Model:
RAVE4013I-C
Owner’s Manual
Installation and Operation
NOTICE
DO NOT DISCARD THIS MANUAL
• Important operating
and maintenance
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency , or the
gas supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer’s instructions
and the manufactured home construction and safety standard,
Title 24 CFR, Part 3280 or Standard for Installation in Mobile
Homes, CAN/CSA Z240MH, in Canada.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
• Read, understand and follow
these instructions for safe
installation and operation.
DO NOT
DISCARD
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
1Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 2
Read this manual before installing or operating this appliance.
Please retain this owner’s manual for future reference.
A. Congratulations
Congratulations on selecting a Heatilator gas fi replace, an
elegant and clean alternative to wood burning fi replaces.
The Heatilator gas fi replace you have selected is designed
to provide the utmost in safety, reliability, and effi ciency.
As the owner of a new fi replace, you’ll want to read and
carefully follow all of the instructions contained in this
owner’s manual. Pay special attention to all cautions and
warnings.
Homeowner Reference Information
This owner’s manual should be retained for future
reference. We suggest that you keep it with your other
important documents and product manuals.
The information contained in this owner’s manual, unless
noted otherwise, applies to all models and gas control
systems.
Your new Heatilator gas fi replace will give you years of
durable use and trouble-free enjoyment. Welcome to the
Heatilator family of fi replace products!
We recommend that you record the following pertinent
information about your fi replace.
Model Name: ___________________________________________ Date purchased/installed: __________________
Serial Number: __________________________________________ Location on fi replace: _____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
Listing Label Information/Location
Type of Gas
Gas and Electric
Information
Not Not for for use use with with solid solid fuel.fuel.
((Ne Ne doit doit pas pas entre entre utilise utilise avec avec un un combustible combustible solide).solide).
Type Type o f of Gas Gas (Sorte (Sorte De De Gaz)Gaz)::
NNAATURALTURAL GASGAS
Minimum Minimum Permissible Permissible Gas Gas Supply Supply for for Purposes Purposes of of Input Input Adjustment.Adjustment.
Approved Approved Minimum Minimum (De (De Gaz) Gaz) AcceptableAcceptable 0.00.0 in in w.c.w.c. (Po. (Po. Col. Col. d’eau)d’eau)
Maximum Maximum Pressure Pressure (Pression)(Pression) 0.00.0 in in w.c.w.c. (Po. (Po. Col. Col. d’eau)d’eau)
Maximum Maximum Manifold Manifold Pressure Pressure (Pression)(Pression) 0.00.0 in in w.c.w.c. (Po. (Po. Col. Col. d’eau)d’eau)
Minimum Minimum Manifold Manifold Pressure Pressure (Pression)(Pression) 0.00.0 in in w.c.w.c. (Po. (Po. Col. Col. d’eau)d’eau)
Total Total Electrical Electrical Requirements: Requirements: 000Vac, 000Vac, 00Hz., 00Hz., less less than than 00 00 AmperesAmperes
ALTITUDE:ALTITUDE: 0-0000 0-0000 FT.FT. 0000-0000FT.0000-0000FT.
MAX. MAX. INPUT INPUT BTUH:BTUH: 00,00000,000 00,00000,000
MIN. MIN. INPUT INPUT BTUH:BTUH: 00,00000,000 00,00000,000
ORIFICE ORIFICE SIZE:SIZE: #XXXXX#XXXXX #XXXXX#XXXXX
The model information regarding your specifi c fi replace can be found on
the rating plate usually located in the control area of the fi replace.
Heat & Glo, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
This This appliance appliance must must be be installed installed in in accordance accordance with with local local codes, codes, if if any; any; if if not, not, follow follow ANSI ANSI Z223.1Z223.1
in in the the USA USA or or CAN/CGA CAN/CG A B149 B149 installation installation codes. codes. (Installer (Installer l’appareil l’appareil selon selon les les codes codes ou ou reglementsreglements
locaux locaux ou, ou, en en l’absence l’absence de de tels tels reglements, reglements, selon selon les les codes codes d’installation d’installation CAN/CGA-B149.)CAN/CGA-B149.)
ANSI ANSI Z21XX-XXXX Z21XX-XXXX · · CSA CSA 2.XX-MXX 2.XX-MXX · · UL307BUL307B
IN IN CANADACANADA
Model:Model:
(Modele):(Modele):
SerialSerial
(Serie):(Serie):
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
MADE MADE IN IN USAUSA
Model Number
Serial Number
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/132
Page 3
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
Table of Contents
A. Congratulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
B. Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1 Listing and Code Approvals
A. Appliance Certifi cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
B. Tempered Glass Specifi cations . . . . . . . . . . . . . . . . . . . . . 7
C. BTU Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
D. High Altitude Installations . . . . . . . . . . . . . . . . . . . . . . . . . . 7
E. Non-Combustible Materials Specifi cation. . . . . . . . . . . . . . 7
F. Combustible Materials Specifi cation . . . . . . . . . . . . . . . . . 7
G. Electrical Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
H. Requirements for the Commonwealth of Massachusetts . . 8
User Guide
2 Operating Instructions
A. Gas Fireplace Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
B. Your Fireplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
C. Clear Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
D. Decorative Doors and Fronts . . . . . . . . . . . . . . . . . . . . . . 10
E. Fixed Glass Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
F. Remote Controls, Wall Controls and Wall Switches . . . . . 10
G. Before Lighting Fireplace . . . . . . . . . . . . . . . . . . . . . . . . . 10
H. Lighting Instructions (IPI) . . . . . . . . . . . . . . . . . . . . . . . . . 11
I. After Fireplace is Lit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
J. Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . 12
3 Maintenance and Service
A. Maintenance Tasks-Homeowner . . . . . . . . . . . . . . . . . . . 13
B. Maintenance Tasks-Qualifi ed Service Technician . . . . . . 14
Installer Guide
4 Getting Started
A. Typical Appliance System. . . . . . . . . . . . . . . . . . . . . . . . . 15
B. Design and Installation Considerations . . . . . . . . . . . . . . 16
C. Tools and Supplies Needed . . . . . . . . . . . . . . . . . . . . . . . 16
D. Inspect Appliance and Components . . . . . . . . . . . . . . . . . 16
5 Framing and Clearances
A. Selecting Appliance Location . . . . . . . . . . . . . . . . . . . . . . 17
B. Constructing the Appliance Chase . . . . . . . . . . . . . . . . . . 18
C. Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
D. Mantel and Wall Projections . . . . . . . . . . . . . . . . . . . . . . . 20
6 Termination Locations
A. Vent Termination Minimum Clearances . . . . . . . . . . . . . . 22
7 Vent Information and Diagrams
A. Approved Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
B. Vent Table Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
C. Use of Elbows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
D. Measuring Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
E. Vent Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Vent Clearances and Framing
A. Pipe Clearances to Combustibles . . . . . . . . . . . . . . . . . . 35
B. Wall Penetration Framing . . . . . . . . . . . . . . . . . . . . . . . . . 35
C. Install the Ceiling Firestop . . . . . . . . . . . . . . . . . . . . . . . . 36
D. Install Attic Insulation Shield . . . . . . . . . . . . . . . . . . . . . . . 37
9 Appliance Preparation
A. Top Vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
B. Securing and Leveling the Appliance . . . . . . . . . . . . . . . . 39
10 Installing Vent Pipe (SLP Pipe)
A. Assemble Vent Sections. . . . . . . . . . . . . . . . . . . . . . . . . . 40
B. Assemble Slip Sections . . . . . . . . . . . . . . . . . . . . . . . . . . 41
C. Secure The Vent Sections . . . . . . . . . . . . . . . . . . . . . . . . 41
D. Disassemble Vent Sections . . . . . . . . . . . . . . . . . . . . . . . 42
E. Install Decorative Ceiling Components . . . . . . . . . . . . . . 42
F. Install Metal Roof Flashing . . . . . . . . . . . . . . . . . . . . . . . . 43
G. Assemble and Install Storm Collar . . . . . . . . . . . . . . . . . . 43
H. Install Vertical Termination Cap . . . . . . . . . . . . . . . . . . . . 44
I. Install Decorative Wall Components . . . . . . . . . . . . . . . . 44
J. Heat Shield Requirements for Horizontal Termination . . . 44
K. Install Horizontal Termination Cap . . . . . . . . . . . . . . . . . . 45
11 Gas Information
A. Fuel Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
B. Gas Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
C. Gas Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
D. High Altitude Installations . . . . . . . . . . . . . . . . . . . . . . . . . 47
12 Electrical Information
A. Wiring Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
B. IntelliFire Ignition System Wiring . . . . . . . . . . . . . . . . . . . 48
C. Optional Accessories Requirements . . . . . . . . . . . . . . . . 48
D. Electrical Service and Repair . . . . . . . . . . . . . . . . . . . . . . 49
E. Junction Box Installation. . . . . . . . . . . . . . . . . . . . . . . . . . 49
3Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 4
13 Finishing
A. Framing and Finishing Instructions . . . . . . . . . . . . . . . . . 50
B. Mantel and Wall Projections . . . . . . . . . . . . . . . . . . . . . . . 53
C. Facing Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
D. Decorative Fronts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
14 Appliance Setup
A. Remove Fixed Glass Assembly . . . . . . . . . . . . . . . . . . . . 57
B. Remove the Shipping Materials . . . . . . . . . . . . . . . . . . . . 57
C. Clean the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
D. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
E. Fixed Glass Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
F. Install the Mesh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
G. Air Shutter Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
15 Troubleshooting
A. IntelliFire Ignition System . . . . . . . . . . . . . . . . . . . . . . . . . 59
16 Reference Materials
A. Appliance Dimension Diagram . . . . . . . . . . . . . . . . . . . . . 61
B. Vent Components Diagrams . . . . . . . . . . . . . . . . . . . . . . 62
C. Service Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
D. Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
= Contains updated information.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/134
Page 5
Parts Labor Gas Wood Pellet
EPA
Wood
Coal Electric Venting
XXXXXXX
All parts and material except as
covered by Conditions,
Exclusions, and Limitations
listed
XXX
Igniters, electronic components,
and glass
XXXXX Factory-installed blowers
X Molded refractory panels
X Firepots and burnpots
5 years 1 year X X Castings and baffles
7 years 3 years X X X
Manifold tubes,
HHT chimney and termination
10
years
1 year X Burners, logs and refractory
Limited
Lifetime
3 yearsXXXXX Firebox and heat exchanger
XXXXXXX
All replacement parts
beyond warranty period
Warranty Period
HHT Manufactured Appliances and Venting
1 Year
Components Covered
3 years
2 years
90 Days
B. Limited Lifetime Warranty
Hearth & Home Technologies
LIMITED LIFETIME WARRANTY
Hearth & Home Technologies, on behalf of its hearth brands (”HHT”), extends the following warranty for HHT
gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer.
WARRANTY COVERAGE:
HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership
of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance
will be free from defects in materials and workmanship at the time of manufacture. After installation, if covered components manufactured by HHT are found to be defective in materials or workmanship during the applicable warranty period,
HHT will, at its option, repair or replace the covered components. HHT, at its own discretion, may fully discharge all of its
obligations under such warranties by replacing the product itself or refunding the verified purchase price of the product
itself. The maximum amount recoverable under this warranty is limited to the purchase price of the product. This warranty
is subject to conditions, exclusions and limitations as described below.
WARRANTY PERIOD:
Warranty coverage begins on the date of original purchase. In the case of new home construction, warranty coverage
begins on the date of first occupancy of the dwelling or six months after the sale of the product by an independent,
authorized HHT dealer/ distributor, whichever occurs earlier. The warranty shall commence no later than 24 months
following the date of product shipment from HHT, regardless of the installation or occupancy date. The warranty period for
parts and labor for covered components is produced in the following table.
The term “Limited Lifetime” in the table below is defined as: 20 years from the beginning date of warranty coverage for
gas appliances, and 10 years from the beginning date of warranty coverage for wood, pellet, and coal appliances. These
time periods reflect the minimum expected useful lives of the designated components under normal operating conditions.
See conditions, exclusions, and limitations on next page.
4021-645D 01-16-13 Page 1 of 2
5Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 6
B. Limited Lifetime Warranty (continued)
WARRANTY CONDITIONS:
• This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of
HHT authorized dealers is available on the HHT branded websites.
• This warranty is only valid while the HHT appliance remains at the site of original installation.
• Contact your installing dealer for warranty service. If the installing dealer is unable to provide necessary parts, contact
the nearest HHT authorized dealer or supplier. Additional service fees may apply if you are seeking warranty service
from a dealer other than the dealer from whom you originally purchased the product.
• Check with your dealer in advance for any costs to you when arranging a warranty call. Travel and shipping charges
for parts are not covered by this warranty.
WARRANTY EXCLUSIONS:
This warranty does not cover the following:
• Changes in surface finishes as a result of normal use. As a heating appliance, some changes in color of interior and
exterior surface finishes may occur. This is not a flaw and is not covered under warranty.
• Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse, scratches, melted items,
or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes.
• Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts
include: paint, wood, pellet and coal gaskets, firebricks, grates, flame guides, batteries and the discoloration of glass.
• Minor expansion, contraction, or movement of certain parts causing noise. These conditions are normal and complaints related to this noise are not covered by this warranty.
• Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation
instructions, operating instructions, and listing agent identification label furnished with the appliance; (2) failure to
install the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper operation, abuse, misuse, continued operation with damaged, corroded or failed components, accident, or improperly/
incorrectly performed repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting
caused by tightly sealed constructions, insufficient make-up air supply, or handling devices such as exhaust fans or
forced air furnaces or other such causes; (6) use of fuels other than those specified in the operating instructions; (7)
installation or use of components not supplied with the appliance or any other components not expressly authorized
and approved by HHT; (8) modification of the appliance not expressly authorized and approved by HHT in writing;
and/or (9) interruptions or fluctuations of electrical power supply to the appliance.
• Non-HHT venting components, hearth components or other accessories used in conjunction with the appliance.
• Any part of a pre-existing fireplace system in which an insert or a decorative gas appliance is installed.
• HHT’s obligation under this warranty does not extend to the appliance’s capability to heat the desired space. Information is provided to assist the consumer and the dealer in selecting the proper appliance for the application. Consideration must be given to appliance location and configuration, environmental conditions, insulation and air tightness of
the structure.
This warranty is void if:
• The appliance has been over-fired or operated in atmospheres contaminated by chlorine, fluorine, or other damaging
chemicals. Over-firing can be identified by, but not limited to, warped plates or tubes, rust colored cast iron, bubbling,
cracking and discoloration of steel or enamel finishes.
• The appliance is subjected to prolonged periods of dampness or condensation.
• There is any damage to the appliance or other components due to water or weather damage which is the result of, but
not limited to, improper chimney or venting installation.
LIMITATIONS OF LIABILITY:
• The owner’s exclusive remedy and HHT’s sole obligation under this warranty, under any other warranty, express or
implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above. In no
event will HHT be liable for any incidental or consequential damages caused by defects in the appliance. Some states
do not allow exclusions or limitation of incidental or consequential damages, so these limitations may not apply to you.
This warranty gives you specific rights; you may also have other rights, which vary from state to state. EXCEPT TO
THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY
SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE
EXPRESSED WARRANTY SPECIFIED ABOVE.
4021-645D 01-16-13 Page 2 of 2
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/136
Page 7
1
1
Listing and Code Approvals
A. Appliance Certifi cation
MODEL: RAVE4013I-C
LABORATORY: Underwriters Laboratories, Inc. (UL)
TYPE: Vented Gas Fireplace Heater
STANDARD: ANSI Z21.88-2009/CSA 2.33-2009
Vented Gas Fireplace Heaters
This product is listed to ANSI standards for “Vented Gas
Fireplace Heaters” and applicable sections of “Gas Burning Heating Appliances for Manufactured Homes and
Recreational Vehicles”, and “Gas Fired Appliances for
Use at High Altitudes”.
NOTICE: This installation must conform with local codes.
In the absence of local codes you must comply with the
National Fuel Gas Code, ANSI Z223.1-latest edition in
the U.S.A. and the CAN/CGA B149 Installation Codes in
Canada.
NOT INTENDED FOR USE AS A PRIMAR Y HEAT SOURCE.
This appliance is tested and approved as either supplemental room heat or as a decorative appliance. It should not be
factored as primary heat in residential heating calculations.
B. Tempered Glass Specifi cations
Hearth & Home Technologies appliances manufactured
with tempered glass may be installed in hazardous locations such as bathtub enclosures as defi ned by the Con-
sumer Product Safety Commission (CPSC). The tempered
glass has been tested and certifi ed to the requirements
of ANSI Z97.1 and CPSC 16 CFR 1202 (Safety Glazing
Certifi cation Council SGCC# 1595 and 1597. Architectur-
al Testing, Inc. Reports 02-31919.01 and 02-31917.01).
This statement is in compliance with CPSC 16 CFR Sec-
tion 1201.5 “Certifi cation and labeling requirements”
which refers to 15 U.S. Code (USC) 2063 stating “…Such
certifi cate shall accompany the product or shall otherwise
be furnished to any distributor or retailer to whom the
product is delivered.”
Some local building codes require the use of tempered
glass with permanent marking in such locations. Glass
meeting this requirement is available from the factory.
Please contact your dealer or distributor to order.
C. BTU Specifi cations
Models
RAVE4013I-C
(NG)
RAVE4013I-C
(LP)
Maximum
Input
BTU/h
(0-2000 FT) 26,000 N/A #42
(0-2000 FT) 25,000 N/A .057
Minimum
Input
BTU/h
Orifi ce
Size
(DMS)
D. High Altitude Installations
NOTICE: If the heating value of the gas has been reduced,
these rules do not apply. Check with your local gas utility
or authorities having jurisdiction.
When installing above 2000 feet elevation:
• In the USA: Reduce input rate 4% for each 1000 feet
above 2000 feet.
• In CANADA: Input ratings are certifi ed without a reduction
of input rate for elevations up to 4500 feet (1370 m)
above sea level. Please consult provincial and/or
local authorities having jurisdiction for installations at
elevations above 4500 feet (1370 m).
Check with your local gas utility to determine proper
orifi ce size.
E. Non-Combustible Materials Specifi cation
Material which will not ignite and burn. Such materials are
those consisting entirely of steel, iron, brick, tile, concrete,
slate, glass or plasters, or any combination thereof.
Materials that are reported as passing ASTM E 136,
Standard Test Method for Behavior of Materials in
a Vertical Tube Furnace at 750 ºC shall be considered
non-combustible materials.
F. Combustible Materials Specifi cation
Materials made of or surfaced with wood, compressed paper, plant fi bers, plastics, or other material that can ignite
and burn, whether fl ame proofed or not, or plastered or
unplastered shall be considered combustible materials.
G. Electrical Codes
NOTICE: This appliance must be electrically wired and
grounded in accordance with local codes or, in the absence
of local codes, with National Electric Code ANSI/NFPA
70-latest edition or the Canadian Electric Code CSA
C22.1.
• A 110-120 VAC circuit for this product must be protected
with ground-fault circuit-interrupter protection, in
compliance with the applicable electrical codes, when it is
installed in locations such as in bathrooms or near sinks.
7Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 8
Note: The following requirements reference various
Massachuset ts and national codes not contain ed in this
document.
H. Requirements for the Commonwealth of
Massachusetts
For all side wall horizontally vented gas fueled equipment
installed in every dwelling, building or structure used in
whole or in part for residential purposes, including those
owned or operated by the Commonwealth and where the
side wall exhaust vent termination is less than seven (7)
feet above fi nished grade in the area of the venting, in-
cluding but not limited to decks and porches, the following
requirements shall be satisfi ed:
Installation of Carbon Monoxide Detectors
At the time of installation of the side wall horizontal vented
gas fueled equipment, the installing plumber or gas fi tter
shall observe that a hard wired carbon monoxide detector
with an alarm and battery back-up is installed on the fl oor
level where the gas equipment is to be installed. In addition, the installing plumber or gas fi tter shall observe that
a battery operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of
the dwelling, building or structure served by the side wall
horizontal vented gas fueled equipment. It shall be the
responsibility of the property owner to secure the services
of qualifi ed licensed professionals for the installation of
hard wired carbon monoxide detectors.
In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic,
the hard wired carbon monoxide detector with alarm and
battery back-up may be installed on the next adjacent
fl oor level.
In the event that the requirements of this subdivision can
not be met at the time of completion of installation, the
owner shall have a period of thirty (30) days to comply
with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
Inspection
The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the
installation unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed
in accordance with the provisions of 248 CMR 5.08(2)(a)1
through 4.
Exemptions
The following equipment is exempt from 248 CMR
5.08(2)(a)1 through 4:
• The equipment listed in Chapter 10 entitled “Equipment
Not Required To Be Vented” in the most current edition
of NFPA 54 as adopted by the Board; and
• Product Approved side wall horizontally vented gas fu-
eled equipment installed in a room or structure separate
from the dwelling, building or structure used in whole or
in part for residential purposes.
MANUFACTURER REQUIREMENTS
Gas Equipment Venting System Provided
When the manufacturer of Product Approved side wall
horizontally vented gas equipment provides a venting
system design or venting system components with the
equipment, the instructions provided by the manufacturer
for installation of the equipment and the venting system
shall include:
• Detailed instructions for the installation of the venting
system design or the venting system components; and
• A complete parts list for the venting system design or
venting system.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall
horizontally vented gas fueled equipment does not provide the parts for venting the fl ue gases, but identifi es
“special venting systems”, the following requirements
shall be satisfi ed by the manufacturer:
Approved Carbon Monoxide Detectors
Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA
720 and be ANSI/UL 2034 listed and IAS certifi ed.
Signage
A metal or plastic identifi cation plate shall be permanent-
ly mounted to the exterior of the building at a minimum
height of eight (8) feet above grade directly in line with the
exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The sign shall read,
in print size no less than one-half (1/2) in. in size, “GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/138
• The referenced “special venting system” instructions
shall be included with the appliance or equipment installation instructions; and
• The “special venting systems” shall be Product Ap-
proved by the Board, and the instructions for that system shall include a parts list and detailed installation
instructions.
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting
instructions, and/or all venting design instructions shall
remain with the appliance or equipment at the completion
of the installation.
See Gas Connection section for additional Commonwealth of Massachusetts requirements.
Page 9
2
2
Operating Instructions
User Guide
A. Gas Fireplace Safety
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
• Install a switch lock or a wall/remote control with child
protection lockout feature.
• Keep remote controls out of reach of children.
• Never leave children alone near a hot fi replace, whether
operating or cooling down.
• Teach children to NEVER touch the fi replace.
• Consider not using the fi replace when children will be
present.
Contact your dealer for more information, or visit: www.
hpba.org/safety-information.
T o prevent unintended operation when not using your fi re-
place for an extended period of time (summer months,
vacations, trips, etc):
• Remove batteries from remote controls.
• Turn off wall controls.
• Unplug 3 volt adapter plug and remove batteries on IPI
models.
WARNING! Choking Hazard! Keep glass rock media
out of reach of children.
If you expect that small children or vulnerable adults may
come into contact with this fi replace, the following precau-
tions are recommended:
• Install a physical barrier such as:
- A decorative fi rescreen.
- Adjustable safety gate.
DECORATIVE DOORS
(NOT SHOWN)
SECTION 2.D.
CLEAR SPACE
SECTION 2.C.
B. Your Fireplace
WARNING! DO NOT operate fi replace before read-
ing and understanding operating instructions. Failure
to operate fi replace according to operating instructions
could cause fi re or injury.
FIXED GLASS ASSEMBLY
(NOT SHOWN)
SECTION 14.E.
Figure 2.1 General Operating Parts
9Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 10
C. Clear Space
WARNING! DO NOT place combustible objects in front
of the fi replace or block louvers. High temperatures may
start a fi re. See Figure 2.2.
A void placing candles and other heat-sensitive objects on
mantel or hearth. Heat may damage these objects.
CLEAR SPACE
3 FT. IN FRONT
OF FIREPLACE
Figure 2.2 Clear Space
D. Decorative Doors and Fronts
WARNING! Risk of Fire! Install ONLY doors or fronts
approved by Hearth & Home Technologies. Unapproved
doors or fronts may cause fi replace to overheat.
This decorative front has been supplied with an
integral barrier to prevent direct contact with the fi xed
glass panel. DO NOT operate the fi replace with the
barrier removed.
Contact your dealer or Hearth & Home Technologies if
the barrier is not present or help is needed to properly
install one.
E. Fixed Glass Assembly
See Section 14.E.
F. Remote Controls, Wall Controls and Wall
Switches
Follow the instructions supplied with the control installed
to operate your fi replace:
For safety:
• Install a switch lock or a wall/remote control with child
protection lockout feature.
• Keep remote controls out of reach of children.
See your dealer if you have questions.
G. Before Lighting Fireplace
Before operating this fi replace for the fi rst time, have a
qualifi ed service technician:
• Verify all shipping materials have been removed from
inside and/or underneath the fi rebox.
• Verify that burner cover tray is securely fastened to the
base pan.
• Check the wiring.
• Check the air shutter adjustment.
• Ensure that there are no gas leaks.
• Ensure that the glass is sealed and in the proper position
and that the integral barrier is in place.
WARNING! Risk of Fire or Asphyxiation! DO NOT operate fi replace with fi xed glass assembly removed.
For more information refer to the instructions supplied with
your decorative door or front.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1310
Page 11
H. Lighting Instructions (IPI)
The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery
life, remove them when using the transformer.
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: If you do not follow these instructions exactly, a fi re or explosion
may result causing property damage, personal injury or loss of life.
A. This appliance is equipped with an
intermittent pilot ignition (IPI) device
which automatically lights the burner. DO NOT try to light the burner by
hand.
B. BEFORE LIGHTING, smell all around
the appliance area for gas. Be sure to
smell next to the fl oor because some
gas is heavier than air and will settle
on the fl oor.
WHA T TO DO IF YOU SMELL GAS
• DO NOT try to light any appliance.
• DO NOT touch any electric switch; do
not use any phone in your building.
WARNING:
DO NOT CONNECT LINE VOLTAGE (110/120 VAC OR 220/240
V AC) TO THE CONTROL VALVE.
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to the owner’s information manual
provided with this appliance.
This appliance needs fresh air for
safe operation and must be installed
so there are provisions for adequate
combustion and ventilation air.
If not installed, operated, and maintained in accordance with the manufacturer’s instructions, this product could
expose you to substances in fuel or
fuel combustion which are known to
the State of California to cause cancer, birth defects, or other reproductive
harm.
Keep burner and control compartment
clean. See installation and operating
instructions accompanying appliance.
For additional information on operating your
Hearth & Home Technologies fi replace, please refer to www.fi replaces.com.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fi re department.
C. DO NOT use this appliance if any
part has been under water. Immediately call a qualifi ed service tech-
nician to inspect the appliance and
to replace any part of the control
system and any gas control which
has been under water.
CAUTION:
Hot while in operation. DO NOT touch.
Keep children, clothing, furniture, gasoline and other liquids having fl ammable
vapors away.
DO NOT operate the appliance with
fi xed glass assembly removed, cracked
or broken. Replacement of the fi xed
glass assembly should be done by a
licensed or qualifi ed service person.
NOT FOR USE
WITH SOLID FUEL
For use with natural gas and propane.
A conversion kit, as supplied by the
manufacturer, shall be used to convert
this appliance to the alternate fuel.
Also Certifi ed for Installation in a
Bedroom or a Bedsitting Room.
For assistance or additional information, consult a qualifi ed installer, ser-
vice agency or the gas supplier.
LIGHTING
INSTRUCTIONS (IPI)
1. This appliance is equipped with an ignition
device which automatically lights the burner.
DO NOT try to light the burner by hand.
GAS
VALVE
2. Wait fi ve (5) minutes to clear out any gas.
Then smell for gas, including near the fl oor. If
you smell gas, STOP! Follow “B” in the Safety
Information located on the left side of this label. If you do not smell gas, go to next step.
3. To light the burner:
Equipped with wall switch: Turn ON/OFF switch
to ON.
Equipped with remote or wall control: Press
ON or FLAME button.
Equipped with thermostat: Set temperature to
desired setting.
4. If the appliance does not light after three tries,
call your service technician or gas supplier.
TO TURN OFF
GAS TO APPLIANCE
1. Equipped with wall switch: Turn ON/OFF switch
to OFF.
Equipped with remote or wall control: Press
OFF button.
Equipped with thermostat: Set temperature to
lowest setting.
2. Service technician should turn off electric
power to the control when performing service.
593-913G
Final inspection by
11Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 12
I. After Fireplace is Lit
Initial Break-in Procedure
• The fireplace should be run three to four hours
continuously on high.
• Turn the fi replace off and allow it to completely cool.
• Remove fi xed glass assembly. See Section 14.E.
• Clean fi xed glass assembly. See Section 3.
• Replace the fi xed glass assembly and run continuously
on high an additional 12 hours.
This cures the materials used to manufacture the fi re-
place.
NOTICE! Open windows for air circulation during fi re-
place break-in.
• Some people may be sensitive to smoke and odors.
• Smoke detectors may activate.
TO CEILING
FIREPLACE
OPENING
136°F
139°F
136°F
29 in.
23 in.
MEASUREMENTS FROM
TOP EDGE OF THE OPENING
APPLIANCE FRONT
Figure 2.3. Wall Surface Temperatures Above Appliance
129°F
133°F
47 in.
41 in.
35 in.
126°F
128°F
59 in.
53 in.
J. Frequently Asked Questions
ISSUE SOLUTIONS
Condensation on the glass
Blue fl ames
Odor from fi replace
Film on the glass
Metallic noise
Optional Rock Media Kit
This is a result of gas combustion and temperature variations. As the fi replace warms, this con-
densation will disappear.
This is a result of normal operation and the fl ames will begin to yellow as the fi replace is allowed
to burn for 20 to 40 minutes.
When fi rst operated, this fi replace may release an odor for the fi rst several hours. This is caused
by the curing of materials from manufacturing. Odor may also be released from fi nishing materials
and adhesives used near the fi replace. These circumstances may require additional curing related
to the installation environment.
This is a normal result of the curing process of the paint. Glass should be cleaned within 3 to 4
hours of initial burning. A non-abrasive cleaner such as gas appliance glass cleaner may be necessary. See your dealer.
Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the
sound produced by a furnace or heating duct. This noise does not affect the operation or longevity
of the fi replace.
There may be some “cracking” noise coming from the fi replace during the fi rst few heating and
cooling cycles. This noise is associated with settling rock and some minor cracking of larger
pieces of rock. This will lessen over time as the glass rock is conditioned to the heating and cooling temperature changes.
It is expected that a few small pieces (approximately 10 pieces) of rock may fall through the basepan and come to rest on the fi replace bottom. This has no affect on fi replace performance.
Power Outages
(battery backup)
Wall above appliance feels hot to
the touch.
This appliance can operated on battery power in the event of a power outage. To access the battery pack, the decorative front, mesh and glass assembly must be removed. Refer to Section 12
for more details.
No action necessary. This appliance ships with a non-combustible material attached. Specifi ca-
tions of the attached non-combustible material are listed in Section 1.E.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1312
Page 13
3
3
Maintenance and Service
Any safety screen or guard removed for servicing must be
replaced prior to operating the fi replace.
When properly maintained, your fi replace will give you
many years of trouble-free service. We recommend annual service by a qualifi ed service technician.
A. Maintenance Tasks-Homeowner
Installation and repair should be done by a qualifi ed service
technician only. The fi replace should be inspected before
use and at least annually by a professional service person.
The following tasks may be performed annually by the
homeowner. If you are uncomfortable performing any of
the listed tasks, please call your dealer for a service appointment.
More frequent cleaning may be required due to lint from
carpeting or other factors. Control compartment, burner
and circulating air passageway of the fi replace must be
kept clean.
CAUTION! Risk of Burns! The fi replace should be turned
off and cooled before servicing.
Glass Cleaning
Frequency: Seasonally
By: Homeowner
Tools Needed: Protective gloves, glass cleaner, drop
cloth and a stable work surface.
CAUTION! Handle fi xed glass assembly with care.
Glass is breakable.
• Avoid striking, scratching or slamming glass
• Avoid abrasive cleaners
• DO NOT clean glass while it is hot
• Prepare a work area large enough to accommodate fi xed
glass assembly and door frame by placing a drop cloth
on a fl at, stable surface.
Note: Fixed glass assembly and gasketing may have residue that can stain carpeting or fl oor surfaces.
• Remove door or decorative front from fi replace and set
aside on work surface.
• See Section 14.E for instructions to remove fi xed glass
assembly.
• Clean glass with a non-abrasive commercially available
cleaner.
- Light deposits: Use a soft cloth with soap and water
- Heavy deposits: Use commercial fireplace glass
cleaner (consult with your dealer)
• Refer to Section 14.E for glass removal and replacement
instructions.
• Reinstall door or decorative front.
Doors, Surrounds, Fronts
Frequency: Annually
By: Homeowner
Tools needed: Protective gloves, stable work surface
• Assess condition of screen and replace as necessary.
• Inspect for scratches, dents or other damage and repair
as necessary.
• Check that louvers are not blocked.
• Vacuum and dust surfaces.
Remote Control
Frequency: Seasonally
By: Homeowner
Tools needed: Replacement batteries and remote con-
trol instructions.
• Locate remote control transmitter and receiver.
• Verify operation of remote. Refer to remote control
operation instructions for proper calibration and setup
procedure.
• Place batteries as needed in remote transmitters and
battery-powered receivers.
• Place remote control out of reach of children.
If not using your fi replace for an extended period of time
(summer months, vacations/trips, etc), to prevent unintended operation:
• Remove batteries from remote controls.
• Unplug 3 volt adapter plug on IPI models.
Venting
Frequency: Seasonally
By: Homeowner
Tools needed: Protective gloves and safety glasses.
• Inspect venting and termination cap for blockage or
obstruction such plants, bird nests, leaves, snow, debris,
etc.
• Verify termination cap clearance to subsequent construction (building additions, decks, fences, or sheds). See
Section 6.
• Inspect for corrosion or separation.
• Verify weather stripping, sealing and fl ashing remains
intact.
• Inspect draft shield to verify it is not damaged or missing.
13Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 14
B. Maintenance Tasks-Qualifi ed Service
Technician
The following tasks must be performed by a qualifi ed ser-
vice technician.
Gasket Seal and Glass Assembly Inspection
Frequency: Annually
By: Qualifi ed Service Technician
T ools needed: Protective gloves, drop cloth and a stable
work surface.
• Inspect gasket seal and its condition.
• Inspect fi xed glass assembly for scratches and nicks that
can lead to breakage when exposed to heat.
• Confi rm there is no damage to glass or glass frame.
Replace as necessary.
• Verify that fi xed glass assembly is properly retained and
attachment components are intact and not damaged.
Replace as necessary.
Firebox
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves, sandpaper, steel wool,
cloths, mineral spirits, primer and touch-up paint.
• Inspect for paint condition, warped surfaces, corrosion
or perforation. Sand and repaint as necessary.
• Replace fi replace if fi rebox has been perforated.
• Verify batteries have been removed from battery backup IPI systems to prevent premature battery failure or
leaking.
• Check for smooth lighting and ignition carryover to all
ports. Verify that there is no ignition delay.
• Inspect for lifting or other fl ame problems.
• Verify air shutter setting is correct. See Section 14.G for
required air shutter setting. Verify air shutter is clear of
dust and debris.
• Inspect orifi ce for soot, dirt and corrosion. Verify orifi ce
size is correct. See Service Parts List for proper orifi ce
sizing.
• Verify manifold and inlet pressures. Adjust regulator as
required.
• Inspect pilot fl ame pattern and strength. See Figure 3.1
for proper pilot fl ame pattern. Clean or replace orifi ce
spud as necessary.
• Inspect IPI fl ame sensing rod for soot, corrosion and
deterioration. Polish with fi ne steel wool or replace as
required.
• Verify IPI millivolt output. Replace as necessary.
• Verify that there is not a short in fl ame sense circuit
by checking continuity between pilot hood and fl ame
sensing rod. Replace pilot as necessary.
Control Compartment and Firebox Top
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves, vacuum cleaner, dust
cloths
• V acuum and wipe out dust, cobwebs, debris or pet hair.
Use caution when cleaning these areas. Screw tips that
have penetrated the sheet metal are sharp and should
be avoided.
• Remove all foreign objects.
• Verify unobstructed air circulation.
Burner Ignition and Operation
Frequency: Annually
By: Qualifi ed Service Technician
T ools needed: Protective gloves, vacuum cleaner, whisk
broom, fl ashlight, voltmeter, indexed drill bit set, and a
manometer.
• Verify burner is properly secured and aligned with pilot
or igniter.
• Clean off burner top, inspect for plugged ports, corrosion
or deterioration. Replace burner if necessary.
Figure 3.1 IPI Pilot Flame Pattern
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1314
Page 15
4
4
A. Typical Appliance System
NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only . Illustrations/diagrams are not
drawn to scale. Actual product may vary from pictures in manual
Getting Started
Installer Guide
HORIZONTAL
TERMINATION CAP
(SECTION 10.K)
WALL PENETRATION
FRAMING
(SECTION 8.B)
NON-COMBUSTIBLE ROOF
FLASHING MAINTAINS MINIMUM
CLEARANCE AROUND PIPE
(SECTION 10.F)
VENT PIPE
(SECTIONS 7 and 8)
CEILING FIRESTOP ON FLOOR
OF ATTIC (SECTION 8.C)
FRAMING/HEADER (SECTION 5)
VERTICAL TERMINATION CAP
(SECTION 10.H)
STORM COLLAR
(SECTION 10.G)
VENT PIPE PENETRATES
ROOF PREFERABLY
WITHOUT AFFECTING ROOF
RAFTERS (SECTION 8.C)
ATTIC INSULATION SHIELD (NOT
SHOWN) MUST BE USED HERE
TO KEEP INSULATION AWAY
FROM VENT PIPE IF ATTIC IS
INSULATED. (SECTION 8.D)
FRAMING HEADED
OFF IN CEILING
JOISTS (SECTION 8.C)
WALL SWITCH
Figure 4.1 Typical System
GAS LINE
(SECTION 11)
15Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 16
B. Design and Installation Considerations
Heatilator direct vent gas appliances are designed to operate with all combustion air siphoned from outside of the
building and all exhaust gases expelled to the outside. No
additional outside air source is required.
Installation MUST comply with local, regional, state and
national codes and regulations. Consult insurance carrier,
local building inspector, fi re offi cials or authorities having
jurisdiction over restrictions, installation inspection and
permits.
Before installing, determine the following:
• Where the appliance is to be installed.
• The vent system confi guration to be used.
• Gas supply piping.
• Electrical wiring requirements.
• Framing and fi nishing details.
• Whether optional accessories—devices such as a wall
switch or remote control—are desired.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. For
assistance or additional information, consult a qualifi ed
service technician, service agency or your dealer.
C. Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Tape measure Framing material
Pliers Non-corrosive leak check solution
Hammer Phillips screwdriver (magnetic)
Gloves Framing square
Voltmeter Electric drill and bits (1/4 in. magnetic)
Plumb line Safety glasses
Level Reciprocating saw
Manometer Flat blade screwdriver
1/2 - 3/4 in. length, #6 or #8 Self-drilling screws
Caulking material (300ºF minimum continuous exposure
rating)
D. Inspect Appliance and Components
• Carefully remove the appliance and components from
the packaging.
• The vent system components and decorative doors and
fronts may be shipped in separate packages.
• Report to your dealer any parts damaged in shipment,
particularly the condition of the glass.
• Read all of the instructions before starting the instal-
lation. Follow these instructions carefully during the
installation to ensure maximum safety and benefi t.
WARNING! Risk of Fire or Explosion! Damaged parts
could impair safe operation. DO NOT install damaged, in-
complete or substitute components. Keep appliance dry.
Hearth & Home T echnologies disclaims any responsibility for ,
and the warranty will be voided by, the following actions:
• Installation and use of any damaged appliance or vent
system component.
• Modifi cation of the appliance or vent system.
• Installation other than as instructed by Hearth & Home
Technologies.
• Improper positioning of the gas logs or the glass door.
• Installation and/or use of any component part not approved
by Hearth & Home Technologies.
Any such action may cause a fi re hazard.
WARNING! Risk of Fire, Explosion or Electric Shock!
DO NOT use this appliance if any part has been under
water. Call a qualifi ed service technician to inspect the
appliance and to replace any part of the control system
and/or gas control which has been under water.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1316
Page 17
5
5
Framing and Clearances
A. Selecting Appliance Location
When selecting a location for the appliance it is important to
consider the required clearances to walls (see Figure 5.1).
WARNING! Risk of Fire or Burns! Provide adequate
clearance around air openings and for service access.
Due to high temperatures, the appliance should be located out of traffi c and away from furniture and draperies.
NOTICE: Illustrations refl ect typical installations and are
FOR DESIGN PURPOSES ONLY. Illustrations/diagrams
are not drawn to scale. Actual installation may vary due to
individual design preference.
A
E
1 IN.
It is important to follow the framing and fi nishing
instructions step by step to ensure proper placement of
fi replace in the surrounding framing/fi nishing materials.
Unlike many traditional, single sided Heatilator fi replaces,
the RA VE4013I-C is recessed into surround framing. The left
and right nailing tabs were designed to ensure the fi replace is
recessed to the correct location within the framing materials.
Refer to Section 13 for detailed instructions on fi nishing.
D*
A
B
C
TOP VENT
0
ELBOW
ONE 90
ALCOVE
INSTALLATION
TOP VENT
ONE 90° ELBOW
B
F
Inches 53-1/32 48 75
Millimeters 1347 1218 1905 490 451
Figure 5.1 Appliance Locations
ABC D E F
See Section D.
Figure 5.5 & 5.6
19-9/32 17-3/4
17Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 18
B. Constructing the Appliance Chase
A chase is a vertical box-like structure built to enclose the
gas appliance and/or its vent system. In cooler climates
the vent should enclosed inside the chase.
NOTICE: Treatment of ceiling fi restops and wall shield
fi restops and construction of the chase may vary with the
type of building. These instructions are not substitutes
for the requirements of local building codes. Therefore,
you MUST check local building codes to determine the
requirements to these steps.
Chases should be constructed in the manner of all outside walls of the home to prevent cold air drafting problems. The chase should not break the outside building
envelope in any manner.
Walls, ceiling, base plate and cantilever fl oor of the chase
should be insulated. Vapor and air infi ltration barriers
should be installed in the chase as per regional codes for
the rest of the home. Additionally, in regions where cold
air infi ltration may be an issue, the inside surfaces may be
sheetrocked and taped for maximum air tightness.
To further prevent drafts, the wall shield and ceiling fi re-
stops should be caulked with caulk with a minimum of
300ºF continuous exposure rating to seal gaps. Gas line
holes and other openings should be caulked with caulk
with a minimum of 300ºF continuous exposure rating or
stuffed with unfaced insulation. If the appliance is being
installed on a cement surface, a layer of plywood may be
placed underneath to prevent conducting cold up into the
room.
The factory-supplied non-combustible board must be
used in all installations. It must be directly attached to
structural framing adjacent to the appliance. Screw fasteners should be installed in the pilot holes provided in
the outer perimeter of the non-combustible board. See
Figure 13.2.
The factory-supplied board is designed such that its edges will be at the approximate center of the adjacent framing, assuming it is 1-1/2 in. nominal thickness. This will
allow the wallboard joints to occur on the center of the
framing where the panels can be fastened properly . If the
framing thickness is less than 1-1/2 in. nominal, such as
with formed steel systems, then it may be necessary to
adjust the adjacent framing dimensions so that the noncombustible board and wallboard joints are centered on
the framing.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1318
Page 19
C. Clearances
NOTICE: Install appliance on hard metal or wood surfaces
extending full width and depth. DO NOT install directly
on carpeting, vinyl, tile or any combustible material other
than wood.
WARNING! Risk of Fire! Maintain specifi ed air space
clearances to appliance and vent pipe:
• Insulation and other materials must be secured to prevent
accidental contact.
• The chase must be properly blocked to prevent blown
insulation or other combustibles from entering and
making contact with fi replace or chimney.
• Failure to maintain airspace may cause overheating and
a fi re.
Note: Figure 5.2 shows the fi replace installed on the
fl oor. However, this fi replace can be elevated off the fl oor
provided that the fi replace is properly supported by framing
materials and the ceiling clearances are maintained.
A
MEASURE FROM TOP
OF FIREPLACE OPENING
F
B
C
D
MINIMUM FRAMING DIMENSIONS*
ABCDE F GHIJ
Rough
Opening
(Vent Pipe)
Inches
Millimeters
8-5/8 42 1/4 18-1/4 50 31 0 0 1 1 36
219 1073 464 1270 787 0 0 25 25 914
* Adjust framing dimensions for interior sheathing (such as sheetrock)
Rough
Opening
(Height)
Rough
Opening
(Depth)
Rough
Opening
(Width)
Clearance
to Ceiling
Combustible
Floor
J
Combustible
Flooring
E
H
G
I
Behind
Appliance
Sides of
Appliance
Front of
Appliance
Figure 5.2. Clearances to Combustibles
19Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 20
D. Mantel and Wall Projections
WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specifi ed. Framing or fi nishing
material closer than the minimums listed must be constructed entirely of noncombustible materials (i.e., steel studs,
concrete board, etc).
Combustible Mantels
1/2 IN.
Thick Wall
Sheathing
12 IN.
MAX.
Combustible Mantel Legs Or Wall Projections
Extending Past The Face Of The Fireplace
2 IN.
FIREPLACE
OPENING
Figure 5.5 Combustible Mantel Leg or Wall Projections
(Acceptable on both sides of opening)
MINIMUM
MINIMUM
3 FT. MAXIMUM
6 IN.
MEASUREMENT
14 IN.
MIN.
FROM TOP OF
FIREPLACE
OPENING
Figure 5.3 Clearances To Combustible Mantels Or Other
Combustibles Above Appliance
Non-combustible Mantels
1/2 IN.
Thick Wall
Sheathing
12 IN.
MAX.
Non-combustible Mantel Legs Or Wall Projections
Extending Past The Face Of The Fireplace
3 IN.
FIREPLACE
OPENING
Figure 5.6 Non-Combustible Mantel Leg or Wall Projections
(Acceptable on both sides of opening)
MINIMUM
7 IN.
UNLIMITED
14 IN.
MIN.
MEASUREMENT
FROM TOP OF
FIREPLACE
OPENING
1 IN.MIN.
4 IN.
MAX.
Figure 5.4 Clearances To Non-Combustible Mantels Or Other
Non-Combustibles Above Appliance
Note: For non-combustible fi replace fi nish material (marble,
stone, etc) specifi cations refer to Section 13.C.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1320
1 IN.
FRAMING
NAILING TAB
1/2 IN. FACTORY-SUPPLIED
NON-COMBUSTIBLE BOARD
Figure 5.7 Front Side Finishing Detail
Page 21
3-1/2 IN.
1 IN.
1 IN.
AIR SPACE
Figure 5.8 Non-Combustible Zone
NON-COMBUSTIBLE
BOARD SHIPPED
WITH APPLIANCE
21Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 22
6
6
Termination Locations
A. Vent Termination Minimum Clearances
WARNING
Fire Risk.
Maintain vent clearance to combustibles as
specifi ed.
• DO NOT pack air space with insulation or other
materials.
Failure to keep insulation or other materials away
from vent pipe may cause overheating and fi re.
HORIZONTAL
OVERHANG
2 FT.
MIN.
GAS DIRECT VENT
TERMINATION CAP
20 INCHES MIN.
LOWEST
DISCHARGE
OPENING
H (MIN.) - MINIMUM HEIGHT FROM ROOF
TO LOWEST DISCHARGE OPENING
X
12
ROOF PITCH
VERTICAL
WALL
IS X/ 12
6 in. (minimum) up to 20 in.
AB
152 mm/508 mm
20 in. and over 0 in. minimum
18 in. minimum
457 mm
Gas, Wood or Fuel Oil
Termination Cap
B
A *
Gas
Termination
Cap **
If using decorative cap cover(s), this distance may need to be
*
increased. Refer to the installation instructions supplied with the
decorative cap cover.
In a staggered installation with both gas and wood or fuel oil
**
terminations, the wood or fuel oil termination cap must be
higher than the gas termination cap.
Roof Pitch H (Min.) Ft.
Flat to 6/12...........................................................1.0*
Over 6/12 to 7/12 .................................................1.25*
Over 7/12 to 8/12 .................................................1.5*
Over 8/12 to 9/12 .................................................2.0*
Over 9/12 to 10/12 ...............................................2.5
Over 10/12 to 11/12 .............................................3.25
Over 11/12 to 12/12 .............................................4.0
Over 12/12 to 14/12 .............................................5.0
Over 14/12 to 16/12 .............................................6.0
Over 16/12 to 18/12 .............................................7.0
Over 18/12 to 20/12 .............................................7.5
Over 20/12 to 21/12 .............................................8.0
* 3 foot minimum in snow regions
Figure 6.1 Minimum Height From Roof To Lowest Discharge
Opening
Figure 6.2 Staggered Termination Caps
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1322
Page 23
C
V
B
J
V
V
= VENT TERMINAL
X
= AIR SUPPLY INLET
B
D
V
V
V
A
F
B
G
M
= AREA WHERE TERMINAL IS NOT PERMITTED
A = 12 inches.................clearances above grade, veranda,
porch, deck or balcony
12 inches.................clearance to window or door that may
B =
be opened, or to permanently closed
window
C = 18 inches.................clearance below unventilated soffi t
18 inches.................clearance below ventilated soffi t
30
inches .................clearance below vinyl soffits and
electrical service
D = 6 inches...................clearance to outside corner
E = 6 inches...................clearance to inside corner
F = 3 ft. (Canada) ..........not to be installed above a gas me-
ter/regulator assembly within 3 feet
horizontally from the center-line of the
regulator
G = 3 ft ...........................clearance to gas service regulator
vent outlet
H =
12 inches.................clearance to non-mechanical (unpow-
ered) air supply inlet, combustion air
inlet or direct-vent termination
i = 3 ft. (U.S.A.)
6 ft. (Canada) ...........clearance to a mechanical (powered)
air supply inlet
All mechanical air intakes within 10 feet of a termination cap
must be a minimum of 3 feet below termination.
J = 7 ft. ......................... On public property: clearance above
paved sidewalk or a paved driveway.
A vent shall not terminate directly above a sidewalk or paved
driveway which is located between two single family dwellings
and serves both dwellings.
O
N
P
R
Q
H or i
V
X
H
V
V
H
E
V
V
A
V
K
V
L
Electrical
Service
C
V
K
V
Covered Alcove Applications
(Spaces open only on one side and with an overhang)
N = 6 inches ........... non-vinyl sidewalls
12 inches ......... vinyl sidewalls
O = 18 inches ......... non-vinyl soffi t and overhang
42 inches ......... vinyl soffi t and overhang
P = 8 ft.
Q
MIN
1 cap 3 feet 2 x Q
2 caps 6 feet 1 x Q
3 caps 9 feet 2/3 x Q
4 caps 12 feet 1/2 x Q
Q
= # termination caps x 3 R
MIN
Measure vertical clearances from this surface.
Measure horizontal clearances from this surface.
= (2 / # termination caps) x Q
MAX
R
MAX
ACTUAL
ACTUAL
ACTUAL
ACTUAL
ACTUAL
K = 6 inches................. clearance from sides of electrical
service
L = 12 inches................ clearance above electrical service
Location of the vent termination must not interfere with access to the
electrical service.
M = 18 inches ....................clearance under veranda, porch, deck,
balcony or overhang
42
inches ................vinyl or composite overhang
Permitted when veranda, porch, deck or balcony is fully open
on a minimum of 2 sides beneath the fl oor.
Figure 6.3 Minimum Clearances for Termination
CAUTION! Risk of Burns! Termination caps are HOT,
consider proximity to doors, traffi c areas or where people
may pass or gather (sidewalk, deck, patio, etc.). Listed cap
shields available. Contact your dealer.
• Local codes or regulations may require different
clearances.
• Vent system termination is NOT permitted in screened
porches.
• Vent system termination is permitted in porch areas with
two or more sides open.
• Hearth & Home Technologies assumes no responsibility
for the improper performance of the appliance when the
venting system does not meet these requirements.
• Vinyl protection kits are suggested for use with vinyl siding.
23Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 24
7
7
Vent Information and Diagrams
A. Approved Pipe
This appliance is approved for use with Hearth & Home
Technologies SLP venting systems. Refer to Section 16B
for vent component information.
DO NOT mix pipe, fi ttings or joining methods from differ-
ent manufacturers.
The pipe is tested to be run inside an enclosed wall.
There is no requirement for inspection openings at each
joint within the wall.
WARNING! Risk of Fire or Asphyxiation. This appliance requires a separate vent. DO NOT vent to a pipe
serving a separate solid fuel burning appliance.
CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS termination caps are not approved for use with propane
(LP) fuel. May lead to elevated glass temperature that
may cause tempered glass breakage.
B. Vent Table Key
The abbreviations listed in this vent table key are used in
the vent diagrams.
Symbol Description
V
First section (closest to appliance) of vertical length
1
D. Measuring Standards
Vertical and horizontal measurements listed in the vent
diagrams were made using the following standards.
• Pipe measurements are shown using the effective length
of pipe (see Figure 7.2).
• Measurements are made from the appliance outer wrap,
not from the standoffs.
• Horizontal terminations are measured to the outside
mounting surface (fl ange of termination cap).
• Vertical terminations are measured to bottom of
termination cap.
• Horizontal pipe installed level with no rise.
A
B
V
H
H
Second section of vertical length
2
First section (closest to appliance) of horizontal length
1
Subsequent sections of horizontal length
2
C. Use of Elbows
Diagonal runs have both vertical and horizontal vent aspects when calculating the effects. Use the rise for the
vertical aspect and the run for the horizontal aspect (see
Figure 7.1).
Two 45º elbows may be used in place of one 90º elbow.
On 45º runs, one foot of diagonal is equal to 8-1/2 in. (216
mm) horizontal run and 8-1/2 in. (216 mm) vertical run. A
length of straight pipe is allowed between two 45º elbows
(see Figure 7.1).
Vertical
12 in.
8-1/2 in.
8-1/2 in.
Horizontal
Figure 7.1
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1324
1-1/4 in. (32 mm)
OVERLAP
Figure 7.2 Chimney Offset/Return
Effective Height/Length
Pipe inches mm
SLP4 4 102
Effective
Height/
Length
Figure 7.3 SLP Pipe Effective Length
SLP6 6 152
SLP12 12 305
SLP24 24 610
SLP36 36 914
SLP48 48 1219
SLP6A 2 - 6 51 - 152
SLP12A 2 - 12 51 - 305
E. Vent Diagrams
General Rules:
• When penetrating a combustible wall, a wall shield
fi restop must be installed.
• When penetrating a combustible ceiling, a ceiling fi restop
must be installed.
• Horizontal runs of vent do not require vertical rise;
horizontal runs may be level.
Page 25
Fire Risk. Explosion Risk.
Do NOT pack insulation or other combustibles between ceiling fi restops.
• ALWAYS maintain specifi ed clearances around venting and fi restop systems.
• Install wall shield and ceiling fi restops as specifi ed.
Failure to keep insulation or other material away from vent pipe may cause fi re.
Top Vent - Horizontal Termination
Venting with 1 elbow
WARNING
V Minimum
90 Elbow 1-1/2 ft. 457mm
1 ft. 305 mm 3 ft. 914 mm
2 ft. 610 mm 5 ft. 1.5 m
3 ft. 914 mm 7 ft. 2.1 m
4 ft. 1.2 m 14 ft. 4.3 m
H MAX. =14 ft. (4.3 m)
V + H MAX. = 40 ft. (12.2 m)
H1 Maximum
RAVE4013I-C
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
fl ex vent except when using the
simple up and out installation
(see Figure 7.3).
CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS
termination caps are not approved for use with propane (LP) fuel. May lead to elevated glass temperature that may cause tempered glass breakage.
V
1
Figure 7.4
H
1
25Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 26
1. Top Vent - Horizontal Termination - (continued)
Top Vent - Horizontal Termination
Venting with 2 elbows
V Minimum
90° Elbow 1 ft. 305 mm
1 ft. 305 mm 2 ft. 610 mm
2 ft. 610 mm 4 ft. 1.2 m
3 ft. 914 mm 6 ft. 1.8 m
4 ft. 1.2 m 15 ft. 4.6 m
H
+ H2 MAX. =15 ft. (4.6 m)
1
V + H1 + H2 MAX. = 40 ft. (12.2 m)
H1 + H2 MAXIMUM
RAVE4013I-C
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
fl ex vent except when using the
simple up and out installation
(see Figure 7.3).
CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS
termination caps are not approved for use with propane (LP) fuel. May lead to elevated glass temperature that may cause tempered glass breakage.
H
V
1
2
H
1
INSTALLED
HORIZONTALLY
Figure 7.5
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1326
Page 27
1. Top Vent - Horizontal Termination - (continued)
Top Vent - Horizontal Termination
Venting with 3 elbows
RAVE4013I-C
Minimum H1 + H2 Maximum V
V
1
2
V1 + V2 Minimum
90° Elbow 6 ft. 1.8 m * *
1 ft. 305 mm 10 ft. 3.0 m * *
2 ft. 610 mm 12 ft. 3.7 m * *
3 ft. 914 mm 14 ft. 4.3 m * *
H1 + H2 MAX. =14 ft. (4.3 m)
*No specifi c restrictions on this value EXCEPT V1 + V2 + H cannot exceed 40 ft. (12.2 m)
V1 + V2 + H1 + H2 MAX. = 40 ft. (12.2 m)
CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS
termination caps are not approved for use with propane (LP) fuel. May lead to elevated glass temperature that may cause tempered glass breakage.
H
2
V
2
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
fl ex vent except when using the
simple up and out installation
(see Figure 7.3).
Figure 7.6
H
V
1
1
27Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 28
1. Top Vent - Horizontal Termination - (continued)
Top Vent - Horizontal Termination
Venting with 3 elbows
V Minimum
3 ft. 914 mm 15 ft. 4.6 m
H
+ H2 + H3 MAX. = 15 ft. (4.6 m)
1
V1 MAX. = 7 ft (2.1 m)
H1 + H2 + H3 MAXIMUM
RAVE4013I-C (NG ONLY)
INSTALLED
HORIZONTALLY
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
fl ex vent except when using the
simple up and out installation
(see Figure 7.3).
CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS
termination caps are not approved for use with propane (LP) fuel. May lead to elevated glass temperature that may cause tempered glass breakage.
H
2
V
1
Figure 7.7
H
1
H
3
INSTALLED
HORIZONTALLY
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1328
Page 29
Top Vent - Vertical Termination
No Elbows
V1 = 44 ft. Max. (13.4 m)
Note: If installing a vertical vent/termination of f the top of the
appliance, the optional exhaust restrictor may be needed.
Exhaust restrictor Instructions
1. Locate the two pilot holes located in the inside fi rebox
heat shield as shown in Figure 7.9.
2. Center the exhaust restrictor such that the through
holes in the vent restrictor align with the pilot holes in
the restrictor.
3. Use (2) ½” self-piercing screws to secure vent restrictor to fi rebox heat shield. See Figure 7.10.
Note: Use SLP Series
components only.
PILOT HOLES
Figure 7.9 Location of Pilot Holes
V
1
Figure 7.8 Vertical Vent Maximum
Exhaust restrictors are recommended for these vertically
terminated products which have excessive draft. Exhaust
restrictors will compensate for high draft, and restore visual fl ame height. If the vent confi guration has a total ver-
tical of 15-44 feet, an exhaust restrictor may be needed.
The exhaust restrictor can be located in the appliance
manual bag.
Figure 7.10 Exhaust Restrictor Installation
4. In some applications, such as those where the fi re-
place is elevated off the fl oor, the vent restrictor may
be painted, but painting is not required.
Notice: Before painting, contact your dealer for information on
the appropriate high temperature paint.
29Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 30
Top Vent - Vertical Termination
Venting with 2 elbows
RAVE4013I-C
Minimum H Maximum V
V
1
2
90° Elbow 2 ft. 610 mm * *
1 ft, 152 mm 3 ft. 914 mm * *
2 ft. 457 mm 5 ft. 1.5 m * *
3 ft. 914 mm 7 ft. 2.1 m * *
4 ft. 1.1 m 15 ft. 4.6 m * *
H MAX. =15 ft. (4.6 m)
V1 + V2 + H MAX. = 40 ft. (12.2 m)
* No specifi c restrictions on this value EXCEPT V1 + V2 + H cannot exceed 40 ft. (12.2 m)
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
fl ex vent except when using the
simple up and out installation
(see Figure 7.3).
V1 + V2 Minimum
V
2
V
H
1
1
Figure 7.11
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1330
Page 31
Top Vent - Vertical Termination
Venting with 3 elbows
RAVE4013I-C
Minimum H1 + H2 Maximum V
V
1
2
90° Elbow 1 ft. 305 mm * *
1 ft. 305 mm 2 ft. 610 mm * *
2 ft. 610 mm 4 ft. 1.2 m * *
3 ft. 914 mm 6 ft. 1.8 m * *
4 ft. 1.2 m 14 ft. 4.3 m * *
H MAX. =14 ft. (4.3 m)
V1 + V2 + H1 + H2 MAX. = 40 ft. (12.2 m)
* No specifi c restrictions on this value EXCEPT V1 + V2 + H1 + H2 cannot exceed 40 ft. (12.2 m)
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
V
2
fl ex vent except when using the
simple up and out installation
(see Figure 7.3).
V1 + V2 Minimum
Figure 7.12
H
1
H
2
INSTALLED
HORIZONTALLY
V
1
31Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 32
Top Vent - Vertical Termination
Venting with 4 elbows
Note: Use SLP Series
components only.
Note: There MUST be a 25%
reduction in total H when using
fl ex vent except when using the
simple up and out installation
(see Figure 5.3).
V1 MIN. H1 MAX. V2 MIN. H2 MAX. V3 MIN.
1-1/2 ft. 457 mm 4 ft. 1.2 m 4 ft. 1.2 m 4 ft. 1.2 m 3-1/2 ft. 1.0 m
V
+ V2 + V
1
V
3
H
2
+ H2 Maximum= 40 ft. (12.2 m)
3 + H1
V
2
H
1
V
1
Figure 7.13
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1332
Page 33
E
Coaxial to Colinear Venting
The coaxial to colinear adapter (DV-46DVA-GCL) is approved for installations into solid fuel masonry or factory
built fi replaces that have been installed in accordance
with the National, Provincial, State and local building
codes. The DV-46DVA-GCL must be recessed into existing masonry fi replace. See Table 1 and Figure 7.15.
INLET AIR VENT PIPE
Figure 7.14 Coaxial/Colinear Appliance Adapter (DV-46DVA-GCL)
EXHAUST VENT PIP
OUTSIDE FACE OF
FIREPLACE
EXHAUST VENT PIPE
TOP OF FIREPLACE
OPENING
5 IN. MIN.
3 IN. MIN.
SHADED AREA DEFINED AS
“INSIDE EXISTING MASONRY FIREPLACE”
Figure 7.15 Existing Fireplace DV-46DVA-GCL Clearance
Requirements
WARNING! Risk of Fire! Coaxial to colinear venting
confi guration may only be used in existing non-combus-
tible chimney. Installation in any other venting application
could cause fi re.
Prior to installing the gas appliance:
• Have the chimney and adjacent structure inspected
and cleaned by qualifi ed professionals. Hearth & Home
T echnologies recommends that NFI or CSIA certifi ed pro-
fessionals, or technicians under the direction of certifi ed
professionals, conduct a minimum of a NFP A 21 1 Level
2 inspection of the chimney.
• Replace component parts of the chimney and fi replace
as specifi ed by the professionals.
• Ensure all joints are properly engaged and the chimney
is properly secured.
Table 1
CLEARANCE TO COMBUSTIBLES REQUIREMENTS
DV-46DVA-GCL 3 IN.
Exhaust Vent Pipe 5 IN.
Clearances to Combustibles:
Refer to Section 5 for clearances to the appliance, mantel, mantel legs and wall projection.
Refer to Section 8 for pipe clearances to combustibles.
Termination Cap
For installation of termination cap see minimum vent
heights for various pitched roofs. See Section 6 of appliance owner’s manual.
Flue Damper
Fully lock the solid fuel fi replace’s fl ue damper in the open
position, OR completely remove it.
Venting Components
The LINK-DV30B is approved for use with the coaxial/colinear venting application. The LINK-DV30B kit includes:
• Two 30 feet sections of fl exible vent pipe (3 inches Ø).
One section is used to draw combustion air and the other
section is used to expel exhaust gases.
• One vertical termination cap.
CAUTION! DO NOT use any fl ue restrictor when vent-
ing with the DV-46DVA-GCL adapter and LINK-DV30B
kit. This may result in poor fl ame appearance, sooting,
pilot malfunction, or overheating.
33Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 34
Connecting the DV-46DVA-GCL Adapter to Appliance
Top Vent
• Remove top seal cap and insulation if equipped. See
Section 14, “Appliance Setup.” Attach the DV-46DVAGCL adapter to the appliance starting collar with 3-1/2
in. self-tapping screws. See Figure 7.16.
Connecting the LINK-DV30B to the DV-46DVA-GCL
adapter
• Insert the two sections of fl exible vent pipe down the
existing chimney.
• Attach one section of fl exible vent pipe to the exhaust
collar on top of the DV-46DVA-GCL adapter with three
self-tapping screws.
• Attach one section of fl exible vent pipe to the inlet collar
on top of the DV-46DVA-GCL adapter with three selftapping screws.
• To minimize cold air drafts, seal around the fl ex vents
at the damper inside the chimney with non-combustible
unfaced fi berglass or rock wool insulation.
The DV-46DVA-GCL adapter must be recessed into existing
masonry fi replace. This measurement is taken from the top
of the fi replace opening. See Table 1 and Figure 7.15.
WARNING! Risk of Fire, Explosion or Asphyxiation!
Do NOT connect this gas appliance to a chimney fl ue
serving a separate solid fuel or gas burning appliance.
• May impair safe operation of this appliance or other
appliances connected to the fl ue.
• Vent this appliance directly outside.
• Use separate vent system for this appliance.
CAUTION! DO NOT use any fl ue restric-
tor when venting with the DV-46DV A-GCL
adapter and LINK-DV30B kit. This may re-
sult in poor fl ame appearance, sooting, pilot
malfunction, or overheating.
NOTICE: To achieve optimum performance of appliance, minimize or
avoid bends in exhaust vent pipe.
EXISTING CHIMNEY
EXHAUST AIR
VENT PIPE
TOP VENT
TERMINATION CAP
V
INLET AIR
VENT PIPE
V
Minimum 10 ft. 3.05 m
Maximum 40 ft. 12.2 m
Figure 7.16
EXISTING CHIMNEY
DIRECT VENT FIREPLACE
FLOOR
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1334
HEARTH
To minimize cold air
drafts, seal with
non-combustible
insulation.
Page 35
* When using SLP pipe, minimum clearances from the vent pipe to combustible materi-
als at inside wall firestops are: Top: 2-1/2 in. (64 mm)
Bottom: 1/2 in. (13 mm)
Sides: 1 in. (25 mm)
Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm).
SLP heat shield - designed to be used on a wall 4-3/8 in. to 7-5/8 in. (111 mm to
194 mm thick).
,f wall thickness is less than 4-3/8 the e[isting heat shields must be field trimmed.
,f wall thickness is greater than 7-5/8 in. a '9P-HSM-B will be reTuired.
(SLP Pipe Shown)
3 in. (76 mm)
top clearance *
1 in. (25 mm)
clearance
bottom & sides
Heat
Shield
Wall
Shield
Firestop
Heat
Shield
WALL
3 in. (76 mm)
top clearance
1 in. (25 mm)
clearance around
vertical sections
8
8
Vent Clearances and Framing
A. Pipe Clearances to Combustibles
WARNING! Risk of Fire! Maintain air space clearance to
vent. DO NOT pack insulation or other combustibles:
• Between ceiling fi restops
• Between wall shield fi restops
• Around vent system
Failure to keep insulation or other material away from
vent pipe may cause over heating and fi re.
B. Wall Penetration Framing
Combustible Wall Penetration
Whenever a combustible wall is penetrated, you must
frame a hole for the wall shield fi restop(s). The wall shield
fi restop maintains minimum clearances and prevents cold
air infi ltration.
• The opening must be framed on all four sides using the
same size framing materials as those used in the wall
construction.
• SLP pipe - A wall shield fi restop must be placed on each
side of an interior wall. A minimum 1-1/2 in. (38 mm)
overlap of attached heat shields must be maintained.
• See Section 10.K for information for regarding the installation of a horizontal termination cap.
Non-Combustible Wall Penetration
If the hole being penetrated is surrounded by noncombustible materials such as concrete, a hole with diameter
one in. greater than the pipe is acceptable.
Whenever a non-combustible wall is penetrated, the wall
shield fi restop is only required on one side and no heat
shield is necessary.
Figure 8.1 Horizontal Venting Clearances To Combustible
Materials
DO NOT PACK WITH
INSULATION OR
OTHER MATERIAL
10 in.
10 in.
A
A* B
48-1/16 in. 47-1/16 in.
* Shows center of vent framing hole for top venting. The
center of the hole is one (1) in. (25.4 mm) above the
center of the horizontal vent pipe.
Figure 8.2 Wall Penetration
B
35Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 36
C. Install the Ceiling Firestop
A ceiling fi restop MUST be used between
fl oors and attics.
• SLP pipe only - Frame opening 9 in. x
9 in. (229 mm x 229 mm) whenever the
vent penetrates a ceiling/floor (see Figure
8.4).
• Frame the area with the same sized lumber
as used in ceiling/fl oor joist.
• The ceiling fi restop may be installed above or
below the ceiling joists when installed with a
attic insulation shield. It must be under joists
between fl oors that are not insulated. Refer
to Figure 8.5.
• Secure with three fasteners on each side.
WARNING! Risk of Fire! DO NOT pack insu-
lation around the vent. Insulation must be kept
back from the pipe to prevent overheating.
ATTIC ABOVE
A
A
Figure 8.4 Installing Ceiling Firestop
INSTALL ATTIC INSULATION SHIELDS
BEFORE OR AFTER INSTALLATION OF VENT SYSTEM
PIPE
SLP
A
9 in. (229 mm)
3 FASTENERS
PER SIDE
CEILING FIRESTOP
INSTALLED BELOW CEILING
Figure 8.5 Installing the Attic Shield
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1336
CEILING FIRESTOP
INSTALLED ABOVE CEILING
Page 37
D. Install Attic Insulation Shield
WARNING! Fire Risk. DO NOT allow loose materials or
insulation to touch vent. Hearth & Home Technologies requires the use of an attic shield.
The National Fuel Gas Code ANSI Z223.1 and NFPA 54
requires an attic shield constructed of 26 gauge minimum
metal that extends at least 2 in. (51 mm) above insulation.
Attic shields must meet specifi ed clearance and be se-
cured in place.
Flat Ceiling Installation
• Remove one shield from box.
NOTICE: Cut previously installed batt insulation to make
room for the attic insulation shield.
• Wrap shield around pipe if pipe is already installed in
area to be insulated.
• Match the three holes in each side and fasten with three
screws to form a tube.
• Bend three tabs on the bottom of the shield outward to
allow attachment to the ceiling fi restop.
• Bend the remaining bottom tabs inward 90° to maintain
the air space between the pipe and the shield. Set the
shield on the ceiling fi restop and attach to the fi restop.
• Bend all tabs inward 90° around the top of the shield.
These tabs must be used to prevent blown insulation
from getting between the shield and vent pipe, and to
maintain air space clearance.
BEND ALL TABS INWARD 90°
TO MAINTAIN CLEARANCE
AND PREVENT INSULATION
FROM FALLING INSIDE
INSERT 3
SCREWS
Figure 8.6 Attic Insulation Shield
BEND 3 TABS
OUTWARD TO
FASTEN TO CEILING
FIRESTOP-BEND
REMAINING TABS
INWARD 90 DEGREES
TO MAINTAIN
CLEARANCE
Vaulted Ceiling Installation
• Remove one shield from box.
NOTICE: Cut previously installed batt insulation to make
room for the attic insulation shield.
• Cut the attic insulation shield (if application is for vaulted
ceiling) to fi t your ceiling pitch. Snip cut edge to recreate
1 in. bend tabs all the way around the bottom.
• Wrap shield around pipe if pipe is already installed in
area to be insulated.
• Match the three holes in each side and fasten with three
screws to form a tube.
• Bend three tabs on the bottom of the shield outward to
allow attachment to the ceiling fi restop.
• Bend the remaining bottom tabs inward 90° to maintain
the air space between the pipe and the shield. Set the
shield on the ceiling fi restop and attach to the fi restop.
• Bend all tabs inward 90° around the top of the shield.
These tabs must be used to prevent blown insulation
from getting between the shield and vent pipe, and to
maintain air space clearance.
37Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 38
9
9
Appliance Preparation
A. Top Vent
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during installation. Sheet metal edges are sharp.
ELBOW HEAT SHIELD SHOWN
IN SHIPPING POSITION
ELBOW HEAT SHIELD
SHOWN AS INSTALLED
PIPE GASKET
Figure 9.1 Elbow Shield Shown as Shipped
If venting with a 90 degree elbow directly off of the top of
the appliance, the elbow heat shield must be repositioned
as shown in Figure 9.2.
If venting vertically or using a straight section of vertical
pipe, remove the elbow heat shield and discard by removing the two 1/4 in. screws that secure the elbow heat shield
to the top of the fi replace.
For all venting applications, ensure that the pipe gasket is
in place before attaching any pipe section. This gasket is
shipped in place around the starting collar. See Figure 9.2.
Figure 9.2 Elbow Shield Shown Installed
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1338
Page 39
B. Securing and Leveling the Appliance
WARNING! Risk of Fire! Prevent contact with:
• Sagging or loose insulation
• Insulation backing or plastic
• Framing and other combustible materials
Block openings into the chase to prevent entry of blown-
in insulation. Make sure insulation and other materials
are secured.
DO NOT notch the framing around the appliance
standoffs. Failure to maintain air space clearance may
cause overheating and fi re.
For details on setting the appliance in the framing, refer to
section 13.A. Figure 9.3 shows how to properly position,
level, and secure the appliance. Nailing tabs are provided
to secure the appliance to the framing members.
• Bend out nailing tabs on each side.
• Place the appliance into position.
• Keep nailing tabs fl ush with the framing.
• Level the appliance from side to side and front to back.
• Shim the appliance as necessary. It is acceptable to use
wood shims underneath the appliance.
• Secure the appliance to the framing by using nails or
screws through the nailing tabs.
• Secure the appliance to the fl oor by inserting two screws
through the pilot holes at the bottom of the appliance.
Figure 9.3 shows the fireplace installed on the floor.
However, this fireplace can be elevated off the floor
provided that the fi replace is properly supported by framing
materials and the ceiling clearances are maintained.
NAILING TABS
BOTH SIDES
Figure 9.3 Proper Positioning, Leveling And Securing Of
Appliance
39Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 40
10
10
Installing Vent Pipe (SLP Pipe)
A. Assemble Vent Sections
To attach the fi rst vent component to the starting collars
of the appliance:
• Lock the vent components into place by sliding the pipe
section onto the collar.
• Align the seam of the pipe and seam of collar to allow
engagement. Rotate the vent component to lock into
place. Use this procedure for all vent components. See
Figure 10.1.
• Slide the gasket over the fi rst vent section and place it
fl ush to the appliance. This will prevent cold air infi ltration.
Caulk with a minimum of 300ºF continuous exposure rating
may be used to hold the part in place.
• Continue adding vent components, locking each
succeeding component into place.
• Ensure that each succeeding vent component is securely
fi tted and locked into the preceding component.
Commercial, Multi-family (Multi-level exceeding two stories), or High-Rise Applications
For Installation into a commercial, multi-family (multi-level
exceeding two stories) or high-rise applications: All outer
pipe joints must be sealed with silicone with a minimum of
300ºF continuous exposure rating, including the slip section
that connects directly to the horizontal termination cap.
• Apply a bead of silicone sealant inside the female outer
pipe joint prior to joining sections. See Figure 10.2
• Only outer pipes need to be sealed. All unit collar, pipe,
slip section, elbow and cap outer fl ues shall be sealed
in this manner, unless otherwise stated.
Note: Align seams to engage pipe,
then rotate counterclockwise to lock
Figure 10.1 Adding Venting Components
Figure 10.2 High Temperature Silicone Sealant
WARNING! Risk of Fire or Explosion! DO NOT break
silicone seals on slip sections. Use care when removing
termination cap from slip pipe. If slip section seals are
broken during removal of the termination cap, vent may
leak.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1340
Page 41
B. Assemble Slip Sections
Pilot hole
• Slide the inner fl ue of the slip section into the inner fl ue of
the pipe section and the outer fl ue of the slip section over
the outer fl ue of the pipe section. See Figure 10.3.
• Slide together to the desired length.
Pilot hole
Figure 10.3 Slip Section Pilot Holes
• Maintain a 1-1/2 in. (38 mm) overlap between the slip
section and the pipe section.
• Secure the pipe and slip section with two screws no
longer than 1/2 in. (13 mm), using the pilot holes in the
slip section. See Figure 10.4.
C. Secure the Vent Sections
• Vertical runs originating off the top of the appliance, with
no offsets, must be supported every 8 ft. (2.44 m) after
the maximum allowed 25 ft. (7.62 m) of unsupported rise.
• Vertical runs originating off the rear of the appliance, or
after any elbow, must be supported every 8 ft. (2.44 m).
• Horizontal runs must be supported every 5 feet (1.52
m).
• Vent supports or plumbers strap (spaced 120º apart)
may be used to support vent sections. See Figures 10.5
and 10.6.
• Wall shield fi restops may be used to provide horizontal
support to vent sections.
• SLP ceiling fi restops have tabs that may be used to
provide vertical support.
WARNING! Risk of Fire, Explosion or Asphyxiation!
Improper support may allow vent to sag and separate.
Use vent run supports and connect vent sections per installation instructions. DO NOT allow vent to sag below
connection point to appliance.
Figure 10.4 Screws into Slip Section
• Continue adding pipe as necessary following instructions
in “Assembling Pipe Sections.”
NOTICE: If slip section is too long, the inner and outer fl ues
of the slip section can be cut to the desired length.
NOTICE: When installing a vent system with an HRC
termination cap, all pipe system joints shall be sealed using
a silicone sealant with a minimum of 300ºF continuous
exposure rating.
• Apply a bead of silicone sealant inside the female outer
pipe joint prior to joining sections.
• Only outer pipes are sealed, sealing the inner fl ue is not
required.
• All unit collar, pipe, slip section, elbow and cap outer fl ues
shall be sealed.
Figure 10.5 Securing Vertical Pipe Sections
Figure 10.6 Securing Horizontal Pipe Sections
41Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 42
D. Disassemble Vent Sections
• Rotate either section (see Figure 10.7) so the seams on
both pipe sections are aligned as shown in Figure 10.8.
• Pull carefully to separate the pieces of pipe.
• Lower the support box through the hole in the roof until its
bottom is at least 2 in. (51 mm) below the ceiling (Figure
10.9).
• Level the support box both vertically and horizontally and
temporarily tack it in place through the inside walls into
the roof sheathing.
• Use tin snips to cut the support box from the top corners
down to the roof line and fold the resulting fl aps to the
roof. See Figure 10.10.
• Nail the fl aps to the roof AFTER running a bead of non
hardening sealant between the fl aps and the roof.
WARNING! Risk of Fire! Clean out ALL materials from
inside the support box and complete the vertical vent run
and termination.
LEVEL
Figure 10.7 Rotate Seams for Disassembly
Figure 10.8 Align and Disassemble Vent Sections
E. Install Decorative Ceiling Components
A decorative ceiling thimble can be installed on a fl at ceil-
ing through which the vent passes. The decorative ceiling
thimble is used to cover the fi restop.
• Seal the gap between the vent pipe and fi restop using
silicone sealant with a minimum of 300ºF continuous
exposure rating to prevent cold air infi ltration.
• Install the decorative ceiling thimble by sliding it up to
the ceiling and attaching it using the provided screws.
A decorative cathedral ceiling support box can be installed
on a cathedral ceiling through which the vent passes.
• Use a plumb-bob to mark the center line of the venting
system on the ceiling and drill a small hole through the
ceiling and roof at this point. Locate the hole and mark
the outline of the cathedral ceiling support box on the
outside roof.
• Remove shingles or other roof covering as necessary to
cut the rectangular hole for the support box. Cut the hole
1/8 in. (3 mm) larger than the support box outline.
CATHEDRAL CEILING
SUPPORT BOX
2 in. (51 mm) MIN. BELOW
FINISHED CEILING
CUT HOLE 1/8 in. (3 mm)
GREATER IN SIZE THAN
PATTERN OF SUPPORT
BOX AS IT IS PROJECTED
ONTO ROOF LINE
Figure 10.9
Figure 10.10
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1342
Page 43
F. Install Metal Roof Flashing
Figure 10.13 Assembling the Storm Collar
Figure 10.14 Assembling the Storm Collar Around the Pipe
• See minimum vent heights for various pitched roofs
(Figure 10.1 1) to determine the length of pipe to extend
through the roof.
• Slide the roof fl ashing over the pipe sections extending
through the roof as shown in Figure 10.12.
HORIZONTAL
OVERHANG
CAULK
2 FT.
MIN.
GAS DIRECT VENT
TERMINATION CAP
Roof Pitch H (Min.) Ft.
Flat to 6/12........................................1.0*
Over 6/12 to 7/12 ............................1.25*
Over 7/12 to 8/12 ..............................1.5*
Over 8/12 to 9/12 ..............................2.0*
Over 9/12 to 10/12 ............................. 2.5
Over 10/12 to 11/12 ......................... 3.25
Over 11/12 to 12/12 ........................... 4.0
Over 12/12 to 14/12 ........................... 5.0
Over 14/12 to 16/12 ........................... 6.0
Over 16/12 to 18/12 ........................... 7.0
Over 18/12 to 20/12 ........................... 7.5
Over 20/12 to 21/12 ........................... 8.0
20 INCHES MIN.
LOWEST
DISCHARGE
OPENING
X
12
ROOF PITCH
H (MIN.) - MINIMUM HEIGHT FROM ROOF
TO LOWEST DISCHARGE OPENING
* 3 foot minimum in snow regions
VERTICAL
WALL
IS X/ 12
Figure 10.12
G. Assemble and Install Storm Collar
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during installation. Sheet metal edges are sharp.
• Connect both halves of the storm collar with two screws
(see Figure 10.13).
• Wrap the storm collar around the exposed pipe section
closest to the roof and align brackets. Insert a bolt
(provided) through the brackets and tighten the nut to
complete the storm collar assembly . Make sure the collar
is tight against the pipe section.
• Slide the assembled storm collar down the pipe section
until it rests on the roof fl ashing (see Figure 10.14).
• Caulk around the top of the storm collar (see Figure 10.15).
Figure 10.11 Minimum Height From Roof To Lowest Discharge
Opening
NOTICE: Failure to properly caulk the roof fl ashing and
pipe seams may permit entry of water.
• Caulk the gap between the roof fl ashing and the outside
diameter of the pipe.
• Caulk the perimeter of the fl ashing where it contacts the
roof surface. See Figure 10.12.
• Caulk the overlap seam of any exposed pipe sections
that are located above the roof line.
Figure 10.13 Assembling the Storm Collar
Figure 10.14 Assembling the Storm Collar Around the Pipe
43Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 44
H. Install Vertical Termination Cap
• Attach the vertical termination cap by sliding the inner
collar of the cap into the inner fl ue of the pipe section
while placing the outer collar of the cap over the outer
fl ue of the pipe section.
• Secure the cap by driving three self-tapping screws
(supplied) through the pilot holes in the outer collar of the
cap into the outer fl ue of the pipe (see Figure 10.15).
TERMINATION CAP
(1 of 3)
STORM
COLLAR
SCREWS
CAULK
Figure 10.15
I. Install Decorative Wall Components
A decorative wall thimble can be installed on wall through
which the vent passes. The decorative wall thimble is used
to cover the fi restop.
• Slide the decorative wall thimble over the last section of
horizontal pipe before connecting the termination cap to
the pipe.
• Once the pipe section and the termination cap have been
connected, slide the wall thimble up to the interior wall
surface and attach with screws provided. See Figure
10.16.
J. Heat Shield Requirements for Horizontal
Termination
WARNING! Risk of Fire! To prevent overheating and fi re,
heat shields must extend through the entire wall thickness.
• DO NOT remove the heat shields attached to the
wall shield fi restop and the horizontal termination cap
(shown in Figure 10.17).
• Heat shields must overlap 1-1/2 in. (38 mm) minimum.
There are two sections of the heat shield. One section
is factory-attached to the wall shield fi restop. The other
section is factory-attached to the cap. See Figure 10.17.
If the wall thickness does not allow the required 1-1/2 in.
(38 mm) heat shield overlap when installed, an extended
heat shield must be used.
• If the wall thickness is less than 4 in./102 mm (DVP)
or 4-3/8 in./ 111 mm (SLP), the heat shields on the cap
and wall shield fi restop must be trimmed. A minimum
1-1/2 in. (38 mm) overlap MUST be maintained.
• Use an extended heat shield if the fi nished wall thickness
is greater than 7-1/4 in. (184 mm).
• The extended heat shield may need to be cut to length
maintaining suffi cient length for a 1-1/2 in. (38 mm)
overlap between heat shields.
• Attach the extended heat shield to either of the existing
heat shields using the screws supplied with the extended
heat shield. Refer to vent components diagrams in the
back of this manual.
• Rest the small leg on the extended heat shield on top
of the pipe section to properly space it from the pipe
section.
Important Notice: Heat shields may not be fi eld constructed.
Figure 10.16 Wall Thimble
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1344
Page 45
K. Install Horizontal Termination Cap
WARNING! Risk of Fire! The telescoping fl ue section
of the termination cap MUST be used when connecting
vent.
• 1-1/2 (38 mm) minimum overlap of fl ue telescoping
section is required.
Failure to maintain overlap may cause overheating and
fi re.
• Vent termination must not be recessed in the wall. Siding
may be brought to the edge of the cap base.
• Flash and seal as appropriate for siding material at
outside edges of cap.
• When installing a horizontal termination cap, follow
the cap location guidelines as prescribed by current
ANSI Z223.1 and CAN/CGA-B149 installation codes
and refer to Section 6 of this manual.
CAUTION! Risk of Burns! Local codes may require installation of a cap shield to prevent anything or anyone
from touching the hot cap.
NOTICE: For certain exposures which require superior
resistance to wind-driven rain penetration, a fl ashing kit and
HRC caps are available. When penetrating a brick wall, a
brick extension kit is available for framing the brick.
Note: When using terminatio n caps w ith fac tor y- suppli ed heat
shield attached, no additional wall shield fi restop is required on
the exterior side of a combustible wall.
HEAT SHIELD OR
EXTENDED
WALL SHIELD
FIRESTOP
INNER VENT
OUTER VENT
Figure 10.17 Venting through the wall
HEAT SHIELD
SLIP SECTION
CAN BE EXTENDED
INTERIOR
HEAT SHIELD
1-1/2 IN. (38 MM) MIN.
OVERLAP
SHEATHING
EXTERIOR
45Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 46
11
11
Gas Information
A. Fuel Conversion
• Make sure the appliance is compatible with available gas
types.
• Conversions must be made by a qualified service
technician using Hearth & Home T echnologies specifi ed
and approved parts.
B. Gas Pressure
• Optimum appliance performance requires proper input
pressures.
• Gas line sizing requirements will be determined in ANSI
Z223.1 National Fuel Gas Code in the USA and CAN/
CGA B149 in Canada.
• Pressure requirements are:
Gas Pressure Natural Gas Propane
Minimum inlet pressure 5.0 in. w.c. 11.0 in. w.c.
Maximum inlet pressure 10.0 in. w.c. 13.0 in. w.c.
Manifold pressure 3.5 in. w.c. 10.0 in. w.c.
WARNING! Risk of Fire or Explosion! High pressure
will damage valve. Low pressure may cause explosion.
• Verify inlet pressures. Verify minimum pressures when
other household gas appliances are operating.
• Install regulator upstream of valve if line pressure is
greater than 1/2 psig.
PILOT BRACKET SCREWS
MEDIA TRAY/BASE PAN
ASSEMBLY SCREWS
Figure 11.1 Cover Tray Removal
Access Through the Valve Assembly
The lower access cover panel is removable if fi nishing
material has not been previously installed.
Remove Media Tray, Burner Assembly, and Base pan.
To access components:
1. Remove eleven screws around perimeter of valve
plate that secure valve plate to the fi rebox bottom.
See Figure 11.2.
2. Lift the valve plate from the back so that the gas valve
can clear the valve plate hole in the bottom the fi rebox.
See Figure 11.3.
WARNING
Fire Risk.
Explosion Hazard.
High pressure will damage valve.
• Disconnect gas supply piping BEFORE
pressure testing gas line at test pressures
above 1/2 psig.
• Close the manual shutoff valve BEFORE
pressure testing gas line at test pressures
equal to or less than 1/2 psig.
Note: This appliance does include a manual gas shutoff valve
that is located in the valve compar tment. This manual gas
shutoff valve is accessible for service by removing the base
pan, burner assembly and valve plate. See Figure 11.1.
The lower access cover panel is removable if fi nishing
material has not been previously installed.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1346
Figure 11.2. Remove Valve Plate Screws
Figure 11.3. Remove Valve Plate
3. Set the valve bracket on the front lip of the fi rebox bot-
tom. Turn “off” the ball valve. Disconnect gas valve
from the gas fl ex ball valve assembly at the pressure
fi tting. See Figure 11.4.
Page 47
Figure 11.4. Disconnect Gas Valve
4. Lift the valve assembly up and out to make necessary
service or repair.
Note: Install the gas supply line in accordance with local
codes, if any. If not, follow ANSI 223.1. Installation should
be done by a qualifi ed installer approved and/or licensed
as required by the locality. (In the Commonwealth of
Massachusetts installation must be performed by a
licensed plumber or gas fi tter).
Note: A listed (and Commonwealth of Massachusetts approved) 1/2 in. (13 mm) T-handle manual shut-off valve
and fl exible gas connector are connected to the 1/2 in. (13
mm) control valve inlet.
• If substituting for these components, please consult
local codes for compliance.
Valve Pressure Taps
The pressure taps are available through the front of the
appliance. The decorative mesh front and fi replace gas
assembly must be removed to gain access to the pressure
taps. See Figure 11.5.
C. Gas Connection
• Refer to Section 16 for location of gas line access in
appliance.
• Gas line may be run through knockout(s) provided.
• The gap between supply piping and gas access hole may
be caulked with caulk with a minimum of 300ºF continuous
exposure rating or stuffed with non-combustible, unfaced
insulation to prevent cold air infi ltration.
• Ensure that gas line does not come in contact with outer
wrap of the appliance. Follow local codes.
• Pipe incoming gas line into valve compartment.
• Connect incoming gas line to the 1/2 in. (13 mm)
connection on manual shutoff valve.
WARNING! Risk of Fire or Explosion! Support control
when attaching pipe to prevent bending gas line.
• A small amount of air will be in the gas supply lines.
WARNING! Risk of Fire or Explosion! Gas build-up dur ing line purge could ignite.
• Purge should be performed by qualified service
technician.
• Ensure adequate ventilation.
• Ensure there are no ignition sources such as sparks
or open fl ames.
Light the appliance. It will take a short time for air to purge
from lines. When purging is complete the appliance will
light and operate normally.
WARNING! Risk of Fire, Explosion or Asphyxiation!
Check all fi ttings and connections with a non-corrosive
commercially available leak-check solution. DO NOT use
open fl ame. Fittings and connections could have loos-
ened during shipping and handling.
WARNING! Risk of Fire! DO NOT change valve settings.
This valve has been preset at the factory.
PRESSURE TAPS
Figure 11.5 Valve Pressure Taps and Remote Receiver Location
Note: The manifold and inlet pressure tabs can be ac-
cessed from the front of the fi replace when valve assembly
is installed.
OPTIONAL REMOTE
RECEIVER
D. High Altitude Installations
NOTICE: If the heating value of the gas has been reduced,
these rules do not apply. Check with your local gas utility
or authorities having jurisdiction.
When installing above 2000 feet elevation:
• In the USA: Reduce burner orifi ce 4% for each 1000 feet
above 2000 feet.
• In CANADA: Reduce burner orifi ce 10% for elevations
between 2000 feet and 4500 feet. Above 4500 feet,
consult local gas utility.
47Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 48
12
12
Electrical Information
A. Wiring Requirements
NOTICE: This appliance must be electrically wired
and grounded in accordance with local codes or, in the
absence of local codes, with National Electric Code
ANSI/NFPA 70-latest edition or the Canadian Electric
Code CSA C22.1.
• Wire the appliance junction box to 110-120 VAC. This is
required for use of optional accessories (standing pilot
ignition) or proper operation of the appliance (IntelliFire
ignition).
• A 1 10-120 V AC circuit for this product must be protected
with ground-fault circuit-interrupter protection, in
compliance with the applicable electrical codes, when
it is installed in locations such as in bathrooms or near
sinks.
• Low voltage and 110-120 V AC voltage cannot be shared
within the same wall box.
WARNING! Risk of Shock or Explosion! DO NOT wire
1 10V to the valve or to the appliance wall switch. Incorrect
wiring will damage controls.
B. IntelliFire Ignition System Wiring
• Wire the appliance junction box to 110-120 VAC for
proper operation of the appliance.
WARNING! Risk of Shock or Explosion! DO NOT wire
IPI controlled appliance junction box to a switched circuit.
Incorrect wiring will override IPI safety lockout.
• Refer to Figure 12.2, IntelliFire Pilot Ignition (IPI) Wiring
Diagram.
• This appliance is equipped with an IntelliFire control valve
which operates on a 3 volt system.
• Plug the 3-volt AC transformer into the appliance junction
box to supply power to the unit OR install two D cell
batteries (not included) into the battery pack before
use.
NOTICE: Batteries should not be placed in the battery
pack while using the transformer. Remove batteries
before using the transformer, and unplug the transformer
before installing the batteries. Battery polarity must be
correct or module damage will occur.
C. Optional Accessories Requirements
• This appliance may be used with a wall switch, wall
mounted thermostat and/or a remote control.
NOTE: Install optional remote receiver adjacent to battery
pack. See Figure 11.5.
Wiring for optional Hearth & Home T echnologies approved
accessories should be done now to avoid reconstruction.
Follow instructions that come with those accessories.
Optional Remote Control Receiver and Battery Pack
Location
Batteries are to be installed only when battery power is
required. Because of the limited accessibility to valve
cavity , the position of the battery pack, IPI control module,
and optional remote control receiver locations must be
installed as shown in Figure 12.1.
The battery pack, control module, and remote control
receiver can be accessed through the air space between
the fi rebox front and the lower-front fi nishing cover
panel. The decorative front and glass assembly must be
removed to access these components.
The battery pack is attached with velcro to the inside of
the lower cover panel. The IPI control module and the
remote control receiver are placed on the fi rebox bottom.
Figure 12.1 Valve Cavity
GAS VALVE
CONTROL MODULE GROUND
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1348
CONTROL
MODULE
DC ADAPTER
BATTERY
PACK
Page 49
IGNITION MODULE 3 VAC INTERMITTENT PILOT IGNITOR
I
S
TRANSFORMER
PLUG IN
3 VAC
RED
WIRE ASSEMBLY
BLACK
WIRES
(TO BROWN)
ORANGE
GROUND TO
FIREPLACE
CHASSIS
Note: There is an alternative access to the junction box.
This can be accessed by removing the valve assembly . See
Section 11.
HOT
BATTERY PACK
Figure 12.2 IntelliFire Pilot Ignition (IPI) Wiring Diagram with Wall Switch or Thermostat
NEUTRAL
D. Electrical Service and Repair
WARNING! Risk of Shock! Label all wires prior to disconnection when servicing controls. Wiring errors can
cause improper and dangerous operation. Verify proper
operation after servicing.
WHITE
ORANGE
VALVE
GREEN
NOTE: 1. Ignition module, valve, pilot, and
wall switch operate on 3 volts. 120 VAC is
required at junction box unless equipped
with battery back-up.
WARNING! Risk of Shock! Replace damaged wire with
type 105° C rated wire. Wire must have high temperature
insulation.
E. Junction Box Installation
1. Bend junction box heat shield to the right along the
perforated hand bends.
2. Remove the one screw located in front of the junction
box.
3. Remove the plastic electrical knockout slug in the top
of the junction box.
4. Install wire strain (not included) and route wire through
wire strain fi tting.
5. Make the connections inside the junction box to the
120V wire. Connect the green wire to the ground nut,
the black wire to the black wire and the white wire to
the white wire.
6. Reinstall the junction box.
7. Reposition the junction box heat shield such that it is
positioned over the junction box.
49Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 50
13
13
Finishing
A. Framing and Finishing Instructions
WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specifi ed. Framing closer than the
minimums listed must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc.)
Finishing Instructions
It is important to follow the framing and fi nishing instruc-
tions to ensure proper placement of fi replace into the sur-
rounding framing/fi nishing materials.
Wall sheathing materials 1/2 in. thick are specifi ed in
this installation manual to properly align with the factoryinstalled non combustible material.
WARNING! Risk of Fire! DO NOT remove the factoryinstalled non-combustible board or cover it with combustible material, such as:
• Drywall (gypsum board)
• Plywood
• Materials that do not meet the ASTM E 136 Non-combustibility standard (below).
Removal of factory-installed, non-combustible board and/
or use of materials not meeting the ASTM E 136 standard
may cause fi re.
FACTORY-INSTALLED
NON-COMBUSTIBLE BOARD
NAILING
TABS
Non-Combustible Materials Specifi cation
Material which will not ignite and burn. Such materials are
those consisting entirely of steel, iron, brick, tile, concrete,
slate, glass or plasters, or any combination thereof.
Materials that are reported as passing ASTM E 136,
Standard Test Method for Behavior of Materials in
a Vertical Tube Furnace at 750 ºC shall be considered
non-combustible materials.
Setting the Fireplace into the Framing
Unlike many traditional, single-sided Heatilator fi replaces,
this fi replace is recessed into surround framing. The left
and right nailing tabs were designed for the RA VE4013I-C
model as a means to ensure the fi replace is recessed to
the correct location within the framing materials.
1. Bend two nailing tabs away from fi replace 180 degrees
on both left and right nailing tabs. See Figure 13.1.
2. Screw each nailing tab to the adjoining framing ma-
terial. Ensure that the 1 inch air space clearance is
maintained on the sides of the fi replace.
Figure 13.1 Nailing Tabs Installation Position
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1350
Page 51
WARNING! Risk of Fire! Maintain specifi ed air space
clearances to combustibles.
Failure to comply with these instructions may cause a
fi re or cause the appliance to overheat.
PILOT HOLES (11 LOCATIONS) TO ATTACH
NON-COMBUSTIBLE BOARD TO FRAMING
FACTORY-INSTALLED
NON-COMBUSTIBLE BOARD
LOWER COVER PANEL
= 1 INCH. MAX. SELF-TAPPING SCREWS ALLOWED
= NO SCREWS ALLOWED
= 5 INCH - 7 INCH SELF-TAPPING SCREWS ALLOWED
Note: It is acceptable to use a silicone sealant with a
minimum of 300ºF continuous exposure rating to adhere
drywall to lower cover panel.
Figure 13.2 Finishing Details
CAUTION! Risk of Glass Damage and Cuts! DO NOT
drill or install any type of screw or fastener into the lower
cover panel. Sharp screw or fastener tips may penetrate
and break the glass or cause cuts.
Do not drill or install screws which may penetrate the lower cover panel as this will restrict required access to the
glass, battery-back-up, and remote receiver. See Figure
13.2.
The appliance is designed to accept 1/2 in. wall sheathing
materials such as drywall, plywood, wood composites, or
non-combustible materials. The type of material used depends whether the installation is an Inside or Overlap Fit
Method. Refer to Section 13.C regarding installation details associated with the Inside and Overlap Fit methods.
Requirements for fi nishing to bottom of fi replace opening
are specifi c to decorative fronts as follows:
DECO: Non-combustible fi nish materials maybe installed
up to the fi replace opening, covering lower fi nishing
fl ange.
ILLUSION: Requires a minimum of 1 inch clearance to
the non-combustible fi nishing material from the bottom
fi replace opening. See Figure 13.9.
The factory-supplied non-combustible board must be
used in all installations. It must be directly attached to
structural framing adjacent to the appliance. Screw fasteners should be installed in the pilot holes provided in
the outer perimeter of the non-combustible board. See
Figure 13.2.
The factory-supplied board is designed such that its edges will be at the approximate center of the adjacent framing, assuming it is 1-1/2 in. nominal thickness. This will
allow the wallboard joints to occur on the center of the
framing where the panels can be fastened properly . If the
framing thickness is less than 1-1/2 in. nominal, such as
with formed steel systems, then it may be necessary to
adjust the adjacent framing dimensions so that the noncombustible board and wallboard joints are centered on
the framing.
Note: Refer to Section 13.C regarding installation details
associated with the Inside and Overlap Fit methods.
The RAVE4013I-C must be fi nished using either the
Deco or Illusion decorative fronts. See Figures 13.11
and 13.12. The fi nal fi replace installation can be accom-
plished by either the Overlap Fit or Inside Fit method.
Reference Section 13.C regarding installation details associated with the Inside Fit and Overlap Fit methods.
It is acceptable to pre-drill holes and use self-tapped
screws in the factory-installed non-combustible board to
attach non-combustible backer board for tile, marble, etc.
Refer to Figure 13.2 for acceptable screw location and
screw length requirements.
Self-tapping screws, up to one inch long, can be installed
through the nailing tab and outer three inch edges of the
factory-installed non-combustible board to secure the
drywall adjacent to the factory-installed non-combustible
board. See Figure 13.2.
51Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 52
• For the initial Taping Coat, it is critical that a generalpurpose chemically hardening joint compound, such
as SHEETROCK™ Brand Durabond™ Setting-Type
Joint Compound, be used to fi ll the joint and embed
the mesh tape. Fiberglass-mesh tape is recommended
because it will provide a more crack-resistant joint
than one fi nished with paper tape. Let the Taping
Coat properly cure before applying subsequent Finish
Coats.
FIREPLACE OPENING
15-7/8 IN. TO 16-1/8 IN.
Figure 13.3. Required Fireplace Opening Height
Verify that the lower cover panel is installed correctly, and
that the fi replace opening height is between 15-7/8 in. and
16-1/8 in. See Figure 13.3.
Note: The lower cover panel must be pushed all the way
down. The outer fi nishing fl anges should line up. The
fi replace opening must be between 15-7/8 in. and 16-1/8
in. for the decorative fronts to fi t correctly. See Figure
13.3.
Finish and Sealing Joints
All joints between the fi nished wall sheating and the
appliance must be sealed with non-combustible materials.
Sealants, such as caulk or mastic used to seal the gap
between the wall and the fi replace, should be rated at
a minimum continuous exposure to 300°F. Wall board
joints can be taped and sealed with combustible drywall
tape.
Finishing Around Opening with Gypsum Wallboard
Gypsum wallboard (drywall) joints adjacent to the fi replace
opening require special attention to minimize potential
development of cracking. Hearth and Home Technologies
recommends the following steps to minimize potential
cracks in the fi nished drywall around the fi replace opening:
• When installing gypsum wallboard around the fi replace,
install the hole for the fi replace opening in a single
wallboard sheet, if possible. This will minimize the joints
adjacent to the fi replace opening.
• The factory-supplied non-combustible board and the
gypsum wallboard must join on the structural framing,
where applicable. Wallboard and non-combustible board
should be fastened to the framing with at least 1-1/4 in.
long screw fasteners, located within 1-1/2 in. from each
corner, and at no more than 12 inch intervals along the
joint length.
• The wall-board joints should be fi nished with a Taping
Coat, followed by at least two subsequent Finish Coats
of joint compound.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1352
• For the second and third fi nishing coats, it is acceptable
to use a light-weight joint compound and standard
application, curing and sanding methods.
• Do not operate the fi replace during the drywall fi nishing
process. Allow the fi nish coat to cure for at least 24
hours prior to using the appliance.
Painting
If desired fi nishing includes a painted wall, 100%
acrylic latex with compatible primer is recommend
around the appliance. Oil-based or standard
acrylic paints may discolor due to heat exposure.
Wallboard Joint-Crack Prevention and Repair
Wallboard joints around the fi replace will be affected
by exposure to elevated temperatures, along with
other environmental and structural factors. The specifi c
methods presented in the previous section will help
prevent or minimize development of cracks.
If a crack does emerge adjacent the fi replace, it can be
permanently repaired by fi lling it with spackling paste or
paintable latex caulk, followed by repainting.
Page 53
B. Mantel and Wall Projections
WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specifi ed. Framing closer than the
minimums listed must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc.)
Failure to comply could cause fi re.
Note: For non-combustible fi replace fi nish material (marble,
stone, etc) specifi cations refer to Section 13.C.
Combustible Mantel Legs Or Wall Projections
Extending Past The Face Of The Fireplace
Combustible Mantels
1/2 IN.
Thick Wall
Sheathing
12 IN.
MAX.
MEASUREMENT
14 IN.
MIN.
FROM TOP OF
FIREPLACE
OPENING
Figure 13.4 Clearances To Combustibles Mantels Or Other
Combustibles Above Appliance
Non-combustible Mantels
1/2 IN.
Thick Wall
Sheathing
12 IN.
MAX.
2 IN.
FIREPLACE
OPENING
Figure 13.6 Combustible Mantel Leg or Wall Projections
(Acceptable on both sides of opening)
MINIMUM
6 IN.
MINIMUM
3 FT. MAXIMUM
Non-combustible Mantel Legs Or Wall Projections
Extending Past The Face Of The Fireplace
3 IN.
FIREPLACE
OPENING
Figure 13.7 Non-Combustible Mantel Leg or Wall Projections
(Acceptable on both sides of opening)
MINIMUM
7 IN.
UNLIMITED
14 IN.
MIN.
MEASUREMENT
FROM TOP OF
FIREPLACE
OPENING
1 IN.MIN.
4 IN.
MAX.
Figure 13.5 Clearances To Non-Combustible Mantels Or Other
Non-Combustibles Above Appliance
53Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 54
C. Facing Material
• Facing and/or fi nishing materials must not interfere with
air fl ow through louvers, operation of louvers or doors,
or access for service.
• Facing and/or fi nishing materials must never overhang
into the glass opening.
• Observe all clearances when applying combustible
materials.
WARNING! Risk of Fire! DO NOT apply combustible
materials beyond the minimum clearances. Comply with
all minimum clearances to combustibles as specifi ed in
this manual. Overlapping materials could ignite and will
interfere with proper operation of doors and louvers.
WARNING! Risk of Fire! DO NOT install drywall or other
combustible materials over the factory-installed non-combustible board. Overlapping materials could ignite.
Decorative facing material thickness is measured from
the face of the factory-installed non-combustible board.
See Figure 13.8.
Non-Combustible Finish Materials
0 - 1 inch Thickness-Overlap Fit Method
Both the Deco and Illusion decorative fronts are designed
to overlap fi nish materials 0 inches to 1 inch thick. See
Figure 13.8.
NOTICE: This one inch maximum not only includes the
decorative fi nish materials (marble, tile, slate, etc) but also
the thinset, and adhesive used to attach the decorative
fi nish material.
The non-combustible fi nish material can be installed up
to the fi replace opening covering the top, left and right
fi nishing fl anges. See Figure 13.8.
Requirements for fi nishing to bottom of fi replace opening
are specifi c to decorative fronts as follows:
DECO: Non-combustible fi nish materials maybe installed
up to the fi replace opening, covering lower fi nishing
fl ange.
ILLUSION: Requires a minimum of 1 inch clearance to
the non-combustible fi nishing material from the bottom
fi replace opening. See Figure 13.9.
1-1/2 IN. ABOVE STANDOFF
DRYWALL OR
EQUIVALENT (1/2 IN.)
FACTORY-INSTALLED
NON-COMBUSTIBLE BOARD
NON-COMBUSTIBLE
FINISHING MATERIAL
0 - 1 IN. THICK
DECO DECORATIVE
FRONT SHOWN
NON-COMBUSTIBLE
FINISHING MATERIAL
0 - 1 IN. THICK
BOTTOM
SIDE PLATE
STOP
RETURN BEND
1 IN. MIN.
LOWER
ILLUSION
FRONT
OPTIONAL FINISH MATERIAL
Figure 13.9. Illusion Front, Side View - Bottom Side Plate
Installed Over Lower Cover Panel
1/2 IN. BUILDING MATERIAL
COVER PANEL
Reference dimensions for the Deco and Illusion fronts installed
on the appliance are shown in Figure 13.14 and Figure 13.15.
Figure 13.8 Overlap Fit Method (Deco or Illusion Decorative Front)
Both the Deco and Illusion decorative fronts can be installed with an “Overlap” or “Inside Fit” method:
Overlap Requirement: See Figure 13.8 and 13.9
Inside Fit requirement: See Figure 13.10.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1354
Page 55
Non-Combustible Finish Materials
0 Inches to 4 Inches Thick Inside Fit Method
The Deco and Illusion decorative fronts are approved for
inside fi t applications. Non-combustible fi nishing materi-
als up to 4 inches thick can be installed around the front
(left, right, top, and bottom).
For inside fi t applications, the decorative front must be in-
stalled tight to the fi nishing fl anges and must not overlap
any fi nish material.
The Deco front requires a 1/2 inch clearance between
the outer edge of the decorative front and inside edge of
the surrounding fi nish materials. HHT recommends that
the front be temporarily installed as a template, traced to
ensure the fi nishing materials will fi t properly, and then
removed.
Reference dimensions for the Deco and Illusion fronts installed
on the appliance are shown in Figure 13.13 and Figure 13.14.
FACTORY-INSTALLED
NON-COMBUSTIBLE
BOARD
0 - 4 IN.
20-1/2 IN. APPLIANCE
OPENING (HEIGHT)
3/4 IN.
3 IN.
0 - 4 IN.
DRYWALL OR
EQUIVALENT
(1/2 IN.)
Figure 13.10 Inside Fit Method (Deco Decorative Front Only)
55Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 56
D. Decorative Fronts
WARNING! Risk of Fire! A decorative front is required
for this model. DO NOT operate this appliance without a
decorative front in place.
Only doors certifi ed for use with this appliance model may
be used. Contact your dealer for a list of doors that may
be used.
F
E
A
Figure 13.11 Deco Decorative Front
Inside and Overlap Fit
See Section 13.C.
Inside and Overlap Fit
See Section 13.C.
B
C
D
Figure 13.13. Dimensions of Deco Decorative Front
Table 1. Dimensions of Deco Decorative Front
Top of decorative front to bottom of
A
appliance.
Bottom of decorative front to bottom of
B
appliance.
Inside dimension of decorative front
C
(width).
Outside dimension of decorative front
D
(width).
Inside dimension decorative front
E
(height).
Outside dimension of decorative front
F
(height).
27-1/2 in. 699 mm
5-3/8 in. 137 mm
39 in. 991 mm
45 in. 1143 mm
13 in. 330 mm
22-1/8 in. 562 mm
Figure 13.12 Illusion Decorative Front
A
B
C
D
Figure 13.14. Dimensions of Illusion Decorative Front
Table 2. Dimensions of Illusion Decorative Front
Top of decorative front to bottom of
A
appliance.
Bottom of decorative front to bottom
B
of appliance.
Inside dimension of decorative front
C
(width).
Outside dimension of decorative
D
front (width).
Inside dimension decorative front
E
(height).
Outside dimension of decorative
F
front (height).
26-7/16 in. 672 mm
6-7/8 in. 175 mm
39 in. 991 mm
44-1/2 in. 1130 mm
13 in. 330 mm
19-1/2 in. 495 mm
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1356
Page 57
14
14
A. Remove Fixed Glass Assembly
See Section 14.E.
B. Remove the Shipping Materials
Remove shipping materials from inside or underneath the
fi rebox. The standard black rock media and manual bag
assembly are also shipped underneath the fi rebox.
C. Clean the Appliance
Clean/vacuum any sawdust that may have accumulated
inside the fi rebox or underneath in the control cavity.
D. Accessories
Install approved accessories per instructions included
with accessories. Contact your dealer for a list of ap-
proved accessories.
WARNING! Risk of Fire and Electric Shock! Use ONLY
Hearth & Home Technologies-approved optional accessories with this appliance. Using non-listed accessories
could result in a safety hazard and will void the warranty.
Appliance Setup
57Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 58
E. Fixed Glass Assembly
WARNING! Risk of Asphyxiation! Handle fi xed glass
assembly with care. Inspect the gasket to ensure it is
undamaged and inspect the glass for cracks, chips or
scratches.
• DO NOT strike, slam or scratch glass.
• DO NOT operate fi replace with glass removed, cracked,
broken or scratched.
• Replace as a complete assembly.
Removing Fixed Glass Assembly
1. Remove the decorative front.
2. Locate the two spring latches that are on the upper
left and right of the fi replace.
3. Use both index fi ngers to release spring latches. See
Figure 14.1.
4. Allow glass to tilt forward. Grasp glass on the upper
right and left sides and lift glass “up” and “out.”
Replacing Fixed Glass Assembly
1. Locate glide tabs on lower left and right corners.
2. Grasp glass on upper right and left sides and tilt bot-
tom of glass assembly toward fi replace.
3. Allow of the bottom gasketing of the glass assembly
to touch the face of the fi replace.
4. Put pressure on the glass as you allow the glass
assembly to drop into the two lower glass clips. See
Figure 14.1.
5. Tilt top of glass towards fi replace and engage both
top spring latches
F. Install the Mesh
The mesh front is included with the Deco and Illusion
fronts.
1. Remove fi xed glass assembly as instructed.
2. Place glass assembly into mesh screen such that the
four mesh clips attached to the mesh assembly snap
into the four corresponding slots on the fi xed glass as-
sembly.
G. Air Shutter Setting
Air shutter settings may be adjusted by a qualifi ed install-
er at the time of installation. The air shutter is set at the
factory for minimum vertical vent run. Adjust air shutter for
longer vertical runs. See Figure 14.2.
• Loosen the 1/4 in. screw.
• Twist shutter to adjust.
• Shutter may be opened for longer horizontal vent runs.
• Do not close the air shutter more than the settings
specifi ed below.
• Tighten the screw.
NOTICE: If the fl ames appear to be orange, open the air
shutter to prevent residue buildup on the glass.
UPPER SPRING LATCH
LOWER GLASS CLIP
Figure 14.1 Fixed Glass Assembly
Figure 14.2 Air Shutter
Air Shutter Settings
NG LP
RAVE4013I-C 3/16 in. 9/16 in.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1358
Page 59
15
15
Troubleshooting
With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do
experience a problem, this troubleshooting guide will assist a qualifi ed service technician in the diagnosis of a problem and
the corrective action to be taken. This troubleshooting guide can only be used by a qualifi ed service technician. Contact
your dealer to arrange a service call by a qualifi ed service technician.
A. IntelliFire Ignition System
Symptom Possible Cause Corrective Action
1. Pilot won’t light.
The ignitor/module
makes noise, but no
spark.
2. Pilot won’t light,
there is no noise or
spark.
a. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor
are connected to correct terminals on module and pilot assembly.
b. Loose connections or electrical
shorts in the wiring.
c. Ignitor gap is too large. Verify gap of igniter to right side of pilot hood. The gap should be
d. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove
a. No power or transformer installed
incorrectly.
b. A shorted or loose connection in wir-
ing confi guration or wiring harness.
Verify no loose connections or electrical shorts in wiring from
module to pilot assembly. Verify connections underneath pilot assembly are tight; also verify connections are not grounding out to
metal chassis, pilot burner, pilot enclosure, mesh screen if present,
or any other metal object.
approximately .17 in. or 1/8 in. (3 mm).
ignitor wire “I” from module. Place a grounded wire about 3/16 in. (5
mm) away from “I” terminal on module. Place ON/OFF rocker switch
or wall switch in ON position. If there is no spark at “I” terminal
module must be replaced. If there is a spark at “I” terminal, module
is fi ne. Inspect pilot assembly for shorted sparker wire or cracked
insulator around electrode. Replace pilot if necessary .
Verify that transformer is installed and plugged into module. Check
voltage of transformer under load at spade connection on module
with ON/OFF switch in ON position. Acceptable readings of a good
transformer are between 3.2 and 2.8 volts AC.
Remove and reinstall the wiring harness that plugs into module.
Verify there is a tight fi t. Verify pilot assembly wiring to module. Re-
move and verify continuity of each wire in wiring harness. Replace
any damaged components.
3. Pilot sparks, but
Pilot will not light.
c. Improper wall switch wiring. Verify that 110-120 VAC power is “ON” to junction box.
d. Module not grounded. Verify black ground wire from module wire harness is grounded to
metal chassis of appliance.
e. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Re-
move ignitor wire “I” from module. Place ON/OFF rocker switch
or wall switch in ON position. If there is no spark at “I” terminal
module must be replaced. If there is a spark at “I” terminal, module
is fi ne. Inspect pilot assembly for shorted sparker wire or cracked
insulator around electrode.
a. Gas supply. Verify that incoming gas line ball valve is “open”. Verify that inlet
pressure reading is within acceptable limits, inlet pressure must
not exceed 14 in. W.C.
b. Ignitor gap is incorrect. Verify that spark gap from ignitor to pilot hood is .17 in. or 1/8 in (3 mm).
c. Module is not grounded. Verify module is securely grounded to metal chassis of appliance.
d. Module voltage output / Valve/Pilot
solenoid ohms readings.
Verify battery voltage is at least 2.7 volts. Replace batteries if volt-
age is below 2.7.
59Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 60
IntelliFire Ignition System - (continued)
Symptom Possible Cause Corrective Action
4. Pilot lights but continues to spark, and main
burner will not ignite.
(If the pilot continues
to spark after the
pilot fl ame has been lit,
fl ame rectifi cation has
not occurred.)
a. A shorted or loose connection in fl ame
sensing rod.
b. Poor fl ame rectifi cation or contaminated
fl ame sensing rod.
c. Module is not grounded. Verify module is securely grounded to metal chassis of
d. Damaged pilot assembly or contami-
nated fl ame sensing rod.
e. Module. Turn ON/OFF rocker switch or wall switch to OFF position.
Verify all connections to wiring diagram in manual. Verify
connections underneath pilot assembly are tight. Verify
connections are not grounding out to metal chassis, pilot
burner, pilot enclosure or screen if present, or any other
metal object.
With fi xed glass assembly in place, verify that fl ame is en-
gulfi ng fl ame sensing rod on left side of pilot hood. Flame
sensing rod
rect pilot orifi ce is installed and gas inlet is set to pressure
specifi cations. Polish fl ame sensing rod with fi ne steel wool
to remove any contaminants that may have accumulated
on fl ame sensing rod.
appliance. Verify that wire harness is fi rmly connected to
the module.
Verify that ceramic insulator around the fl ame sensing rod
is not cracked, damaged, or loose. Verify connection from
fl ame sensing rod to white sensor wire. Polish fl ame sens-
ing rod with fi nes steel wool to remove any contaminants
that may have accumulated on fl ame sensing rod. Verify
continuity with a multimeter with ohms set at lowest range.
Replace pilot if any damage is detected.
Remove ignitor wire “I” from module. Place ON/OFF rocker
switch or wall switch in ON position. If there is no spark at
“I” terminal module must be replaced. If there is a spark at
“I” terminal, module is fi ne.
should glow shortly after ignition. Verify cor-
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1360
Page 61
16
16
G
Q
L
H
O
F
P
N
Ø
I
J
K
M
S R
GAS LINE
ACCESS
LEFT VIEW RIGHT VIEW
1 INCH STANDOFF
ELECTRICAL
ACCESS
FRONT VIEW
A
B
C
D
E
T
U
Reference Materials
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5.
Location Inches Millimeters
A 48 1218
B 43 1092
C 39-1/16 993
D 13-1/4 337
E 39-5/8 1006
F 3-9/16 90
G 6-7/8 174
H 47-1/16 1195
I 9-5/16 237
J 16-3/4 425
Location Inches Millimeters
K125
L 37-3/4 959
M 15-3/4 400
N 6-5/8 168
O 41-3/4 1060
P 2-3/16 55
Q 6 152
R 17-1/4 438
S 18-1/4 464
T 25-7/8 657
U 9-3/4 248
Figure 16.1 Appliance Dimensions
61Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 62
B. Vent Components Diagrams
6-1/2 in.
165 mm
8-3/4 in.
222 mm
6 in.
152 mm
6-1/2 in.
165 mm
6-1/2 in.
165 mm
9-1/4 in.
235 mm
6-5/8 in.
168 mm
SLP-45 - 45° Elbow
Effective
Height/
Length
SLP-PIPE
8-11/16 in.
220 mm
Effective Height/Length
Pipe
SLP4 4 102
SLP6 6 152
SLP12 12 305
SLP24 24 610
SLP36 36 914
SLP48 48 1219
SLP6A 2 - 6 51 - 152
SLP12A 2 - 12 51 - 305
SLP-FLEX-2 24 610
SLP-FLEX-3 36 914
SLP-FLEX-5 60 1524
SLP-FLEX-10 120 3048
inches mm
6-5/8 in.
168 mm
9-7/8 in.
251 mm
SLP90- 90° Elbow
EFFECTIVE HEIGHT/
LENGTH
SLP-FLEX-PIPE
26 in.
660 mm
8-11/16 in.
220 mm
SLP-FS
Ceiling Firestop
10-7/8 in.
276 mm
8-7/8 in.
225 mm
SLP-HVS
Horizontal Pipe
Support
Figure 16.2 SLP Series Vent Components
1-1/2 in.
38 mm
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1362
1-1/2 in.
38 mm
12 in.
305 mm
DVP-HSM-B
Extended Heat Shield
12 in.
305 mm
5-1/2 in.
146 mm
SLP-WS
Wall Shield Firestop
Page 63
B. Vent Components Diagrams (continued)
10-11/16 in.
271mm
12 in.
305 mm
28-1/2 in.
724 mm
13 in.
330 mm
13-1/2 in.
343 mm
SLK-SNKD
Snorkel
Termination Cap
13 in.
330 mm
SLP-DCF-BK
Ceiling Firestop
Black
1-5/16 in.
34 mm
14-7/16 in.
367 mm
12-1/2 in.
318 mm
SLP-TVHW
Vertical
Termination Cap
14-7/16 in.
367 mm
2-5/16 in.
59 mm
SLP-WT-BK
Wall Thimble-Black
14 in.
356 mm
10-9/16 in.
269 mm
SLP-CCS-BK
Cathedral Ceiling
Support Box-Black
Figure 16.3 SLP Series Vent Components
3-15/16 in.
(101 mm)
6-11/16 in.
(169 mm)
8 in.
(203 mm)
3-15/16 in.
(101 mm)
3-13/16 in.
(97 mm)
5-1/16 in.
(128 mm)
SL-2DVP
Adapter
63Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 64
15-1/8 in.
(384 mm)
Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be
used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm)
the existing heat shields must be field trimmed. If wall thickness is greater than 7-1/4 in. (184 mm) a
DVP-HSM-B will be required.
8 in.
(203 mm)
Heat
Shield
15 in.
(381 mm)
12 in.
(305 mm)
8-1/8 in.
(206 mm)
Term Cap
Max
Effective
Trap1
Length
SLP-TRAP
Trap2
Horizontal Termination Cap
13 in.
(330 mm)
Effective Length
5-3/4 to 8-3/8 in.
146 to 213 mm
5-1/2 in.
140 mm
87°
CAUTION: THE SLP-HRC-SS AND SLP-HRC-ZC-SS
TERMINATION CAPS ARE NOT APPROVED FOR
USE WITH PROPANE (LP) FUEL. May lead to elevated glass temperature that may cause tempered
glass breakage.
SLP-HRC-SS
SLP-HRC-ZC-SS
HORIZONTAL TERMINATION CAP
Minimum
Effective Length
3-1/8 in. 4-3/4 in.
79 mm 121 mm
5-1/4 in. 9-1/4 in.
133 mm 235 mm
8-3/8 in.
213 mm
3°
10-1/2 in.
267 mm
Maximum
Effective Length
10-7/8 in.
276 mm
15-1/2 IN.
394 mm
SLP90
Figure 16.4 SLP Series Vent Components
SL-2DVP
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1364
7 IN.
178 mm
DVP-FBHT
12 IN.
305 mm
DVP-FBHT
Page 65
B. Vent Components Diagrams (continued)
PVI-SLP
13-5/8 IN.
346 mm
12-1/2 IN.
318 mm
20-3/4 IN.
527 mm
PVI-SLP
Power Vent Inline
Optional Wire Harness
DESCRIPTION PART NUMBER
10 ft. PV Wire Harness PVI-WH10
20 ft. PV Wire Harness PVI-WH20
40 ft. PV Wire Harness PVI-WH40
60 ft. PV Wire Harness PVI-WH60
80 ft. PV Wire Harness PVI-WH80
100 ft. PV Wire Harness PVI-WH100
Note: Wire harnesses required to power the PVI-SLP
connect to the appliance and are ordered separately
from PVI-SLP. Contact your dealer to order.
12-1/2 IN.
(318 mm)
16 IN.
406 mm
4-1/2 IN.
9-3/16 IN.
(233 mm)
13-5/8
(346 mm)
114 mm
16-11/16 IN.
424 mm
SLP-LPC
SLP Low Profi le Cap
COAXIAL to COLINEAR VENTING
15 IN.
(381 mm)
16-11/16 IN.
(424 mm)
LINK-DV30B
Flex Liner Kit
Figure 16.5 Vent Components
DVP-2SL
Adapter
DV-46DVA-GCL
Coaxial/Colinear Appliance Connector
65Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 66
B. Vent Components Diagrams
14 in.
(356 mm)
2-3/4 in.
(70 mm)
13-7/8 in.
(352 mm)
DRC-RADIUS
9-1/2 in.
(241 mm)
Cap Shield
9 in.
(229 mm)
11-1/2 in.
(292 mm)
12-1/4 in.
(311 mm)
16 in.
(406 mm)
PVK-80
(For use with IPI and DSI appliances only.)
12-1/2 in.
(318 mm)
7-1/8 in.
(181 mm)
13-7/8 in.
(352 mm)
11-5/8 in.
(295 mm)
12-1/8 in.
(308 mm)
5-3/4 in.
(146 mm)
11-7/8 in.
(302 mm)
DVP-BEK2
DVP-HPC Cap Brick Extension
COOL-ADDM
Cap Shield
5 in.
(127 mm)
Figure 16.6 Vent Components
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1366
Page 67
C. Service Parts List
Service Parts
RAVE4013i-C
42” Gas Fireplace - DV
1
3
4
2
6
5
Beginning Manufacturing Date: June 2012
Ending Manufacturing Date: Active
7
8
9
10
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Sheet Rock Ledge
2 Lower Cover Panel
3 Top Panel Finish Edge 2292-102
4
5
6 Base Pan 2292-010
7 Burner Assembly 2292-007
8
9
10 Bracket, Junction Box 2195-154
11
Additional service part numbers appear on following page. 2/13
Non Combustible Board
Tray, Clean Cover
Glass Door Assembly
Junction box
Nailing Tab
Qty 2 req 2198-200
2184-147
2184-103
2198-405
2293-117
GLA-SLR
4021-013
11
Stocked
at Depot
Y
Y
Y
67Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 68
Service Parts
RAVE4013i-C
Beginning Manufacturing Date: June 2012
Ending Manufacturing Date: Active
#12 Valve Assembly
12.6
12.4
12.5
12.8
12.1
12.3
12.2
12.7
12.15
12.14
12.13
12.12
12.11
12.10
12.9
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
12.1
12.2
12.3
12.4 Valve Bracket
12.5
12.6 Male Connector Pkg of 5 303-315/5 Y
12.7 Module Wire Assembly
12.8 Thermostat Wire Assembly
12.9 Flex Ball Valve Assembly
12.10
12.11
12.12
12.13
12.14
12.15 Pilot Bracket
Pilot Hood 2269-123
Pilot Assembly NG
Pilot Assembly LP
Orifi ce NG (#42C)
Orifi ce LP (.057C)
Valve NG 593-500 Y
Valve LP 593-501 Y
3 Volt Transformer 593-593A Y
Battery Pack 593-594A Y
Module 593-592 Y
Bulkhead W/Flex Tube 383-302A Y
Grommet 21 18-420
2090-012 Y
2090-013 Y
582-842 Y
582-057 Y
2269-153
593-590A Y
2118-170 Y
531-320A Y
2292-127
Additional service part numbers appear on following page.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1368
Page 69
Service Parts
Beginning Manufacturing Date: June 2012
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
ITEM DESCRIPTION COMMENTS PART NUMBER
Elbow Heat Shield
Exhaust Restrictor
Gasket Assembly
Contains burner neck, shutter bracket, vent, seal cap, valve plate, and air passage gaskets
Glass Latch Assembly
Heat Shield, Inner
Touch Up Paint
Wall Switch Kit
Pkg of 2 33858/2
RAVE4013i-C
2143-168
530-299
2113-080
2198-130
TUP-GBK-12
WSK-21-W
Stocked
at Depot
Y
Conversion Kit NG
Conversion Kit LP
Pilot Orifi ce NG 593-528
Pilot Orifi ce LP 593-527
Regulator NG NGK-DXF
Regulator LP LPK-DXF
N/A
LPK-RAVE-C
Y
Y
Y
Y
Y
69Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Page 70
D. Contact Information
Heatilator, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.heatilator.com
Please contact your Heatilator dealer with any questions or concerns.
For the location of your nearest Heatilator dealer,
please visit www.heatilator.com.
- NOTES -
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
NOTICE
DO NOT DISCARD THIS MANUAL
• Important operating
and maintenance
instructions included.
• Read, understand and follow
these instructions for safe
installation and operation.
• Leave this manual with
party responsible for use
and operation.
his product may be covered by one or more of the following patents: (United States) 5601073, 5613487, 5647340,
890485, 5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122,
098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending.
2000-945B
Printed in U.S.A. - Copyright 2013
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/1370
Loading...
