Hikvision HWT-B220-M User Manual

Key Features

 2 MP high-performance CMOS

 1920 × 1080 resolution

 2.8 mm, 3.6 mm, 6 mm fixed lens

 Day/Night switch

 EXIR 2.0, smart IR, up to 40 m IR distance

 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)

 IP66

HWT-B220-M
2 MP EXIR Bullet Camera

Specifications

Camera

Image Sensor

2 MP CMOS image sensor

Signal System

PAL/NTSC

Resolution

1920 (H) × 1080 (V)

Min. Illumination

0.01 Lux@(F1.2, AGC ON), 0 Lux with IR

Shutter Time

1/25 (1/30) s to 1/50,000 s

Lens

2.8 mm, 3.6 mm, 6 mm

Horizontal Field of View

103° (2.8 mm), 80.7° (3.6 mm), 50.1° (6 mm)

Lens Mount

M12

Day & Night

IR cut filter

Angle Adjustment

Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°

Synchronization

Internal synchronization

Video Frame Rate

PAL: 1080p@25fps
NTSC: 1080p@30fps

Menu

AGC

High/Medium/Low/Off

D/N Mode

Auto/Color/BW (Black and White)

BLC

Support

DWDR

Support

Language

English

Functions

Brightness, Sharpness, DNR, Mirror, Smart IR

Interface

Video Output

1 HD analog output

Switch Button

TVI/AHD/CVI/CVBS

General

Operating Conditions

-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

Power Supply

12 VDC ±15%

Power Consumption

Max. 4 W

Protection Level

IP66

Material

Metal

IR Range

Up to 40 m

Dimensions

75.4mm × 230.8 mm × 87.2 mm (2.97" ×9.09" × 3.43")

Weight

545 g (1.20 lb.)
