Hikvision DS-2CE19D3T-AIT3ZF, DS-2CE5AD3T-AVPIT3ZF, DS-2CE5AD3T-AVPIT3ZFB, DS-2CE79D3T-IT3ZF User Manual

TURBO HD

D3T Series

Bullet & Turret & Dome

Camera

User Manual

User Manual

Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:

Model

Type I Camera

DS-2CE19D3T-(A)IT3ZF

Type II Camera

DS-2CE79D3T-IT3ZF

Type III Camera

DS-2CE5AD3T-(A)VPIT3ZF

This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.

0100001080815

Regulatory Information

FCC Information

Please take attention that changes or modification not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
FCC compliance: This equipment has been tested and
found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,
including interference that may cause undesired
operation.

EU Conformity Statement

This product and - if applicable - the
supplied accessories too are marked with
"CE" and comply therefore with the

applicable harmonized European
standards listed under the Low Voltage Directive
2014/35/EU, the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products

marked with this symbol cannot be

disposed of as unsorted municipal waste in

the European Union. For proper recycling,

return this product to your local supplier

upon the purchase of equivalent new
equipment, or dispose of it at designated collection
points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a

battery that cannot be disposed of as

unsorted municipal waste in the Europea n

Union. See the product documentation for

specific battery information. The battery is

marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery
to your supplier or to a designated collection point. For
more information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A)
standards requirements.

Warning

This is a class A product. In a domestic environment this
product may cause radio interference in which case the
user may be required to take adequate measures.

Safety Instruction

These instructions are intended to ensure that user can
use the product correctly to avoid danger or property
loss.
The precaution measure is divided into “Warnings” and
“Cautions”.
Warnings: Serious injury or death may occur if any of
the warnings are neglected.
Cautions: Injury or equipment damage may occur if any
of the cautions are neglected.

Warnings

 In the use of the device, you must be in strict

compliance with the electrical safety regulations of
the nation and region.

 Input voltage should meet both the SELV (Safety Extra

Low Voltage) and the Limited Power Source with 12
VDC according to the IEC60950-1 standard. Refer to
technical specifications for detailed information.

 Do not connect multiple devices to one power

adapter to avoid over-heating or a fire hazard caused
by overload.

 Make sure that the plug is firmly connected to the

power socket.

 Make sure that the device is firmly fixed if wall

mounting or ceiling mounting is adopted.

 If smoke, odor or noise rise from the device, turn off

the power at once and unplug the power cord, and
then contact the service center.

 Never attempt to disassemble the camera by

unprofessional personal.

Cautions

 Do not drop the camera or subject it to physical

shock.

 Do not touch senor modules with fingers.
 Do not place the camera in extremely hot, cold (the

operating temperature shall be -40°C to 60°C), dusty
or damp locations, and do not expose it to high
electromagnetic radiation.

 If cleaning is necessary, use clean cloth with a bit of

ethanol and wipe it gently.

 Do not aim the camera at the sun or extra bright

places.

 The sensor may be burned out by a laser beam, so

when any laser equipment is in using, make sure that
the surface of sensor will not be exposed to the laser
beam.

 Do not expose the device to high electromagnetic

radiation or extremely hot, cold, dusty or damp
environment.

 To avoid heat accumulation, good ventilation is

required for the operating environment.

Warnings Follow
these safeguards to
prevent serious injury
or death.

Cautions Follow these
precautions to prevent
potential injury or
material damage.
