HWI-D140H(-M)

4.0 MP IR Network Dome Camera

Key Features

 1/3" progressive scan CMOS  3D DNR

 2560 × 1440@20fps  Up to 30 m IR range

 2.8 mm/4 mm fixed lens  PoE

 H.265+, H.265, H.264+, H.264  IP67, IK10

 Dual stream

 120 dB WDR

Specification

Camera

Image Sensor 1/3" progressive scan CMOS
Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)
Shutter Speed 1/3 s to 1/100, 000 s
Slow Shutter Yes
Auto-Iris No
Day &Night IR cut filter
Digital Noise Reduction 3D DNR
WDR 120 dB
Angle Adjustment Pan: 0° to 355°, tilt: 0° to 75°
Lens
Focal Length 2.8 mm, 4 mm
Aperture F2.0
Focus Fixed

FOV

Lens Mount M12
IR
IR Range Up to 30 m
Wavelength 850 nm

Compression Standard

Video Compression

H.264 Type Baseline Profile/Main Profile/High Profile
H.264+ Main stream supports
H.265 Type Main Profile
H.265+ Main stream supports
Video Bit Rate 32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest 1 fixed region for main stream and sub-stream


Max. Resolution 2560 × 1440
Main Stream

Max. Frame Rate
Sub-stream

Max. Frame Rate
Image Enhancement BLC, 3D DNR

Image Settings

Day/Night Switch Auto, scheduled

Network

Network Storage NAS (NFS, SMB/CIFS)
Alarm Trigger Motion detection, video tampering alarm, illegal login

Protocols

General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
API ONVIF (PROFILE S, PROFILE G), ISAPI

2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°
4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88°

Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG

50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or
web browser

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
