Novus
Direct Vent & B-Vent Series
Shown with optional Demi front, traditional refractory,
Plymouth mantel and absolute black granite
The Most Demanded Gas
Fireplace in the Industry!
• Voted a Consumers Digest Best Buy!
• New sleek, clean lines create a streamlined fireplace
appearance homeowners are demanding
• Choose from four sizes, 30", 33", 36" and 42"
wide viewing widths
• Direct vent and B-vent choices available for all
sizes and styles
• New, more realistic gas log configuration increases
flame height and creates a more exposed ember bed
• All four sizes possess the same log configuration to
create a consistent appearance across the Novus
family
• Choice of three optional fronts, ceramic fiber
refractory, fan and controls
• Top/rear direct vent to simplify ordering and
installation
• Depth is value — 19-1/8" deep firebox on all models
• Heater listed to ANSI Z21.88 standards
• Btu/hour input -
30"-20,000/14,000
33"-22,000/15,000
36"-25,000/17,000
42"-30,000/20,500
• Certified for installation in bedrooms; direct vent
models also certified for mobile homes
• Direct vent models preserve Indoor Air Quality
(IAQ) and provide efficient zone heating
30" Novus shown with Camden cast surround
IntelliFire
• With IntelliFire, there’s no need for a constantly-
burning pilot, saving the homeowner from extra
expense
• When the fireplace is turned on, the pilot lights
first then ignites the main burner; when the fireplace is not operating, the pilot also shuts down
• e IntelliFire system may be wired for 120V or
operate with two D size batteries (not included)
for operation during a power outage
™
Exceptional Value
36" Novus shown with Plymouth mantel and
absolute black granite
Dependability
Model A B C
Mantel
A
19-5/8 in.
34-7/8 in.
Electrical
Access
Alternative
Gas Access
1-3/4 in.
34-1/2 in.
1-1/2 in.
15-3/4 in.
8 in.
2-3/8 in.
31-1/2 in.
34 in.
A
B
23-1/2 in.
6-1/2 in.
C
19-1/8 in.
11-5/8in.
Gas Line
Access
3 in.
A
19-1/8 in.
11-5/8 in.
C
Rear vent
One 45° elbow
Horiz Term
Rear Vent
Two 90° elbows
Horiz Term
Rear Vent
One 90° elbow
Vert Term
Top Vent
One 90° elbow
Horiz Term
No elbows
Horiz Term
A
A
A
A
A
A
C
B
B
E
F
D
1/2 in. min.
appliance to
combustibles
D
F
1 in.
min. pipe to
combustibles
E
1/2 in.
min. appliance
to combustibles
Alcove
Installation
C
1 in.
min. pipe to
combustibles
G
Drywall
48 in.
maximum
NDV/NBV3630 35" 30" 8-5/8"
NDV/NBV3933 38" 33" 11-5/8"
NDV/NBV4236 41" 36" 14-5/8"
NDV/NBV4842 47" 42" 20-5/8"
Novus
Technical Specifications
DV Top
BV Top
Extremely tight
corner fit!
NDV/NBV3630
NDV/NBV3933
Model
NDV/NBV4236
NDV/NBV4842
The rough framing dimensions shown represent the distance from stud to stud only and do not take into consideration the addition of drywall. Please
refer to installation instructions for complete specifications and drawings when installing this product. Go to www.heatilator.com to download.
A
Rough
Opening
(width)
36"
39"
42"
48"
Model A B C D E F G
NDV3630 36" 33-1/2" 19-5/8" 43-3/8" 47" 53-1/4" 37"
NDV3933 39" 35-1/2" 19-5/8" 43-3/8" 47" 53-1/4" 40"
NDV4236 42" 37-5/8" 19-5/8" 43-3/8" 47" 53-1/4" 43"
NDV4842 48" 41-7/8" 19-5/8" 43-3/8" 47" 53-1/4" 49"
Most Recognized Brand
Novus
Models Available*
Opening Sizes Venting Ignition Systems Fuel
30" Direct Vent IntelliFire Natural Gas
33" B-Vent Standing Pilot LP Gas
36"
42"
Options
Demi Operable Front
*Consult your Heatilator MSRP book for a complete list of models.
Finish options shown here available
for the Demi and Tres fronts (also
available in Black)
Demi Non-Operable
Pewter
Front
Bronze
Tres Operable Front
Options Not Pictured
Remote Controls and Wall Switches
•
Fan Kit
•
Outside Air Kit (for B-vent models only)
•
Gas Conversion Kits
•
Mantels and Surrounds
•
For a complete listing of Options, see Heatilator MSRP book
A V A I L A B L E F R O M
Traditional Refractory Herringbone Refractory
Venting
Direct Vent: DVP pipe
B-Vent: 5" B-vent pipe
a brand of Hearth & Home Technologies Inc.
1915 West Saunders Street
Mt. Pleasant, Iowa 52641
800-927-6841 • heatilator.com
