qvi30fb
GAS FIREBRICK® FIREPLACE
TOP OF UNIT
MANTEL
12"
MAX.
12" MIN.
Town Square with cabinet doors shown in
29-3/8"
13-3/4"
18"
6-1/2"
21-1/4"
3-9/16"
ELECTRICAL
ACCESS
(IF EQUIPPED)
22-1/8"
black. Also available in hammered pewter.
Sun Prairie with cabinet doors shown in
hammered pewter. Also available in black.
FireBrick® technology from Quadra-Fire offers you a stunning
new alternative for upgrading your existing fireplace. Utilizing
a new patented process, the firebox and interior brick lining are
molded from FireBrick material to capture that traditional wood
fireplace look. This seamless firebox
construction also allows us to use larger
glass, giving you a better view into
those soothing flames and logs. This
quiet and durable material is extremely
efficient. FireBrick pushes the heat into the room instead of
absorbing and losing heat into the fireplace itself. Three front
options are available in several finishes to help you complement
your original fireplace and room décor. The model qvi30fb will
operate during an electrical power outage and is the best choice
for high efficiency and heat output in mid-size fireplaces.
Standard Features
396 sq. in. of viewing glass•
High efficiency FireBrick firebox•
Variable speed blower (160 cfm)•
Six-piece glowing log set•
Tapered firebox•
Decorative andirons•
Adjustable flame•
Affinity Arch available only
in black
Quiet operation•
Bedroom approved•
Options
7 available fronts•
Affinity Arch – Chapel Hill −
Sun Prairie – Town Square −
Tudor Panel – Tuscan Bar −
Remington Avenue −
3 panel sizes•
Standard (40" x 27") −
Medium ( 40" x 32") −
Large (44" x 32") −
Adjustable hearth support•
Cutting edge surround•
3 remote controls, including •
On/Off with digital thermostat
control
2 wall thermostats•
Cover photo: qvi30fb shown with Remington front in black
finish and cutting edge surround
Chapel Hill shown in hammered
pewter. Also available in black and
sienna bronze
Tudor Panel shown in black with
antique pewter accents. Also available in black, sienna bronze & sienna
bronze with antique copper accents.
Tuscan Bar shown in sienna bronze
with antique copper bars & brackets.
Also available in black with antique
pewter bars & brackets.
qvi30fb
Dimensions
Clearances
MINIMUM FIREPLACE SIZE
Location inches millimeters
Front Width 30-1/4 768
Rear Width 19 483
Depth 14-1/8 359
Height* 22-1/2 572
*NOTE: If exhaust collar on insert and fireplace damper do
not line up, add 4 inches (102 mm) to minimum fireplace
height for bends in vent pipe.
Technical & Performance Data
Width (front)• ......... 29 3/8"
Width (back)• ................18"
Height (back)• .........21 1/4"
Depth• ....................13 3/4"
Heating Capacity• * .....................................up to 1,800 sq. ft.
BTU Input NG• ............................................. 27,000 – 38,000
BTU Input LP• ...............................................22,000 – 36,000
Efficiency• * ......................................... up to 79% NG/81% LP
Canadian EnerGuide Efficiencies• ........43.17% NG/46.17% LP
The strongest in the industry, Quadra-Fire provides a
limited lifetime warranty on gas-burning products for their
most important aspects: firebox and heat exchanger.
For full warranty details go to www.quadrafire.com
IMPORTANT - READ BEFORE YOU INSTALL!
Refer to the Owner/Installation Manual for complete clearance requirements and specifications. The
images and descriptions in this brochure are provided to assist you in product selection only.
*Heating capacity rating and efficiencies are to be used as a guideline only. Actual performance may
differ slightly due to climate, building construction and condition, amount and quality of insulation,
location of the heater, and air movement in the room.
Quadra-Fire is a registered trademark of Hearth & Home Technologies. Product specifications and
pricing subject to change without notice. The Quadra-Fire qvi30fb direct vent gas fireplace heater is
listed by Underwriters Laboratories and is approved for Canada and USA to ANSI Z21.88-2002/CSA
2.33-2002, Vented Gas Fireplace Heaters, and UL307B.
Available From:
Shipping Weight• ...... 110 lbs.
Flue Size• ........Dual 3" Direct
Vent Chimney
Liner
1445 North Highway, Colville, WA 99114
www.quadrare.com•800-926-4356
QDF-1013U-1108
