Key Feature
5 MP high performance CMOS
2560 × 1944 resolution
2.8 mm, 3.6 mm fixed focal lens
PIR detection, visual alarm
EXIR 2.0, smart IR, up to 20 m IR distance
IP67
Up the coax (HIKVISION-C)
DS-2CE11H0T-PIRL
5 MP PIR Bullet Camera
Camera
Image Sensor
5.0 megapixel progressive scan CMOS
Signal System
PAL/NTSC
Frame Rate
PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps
NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
Resolution
2560 (H) × 1944 (V)
Min. Illumination
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Lens
2.8 mm, 3.6 mm fixed focal lens
Horizontal Field of View
85.5° (2.8 mm), 80.1° (3.6 mm)
Lens Mount
M12
Visual Alarm
Yes
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
Synchronization
Internal synchronization
Menu
White Light
Alarm/Off
AGC
Yes
Day/Night Mode
Auto/Color/BW (Black and White)
White Balance
Auto/Manual
Backlight Compensation
Yes
Language
English
Functions
Brightness, Contrast, Sharpness, Saturation, DNR, Mirror
Interface
Video Output
1 HD analog output
General
Operating Conditions
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply
12 VDC ±25%
Power Consumption
Max. 4 W
Ingress Protection
IP67
Material
Metal
IR Range
Up to 20 m
PIR Range
Angle: 110°, Range:11 m
Communication
Up the coax, Protocol: HIKVISION-C (TVI output)
Dimensions
68 mm × 70 mm × 179.8 mm ( 2.68" × 2.76" × 7.08" )
Weight
Approx. 345 g (0.76 lb.)
