Hewlett Packard C6019B Product Data Sheet

HP Coated Paper

HP Designjet printing system
The complete solution

o

HP Coated Paper

HP Coated Paper is perfect for color-accurate every­day prints, working comps and design proofs. This
premium bright white paper offers excellent handle­ability enabling technical professionals to roll or
stack time-sensitive documents as soon as they
come off the printers.

Target customers

• CAD

• AEC

•GIS

• Graphic artists and Designers

• Print service providers

HP Designjet

printers

Image quality

Consistency

Performance

Durability

Value

HP Designjet

ink supplies

Applications

• Posters and Presentations

• POP and Retail Displays

• Geographic Information Systems (GIS)

• Architecture (AEC) and Engineering
(CAD)

Benefits

• Perfect prints every time

• Excellent handleability

• Dye and pigment ink compatible

• Metric-sized media[1]

HP large format

printing material

hh

Printer/ink compatibility

Printer Ink Front panel setting

Designjet 1050c/1055cm/1050c Plus/1055cm Plus HP 80 Coated Paper
Designjet 110 HP 10, HP 11 Coated Paper
Designjet 110plus HP 10, HP 11 Coated Paper
Designjet 120 HP 11, HP 82, HP 84 Coated Paper
Designjet 130 HP 84, HP 85 Coated Paper
Designjet 2800cp/2500cp/2000cp HP CP dye Coated Paper
Designjet 3800cp/3500cp/3000cp HP CP dye Coated Paper
Designjet 4000/4000ps HP 90 Coated Paper
Designjet 430/330 HP 40 Coated Paper
Designjet 4500/4500ps/4500mfp/4500 Scanner HP 90
Designjet 488ca/450c/455ca/350c HP 40, HP 44 Coated Paper
Designjet 500 Mono HP 10
Designjet 500/500 Plus/500ps/500ps Plus HP 10, HP 82 Coated Paper
Designjet 5000/5000ps HP 81 dye, HP 83 uv Coated Paper
Designjet 5500/5500ps HP 81 dye, HP 83 uv Coated Paper
Designjet 700 HP 45 Coated Paper
Designjet 750c/750c plus/755cm HP 44, HP 45 Coated Paper
Designjet 800/800ps/cc800ps/815mfp/820 MFP HP 10, HP 82 Coated Paper
Designjet T1100/T1100ps/T1100 MFP/T610 HP 72 Vivera
Designjet Z2100/Z3100 HP 70 Vivera pigment
Designjet Z6100/Z6100ps HP 91 Vivera pigment

For the latest ICC/Media profiles, please visit www.hp.com/go/designjet/supplies/support (click on the ICC profiles and select your printer). For non-Post Script printers see your
external RIP Vendor.

Product specifications

Property Value and test method

Grammage 90 g/m2
Basis Weight 26 lb
Thickness/caliper 5 mil
Core size 2 in (50.8 mm)
CIE whiteness 143 per CIE Ganz 82 Test Method
Brightness 89
Opacity 93% per TAPPI T-425 Test Method
Finish Matte per ASTM D-523 Test Method
Country of Origin Product of Germany
Waterfastness Lamination required

Image permanence

Dye Pigment

Fade resistance (indoor)+ 1+ years with HP 72 Vivera inks[1a]
Fade resistance (commercial window)
Fade resistance (outdoor)

+ For the ’Indoor’ category, test results were achieved under glass unless otherwise indicated. [1a]Indoor, Display permanence rating by HP Image Permanence Lab for interior dis­plays away from direct sunlight without lamination or protection behind glass.

Operating specifications

Operating temperature 15 to 35 ° C (59 to 95 ° F)
Operating humidity 20 to 80% RH
Dry time Immediate (@ 23°C, 50% RH)
Shelf life 2 years, unopened in original packaging

Warranty Statement

Technical information contained in this document is subject to change without notice. © Copyright 2007 Hewlett-Packard
Development Company, L.P. Hewlett-Packard large-format printing materials are guaranteed to meet HP published specifications,
to be free of manufacturing flaws and defects, and are designed to resist paper jams when used correctly. If you are not satisfied
with this product for any reason, please visit www.hp.com/go/designjet/supplies, and select HP product support center to locate
product support in your region.

For information on similar products, please visit HP Designjet
Supplies at http://www.hp.com/go/designjet/supplies

Last revised: 11/2007
