Hewlett Packard CF066A Getting Started Guide

Data sheet
HP LaserJet Enterprise 700 MFP M725 series
Ramp up your business efficiency and print in sizes up to A3 with ease.
Enable large-volume printing on a wide range of paper sizes – up to A3 – with a 4,600-sheet maximum input capacity.1Preview and edit scanning jobs; centrally manage printing policies; safeguard sensitive business information.
Empower teams to do more – print, scan, copy and fax1on paper sizes up to A3 – from a desktop MFP
Stay focused on work – paper capacity up to 4,600 sheets and high-capacity cartridges
limit interruptions.
Get impressive document quality with near edge-to-edge printing and a convenient,
built-in stapler.
Print what you need, even on the go – from your smartphone or tablet – using HP
ePrint4or Apple Airprint™.
2
3
5
Quicken your business pace.
Set a swift pace – use this powerful MFP to keep your work moving. Save time and make
your job easier, using HP Quick Sets.
Efficiently capture the right content: automatically remove blank pages, preview, edit and
control jobs on the large colour touchscreen.
Incorporate paper documents into digital workflows – easily send scans to fax6, email,
network folders or USB. Print right from a memory device via the USB port.
Simplify fleet management and safeguard devices using world-class tools.
Monitor your devices with industry-leading tools, including HP Web Jetadmin.7Help
protect data both in transit and at rest.
Enhance security with PIN printing. Add safeguards via the hardware integration pocket.
Integrate tomorrow's solutions with ease.
Add security tools – such as card and badge readers – via the hardware integration
pocket.
8
Reduce energy use with HP Auto-On/Auto-Off Technology9and HP Instant-on Technology.
Help conserve resources and meet corporate environmental goals. HP Auto-On/Auto-Off
Technology helps reduce energy use.
Easily recycle Original HP LaserJet toner cartridges through HP Planet Partners11.
Save paper and cut costs, using automatic two-sided printing.
10
9
7
1/6
Data sheet | HP LaserJet Enterprise 700 MFP M725 series
Product walkaround
HP LaserJet Enterprise 700 MFP M725z:
1. 100-sheet automatic document feeder
2. Intuitive 20.3 cm (8-inch) pivoting light touch SVGA colour control panel with FutureSmart firmware and scan preview
3. Hardware integration pocket for solution integration
4. Easy-access USB port to save and print files directly
5. In-line stapler/stackerfor stapling up to 30-pages and a 500-sheet output tray
6. Standard 250-sheet stacker output bin
7. Front door allows convenient access to print cartridge
8. Built-in automatic two-sided printing
9. 2 x 250-sheet input tray 2 and tray 3
10. 3,500-sheet high-capacity feeder with cabinet for a 4,100-sheet total input capacity
11. 100-sheet multipurpose tray 1 handles up to 100 pages
12. Fax port
13. 800 MHz processor,1 GB standard memory (Expandable to 1,5 GB)
14. HP High Performance Encrypted Hard Drive
15. Hi-Speed USB 2.0 printing port
16. HP Jetdirect Gigabit Ethernet print server
Series at a glance
Model
Product number
Features
Print speed
First page out (black/colour, A4)
Input capacity (standard/optional)
Output capacity
RMPV
ADF capacity
Paper trays (standard/maximum)
In-line stapler
Control panel
Memory (standard/maximum)
Networking
HP LaserJet Enterprise MFP
M725dn
CF066A CF067A CF068A CF069A
Print, copy, scan (fax optional) Print, copy, scan, fax Print, copy, scan, fax Print, copy, scan, fax
41 ppm, A4 41 ppm, A4 41 ppm, A4 41 ppm, A4
As fast as 10 seconds A4 As fast as 10 seconds A4 As fast as 10 seconds A4 As fast as 10 seconds A4
600/4600 1600 2100 4100/4600
250 250 750 750
5000/20,000 5000/20,000 5000/20,000 5000/20,000
100 100 100 100
3/6 5/5 6/6 4/5
N/A N/A 500-sheet 500-sheet
20.3 cm pivoting colour touchscreen control panel
1/1.5 GB 1/1.5 GB 1/1.5 GB 1/1.5 GB
Standard (built-in Gigabit Ethernet) Standard (built-in Gigabit Ethernet) Standard (built-in Gigabit Ethernet) Standard (built-in Gigabit Ethernet)
HP LaserJet Enterprise MFP M725f HP LaserJet Enterprise MFP M725z HP LaserJet Enterprise MFP
20.3 cm pivoting colour touchscreen control panel
20.3 cm pivoting colour touchscreen control panel
20.3 cm pivoting colour touchscreen
M725z+
control panel
2/6
Data sheet | HP LaserJet Enterprise 700 MFP M725 series
Accessories, Supplies and Support
Supplies
Accessories
Connectivity
Service and support
CF214A HP 14A Black Original LaserJet Toner Cartridge 10,000 pages
CF214X HP 14X High Yield Black Original LaserJet Toner Cartridge 17,500 pages CF254A HP LaserJet CF254A 220V Maintenance/Fuser Kit 200,000 pages C8091A HP Staple Cartridge Refill (5000 staples) for Stapler/Stacker accessories
CC487A HP LaserJet MFP Analog Fax Accessory 500 CF239A HP LaserJet 500-sheet Feeder and Tray CF242A HP LaserJet 3x500-sheet Feeder and Stand CF243A HP LaserJet 1x500-sheet Feeder with Cabinet and Stand CF245A HP LaserJet 3500-sheet High-capacity Input Tray Feeder and Stand L2718A HP 100 ADF Roller Replacement Kit J8021A HP Jetdirect ew2500 802.11b/g Wireless Print Server
J8026A HP Jetdirect 2700w USB Wireless Print Server U7A14E HP 3 year Next Business Day with Defective Media Retention LaserJet M725 MFP Hardware Support
U7A15E HP 4 year Next Business Day with Defective Media Retention LaserJet M725 MFP Hardware Support U7A16E HP 5 year Next Business Day with Defective Media Retention LaserJet M725 Multifunction Hardware Support U7A09E HP 3 year 4 hour 13x5 LaserJet M725 MFP Hardware Support U7Y76PE HP 1 year Post Warranty Next Business Day with Defective Media Retention LJ M725 MFP Support U7Y73PE HP 2 year Post Warranty Next Business Day LaserJet M725 MFP Hardware Support U7Y75PE HP 1 year Post Warranty 4 hour 13x5 LaserJet M725 MFP Hardware Support
Technical specifications
Model
Product number
Functions
Control panel
Print
Print technology
Print speed
First page out
Print resolution
Monthly duty cycle
Printer smart software features
Standard print languages
Fonts and typefaces
Print area
Duplex printing
Copy
Copy speed
Copier specifications
Scan
Scan speed
Scan file format
Scanner specifications
Scanner Advanced Features
1
2
3
HP LaserJet Enterprise MFP M725dn
HP LaserJet Enterprise MFP M725f
HP LaserJet Enterprise MFP M725z
HP LaserJet Enterprise MFP M725z+
CF066A CF067A CF068A CF069A
Print, copy, scan
Print, copy, scan, fax
20.3 cm touchscreen, LCD (colour graphics); rotating (adjustable angle) display; illuminated Home button (for quick return to the Home menu); Easy Access USB; Hardware Integration Pocket
Laser
Black (A4, normal): Up to 41 ppm; Black (A4, duplex): Up to 28 ipm; Black (A3, normal): Up to 20 ppm
Black (A4, ready): As fast as 10 sec
Black (best): Up to 1200 x 1200 dpi; Technology: HP ProRes 1200 (1200 x 1200 dpi), HP FastRes 1200 (1200 dpi quality), HP Resolution
Enhancement technology, 600 x 600 dpi, 300 x300 dpi Up to 200,000 pages (A4); Recommended monthly page volume: 5000 to 20,000
HP ePrint, Apple AirPrint, Mopria-certified, Open Extensibility Platform, FutureSmart Firmware, HP Auto-On/Auto-Off Technology, Easy Access USB, Image Preview
HP PCL 6, HP PCL 5, HP postscript level 3 emulation, PDF 1.4
105 internal TrueType fonts scalable in HP PCL, 92 internal scalable fonts in HP Postscript Level 3 emulation (Euro symbol built-in); 1 internal Unicode Fonts (Andale Mono WorldType); 2 Internal Windows Vista 8 Fonts (Calibri, Cambria); additional font solutions available via third-party flash memory cards; HP LaserJet Fonts and IPDS Emulation available at hp.com/go/laserjetfonts
Print margins: Top: 2 mm, Bottom: 2 mm, Left: 2 mm, Right: 2 mm; Maximum print area: 308 x 465.9 mm
Automatic (standard)
Black (A4): Up to 41 cpm
Sides; Collate; Paper Selection; Reduce/Enlarge; Image Adjustment; Content Orientation; Pages per sheet; Booklet format; Edge to Edge; Optimise Text/Picture; Original Size; Job Build; Maximum number of copies: Up to 9999 copies; Copy resolution: 600 x 600 dpi;
Reduce/Enlarge: 25 to 400%
Normal (A4): Up to 50 ppm (black and white), up to 30 ppm (colour); Duplex (A4): Up to 19 ipm (black and white), up to 14 ipm (colour)
PDF, JPEG, TIFF, MTIFF, XPS, PDF/A
Scanner type: Flatbed, ADF; Scan technology: Charge Coupled Device (CCD); Scan input modes: Copy, scan to E-mail, scan to network folder, scan to USB, save to device memory, fax, Open Extensibility Platform (OXP) applications; Duplex ADF scanning: Yes, reversing ADF; Scan size maximum (flatbed, ADF): 297 x 420 mm; Optical scan resolution: Up to 600 dpi
Optimise text/picture; Image adjustments; Job build; Output quality setting; Selectable scan resolution 75 to 600 dpi; Auto detect colour; Edge erase; Auto tone; Auto job notification; Blank page suppression; HP Quick Sets
3/6
Data sheet | HP LaserJet Enterprise 700 MFP M725 series
Model
Product number
Recommended monthly scan volume
Scannable area
Bit depth/ Grey scale levels
Digital sending
Fax
4
Fax
Processor speed Connectivity
Standard
Optional
Wireless
Mobile printing capability
Supported network protocols
Network ready
Hard disk
Memory Media handling
Number of paper trays
Media types
Media size
Media handling
HP LaserJet Enterprise MFP M725dn
HP LaserJet Enterprise MFP M725f
HP LaserJet Enterprise MFP M725z
HP LaserJet Enterprise MFP M725z+
CF066A CF067A CF068A CF069A
6,250 to 10,500
Maximum media size (flatbed): 297 x 420 mm; Minimum media size (ADF): 68 x 148 mm; Maximum media size (ADF): 297 x 420 mm
24-bit / 256
Standard: Scan to E-mail; Save to Network Folder; Save to USB drive; Send to FTP; Send to LAN Fax; Send to Internet Fax; Local Address Book; SMTP over SSL; Optional: Optional via HP Digital Sending Software (HP DSS); Send to folder; Send to workflow; Send to printer; Authentication; Digital fax (send to LAN, Internet); OCR; Local Address Book
Optional Yes, 33.6 kbps
800 MHz
2 Hi-Speed USB 2.0 Host; 1 Hi-Speed USB 2.0 Device; 1 Gigabit Ethernet 10/100/1000T network; 1 Foreign Interface; 1 Hardware Integration Pocket; 2 Internal USB Host
HP Jetdirect ew2500 802.11b/g Wireless Print ServerJ8021A; HP Jetdirect 2700w USB Wireless Print Server J8026A
Optional, enabled with purchase of a hardware accessory
HP ePrint; Apple AirPrint™; Mopria™-certified
IPv4/IPv6: Apple Bonjour Compatible (Mac OS v10.2.4 or higher), SNMPv1/v2c/v3, HTTP, HTTPS, FTP, TFTP, Port 9100, LPD, WS Discovery, IPP, Secure-IPP, XMPP, IPsec/Firewall; IPv6: DHCPv6, MLDv1, ICMPv6; IPv4: Auto-IP, SLP, Telnet, IGMPv2, BOOTP/DHCP, WINS, IP Direct Mode, WS Print
Standard (built-in Gigabit Ethernet)
Standard, embedded HP High-Performance Secure Hard Disk, minimum 320 GB; AES 256 hardware encryption or greater; Secure erase capabilities (Secure File Erase-Temporary Job Files, Secure Erase-Job Data, Secure ATA Erase-Disk)
Standard: 1 GB; Maximum : 1.5 GB
Standard: 3; Maximum: 6 Standard: 5; Maximum: 5 Standard: 6; Maximum: 6 Standard: 5; Maximum: 6
Paper (colour, letterhead, light, plain, preprinted, prepunched, recycled, rough, tough paper), bond, cardstock, envelope, labels, transparency, vellum
Custom (metric): Tray 1: 76.2 x 127 to 312 x 469.9 mm; Tray 2: 148 x 210 to 297 x 363 mm; Tray 3: 148 x 210 to 297 x 431 mm
Supported (metric): A3; A4; A5; B4 (JIS); B5 (JIS) ADF: A3; A4; A4-R; A5; A6; B4 (JIS); B5 (JIS); B6 (JIS); 10 x 15 cm; 13 x
18 cm
Custom (metric): Tray 1: 76.2 x 127 to 312 x 469.9 mm; Tray 2: 148 x 210 to 297 x 363 mm; Trays 3 - 6: 148 x 210 to 297 x 431 mm Supported (metric): A3; A4; A5; B4 (JIS); B5 (JIS) ADF: A3; A4; A4-R; A5; A6; B4 (JIS); B5 (JIS); B6 (JIS); 10 x 15 cm;
Custom (metric): Tray 1: 76.2 x 127 to 312 x 469.9 mm; Tray 2: 148 x 210 to 297 x 363 mm; Tray 3: 148 x 210 to 297 x 431 mm Supported (metric): A3; A4; A5; B4 (JIS); B5 (JIS) ADF: A3; A4; A4-R; A5; A6; B4 (JIS); B5 (JIS); B6 (JIS); 10 x 15 cm; 13 x 18 cm
13 x 18 cm
Standard input: 100-sheet multipurpose tray, two 250-sheet input trays Standard output: 250-sheet output bin Optional input: Optional 500-sheet input tray, optional 1 x 500-sheet paper feeder with cabinet and stand, optional 3 x 500-sheet paper feeder with
Standard input: 100-sheet multipurpose tray, two 250-sheet input trays, one 500-sheet feeder, and one 500-sheet feeder and stand Standard output: 250-sheet output bin
ADF: Standard, 100 sheets
Standard input: 100-sheet
multipurpose tray, two 250-sheet input trays and three 500-sheet feeders and stand Standard output: 250-sheet output bin, 500-sheet output bin
ADF: Standard, 100 sheets
Standard input: 100-sheet
multipurpose tray, two 250-sheet input trays and one 3500-sheet High-capacity Input Tray Feeder and Stand Standard output: 250-sheet output bin, 500-sheet output bin Optional input: Optional 500-sheet input tray
ADF: Standard, 100 sheets stand, optional 3500-sheet High-capacity Input Tray Feeder and Stand ADF: Standard, 100 sheets
4/6
Data sheet | HP LaserJet Enterprise 700 MFP M725 series
Model
Product number
Input capacity
Output capacity
Compatible operating systems
Minimum system requirements
Software included
Security management
Printer management
Dimensions and Weight
Printer dimensions (W x D x H)
Package dimensions (W x D x H)
Printer weight
Package weight
Operating environment
Storage
Acoustics
Power
Energy savings feature technology
Certifications
What's in the box
Warranty
HP LaserJet Enterprise MFP M725dn
HP LaserJet Enterprise MFP M725f
HP LaserJet Enterprise MFP M725z
HP LaserJet Enterprise MFP
M725z+
CF066A CF067A CF068A CF069A
Tray 1: sheets: 100; envelopes: 10; labels: 100; transparencies: 100; postcards: 10
Tray 2: sheets: 250 Tray 3: sheets: 250 Maximum: Up to 4600 sheets ADF: Standard, 100 sheets
Standard: Up to 250 sheets
Envelopes: Up to 50 envelopes Transparencies: Up to 250 sheets
Maximum: Up to 250 sheets
Tray 1: sheets: 100; envelopes:
10; labels: 100; transparencies: 100; postcards: 10
Tray 2: sheets: 250 Tray 3: Tray 3: sheets: 250; Tray
4: sheets: 500; Tray 5: sheets: 500
Maximum: Up to 1600 sheets ADF: Standard, 100 sheets
Tray 1: sheets: 100; envelopes:
10; labels: 100; transparencies: 100; postcards: 10
Tray 2: sheets: 250 Tray 3: Tray 3: sheets: 250; Tray
4: sheets: 500; Tray 5: sheets: 500; Tray 6: sheets: 500
Maximum: Up to 2100 sheets ADF: Standard, 100 sheets
Standard: Up to 750 sheets
Envelopes: Up to 50 envelopes Transparencies: Up to 750 sheets
Maximum: Up to 750 sheets
Tray 1: sheets: 100; envelopes:
10; labels: 100; transparencies:
100; postcards: 10
Tray 2: sheets: 250
Tray 3: Tray 3: sheets: 250; Tray
4: sheets: 1500; Tray 5: sheets:
2000
Maximum: Up to 4600 sheets
ADF: Standard, 100 sheets
Windows 10, Windows 8, Windows 7, Windows Vista, Windows Server 2012 (64-bit), Windows Server 2008 (32-bit/64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2003 (SP1+); Mac OS X v10.6, OS X Lion, OS X Mountain Lion; For the latest operating system support see: Citrix and Windows TerminalServices (http://www.hp.com/go/upd), Novell (http://www.novell.com/iprint), Linux (http://www.hplip.net), UNIX (http://www.hp.com/go/unix, http://www.hp.com/go/unixmodelscripts, http://www.hp.com/go/jetdirectunix_software), SAP device types (http://www.hp.com/go/sap/drivers, http://www.hp.com/go/sap/print), HP ePrint Mobile Driver (http://www.hp.com/go/eprintmobiledriver)
Windows: Windows 10, Windows 8, Windows 7, Windows Vista, Windows Server 2012 (64-bit), Windows Server 2008, Windows Server 2008 R2, Windows Server 2003 (SP1+): 200 MB available hard disk space (for OS compatible hardware system requirements, see http://www.microsoft.com); Mac: Mac OS X 10.6, OS X Lion, OS X Mountain Lion; 1 GB available hard disk space; operating system compatible hardware system requirements, CD-ROM/DVD-ROM or Internet, see apple.com
Windows Installer, HP PCL 6 discrete driver, Mac Software Link to Web (Postscript emulation driver & Installer on Web), Note: No Mac Software inbox
Management security: SNMPv3, SSL/TLS, WPA2-Enterprise, 802.1X authentication (EAP- PEAP, EAP-TLS), IPP over TLS, IPsec/Firewall with Certificate, Pre-Shared Key Authentication, and Kerberos Authentication; Support for WJA-10 IPsec Configuration using IPsec Plug-in
HP Web Jetadmin, HP Utility (Mac)
Minimum: 614 x 649 x 609 mm; Maximum: 865 x 989 x 609 mm
Minimum: 745 x 681 x 1160 mm; Maximum: 917 x 1032 x 1160
Minimum: 745 x 681 x 1192 mm; Maximum: 917 x 1032 x 1192 mm
mm
760 x 745 x 832 mm 856 x 760 x 1522 mm 856 x 760 x 1553 mm
54.11 kg 87.1 kg 92.35 kg 102.42 kg
68.6 kg 105.4 kg 113 kg 122 kg
Temperature: 10 to 32.5ºC; Humidity: 30 to 70% RH
Temperature: 0 to 60ºC; Humidity: 10 to 90% RH
Acoustic power emissions: 6.8 B(A); Acoustic pressure emissions: 54 dB(A)
Requirements: Input voltage: 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz); Consumption: 890 watts (active print/copy), 39 watts (ready), 6.5
watts (sleep), 0.3 watts (off). Typical Electricity Consumption (TEC): 4.39 kWh/Week; Typical Electricity Consumption (TEC): 3.31 kWh/Week (110/220 V); 2.8 kWh/Week (Blue Angel); Power supply type: Built-in power supply
HP Auto-On/Auto-Off Technology; Instant-on Technology
CISPR 22:2008 / EN 55022:2010 (Class A); EN 61000-3-2 :2006 +A1:2009 +A2:2009; EN 61000-3-3 :2008; EN 55024:1998+A1+A2; EMC Directive 2004/108/EC with CE Marking (Europe); other EMC approvals as required by individual countries ENERGY STAR® qualified
HP LaserJet Enterprise MFP M725dn; HP Black LaserJet Toner Cartridge (~10,000 pages); Printer documentation and software on CD-ROM; Installation guide, Support flyer, Warranty card; Power cord; 2x250-sheet trays.
HP LaserJet Enterprise MFP M725f; HP Black LaserJet Toner Cartridge (~10,000 pages); Printer documentation and software on CD-ROM; Installation guide, Support flyer, Warranty card; Power cord; Fax cable; 2x250-sheet trays; 1x500 sheet feeder; cabinet and stand; Built-in fax.
HP LaserJet Enterprise MFP M725z; HP Black LaserJet Toner Cartridge (~10,000 pages); Printer documentation and software on CD-ROM; Installation guide, Support flyer, Warranty card; Power cord; Fax cable; 2x250-sheet trays; 3x500-sheet Paper feeder and stand; 500-sheet inline Stapler/Stacker; Built-in fax.
HP LaserJet Enterprise MFP
M725z+; HP Black LaserJet Toner
Cartridge (~10,000 pages); Printer
documentation and software on
CD-ROM; Installation guide,
Support flyer, Warranty card;
Power cord; Fax cable;
2x250-sheet trays; 1 x
3500-sheet Feeder and Stand;
500-sheet inline Stapler/Stacker;
Built-in fax. One-year, next-business day, onsite warranty. Warranty and support options vary by product, country and local legal requirements. Go to
http://www.hp.com/support to learn about HP award winning service and support options in your region.
5/6
Data sheet | HP LaserJet Enterprise 700 MFP M725 series
Footnotes
1
Maximum paper capacity of 4,600 sheets; requires the purchase of optional paper tray accessories.
2
High-capacity cartridges are optional for the HP LaserJet Enterprise 700 MFP Series M725.
3
In-line stapler is not available on the HP LaserJet Enterprise MFP M725dn or M725f.
4
Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hpconnected.com). Mobile devices require Internet connection and email capability. May require wireless access point. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary. Some HP LaserJet printers may require firmware upgrades.
5
Supports the following devices running iOS 4.2 or later: iPad®, iPad® 2, iPhone® (3GS or later) or iPod touch® (3rd generation or later). Works with HP's AirPrint-enabled printers and requires the printer be connected to the same network as your iOS device. Wireless performance is dependent upon physical environment and distance from the access point. AirPrint, the AirPrint Logo, iPad, iPhone and iPod touch are trademarks of Apple® Inc., registered in the U.S. and other countries.times and connection speeds may vary. Some HP LaserJet printers may require firmware upgrades.
6
Fax capabilities are available with an optional fax card on the HP LaserJet Enterprise MFP M725dn.
7
HP Web Jetadmin is free and can be downloaded at www.hp.com/go/webjetadmin.
8
Solutions deployed through the hardware integration pocket may require additional purchase.
9
HP Auto-On/Auto-Off Technology capabilities subject to printer and settings; may require a firmware upgrade.
10
Compared with products that use traditional fusing.
11
Programme availability varies. Original HP cartridge return and recycling is currentlyavailable in more than 50 countries, territories and regions in Asia, Europe, and North and South America through the HP Planet Partners
programme. For more information, visit: www.hp.com/recycle.
Technicalspecifications disclaimers
1
Measured using ISO/IEC 24734, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
2
Exact speed varies depending on the system configuration, software application, driver and document complexity.
3
Actual speeds may vary depending on scan resolution, network conditions, computer performance and application software.
4
Based on standard ITU-T test image at standard resolution. More complicated pages or higher resolution will take longer and use more memory.
http://www.hp.com/uk
The product could differ from the images shown. © Copyright 2017 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanyingsuch products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Published in EMEA 4AA4-5715EEE, November 2017
AD
6/6
Loading...
