Hikvision DS-2CD2365G1-I-2-8MM Specsheet

DS-2CD2365G1-I
6 MP IR Fixed Turret Network Camera

Key Features

 Up to 6 megapixel high resolution
 Max. 3072 × 2048 @20fps
 2.8 mm/4 mm/6 mm fixed lens, optional
 H.265, H.265+, H.264+, H.264
 120dB WDR
 Powered by Darkfighter

 12 VDC & PoE (802.3af, class 3)
 IR range: Up to 30 m
 Support on-board storage, up to 128 GB
 IP67
 BLC/3D DNR/ROI/HLC
 Color: 0.008 Lux @ (F1.2, AGC ON), 0.014 Lux

@(F1.6, AGC ON)

Specification

Camera

Image Sensor

1/2.4" Progressive Scan CMOS

Min. Illumination

Color: 0.008 Lux @ (F1.2, AGC ON), 0.014 Lux @ (F1.6, AGC ON)

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Focal length

2.8/4/6 mm

Focus

Fixed

Lens

2.8 mm, horizontal FOV: 99°, vertical FOV: 61°, diagonal FOV: 128°
4 mm, horizontal FOV: 80°, vertical FOV: 51°, diagonal FOV: 101°
6 mm, horizontal FOV: 60°, vertical FOV: 38°

Lens Mount

M12

Aperture

F1.6

Day &Night

IR cut filter

DNR

3D DNR

Wide Dynamic Range

120dB

3-Axis Adjustment

Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Compression Standard

Video Compression

Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
Third stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main stream supports

H.265 Type

Main Profile

H.265+

Main stream supports

Video Bit Rate

32 Kbps to 16 Mbps


Max. Resolution

3072 × 2048

Main Stream

50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×

720)
60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 ×

720)

Sub Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Third Stream

50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240)

Image Enhancement

BLC/3D DNR/HLC

Image Settings

Rotate mode, brightness, contrast, saturation, and sharpness are adjustable via web browser
and client software

ROI (Region of Interest)

Support 1 fixed region for main stream and sub stream separately

Day/Night Switch

Day/Night/Auto/Schedule

*Note: When the main stream resolution is 2944 × 1656 and above, max frame rate is 20 fps for all streams.

Network

Network Storage

Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR

Alarm Trigger

Motion detection, tampering alarm, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
