Hikvision DS-2CE16D1T-AVFIR3 Specsheet

DS-2CE16D1T-(A)VFIR3
HD1080P Vari-focal IR Bullet Camera

 2 Megapixel high-performance CMOS

 Analog HD output, up to 1080P resolution

 2.8 – 12mm vari-focal lens

 True Day/Night, Smart IR

 Up to 40m IR distance

 IP66 weatherproof

 OSD menu

 24V AC/ 12V DC (-A)

 Up the Coax(HIKVISION-C protocol)

Key Features

Specifications

Camera

Image Sensor

2MP CMOS Image Sensor

Signal System

PAL/NTSC

Effective Pixels

1930(H)*1088(V)

Min. illumination

0.01 Lux @ (F1.2,AGC ON),0 Lux with IR

Shutter Time

1/25(1/30)s to 1/50,000s

Lens

2.8 - 12 mm @ F1.4

Angle of view: 114.5 - 35.1°

Lens Mount

φ14

Day & Night

ICR

Angle Adjustment

Pan: 0° - 360°; Tilt:0° - 90°; Rotate: 0° - 360°

Synchronization

Internal synchronization

Video Frame Rate

1080p@25fps/1080p@30fps

HD Video Output

1 Analog HD output

S/N Ratio

＞62dB

Menu

Camera ID

On/off (0-255)

AGC

Support

D/N Mode

Color/BW/Auto/EXT

White Balance

Auto/User/Push/8000K/6000K/4200K/3000K

Privacy Mask

On/Off, maximum 2 zones

Motion Detection

On/Off, maximum 4 zones

BLC

Support

Anti-flicker

On/Off

Language

English/Chinese

Functions

Digital noise reduction, Mirror

General

Operating Conditions

-40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

Power Supply

12 VDC±15%; -A: 12 VDC±15% 24 VAC±15%

Power Consumption

Max. 5W; -A: Max. 6W

Protection Level

IP66

IR Range

Up to 40m

Communication

Up the coax, Protocol: HIKVISION-C(TVI output)

Dimensions

92 × 84.8 × 269.6mm(3.62” × 3.34” × 10.6”)

Weight

1000 g

Order Models

DS-2CE16D1T-VFIR3, DS-2CE16D1T-AVFIR3
