Hikvision DS-2DF8225IH-AEL(W) DarkfighterX 2MP 25× IR
Network Speed Dome adopts 2× 1/2.8" progressive scan
CMOS chips. With the 25× optical zoom lens, the camera
offers more details over expansive areas.
This series of cameras can be widely used for wide
ranges of high-definition, such as the rivers, forests,
roads, railways, airports, ports, squares, parks, scenic
spots, stations and large venues, etc.

Key Features

 2× 1/2.8" progressive scan CMOS
 Up to 1920 × 1080 resolution
 Ultra-low light:

Color: 0.001 Lux @(F1.5, AGC ON)
B/W: 0.0001 Lux @(F1.5, AGC ON)
0 Lux with IR

 25× Optical Zoom, 16× Digital Zoom
 Digital WDR, 3D DNR, HLC, BLC
 Up to 200 m IR distance
 24 VAC &Hi-PoE
 Support H.265+/H.265 video compression
 Deep-learning-based target classification

algorithm for auto-tracking 2.0 and perimeter
protection

DS-2DF8225IH-AEL(W)
DarkfighterX 2MP 25× IR Network Speed Dome

Camera Module

Image Sensor

2× 1/2.8" progressive scan CMOS

Min. Illumination

Color: 0.001 Lux @(F1.5, AGC ON)
B/W: 0.0001Lux @(F1.5, AGC ON)
0 Lux with IR

White Balance

Auto/Manual/ATW (Auto Tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium Lamp

AGC

Auto/Manual

Shutter Time

1/1 s to 1/30,000 s

Day & Night

IR Cut Filter

Digital Zoom

16×

Privacy Mask

24 programmable polygon privacy masks

Focus Mode

Auto/Semi-automatic/Manual

Digital WDR

Support

Lens

Focal Length

4.8 mm to 120 mm, 25× Optical

Zoom Speed

Approx. 4 s (optical lens, wide-tele)

FOV

Horizontal field of view: 58.2° to 3.2° (wide-tele)
Vertical field of view: 32.7° to 1.8° (wide-tele)
Diagonal field of view: 66.8° to 3.7° (wide-tele)

Working Distance

10 mm to 1500 mm (wide-tele)

Aperture Range

F1.5 to F3.5

IR

IR Distance

Up to 200 m

Smart IR

Support

PTZ

Movement Range (Pan)

360° endless

Pan Speed

Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s

Movement Range (Tilt)

From -20° to 90°

Tilt Speed

Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s

Proportional Zoom

Support

Presets

300

Patrol Scan

8 patrols, up to 32 presets for each patrol

Pattern Scan

4 pattern scans, record time over 10 minutes for each scan

Power-off Memory

Support

Park Action

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama
Scan

PTZ Position Display

ON/OFF

Preset Freezing

Support

Scheduled Task

Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama
Scan/Dome Reboot/Dome Adjust/Aux Output

Compression Standard

Video Compression

Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG

H.264 Type

Baseline Profile/Main Profile/High Profile

H.264+

Support

H.265 Type

Main Profile

H.265+

Support
