Key Features
1/3" progressive scan CMOS
3D DNR (Digital Noise Reduction)
2560 × 1440@20fps
Up to 30 m IR range
2.8 mm to 12 mm manual/motorized (with
-Z) vari-focal lens
PoE (Power over Ethernet)
IP67
H.265+, H.265, H.264+, H.264
Dual stream
120 dB WDR (Wide Dynamic Range)
HWI-D640H-V/Z
4.0 MP VF Network Dome Camera
Camera
Image Sensor
1/3" progressive scan CMOS
Min. Illumination
Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON)
Shutter Speed
1/3 s to 1/100, 000 s, support slow shutter
Slow Shutter
Yes
Auto-Iris
No
Day &Night
IR cut filter
Digital Noise Reduction
3D DNR
WDR
120 dB
Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 70°, rotation: 0° to 360°
Lens
Focal Length
2.8 to 12 mm
Aperture
F1.6
Focus
-V: Manual
-Z: Auto
FOV
Horizontal field of view: 98° to 28°
Vertical field of view: 51° to 16°
Diagonal field of view: 115° to 32°
Lens Mount
Φ14
IR
IR Range
Up to 30 m
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest
1 fixed region for main stream and sub-stream
Max. Resolution
2560 × 1440
Main Stream
Max. Frame Rate
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-stream
Max. Frame Rate
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement
BLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or
web browser
Day/Night Switch
Auto, scheduled
Network
Network Storage
Support micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal
login
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
Specification
Available Models
HWI-D640H-V (2.8 mm to 12 mm), HWI-D640H-Z (2.8 mm to 12 mm)
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP
address filter
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, iVMS-5200
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Video Output (Without -Z)
1Vp-p composite output (75 Ω/BNC)
Reset Button
Yes
General
Operating Conditions
-30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption and Current
-Z: 12 VDC, 0.8 A, max: 10 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max: 12 W
-V: 12 VDC, 0.5 A, max: 6 W; PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max: 8 W
Protection Level
IP67, IK10
Material
Metal & Plastic
Dimensions
Camera: Ø 141.2 mm × 99.6 mm (Ø 5.6" × 3.9")
With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1")
Weight
Camera: approx. 820 g (1.8 lb.)
With package: approx. 1200 g (2.6 lb.)
Dimension
98.6 mm (3.9" )
99.6 mm (3.9" )
Ø 141.2 mm (5.6" )
100.5 mm (4" )
43.3 mm
(1.7" )
29 mm
(1.1" )
58 mm
(2.3" )
25 mm
(1" )
Accessory
DS-1227ZJ
In-ceiling Mount
DS-1273ZJ-135
Wall Mount
DS-1273ZJ-135B
Wall Mount
DS-1280ZJ-DM21
Junction Box
DS-1276ZJ-SUS
Corner Mount
DS-1275ZJ-SUS
Vertical Pole Mount
DS-1281ZJ-DM23
Inclined Ceiling Mount
DS-1271ZJ-135
Pendant mount
