Overview
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
AC Smart Pin adapter plug
HP 250 G6 Notebook PC

c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Security lock slot (Locks sold seperately)

c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Windows 10 versions, FreeDOS 2.0
Choice of the latest Intel® Core™, Intel® Pentium®, or Intel® Celeron® processors
Intel® HD Graphics or AMD Radeon™ 520 (up to 2 GB of dedicated video memory)
New Dark Ash Silver color with a fresh woven texture
Display choices include: 15.6" diagonal HD or FHD
Choice of hard drives up to 1 TB or M.2 SATA solid state drives up to 512 GB
Weight starting at: 4.1 lbs (1.86 kg)
Security features including FW TPM 2.0 and security lock slot (Lock not included)
Keyboard
- Full size textured island-style keyboard with numeric pad on the HP 250 G6"
Touchpad with gestures support
HP webcam with single digital microphone and HD (supporting WDR- Wide Dynamic Range) or VGA camera
Two USB 3.1 (Gen 1) ports and One USB 2.0 port
Wireless LAN (WLAN) up to 2x2 802.11ac to keep you connected
NOTE: See important legal disclosures for all listed specs in their respective features sections.
AT A GLANCE

HP 250 G6 Series Notebook PC
Features
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Windows 10 Pro 64 1
Windows 10 Pro 64 (National Academic only) 1
Windows 10 Home 64 1
Windows 10 Home Single Language 64 1
FreeDOS 2.0
NOTE 1: Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is
automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for
updates. See http://www.windows.com/.
Intel® Core™ i7-7500U with Intel® HD Graphics 620 (2.7 GHz, up to 3.5 GHz with Intel Turbo Boost Technology, 4 MB cache, 2
cores)
2,3
Intel® Core™ i5-7200U with Intel® HD Graphics 620 (2.5 GHz, up to 3.1 GHz with Intel Turbo Boost Technology, 3 MB cache, 2
cores)
2,3
Intel® i3-6006U with Intel® HD Graphics 520 (2 GHz, 3 MB cache, 2 cores) 2
Intel® Pentium® N3710 with Intel® HD Graphics 405 (1.6 GHz, up to 2.56 GHz, 2 MB cache, 4 cores) 2
Intel® Celeron® N3060 with Intel® HD Graphics 400 (1.6 GHz, up to 2.48 GHz, 2 MB cache, 2 cores) 2
Processor Family
7th Generation Intel® Core™ i7 processor (7500U model)
7th Generation Intel® Core™ i5 processor (7200U model)
6th Generation Intel® Core™ i3 processor (6006U model)
Intel Braswell processor (Pentium N3710, Celeron N3060)
NOTE 2: Multicore is designed to improve performance of certain software products. Not all customers or software
applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on
application workload and your hardware and software configurations. Intel’s numbering is not a measurement of higher
performance.
NOTE 3: In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on
products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7
drivers on http://www.support.hp.com.
Chipset is integrated with processor
PRODUCT NAME
OPERATING SYSTEM
PROCESSOR
CHIPSET

HP 250 G6 Series Notebook PC
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Integrated
Intel® HD Graphics 620 4
Intel® HD Graphics 520 4
Intel® HD Graphics 405 4
Intel® HD Graphics 400
4
Discrete
AMD Radeon™ 520 (up to 2048 MB of dedicated video memory)
5,6
NOTE 4: HD content required to view HD images.
NOTE 5: AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon™ discrete graphics
configuration and is not available on FreeDOS. With AMD Dynamic Switchable Graphics technology, full enablement of all
discrete graphics video and display features may not be supported on all systems (e.g. OpenGL applications will run on the
integrated GPU or the APU as the case may be).
NOTE 6: Available on select processors.
NOTE 7: Cables sold seperately.
Internal
39.6 cm (15.6") diagonal HD SVA eDP anti-glare slim WLED (1366 x 768)
4,8
39.6 cm (15.6") diagonal FHD SVA eDP anti-glare slim WLED (1920 x 1080)
4,8
NOTE 4: HD content required to view HD images.
NOTE 8: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
Primary Storage
Support all 7.2mm/9.5mm, SATA 2.5" Hard Drives
1 TB SATA 5400 rpm SATA (7.2/9.5 mm) 9
500 GB SATA 5400 rpm SATA (7 mm) 9
500 GB SATA 7200 rpm SATA (7 mm)
9
M.2 SATA-3 Solid State Drives
128 GB M.2 SATA SSD 9
256 GB M.2 SATA SSD 9
512 GB M.2 SATA SSD
9
128 GB eMMC
9
Optical Drive
Optional DVD+/-RW Double-Layer Writer
10,11
NOTE 9: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for
Windows 10) is reserved for system recovery software.
NOTE 10: HD-DVD disks cannot be played on this drive. No support for DVDRAM. Actual speeds may vary. Don't copy
copyright-protected materials. Double Layer discs can store more data than single layer discs; discs burned with this drive
may not be compatible with many existing single-layer DVD drives and players.
GRAPHICS
DISPLAY
STORAGE AND DRIVES

HP 250 G6 Series Notebook PC
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
NOTE 11: Sold separately or as an optional feature.
DDR4 (Intel® Core™ i7-7500U, i5-7200U, i3-6006U processors only)
DDR4-2133 (Transfer rates up to 2133 MT/s) (DDR4-2400 bridge to DDR4-2133)
Dual channel support
No customer accessible / upgradeable
Configurations
4096 MB Total System Memory (4096 MB x 1)
6144 MB Total System Memory (2048 MB x 1 + 4096 MB x 1)
8192 MB Total System Memory (4096 MB x 2)
8192 MB Total System Memory (8192 MB x 1)
Maximum
Up to 8 GB DDR4-2133 SDRAM
DDR3L (Intel® Pentium® N3710, Celeron® N3060 processors only)
DDR3L-1600 (Transfer rates up to 1600 MT/s)
Single channel support
No customer accessible / upgradeable
Configurations
2048 MB Total System Memory (2048 MB x 1)
4096 MB Total System Memory (4096 MB x 1)
8192 MB Total System Memory (8192 MB x 1)
Maximum
Up to 8 GB DDR3L-1600 SDRAM
MEMORY

HP 250 G6 Series Notebook PC
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Wireless LAN (WLAN)
Realtek 802.11b/g/n (1x1) WiFi and Bluetooth® 4.0 Combo 12
Intel® Dual Band Wireless-AC 3168 802.11ac (1x1) Wi-Fi and Bluetooth® 4.2 Combo (non-vPro™) 12
Intel® Dual Band Wireless-AC 7265 802.11ac (2x2) WiFi and Bluetooth® 4.2 Combo (non-vPro™)
12
Ethernet
Integrated 10/100/1000 NIC
Communications
Compatible with Miracast-certified devices 13
NOTE 12: Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ
from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
NOTE 13: Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media
players that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide show. For
more information: http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast.
Audio
(2) Integrated stereo speakers
Camera
HP TrueVision HD Camera 4
Indicator LED, USB2.0, HD BSI sensor, f2.0, WDR
720p by 30 frames per second
Single digital microphone
Webcam
HP Webcam 14
VGA camera, indicator LED, USB 2.0, f2.4
480p by 30 frames per second
Single digital microphone
NOTE 4: HD content required to view HD images.
NOTE 14: Wireless access point and Internet service is required and is not included. Availability of public wireless access
points limited.
Keyboard
Full size textured island-style keyboard with numeric keypad
Jet black
Touchpad
Multitouch gestures enabled
Support Modern Trackpad Gestures
Taps enabled as default
NETWORKING/COMMUNICATIONS
AUDIO/MULTIMEDIA
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

HP 250 G6 Series Notebook PC
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Buy Office
HP JumpStart
Discover HP Touchpoint Manager 15
Windows 10 Redstone1 Recovery Manager Installer - CPS
Windows 10 Redstone1 Push Button Reset Recovery - CPS
HP Support Assistant
HP PC Hardware Diagnostics UEFI
HP ePrint 16
HP System Event Utility
CyberLink Power Media Player
Bing Search for IE11
Security
firmware TPM 2.0
Security lock slot (Locks sold seperatley)
NOTE15: HP Touchpoint Manager requires purchase of a subscription and supports Android™, iOS and Windows 7 or higher
operating systems and PCs, notebooks, tablets and smartphones from various manufacturers. Not available in all countries
see http://www.hp.com/touchpoint for availability information.
NOTE16: Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible
printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter). Requires
optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for
coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection
speeds may vary.
65 W Smart AC adapter 17
65 W EM Smart AC adapter 17
45 W Smart AC adapter
17
Primary Battery
HP 3-cell battery, 31 Whr Li-ion
HP 4 cell battery, 41 Whr Li-ion
Power Cord
1 M (3.28 feet) length power cord with sticker label
Battery life
7th gen core CPU: Up to 12 hours (4 cell battery) 18
6th gen core CPU: Up to 10 hours (4 cell battery) 18
Intel® Pentium® and Celeron® CPU: Up to 9 hours and 30 minutes (4 cell battery) 18
Fast Charge (90 mins, 90% charged)
Supports battery fast charge
NOTE 17: Availability may vary by country.
SOFTWARE AND SECURITY
POWER

HP 250 G6 Series Notebook PC
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
NOTE 18: Windows 10 MM14 battery life will vary depending on various factors including product model, configuration,
loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the
battery will naturally decrease with time and usage. See www.bapco.com for additional details.
Weight
Starting at 1.86 kg (4.1 lb) 19
NOTE 19: Weight varies by configuration and components.
Dimensions (W x D x H)
38 x 25.38 x 2.38 cm
14.96 x 9.99 x 0.93 in
USB 3.1 (Gen 1) ports - Two (Left)
USB 2.0 port - One (Right)
HDMI 1.4b - One 20
VGA port - One
RJ-45 / Ethernet - One 20
Headphone / microphone combo jack - One
AC Smart adapter port - One
Slots
HP Multi-Format Digital Media Card Reader
Supports SD/SDHC/SDXC
NOTE 20: All cables are sold separately.
WEIGHTS & DIMENSIONS
PORTS/SLOTS

HP 250 G6 Series Notebook PC
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
HP Services offers limited 1-year warranty; 1-year limited warranty on primary battery. On-site service is also available with
optional HP Care Services, which extend protection beyond the standard limited warranty. To choose the right level of
service for your HP product, use the HP Care Services Lookup Tool at: http://www.hp.com/go/lookuptool. Additional HP Care
Services, information by product is available at: http://www.hp.com/go/cpc.21
NOTE 21: HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on
your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated to
Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and
such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with
your HP Product.
SERVICE AND SUPPORT

HP 250 G6 Series Notebook PC
Options and Accessories (sold separately and availability may vary by country)
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
HP S140u 14-inch Portable Display
HP ProDisplay P223 21-5 inch Monitor
HP ProDisplay P232 23-inch Monitor
HP ProDisplay P240va 23.8-inch Monitor

HP 250 G6 Series Notebook PC
Summary of Changes
c05468499 — DA – 15868 —Worldwide — Version 1 — April 17, 2017
Copyright © 2017 HP Development Company, L.P.
The only warranties for HP products are set forth in the express limited warranty statements accompanying such products.
Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein.
Intel, Core, Celeron and Pentium are trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a trademark
of its proprietor used by HP Inc. under license. ENERGY STAR is a registered trademark owned by the U.S. Environmental
Protection Agency. All Rights Reserved.
