Key Features

 1/2.8" progressive scan CMOS
 Up to 1920 × 1080@30fps resolution
 Min. illumination:

Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR

 4× optical zoom, 16× digital zoom
 120 dB WDR, 3D DNR, HLC, EIS,

Regional Exposure, Regional Focus

 12 VDC & PoE
 Up to 20 m IR distance
 IK10, IP66
 Support H.265+/H.265 video compression

Available Model

 PTZ-N2204I-DE3

Dimension

1/4-20UNC

46[1.81]

83.5[3.29]

6-n 4.5

101.7[4.00]

Ø 130.7[5.15]

Ø 120[4.72]

Ø 80.7[3.18]

Unit: mm[inch]

PTZ-N2204I-DE3
2MP 4× IR Network PTZ Camera

Camera Module

Image Sensor

1/2.8" progressive scan CMOS

Min. Illumination

Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR

White Balance

Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium Lamp

Gain

Auto/Manual

Shutter Time

50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s

Day & Night

IR Cut Filter

Digital Zoom

16×

Privacy Mask

24 programmable privacy masks

Focus Mode

Auto/Semi-automatic/Manual

WDR

120 dB WDR

Lens

Focal Length

2.8 mm to 12 mm, 4× optical zoom

Zoom Speed

Approx. 2 s (optical lens, wide-tele)

Field of View

Horizontal field of view: 109° to 34° (Wide-Tele)
Vertical field of view: 57° to 19° (Wide-Tele)
Diagonal field of view: 135° to 39° (Wide-Tele)

Working Distance

10 mm to 1500 mm (wide-tele)

Aperture Range

F1.6 to F2.7

PTZ

Movement Range (Pan)

0° to 330°

Pan Speed

Configurable, from 0.1°/s to 100°/s,
Preset speed: 100°/s

Movement Range (Tilt)

From 0° to 90°

Tilt Speed

Configurable, from 0.1°/s to 100°/s
Preset Speed: 100°/s

Proportional Zoom

Support

Presets

300

Power-off Memory

Support

Compression Standard

Video Compression

Main Stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG

H.264 Type

Baseline Profile/Main Profile/High Profile

H.264+

Support

H.265 Type

Main Profile

H.265+

Support

Video Bitrate

32 Kbps to 16384 Kbps

Audio Compression

G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM

Audio Bitrate

64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2)

SVC

Support

Smart Features

Basic Event

Motion Detection, Video Tampering Detection, Exception

Smart Event

Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection,
Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio
Exception Detection

Specification
