Hewlett-Packard MZ60 Quick Start Guide

HP Photosmart Mz60 series Digital Camera

English

Legal and notice information

only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

English

Windows® is a U.S. registered trademark of Microsoft Corporation.

SD Logo is a trademark of its proprietor.

Disposal of waste equipment by users in private households in the European Union

This symbol on the product or on its packaging indicates that this

product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

For future reference, enter the following information:

Model number: _________

•

Serial number: _________

•

Purchase date: _________

•

Contents

1 Getting started

Viewing the electronic User Guide...........................4

Camera top and back ..............................................6

Camera front, side, and bottom................................7

2 Setting up your camera

Install the batteries...................................................8

Turn on the camera..................................................9

Choose the language...............................................9

Set the region...........................................................9

Set the date and time...............................................9

Install and format an optional memory card...........10

Install the software.................................................11

Windows...........................................................11

Macintosh.........................................................12

3 Taking pictures and recording video clips

Take a picture.........................................................13

Record a video clip.................................................13

4 Reviewing and deleting images and video clips

Review images and video clips..............................15

Delete an image.....................................................15

5 Transferring and printing images

Transfer images.....................................................16

Print images from the camera................................16

6 Camera quick reference.......................................18

English

1 Getting started

This printed Quick Start Guide provides the information you need to get started using the essential features of your camera. For detailed information about camera features, see the electronic User Guide (see Viewing the

English

electronic User Guide on page 4).

Quick Start Guide

This printed guide will help you to:

• Start using your camera quickly

• Install the HP Photosmart Software

• Become familiar with your camera's basic features

Electronic User Guide

The electronic User Guide includes:

• Descriptions of all the camera features

• Battery information, including:

• Extending battery

life

• Supported battery

types

• A description of the

power indicator icons

• Getting assistance from HP

• Troubleshooting

• Camera specifications

Viewing the electronic User Guide

The electronic User Guide is on the HP Photosmart Software CD.

4 HP Photosmart Mz60 series Digital Camera

To view the User Guide:

1. Insert the HP Photosmart Software CD into the CD

drive of your computer.

2. Click View User Guide on the main page of the

installation screen.

The electronic User Guide is also copied to your computer when you install the HP Photosmart Software. To view the User Guide after it has been installed on your computer:

• On Windows: Open the HP Solution Center and click on Help and Support.

• On Macintosh: Open the HP Device Manager and select Camera User Guide from the Information and

Settings pop-up menu.

Getting assistance

• For tips and tools to help you use your camera more effectively, visit www.hp.com. From here, click on Learn About: Digital Photography (English only).

• For product support, including firmware, software, and driver updates, visit www.hp.com/support.

• For help with the HP Photosmart Software, see the software's online help.

English

Getting started 5

Camera top and back

English

4 5 6

321

1 Power light. 2 button. 3 Shutter button. 4

Delete button—Accesses the Delete function

while in

5 Flash button—Accesses the flash settings while

in Flash On, Flash Off.

6 selector—Switches between Picture

Capture, (see Picture Capture, Video Record, and Playback on page 18).

6 HP Photosmart Mz60 series Digital Camera

Playback.

Picture Capture. Settings are Auto, Red-Eye,

Video Record, and Playback

11 10

Zoom lever—Accesses / Zoom while in

Picture Capture or Video Record; accesses

Thumbnails and Magnify while in Playback.

9 USB connector. 10

11 Back button—Returns you to a previous menu

12 Image Display.

and buttons—Scroll through menus and

images.

button—Displays camera menus, selects

options, and confirms actions.

or view. Press and hold to back out of all menus.

Camera front, side, and bottom

English

1 Flash. 2 Self-Timer light. 3 Microphone. 4 Tripod mount. 5 Battery/Memory Card door.

Getting started 7

2 Setting up your camera

Install the batteries

1. Open the Battery/Memory Card door

English

by sliding the door latch as indicated on the Battery/Memory Card door.

2. Insert the two AA batteries.

3. Close the Battery/Memory Card door.

NOTE: If using rechargeable NiMH batteries, fully

charge the batteries before using them the first time. Turn the camera off before removing the batteries.

The batteries shipped with your camera are AA alkaline. These have a short life and are intended to let you begin using your camera immediately. When the camera warns that the battery charge is low, HP recommends replacing them with Photo Lithium or rechargeable NiMH batteries for longer battery life.

This graph shows the approximate average number of pictures you can take using Photo Lithium, NiMH, and Alkaline batteries. Actual performance may vary based on usage, battery type, and battery manufacturer. Many additional factors affect the actual number of pictures you can take (see Extending battery life on page 21).

8 HP Photosmart Mz60 series Digital Camera

Turn on the camera

To turn on the camera, press the button.

Choose the language

Use to choose the language you want, then press

Set the region

Along with the language setting, the region setting determines the default date format.

Use you want, then press

to choose the region

Set the date and time

Accurately setting the date and time will help you locate images once you have transferred them to your computer, and will ensure that images are accurately marked if you use the date and time imprint feature.

Use highlighted value.

2. Use selections and repeat Step 1 until the date and time are set correctly.

Press

to adjust the

to move to the other

when the date,

English

Setting up your camera 9

time, and format settings are correct, then press

again to confirm.

Install and format an optional memory card

This camera supports standard, high speed, and high

English

capacity Secure Digital (SD and SDHC) memory cards, 32MB to 8GB.

1. Turn off the camera and open

the Battery/Memory Card door.

2. Insert the optional memory card

in the smaller slot as shown. Make sure the memory card snaps into place.

3. Close the Battery/Memory Card

door and turn on the camera.

NOTE: When you turn on your camera with a

memory card installed, the camera indicates the number of images you can put on the memory card at the current Image Quality setting. This camera supports storing a maximum of 2000 images on a memory card.

Always format new memory cards before first use. Formatting removes all images from the memory card, so make sure to transfer existing images before formatting.

1. With the camera turned on, slide

Press

Use menu, then press

Use card.

to select Format Card from the Delete

to select Yes, then press to format the

to .

10 HP Photosmart Mz60 series Digital Camera

Once you install a memory card, all new images and video clips are stored on the card, rather than in internal memory.

To use internal memory and view images stored there, turn off the camera then remove the memory card.

Install the software

The HP Photosmart Software provides features for transferring images and video clips to your computer, as well as features for modifying stored images (remove red eyes, rotate, crop, resize, and more).

To install the HP Photosmart Software, your computer must meet the system requirements as stated on the camera packaging. To learn about Windows Vista support for your camera, see www.hp.com/go/windowsvista (English only).

If you have trouble installing or using the HP Photosmart Software, see the Hewlett-Packard Technical Support website for more information: www.hp.com/support.

Windows

1. Close all programs and temporarily disable any virus

protection software.

2. Insert the HP Photosmart Software CD into the CD drive and follow the on-screen instructions. If the installation window does not appear, click Start, click Run, type D:\Setup.exe, where D is the letter of your CD drive, then click OK.

3. When the software has finished installing, re-enable virus protection software.

English

Setting up your camera 11

Macintosh

1. Insert the HP Photosmart Software CD into the CD

drive.

2. Double-click the CD icon on the computer desktop.

3. Double-click the installer icon, then follow the on-

English

screen instructions.

Once installation is complete and you have restarted your computer, System Preferences automatically opens to the HP Photosmart Camera settings. You may change settings so the HP Photosmart Software starts automatically when you connect your camera to your Macintosh (for more information, click the help button on the HP Photosmart Camera settings dialog).

12 HP Photosmart Mz60 series Digital Camera

3 Taking pictures and

recording video clips

Slide to either to take pictures or to to record video clips.

Take a picture

You can take a picture when you are in

Picture Capture.

1. Slide

2. Frame the subject in the Image

Display.

3. Press the Shutter button halfway down to measure and lock the focus and exposure. The focus brackets in the Image Display turn solid green when focus is locked.

4. Press the Shutter button all the way down to take the picture.

After you have taken a picture, the camera displays it briefly in the Image Display.

Record a video clip

You can record a video when you are in

Video Record.

1. Slide

2. Frame the subject in the Image

Display.

3. Press the Shutter button halfway down to measure and lock the focus. The focus brackets in the Image Display turn solid green when focus is locked.

to .

English

Taking pictures and recording video clips 13

4. Press the Shutter button all the way down to start

recording.

5. To stop recording video, press and release the Shutter button again.

After you have recorded a video clip, the camera displays it briefly in the Image Display.

English

14 HP Photosmart Mz60 series Digital Camera

4 Reviewing and deleting

images and video clips

Review images and video clips

You can review images and video clips in Playback.

1. Slide

2. Use

To play a video clip, press the clip appears on the Image Display.

NOTE: To hear audio associated with video clips,

transfer them to your computer.

Delete an image

You can delete individual images during Playback:

1. Slide

2. Use

Press

Use menu, then press

to .

to scroll through your images and video clips.

once the first screen of

to .

to select an image or video clip.

to select This Image from the Delete

English

Reviewing and deleting images and video clips 15

5 Transferring and printing

images

Transfer images

English

Use this procedure to transfer images and video clips to your computer.

NOTE: Transferring a large number of high-

resolution images from a memory card to your computer may take up to two hours. When transferring a large number of images, be sure your camera batteries are fully charged or use an optional memory card reader.

1. Turn off the camera.

2. Connect the camera and

computer using the USB cable that came with your camera.

3. Turn on the camera. When the Image Display indicates that the camera is connected to the computer, follow the instructions on the computer screen to transfer the images. If you have installed the HP Photosmart Software and need more information, see the Help feature in the HP Photosmart Software.

Print images from the camera

You can connect the camera to any PictBridgecertified printer to print images.

1. Check that the printer is turned on, there is paper in the printer, and there are no printer

16 HP Photosmart Mz60 series Digital Camera

error messages.

2. Turn off the camera,

connect the camera and printer using the USB cable that came with your camera, then turn on the camera.

3. When the camera is

connected to the printer, the Image Display shows an image. Use

to select the image you want to

print.

Press

5. In the Print Options menu, select Print this image now and

to begin printing.

displays on the selected image in the Image

Display to indicate that the image is being printed.

6. After the printer has printed the image, disconnect the camera from the printer.

To learn about other printing options, see either the electronic User Guide or

Camera Help located in any

menu.

English

Transferring and printing images 17

6 Camera quick reference

Use this chapter as a quick reference to camera features. To learn more about these camera features, refer to the electronic User Guide or on-camera Help.

English

Picture Capture, Video Record, and Playback

•

Picture Capture allows you to frame pictures in

the Image Display and take pictures. To activate Picture Capture, slide

Video Record allows you to frame videos in the

• Image Display and record videos. To activate Video Record, slide

Playback allows you review and delete images

• and video clips. To activate

Camera Menus

Menus allow you to adjust camera settings, work with images, and access camera Help.

•

Within a menu, use selections.

• To exit the menu, press

Picture Capture Menu—Allows you to adjust camera

settings that affect the characteristics of future images you capture with your camera. To access this menu, slide

following options:

• Shooting Mode (Auto, Close-up, Super Close-up, Steady Photo, Theatre, Landscape, Portrait, Action, Night Portrait, Sunset)

•Self-Timer

to .

to , then press . You can select from the

to .

Playback, slide

to move to specific

at any time.

18 HP Photosmart Mz60 series Digital Camera

• Image Quality

•Burst

• Date & Time Imprint

• Camera Setup

• Camera Help

Video Record Menu—Allows you to adjust camera

settings that affect the characteristics of future video clips you record with your camera. To access this menu, slide

to , then press . You can select from

the following options:

•Self-Timer

• Camera Setup

• Camera Help

Playback Menu—Allows you to work with images. To

access this menu, slide

to , then press .

You can select from the following options:

• Remove Red Eyes

• Design Gallery (Modify Color, Add Borders, Rotate, Crop)

• Photosmart Express (Print, Share, Buy Prints Online)

• Favorites

• View Slideshow

• Move Images to Card

• Camera Setup

• Camera Help

English

Camera Setup Menu—Allows you to change the

camera's behavior. To access this menu, press

Camera quick reference 19

from

, , or , then select Camera Setup. You can

select from the following options:

• Display Brightness

• Camera Sounds

• Date & Time

English

• USB Configuration

• Language

Camera Help Menu—Provides descriptions of camera

features and picture-taking tips. To access this menu, press

from , , or , then select Camera

Help. You can select from the following options:

• Top Ten Tips

• Camera Accessories

• Camera Buttons

• Using Shooting Modes

• Using Design Gallery

• Using Photosmart Express

• Printing Images

• Recording Video Clips

• Reviewing Pictures and Videos

• Tagging Favorites

• Deleting Images

• Transferring Images

• Managing Batteries

• Getting Assistance

• Tour Camera Features

• Camera Shortcuts

• About

20 HP Photosmart Mz60 series Digital Camera

Extending battery life

To conserve battery power, the Image Display turns off after a period of inactivity. Pressing any button wakes up the camera. After five minutes of inactivity, the camera turns off.

To further extend battery life:

•Set

Display Brightness to Low (see the

electronic User Guide for details).

• Set your camera to

Auto Flash (see the electronic

User Guide for details).

• Use optical zoom, video recording, and Image Display sparingly.

• If you are turning on the camera only to view images, slide in

Playback without extending the lens.

to , then turn on the camera to start

For more information about batteries, go to www.hp.com/ support and search on the code AA-400 or see Appendix A in the electronic User Guide.

English

Camera quick reference 21

English

22 HP Photosmart Mz60 series Digital Camera

HP Photosmart Mz60-serien digitalkamera

Svenska

Juridiska meddelanden

föregående avisering. De enda garantierna för HP:s produkter och tjänster beskrivs i uttalandena om uttryckt garanti som medföljer sådana produkter och tjänster. Ingenting i detta dokument skall anses utgöra en utökning av sådan garanti. HP ansvarar inte för tekniska eller redaktionella fel eller utelämnad information i detta dokument.

Windows® är ett USA-registrerat varumärke tillhörande Microsoft Corporation.

SD-logotypen är ett varumärke som tillhör innehavaren.

Kassering av uttjänt utrustning från användare i privathushåll i Europeiska unionen

Den här symbolen på en produkt eller dess förpackning talar om att produkten inte får kasseras med det övriga hushållsavfallet. Du

ansvarar för att kassera uttjänt utrustning genom att lämna in den på en angiven insamlingsplats för återvinning av elektrisk och elektronisk

Svenska

utrustning. Särskild insamling och återvinning av uttjänt utrustning som kasseras hjälper till att bevara naturtillgångarna och ser till att utrustningen återvinns på ett sätt som skyddar människors hälsa och miljö. Om du önskar mer information om var du kan lämna in uttjänt utrustning för återvinning, kontakta det lokala stadskontoret, din sophämtningstjänst eller försäljaren av produkten.

Anteckna följande information för framtida referens:

Modellnummer: _________

•

Serienummer: _________

•

Inköpsdatum: _________

•

Innehåll

1 Komma igång

Visa den elektroniska användarhandboken...........27

Kamerans ovansida och baksida ..........................28

Kamerans framsida, sida och undersida................29

2 Göra i ordning kameran

Sätta i batterier.......................................................31

Slå på kameran......................................................32

Välja språk..............................................................32

Ställa in region........................................................32

Ställa in datum och tid............................................32

Installera och formatera ett minneskort

(tillval).....................................................................33

Installera programvaran.........................................34

Windows...........................................................35

Macintosh.........................................................35

3 Ta bilder och spela in videoklipp

Ta en bild................................................................36

Spela in ett videoklipp............................................36

4 Granska och ta bort bilder och videoklipp

Granska bilder och videoklipp................................38

Radera en bild........................................................38

5 Överföra och skriva ut bilder

Överföra bilder........................................................39

Skriva ut bilder från kameran.................................39

6 Snabbgenomgång av kameran...........................41

Svenska

1 Komma igång

Den här snabbintroduktionen innehåller all information du behöver för att komma i gång med kamerans grundfunktioner. Detaljerad information om kamerans funktioner finns i den elektroniska användarhandboken (se Visa den elektroniska användarhandboken på sidan 27).

Snabbintroduktion

Med snabbintroduktionen kan du göra följande:

• Snabbt komma i gång

Svenska

och använda kameran

• Installera HP Photosmartprogramvaran

• Lära dig kamerans grundläggande funktioner

26 HP Photosmart Mz60-serien digitalkamera

Elektronisk användarhandbok

Användarhandboken innehåller följande:

• Beskrivningar av samtliga funktioner i kameran

• Batteriinformation, bl.a. följande:

• Förlänga batteriets

livstid

• Batterityper som

kan användas

• Beskrivning av

strömindikatorsymbolerna

• Support från HP

•Felsökning

• Kameraspecifikationer

Visa den elektroniska användarhandboken

Användarhandboken finns på HP Photosmart Software CD.

Så här visar du användarhandboken:

1. Mata in HP Photosmart Software CD i datorns cd-

enhet.

2. Klicka på View User Guide (Visa

användarhandboken) på huvudskärmen för installation.

Den elektroniska användarhandboken kopieras dessutom till datorn när du installerar HP Photosmartprogramvaran. Så här visar du den installerade användarhandboken på datorn:

• Windows: Öppna HP Lösningscenter och klicka på Hjälp och support.

• Macintosh: Öppna HP Device Manager och välj

Användarhandbok för kamera på menyn Information och inställningar.

Hjälp och support

•På www.hp.com hittar du tips och hjälpmedel för att använda kameran mer effektivt. Härifrån klickar du på Learn About: Digital Photography (endast på engelska).

• Om du vill ha produktsupport, inklusive uppdateringar av fast programvara, programvara och drivrutiner, besök www.hp.com/support.

• Hjälp med HP Photosmart-programvaran hittar du i programhjälpen på datorn.

Svenska

Komma igång 27

Kamerans ovansida och baksida

321

4 5 6

Svenska

1 Strömlampa. 2 -knapp. 3 Slutarknapp. 4

Radera-knapp — ger tillgång till funktionen

Radera i

5 Blixt-knapp — används för att nå

blixtinställningarna i läget Inställningarna är Auto, Röda ögon, Blixt på och Blixt av.

6 -väljare — används för att växla mellan

Bildtagning, Videoinspelning och

28 HP Photosmart Mz60-serien digitalkamera

Uppspelning.

11 10

Bildtagning.

Uppspelning (se Bildtagning, Videoinspelning

och Uppspelning på sidan 41).

Zoom-reglage — ger tillgång till / Zoomfunktionen i

Videoinspelning och knapparna Miniatyrer och Förstora i Uppspelning.

9 USB-anslutning. 10

11 Tillbaka-knapp — används för att återgå till

12 Bildskärm.

- och -knappar — bläddrar genom menyer

och bilder.

-knapp — används för att visa kameramenyer,

välja alternativ och bekräfta åtgärder.

föregående meny eller vy. Du kan lämna alla menyer genom att trycka in och hålla kvar denna knapp.

Bildtagning eller

Kamerans framsida, sida och undersida

Svenska

1 Blixt.

Komma igång 29

2 Självutlösarlampa. 3 Mikrofon. 4 Stativfäste. 5 Batteri-/minneskortfack.

Svenska

30 HP Photosmart Mz60-serien digitalkamera

+ 106 hidden pages
