Hikvision DS-2CE56D0T-IT3F Service Manual

Type

Model

Type I

DS-2CE16C0T-IT1F/3F/5F
DS-2CE16D0T-IT1F/3F/5F

Type II

DS-2CE56C0T-IT1F/3F
DS-2CE56D0T-IT1F/3F

Type III

DS-2CE56C0T-IRMMF
DS-2CE56D0T-IRMMF

TURBO HD

TVI Bullet & Turret & Dome
Camera

User Manual

UD03600B

User Manual

Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.

This manual applies to the model listed below.

This manual may contain several technically incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.

0100001061107

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and

found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,
including interference that may cause undesired
operation

EU Conformity Statement

This product and - if applicable - the
supplied accessories too are marked with
"CE" and comply therefore with the

standards listed under the EMC Directive 2014/30/EU,
the RoHS Directive 2011/65/EU.

equipment, or dispose of it at designated collection
points. For more information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A)
standards requirements.

applicable harmonized European

2012/19/EU (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste in
the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new

Safety Instruction

Warnings Follow

these safeguards to
prevent serious injury
or death.

Cautions Follow these
precautions to prevent
potential injury or
material damage.

These instructions are intended to ensure that user can
use the product correctly to avoid danger or property
loss.

The precaution measure is divided into “Warnings” and
“Cautions”

Warnings: Serious injury or death may occur if any of
the warnings are neglected.

Cautions: Injury or equipment damage may occur if any
of the cautions are neglected.

Warnings

 In the use of the product, you must be in strict

compliance with the electrical safety regulations of
the nation and region.

 Refer to technical specifications for detailed

information.

 Input voltage should meet both the SELV (Safety Extra

Low Voltage) and the Limited Power Source with 12 V
DC according to the IEC60950-1 standard. Refer to
technical specifications for detailed information.

 Do not connect several devices to one power adapter

as adapter overload may cause over-heating or a fire
hazard.

 Make sure that the plug is firmly connected to the

power socket.

 When the product is mounted on wall or ceiling, the

device shall be firmly fixed.

 If smoke, odor or noise rise from the device, turn off

the power at once and unplug the power cable, and
then contact the service center.

 If the product does not work properly, contact your

dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not
assume any responsibility for problems caused by
unauthorized repair or maintenance.)

Cautions

 Make sure the power supply voltage is correct before

using the camera.

 Do not drop the camera or subject it to physical

shock.

 Do not touch senor modules with fingers. If cleaning

is necessary, use clean cloth with a bit of ethanol and
wipe it gently.

 Do not aim the camera at the sun or extra bright

places. Blooming or smearing may occur otherwise
(which is not a malfunction), and affect the
endurance of sensor at the same time.
