Hikvision I7604N1TA, I7604N1TP, I7608N2TA Specsheet

I760xNxTx Series Surveillance Kits

DS-2CD2120F

-

I

I7608N2TA Kits)

DS-2CD

2342WD-I Outdoor

and I7608N2TP

Kits)

DS-7604NI-EV1/4P NVR

I7608N1TP

Kits

)

DS-7608NI-EV2/8P NVR

I7608N2TP

Kits)

NVR and Camera Kits

 Up to 5 Megapixel Resolution Recording

 40 Mbps/60 Mbps Incoming Bandwidth

 Supports H.264+ and H.264

 Synchronous HDMI and VGA Output 1920 × 1080p Resolution

 4/8-ch Network Cameras Can Be Connected

 1 SATA Interface

 Plug & Play w/Up to 8 Independent PoE Network Connections

 Supports Network Detection, Including Network Delay, Packet Loss

 Alarm and Audio I/O

(included with I7604N1TA and

Turret Camera
(included with I7604N1TP

Outdoor Dome Camera
(included with
I7604N1TA and

(included with I7604N2TA and

Each of the four Hikvision I760xN1Tx Surveillance Kits feature
a Network Video Recorder (NVR) bundled with IP cameras for
quick setup.

The kits are available with four channel (includes four cameras)
or eight channel (includes six cameras) NVRs. Each dual
stream NVR features 30 fps HDMI output, PoE+ connections,
and two-way audio input.

The 2 megapixel dome or 4 megapixel turret cameras with
1/2.8" progressive scan CMOS sensors offer resolutions up to
1920 x 1080 (I7604N1TA and I7608N2TA) and 2688 x 1520
(I760N1TP and I7608N2TP).

Available Models:

I7604N1TA: (1) DS-7604NI-EV1/4P NVR

(4) DS-2CD2120F-I Outdoor Dome Cameras

I7608N2TA: (1) DS-7608NI-EV2/8P NVR
(6) DS-2CD2120F-I Outdoor Dome Cameras

I7604N1TP: (1) DS-7604NI-EV1/4P NVR
(4) DS-2CD2342WD-I Outdoor Turret Cameras

I7608N2TP: (1) DS-7608NI-EV2/8P NVR
(6) DS-2CD2342WD-I Outdoor Turret Cameras



Specifications

DS-

2CD2342WD

-I Turret Camera

DS-2CD2120F

-

I Dome Camera

AB110

WMS

PC110

SRSM

SRS

CB110

WM110

I7604N1TA

I7604N1TP

I7608N

2TA

I7608N

2TP



CAMERA

Camera Quantity

4 6

Model DS-2CD2120F

-I DS-

2CD2342WD

-I DS-

2CD2120F

-I DS-

2CD2342WD

-I

Type 2 MP

CMOS vandal

-

resistant

network dome camera

4 MP CMOS network

turret

camera

2 MP

CMOS vandal

-

resistant

network dome camera

4 MP CMOS network

turret

camera

Lens 2.8 mm @ ƒ/2.0; angle of view: 106°

Image Sensor

1/2.8" progressive scan CMOS

1/3"

progressive scan CMOS

1/2.8" progressive scan CMOS

1/3"

progressive scan CMOS

Min. Illumination

0.028 lux @ ƒ/2.0, AGC on, 0 lux with IR

Shutter Speed

1/3 s to 1/100,000 s

1/3 s to 1/10,000 s

1/3 s to 1/100,000 s

1/3 s to 1/10,000 s

Lens Mount

M12

Day/Night

IR cut filter with auto switch

Digital Noise Reduction

3D DNR

Wide Dynamic Range

Digital WDR

120 dB

Digital WDR

120 dB

Angle Adjustment

Pan: 0° to 355°, tilt: 0° to 75°,

rotation: 0° to 355°

Pan: 0° to 360°, tilt: 0° to 75°,

rotation: 0° to

360°

Pan: 0° to 355°, tilt: 0° to 75°,

rotation: 0° to 355°

Pan: 0° to 360°, tilt: 0° to 75°,

rotation: 0° to 360°

Compression Standard

Video Compression

H.264/MJPEG

H.264+, H.264, MJPEG

H.264/MJPEG

H.264+, H.264, MJPEG

H.264 Type

Main profile

Video

Bit Rate

32 Kbps to 8 Mbps

32 Kbps to 16

Mbps 32 Kbps to 8 Mbps

32 Kbps to 16

Mbps

Dual Stream

Yes


Max. Resolution

1920 x 1080

2688 × 1520

1920 x 1080

2688 × 1520

Frame Rate

@ 60 Hz

30 fps (1920 x 1080, 1280 x 720,

1280 x 720)

20 fps (2

6

88 x

1520)

, 30 fps

(1920 x 1080, 1280 x 720)

30 fps (1920 x 1080, 1280 x 720,

1280 x 720)

20 fps (2

6

88 x 1520), 30 fps

(1920 x 1080, 1280 x 720)

Sub Stream

60 Hz:

30 fps (320 x 240), 30 fps

30 fps (704 x 576)

60 Hz:

30 fps (352 x 240),

60 Hz:

30 fps (320 x 240), 30 fps

30 fps (704 x 576)

60 Hz:

30 fps (352 x 240),

Image Settings

Rotate mode, saturation, brightness, contrast adjustable by client

software or Web browser

BLC Yes, zone optional

ROI Supported

Network

M

icroSD/SD

HC/SDXC

Built-in slot, 128 GB

maximum

--- Built-in slot, 128 GB

maximum

---

NAS S

upports NFS,

SMB/CIFS

Detection

Intrusion detection, line crossing detection, motion

detection, dynamic analysis

Alarm Trigger

Motion detection, tampering alarm, network disconnect, IP address conflict, storage exception

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6,

Bonjour

Security

User authentication, watermark

Standard

ONVIF

, CGI, ISAPI

General

One-key reset, anti

-

flicker, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, anonymous access

Interface

Communication Interface

1 RJ-45 10M/100M Ethernet interface

General

Operating Conditions

-30° C to 60° C (

-

22° F to 140° F);

h

umidity 95% or less (non

-

condensing)

Power Supply

12 VDC ±10%, PoE (802.3af)

Power Consumption

Max.

5.3 W Max.: 5.5 W (7.5 W w

/

ICR on)

Max.

5.3 W Max.: 5.5 W (7.5 W w

/

ICR on)

Ingress Protection level

IP67

IR Range

100 ft (

30 m)

Impact Protection

IEC60068

-2-

75Eh, 20J;

EN50102, up to IK10

N/A IEC60068

-2-

75Eh, 20J;

EN50102, up to IK10

N/A

Dimensions

Φ4.4

" ×

3.2"

(111 mm × 82 mm)

Φ

5.0" × 3.8"

(Φ127 mm × 97.5

mm)

Φ

4.4

" ×

3.2"

(111 mm × 82 mm)

Φ

5.0" × 3.8"

(Φ127 mm × 97.5

mm)

Weight

1.1 lb (500 g)

1.5 lbs (670 g)

1.1 lb (500 g)

1.5 lbs (670 g)

(352 x 288), 30 fps (640 x 480),

30 fps (640 x 360)

(352 x 288), 30 fps (640 x 480),

30 fps (640 x 360)

Accessories

Inclined Ceiling Mount

Wall Mount

WMS

Wall Mount

Pendant Cap

PC130T

Pendant Cap

Junction Box

CBM

Sun/Rain Shade

Inclined Ceiling Mount

Rain Shade

ABM

Corner Mount

CM

Conduit Box

Vertical Pole Mount

PM

Wall Mount



Specifications



NVR

Model DS-7604NI

-

EV1/4P

DS-

7608NI

-

EV2

/8P

Video/Audio Input

IP Video Input

4-ch 8-ch

Two-Way Audio Input

1-

ch, RCA (2.0 Vp

-

p, 1k Ω)

Network

Video Compression

H.264+,

H.264

Incoming Bandwidth

40 Mbps

60 Mbps

Outgoing Bandwidth

60 Mbps

Remote Connections

128

Video Output

Recording Resolution

5 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Frame Rate

Main stream: 3

0 fps

Sub-stream: 3

0 fps

HDMI/VGA Output

1-

ch, resolution: 1920 × 1080p/1600 × 1200/1280 × 1024/1280 × 720/1024 × 768

Decoding

Live View

Resolution

5 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Playback Resolution

Capability

2-

ch @ 1080p

2-

ch @ 720p,

2-ch @ 1080p

2-

ch @ 1080p

2-

ch @ 720p,

2-ch @ 1080p

Hard Disk

SATA 1 SATA interface for 1 HDD

HDD Included

1 TB 2 TB

Capacity

Up to 6 TB

External Interface

Network Interface

1 RJ-45 10/100/1000 Mbps self

-

adaptive Ethernet interface

USB Interface

1 × USB 2.0 and 1 × USB 3.0

Alarm In/Out

4 /1

PoE

Interface

4 independent 100 Mbps PoE network interfaces

8 independent 100 Mbps PoE network interfaces

Maximum Power

50 W 120 W

Supported Standards

802.3af and 802.3at

Other

Power Supply

48 VDC, PoE+ (802.3at)

100 to 240 VAC,

PoE+ (802.3at)

Consumption (without hard disk)

≤10 W

Working Temperature

+14° F to +131° F (

-

10°C to +55° C)

Working Humidity

10% to 90%

Chassis

1U chassis

Dimensions (W × D × H)

12.4" × 9.1" × 1.8" (315 mm × 230 mm × 45 mm)

17.5" × 11.4" × 1.8" (445

mm × 290 mm × 45 mm)

Weight (without hard disk)

≤2.2 lb (1 kg)

I7604N1TA

I7604N1TP

I7608N1TA

I7608N1TP

(continued)



DS-2CD2342WD-I

Dimensions

1. Audio In

2. Audio Out

3. VGA

4. HDMI

6. LAN

7. USB

8. Ground

9. Power In

5. Alarm I/O

10. Power Switch

11. Network Interfaces with PoE Function
