Specification Sheet
Part Number:
TFOT-1
Fiber Optic Cable Marker Tape, 1.0" x 54', VL, Orange, 1/roll
Article Number
597-00044
Type
TFOT1
Color
Orange (OG)
Features & Benefits
• Markers are pre-coiled so that they can be snapped into place over the cable
without the use of adhesives. • Non-adhesive design means that the markers
can be installed at any temperature or over dirty or oily surfaces. • Pre-printed
text is protected by a thick layer of clear acrylic which provides UV protection
and abrasion resistance.
Quantity Per
pack
Product Description
Designed to be used on the Lightguide Fiber Optic Protection System to
identify the routing of fiber optic cable. It is a 1" wide range vinyl with black
lettering that states, "FIBER OPTIC CABLE." The legend is repeated every six
inches.
Short Description
Fiber Optic Cable Marker Tape, 1.0" x 54', VL, Orange, 1/roll
Global Part Name
TFOT1-V-OG
Length L (Imperial)
54
Length L (Metric)
16.46
Width W (Imperial)
1.0
Width W (Metric)
25.4
Height H (Imperial)
2.2
Height H (Metric)
50.8
Material
Vinyl
Material Shortcut
V
Halogen free
No
Operating Temperature (Metric)
-18°F to +200°F (-29°C to +93°C)
Reach Complaint(Article 33)
No
ROHS Complaint
Yes
Package Quantity(Imperial)
648
