Hewlett Packard 4QW30EA Product Data Sheet

QuickSpecs
HP 250 G6 Notebook PC

Overview

c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 1
Front
1.
Webcam LED
8.
USB 3.1 (Gen 1) port
2.
Webcam
9.
HDMI port
3.
Microphone
10.
RJ-45/Ethernet port
4.
Touchpad
11.
VGA port
5.
Touchpad buttons
12.
AC plug LED
6.
Audio in/out combo jack
13.
AC Smart Pin adapter plug
7.
USB 3.1 (Gen 1) port
14.
Power button
HP 250 G6 Notebook PC
QuickSpecs
HP 250 G6 Notebook PC
Overview
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 2
Right
1.
Webcam LED
7.
SD Card slot
2.
Webcam
8.
Hard drive indicator LED
3.
Microphone
9.
Power indicator LED
4.
Security lock slot (Locks sold seperately)
10.
Touchpad buttons
5.
Optical drive (optional)
11.
Touchpad
6.
USB 2.0 port
12.
Power button
QuickSpecs
HP 250 G6 Notebook PC
Overview
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 3
Windows 10 versions, FreeDOS 2.0 Choice of the latest Intel® Core™, Intel® Pentium®, or Intel® Celeron® processors Intel® HD Graphics or AMD Radeon™ 520 (up to 2 GB of dedicated video memory) New Dark Ash Silver color with a fresh woven texture Display choices include: 15.6" diagonal HD or FHD Choice of hard drives up to 1 TB or M.2 SATA solid state drives up to 512 GB Weight starting at: 4.1 lbs (1.86 kg) Security features including FW TPM 2.0 and security lock slot (Lock not included) Keyboard
- Full size textured island-style keyboard with numeric pad on the HP 250 G6"
Touchpad with gestures support HP webcam with single digital microphone and HD (supporting WDR- Wide Dynamic Range) or VGA camera Two USB 3.1 (Gen 1) ports and One USB 2.0 port Wireless LAN (WLAN) up to 2x2 802.11ac to keep you connected
NOTE: See important legal disclosures for all listed specs in their respective features sections.
AT A GLANCE
QuickSpecs
HP 250 G6 Series Notebook PC

Features

c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 4
HP 250 G6 Notebook PC
Preinstalled OS
Windows 10 Pro 64 1 Windows 10 Pro 64 (National Academic only) 1 Windows 10 Home 64 1 Windows 10 Home Single Language 64 1 FreeDOS 2.0
NOTE 1: Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.
Intel® Core™ i7-7500U with Intel® HD Graphics 620 (2.7 GHz, up to 3.5 GHz with Intel Turbo Boost Technology, 4 MB cache, 2 cores)
2,3
Intel® Core™ i5-7200U with Intel® HD Graphics 620 (2.5 GHz, up to 3.1 GHz with Intel Turbo Boost Technology, 3 MB cache, 2 cores)
2,3
Intel® i3-6006U with Intel® HD Graphics 520 (2 GHz, 3 MB cache, 2 cores) 2
Intel® Pentium® N3710 with Intel® HD Graphics 405 (1.6 GHz, up to 2.56 GHz, 2 MB cache, 4 cores) 2
Intel® Celeron® N3060 with Intel® HD Graphics 400 (1.6 GHz, up to 2.48 GHz, 2 MB cache, 2 cores) 2
Processor Family
7th Generation Intel® Core™ i7 processor (7500U model) 7th Generation Intel® Core™ i5 processor (7200U model) 6th Generation Intel® Core™ i3 processor (6006U model) Intel Braswell processor (Pentium N3710, Celeron N3060)
NOTE 2: Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on
application workload and your hardware and software configurations. Intel’s numbering is not a measurement of higher
performance.
NOTE 3: In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com.
Chipset is integrated with processor
PRODUCT NAME
OPERATING SYSTEM
PROCESSOR
CHIPSET
QuickSpecs
HP 250 G6 Series Notebook PC
Features
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 5
Integrated Intel® HD Graphics 620 4 Intel® HD Graphics 520 4 Intel® HD Graphics 405 4 Intel® HD Graphics 400
4
Discrete
AMD Radeon™ 520 (up to 2048 MB of dedicated video memory)
5,6
NOTE 4: HD content required to view HD images. NOTE 5: AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon™ discrete graphics
configuration and is not available on FreeDOS. With AMD Dynamic Switchable Graphics technology, full enablement of all discrete graphics video and display features may not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU or the APU as the case may be).
NOTE 6: Available on select processors. NOTE 7: Cables sold seperately.
Internal
39.6 cm (15.6") diagonal HD SVA eDP anti-glare slim WLED (1366 x 768)
4,8
39.6 cm (15.6") diagonal FHD SVA eDP anti-glare slim WLED (1920 x 1080)
4,8
NOTE 4: HD content required to view HD images. NOTE 8: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
Primary Storage
Support all 7.2mm/9.5mm, SATA 2.5" Hard Drives 1 TB SATA 5400 rpm SATA (7.2/9.5 mm) 9 500 GB SATA 5400 rpm SATA (7 mm) 9 500 GB SATA 7200 rpm SATA (7 mm)
9
M.2 SATA-3 Solid State Drives
128 GB M.2 SATA SSD 9 256 GB M.2 SATA SSD 9 512 GB M.2 SATA SSD
9
128 GB eMMC
9
Optical Drive
Optional DVD+/-RW Double-Layer Writer
10,11
NOTE 9: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software. NOTE 10: HD-DVD disks cannot be played on this drive. No support for DVDRAM. Actual speeds may vary. Don't copy copyright-protected materials. Double Layer discs can store more data than single layer discs; discs burned with this drive may not be compatible with many existing single-layer DVD drives and players.
GRAPHICS
DISPLAY
STORAGE AND DRIVES
QuickSpecs
HP 250 G6 Series Notebook PC
Features
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 6
NOTE 11: Sold separately or as an optional feature.
DDR4 (Intel® Core™ i7-7500U, i5-7200U, i3-6006U processors only) DDR4-2133 (Transfer rates up to 2133 MT/s) (DDR4-2400 bridge to DDR4-2133) Dual channel support No customer accessible / upgradeable
Configurations
4096 MB Total System Memory (4096 MB x 1) 6144 MB Total System Memory (2048 MB x 1 + 4096 MB x 1) 8192 MB Total System Memory (4096 MB x 2) 8192 MB Total System Memory (8192 MB x 1)
Maximum
Up to 8 GB DDR4-2133 SDRAM DDR3L (Intel® Pentium® N3710, Celeron® N3060 processors only) DDR3L-1600 (Transfer rates up to 1600 MT/s) Single channel support No customer accessible / upgradeable
Configurations
2048 MB Total System Memory (2048 MB x 1) 4096 MB Total System Memory (4096 MB x 1) 8192 MB Total System Memory (8192 MB x 1)
Maximum
Up to 8 GB DDR3L-1600 SDRAM
MEMORY
QuickSpecs
HP 250 G6 Series Notebook PC
Features
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 7
Wireless LAN (WLAN) Realtek 802.11b/g/n (1x1) WiFi and Bluetooth® 4.0 Combo 12 Intel® Dual Band Wireless-AC 3168 802.11ac (1x1) Wi-Fi and Bluetooth® 4.2 Combo (non-vPro™) 12 Intel® Dual Band Wireless-AC 7265 802.11ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro™)
12
Ethernet
Integrated 10/100/1000 NIC Communications Compatible with Miracast-certified devices 13
NOTE 12: Wireless access point and Internet service required and sold separately. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
NOTE 13: Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media players that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide show. For more information: http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast.
Audio
(2) Integrated stereo speakers
Camera
HP TrueVision HD Camera 4 Indicator LED, USB2.0, HD BSI sensor, f2.0, WDR 720p by 30 frames per second Single digital microphone
Webcam
HP Webcam 14 VGA camera, indicator LED, USB 2.0, f2.4 480p by 30 frames per second Single digital microphone
NOTE 4: HD content required to view HD images. NOTE 14: Wireless access point and Internet service is required and is not included. Availability of public wireless access
points limited.
Keyboard
Full size textured island-style keyboard with numeric keypad Jet black Touchpad Multitouch gestures enabled Support Modern Trackpad Gestures Taps enabled as default
NETWORKING/COMMUNICATIONS
AUDIO/MULTIMEDIA
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
QuickSpecs
HP 250 G6 Series Notebook PC
Features
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 8
Preinstalled Software
Buy Office HP JumpStart Discover HP Touchpoint Manager 15 Windows 10 Redstone1 Recovery Manager Installer - CPS Windows 10 Redstone1 Push Button Reset Recovery - CPS HP Support Assistant HP PC Hardware Diagnostics UEFI HP ePrint 16 HP System Event Utility CyberLink Power Media Player Bing Search for IE11 Security firmware TPM 2.0 Security lock slot (Locks sold seperatley)
NOTE15: HP Touchpoint Manager requires purchase of a subscription and supports Android™, iOS and Windows 7 or higher operating systems and PCs, notebooks, tablets and smartphones from various manufacturers. Not available in all countries see http://www.hp.com/touchpoint for availability information.
NOTE16: Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter). Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.
Power Supply
65 W Smart AC adapter 17 65 W EM Smart AC adapter 17 45 W Smart AC adapter
17
Primary Battery
HP 3-cell battery, 31 Whr Li-ion HP 4 cell battery, 41 Whr Li-ion
Power Cord
1 M (3.28 feet) length power cord with sticker label
Battery life
7th gen core CPU: Up to 12 hours (4 cell battery) 18 6th gen core CPU: Up to 10 hours (4 cell battery) 18 Intel® Pentium® and Celeron® CPU: Up to 9 hours and 30 minutes (4 cell battery) 18 Fast Charge (90 mins, 90% charged) Supports battery fast charge
NOTE 17: Availability may vary by country.
SOFTWARE AND SECURITY
POWER
QuickSpecs
HP 250 G6 Series Notebook PC
Features
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 9
NOTE 18: Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See www.bapco.com for additional details.
Weight
Starting at 1.86 kg (4.1 lb) 19
NOTE 19: Weight varies by configuration and components.
Dimensions (W x D x H)
38 x 25.38 x 2.38 cm
14.96 x 9.99 x 0.93 in
Ports/Connectors
USB 3.1 (Gen 1) ports - Two (Left) USB 2.0 port - One (Right) HDMI 1.4b - One 20 VGA port - One RJ-45 / Ethernet - One 20 Headphone / microphone combo jack - One AC Smart adapter port - One
Slots
HP Multi-Format Digital Media Card Reader Supports SD/SDHC/SDXC
NOTE 20: All cables are sold separately.
WEIGHTS & DIMENSIONS
PORTS/SLOTS
QuickSpecs
HP 250 G6 Series Notebook PC
Features
c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 10
HP Services offers limited 1-year warranty; 1-year limited warranty on primary battery. On-site service is also available with optional HP Care Services, which extend protection beyond the standard limited warranty. To choose the right level of service for your HP product, use the HP Care Services Lookup Tool at: http://www.hp.com/go/lookuptool. Additional HP Care Services, information by product is available at: http://www.hp.com/go/cpc.21
NOTE 21: HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated to
Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.
SERVICE AND SUPPORT
QuickSpecs
HP 250 G6 Series Notebook PC

Options and Accessories (sold separately and availability may vary by country)

c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 11
Type
Description
Part Number
Monitors
HP S140u 14-inch Portable Display
G8R65AA
HP ProDisplay P223 21-5 inch Monitor
X7R61AA
HP ProDisplay P232 23-inch Monitor
K7X31AA
HP ProDisplay P240va 23.8-inch Monitor
N3H14AA
QuickSpecs
HP 250 G6 Series Notebook PC

Summary of Changes

c05468499 DA – 15868 Worldwide Version 1 April 17, 2017
Page 12
Date of change:
Version History:
Description of change:
From v1 to v2
