type.

HD-TVI Speed Dome User Manual

Table of Contents

Chapter 1 Overview .................................................................................................................. 1

1.1 Description ............................................................................................................................... 1

1.2 Functions .................................................................................................................................. 1

Chapter 2 Getting Started ......................................................................................................... 4

2.1 Power-up Action ....................................................................................................................... 4

2.2 Basic Operations ...................................................................................................................... 5

2.3 System-defined Presets ............................................................................................................ 5

2.4 On-screen Displays ................................................................................................................... 6

Chapter 3 Menu Operation ....................................................................................................... 7

3.1 Accessing and Operating the Menu ......................................................................................... 8

3.2 Configuring System Information .............................................................................................. 8

3.2.1 Checking System Information ............................................................................................... 8

3.2.2 Configuring System Parameters ........................................................................................... 9

3.3 Configuring Image Parameters............................................................................................... 13

3.3.1 Configuring Camera Parameters......................................................................................... 13

3.3.2 Configuring Privacy Mask ................................................................................................... 19

3.3.3 Configuring Output Standard ............................................................................................. 20

3.3.4 Configuring IR Parameters .................................................................................................. 21

3.4 Configuring PTZ Control Parameters ...................................................................................... 22

3.4.1 Configuring PTZ Parameters ............................................................................................... 22

3.4.2 Configuring Presets ............................................................................................................. 24

3.4.3 Configuring Patrols ............................................................................................................. 25

3.4.4 Configuring Patterns ........................................................................................................... 26

3.4.5 Configuring Timing Tasks .................................................................................................... 28

3.4.6 Configuring Zone ................................................................................................................ 30

3.5 Configuring and Handling Alarms .......................................................................................... 32

3.5.1 Configuring Alarm Input and Linkage Actions .................................................................... 32

3.5.2 Configuring Alarm Parameters ........................................................................................... 33

3.5.3 Configuring Alarm Output .................................................................................................. 34

3.6 Others ..................................................................................................................................... 35

3.6.1 Restoring Default Dome Settings ........................................................................................ 35

3.6.2 Restoring Default Camera Settings ..................................................................................... 35

3.6.3 Rebooting the Dome .......................................................................................................... 35

Appendix .................................................................................................................................................................. 35

Appendix 1 Lightning & Surge Protection ........................................................................................ 36

Appendix 2 RS485 Bus Connection .................................................................................................. 37

Appendix 3 24VAC Wire Gauge & Transmission Distance ................................................................ 40

Appendix 4 Wire Gauge Standards .................................................................................................. 41

HD-TVI Speed Dome User Manual

Chapter 1 Overview

1.1 Description

Integrated with the built-in pan/tilt unit, the HD-TVI speed dome features highly sensitive response and reliable performance. The speed dome can be adopted in various surveillance fields with its full-integral functions and features, such as corridor, large venue, meeting room, station, neighborhoods, etc.

1.2 Functions

The functions vary according to the different models of the speed dome.

 Coaxial Control

The speed dome with a specified DVR or controller can be sent the control signals via coaxial cable (BNC cable).

 High-Definition Output

The resolution of the output image can be up to 1080P.

 Limits

The dome can be programmed to move within the limits(left/right, up/down).

 Self-adaptive Protocol

While using RS485 control, the speed dome is compatible with PELCO-D, PELCO-P and PRIVATE-Code, etc., and is capable of being self-adaptive to these protocols without selecting protocol by DIP switch settings. While using coaxial control, the speed dome is self-adaptive to PELCO-D and PRIVATE-Code protocols.

 Keyboard Control

The pan/tilt movement and zoom actions of dome can be controlled by the control keyboard, DVR, matrix, etc.

 Scan Modes

The dome provides 5 scan modes: auto scan, tilt scan, and panorama scan.

 Preset Freezing

This feature freezes the scene on the monitor when the dome is moving to a preset. This allows for smooth transition from one preset scene to another. It also guarantees that masked area will not be revealed when the dome is moving to a preset.

 Presets

A preset is a predefined image position. When the preset is called, the dome will automatically move to the defined position. The presets can be added, modified, deleted and called.

 Label Display

The on-screen label of the preset title, PT display, zoom, and time can be displayed on the monitor.

 Auto Flips

HD-TVI Speed Dome User Manual

In manual tracking mode, when a target object goes directly beneath the dome, the video will automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This function can also be realized by auto mirror image depending on different camera models.

 Privacy Mask

This function allows you to block or mask certain area of a scene, for preventing the personal privacy from recording or live viewing. A masked area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.

 3D Positioning

In the client software, use the left key of mouse to click on the desired position in the video image and drag a rectangle area in the lower right direction, then the dome system will move the position to the center and allow the rectangle area to zoom in. Use the left key of mouse to drag a rectangle area in the upper left direction to move the position to the center and allow the rectangle area to zoom out.

 Proportional Pan/Tilt

Proportional pan/tilt automatically reduces or increases the pan and tilt speeds according to the amount of zoom. At telephoto zoom settings, the pan and tilt speeds will be slower than at wide zoom settings. This keeps the image from moving too fast on the live view image when there is a large amount of zoom.

 Auto Focus

The auto focus enables the camera to focus automatically to maintain clear video images.

 Day/Night Auto Switch

The speed domes deliver color images during the day. And as light diminishes at night, the speed domes switch to night mode and deliver black and white images with high quality.

 Slow Shutter

In slow shutter mode, the shutter speed will automatically slowdown in low illumination conditions to maintain clear video images by extending the exposure time. The feature can be enabled or disabled.

 Backlight Compensation (BLC)

If you focus on an object against strong backlight, the object will be too dark to be seen clearly. The BLC (Backlight Compensation) function can compensate light to the object in the front to make it clear, but this causes the over-exposure of the background where the light is strong.

 Wide Dynamic Range (WDR)

The wide dynamic range (WDR) function helps the camera provide clear images even under back light circumstances. When there are both very bright and very dark areas simultaneously in the field of view, WDR balances the brightness level of the whole image and provide clear images with details.

 White Balance (WB)

White balance can remove the unrealistic color casts. White balance is the white rendition function of the camera to adjust the color temperature according to the environment automatically.

 Patrol

A patrol is a memorized series of pre-defined preset function. The scanning speed between two presets and the dwell time at the preset are programmable.

 Pattern

A pattern is a memorized series of pan, tilt, zoom, and preset functions. By default the focus and iris

HD-TVI Speed Dome User Manual

are in auto status during the pattern is being memorized.

 Power Off Memory

The dome supports the power off memory capability with the predefined resume time. It allows the dome to resume its previous position after power is restored.

 T ime Task

A time task is a preconfigured action that can be performed automatically at a specific date and time. The programmable actions include: pan scan, patrol 1-8, pattern 1-4, preset 1-8, panorama scan, tilt scan, day, night, and none.

 Park Action

This feature allows the dome to start a predefined action automatically after a period of inactivity.

HD-TVI Speed Dome User Manual

XX-XXXXX-XX

SN XXXXXXXX

ADDRESS 0

COM FORMAT 2400,8,1

PROTOCOL AUTO MATCH

FIRMWARE X.XX

HARDWARE X.XX

BUILD DATE XX XX XX

TILT SUCCESS

PAN CHECK ERR

SMART VERSION VX.XX

System Info

Description

The serial No. of the speed dome, which is unique.

ADDRESS

The default communication address of the speed dome.

COM Format

The communication settings of the speed dome, including baudrate

(2400 by default), data bit (8 by default) and stop bit (1 by default)

PROTOCOL

It is for the communication with other devices.

FIRMWARE

The version of the firmware.

HARDWARE

The version of the hardware.

BUILD DATE

The date when the program of the software is compiled.

Chapter 2 Getting Started

2.1 Power-up Action

After the speed dome is power-on, it will perform a series of self-test actions. It runs the pan checking firstly, then the tilt checking and the camera checking at last. After the power-up actions, the system information will be displayed for 120 s on the live view screen as shown below.

Figure 2-1 System Information

Table 2-1 Descriptions of the System Information

 You have to configure the address and the baudrate for the speed dome the same as those in

the control devices.

 The speed dome is self-adaptive to the PELCO-D, PELCO-P, and PRIVATE-Code protocols.

HD-TVI Speed Dome User Manual

Preset NO.

Function

Preset NO.

Function

Auto-flip

Enable limits

Return to home position

Set manual limits

Patrol 1

Remote reboot

Patrol 2

Access main menu

Patrol 3

Stop scanning

Patrol 4

Start Random Scanning

IR cut filter in

Start Frame Scanning

IR cut filter out

Start auto scanning

Pattern 1

100

Start tilt scanning

Pattern 2

101

Start panorama scanning

Pattern 3

102

Patrol 5

Pattern 4

103

Patrol 6

Enable fast patrol

104

Patrol 7

Enable Wiper

105

Patrol 8

2.2 Basic Operations

You can operate the speed dome by using a control device, including the control keyboard, DVR, DVS, etc. In this manual, accessing the speed dome via the web browser will be taken as the example.

Panning and tilting:

Click the direction buttons to control the pan and tilt movement of the speed dome.

Zooming: Click the ZOOM+ and ZOOM- buttons to control the zooming. Focusing: Click the FOCUS+ and FOCUS- buttons to adjust the focus. Iris: Click the IRIS+ and IRIS- buttons to adjust the iris.

2.3 System-defined Presets

Purpose:

The section lists the system-defined presets with special functions. These presets cannot be edited but can be only called through a control device, e.g. a DVS or web browser. To call the system-defined presets remotely, you can choose the preset number from the list in the PTZ control panel. Please refer to table below for details. For instance, preset 99 is the “Start auto scan”. If you call the preset 99, the speed dome starts auto scan function.

Table 2-2 System-defined Presets

HD-TVI Speed Dome User Manual

2.4 On-screen Displays

The speed dome supports following on-screen displays:

Zoom Ratio: Identifies the amount of magnification. The format is ZXXX. XXX is the zoom amount. PT Angle: Displays panning and tilting direction, with the format of NEXXX/TXXX. The NE followed

with XXX indicates the degrees in north east direction, while the T followed with XXX indicates the degrees in tilt position.

Alarm: When an alarm is triggered, the corresponding information will be displayed. Time: Displayed as Day/Month/Year/Day of Week/Hour/Minute. It supports 24-hour time system. Preset Label: After you call the configured preset, the preset number is displayed if the lens moves

to the certain place where you’ve set a preset for.

Zone: Display the zone title. Address: Display the address of the speed dome. Error Rate: Display the error rate of the speed dome. Fan and Heat: Display the heat information of the speed dome.

HD-TVI Speed Dome User Manual

MAIN MENUS

DOME

SETTINGS

SYSTEM INFO

ADDRESS

COM FORMAT

PROTOCOL

FIRMWARE

HARDWARE

BUILD DATE

TEMPERATURE

SYSTEM

SETTINGS

CAMERA

PARAMETER

MOTION

PARAMETER

PRESETS

PATROLS

TIME TASKS

PATTERNS

PRIVACYS

ALARMS

AUXS

CLEAR

SETTINGS

RESTORE

DEFAULTS

RESTORE CAMERA

REBOOT

DOME

LANGUAGE

CAM VERSION

PARAM DATE

ZONES

PARAMETER

VIDEO SET

SMART

SETTINGS

Chapter 3 Menu Operation

 The operation interface of the different speed domes may differ. Please refer to the actual

operation interface.

 You can click the left and right direction buttons in the PTZ control panel via the web browser of

the DVR to enter the next page or return to the previous page of the submenu if more than one page is available.

Figure 3-1 Menu Structure

Before you start:

You can operate the speed dome by using the on-screen display menu remotely by connecting to a DVR or a DVS (encoder).

Examples of entering speed dome menu are listed as follows:

 Enter the menu by pressing buttons: PTZ -> REC -> 9 -> 5 on the front panel of the DVR.  Enter the menu by pressing buttons: CALL -> 9 -> 5 -> ENTER on the keyboard.  Enter the menu via the web browser of a DVR/DVS.

Menu operations via the web browser of a DVR will be taken as an example in this chapter.

HD-TVI Speed Dome User Manual

MAIN MENUS

<LANGUAGE> ENGLISH

EXIT

3.1 Accessing and Operating the Menu

To enter the main menu:

Steps:

1. Connect the video and RS-485 cables of speed dome to a DVR.

2. Visit the DVR via the web browser.

3. View the live video of the speed dome.

4. For PELCO-P/D and other private PTZ protocols, call preset 95 from the preset list in the PTZ

control panel of the DVR.

Figure 3-2 Main Menu

To move the cursor and operate the menu:

 Move the cursor up/down: On the live view page of the web browser, click up/down direction

buttons or FOCUS + and FOCUS - buttons in the PTZ control panel to move the cursor up and down.

 Enter/Exit: On the live view page of the web browser, click IRIS+ to enter a submenu; move the

cursor to Exit and click IRIS+ to exit.

To change the value of a parameter:

Steps:

1. Move the cursor to the target item and click IRIS+ button. You can see the shape of cursor

changes.

2. Click the up/down or left/right buttons in the PTZ control panel to choose the value from the

selectable value list.

3. Press IRIS+ to confirm the change or click IRIS- to cancel and restore the original value. You can

see the shape of cursor changes again.

3.2 Configuring System Information

3.2.1 Checking System Information

Purpose:

System information menu displays the current system information of the speed dome, including

HD-TVI Speed Dome User Manual

SYS INFO

XX-XXXXX-X

ADDRESS 0

COM FORMAT 2400,8,1

PROTOCOL SELF ADAPTIVE

VERSION 1.00

HARDVERSION 1.00

BUILD DATE 16 11 04

BACK EXIT

SYS INFO

CAM VERSION X.XX

PARAM DATE X XX XX

TEMPERATURE 38

TRACK X.XX

TRACKBUILDTIM 161130

BACK EXIT

SYSTEM INFO SETTINGS

SOFT ADDRESS 1

SOFT ADDR ACT OFF

SOFT BAUD 2400

SOFT BAUD ACT OFF

BROADCAST ADDR ON

PELCO CHECKSUM ON

SYSTEM TIME

BACK EXIT

SYSTEM INFO SETTINGS

ZERO ANGLE

HEAT CONTROL TEMP

FAN CONTROL TEMP

EIS FUNCTION OFF

EIS LEVEL N/A

PRESET FOCUS OFF

BACK EXIT

SYSTEM INFO SETTINGS

PROTOCOL STATUS OFF

PROTOCOL AUTO MATCH

485 CHECK AUTO

POWER MEMORY 180S

COAXITION ACTIVE ON

PROTOCOL-C HIK-C

BACK EXIT

model, address, protocol, etc. The information shown on this submenu is similar to the system information shown after the power-up action. Please refer to Section 2.1 for more details. Enter the system information display menu:

MAIN MENUS > SYSTEM INFO

Figure 3-3 System Information

 Information on this menu cannot be edited.  The temperature refers to the internal temperature of the speed dome.

3.2.2 Configuring System Parameters

Purpose:

You can check and also edit the system information of software address, baud rate, system time, etc. on the system information settings menu.

MAIN MENUS > DOME SETTINGS > SYSTEM INFO SETTINGS

Figure 3-4 System Information Settings

You can click the left and right direction buttons in the PTZ control panel via the web browser of the encoder to enter the next page and return to the previous page of the submenu if more than one page is available.

+ 33 hidden pages
