DS-2CD50C5G0-(AP)
12 MP Box Network Camera
● 1/1.7” Progressive Scan CMOS
● Color: 0.008 Lux @ (F1.2, AGC ON)
● 4000 × 3000 @ 20fps
● MJPEG up to 1920 × 1080 @ 30fps
● Auto-iris, DC drive and P-iris optional
● Auto back focus (ABF) optional
● H.265, H.265+, H.264, H.264+
● Digital WDR
● Alarm 2 inputs/2 outputs, audio 1 input/1 output, 1 RS-
485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D
● 5 streams and up to 5 custom streams
● 6 behavior analyses, 3 exception detection, and face
detection
● Built-in microSD/SDHC/SDXC card slot, up to 256 GB
● Metadata of intrusion detection, line crossing detection,
region entrance detection, region exiting detection,
unattended baggage detection, and object removal are
supported.
Function
Smooth Streaming
Smooth streaming offers solutions to improve the video quality in different network conditions. For example, in poor
network conditions, adapting to the detected real-time network condition, streaming bit rate and resolution are
automatically adjusted to avoid mosaic and lower latency in live view; in multiplayer network conditions, the camera
transmits the redundant data for the self-error correcting in back-end device, so that to solve the mosaic problem because of
the packet loss and error rate.
Metadata
Metadata uses individual instances of application data or the data content. Metadata can be used for third-party application
development.
Power Protection
The camera supports a wide voltage range of 10 VDC to 48 VDC. If the voltage instability occurs, the camera still works
properly. The camera supports reverse polarity protection which can avoid the camera malfunction caused by false
operation.
Specifications
Camera
Image Sensor
1/1.7ʺ Progressive Scan CMOS
Min. Illumination
Color: 0.008 Lux @ (F1.2, AGC ON); B/W: 0.0008 Lux @ (F1.2, AGC ON)
Shutter Speed
1 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR cut filter
WDR
Digital WDR
Lens
Auto-Iris
DC drive. -P: P-iris supported
Lens Mount
CS mount
Video
Max. Resolution
4000 × 3000
Video Stream
5 defined streams and up to 5 custom stream
Main Stream
50Hz: 20fps (4000 × 3000), 25fps (4096 × 2160, 3840 × 2160, 3072 × 1728, 2560 ×
1440, 1920 × 1080, 1280 x 720)
60Hz: 20fps(4000 × 3000), 30fps (4096 × 2160, 3840 × 2160, 3072 × 1728, 2560 × 1440,
1920 × 1080, 1280 x 720)
Sub Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub stream/third stream/fourth stream/fifth stream/custom stream:
H.265/H.264/MJPEG
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream support
H.265 Type
Main Profile
H.265+
Main stream support
Video Bit Rate
32 Kbps to 16 Mbps
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Audio
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/
8-320Kbps(MP3)
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Smart Feature-Set
Smart Event
Line crossing detection, up to 4 lines configurable
Intrusion detection, up to 4 regions configurable
Region entrance detection, up to 4 regions configurable
Region exiting detection, up to 4 regions configurable
Unattended baggage detection, up to 4 regions configurable
Object removal detection, up to 4 regions configurable
Face detection: detects faces and upload images
Scene change detection, audio exception detection, defocus detection
Basic Event
Motion detection, video tampering alarm, exception (network disconnected, IP
address conflict, illegal login, HDD full, HDD error)
Statistics
Counting
Linkage Method
Trigger recording：memory card, network storage, pre-record and post-record
Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email
Trigger notification: HTTP, ISAPI, alarm output, Email
Region of Interest
Main stream/sub stream/third stream/fourth stream/fifth stream: 4 fixed regions and
dynamic face tracking for each stream
Image Enhancement
BLC, HLC, 3D DNR, Defog, EIS
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are
adjustable by client software or web browser
Target Cropping
Yes
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
SNR
≥52dB
Network
Network Storage
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
Together with high-end Hikvision memory card, memory card encryption and health
detection are supported.
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE,
NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
API
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Smooth Streaming
Yes
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP
over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS1.0, TLS1.1
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE8+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local service: Chrome57.0+，Firefox52.0+
Interface
Audio
1 input (line in), 1 output (line out), 2-core terminal block, mono sound
Communication Interface
1 RJ45 10M/100M/1000M Ethernet port
1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Alarm
2 inputs, 2 outputs (max. 24 VDC/VAC, 1A max.)
Video Out
1Vp-p composite output (75 Ω/CVBS), only for adjustment
Power Output
12 VDC, max. 200 mA
Interface Style
Connector panel
On-board Storage
Built-in microSD/SDHC/SDXC slot, up to 256 GB
General
Firmware Version
V5.6.0
Web Client Language
32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General Function
Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks,
flash log, password reset via e-mail, pixel counter, HTTP listening
Reset
Reset via reset button on camera body, web browser and client software
Startup and Operating
Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Power Supply
12 VDC is recommended, 10 to 48 VDC; 24 VAC (-25%, + 24.9%); two-core terminal
block; PoE (802.3af, class 3); Reverse polarity protection
Power Consumption and Current
With extra load: 12 VDC, 0.8 A, max. 10 W; 24 VAC, 0.7 A, max. 10 W; PoE (802.3af, 36
V to 57 V), 0.1 A to 0.3 A, max. 10 W, class 3
Without extra load: 12 VDC, 0.65 A, max. 7.6 W; 24 VAC, 0.55 A, max. 7.6 W; PoE
(802.3af, 36 V to 57 V), 0.1 A to 0.3 A, max. 7.6 W, class 3
Material
Metal
Dimensions
Camera: 142.6 × 69.8 × 68 mm (5.61ʺ × 2.75ʺ × 2.68ʺ)
Package: 315 × 140 × 140 mm (12.4ʺ × 5.51ʺ × 5.51ʺ)
Weight
-AP: approx. 730 g (1.61 lb.), 1020 g (2.25 lb.) with package
Non-AP: approx. 690 g (1.52 lb.), 975 g (2.15 lb.) with package
Approval
EMC
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013,
EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32:
2015, KN 35: 2015
Safety
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am
1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Chemistry
2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
* Listed resolutions are only selectable options. It does not mean that all streams can work at their maximum resolution at the
same time.
Available Model
DS-2CD50C5G0, DS-2CD50C5G0-AP
* -AP: Auto back focus and P-iris are supported.
Dimension
Accessory
DS-1332HZ
Indoor Housing
DS-1292ZJ
Wall Mount
DS-1299ZJ
Pendant Mount
DS-1331HZ Series
Outdoor Housing
DS-1293ZJ
Wall Mount
DS-1214ZJ
Horizontal Pole
Mount
DS-1269ZJ
Pendant Mount
DS-1233ZJ
Column Mount
DS-1331HZ-B
Outdoor Housing +
DS-2202ZJ Integrated
Mount
HV1140D-8MPIR
11 to 40 mm DC Iris
HV1140P-8MPIR
11 to 40 mm P-Iris
HV1050D-12MPIR
10 to 50 mm DC Iris
