DS-2DF1-537-B
Network High Speed Dome
1/4”
WDR
Alarm
IP66
3D
3D
Key features
•
1/4" SONY EXVIEW HAD progressive scan CCD
•
True day/night
•
128x wide dynamic range
•
3D intelligent positioning function
•
3D digital noise reduction
•
Programmable alarm triggering
•
IP66 rating
Dimensions
Indoor
In
-
ceiling
Bore Size
Unit: mm
Accessories
Camera
Image sensor 1 / 4" SONY EXVIEW HAD progressive scan CCD
Effective pixel PAL:752(H)×582(V), NTSC:768(H)×494(V)
Horizontal resolution Color: 540 TVL, B / W: 570 TVL
Signal system PAL / NTSC
Min.illumination Color: 1.4 lux@F1.6, B / W: 0.01 lux@F1.6
White balance Auto / Manual / ATW / Indoor / Outdoor / Outdoor Auto / sodium lamp
AGC Auto / manual
S / N ratio ≥ 50dB
BLC On / off
WDR 128x (on / off / auto)
Anti-shake On / off
Shutter time PAL: 1 / 3 ~ 1 / 10,000s, NTSC: 1 / 4 ~ 1 / 10,000s
Digital zoom 12x
Privacy mask 24 privacy masks programmable
Focus model Auto / semi-automatic / manual
Lens
Focal length 3.4-122.4mm,36X
Zoom speed Approx.2.7s(Optical Wide-Tele)
Angle of view 57.8-1.7° (Wide-Tele)
Min. working distance 320-1,500mm(Wide-Tele)
Aperture range F1.6 - F4.5
Pan and tilt
Pan Range 360°endless
Pan Speed Pan Manual Speed: 0.1° -300° / s, Pan Preset Speed: 540° / s
Tilt Range -5°-185°(Auto Mirror)
Tilt Speed Tilt Manual Speed: 0.1°-240° / s, Tilt Preset Speed: 400° / s
Proportional Zoom Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset 256
Patrol 8 patrols, up to 32 presets per patrol
Pattern 4 patterns, with the total recording time not less than 10 min
Power-off Memory Support
Park Action Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display On / Off
Freeze Frame Support
Alarm
Alarm input 2 (7 alarm inputs optional)
Alarm action Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan / Relay output
Input/output
Monitor output 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
Network
Ethernet 10Base-T / 100Base-TX, RJ45 connector
Max.image resolution PAL:704×576, NTSC:704×480
Frame rate PAL :25 fps (704×576), NTSC: 30 fps (704×480)
Image compression H.264 / MJPEG
Audio compression G.711 / 16kbps
Protocols
No. of simultaneous users Up to 6 users
Dual streams Support
Mini SD memory card Manual REC / Alarm REC., Built-in SD / SDHC Slot, up to 32GB
User / Host level 3 Levels: Administrator, Camera control, Live view only
Security measures User authentication (ID and PW), Host authentication (MAC address)
Client GUI
Camera control Pan / Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call and program, Auto mode.
Camera name Up to 18 characters
Date & time display Time: Week: Date, 6 formats on the Client
Reading patrol message Display and reading of preset message contained in each patrol via client software
General
Menu Language
RS-485 Protocols(optional) HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power Supply 24VAC
Power Consumption Outdoor dome: Max.45 W
Working Temperature / Humidity
Protection Level IP66 standard (outdoor dome), TVS 3,000V lightning protection, surge protection and voltage transient protection
Mounting Various mounting modes optional
Dimension
Weight (approx.) 5kg (11.02Ibs)
DS-2DF1-537-B
IR cut filterDay & night
2 relay outputs, alarm response actions configurableAlarm output
TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, RTSP, PPPoE, SMTP, NTP (FTP, SNMP optional )
English, Chinese
-10°C ~ 50°C (14°F ~ 122°F) (indoor), 90% or less
Φ 183.4 × 247mm ( Φ 7.22”×9.72”) (indoor), Φ 245 × 240mm (Φ 9.65”×9.45”) (in-ceiling)
DS-1614ZJ
(Long-arm Wall Mount Bracket)
We reserve the rights to modify product and specifications without notice.
Updated 04/26/13
