Hikvision DS-2CD4065F-A Specsheet

DS-2CD4065F-(A)(P)
6MP Smart IP Box Camera

DS-2CD4065F-(A)(P) is Hikvision Smart IPC and features
complete Smart functions including:

Smart Detection

Intrusion Detection, Line Crossing Detection, Object

Left/Removal, Area Entering/Leaving, Scene Change Detection,

Audio Surge Detection, Audio Loss Detection, Defocus Detection,
Face Detection, Object Counting, etc.

Smart Codec

Smart Recording with dual-VCA, Low Bitrate, Low Latency, ROI
enhancement, Multi-stream, Edge Recording, etc.

Smart Image Control

Smart Auto Focus with ABF (-A Model)

The 6MP series Smart cameras are able to capture

high quality colored images. DS-2CD4065F-(A)(P)

offers Full HD resolution with up to 20fps high

frame rate, DWDR, Auto Back Focus, PoE, Defog,

3D DNR and complete Smart Feature-set to meet a
wide variety of applications.

 1/1.8” Progressive Scan CMOS
 6MP @20fps
 Slow shutter
 Digital WDR
 3D DNR
 -A: Auto Back Focus
 -P: P-iris
 Audio/Alarm IO

 Support 128G on-board storage

 DC12V/AC24V/PoE

Key Features

Smart

 6 behavior analysis, 4 exception detections, 1 recognition, 1 statistic function.
 Smart recording: Support edge recording and dual-VCA.
 Smart encoding: Support low bit rate; low latency; ROI enhance encoding
 Smart lens options: ABF (-A), P-iris(-P).


 HD 3072 × 2048@20fps
 Support suitable for environment as corridor.
 Support regional cropping, details can be seen with low bandwidth.
 Code smoothness setting for different requirements of image quality and fluency.
 Support H.264+/H.264/MJPEG video compression, multi-level video quality configuration; support

Basic/Main/High Profile H.264 encoding complexity.

 Multiple OSD color: Black & white self-adaptive; Custom
 Digital WDR is supportable for backlight environment.
 Support defog, BLC, HLC.

System

 Support ONVIF (profile S/profile G), CGI, PSIA, ISAPI protocol.
 Support three streams, and Support 20 channels live view at the same time.
 Anti-surge, anti-static protection level.

Interface

 Support standard 128G Micro SD/SDHC/SDXC card storage.
 Support 10M/100M/1000M Ethernet Port.
 Support Audio I/O, support dual channel stereo audio.
 Support Alarm I/O
 Support CVBS analog output (4CIF resolution)

Security

 Support three-level user authentication management, user and password authorization, IP address filtering and

anonymous access.

 Support security certificate as HTTPS, SSH; support creating certificate.
 Basic and digest authentication is supportable in IE configuration
 Lock user IP for many times error login
