HP 7 Plus G2 Tablet
Maintenance and Service Guide
IMPORTANT! This document is intended for
HP authorized service providers only.
Page 2
© Copyright 2014 Hewlett-Packard
Development Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. SD Logo is a
trademark of its proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: September 2014
Document Part Number: 786902-001
Product notice
This guide describes features that are
common to most models. Some features
may not be available on your tablet.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this tablet, you agree to be
bound by the terms of the HP End User
License Agreement (EULA). If you do not
accept these license terms, your sole
remedy is to return the entire unused
product (hardware and software) within 14
days for a refund subject to the refund
policy of your place of purchase.
For any further information or to request a
full refund of the tablet, please contact your
local point of sale (the seller).
Page 3
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not
place the device directly on your lap or obstruct the device air vents. Use the device only on a hard,
flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The device
and the AC adapter comply with the user-accessible surface temperature limits defined by
the International Standard for Safety of Information Technology Equipment (IEC 60950).
iii
Page 4
iv Safety warning notice
Page 5
Table of contents
1 Product description ........................................................................................................................................... 1
2 External component identification ..................................................................................................................... 2
3 Illustrated parts catalog ..................................................................................................................................... 4
Locating the product number and serial number .................................................................................. 4
Tablet major components ..................................................................................................................... 5
Miscellaneous parts .............................................................................................................................. 6
Sequential part number listing .............................................................................................................. 6
4 Removal and replacement preliminary requirements ....................................................................................... 8
Tools required ...................................................................................................................................... 8
Service considerations ......................................................................................................................... 8
Plastic parts ......................................................................................................................... 8
Cables and connectors ........................................................................................................ 8
Grounding guidelines ........................................................................................................................... 9
Electrostatic discharge damage ........................................................................................... 9
Packaging and transporting guidelines ............................................................. 10
Workstation guidelines ..................................................................... 10
5 Removal and replacement procedures ........................................................................................................... 12
Tablet component replacement procedures ....................................................................................... 12
Back cover .......................................................................................................................................... 12
Battery ................................................................................................................................................ 14
Antenna .............................................................................................................................................. 16
Speaker .............................................................................................................................................. 17
Rear-facing webcam .......................................................................................................................... 19
Microphone ......................................................................................................................................... 20
Connector board ................................................................................................................................. 21
System board ..................................................................................................................................... 22
Front-facing webcam .......................................................................................................................... 24
6 Specifications .................................................................................................................................................. 26
v
Page 6
7 Power cord set requirements .......................................................................................................................... 27
Requirements for all countries ............................................................................................................ 27
Requirements for specific countries and regions ............................................................................... 27
8 Recycling ........................................................................................................................................................ 29
Index ................................................................................................................................................................... 30
vi
Page 7
1 Product description
Category Description
Product Name HP 7 Plus G2 Tablet
Processor Intel® Z2520 1.20-GHz dual core processor
Panel 7.0-in [1024×600], AG, IPS, LED, multi-touch, wide-viewing angle, 5-point capacitive,
auto-rotate [selectable], tempered-glass, backlit, TouchScreen display panel
Memory Supports 1.0-GB DDR
Mass storage Supports 8.0- or 16.0-GB eMMC solid-state drives
Audio and video One microphone
One speaker
2.0-MP, fixed-focus, HD, rear-facing webcamera
0.3-MP, fixed-focus, VGA front-facing webcamera
Sensor Accelerometer
G-sensor
GPS
Wireless networking WLAN: 802.11 b/g/n, Miracast compatible
3G data (GSM): 900-/1800- or 850-/1900-MHz
WCDMA: 900-/2100- or 850-/1900M-Hz)
Bluetooth: 4.0, WAPI
External expansion Integrated micro SD Card Reader expandable to 64-GB
Ports
Power requirements Support for 3100-mAhr, USB charging (non-removable)
Operating system Preinstalled: Android 4.4.2
Serviceability End user replaceable part: AC adapter and USB cable
Audio: headphone/microphone combo jack
●
Micro SD Card Reader
●
Micro USB
●
Support for 5-V / 1-A AC adapter with DC plug and localized cable plug support
1
Page 8
2 External component identification
Item Component Item Component
(1) Rear-facing webcam (6) Power button
2 Chapter 2 External component identification
Page 9
Item Component Item Component
(2) Micro USB 2.0 port (7) Volume control buttons (2)
(3) Audio-out (headphone)/Audio-in
(microphone) jack
(4) Speaker (9) Micro SIM slot
(5) Front-facing webcam (10) Microphone
(8) Micro SD Card Reader slot
3
Page 10
3 Illustrated parts catalog
NOTE: HP continually improves and changes product parts. For complete and current information
on supported parts for your computer, go to http://partsurfer.hp.com, select your country or region,
and then follow the on-screen instructions.
Locating the product number and serial number
The tablet product number (1) and serial number (2) are located on the tablet back cover. This
information may be needed when travelling internationally or when contacting support.
4 Chapter 3 Illustrated parts catalog
Page 11
Tablet major components
Item Component Spare part number
(1) Back cover (includes antenna and power/volume button actuator) 790586-001
(2) Speaker (includes cables) 790591-001
(3) Audio jack light pipe
(4) Rear-facing webcam (2.0-MP, fixed-focus, HD; includes cable) 790595-001
(5) Front-facing webcam (0.3-MP, fixed-focus, VGA; includes cable and double-
sided adhesive)
(6) Battery (3100-mAh, USB-charging; includes cable and double-sided adhesive) 790587-001
(7) System board equipped with an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem with UMA
memory, and 1.0-GB of system memory
Equipped with a 16-GB eMMC hard drive 790593-001
Equipped with a 8-GB eMMC hard drive 790592-001
(8) Connector board (includes SD Card reader slot, SIM slot, and cable) 790596-001
(9) Microphone (includes cable) 790597-001
(10) Antenna (included in the Antenna Kit, spare part number 790600-001. Includes the antenna transceiver, cable,
and double-sided adhesive.)
(11) Display panel assembly (7.0-in [1024×600], AG, IPS, LED, multi-touch, wide-viewing
angle, 5-point capacitive, auto-rotate [selectable], tempered-glass, backlit,
TouchScreen; includes display panel cable and TouchScreen cable)
790594-001
790589-001
Tablet major components 5
Page 12
Miscellaneous parts
Component Spare part number
5-V / 1-A AC adapter:
For use in Asia/Pacific countries and regions 791731-004
For use in Europe 791731-009
For use in Latin America 791731-007
For use in North America 791731-008
For use in the United Kingdom 791731-003
Cable Kit 745159-001
HP 7 Plus G2 Tablet equipped with a 7.0-in (1024×600), AG, IPS, LED, multi-touch, wide-viewing angle, 5-point capacitive,
auto-rotate (selectable), tempered-glass, backlit, TouchScreen display panel, an Intel Z2520 1.20-GHz dual core processor,
a graphics subsystem with UMA memory, and 1.0-GB of system memory
Equipped with a 16-GB eMMC hard drive for use in Europe, the Middle East, and Africa 790616-021
Equipped with a 16-GB eMMC hard drive for use in North America 790616-001
Equipped with a 8-GB eMMC hard drive for use in Europe, the Middle East, and Africa 790601-021
Equipped with a 8-GB eMMC hard drive for use in North America 790601-001
Plastics Kit 790599-001
Rubber Kit (includes rear-facing webcam rubber lens cover) 790598-001
Screw Kit 790590-001
USB extension cable 791929-001
Sequential part number listing
Spare part number Description
790586-001 Back cover (includes antenna and power/volume button actuator)
790587-001 Battery (3100-mAh, USB-charging; includes cable and double-sided adhesive)
790588-001 Cable Kit
790589-001 Display panel assembly (7.0-in [1024×600], AG, IPS, LED, multi-touch, wide-viewing angle, 5-
point capacitive, auto-rotate [selectable], tempered-glass, backlit, TouchScreen; includes display
panel cable and TouchScreen cable)
790590-001 Screw Kit
790591-001 Speaker (includes cables)
790592-001 System board equipped with an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem
with UMA memory, 1.0-GB of system memory, and a 8-GB eMMC hard drive
790593-001 System board equipped with an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem
with UMA memory, 1.0-GB of system memory, and a 16-GB eMMC hard drive
790594-001 Front-facing webcam (0.3-MP, fixed-focus, VGA; includes cable and double-sided adhesive)
6 Chapter 3 Illustrated parts catalog
Page 13
Spare part number Description
790595-001 Rear-facing webcam (2.0-MP, fixed-focus, HD; includes cable)
790596-001 Connector board (includes SD Card reader slot, SIM slot, and cable)
790597-001 Microphone (includes cable)
790598-001 Rubber Kit (includes rear-facing webcam rubber lens cover)
790599-001 Plastics Kit
790600-001 Antenna Kit (includes the antenna transceiver, cable, and double-sided adhesive)
790601-001 HP 7 Plus G2 Tablet equipped with a 7.0-in (1024×600), AG, IPS, LED, multi-touch, wide-viewing
angle, 5-point capacitive, auto-rotate (selectable), tempered-glass, backlit, TouchScreen display
panel, an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem with UMA memory,
1.0-GB of system memory, and a 8-GB eMMC hard drive for use in North America
790601-021 HP 7 Plus G2 Tablet equipped with a 7.0-in (1024×600), AG, IPS, LED, multi-touch, wide-viewing
angle, 5-point capacitive, auto-rotate (selectable), tempered-glass, backlit, TouchScreen display
panel, an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem with UMA memory,
1.0-GB of system memory, and a 8-GB eMMC hard drive for use in Europe, the Middle East,
and Africa
790616-001 HP 7 Plus G2 Tablet equipped with a 7.0-in (1024×600), AG, IPS, LED, multi-touch, wide-viewing
angle, 5-point capacitive, auto-rotate (selectable), tempered-glass, backlit, TouchScreen display
panel, an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem with UMA memory,
1.0-GB of system memory, and a 16-GB eMMC hard drive for use in North America
790616-021 HP 7 Plus G2 Tablet equipped with a 7.0-in (1024×600), AG, IPS, LED, multi-touch, wide-viewing
angle, 5-point capacitive, auto-rotate (selectable), tempered-glass, backlit, TouchScreen display
panel, an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem with UMA memory,
1.0-GB of system memory, and a 16-GB eMMC hard drive for use in Europe, the Middle East,
and Africa
791731-003 5-V / 1-A AC adapter for use only in the United Kingdom
791731-004 5-V / 1-A AC adapter for use only in Asia/Pacific countries and regions
791731-007 5-V / 1-A AC adapter for use only in Latin America
791731-008 5-V / 1-A AC adapter for use only in North America
791731-009 5-V / 1-A AC adapter for use only in Europe
791929-001 USB extension cable
Sequential part number listing 7
Page 14
4 Removal and replacement preliminary
requirements
Tools required
You will need the following tools to complete the removal and replacement procedures:
Magnetic screw driver
●
Phillips P0 screw driver
●
Plastic case utility tool
●
Service considerations
The following sections include some of the considerations that you must keep in mind during
disassembly and assembly procedures.
NOTE: As you remove each subassembly from the tablet, place the subassembly (and all
accompanying screws) away from the work area to prevent damage.
Plastic parts
CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts.
Use care when handling the plastic parts. Apply pressure only at the points designated in the
maintenance instructions.
Cables and connectors
CAUTION: When servicing the tablet, be sure that cables are placed in their proper locations during
the reassembly process. Improper cable placement can damage the tablet.
Cables must be handled with extreme care to avoid damage. Apply only the tension required to
unseat or seat the cables during removal and insertion. Handle cables by the connector whenever
possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in
such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex
cables with extreme care; these cables tear easily.
8 Chapter 4 Removal and replacement preliminary requirements
Page 15
Grounding guidelines
Electrostatic discharge damage
Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure
determine the degree of sensitivity. Networks built into many integrated circuits provide some
protection, but in many cases, ESD contains enough power to alter device parameters or melt
silicon junctions.
A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.
An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a
normal cycle. Or the device may function normally for a while, then degrade in the internal layers,
reducing its life expectancy.
CAUTION: To prevent damage to the tablet when you are removing or installing internal
components, observe these precautions:
Keep components in their electrostatic-safe containers until you are ready to install them.
Before touching an electronic component, discharge static electricity by using the guidelines
described in this section.
Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.
If you remove a component, place it in an electrostatic-safe container.
The following table shows how humidity affects the electrostatic voltage levels generated by
different activities.
CAUTION: A product can be degraded by as little as 700 V.
Typical electrostatic voltage levels
Relative humidity
Event 10% 40% 55%
Walking across carpet 35,000 V 15,000 V 7,500 V
Walking across vinyl floor 12,000 V 5,000 V 3,000 V
Motions of bench worker 6,000 V 800 V 400 V
Removing DIPS from plastic tube 2,000 V 700 V 400 V
Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V
Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V
Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V
Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V
Grounding guidelines 9
Page 16
Packaging and transporting guidelines
Follow these grounding guidelines when packaging and transporting equipment:
To avoid hand contact, transport products in static-safe tubes, bags, or boxes.
●
Protect ESD-sensitive parts and assemblies with conductive or approved containers or
●
packaging.
Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
●
Place items on a grounded surface before removing items from their containers.
●
Always be properly grounded when touching a component or assembly.
●
Store reusable ESD-sensitive parts from assemblies in protective packaging or
●
nonconductive foam.
Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that
●
mechanized equipment used for moving materials is wired to ground and that proper materials
are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate
electric charges.
Workstation guidelines
Follow these grounding workstation guidelines:
Cover the workstation with approved static-shielding material.
●
Use a wrist strap connected to a properly grounded work surface and use properly grounded
●
tools and equipment.
Use conductive field service tools, such as cutters, screw drivers, and vacuums.
●
When fixtures must directly contact dissipative surfaces, use fixtures made only of static-
●
safe materials.
Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids
●
and Styrofoam.
Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle
●
these items only at static-free workstations.
Avoid contact with pins, leads, or circuitry.
●
Turn off power and input signals before inserting or removing connectors or test equipment.
●
10 Chapter 4 Removal and replacement preliminary requirements
Page 17
Equipment guidelines
Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.
When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible
●
straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper
ground, wear a strap snugly against the skin at all times. On grounded mats with banana-plug
connectors, use alligator clips to connect a wrist strap.
When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps)
●
can be used at standing workstations and are compatible with most types of shoes or boots. On
conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one
megohm resistance between the operator and ground. To be effective, the conductive must be
worn in contact with the skin.
The following grounding equipment is recommended to prevent electrostatic damage:
Antistatic tape
●
Antistatic smocks, aprons, and sleeve protectors
●
Conductive bins and other assembly or soldering aids
●
Nonconductive foam
●
Conductive tabletop workstations with ground cords of one megohm resistance
●
Static-dissipative tables or floor mats with hard ties to the ground
●
Field service kits
●
Static awareness labels
●
Material-handling packages
●
Nonconductive plastic bags, tubes, or boxes
●
Metal tote boxes
●
Electrostatic voltage levels and protective materials
●
The following table lists the shielding protection provided by antistatic bags and floor mats.
Material Use Voltage protection level
Antistatic plastics Bags 1,500 V
Carbon-loaded plastic Floor mats 7,500 V
Metallized laminate Floor mats 5,000 V
Grounding guidelines 11
Page 18
5 Removal and replacement procedures
NOTE: HP continually improves and changes product parts. For complete and current information
on supported parts for your computer, go to http://partsurfer.hp.com, select your country or region,
and then follow the on-screen instructions.
Tablet component replacement procedures
CAUTION: Tablet components described in this chapter should only be accessed by an
authorized service provider. Accessing these parts can damage the tablet and void the warranty.
This chapter provides removal and replacement procedures for authorized service provider
only parts.
There are as many as [] screws that must be removed, replaced, and/or loosened when servicing the
tablet. Make special note of each screw size and location during removal and replacement.
Back cover
Description Spare part number
Back cover (includes antenna and power/volume button actuator) 790586-001
Display panel assembly (7.0-in [1024×600], AG, IPS, LED, multi-touch, wide-viewing angle, 5point capacitive, auto-rotate [selectable], tempered-glass, backlit, TouchScreen; includes display
panel cable and TouchScreen cable)
Before disassembling the tablet, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
Remove the back cover:
CAUTION: Before turning the display panel assembly upside down, make sure the work surface is
clear of tools, screws, and any other foreign objects. Failure to follow this caution can result in
damage to the display panel assembly.
1. Place the tablet on a flat surface, display panel side down, with the power button toward you.
CAUTION: When inserting the plastic tool into the tablet as described in Step 2, make sure not
to insert the tool into the volume control buttons area. Failure to follow this caution can result in
damage to the tablet.
2. Insert a thin, plastic tool (1) between the back cover and the display panel assembly. The first
insertion point should be near the bottom edge of the tablet.
790589-001
3. Lift the bottom edge of the back cover (2) until it separates from the display panel assembly.
12 Chapter 5 Removal and replacement procedures
Page 19
4. Remove the back cover (3).
NOTE: If the volume button actuator (1) and power button actuator (2) should become
displaced during the removal of the back cover, install the actuator into the openings in the back
cover as indicated in the following illustration.
The actuators are included in the back cover spare part kit.
Back cover 13
Page 20
Reverse this procedure to install the back cover.
Battery
Before removing the battery, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
WARNING! To reduce potential safety issues, use only the battery provided with the tablet, a
replacement battery provided by HP, or a compatible battery purchased from HP.
CAUTION: Removing a battery that is the sole power source for the tablet can cause loss of
information. To prevent loss of information, save your work or shut down the tablet through Windows
before removing the battery.
Description Spare part number
Battery (3100-mAh, USB-charging; includes cable and double-sided adhesive) 790587-001
and then shut it down through the operating system.
Remove the battery:
1. Disconnect the battery cable (1) from the system board.
2. Release the battery cable from the retention clip (2) built into the display panel assembly.
3. Insert a thin, plastic tool (3) between the battery and the display panel assembly.
4. Detach the battery (4) from the display panel assembly. (The battery is attached to the display
panel assembly with double-sided adhesive.)
14 Chapter 5 Removal and replacement procedures
Page 21
5. Remove the battery (5).
Reverse this procedure to install the battery.
Battery 15
Page 22
Antenna
Description Spare part number
Antenna (included in the Antenna Kit, spare part number 790600-001. Includes the antenna transceiver, cable, and doublesided adhesive.)
Before removing the antenna, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
5. Disconnect the battery cable from the system board (see Battery on page 14).
Remove the antenna board:
1. Disconnect the antenna cable from the connector board antenna terminal (1).
2. Release the antenna cable from the retention clips (2) and routing channel built into the display
and then shut it down through the operating system.
panel assembly.
3. Remove the two Phillips PM1.4×3.6 screws (3) that secure the antenna transceiver to the
display panel assembly.
4. Detach the antenna transceiver (4) from the display panel assembly. (The antenna transceiver is
attached to the display panel assembly with double-sided adhesive.)
16 Chapter 5 Removal and replacement procedures
Page 23
5. Remove the antenna transceiver (5) and cable.
6. Remove the antenna board and cables.
Reverse this procedure to install the antenna board.
Speaker
Description Spare part number
Speaker (includes cables) 790591-001
Before removing the speaker, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
5. Disconnect the battery cable from the system board (see Battery on page 14).
Remove the speaker:
and then shut it down through the operating system.
Speaker 17
Page 24
1. Unsolder the red and black speaker cables (1) from the system board speaker contact points.
NOTE: When installing the speaker, the red speaker cable should be soldered to the system
board speaker “positive” terminal. The black speaker cable should be soldered to the system
board speaker “negative” terminal.
2. Release the speaker cables from the retention clips (2) built into the speaker.
3. Remove the two Phillips PM1.4×3.6 screws (3) that secure the speaker to the
display panel assembly.
4. Remove the speaker (4).
Reverse this procedure to install the speaker.
18 Chapter 5 Removal and replacement procedures
Page 25
Rear-facing webcam
Description Spare part number
Rear-facing webcam (2.0-MP, fixed-focus, HD; includes cable) 790595-001
Before removing the rear-facing webcam, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
5. Disconnect the battery cable from the system board (see Battery on page 14).
Remove the rear-facing webcam:
1. Disconnect the rear-facing webcam cable (1) from the system board.
2. Remove the rear-facing webcam (2) and cable from the molding built into the display
panel assembly.
NOTE: If the rear-facing webcam rubber lens cover (3) should become lost or damaged when
removing the rear-facing webcam, a replacement cover is available in the Rubber Kit, spare part
number 790598-001.
Reverse this procedure to install the rear-facing webcam.
Rear-facing webcam 19
Page 26
Microphone
Description Spare part number
Microphone (includes cable) 790597-001
Before removing the microphone, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
5. Disconnect the battery cable from the system board (see Battery on page 14).
Remove the microphone:
1. Unsolder the red and black microphone cables (1) from the system board microphone
contact points.
NOTE: When installing the microphone, the red microphone cable should be soldered to the
system board microphone “positive” terminal. The black microphone cable should be soldered to
the system board microphone “negative” terminal.
2. Release the microphone (2) from the molding built into display panel assembly.
3. Remove the microphone and cable.
20 Chapter 5 Removal and replacement procedures
Page 27
Reverse this procedure to install the microphone.
Connector board
Description Spare part number
Connector board (includes SD Card reader slot, SIM slot, and cable) 790596-001
Before removing the connector board, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
5. Disconnect the battery cable from the system board (see Battery on page 14).
Remove the connector board:
1. Disconnect the antenna cable from the connector board antenna terminal (1).
2. Release the microphone (2) from the molding built into display panel assembly.
3. Disconnect the connector board cable (3) from the system board.
4. Release the zero insertion force (ZIF) connector (4) to which the TouchScreen cable is attached,
and then disconnect the TouchScreen cable from the system board.
Connector board 21
Page 28
5. Remove the Phillips PM1.4×3.6 screw (1) and the Phillips PM1.4×2.2 broad head screw (2) that
secure the connector board to the display panel assembly.
6. Remove the connector board (3).
Reverse this procedure to install the connector board.
System board
Description Spare part number
System board equipped with an Intel Z2520 1.20-GHz dual core processor, a graphics subsystem with UMA memory, and
1.0-GB of system memory
Equipped with a 16-GB eMMC hard drive 790593-001
Equipped with a 8-GB eMMC hard drive 790592-001
Before removing the system board, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
22 Chapter 5 Removal and replacement procedures
Page 29
5. Disconnect the battery cable from the system board (see Battery on page 14).
6. Remove the speaker (see Speaker on page 17).
Remove the system board: [callout 5 IDing button board cable ZIF connector on system board]
1. Disconnect the following cables from the system board:
(1) Connector board cable (see Connector board on page 21)
(2) Microphone cables (must be unsoldered, see Microphone on page 20)
(3) TouchScreen cable ZIF connector on system board
(4) XRay cable ZIF connector on system board
(5) Power/volume button board cable ZIF connector on system board
2. Remove the three Phillips PM1.4×3.6 screws (1) that secure the system board to the display
panel assembly.
3. Remove the three Phillips PM1.4×2.2 broad head screws (2) that secure the audio jack light pipe
and system board to the display panel assembly.
4. Remove the audio jack light pipe (3).
The audio jack light pipe is included with the ???.
System board 23
Page 30
5. Remove the system board (4).
Reverse this procedure to install the system board.
Front-facing webcam
Description Spare part number
Front-facing webcam (0.3-MP, fixed-focus, VGA; includes cable and double-sided adhesive) 790594-001
Before removing the front-facing webcam, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 12).
5. Disconnect the battery cable from the system board (see Battery on page 14).
6. Remove the speaker (see Speaker on page 17).
7. Remove the system board (see System board on page 22).
Remove the front-facing webcam:
1. Disconnect the front-facing webcam cable (1) from the system board.
24 Chapter 5 Removal and replacement procedures
Page 31
2. Detach the front-facing webcam (2) from the display panel assembly. (The front-facing webcam
is attached to the display panel assembly with double-sided adhesive.)
3. Remove the front-facing webcam and cable.
Reverse this procedure to install the front-facing webcam.
Front-facing webcam 25
Page 32
6 Specifications
Metric U.S.
Dimensions (portrait orientation)
Width 19.3 cm 7.6 in
Depth 11.7 cm 4.6 in
Height 0.9 cm 0.4 in
Weight (lowest weight configuration) 287 g 0.63 lb
Input power
The tablet operates on DC power, which can be supplied by an AC or a DC power source. The AC power source must be
rated 100-240 V, 50/60 Hz.
NOTE: The tablet can operate on DC power using an industry-standard micro-B USB cable. The HP adapter included with
the tablet is recommended for charging the tablet.
Temperature
Operating 5°C to 35°C 41°F to 95°F
Nonoperating ‑20°C to 60°C ‑4°F to 140°F
Relative humidity (non-condensing)
Operating 10% to 90%
Nonoperating 5% to 95%
Maximum altitude (unpressurized)
Operating ‑15 m to 3,048 m ‑50 ft to 10,000 ft
Nonoperating ‑15 m to 12,192 m ‑50 ft to 40,000 ft
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The device operates well within this
range of temperatures.
26 Chapter 6 Specifications
Page 33
7 Power cord set requirements
The wide-range input feature of the tablet permits it to operate from any line voltage from 100 to 120
volts AC, or from 220 to 240 volts AC.
The 3-conductor power cord set included with the tablet meets the requirements for use in the country
or region where the equipment is purchased.
Power cord sets for use in other countries and regions must meet the requirements of the country or
region where the tablet is used.
Requirements for all countries
The following requirements are applicable to all countries and regions:
The length of the power cord set must be at least 1.0 m (3.3 ft) and no more than 2.0 m (6.5 ft).
●
All power cord sets must be approved by an acceptable accredited agency responsible for
●
evaluation in the country or region where the power cord set will be used.
The power cord sets must have a minimum current capacity of 10 amps and a nominal voltage
●
rating of 125 or 250 V AC, as required by the power system of each country or region.
The appliance coupler must meet the mechanical configuration of an EN 60 320/IEC 320
●
Standard Sheet C13 connector for mating with the appliance inlet on the back of the tablet.
Requirements for specific countries and regions
Country/region Accredited agency Applicable note number
Australia EANSW 1
Austria OVE 1
Belgium CEBC 1
Canada CSA 2
Denmark DEMKO 1
Finland FIMKO 1
France UTE 1
Germany VDE 1
Italy IMQ 1
Japan METI 3
The Netherlands KEMA 1
Norway NEMKO 1
The People's Republic of China COC 5
South Korea EK 4
Requirements for all countries 27
Page 34
Country/region Accredited agency Applicable note number
Sweden CEMKO 1
Switzerland SEV 1
Taiwan BSMI 4
The United Kingdom BSI 1
The United States UL 2
1. The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance
coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region
where it will be used.
2. The flexible cord must be Type SPT-3 or equivalent, No. 18 AWG, 3-conductor. The wall plug must be a two-pole
grounding type with a NEMA 5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.
3. The appliance coupler, flexible cord, and wall plug must bear a “T” mark and registration number in accordance with the
Japanese Dentori Law. The flexible cord must be Type VCT or VCTF, 3-conductor, 1.00-mm² conductor size. The wall
plug must be a two-pole grounding type with a Japanese Industrial Standard C8303 (7 A, 125 V) configuration.
4. The flexible cord must be Type RVV, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler
and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it
will be used.
5. The flexible cord must be Type VCTF, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler
and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it
will be used.
28 Chapter 7 Power cord set requirements
Page 35
8 Recycling
When a non-rechargeable or rechargeable battery has reached the end of its useful life, do not
dispose of the battery in general household waste. Follow the local laws and regulations in your area
for battery disposal.
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and
rechargeable batteries. For more information about recycling programs, see the HP Web site at
http://www.hp.com/recycle.
29
Page 36
Index
A
AC adapter, spare part numbers
7
antenna
removal 16
spare part number 5, 7
Antenna Kit, spare part number
5, 7, 16
audio, product description 1
audio-in jack 3
audio-out jack 3
B
back cover
removal 12
spare part number 5, 6, 12
battery
removal 14
spare part number 5, 6, 14
buttons
power 2
volume control 3
C
Cable Kit, spare part number 6
cables, service considerations 8
Card Reader slot 3
connector board
removal 21
spare part number 5, 7, 21
connectors, service
considerations 8
D
display panel assembly, spare part
number 5, 6, 12
display panel, product
description 1
E
electrostatic discharge 9
equipment guidelines 11
external expansion, product
description 1
F
front-facing webcam
location 3
removal 24
spare part number 5, 6, 24
G
grounding guidelines 9
guidelines
equipment 11
grounding 9
packaging 10
transporting 10
workstation 10
H
headphone jack 3
J
jacks
audio-in 3
audio-out 3
headphone 3
microphone 3
M
mass storage device, product
description 1
memory module, product
description 1
microphone
location 3
product description 1
removal 20
spare part number 5, 7, 20
microphone jack 3
model name 1
O
operating system, product
description 1
P
packaging guidelines 10
plastic parts, service
considerations 8
Plastics Kit, spare part number 6,
7
ports
product description 1
USB 2.0 3
power adapter, spare part
numbers 6
power button 2
power cord, set requirements 27
power requirements, product
description 1
processor, product description 1
product description
audio 1
display panel 1
external expansion 1
mass storage 1
memory module 1
microphone 1
operating system 1
ports 1
power requirements 1
processors 1
product name 1
sensor 1
serviceability 1
video 1
wireless networking 1
product name 1
R
rear-facing webcam
location 2
removal 19
spare part number 5, 7, 19
Rubber Kit, spare part number 6,
7
S
Screw Kit, spare part number 6
sensor, product description 1
service considerations
cables 8
30 Index
Page 37
connectors 8
plastic parts 8
serviceability, product
description 1
SIM slot 3
speaker
location 3
removal 17
spare part number 5, 6, 17
system board
removal 22
spare part numbers 5, 6, 22
T
tablet
major components 5
spare part numbers 6, 7
specifications 26
tools required 8
transporting guidelines 10
U
USB 2.0 port 3
USB extension cable, spare part
number 6, 7
V
video, product description 1
volume control buttons 3
W
webcam
location 2, 3
removal 19, 24
spare part numbers 5, 6, 7,
19, 24
wireless networking, product
description 1
workstation guidelines 10
Index 31
Loading...
