Hikvision DS-2CE56C5T-AVFIR Specsheet

DS-2CE56C5T-(A)VFIR
HD720P Low-light Indoor Vari-focal IR Dome Camera

 1.27 Megapixel high-performance CMOS

 Analog HD output, up to 720P resolution

 Low illumination

 2.8 – 12mm vari-focal lens

 True Day/Night

 OSD menu, 3D DNR, Smart IR

 Up to 30m IR distance

 24V AC/ 12V DC (-A)

 Up the Coax(HIKVISION-C, Pelco-C Protocol)

Key Features

Specifications

Camera

Image Sensor

1.27MP CMOS Image Sensor

Signal System

PAL/NTSC

Effective Pixels

1305(H)*977(V)

Min. illumination

0.001 Lux @(F1.2,AGC ON), 0 Lux with IR

Shutter Time

1/25(1/30)s to 1/50,000s

Lens

2.8 - 12 mm @ F1.4

Angle of view: 92° - 29.3°

Lens Mount

φ14

Day & Night

ICR

Angle Adjustment

Pan: 0 - 340°, Tilt: 0 - 75°, Rotation: 0 - 355°

Synchronization

Internal synchronization

Video Frame Rate

720p@25fps/720p@30fps

HD Video Output

1 Analog HD output

CVBS Output

1Vp-p Composite Output(75Ω/BNC)

S/N Ratio

＞62dB

Menu

Automatic Exposure

Globe AE/DWDR

AGC

Low/Middle/High/Off

Slow Shutter

Support

White Balance

Auto/Manual

D/N Mode

Color/BW/SMART IR

3D DNR

Low/Middle/High/Off

Motion Detection

Support, maximum 4 zones

Privacy Mask

On/Off, maximum 8 zones

Language

English/Chinese

Function

Digital Wide Dynamic Range, 3D Digital Noise Reduction, Sharpness, Brightness, Digital Zoom, Mirror,

General

Operating Conditions

-20 °C – 45 °C (-4 °F – 113 °F), Humidity 90% or less (non-condensing)

Power Supply

12 VDC±15%; -A: 12 VDC±15% 24 VAC±15%,

Power Consumption

Max. 4W; -A: Max. 5W

IR Range

Up to 30m

Communication

Up the coax, Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output)

Dimensions

Φ136 × 101 mm (Φ 5.35” × 3. 98”)

Weight

600 g

Order Models

DS-2CE56C5T-(A)VFIR
