Specification Sheet
Part Number:
133-00997
HC Clamp Bundle Separator, Two Hole, PA66GFHIRHS, Red, 500/pkg
Article Number
133-00997
Type
HC2E
Color
Red (RD)
Features & Benefits
• Separates and secures bundles avoiding abrasion • Designed to handle both
convoluted tubing and bundles not covered in convoluted tubing • Come in a
variety of sizes and colors to be easily identified
Quantity Per
bag
Product Description
HC Clamps separate multiple bundles and secure them to brackets or frame
rails. Each mount has two pawls for easy pre-installation on a threaded
fastener prior to securing with a mechanical fastener. HC Clamps have ribs
that make them ideal for convoluted tubing, but they can also be used to
separate separate bundles that aren't protected with convoluted tubing.
Short Description
HC Clamp Bundle Separator, Two Hole, PA66GFHIRHS, Red, 500/pkg
Global Part Name
HC2E-PA66HIRGF13-RD
Length L (Imperial)
2.747
Length L (Metric)
67.77
Width W (Imperial)
1.1
Width W (Metric)
27.94
Bundle Diameter Min (Imperial)
0.513
Bundle Diameter Min (Metric)
13.03
Bundle Diameter Max (Imperial)
0.513
Bundle Diameter Max (Metric)
13.03
Bundle Diameter 1st Loop Max (Imperial)
0.513
Bundle Diameter 1st Loop Max (Metric)
13.03
Bundle Diameter 2nd Loop Max (Imperial)
0.513
Bundle Diameter 2nd Loop Max (Metric)
13.03
Height H (Imperial)
1.38
Height H (Metric)
34.94
Mounting Hole Diameter D (Imperial)
0.32
Mounting Hole Diameter D (Metric)
8.12 mm
