DS-2CD2645FWD-IZS
4 MP IR Varifocal Bullet Network Camera
BLC/3D DNR/ROI/HLC
IP66, IK10
Built-in microSD/SDHC/SDXC card slot, up
to 128 GB
Color: 0.008 lux @(F1.2, AGC ON), 0.011
lux @(F1.4, AGC ON), 0 lux with IR
1/2.5" Progressive Scan CMOS
2688 × 1520 @30 fps
2.8 to 12 mm motorized varifocal lens
H.265+, H.265, H.264+, H.264
4 Behavior analyses
120dB WDR
Powered by Darkfighter
IR range: up to 50 m
Key Features
Specifications
Camera
Image Sensor
1/2.5" Progressive Scan CMOS
Min. Illumination
Color: 0.008 lux @(F1.2, AGC ON), 0.011 lux @(F1.4, AGC ON), 0 lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120dB
3-Axis Adjustment
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
Focal Length
2.8 to 12 mm
Lens Type
Motorized
Aperture
F1.4
Focus
Auto
FOV
2.8 mm to 12 mm, horizontal FOV: 114° to 32°, vertical FOV: 59° to 18°, diagonal FOV: 141° to 36.5°
Lens Mount
Φ14
IR
IR Range
Up to 50 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
Audio Compression
G722.1/G.711/G726/MP2L2/PCM/MP3
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3)
Smart Feature-set
Smart Event
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection,
face detection, scene change detection
Basic Event
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal
login, HDD full, HDD error)
Linkage Method
Trigger recording: memory card, network storage, pre-record and post-record
Trigger captured pictures uploading: FTP, HTTP, NAS, Email
Trigger notification: HTTP, ISAPI, alarm output, Email
Region of Interest
Support 1 fixed region for main stream and sub-stream
Max. Resolution
2688 × 1520
Main Stream
50Hz: 25 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-Stream
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
Image Enhancement
BLC/3D DNR/HLC
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client
software or web browser
SVC
H.264 and H.265 encoding support
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by alarm in
Network
Network Storage
Support microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
General Function
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP
listening
API
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2,
EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE
and digest authentication for ONVIF, TLS1.2
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE8+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local Service: Chrome 41.0+, Firefox 30.0+
Interface
Audio
1 input (line in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound
Alarm
1 input, 1 output (max. 12 VDC, 30 mA), terminal block
Video Output
1Vp-p Composite Output(75Ω) (For adjustment only)
Communication
Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board storage
Built-in microSD/SDHC/SDXC slot, up to 128 GB
Reset Button
Yes
Audio
Environment Noise
Filtering
Yes
Audio Sampling Rate
8kHz/16kHz/32kHz/44.1kHZ/48kHz
General
Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
Web Client Language
32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish,
Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian,
Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power Supply
12 VDC ± 25%, terminal block for DC input
PoE(802.3at, class 4)
Power Consumption and
Current
12 VDC, 1.2 A, max. 14.4 W
PoE (802.3at, 42.5V to 57V), 0.5 A to 0.3 A, max. 18 W
Protection Level
IP66, IK10
Material
Metal
Dimensions
Φ144.1 × 332.7 mm (Φ5. 7"× 13.1")
46 mm (1.8")
332.7 mm (13.1")
185.2 mm (7.3")
174.3 mm (6.9")
83.5 mm (3.3")
Unit: mm (inch)
DS-1475ZJ-SUS
Vertical Pole Mount
DS-1476ZJ-SUS
Corner Mount
DS-1475ZJ-SUS(Black)
Vertical pole mount
DS-1275ZJ-S-SUS
Vertical Pole Mount
Weight
Camera: approx. 1893 g (4.2 lb.)
Available Model:
DS-2CD2645FWD-IZS (2.8 to 12 mm)
Accessories
Dimensions
