Page 1

Model(s):

EDV3633, EDV3633L, EDV3633I, EDV3633IL

Direct Vent Gas Appliance

Owner’s Manual

Installation and Operation

CAUTION

DO NOT DISCARD THIS MANUAL

•

• Important operating and maintenance instructions included.

Read, understand and follow these instructions for safe installation and operation.

WARNING

If the information in these instructions is not followed exactly, a ﬁ re may result causing property damage, personal injury, or death.

• Do not store or use gasoline or other ﬂ am- mable vapors and liquids in the vicinity of this or any other appliance.

• What to do if you smell gas:

- Do not try to light any appliance.

- Do not touch any electrical switch. Do not use any phone in your building.

- Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

- If you cannot reach your gas supplier, call the ﬁ re department.

• Installation and service must be performed by a qualiﬁ ed installer, service agency, or

the gas supplier.

This appliance may be installed as an OEM installation in manufactured home (USA only) or mobile home and must be installed in accordance with the manufacturer’s instructions and the manufactured home construction and safety standard, Title 24 CFR, Part 3280 or Standard for

Installation in Mobile Homes, CAN/CSA Z240MH.

This appliance is only for use with the type(s) of gas indicated on the rating plate.

DO NOT

DISCARD

•

Leave this manual with party responsible for use and operation.

WARNING

HOT SURFACES!

Glass and other surfaces are hot during operation and cool down.

Hot glass will cause burns.

• Do not touch glass until it is cooled

• NEVER allow children to touch glass

• Keep children away

• CAREFULLY SUPERVISE children in same room as appliance.

• Alert children and adults to hazards of high temperatures.

High temperatures may ignite clothing or other ﬂ ammable materials.

• Keep clothing, furniture, draperies and other combustibles away.

This appliance has been supplied with an integral barrier to prevent direct contact with the ﬁ xed glass panel. Do NOT operate the appliance with the barrier removed.

Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one.

In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas ﬁ tter;

See Table of Contents for location of additional Commonwealth of Massachusetts requirements.

Installation and service of this appliance should be performed by qualiﬁ ed personnel. Hearth & Home Technologies suggests NFI certiﬁ ed or factory-trained professionals, or technicians supervised by an NFI certiﬁ ed professional.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 1

Page 2

Read this manual before installing or operating this appliance.

Please retain this owner’s manual for future reference.

A. Congratulations

Congratulations on selecting a Heatilator gas ﬁ replace, an elegant and clean alternative to wood burning ﬁ replaces. The Heatilator gas ﬁ replace you have selected is designed to provide the utmost in safety, reliability, and efﬁ ciency.

As the owner of a new ﬁ replace, you’ll want to read and carefully follow all of the instructions contained in this owner’s manual. Pay special attention to all cautions and warnings.

Homeowner Reference Information

This owner’s manual should be retained for future reference. We suggest that you keep it with your other important documents and product manuals.

The information contained in this owner’s manual, unless noted otherwise, applies to all models and gas control systems.

Your new Heatilator gas ﬁ replace will give you years of durable use and trouble-free enjoyment. Welcome to the Heatilator family of ﬁ replace products!

We recommend that you record the following pertinent information about your ﬁ replace.

Model Name: ___________________________________________ Date purchased/installed: __________________

Serial Number: __________________________________________ Location on ﬁ replace: _____________________

Dealership purchased from: _______________________________ Dealer Phone: __________________________

Notes: _______________________________________________________________________________________

_____________________________________________________________________________________________

Listing Label Information/Location

Hearth & Home Technologies Inc

1915 W. Saunders Street Mt. Pleasant, IA 52641

Model #

ANSI Standard

MODEL MFG. DATE MODÈLE DATE DE FAB.

GAS TYPE/TYPE DE GAZ NATURAL/NATUREL PROPANE ALTITUDE 0-2000 2000-4000 FT/PI 0-2000 2000-4000 FT/PI MAX INPUT/DÉBIT XX,XXX XX,XXX BTUH XX,XXX XX,XXX BTUH MIN INPUT/DÉBIT XX,XXX XX,XXX BTUH XX,XXX XX,XXX BTUH MANIFOLD PRESSURE/PRESSION TUBULAIRE MAX. XX IN. W.C./C. D'EAU XX IN. W.C./C. D'EAU MIN. XX IN. W.C./C. D'EAU XX IN. W.C./C. D'EAU MIN. INLET PRESS. XX IN. W.C./C. D'EAU 1XX IN. W.C./C. D'EAU FOR THE PURPOSE OF INPUT ADJUSTMENT PRESS. MIN. D'ALIMENTATION ORIFICE SIZE DIAM. DE L'INJECTEUR XX/XX DIA. in./mm XX/XX DIA. in./mm

LESS THAN/MOINS DE 3 AMPÈRES., 115V., 60 Hz

DO NOT REMOVE OR COVER THIS LABEL. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL. FOYER À GAZ À ÉVACUATION - NE DOIT PAS ÊTRE UTILISÉ AVEC UN COMBUSTIBLE SOLIDE.

XXXXXX

The model information regarding your speciﬁ c ﬁ replace can be found on the rating plate usually located in the control area of the ﬁ replace.

Gas Type

SERIAL NO. DE SÉRIE

Serial #

XXXXXXXXX

XXXX

CERTIFIED

FOR CANADA

CERTIFIÉ POUR LE

CANADA

Orifice Size

Heatilator • Eclipse • 4049-229 Rev F • 11/082

Page 3

Safety Alert Key:

• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.

• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.

• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

• NOTICE: Used to address practices not related to personal injury.

Table of Contents

A. Congratulations 2 B. Warranty 5

1 Listing and Code Approvals

A. Appliance Certiﬁ cation 7 B. Tempered Glass Speciﬁ cations 7 C. BTU Speciﬁ cations 7 D. High Altitude Installations 7 E. Non-Combustible Materials Speciﬁ cation 7 F. Combustible Materials Speciﬁ cation 7 G. Electrical Codes 7 H. Requirements for the Commonwealth of Massachusetts 8

User Guide

2 Operating Instructions

A. Gas Fireplace Safety 9 B. Your Fireplace 9 C. Fan Kit 10 D. Clear Space 10 E. Fixed Glass Assembly 10 F. Remote Controls, Wall Controls and Wall Switches 10 G. Before Lighting Fireplace 10 H. Lighting Instructions (IPI) 11 I. Lighting Instructions (Standing Pilot) 12 J. After Fireplace is Lit 13 K. Frequently Asked Questions 13

3 Maintenance and Service

A. Maintenance Tasks-Homeowner 14 B. Maintenance Tasks-Qualiﬁ ed Service Technician 15

Installer Guide

4 Getting Started

A. Typical Appliance System 17 B. Design and Installation Considerations 18 C. Tools and Supplies Needed 18 D. Inspect Appliance and Components 18

5 Framing and Clearances

A. Selecting Appliance Location 19 B. Constructing the Appliance Chase 20 C. Clearances 20 D. Mantel and Wall Projections 21

6 Termination Locations

A. Vent Termination Minimum Clearances 22

7 Vent Information and Diagrams

A. Approved Pipe 24 B. Vent Table Key 24 C. Use of Elbows 24 D. Measuring Standards 24 E. Vent Diagrams 25

8 Vent Clearances and Framing

A. Pipe Clearances to Combustibles 30 B. Wall Penetration Framing 30 C. Install the Ceiling Firestop 31 D. Install Attic Insulation Shield 32

9 Appliance Preparation

A. Securing and Leveling the Appliance 33

10 Installing SLP Vent Pipe

A. Assemble Vent Sections 34 B. Assemble Slip Sections 34 C. Securing the Vent Sections 35 D. Disassemble Vent Sections 35 E. Installing Metal Roof Flashing 36 F. Install RF4-8 37 G. Installing Vertical Termination Cap 38 H. Assemble and Install Storm Collar 38 I. Install Heat Shields and Horizontal Termination Cap 39

11 Gas Information

A. Fuel Conversion 41 B. Gas Pressure 41 C. Gas Connection 41 D. High Altitude Installations 41

12 Electrical Information

A. Wiring Requirements 42 B. Standing Pilot Ignition System Wiring 42 C. Intelliﬁ re Ignition System Wiring 42 D. Optional Accessories Requirements 42 E. Electrical Service and Repair 43 F. Junction Box Installation 44 G. Wall Switch Installation for Fan (Optional) 44

13 Finishing

A. Mantel and Wall Projections 45 B. Facing Material 45

Heatilator • Eclipse • 4049-229 Rev F • 11/08 3

Page 4

14 Appliance Setup

A. Remove Packaging Materials 46 B. Remove Glass Assembly 46 C. Logs 46 D. Place Lava Rock, Rockwool 46 E. Replace Glass 47 F. Install Floor Cover 47 G. Grilles and Screen 47 H. Air Shutter Setting 48 I. Accessories 48

15 Troubleshooting

A. Standing Pilot Ignition System 49 B. Intelliﬁ re Ignition System 51

16 Reference Materials

A. Appliance Dimension Diagram 53 B. Vent Components Diagrams 54 C. Service Parts 56 D. Optional Components 59 E. Contact Information 60

 = Contains updated information.

Heatilator • Eclipse • 4049-229 Rev F • 11/084

Page 5

B. Warranty

Hearth & Home Technologies LIMITED WARRANTY

Hearth & Home Technologies (“HHT”) and its respective brands extends the following warranty for HHT gas, wood, pellet and electric appliances purchased from an authorized HHT dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts.

Warranty Period HHT Manufactured Appliances and Venting

Parts Labor Gas Wood Pellet

1 Year XXXXXX

EPA

Wood

Electric Venting

Components Covered

All Parts and Material Except

as covered by Conditions,

Exclusion, and Limitations listed

2 years

3 years X Firepots

5 years 3 years X X Castings & Bafﬂ es

7 years 3 years X X X

years

Limited

Lifetime

1 year X Burners, Logs & Refractory

1 year X Firebox & Heat Exchanger

90 Days XXXXXX All Replacement Parts

XXXX Blowers

X Molded Refractory Panels

Igniters, Electronic

Components, and Glass

Firebox, HHT Chimney,

Termination & Heat

Exchanger

See Conditions, Exclusions, and limitations. 9-01-08

CONDITIONS, EXCLUSIONS & LIMITATION OF LIABILITY

 This warranty applies to the original owner and is transferable up to two years from date of purchase to the new

homeowner, provided the purchase was made through an authorized dealer or distributor of HHT, and the appliance remains in its original place of installation.

 The maximum amount recoverable under this warranty is limited to the purchase price of the product.

 In no event shall HHT be liable for any incidental or consequential damages caused by defects in the product.

 Adjustments, regular maintenance, cleaning and temporary repairs, or the failure to duplicate the problem in the home

is not covered under this warranty.

4021-645A 09-01-08 Page 1 of 2

Heatilator • Eclipse • 4049-229 Rev F • 11/08 5

Page 6

B. Warranty (continued)

This limited warranty does not extend to or include surface ﬁ nish on the appliance or terminations, door gasketing, glass gasketing, glass discoloration, ﬁ rebrick, pellet logs, kaowool or other ceramic insulating materials. Rust and/or corrosion on any of the metal surfaces, cast iron components, bafﬂ es, ﬁ repots, doors, or ﬁ rebox area are not covered by this warranty.  Noise resulting from minor expansion, contraction, or movement of certain parts is normal and complaints related to

this noise are not covered by this warranty.

 HHT’s obligation under this warranty does not extend to damages resulting from: (1) installation, operation or

maintenance of the appliance not in accordance with the installation instructions; operating instructions and the listing agent identiﬁ cation label furnished with the appliance; (2) installation which does not comply with local building codes; (3) shipping, improper handling, improper operation, abuse, misuse, accident or unworkmanlike repairs; (4) environmental conditions, inadequate ventilation or drafting caused by tight sealing construction of the structure or handling devices such as exhaust fans or forced air furnaces or other such causes; (5) use of fuels other than those speciﬁ ed in the operating instructions; (6) installation or use of components not supplied with the appliance or any other components not expressly authorized and approved by HHT; and/or (7) modiﬁ cation of the appliance not expressly authorized and approved by HHT in writing.

 This warranty does not apply to non-HHT venting components, hearth components or other accessories used in

conjunction with the installation of this product.

 This warranty is void if the appliance has been over-ﬁ red or operated in atmospheres contaminated by chlorine,

ﬂ uorine, or other damaging chemicals the appliance is subject to prolonged periods of dampness or condensation, or

there is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited to, improper chimney or venting installation.

 HHT’s liability under this warranty is limited to the replacement and repair of defective components or workmanship

during the applicable period. HHT may fully discharge all of its obligations under such warranties by repairing the defective component(s) at HHT’s discretion. Shipping costs are not covered under this warranty.

 Some states do not allow exclusions or limitation of incidental or consequential damages, so those limitations may not

apply to you. This warranty gives you speciﬁ c rights; you may also have other rights, which vary from state to state.

 EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE

WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE WARRANTY SPECIFIED ABOVE.

This Limited Warranty is effective on all HHT appliances sold after September 01, 2008 and supersedes any and all warranties currently in existence.

If warranty service is needed, you should contact your installing dealer. If the installing dealer is unable to provide necessary parts or components, contact the nearest authorized HHT dealer or supplier.

4021-645A 09-01-08 Page 2 of 2

Heatilator • Eclipse • 4049-229 Rev F • 11/086

Page 7

Listing and Code Approvals

A. Appliance Certiﬁ cation

MODELS: EDV3633, EDV3633L, EDV3633I, EDV3633IL

LABORATORY: Underwriters Laboratories, Inc. (UL)

TYPE: Vented Gas Fireplace

STANDARD: ANSI Z21.88-2005•CSA2.33-2005•UL307B

This product is listed to ANSI standards for “Vented Gas Fireplace” and applicable sections of “Gas Burning Heating Appliances for Manufactured Homes and Recreational Vehicles”, and “Gas Fired Appliances for Use at High Altitudes”.

NOTICE: This installation must conform with local codes. In the absence of local codes you must comply with the National Fuel Gas Code, ANSI Z223.1-latest edition in the U.S.A. and the CAN/CGA B149 Installation Codes in Canada.

NOT INTENDED FOR USE AS A PRIMARY HEAT SOURCE.

This appliance is tested and approved as either supplemental room heat or as a decorative appliance. It should not be factored as primary heat in residential heating calculations.

B. Tempered Glass Speciﬁ cations

Hearth & Home Technologies appliances manufactured with tempered glass may be installed in hazardous locations such as bathtub enclosures as deﬁ ned by the Consumer Product Safety Commission (CPSC). The tempered glass has been tested and certiﬁ ed to the requirements of ANSI Z97.1 and CPSC 16 CFR 1202 (Safety Glazing Certiﬁ cation Council SGCC# 1595 and

1597. Architectural Testing, Inc. Reports 02-31919.01 and 02-31917.01).

This statement is in compliance with CPSC 16 CFR Section 1201.5 “Certiﬁ cation and labeling requirements”

which refers to 15 U.S. Code (USC) 2063 stating “…Such certiﬁ cate shall accompany the product or shall otherwise be furnished to any distributor or retailer to whom the product is delivered.”

Some local building codes require the use of tempered glass with permanent marking in such locations. Glass meeting this requirement is available from the factory. Please contact your dealer or distributor to order.

C. BTU Speciﬁ cations

EDV3633 Series SP IPI

Input Rate (NG) 20,000 20,000

Oriﬁ ce Size (NG) 0.083 0.083

Input Rate (LP) 20,000 20,000

Oriﬁ ce Size (LP) 0.053 0.053

D. High Altitude Installations

NOTICE: If the heating value of the gas has been reduced, these rules do not apply. Check with your local gas utility or authorities having jurisdiction.

When installing above 2000 feet elevation:

• In the USA: Reduce input rate 4% for each 1000 feet above 2000 feet.

• In CANADA: Reduce input rate 10% for elevations between 2000 feet and 4500 feet. Above 4500 feet, consult local gas utility.

Check with your local gas utility to determine proper oriﬁ ce size.

E. Non-Combustible Materials Speciﬁ cation

Material which will not ignite and burn. Such materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination thereof.

Materials that are reported as passing ASTM E 136,

Standard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750 ºC and UL763 shall be

considered non-combustible materials.

F. Combustible Materials Speciﬁ cation

Materials made of or surfaced with wood, compressed paper, plant ﬁ bers, plastics, or other material that can ig- nite and burn, whether ﬂ ame proofed or not, or plastered or unplastered shall be considered combustible materials.

G. Electrical Codes

NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code

ANSI/NFPA 70-latest edition or the Canadian Electric Code CSA C22.1.

• A 110-120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 7

Page 8

Note: The following requirements reference various Massachusetts and national codes not contained in this document.

H. Requirements for the Commonwealth of Massachusetts

For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above ﬁ nished grade in the area of the venting, in- cluding but not limited to decks and porches, the following requirements shall be satisﬁ ed:

Installation of Carbon Monoxide Detectors

At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gas ﬁ tter shall observe that a hard wired carbon mon- oxide detector with an alarm and battery back-up is installed on the ﬂ oor level where the gas equipment is to be installed. In addition, the installing plumber or gas ﬁ tter shall observe that a battery operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of qualiﬁ ed licensed profes- sionals for the installation of hard wired carbon monoxide detectors.

In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent ﬂ oor level.

In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon monoxide detector with an alarm shall be installed.

Approved Carbon Monoxide Detectors

Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certiﬁ ed.

Signage

A metal or plastic identiﬁ cation plate shall be permanently mounted to the exterior of the building at a minimum height of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The sign shall read, in print size no less than one-half (1/2) in. in size,

“GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.

Inspection

The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR 5.08(2)(a)1 through 4.

Exemptions

The following equipment is exempt from 248 CMR

5.08(2)(a)1 through 4:

• The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54 as adopted by the Board; and

• Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or structure used in whole or in part for residential purposes.

MANUFACTURER REQUIREMENTS

Gas Equipment Venting System Provided

When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment and the venting system shall include:

• Detailed instructions for the installation of the venting system design or the venting system components; and

• A complete parts list for the venting system design or venting system.

Gas Equipment Venting System NOT Provided

When the manufacturer of a Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the ﬂ ue gases, but identi- ﬁ es “special venting systems”, the following requirements shall be satisﬁ ed by the manufacturer:

• The referenced “special venting system” instructions shall be included with the appliance or equipment installation instructions; and

• The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a parts list and detailed installation instructions.

A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation.

See Gas Connection section for additional Commonwealth of Massachusetts requirements.

Heatilator • Eclipse • 4049-229 Rev F • 11/088

Page 9

User Guide

Operating Instructions

A. Gas Fireplace Safety

WARNING

HOT SURFACES!

Glass and other surfaces are hot during operation and cool down.

Hot glass will cause burns.

• Do not touch glass until it is cooled

• NEVER allow children to touch glass

• Keep children away

• CAREFULLY SUPERVISE children in

same room as appliance.

• Alert children and adults to hazards of high temperatures.

High temperatures may ignite clothing or other

ﬂ ammable materials.

• Keep clothing, furniture, draperies and other combustibles away.

This appliance has been supplied with an integral barrier to prevent direct contact with the ﬁ xed glass panel. Do NOT operate the appliance with the barrier removed.

Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one.

• Install a physical barrier such as:

- A decorative ﬁ rescreen.

- Adjustable safety gate.

• Install a switch lock or a wall/remote control with child protection lockout feature.

• Keep remote controls out of reach of children.

• Never leave children alone near a hot ﬁ replace, whether operating or cooling down.

• Teach children to NEVER touch the ﬁ replace.

• Consider not using the ﬁ replace when children will be present.

Contact your dealer for more information, or visit: www. hpba.org/staysafe.

To prevent unintended operation when not using your ﬁ replace for an extended period of time (summer months, vacations, trips, etc):

• Remove batteries from remote controls.

• Turn off wall controls.

• Unplug 3 volt adapter plug and remove batteries on IPI models.

• Turn off gas controls valve on standing pilot models.

When lighting the pilot light on ﬁ replaces with a standing pilot, remove the ﬁ xed glass assembly so you can detect presence of residual gas build-up. See Standing Pilot Lighting instructions and Maintenance Tasks.

If you expect that small children or vulnerable adults may come into contact with this ﬁ replace, the following precau- tions are recommended:

Fixed Glass Assembly

Log Set

(not shown)

SECTION 2.B.

Fan Kit

SECTION 2.C

(not required)

Clear Space

SECTION 2.D.

SECTION 14.K.

Hearth

B. Your Fireplace

WARNING! DO NOT operate ﬁ replace before reading and understanding operating instructions. Failure to operate

ﬁ replace according to operating instructions could cause ﬁ re or injury.

Mantel

SECTION 13.A.

Figure 2.1 General Operating Parts

Heatilator • Eclipse • 4049-229 Rev F • 11/08 9

Page 10

C. Fan Kit

• Optional

• Contact your dealer for the correct fan kit.

D. Clear Space

WARNING! DO NOT place combustible objects in front of the ﬁ replace or block louvers. High temperatures may start a ﬁ re. See Figure 2.2.

Avoid placing candles and other heat-sensitive objects on mantel or hearth. Heat may damage these objects.

G. Before Lighting Fireplace

Before operating this ﬁ replace for the ﬁ rst time, have a qualiﬁ ed service technician:

• Verify all shipping materials have been removed from inside and/or underneath the ﬁ rebox.

• Review proper placement of logs, ember material and/or other decorative materials.

• Check the wiring.

• Check the air shutter adjustment.

• Ensure that there are no gas leaks.

• Ensure that the glass is sealed and in the proper position and that the integral barrier is in place.

WARNING! Risk of Fire or Asphyxiation! DO NOT operate ﬁ replace with ﬁ xed glass assembly removed.

Determine if this ﬁ replace has a standing pilot or an Intelliﬁ re ignition system. Ask your dealer or open control access panel, look at gas valve assembly.

• A standing pilot ignition will have a red or black ignitor button (refer to Figure 2.3).

• An Intelliﬁ re ignition system will not have a button.

Clear space 3 ft (914 mm) in front of appliance

Figure 2.2 Clear Space

E. Fixed Glass Assembly

See Section 14.E.

F. Remote Controls, Wall Controls and Wall Switches

Follow the instructions supplied with the control installed to operate your ﬁ replace:

For safety:

• Install a switch lock or a wall/remote control with child protection lockout feature.

• Keep remote controls out of reach of children.

See your dealer if you have questions.

Red or Black

Button

Figure 2.3 Ignitor Button

Heatilator • Eclipse • 4049-229 Rev F • 11/0810

Page 11

H. Lighting Instructions (IPI)

The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery life, remove them when using the transformer.

Disconnect the electric power before

This appliance must be properly connected to a

venting system in accordance with the

This appliance must be installed in accordance

with local codes, if any; if not, follow ANSI

This appliance needs fresh air for safe operation and must

be installed so there are provisions for adequate

combustion and ventilation air.

Z223.1 or, in Canada, current CAN/CGA-B149.

fire or explosion may result causing property

damage, personal injury or loss of life.

manufacturer's installation instructions.

adjustment, alteration, service or maintenance

can cause injury or property damage. Refer to

the owner's information manual provided with

the appliance. For assistance or additional

information consult a qualified installer, service

WARNING: Improper installation,

department.

valve or turn the gas control knob. Never use tools. If the

lever or knob will not move by hand, don't try to repair it,

call a qualified service technician. Force or attempted

repair may result in a fire or explosion.

C. Use only your hand to push in and move the gas control

• If you cannot reach your gas supplier, call the fire

agency or the gas supplier.

water. Immediately call a qualified service technician to

inspect the appliance and to replace any part of the

control system and any gas control which has been

under water.

D. Do not use this appliance if any part has been under

WARNING RISK OF FIRE

For use with natural gas or propane. A conversion

kit as supplied by the manufacturer shall be used

WARNING:

servicing. If for any reason the original wire supplied with the

Keep children, clothing, furniture, gasoline and other liquids

having flammable vapors away.

CAUTION: Hot while in operation. Do not touch.

This appliance is intended to burn a specified gas fuel only. Do

not attempt to use with solid wood fuel or another type of fuel.

Do not attempt to modify or use any other type of gas burner

system.

STOP! Follow "B" in the safety information above on this label. If

you don't smell gas, go to the next step.

and turn on the wall switch or set the thermostat to the desired

setting.

OFF GAS TO APPLIANCE" and call your service technician or gas

5. Wait five minutes to clear out any gas. If you then smell gas,

6. To turn on the burner, turn on all electric power to this appliance

7. If the appliance will not operate, follow the instructions "TO TURN

appliance must be replaced, it must be replaced with 105° C or its

supplier.

to convert this appliance to the alternative fuel.

equivalent.

position or push the gas control lever to the "OFF"

position. Do not force.

3. Push the gas control lever in and move to the "OFF"

4. Replace the control access panel.

NATURAL GAS

a bed-sitting room.

* Also certified for installation in a bedroom or

* For U.S. only!

33631D

WARNING: If you do not follow these instructions exactly, a

FOR YOUR SAFETY READ BEFORE LIGHTING

automatically lights the pilot. Do not try to light the pilot

by hand.

for gas. Be sure to smell next to the floor because some

gas is heavier than air and will settle on the floor.

A. This appliance is equipped with an ignition device which

B. BEFORE LIGHTING smell all around the appliance area

phone in your building.

• Immediately call your gas supplier from a neighbor's

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any

WHAT TO DO IF YOU SMELL GAS

LIGHTING INSTRUCTIONS

phone. Follow the gas supplier's instructions.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 11

the lowest setting.

automatically lights the pilot. Do NOT try to light the pilot

by hand.

1. STOP! Read the safety information above on this label.

2. Turn wall switch to the "OFF" position or thermostat to

3. Turn off all electric power to the appliance.

4. This appliance is equipped with an ignition device which

TO TURN OFF GAS TO APPLIANCE

be performed.

Due to high surface temperatures, keep children, clothing and furniture away.

1. Turn off wall switch or set thermostat to lowest setting.

2. Turn off all electric power to the appliance if service is to

Keep burner and control compartment clean. See installation and operating instructions accompanying the appliance.

Page 12

I. Lighting Instructions (Standing Pilot)

Improper installation,

This appliance must be properly connected to a

venting system in accordance with the

This appliance must be installed in accordance with

This appliance needs fresh air for safe operation

local codes, if any; if not, follow ANSI Z223.1 or, in

and must be installed so there are provisions for

adequate combustion and ventilation air.

manufacturer's installation instructions.

Canada, current CAN/CGA-B149.

department.

• If you cannot reach your gas supplier, call the fire

WARNING:

adjustment, alteration, service or maintenance can

cause injury or property damage. Refer to the owner's

information manual provided with the appliance. For

assistance or additional information consult a

qualified installer, service agency or the gas supplier.

the manual gas valve will not push in or turn by hand, don't try

to repair it; call a qualified service technician. Force or

attempted repair may result in a fire or explosion.

Immediately call a qualified service technician to inspect the

appliance and to replace any part of the control system and

any gas control which has been under water.

C. Use only your hand to push in or turn knob. Never use tools. If

D. Do not use this appliance if any part has been under water.

Disconnect the electric power

Hot while in operation. Do not touch.

CAUTION:

This appliance is intended to burn a specified gas

fuel only. Do not attempt to use with solid wood fuel

or another type of fuel. Do not attempt to modify or

use any other type of gas burner system.

WARNING:

WARNING RISK OF FIRE

Keep children, clothing, furniture, gasoline and other liquids

having flammable vapors away.

For use with natural gas or propane. A conversion

before servicing. If for any reason the original wire

kit as supplied by the manufacturer shall be used to

supplied with the appliance must be replaced, it must be

replaced with 105° C or its equivalent.

VENT

OFF

3. CLOSED

NATURAL GAS

bed-sitting room.

* Also certified for installation in a bedroom or a

* For U.S. only!

convert this appliance to the alternative fuel.

29097D

3. Turn manual gas valve to "CLOSED position. Do not force.

4. Replace control access panel.

PILOT

OFF

4. OPEN

OFF

PILOT

OFF

PILOT

explosion may result causing property damage,

personal injury or loss of life.

Stop! Read the safety information above on this label.

LIGHTING INSTRUCTIONS

WARNING: If you do not follow these instructions exactly, a fire or

your building.

FOR YOUR SAFETY READ BEFORE LIGHTING

When lighting the pilot, follow these instructions exactly.

gas. Be sure to smell next to the floor because some gas is

heavier than air and will settle on the floor.

A. This appliance has a pilot which must be lighted by hand.

B. BEFORE LIGHTING smell all around the appliance area for

• Do not try to light any appliance.

WHAT TO DO IF YOU SMELL GAS

Follow the gas supplier's instructions.

lowest setting.

clear out any gas. If you then smell gas, STOP! Follow "B" in

the safety information above on this label. If you don't smell

gas, go to next step.

• Immediately call your gas supplier from a neighbor's phone.

• Do not touch any electric switch; do not use any phone in

1. Turn wall switch to the "OFF" position or thermostat to the

2. Remove control access panel.

3. Turn manual gas valve to CLOSED. Wait five [5] minutes to

depressed to pass "PILOT" position.)

4. Turn gas line to "OPEN".

5. Turn pilot knob clockwise to "OFF". (Knob may have to be

6. Locate pilot assembly inside appliance.

Heatilator • Eclipse • 4049-229 Rev F • 11/0812

TO TURN OFF GAS TO APPLIANCE

12-15 times until small blue pilot flame appears.

Pilot should remain lit. If pilot goes out, wait 5 minutes and

repeat Steps 3-9.

OFF GAS TO APPLIANCE" and call your service technician or

gas supplier.

hand.

1. Turn off wall switch or set thermostat to lowest setting.

2. Remove control access panel.

Due to high surface termperatures, keep children, clothing and furniture away.

7. Locate red ignitor button.

8. Turn pilot knob to "PILOT" and push in.

9. Continue to hold in pilot knob and push the red ignitor button

10. Continue to hold in pilot knob for approximately one minute.

11. Release and turn knob counterclockwise to "ON".

12. If appliance will not operate, follow the instructions "TO TURN

NOTE: To light main burner, turn wall switch to "ON". Do not light by

Keep burner and control compartment clean. See installation and operating instructions accompanying the appliance.

Page 13

J. After Fireplace is Lit

Initial Break-in Procedure

• The fireplace should be run three to four hours continuously on high.

• Turn the ﬁ replace off and allow it to completely cool.

• Remove ﬁ xed glass assembly. See Section 14.B.

• Clean ﬁ xed glass assembly. See Section 3.

• Replace the ﬁ xed glass assembly and run continuously on high an additional 12 hours.

This cures the materials used to manufacture the ﬁ re- place.

NOTICE! Open windows for air circulation during ﬁ replace break-in.

• Some people may be sensitive to smoke and

odors.

• Smoke detectors may activate.



K. Frequently Asked Questions

ISSUE SOLUTIONS

Condensation on the glass

Blue ﬂ ames

Odor from appliance

This is a result of gas combustion and temperature variations. As the appliance warms, this condensation will disappear.

This is a result of normal operation and the ﬂ ames will begin to yellow as the appliance is allowed to burn for 20 to 40 minutes.

When ﬁ rst operated, this appliance may release an odor for the ﬁ rst several hours. This is caused by the curing of materials from manufacturing. Odor may also be released from ﬁ nishing materials and adhesives used near the appliance. These circumstances may require additional curing related to the installation environment.

Film on the glass

Metallic noise

Is it normal to see the pilot ﬂ ame burn continually?

This is a normal result of the curing process of the paint and logs. Glass should be cleaned within 3 to 4 hours of initial burning. A non-abrasive cleaner such as gas appliance glass cleaner may be necessary. See your dealer.

Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the appliance.

In an Intelliﬁ re ignition system it is normal to see the pilot ﬂ ame, but it should turn off when ON/ OFF is turned to OFF. In a standing pilot system the pilot will always stay on.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 13

Page 14

Maintenance and Service

Any safety screen or guard removed for servicing must be replaced prior to operating the ﬁ replace.

When properly maintained, your ﬁ replace will give you many years of trouble-free service. We recommend annual service by a qualiﬁ ed service technician.

A. Maintenance Tasks-Homeowner

Installation and repair should be done by a qualiﬁ ed service technician only. The ﬁ replace should be inspect- ed before use and at least annually by a professional service person.

The following tasks may be performed annually by the homeowner. If you are uncomfortable performing any of the listed tasks, please call your dealer for a service appointment.

More frequent cleaning may be required due to lint from carpeting or other factors. Control compartment, burner and circulating air passageway of the ﬁ replace must be kept clean.

CAUTION! Risk of Burns! The ﬁ replace should be turned off and cooled before servicing.

Glass Cleaning

Frequency: Seasonally By: Homeowner

Tools Needed: Protective gloves, glass cleaner, drop

cloth and a stable work surface.

CAUTION! Handle ﬁ xed glass assembly with care.

Glass is breakable.

• Avoid striking, scratching or slamming glass

• Avoid abrasive cleaners

• DO NOT clean glass while it is hot

• Prepare a work area large enough to accommodate ﬁ xed glass assembly and door frame by placing a drop cloth on a ﬂ at, stable surface.

Note: Fixed glass assembly and gasketing may have residue that can stain carpeting or ﬂ oor surfaces.

• Remove door or decorative front from ﬁ replace and set aside on work surface.

• See Section 14.B for instructions to remove ﬁ xed glass assembly.

• Clean glass with a non-abrasive commercially available cleaner.

- Light deposits: Use a soft cloth with soap and

water

- Heavy deposits: Use commercial ﬁ replace glass

cleaner (consult with your dealer)

• Carefully set ﬁ xed glass assembly in place on ﬁ replace. Hold glass in place with one hand and secure glass latches with the other hand. See Section 14.E. for glass replacement.

• Reinstall door or decorative front.

Doors, Surrounds, Fronts

Frequency: Annually By: Homeowner Tools needed: Protective gloves, stable work surface

• Assess condition of screen and replace as necessary.

• Inspect for scratches, dents or other damage and repair as necessary.

• Check that louvers are not blocked.

• Vacuum and dust surfaces.

Remote Control

Frequency: Seasonally By: Homeowner Tools needed: Replacement batteries and remote control

instructions.

• Locate remote control transmitter and receiver.

• Verify operation of remote. Refer to remote control operation instructions for proper calibration and setup procedure.

• Place batteries as needed in remote transmitters and battery-powered receivers.

• Place remote control out of reach of children.

If not using your ﬁ replace for an extended period of time (summer months, vacations/trips, etc), to prevent unintended operation:

• Remove batteries from remote controls.

• Unplug 3 volt adapter plug on IPI models.

Heatilator • Eclipse • 4049-229 Rev F • 11/0814

Page 15

Venting

Control Compartment and Firebox Top

Frequency: Seasonally By: Homeowner Tools needed: Protective gloves and safety glasses.

• Inspect venting and termination cap for blockage or obstruction such plants, bird nests, leaves, snow, debris, etc.

• Verify termination cap clearance to subsequent construction (building additions, decks, fences, or sheds). See Section 6.

• Inspect for corrosion or separation.

• Verify weather stripping, sealing and ﬂ ashing remains intact.

• Inspect draft shield to verify it is not damaged or missing.

B. Maintenance Tasks-Qualiﬁ ed Service Technician

The following tasks must be performed by a qualiﬁ ed service technician.

Gasket Seal and Glass Assembly Inspection

Frequency: Annually By: Qualiﬁ ed Service Technician Tools needed: Protective gloves, drop cloth and a stable

work surface.

• Inspect gasket seal and its condition.

• Inspect ﬁ xed glass assembly for scratches and nicks that can lead to breakage when exposed to heat.

• Conﬁ rm there is no damage to glass or glass frame. Replace as necessary.

• Verify that ﬁ xed glass assembly is properly retained and attachment components are intact and not damaged. Replace as necessary.

Logs

Frequency: Annually By: Qualiﬁ ed Service Technician Tools needed: Protective gloves.

• Inspect for damaged or missing logs. Replace as necessary. Refer to Section 14 for log reference.

• Verify correct log placement and no ﬂ ame impingement causing sooting. Correct as necessary.

Firebox

Frequency: Annually

Frequency: Annually By: Qualiﬁ ed Service Technician Tools needed: Protective gloves, vacuum cleaner, dust

cloths

• Vacuum and wipe out dust, cobwebs, debris or pet hair. Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided.

• Remove all foreign objects.

• Verify unobstructed air circulation.

Burner Ignition and Operation

Frequency: Annually By: Qualiﬁ ed Service Technician Tools needed: Protective gloves, vacuum cleaner, whisk

broom, ﬂ ashlight, voltmeter, indexed drill bit set, and a manometer.

• Verify burner is properly secured and aligned with pilot or igniter.

• Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary.

• Replace rockwool materials with new dime-size pieces. DO NOT block ports or obstruct lighting paths. Refer to Section 14 for proper rockwool placement.

• Verify batteries have been removed from battery backup IPI systems to prevent premature battery failure or leaking.

• Check for smooth lighting and ignition carryover to all ports. Verify that there is no ignition delay.

• Inspect for lifting or other ﬂ ame problems.

• Verify air shutter setting is correct. See Section 14 for required air shutter setting. Verify air shutter is clear of dust and debris.

• Inspect oriﬁ ce for soot, dirt and corrosion. Verify oriﬁ ce size is correct. See Service Parts List for proper oriﬁ ce sizing.

• Verify manifold and inlet pressures. Adjust regulator as required.

• Inspect pilot ﬂ ame pattern and strength. See Figure 3.1 and 3.2 for proper pilot ﬂ ame pattern. Clean or replace oriﬁ ce spud as necessary.

• Inspect thermocouple/thermopile or IPI ﬂ ame sensing rod for soot, corrosion and deterioration. Clean with emery cloth or replace as required.

• Verify thermocouple/thermopile or IPI millivolt output. Replace as necessary.

By: Qualiﬁ ed Service Technician Tools needed: Protective gloves, sandpaper, steel wool,

cloths, mineral spirits, primer and touch-up paint.

• Inspect for paint condition, warped surfaces, corrosion or perforation. Sand and repaint as necessary.

• Replace ﬁ replace if ﬁ rebox has been perforated.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 15

Page 16

(Either cobrahead or SIT)

PRODUCT SPECIFIC

Figure 3.1 IPI Pilot Flame Patterns

Figure 3.2 Standing Pilot Flame Patterns

Heatilator • Eclipse • 4049-229 Rev F • 11/0816

Page 17

A. Typical Appliance System

NOTICE: Illustrations and photos reﬂ ect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual

Getting Started

Vertical Termination Cap

(SECTION 10)

Installer Guide

Noncombustible roof flashing maintains minimum clearance around pipe (SECTION 10)

Vent Pipe (SECTIONS 7, 8, 10)

Ceiling Firestop on floor of attic (SECTION 8)

Framing/Header (SECTION 5)

Storm Collar (SECTION 10)

Vent pipe penetrates roof, preferably without affecting roof rafters (SECTION 8)

Attic insulation shield (not shown) must be used here to keep insulation away from vent pipe if attic is insulated. (SECTION 8)

Framing Headed off in Ceiling Joists (SECTION 8)

Optional

Wall Switch

Mantel & Mantel Leg (SECTION 13)

Surround

Figure 4.1 Typical System

Hearth Extension (not required)

Gas Line (SECTION 11)

Heatilator • Eclipse • 4049-229 Rev F • 11/08 17

Page 18

B. Design and Installation Considerations

Heatilator direct vent gas appliances are designed to operate with all combustion air siphoned from outside of the building and all exhaust gases expelled to the outside. No additional outside air source is required.

Installation MUST comply with local, regional, state and national codes and regulations. Consult insurance carrier, local building inspector, ﬁ re ofﬁ cials or authorities having jurisdiction over restrictions, installation inspection and permits.

Before installing, determine the following:

• Where the appliance is to be installed.

• The vent system conﬁ guration to be used.

• Gas supply piping.

• Electrical wiring requirements.

• Framing and ﬁ nishing details.

• Whether optional accessories—devices such as a fan or

remote control—are desired.

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. For assistance or additional information, consult a qualiﬁ ed service technician, service agency or your dealer.

C. Tools and Supplies Needed

Before beginning the installation be sure that the following tools and building supplies are available.

Tape measure Framing material Pliers High temperature caulking material Hammer Phillips screwdriver Gloves Framing square Voltmeter Electric drill and bits (1/4 in.) Plumb line Safety glasses Level Reciprocating saw Manometer Flat blade screwdriver Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws One 1/4 in. female connection (for optional fan).

D. Inspect Appliance and Components

• Carefully remove the appliance and components from the packaging.

• The vent system components and decorative doors and fronts may be shipped in separate packages.

• If packaged separately, the log set and appliance grate must be installed.

• Report to your dealer any parts damaged in shipment, particularly the condition of the glass.

• Read all of the instructions before starting the installation. Follow these instructions carefully during the installation to ensure maximum safety and beneﬁ t.

WARNING! Risk of Fire or Explosion! Damaged parts could impair safe operation. DO NOT install damaged, incomplete or substitute components. Keep appliance dry.

Hearth & Home Technologies disclaims any responsibility for, and the warranty will be voided by, the following actions:

• Installation and use of any damaged appliance or vent system component.

• Modiﬁ cation of the appliance or vent system.

• Installation other than as instructed by Hearth & Home Technologies.

• Improper positioning of the gas logs or the glass door.

• Installation and/or use of any component part not approved by Hearth & Home Technologies.

Any such action may cause a ﬁ re hazard.

WARNING! Risk of Fire, Explosion or Electric Shock! DO NOT use this appliance if any part has been under wa-

ter. Call a qualiﬁ ed service technician to inspect the appli- ance and to replace any part of the control system and/or gas control which has been under water.

Heatilator • Eclipse • 4049-229 Rev F • 11/0818

Page 19

Framing and Clearances

A. Selecting Appliance Location

When selecting a location for the appliance it is important to consider the required clearances to walls (see Figure

5.1).

WARNING! Risk of Fire or Burns! Provide adequate clearance around air openings and for service access. Due

to high temperatures, the appliance should be located out of trafﬁ c and away from furniture and draperies.

3/4 in./19 mm

minimum

appliance

to combustibles

36-7/8 in.

934 mm

36-7/8 in.

934 mm

Drywall

36 in./914 mm

NOTICE: Illustrations reﬂ ect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams are not drawn to scale. Actual installation may vary due to individual design preference.

17-7/8 in.

454 mm

36 in.

914 mm

Horiz Term

Figure 5.1 Appliance Locations

Heatilator • Eclipse • 4049-229 Rev F • 11/08 19

Page 20

B. Constructing the Appliance Chase

A chase is a vertical box-like structure built to enclose the gas appliance and/or its vent system. In cooler climates the vent should enclosed inside the chase.

NOTICE:

ﬁ restops and construction of the chase may vary with the type of building. These instructions are not substitutes for the requirements of local building codes. Therefore, you MUST check local building codes to determine the requirements to these steps.

Chases should be constructed in the manner of all outside walls of the home to prevent cold air drafting problems. The chase should not break the outside building envelope in any manner.

Walls, ceiling, base plate and cantilever ﬂ oor of the chase should be insulated. Vapor and air inﬁ ltration barriers should be installed in the chase as per regional codes for the rest of the home. Additionally, in regions where cold air inﬁ ltration may be an issue, the inside surfaces may be sheetrocked and taped for maximum air tightness.

Treatment of ceiling ﬁ restops and wall shield

3/4 in.

(19 mm)

To further prevent drafts, the wall shield and ceiling ﬁ re- stops should be caulked with high temperature caulk to seal gaps. Gas line holes and other openings should be caulked with high temp caulk or stuffed with unfaced insulation. If the appliance is being installed on a cement slab, a layer of plywood may be placed underneath to prevent conducting cold up into the room.

C. Clearances

NOTICE: Install appliance on hard metal or wood surfaces extending full width and depth. DO NOT install directly on carpeting, vinyl, tile or any combustible material other than wood.

WARNING! Risk of Fire! Maintain speciﬁ ed air space clearances to appliance and vent pipe:

• Insulation and other materials must be secured to prevent accidental contact.

• Failure to maintain airspace may cause overheating and a ﬁ re.

Combustible flooring may be installed next to the front of the appliance.

36 in.

(914 mm)

Combustible Object

Drywall

0 in.

30 in.

(762 mm)

to ceiling

0 in. to floor

Model

EDV3633 inches 36 34 17 7/8 9

Figure 5.2 Clearances to Combustibles

Rough Opening

(Width)

mm 914 864 454 229

Heatilator • Eclipse • 4049-229 Rev F • 11/0820

Rough Opening

(Height)

Rough Opening

(Depth)

Rough Opening

(SLP Pipe)

Page 21

D. Mantel and Wall Projections

WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as speciﬁ ed. Framing or ﬁ nishing material closer than the minimums listed must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc).

Mantels

Note: All

measurements in inches.

Mantel Legs or Wall Projections

Top of Appliance

Drywall

30 in. minimum

8-3/4

16-1/4

17-3/4

10-1/4

9-1/2

13-1/4

12-1/2

11-3/4

Measured from top of fireplace opening (in inches)

15-1/2

14-3/4

18-1/2

19-1/4

Figure 5.3 Minimum Vertical and Maximum Horizontal Dimensions

to ceiling

2 in. (51 mm) min.

from fireplace opening to perpendicular wall

Mantel Leg or

Perpendicular Wall

Figure 5.4 Mantel Leg or Wall Projections (Acceptable on both sides of opening)

Heatilator • Eclipse • 4049-229 Rev F • 11/08 21

Page 22

Termination Locations

A. Vent Termination Minimum Clearances

WARNING

Fire Risk. Maintain vent clearance to combustibles as

speciﬁ ed.

• DO NOT pack air space with insulation or other materials.

Failure to keep insulation or other materials away from vent pipe may cause overheating and ﬁ re.

Horizontal overhang

24 in. min.

(610 mm)

Termination

Cap

Storm Collar

Roof

Flashing

20 in.

(508 mm)

Lowest

Discharge

Opening

H (min.) - Minimum height from roof to lowest discharge opening.

Vertical wall

Roof Pitch is X / 12

Measure vertical clearances from this surface.

Measure horizontal clearances from this surface.

(See Figure 6.5 for speciﬁ c clearances)

Figure 6.2 Clearance To Horizontal Termination Cap

6in.(minimum)upto20in.

152 mm/508 mm

20 in. and over 0 in. minimum

18 in. minimum

457 mm

Gas, Wood or Fuel Oil

Termination Cap

Minimum

DV = 20 in.

A *

(508 mm)

BV = 8 ft

(2.44 m)

Perpendicular Wall

Roof Pitch H (Min.) Ft. Roof Pitch H (Min.) Ft.

Flat to 6/12 1.0* Over 11/12 to 12/12 4.0 Over 6/12 to 7/12 1.25* Over 12/12 to 14/12 5.0 Over 7/12 to 8/12 1.5* Over 14/12 to 16/12 6.0 Over 8/12 to 9/12 2.0* Over 16/12 to 18/12 7.0 Over 9/12 to 10/12 2.5 Over 18/12 to 20/12 7.5 Over 10/12 to 11/12 3.25 Over 20/12 to 21/12 8.0

* 3 ft. minimum in snow regions

Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening

Gas

Termination

Cap **

If using decorative cap cover(s), this distance may need to be

increased. Refer to the installation instructions supplied with the decorative cap cover.

In a staggered installation with both gas and wood terminations, the

wood termination cap must be higher than the gas termination cap.

Figure 6.3 Multiple Termination Caps



Heatilator • Eclipse • 4049-229 Rev F • 11/0822

Page 23

Fixed

Closed

Openable

V TERMINATION CAP

Fixed

Closed

Measure vertical clearances

from this surface

Measure horizontal clearances

from this surface.

Covered Alcove

Applications

Dimension Descriptions A Clearance above the ground, a veranda, porch, deck or balcony - 12 in.

(30 cm) minimum. *

B Clearance to window or door that may be opened – 10,000 BTUs or less,

6 in. (15 cm) minimum; 10,000-50,000 BTUs, 9 in. (23 cm) minimum; over 50,000 BTUs, 12 in. (30 cm) minimum. *

C Clearance to permanently closed window – 12 in. (30 cm) minimum -

recommended to prevent condensation on window.

D Vertical clearance to ventilated sofﬁ t located above the termination within

a horizontal distance of 2 ft (60 cm) from the centerline of the termination

– 18 in. (46 cm) minimum. ** E Vertical clearance to unventilated sofﬁ t - 12 in. (30 cm) minimum. ** F Clearance to outside corner - 6 in. (15 cm) minimum. G Clearance to inside corner - 6 in. (15 cm) minimum. H Not to be installed above a meter/regulator assembly within 3 ft (90 cm)

horizontally* from the center line of the regulator (Canada only) I Clearance to service regulator vent outlet – 3 ft (.91 m) U.S. minimum and

3 ft (.91 m) Canada minimum. * J Clearance to non-mechanical air supply inlet into building or the combustion

air inlet to any other appliance – 9” (23 cm) U.S. minimum and 12 in. (30

cm) Canada minimum. * K Clearance to mechanical air supply inlet - 3 ft (.91 m) U.S. minimum and

6 ft (1.8 m) Canada minimum. * L Clearance above a paved sidewalk or paved driveway located on public

property - 7 ft (2.1 m) minimum. A vent may not terminate directly above a sidewalk or paved driveway

which is located between two single family dwellings and serves both

dwellings. M Clearance under veranda, porch, deck or balcony - 12 in. (30 cm) minimum.

* Recommended 30 in. (76 cm) for vinyl or plastic. Only permitted if veranda, porch, deck or balcony is fully open on a

minimum of 2 sides beneath the ﬂ oor. * N Vertical clearance between two horizontal termination caps – 12 in. (30

cm) minimum. O Horizontal clearance between two horizontal termination caps – 12 in. (30

cm) minimum.

Figure 6.4 Minimum Clearances for Termination

GAS METER

AIR SUPPLY INLET

RESTRICTION ZONE (TERMINATION NOT ALLOWED)

K X

lectrical

Service

Clearances to Electrical Service

P 6” - Non-vinyl sidewalls 12” – Vinyl sidewalls Q 18” – Non-vinyl sofﬁ t and overhang 42” – Vinyl sofﬁ t and overhang R 8 ft.

min

max

1 cap 3 ft 2 x S actual 2 caps 6 ft 1 x S actual 3 caps 9 ft 2/3 x S actual 4 caps 12 ft 1/2 x S actual

= # term caps x 3 T

min

= (2/# term caps) x S (actual)

max

U 6” min. – Clearance from sides of electrical service. W 12” min. – Clearance above electrical service. * As speciﬁ ed in CGA B149 Installation Codes Note: Local codes or regulations may require different clearances. ** Clearance required to vinyl sofﬁ t material – 30 in. (76 cm) minimum. Note: Location of the vent termination must not interfere with access to

the electrical service.

WARNING! In the U.S.: Vent system termination is NOT permitted in screened porches.

You must follow side wall, overhang and ground clearances as stated in the instructions.

In Canada: Vent system termination is NOT permitted in screened porches.

Vent system termination is permitted in porch areas with two or more sides open. You must follow all side wall, overhang and ground clearances as stated in the instructions.

Hearth & Home Technologies assumes no responsibility for the improper

performance of the appliance when the venting system does not meet these requirements.

CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS SUGGESTED THAT A VINYL PROTECTOR KIT BE INSTALLED.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 23

Page 24

Vent Information and Diagrams

A. Approved Pipe

This appliance is approved for use with Hearth & Home Technologies SLP venting systems. Refer to Section 16B for vent component information.

DO NOT mix pipe, ﬁ ttings or joining methods from differ- ent manufacturers.

The pipe is tested to be run inside an enclosed wall. There is no requirement for inspection openings at each joint within the wall.

WARNING! Risk of Fire or Asphyxiation. This appliance requires a separate vent. DO NOT vent to a pipe serving a separate solid fuel burning appliance.

B. Vent Table Key

The abbreviations listed in this vent table key are used in the vent diagrams.

Symbol Description

Vertical

12 in.

8-1/2 in.

Horizontal

On 45° runs, 1 ft (.3 m) of diagonal is equal to 8-1/2 in. (216 mm) horizontal run and 8-1/2 in. (216 mm) vertical run.

Figure 7.1 Using Two 45° Elbows

8-1/2 in.

First section (closest to appliance) of vertical length

Second section of vertical length

First section (closest to appliance) of horizontal length

Subsequent sections of horizontal length

C. Use of Elbows

Diagonal runs have both vertical and horizontal vent aspects when calculating the effects. Use the rise for the vertical aspect and the run for the horizontal aspect (see Figure 7.1).

Two 45º elbows may be used in place of one 90º elbow. On 45º runs, one foot of diagonal is equal to 8-1/2 in. (216 mm) horizontal run and 8-1/2 in. (216 mm) vertical run. A length of straight pipe is allowed between two 45º elbows (see Figure 7.1).

D. Measuring Standards

Vertical and horizontal measurements listed in the vent diagrams were made using the following standards.

• Pipe measurements are shown using the effective length of pipe (see Figure 7.2).

• Measurements are made from the appliance outer wrap, not from the standoffs.

• Horizontal terminations are measured to the outside mounting surface (ﬂ ange of termination cap) (refer to Figure 6.2).

• Vertical terminations are measured to bottom of termination cap.

• Horizontal pipe installed level with no rise.

Effective

Height/Length

SLP Pipe

(see chart)

Figure 7.2 Pipe Effective Length

SLP12A 2 - 12 51 - 305

Effective Height/Length

Pipe

SLP4 4 102

SLP6 6 152 SLP12 12 305 SLP24 24 610 SLP36 36 914 SLP48 48 1219 SLP6A 2 - 6 51 - 152

inches

Heatilator • Eclipse • 4049-229 Rev F • 11/0824

Page 25

E. Vent Diagrams

To replace the ﬁ rst starter elbow with two 45° elbows, refer to Figure 7.4. All other 90° elbows can be replaced with two 45° elbows.

General Rules:

• SUBTRACT 3 ft. from the total H measurement for each 90° elbow installed horizontally.

• SUBTRACT 1-1/2 ft. from the total H measurement for each 45° elbow installed horizontally.

• A maximum of three 90° elbows (or six 45° elbows) may be used in any vent conﬁ guration. Some elbows may be installed horizontally. See Figure 7.9.

• Elbows may be placed back to back anywhere in the system as long as the ﬁ rst 90° elbow is a starter elbow except as shown in Figure 7.4.

• When penetrating a combustible wall, a wall shield ﬁ restop must be installed on both sides.

• When penetrating a combustible ceiling, a ceiling ﬁ restop must be installed.

• Horizontal runs of vent do not require vertical rise; horizontal runs may be level.

1. Top Vent - Horizontal Termination - (continued)

One Elbow

Figure 7.3

V1 min. V1 max. H1 max.

ft m ft m ft m

0* - - 1.67 0.51

0.5 0.15 - - 6 1.83 1 0.30 - - 11 3.35

1.5 0.46 - - 18 5.49

2 0.61 - - 25 7.62

- - 25 7.62 25 7.62

* You may install elbow directly on top of appliance.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 25

Page 26

1. Top Vent - Horizontal Termination - (continued)

Two 45° Elbows replacing One 90° Elbow

25 ft max.

(7.62 m)

Figure 7.4

4 ft min. (1.22 m)

Two Elbows

V1 min. V1 max. H1+H2 max. H1+H2+H3 max.

Note: For corner installations: A

6 in. (152 mm) section of straight pipe may need to be attached to the appliance before a 90º elbow, to allow the vent pipe to clear the top standoffs.

ft mftmftmftm

0.5 0.15 - - 6 1.83 - 1 0.30 - - 11 3.35 11 3.35

1.5 0.46 - - 18 5.49 18 5.49 2 0.61 - - 25 7.62 25 7.62

- - 25 7.62 25 7.62 25 7.62

Installed

Vertically

Installed

Horizontally

Figure 7.5

Heatilator • Eclipse • 4049-229 Rev F • 11/0826

Page 27

1. Top Vent - Horizontal Termination - (continued)

Three Elbows

V1 min. V1 + V2 max. H1+H2 max.

ft m ft m ft m 1 0.30 24 7.32 19 5.79

Figure 7.6

Heatilator • Eclipse • 4049-229 Rev F • 11/08 27

Page 28

2. Top Vent - Vertical Termination

No Elbow

Figure 7.7

12 ft (3.66 m) min.

60 ft (18.29 m) min.

Note: If installing a vertical vent/ termination off the top of the appliance, the ﬂ ue restrictor should be used.

Two Elbows

12 ft (3.66 m) min.

60 ft (18.29 m) max.

Maximum horizontal

run is 100% of

vertical, but cannot

exceed 26 ft (7.92 m)

Figure 7.8

Heatilator • Eclipse • 4049-229 Rev F • 11/0828

Page 29

2. Top Vent - Vertical Termination - (continued)

Three Elbows

Maximum horizontal run is

100% of vertical, but cannot

exceed 26 ft (7.92 m)

Figure 7.9

12 ft (3.66 m) min.

60 ft (18.29 m) max.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 29

Page 30

Vent Clearances and Framing

A. Pipe Clearances to Combustibles

WARNING! Risk of Fire! Maintain air space clearance to vent. DO NOT pack insulation or other combustibles:

• Between ceiling ﬁ restops

• Between wall shield ﬁ restops

• Around vent system Failure to keep insulation or other material away from vent

pipe may cause over heating and ﬁ re.

Note: Heat shields MUST overlap by a minimum of 1 1/2 in. (38 mm).

• SLP heat shield - designed to be used on a wall 4-3/8 in. to 7-5/8 in. (111 mm to 194 mm thick).

• If wall thickness is less than 4-3/8 the existing heat shields must

be field trimmed. If wall thickness is greater than 7-5/8 in. an extended heat shield will be required.

3 in.

(76 mm)

Drywall

1 in. (25 mm)

2 x 4 or 2 x 6 header

Air space clearance to bottom and sides of horizontal pipe must be at least 1 in. (25 mm)

No combustible framing to be located within shaded area.

3/4 in. (19 mm) minimum to

WALL

perpendicular wall.

B. Wall Penetration Framing

Combustible Wall Penetration

Whenever a combustible wall is penetrated, you must frame a hole for the wall shield ﬁ restops. A wall shield ﬁ restop maintains minimum clearances and prevents cold air inﬁ ltration.

• The opening must be framed on all four sides using the same size framing materials as those used in the wall construction.

• A wall shield ﬁ restop must be placed on each side of an interior wall. A minimum 1 1/2 in. (38 mm) overlap of attached heat shields must be maintained.

• See Section 10.L. for information for regarding the installation of a horizontal termination cap.

Non-Combustible Wall Penetration

If the hole being penetrated is surrounded by noncombustible materials such as concrete, a hole with diameter one inch greater than the pipe is acceptable.

Whenever a non-combustible wall is penetrated, the wall shield ﬁ restop is only required on one side and no heat shield is necessary.

10 in.

[254mm]

10 in.

[254mm]

Vent

framing

hole

* When using SLP pipe, minimum clearances from the vent pipe to

combustible materials at inside wall firestops are: Top: 2-1/2 in. (64 mm) Bottom: 1/2 in. (13 mm) Sides: 1 in. (25 mm)

Figure 8.1 Horizontal Venting Clearances To Combustible Materials

The center of the framing hole is 1 in. [25mm] above the center of the horizontal vent pipe.

Framing should be constructed of 2 X 4 lumber or heavier.

Figure 8.2 Wall Penetration

36 1/2 in. [927 mm]

(Center of pipe)

Heatilator • Eclipse • 4049-229 Rev F • 11/0830

Page 31

C. Install the Ceiling Firestop

A ceiling ﬁ restop MUST be used between ﬂ oors and attics.

• Frame opening 9 in. x 9 in. (229 mm x 229 mm) whenever the vent penetrates a ceiling/floor (see Figure 8.3).

• Frame the area with the same sized lumber as used in ceiling/ﬂ oor joist.

• The ceiling ﬁ restop may be installed above or below the ceiling joists when installed with a attic insulation shield. It must be under joists between ﬂ oors that are not insulated. Refer to Figure 8.4.

• Secure with three fasteners on each side.

WARNING! Risk of Fire! DO NOT pack insulation around the vent. Insulation must be kept back from the pipe to prevent overheating.

Attic Above

9 in. (229 mm)

9 in.

(229 mm)

Hole should measure

9 in. x 9 in.

(229 mm x 229 mm)

inside to inside

Figure 8.3 Installing Ceiling Firestop

Install attic insulation shields before or after installation of vent system.

3 fasteners

per side

Ceiling firestop

installed below ceiling.

Figure 8.4 Installing the Attic Shield

Ceiling firestop

installed above ceiling.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 31

Page 32

D. Install Attic Insulation Shield

WARNING! Fire Risk. DO NOT allow loose materials or insulation to touch vent. Hearth & Home Technologies Inc. requires the use of an attic shield.

The National Fuel Gas Code ANSI Z223.1 and NFPA 54 requires an attic shield constructed of 26 gauge minimum metal that extends at least 2 in. (51 mm) above insulation.

Attic shields must meet speciﬁ ed clearance and be se- cured in place.

Flat Ceiling Installation

• Remove one shield from box.

NOTICE: Cut previously installed batt insulation to make room for the attic insulation shield.

• Wrap shield around pipe if pipe is already installed in area to be insulated.

• Match the three holes in each side and fasten with three screws to form a tube.

• Bend three tabs on the bottom of the shield outward to allow attachment to the ceiling ﬁ restop.

• Bend the remaining bottom tabs inward 90° to maintain the air space between the pipe and the shield. Set the shield on the ceiling ﬁ restop and attach to the ﬁ restop.

• Bend all tabs inward 90° around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance.

Bend all tabs inward 90° to maintain clearance and prevent insulation from falling inside

Figure 8.5 Attic Insulation Shield



Insert 3 screws

Bend 4 tabs inward 90° to maintain clearance

Vaulted Ceiling Installation



• Remove one shield from box.

NOTICE: Cut previously installed batt insulation to make room for the attic insulation shield.

• Cut the attic insulation shield (if application is for vaulted



ceiling), to ﬁ t your ceiling pitch. Snip cut edge to recreate 1 in. bend tabs all the way around the bottom.

• Wrap shield around pipe if pipe is already installed in area to be insulated.

• Match the three holes in each side and fasten with three screws to form a tube.

• Bend three tabs on the bottom of the shield outward to allow attachment to the ceiling ﬁ restop.

• Bend the remaining bottom tabs inward 90° to maintain the air space between the pipe and the shield. Set the shield on the ceiling ﬁ restop and attach to the ﬁ restop.

• Bend all tabs inward 90° around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance.

Heatilator • Eclipse • 4049-229 Rev F • 11/0832

Page 33

Appliance Preparation

A. Securing and Leveling the Appliance

WARNING! Risk of Fire! Prevent contact with:

• Sagging or loose insulation

• Insulation backing or plastic

• Framing and other combustible materials Block openings into the chase to prevent entry of

blown-in insulation. Make sure insulation and other materials are secured.

DO NOT notch the framing around the appliance standoffs.

Failure to maintain air space clearance may cause overheating and ﬁ re.

The diagram shows how to properly position, level, and secure the appliance (see Figure 9.11). Nailing tabs are provided to secure the appliance to the framing members.

• Bend out nailing tabs on each side.

• Place the appliance into position.

• Keep nailing tabs ﬂ ush with the framing.

• Level the appliance from side to side and front to back.

• Shim the appliance as necessary. It is acceptable to use wood shims underneath the appliance.

• Secure the appliance to the framing by using nails or screws through the nailing tabs.

• Secure the appliance to the ﬂ oor by inserting two screws through the pilot holes at the bottom of the appliance.

Figure 9.1 Proper Positioning, Leveling And Securing Of An Appliance

Heatilator • Eclipse • 4049-229 Rev F • 11/08 33

Page 34

Installing SLP Vent Pipe

A. Assemble Vent Sections

To attach the ﬁ rst vent component to the starting collars of the appliance

• Lock the vent components into place by sliding the pipe section onto the collar.

• Align the seam of the pipe and seam of collar to allow engagement. Rotate the vent component to lock into place. Use this procedure for all vent components. See Figure 10.1.

• Slide the gasket over the ﬁ rst vent section and place it flush to the appliance. This will prevent cold air inﬁ ltration. High temperature caulk may be used to hold the part in place.

• Continue adding vent components, locking each succeeding component into place.

• Ensure that each succeeding vent component is securely ﬁ tted and locked into the preceding component.

Commercial, Multi-family (Multi-level exceeding

two stories), or High-Rise Applications

For Installation into a commercial, multi-family (multi-level exceeding two stories) or high-rise applications: All outer pipe joints must be sealed with high temperature silicone, including the slip section that connects directly to the horizontal termination cap.

• Apply a bead of silicone sealant inside the female outer pipe joint prior to joining sections.

• Only outer pipes need to be sealed. All unit collar, pipe, slip section, elbow and cap outer ﬂ ues shall be sealed in this manner, unless otherwise stated.

B. Assemble Slip Sections

WARNING! Risk of Fire or Asphyxiation! Overlap pipe sections at least 1 1/2 in. (38 mm). Secure slip sections with two screws which must not exceed 1/2 in. (13 mm) in length. Use the pilot holes. Pipe could separate if not properly joined.

• Slide the inner ﬂ ue of the slip section into the inner ﬂ ue of the pipe section and the outer ﬂ ue of the slip section over the outer ﬂ ue of the pipe section. See Figure 11.2.

• Slide together to the desired length.

Figure 10.2 Slip Section Pilot Holes

• Maintain a 1-1/2 in. (38 mm) overlap between the slip section and the pipe section.

• Secure the pipe and slip section with two screws no longer than 1/2 in. (13 mm), using the pilot holes in the slip section. See Figure 10.3.

WARNING! Risk of Fire or Explosion! DO NOT break silicone seals on slip sections. Use care when removing termination cap from slip pipe. If slip section seals are broken during removal of the termination cap, vent may leak.

2 - Rotate

1 - Align Seams

Figure 10.1 Adding Venting Components

Figure 10.3 Screws into Slip Section

• Continue adding pipe as necessary following instructions in “Assembling Pipe Sections.”

NOTICE: If slip section is too long, the inner and outer ﬂ ues of the slip section can be cut to the desired length.

NOTICE: When installing a vent system with an HRC termination cap, all pipe system joints shall be sealed using a high temperature silicone sealant.

• Apply a bead of silicone sealant inside the female outer

pipe joint prior to joining sections.

• Only outer pipes are sealed, sealing the inner ﬂ ue is not

required.

• All unit collar, pipe, slip section, elbow and cap outer ﬂ ues

shall be sealed.

Heatilator • Eclipse • 4049-229 Rev F • 11/0834

Page 35

C. Securing the Vent Sections

• Vertical runs of SLP pipe must be supported every 8 ft. (2.44 m).

• Horizontal sections of vent must be supported every 5 ft. (1.52 m) with a vent support or plumber’s strap.

• Wall shield ﬁ restops may be used to provide horizontal support.

• Vent support or plumber’s strap (spaced 120° apart) may be used for support. See Figures 10.4 and 10.5.

• SLP ceiling ﬁ restops have tabs that may be used to provide vertical support.

WARNING! Risk of Fire, Explosion or Asphyxi-

ation! Improper support may allow vent to sag and separate. Use vent run supports and connect vent sections per installation instructions. DO NOT allow vent to sag below connection point to appliance.

D. Disassemble Vent Sections

• Rotate either section (see Figure 10.6) so the seams on both pipe sections are aligned as shown in Figure

10.7.

• Pull carefully to separate the pieces of pipe.

Figure 10.6 Rotate Seams for Disassembly

Figure 10.4 Securing Vertical Pipe Sections

Figure 10.5 Securing Horizontal Pipe Sections

Figure 10.7 Align and Disassemble Vent Sections

Heatilator • Eclipse • 4049-229 Rev F • 11/08 35

Page 36

E. Installing Metal Roof Flashing

Note: Skip this section if using the RF4-8.

• See minimum vent heights for various pitched roofs (Figure 10.8) to determine the length of pipe to extend through the roof.

• Slide the roof ﬂ ashing over the pipe sections extending through the roof as shown in Figure 10.9.

NOTICE: Failure to properly caulk the roof ﬂ ashing could cause water entry.

• Caulk the gap between the roof ﬂ ashing and the outside diameter of the pipe.

• Caulk the perimeter of the ﬂ ashing where it contacts the roof surface. See Figure 10.9.

Horizontal overhang

24 in. min.

(610 mm)

Termination

Cap

Storm Collar

Roof

Flashing

Roof Pitch H (Min.) Ft. Roof Pitch H (Min.) Ft.

* 3 ft. minimum in snow regions

20 in.

(508 mm)

Lowest

Discharge

Opening

H (min.) - Minimum height from roof to lowest discharge opening.

Vertical wall

Roof Pitch is X / 12

Pipe

Caulk

Flashing

Figure 10.9

Figure 10.8 Minimum Height From Roof To Lowest Discharge Opening

Heatilator • Eclipse • 4049-229 Rev F • 11/0836

Page 37

F. Install RF4-8

The RF4-8 may be used in place of the roof ﬂ ashing and storm collar (Sections 10.E. and 10.H.)

Pipe must be supported within 12 in. (305 mm) of the rooﬂ ine using plumbers strapping or an SLP-FS when using the RF4-8 Flashing. Refer to Sect. 10.C. Securing Vent Sections.

Secure with 4 screws no longer than 1/2 in./13 mm

SLP-FS

Figure 10.10 Secure Pipe with SLP-FS

• Trim the rubber boot (using scissors or a utility knife), cutting along the marked measurement lines. See Figure

10.11. Use the 150 mm line.

• Lubricate pipe or ﬂ ue with water and slide the ﬂ ashing down. It may be necessary to trim the top shingles around the base of the rubber boot to ensure a good ﬁ t.

• Draw around ﬂ ashing, remove.

• Apply silicone sealant to roof inside the lines (Figure 10.12)

• Lubricate pipe or ﬂ ue with water and slide ﬂ ashing down. Seat ﬁ rmly in sealant. Nail roof ﬂ ashing to the roof.

• Apply silicone sealant on the top outside of the base plate on the sides and on top edge. See Figure 10.13. Install shingles, Apply sealant at the top edge of the rubber boot. See Figure 10.14.

• We recommend that you top coat with conventional acrylic house paint to improve the appearance of your galvanized base ﬂ ashing.

Figure 10.12 Apply Sealant

Apply Sealant

Top & Partial Sides

Figure 10.13 Slide Flashing Down, Secure & Apply Sealant

Silicone Sealant (top of boot)

Figure 10.11 Trim Rubber Boot

Shingles Trimmed

Flashing over Shingles

Figure 10.14 Installation Complete

Heatilator • Eclipse • 4049-229 Rev F • 11/08 37

Shingles over Flashing

Page 38

G. Installing Vertical Termination Cap

• Attach the vertical termination cap by sliding the inner collar of the cap into the inner ﬂ ue of the pipe section while placing the outer collar of the cap over the outer ﬂ ue of the pipe section.

• Secure the cap by driving three self-tapping screws (supplied) through the pilot holes in the outer collar of the cap into the outer ﬂ ue of the pipe (see Figure 10.15).

Termination Cap

H. Assemble and Install Storm Collar

CAUTION! Risk of Cuts, Abrasions or Flying Debris.

Wear protective gloves and safety glasses during installation. Sheet metal edges are sharp.

• Connect both halves of the storm collar with two screws (see Figure 10.15).

• Wrap the storm collar around the exposed pipe section closest to the roof and align brackets. Insert a bolt (provided) through the brackets and tighten the nut to complete the storm collar assembly. Make sure the collar is tight against the pipe section.

• Slide the assembled storm collar down the pipe section until it rests on the roof ﬂ ashing (see Figure 10.16).

• Caulk around the top of the storm collar (see Figure

10.15).

Brackets/

Bolts

Caulk

Figure 10.15

(1 of three)

Storm Collar

Screws

Figure 10.15 Assembling the Storm Collar

Figure 10.16 Assembling the Storm Collar Around the Pipe

Heatilator • Eclipse • 4049-229 Rev F • 11/0838

Page 39

I. Install Heat Shields and Horizontal Termination Cap

WARNING! Risk of Fire! To prevent overheating and ﬁ re, heat shields must extend through the entire wall thickness.

• DO NOT remove the heat shields attached to the wall shield ﬁ restop and the horizontal termination cap (shown in Figure 10.26).

• Heat shields must overlap 1-1/2 in. (38 mm) minimum.

There are two sections of the heat shield. One section is factory-attached to the wall shield ﬁ restop. The other section is factory-attached to the cap. See Figure 10.17.

If the wall thickness does not allow the required 1-1/2 in. (38 mm) heat shield overlap when installed, an extended heat shield must be used.

• If the wall thickness is less than 4-3/8 in./111 mm, the

heat shields on the cap and wall shield ﬁ restop must to be trimmed. A minimum 1-1/2 in. (38 mm) overlap MUST be maintained.

• Use an extended heat shield if the ﬁ nished wall thickness

is greater than 7-1/4 in. (184 mm).

• The extended heat shield may need to be cut to length

maintaining sufﬁ cient length for a 1-1/2 in. (38 mm) overlap between heat shields.

• Attach the extended heat shield to either of the existing

heat shields using the screws supplied with the extended heat shield. Refer to “Vent Components Diagrams” in the back of this manual.

• Rest the small leg on the extended heat shield on top

of the pipe section to properly space it from the pipe section.

Important Notice: Heat shields may not be ﬁ eld constructed.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 39

Page 40

Install Horizontal Termination Cap

WARNING! Risk of Fire! The telescoping ﬂ ue section of the termination cap MUST be used when connecting vent.

• 1-1/2 (38 mm) minimum overlap of ﬂ ue telescoping section is required.

Failure to maintain overlap may cause overheating and ﬁ re.

• Vent termination must not be recessed in the wall. Siding

may be brought to the edge of the cap base.

• Flash and seal as appropriate for siding material at

outside edges of cap.

• When installing a horizontal termination cap, follow the cap location guidelines as prescribed by current ANSI Z223.1 and CAN/CGA-B149 installation codes and refer to Section 6 of this manual.

CAUTION! Risk of Burns! Local codes may require installation of a cap shield to prevent anything or anyone from touching the hot cap.

NOTICE: For certain exposures which require superior resistance to wind-driven rain penetration, a ﬂ ashing kit and HRC caps are available. When penetrating a brick wall, a brick extension kit is available for framing the brick.

Note: When using termination caps with factory-supplied heat shield attached, no additional wall shield ﬁ restop is required on the exterior side of a combustible wall.

Heat Shield or

Extended

Wall Shield

Firestop

Inner Vent

Outer Vent

Vent depth from back of appliance to

outside surface of exterior wall

(see chart below)

Figure 10.17 Venting through the wall

Cap Speciﬁ cation Chart (depth without

Heat Shield

Slip Section

can be extended

INTERIOR

using additional pipe sections)

Heat Shield

1-1/2 in. (38 mm) min.

overlap

SHEATHING

EXTERIOR

SLP-TRAP1

Top Vent Depth

EDV Series

SLP-TRAP1 can adjust 1 5/8 in. (3 1/8 to 4 3/4)

SLP-TRAP2 can adjust 4 in. (5 1/4 to 9 1/4)

Heatilator • Eclipse • 4049-229 Rev F • 11/0840

2 to 3 7/8 in.

SLP-TRAP2

Top Vent Depth

4 3/8 to 8 3/8 in.

Page 41

Gas Information

A. Fuel Conversion

• Make sure the appliance is compatible with available gas types.

• Conversions must be made by a qualified service technician using Hearth & Home Technologies speciﬁ ed and approved parts.

B. Gas Pressure

• Optimum appliance performance requires proper input pressures.

• Gas line sizing requirements will be determined in ANSI Z221.3 National Fuel Gas Code in the USA and CAN/ CGA B149 in Canada.

• Pressure requirements are:

Gas Pressure Natural Gas Propane

Minimum inlet pressure 5.0 in. w.c. 11.0 in. w.c. Maximum inlet pressure 7.0 in. w.c. 14.0 in. w.c. Manifold pressure 3.5 in. w.c. 10.0 in. w.c.

WARNING! Risk of Fire or Explosion! High pressure will damage valve. Low pressure may cause explosion.

• Verify inlet pressures. Verify minimum pressures when other household gas appliances are operating.

• Install regulator upstream of valve if line pressure is greater than 1/2 psig.

C. Gas Connection

• Refer to Reference Section 16 for location of gas line access in appliance.

• Gas line may be run through knockout(s) provided.

• The gap between supply piping and gas access hole may be caulked with high temperature caulk or stuffed with non-combustible, unfaced insulation to prevent cold air inﬁ ltration.

• Ensure that gas line does not come in contact with outer wrap of the appliance. Follow local codes.

• Pipe incoming gas line into valve compartment.

• Connect incoming gas line to the 1/2 in. (13 mm) connection on manual shutoff valve.

WARNING! Risk of Fire or Explosion! Support control when attaching pipe to prevent bending gas line.

• A small amount of air will be in the gas supply lines.

WARNING! Risk of Fire or Explosion! Gas build-up during line purge could ignite.

• Purge should be performed by qualified service technician.

• Ensure adequate ventilation.

• Ensure there are no ignition sources such as sparks or open ﬂ ames.

Light the appliance. It will take a short time for air to purge from lines. When purging is complete the appliance will light and operate normally.

WARNING

Fire Risk. Explosion Hazard. High pressure will damage valve.

• Disconnect gas supply piping BEFORE pressure testing gas line at test pressures above 1/2 psig.

• Close the manual shutoff valve BEFORE pressure testing gas line at test pressures equal to or less than 1/2 psig.

Note: Have the gas supply line installed in accordance with local codes, if any. If not, follow ANSI 223.1. Installation should be done by a qualiﬁ ed installer approved and/or licensed as required by the locality. (In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas ﬁ tter).

Note: A listed (and Commonwealth of Massachusetts approved) 1/2 in. (13 mm) T-handle manual shut-off valve and ﬂ exible gas connector are connected to the 1/2 in. (13 mm) control valve inlet.

• If substituting for these components, please consult local codes for compliance.

WARNING! Risk of Fire, Explosion or Asphyxiation!

Check all ﬁ ttings and connections with a non-corrosive commercially available leak-check solution. DO NOT use open ﬂ ame. Fittings and connections could have loos- ened during shipping and handling.

WARNING! Risk of Fire! DO NOT change valve settings. This valve has been preset at the factory.

D. High Altitude Installations

NOTICE: If the heating value of the gas has been reduced, these rules do not apply. Check with your local gas utility or authorities having jurisdiction.

When installing above 2000 feet elevation:

• In the USA: Reduce burner oriﬁ ce 4% for each 1000 feet above 2000 feet.

• In CANADA: Reduce burner oriﬁ ce 10% for elevations between 2000 feet and 4500 feet. Above 4500 feet, consult local gas utility.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 41

Page 42

Electrical Information

A. Wiring Requirements

NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code

ANSI/NFPA 70-latest edition or the Canadian Electric Code CSA C22.1.

• Wire the appliance junction box to 110-120 VAC. This is required for use of optional accessories (standing pilot ignition) or proper operation of the appliance (Intelliﬁ re ignition).

• Low voltage and 110 VAC voltage cannot be shared within the same wall box.

WARNING! Risk of Shock or Explosion! DO NOT wire 110V to the valve or to the appliance wall switch. Incorrect wiring will damage controls.

Determine if the appliance uses an Intelliﬁ re ignition sys- tem or standing pilot ignition system:

• Open the control access panel.

• A red or black ignitor button (as shown in Figure 12.1) indicates this appliance is standing pilot ignition.

B. Standing Pilot Ignition System Wiring

• Refer to Figure 12.2, Standing Pilot Wiring Diagram

• The standing pilot ignition system wiring does not require a 110 VAC supply to operate.

• A 110 VAC junction box MUST be installed for use with a fan or remote control. See Figure 12.5 for junction box wiring. Keep wire lengths short as possible.

C. Intelliﬁ re Ignition System Wiring

• Wire the appliance junction box to 110 VAC for proper operation of the appliance.

WARNING! Risk of Shock or Explosion! DO NOT wire IPI controlled appliance junction box to a switched circuit. Incorrect wiring will override IPI safety lockout.

• Refer to Figure 12.3, Intelliﬁ re Pilot Ignition (IPI) Wiring Diagram.

• This appliance is equipped with an Intelliﬁ re control valve which operates on a 3 volt system.

• Plug the 3-volt AC transformer into the appliance junction box to supply power to the unit OR install two D cell batteries (not included) into the battery pack before use.

NOTICE: Batteries should not be placed in the battery pack while using the transformer. Remove batteries before using the transformer, and unplug the transformer before installing the batteries. Battery polarity must be correct or module damage will occur.

Red or Black

Button

Figure 12.1 Ignitor Button

D. Optional Accessories Requirements

• This appliance may be used with a wall switch or a remote control.

• Wiring for optional Hearth & Home Technologies approved accessories should be done now to avoid reconstruction. Follow instructions that come with those accessories.

Heatilator • Eclipse • 4049-229 Rev F • 11/0842

Page 43

E. Electrical Service and Repair

WARNING! Risk of Shock! Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.

WARNING! Risk of Shock! Replace damaged wire with type 105° C rated wire. Wire must have high temperature insulation.

Ignitor

Thermocouple

Copper Tubing

ORG

Push Button Ignitor

Gas Inlet

GAS

VALVE

Figure 12.2 Standing Pilot Ignition Wiring Diagram

Pilot

Thermopile

Inlet Tap

TAN

BRN

Outlet Tap

RED

WHT

To Burner

Switch

WHT

GRN (not used)

Battery

Pack

Switch

RED

WHT

GRN

(not used)

Adapter

BLK

WHT

RED

Figure 12.3 Intelliﬁ re Pilot Ignition (IPI) Wiring Diagram

Junction

RED

Box

BRN

Valve

Control

Box

BLK

ORG

GRN

Ignitor

Flame

Sensor

ORG

Pilot Assembly

WHT

Heatilator • Eclipse • 4049-229 Rev F • 11/08 43

Page 44

F. Junction Box Installation

If the box is being wired from the OUTSIDE of the appliance:

• Remove the cover plate located on the outer shell - right side (see Figure 12.4).

• Install the supplied Romex™ connector in the cover plate.

If the box is being wired from the INSIDE of the appliance:

• Remove the screw attaching the junction box/receptacle to the outer shell, rotate the junction box inward to disengage it from the outer shell (see Figure 12.4).

• Pull the electrical wires from outside the appliance through this opening into the valve compartment. See Figure

12.4.

G. Wall Switch Installation for Fan (Optional)

If the box is being wired to a wall mounted switch for use with a fan (See Figure 12.5):

• The power supply for the appliance must be brought into a switch box.

• The power can then be supplied from the switch box to the appliance using a minimum of 14-3 with ground wire.

• At the switch box connect the black (hot) wire and red (switch leg) wire to the wall switch as shown.

• At the appliance connect the black (hot), white (neutral) and green (ground) wires to the junction box as shown.

• Add a 1/4 in. insulated female connector to the red (switch leg) wire, route it through the knockout in the face of the junction box, and connect to the top fan switch connector (1/4 in. male) as shown.

WHT

BLK

WHT

BLK

GRN wire inside box

Figure 12.4 Junction Box Detail

Minimum 14-3 AWG with Ground

Junction Box

Red

Black

Green

White

Red

Black

Romex Connector

14/2WG

Cover Plate outside firebox

Copper ground attached to GRN screw with GRN wire

NOTICE: DO NOT wire 110 VAC to wall switch.

White

Green

Switch Box

Black

White

Green

Switch

Power

Supply

Wires

Knockout

Red

Figure 12.5 Junction Box Wired to Wall Switch or BC10

Heatilator • Eclipse • 4049-229 Rev F • 11/0844

Page 45

Finishing

A. Mantel and Wall Projections

Mantels

Note: All

measurements in inches.

10-1/4

9-1/2

8-3/4

13-1/4

12-1/2

11- 3/4

Measured from top of fireplace opening (in inches)

15-1/2

14-3/4

16-1/4

17-3/4

18-1/2

19-1/4

30 in. minimum

to ceiling

B. Facing Material

• Metal front faces may be covered with non-combustible materials only.

• Facing and/or ﬁ nishing materials must not interfere with air ﬂ ow through louvers, operation of louvers or doors, or access for service.

• Facing and/or ﬁ nishing materials must never overhang into the glass opening.

• Observe all clearances when applying combustible materials.

• Seal joints between the ﬁ nished wall and appliance top and sides using a 300 °F minimum sealant. Refer to Figure 13.3.

WARNING! Risk of Fire! DO NOT apply combustible materials beyond the minimum clearances. Comply with all minimum clearances to combustibles as speciﬁ ed in this manual. Overlapping materials could ignite and will interfere with proper operation of doors and louvers.

Finish wall material may be combustible - Top and Sides

0 in.

Figure 13.1 Minimum Vertical and Maximum Horizontal Dimensions

Combustible Mantel Legs/Wall Projections

Top o f Appliance

Drywall

2 in. (51 mm) min. from fireplace opening to perpendicular wall

Figure 13.2 Mantel Leg or Wall Projections (Acceptable on both sides of opening)

Mantel Leg or

Perpendicular Wall

0 in.

High Temperature Sealant (300° F/149° C min.)

Top and Side Seal Joint

Figure 13.3 Noncombustible Facing Diagram

Heatilator • Eclipse • 4049-229 Rev F • 11/08 45

Page 46

Appliance Setup

A. Remove Packaging Materials

Face parts are shipped in tube on glass protector. To remove glass protector unlatch top glass latches and remove glass protector.

Glass Latches

Face Parts Inside

Figure 14.1 Face Parts Location

• Pull the four glass assembly latches out of the groove

on the glass frame. See Figure 14.3

Latches

(both bottom

and top)

Glass

Assembly

Figure 14.3 Glass Assembly

• Remove the glass panel from the appliance.

• Lay aside on a nonabrasive surface.

C. Logs

Logs are factory installed.

Glass Latches

Face Parts Inside

Figure 14.2 Parts Identiﬁ cation

B. Remove Glass Assembly

WARNING! Risk of Asphyxiation! Handle ﬁ xed glass assembly with care. Inspect the gasket to ensure it is undamaged and inspect the glass for cracks, chips or scratches.

• DO NOT strike, slam or scratch glass.

• DO NOT operate ﬁ replace with glass removed, cracked,

broken or scratched.

• Replace as a complete assembly.

Figure 14.4 Log Set

D. Place Lava Rock, Rockwool

WARNING! Risk of Explosion! Follow rockwool placement instructions. DO NOT place rockwool directly over burner ports. Replace rockwool material annually. Improperly placed rockwool interferes with proper burner operation.

• Place the lava rock in front of air slots and to the areas

left and right of burner pan. See Figure 14.5.

Figure 14.5 Placement of Lava Rock

Heatilator • Eclipse • 4049-229 Rev F • 11/0846

Page 47

• Place a small amount of 1/2 in. (13 mm) diameter pieces (dime-size) of rockwool on the burner pan so that the rockwool touches but does not cover the holes in the burner pan. This will provide the “glowing embers” look. It is not necessary to use the entire bag. Save the remaining rockwool for future use. See Figure 14.6.

Figure 14.6 Placement of Rockwool

G. Grilles and Screen

• Lay top grille face down so the thin tabs are pointing up.

• Spread screen out next to the tab side of the grille.

• Starting with one corner of the screen, thread the ﬁ rst loop of the screen over the ﬁ rst tab on top grille and continue threading the screen over tabs along edge of top grille. Adjust screen so it lays evenly (not bunched or too tight between tabs).

Ta b

E. Replace Glass

Replace the glass assembly on the lower access latches and rotate the upper portion of the glass assembly into place. Engage the top access latches. Engage lower access latches.

F. Install Floor Cover

Place ﬂ oor cover (painted side up) as shown in Fig- ure 14.7.

Figure 14.8 Lay Out Screen

• Bend tabs 90 degrees away from the screen with needle nose pliers to secure the screen to top grille. See Figure 14.9.

Figure 14.9 Bend Tabs to Hold Screen

• Place the tabs of the top grill over the shoulder screws on each end. See Figure 14.10.

Figure 14.7 Place Floor Cover

Figure 14.10 Attach Top Grill - Left Side Shown

Heatilator • Eclipse • 4049-229 Rev F • 11/08 47

Page 48

• Swivel the top grill toward the unit and apply slight pressure downward and push forward until the notch locks into the slot. Refer to Figure 14.11.

• To remove grill, apply slight pressure downward (center of grill) and pull out.

Notch

Slot

Figure 14.11 Attach Top Grill - Middle

• Attach screen retaining clips through screen and snap into holes provided in columns.

• Attach the bottom grille by aligning slots of bottom grille with shoulder screws in columns. See Figure 14.12.

H. Air Shutter Setting

This appliance has an adjustable air shutter (which controls the primary air) that can be accessed under the valve compartment located under the ﬁ rebox assembly (Figure 14.13). The air shutter is factory set for the minimum vertical vent run. If your installation has more than the minimum required vertical vent length, adjustment of the air shutter may be necessary to obtain optimal ﬂ ame appearance. This should be adjusted by a qualiﬁ ed

installer at the time of installation.

Air Shutter

Thumb Screw

Figure 14.13 Air Shutter

Figure 14.12 Attach Bottom Grille

NOTICE: Do not force thumb screw - air shutter slide could be damaged!

In the event of soot accumulation inside your appliance, the air shutter should be opened further. When the shutter adjustment handle is all the way down, the air shutter is in the open position. When the shutter adjustment handle is all the way up, the air shutter is in the fully closed position.

I. Accessories

Install approved accessories per instructions included with accessories. Contact your dealer for a list of approved accessories.

WARNING! Rick of Fire and Electric Shock! Use ONLY Hearth & Home Technologies-approved optional accessories with this appliance. Using non-listed accessories could result in a safety hazard and will void the warranty.

Heatilator • Eclipse • 4049-229 Rev F • 11/0848

Page 49

Troubleshooting

With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualiﬁ ed service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualiﬁ ed service technician. Con- tact your dealer to arrange a service call by a qualiﬁ ed service technician.

A. Standing Pilot Ignition System

Symptom Possible Causes Corrective Action

1. After repeated triggering of the red or black piezo ignitor button, the spark ignitor will not light the pilot. Check for spark.

A. No gas or low gas pressure. Check the remote shut-off valves from the appliance. Usually, there

is a valve near the gas main. There can be more than one valve

between the appliance and the main. B. No lp in tank. Check the LP (propane) tank. You may be out of fuel. C. Ignitor. Check the spark at the electrode and pilot. If no spark and electrode

wire is properly connected, replace the ignitor. Verify that there is

no short in electrode wire. D. Pilot or misaligned electrode

(spark at electrode).

Using match, light the pilot. If the pilot lights, turn off the pilot and

trigger the piezo ignitor button again. If the pilot lights, an improper

gas/air mixture caused the bad lighting and a longer purge period

is recommended. If the pilot will not light, ensure the gap at the

electrode and pilot is one-eighth inch to have a strong spark. If the

gap is OK, replace the pilot.

2. The pilot will not stay lit after carefully following the lighting instructions.

3. The pilot is burning, there is no burner ﬂ ame, the valve knob is in the ON position, and the ON/OFF switch is in the ON position.

A. Thermocouple. Check that the pilot ﬂ ame impinges on the thermocouple. Adjust the

pilot for proper ﬂ ame impingement. Ensure that the thermocouple connection at the gas valve is fully

inserted and tight (hand tighten plus 1/4 turn). Verify proper voltage output from the thermocouple to the valve.

Place one millivolt meter lead wire on the thermocouple copper lead. Place the second lead wire on the solder button on the back of the valve (blue wire). Start the pilot and hold the valve knob in. The millivolt reading should read 8-16 millivolts. If millivolt reading is less than 8 millivolts, replace thermocouple.

B. Improper gas inlet pressure. Natural gas should be 5-14 in. w.c. LP should be 10-14 in. w.c.

Verify pressure with manometer.

C. Control valve. If the thermocouple is producing 8-16 millivolts, replace control

valve.

A. On/off switch or wires

defective.

B. Thermopile may not be

generating sufﬁ cient millivoltage.

Check the ON/OFF switch and wires for proper connections. Place the jumper wires across the terminals at the ON/OFF switch. If the burner comes on, replace the ON/OFF switch. If the switch is OK, place the jumper wires across the ON/OFF switch wires at the gas valve. If the burner comes on, the wires are faulty or connections are bad.

Check that the pilot ﬂ ame impinges thermopile properly. Be sure the wire connections from the thermopile at the gas valve

terminals are tight and that the thermopile is fully inserted into the pilot bracket.

Check the thermopile with a millivolt meter. Take the reading at TH-TP&TP terminals of the gas valve. The meter should read 350 millivolts minimum, while holding the valve knob depressed in the pilot position, with the pilot lit, and the ON/OFF switch in the OFF position. Replace the thermopile if the reading is below the speciﬁ ed minimum.

With the pilot in the ON position, disconnect the thermopile leads from the valve. Take a reading at the thermopile leads. The reading should be 350 millivolts minimum. Replace the thermopile if the reading is below the minimum.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 49

Page 50

Troubleshooting (continued)

Symptom Possible Cause Corrective Action

3. (Continued) C. Failed valve. Turn the valve knob to the ON position. Place the ON/OFF switch

in the ON position. Check the millivolt meter a the thermopile terminals. The millivolt meter should read greater than 125mV. If the reading is acceptable, and if the burner does not come on, replace the gas valve.

D. Plugged burner oriﬁ ce. Check the burner oriﬁ ce for stoppage. Remove stoppage.

E. Wall switch or wires. Check the wall switch and wires for proper connections. Place the

jumper wires across the terminals at the wall switch. If the burner comes on, replace the wall switch. If the wall switch is OK, place the jumper wires across the wall switch wires at the gas valve. If the burner comes on, the wires are faulty or connections are bad.

4. Frequent pilot outage problem.

5. The pilot and main burner extinguish while in operation.

6. Glass soots. A. Flame impingement. Adjust the log set so that the ﬂ ame does not excessively impinge on

7. Flame burns blue and lifts off burner.

A. Pilot ﬂ ame may be too high or

too low, or blowing out (high pressure), causing pilot safety to drop out.

A. No LP in tank. Check the LP (propane) tank. Reﬁ ll the fuel tank. B. Improper gas inlet pressure. Verify with manometer. NG should read 5-14 inches w.c. LP should

C. Inner vent pipe leaking exhaust

gases back into the system.

D. Glass installed improperly. Check to ensure glass is installed properly. Replace glass panel

E. Failed thermopile or

thermocouple.

F. Improper vent cap installation. Check for proper installation and freedom from debris or blockage.

B. Improper air shutter setting. Refer to manual for shutter set points. Ensure that set point is

C. Debris around air shutter. Inspect the opening at the base of the burner. NO MATERIAL

A. Insufﬁ cient oxygen being

supplied.

Clean thermocouple and adjust the pilot ﬂ ame for proper ﬂ ame impingement. Follow lighting instructions carefully.

read 10-14 inches w.c. Check venting system for damage. Replace/repair improperly

assembled pipe sections.

assembly. Replace pilot if necessary.

it. Refer to log instructions.

correct for appliance/gas type. If unit has adjustable shutter, it may be necessary to increase shutter opening.

SHOULD BE PLACED IN THIS OPENING. Ensure that the vent cap is installed properly and free of debris.

Ensure that the vent system joints are tight and have no leaks. Ensure that no debris has been placed at the base of, or in the area

of the air holes in the center of the base pan beneath the burner.

Ensure that the glass is tightened properly on the unit, particularly on top corners.

Heatilator • Eclipse • 4049-229 Rev F • 11/0850

Page 51

B. Intelliﬁ re Ignition System

Symptom Possible Cause Corrective Action

1. Pilot won’t light. The ignitor/module makes noise, but no spark.

A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are

B. Loose connections or electrical

shorts in the wiring.

C. Ignitor gap is too large. Verify gap of igniter to right side of pilot hood. The gap should be

D. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove

connected to correct terminals on module and pilot assembly.

Verify no loose connections or electrical shorts in wiring from module to pilot assembly. Verify connections underneath pilot assembly are tight; also verify connections are not grounding out to metal chassis, pilot burner, pilot enclosure, mesh screen if present, or any other metal object.

approximately .17 inch or 1/8 in. (3 mm).

ignitor wire “I” from module. Place a grounded wire about 3/16 in. (5 mm) away from “I” terminal on module. Place ON/OFF rocker switch or wall switch in ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is ﬁ ne. Inspect pilot assembly for shorted sparker wire or cracked insulator around electrode. Replace pilot if necessary.

2. Pilot won’t light, there is no noise or spark.

3. Pilot sparks, but Pilot will not light.

A. No power or transformer

installed incorrectly.

B. A shorted or loose connection

in wiring conﬁ guration or wiring harness.

C. Improper wall switch wiring. Verify that 110/VAC power is “ON” to junction box.

D. Module not grounded. Verify black ground wire from module wire harness is grounded to

E. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove

A. Gas supply. Verify that incoming gas line ball valve is “open”. Verify that inlet

B. Ignitor gap is incorrect. Verify that spark gap from ignitor to pilot hood is .17 in. or 1/8 in (3

C. Module is not grounded. Verify module is securely grounded to metal chassis of appliance.

Verify that transformer is installed and plugged into module. Check voltage of transformer under load at spade connection on module with ON/OFF switch in ON position. Acceptable readings of a good transformer are between 3.2 and 2.8 volts AC.

Remove and reinstall the wiring harness that plugs into module. Verify there is a tight ﬁ t. Verify pilot assembly wiring to module. Remove and verify continuity of each wire in wiring harness. Replace any damaged components.

metal chassis of appliance.

ignitor wire “I” from module. Place ON/OFF rocker switch or wall switch in ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is ﬁ ne. Inspect pilot assembly for shorted sparker wire or cracked insulator around electrode.

pressure reading is within acceptable limits, inlet pressure must not exceed 14 in. W.C.

mm).

D. Module voltage output / Valve/

Pilot solenoid ohms readings.

Heatilator • Eclipse • 4049-229 Rev F • 11/08 51

Verify battery voltage is at least 2.7 volts. Replace batteries if voltage is below 2.7.

Page 52

Intelliﬁ re Ignition System - (continued)

Symptom Possible Cause Corrective Action

4. Pilot lights but continues to spark, and main burner will not ignite. (If the pilot continues to spark after the pilot ﬂ ame has been lit, ﬂ ame rectiﬁ cation has not occurred.)

A. A shorted or loose connection

in ﬂ ame sensing rod.

B. Poor ﬂ ame rectiﬁ cation or

contaminated ﬂ ame sensing rod.

C. Module is not grounded. Verify module is securely grounded to metal chassis of appliance.

Verify all connections to wiring diagram in manual. Verify connections underneath pilot assembly are tight. Verify connections are not grounding out to metal chassis, pilot burner, pilot enclosure or screen if present, or any other metal object.

With ﬁ xed glass assembly in place, verify that ﬂ ame is engulﬁ ng ﬂ ame sensing rod on left side of pilot hood. Flame sensing rod should glow shortly after ignition. Verify correct pilot oriﬁ ce is installed and gas inlet is set to pressure speciﬁ cations.

Verify that wire harness is ﬁ rmly connected to the module.

D. Damaged pilot assembly or

contaminated ﬂ ame sensing rod.

E. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove

Verify that ceramic insulator around the ﬂ ame sensing rod is not cracked, damaged, or loose. Verify connection from ﬂ ame sensing rod to white sensor wire. Clean ﬂ ame sensing rod with emery cloth to remove any contaminants that may have accumulated on ﬂ ame sensing rod. Verify continuity with a multimeter with ohms set at lowest range. Replace pilot if any damage is detected.

Heatilator • Eclipse • 4049-229 Rev F • 11/0852

Page 53

Reference Materials

A. Appliance Dimension Diagram

Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3.

17-1/8 in.

435 mm

10-7/8 in.

276 mm

33-1/4 in./845 mm

35-1/2 in./902 mm

5 in.

127 mm

33-1/2 in.

851 mm

6-1/2 in. 165 mm

Figure 16.1 Appliance Dimensions

3 in.

76 mm

28-1/2 in.

724 mm

20-5/8 in.

524 mm

3/4 in.

19 mm

Alternative

Gas

Access

2-3/16 in.

56 mm

5-3/8 in. 137 mm

12-5/8 in.

321 mm

Heatilator • Eclipse • 4049-229 Rev F • 11/08 53

Page 54

B. Vent Components Diagrams

6-1/2 in. 165 mm

8-3/4 in. 222 mm

6-5/8 in. 168 mm

SLP-45 - 45° Elbow

Effective Height/Length

Pipe

Effective

Height/ Length

SLP-Pipe

SLP4 4 102

SLP6 6 152 SLP12 12 305 SLP24 24 610 SLP36 36 914 SLP48 48 1219 SLP6A 2 - 6 51 - 152

SLP12A 2 - 12 51 - 305

inches mm

6 in.

152 mm

6-1/2 in. 165 mm

9-1/4 in. 235 mm

6-5/8 in. 168 mm

9-7/8 in. 251 mm

SLP-90ST - 90° Elbow

Figure 16.2 SLP Series Vent Components

SLP-FS

Ceiling Firestop

Heatilator • Eclipse • 4049-229 Rev F • 11/0854

SLP-HVS

Horizontal Pipe

Support

SLP-WS

Wall Shield Firestop

RF4-8

Roof Flashing

26 in.

(660 mm)

DVP-HSM-B

Extended Heat Shield

Page 55

B. Vent Components Diagrams (continued)

SLK-SNKD

Snorkel

Termination Cap

DVP-FBHT

Horizontal Termination Cap

(This termination cap requires

an SL-2DVP adapter when

used with SLP Pipe)

SLP-TVHW

Vertical

15 in.

(381 mm)

SL-2DVP

Adapter

8-1/8 in.

(206 mm)

PVK-80

Power Vent

13 in.

(330 mm)

SLP-TRAP1

Horizontal

Termination Cap

SLP-TRAP2

Horizontal

Termination Cap

Figure 16.3 SLP Series Vent Components

SLP-HRC-SS

Effective Length 5-3/4 to 8-3/8 in.

146 to 213 mm

Heatilator • Eclipse • 4049-229 Rev F • 11/08 55

5-1/2 in. 140 mm

87°

8-3/8 in. 213 mm

3°

10-1/2 in.

267 mm

10-7/8 in.

276 mm

SLP-HRC-ZC-SS

Page 56

C. Service Parts

EDV3633

Ending Manufacturing Date: Active

Beginning Manufacturing Date: April 2008

Service Parts List

Eclipse DV

Service Parts

Stocked

at Depot

4049-015

4049-031

4049-032

4049-033

Front Log Assembly

Side Log Assembly

Back Log Assembly

Log Assembly

4049-217

33858

Top Face

Glass Clip Support Assembly Qty 4 req.

4049-034

4049-035

4049-170

4049-053

Burner Pan Top

Burner Pan Gasket

Burner Pan Assembly NG

Burner Pan Assembly LP

4049-123

4049-217

4049-193

4049-218

Burner Pan Bottom

Top Face

Screen

Bottom Face

4049-226

4049-160

4049-161

Floor Cover

Air Shutter

Air Shutter Bracket

4021-013

4031-222

Junction Box

Junction Box Cover Plate

SLK-01TRD

SLP-TRAP2

4049-229

SL-90D

Pre GA1760888

Post GA 1760888

Long Horizontal Term Cap Kit

Ecilpse Installation Instructions

90 degree Elbow

Trapezoid Term Cap 6 5/8

4042-341

14333B

Mineral Wool

Lava Rock Bag Assembly

4021-295

Lava Rock

N/A

SCKP-EHS

29476

29477

NGK-11

Pilot Oriﬁ ce NG

Pilot Oriﬁ ce LP

Conversion Kit NG

Regulator NG

Conversion Kit LP

08/08

LPK-11

Regulator LP

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement

EDV3633

Ending Manufacturing Date: Active

Beginning Manufacturing Date: April 2008

Service Parts

Service Parts Diagram

Ecilpse DV

ITEM DESCRIPTION COMMENTS PART NUMBER

parts for your appliance please provide model number and serial number. All parts listed

in this manual may be ordered from an authorized dealer.

10 Glass/Frame Assembly 4049-039

Additional service part numbers on following page.

08/08

Log Set Assembly

Heatilator • Eclipse • 4049-229 Rev F • 11/0856

Page 57

C. Service Parts (continued)

Stocked

at Depot

4049-015

4049-031

4049-032

Ending Manufacturing Date: Active

Beginning Manufacturing Date: April 2008

EDV3633I, EDV3633IL

Service Parts List

Eclipse DV

Service Parts

4049-033

Log Assembly

4049-217

33858

Top Face

4049-034

4049-035

4049-170

4049-053

Burner Pan Assembly NG

Burner Pan Assembly LP

4049-123

4049-217

4049-193

4049-218

4049-226

4049-160

4049-161

4021-013

4031-222

Junction Box

Junction Box Cover Plate

SLK-01TRD

SLP-TRAP2

4049-229

SL-90D

Pre GA1760888

Post GA 1760888

Long Horizontal Term Cap Kit

Ecilpse Installation Instructions

90 Degree Elbow

Trapezoid Term Cap 6 5/8

4042-341

14333B

Mineral Wool

Lava Rock Bag Assembly

4021-295

Lava Rock

DCKN-EHS

DCKP-EHS

593-528

593-527

NPK-DXF

Pilot Oriﬁ ce NG

Pilot Oriﬁ ce LP

Conversion Kit NG

Regulator NG

Conversion Kit LP

08/08

LPK-DXF

Regulator LP

1 Front Log Assembly

2 Side Log Assembly

ITEM DESCRIPTION COMMENTS PART NUMBER

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement

parts for your appliance please provide model number and serial number. All parts listed

in this manual may be ordered from an authorized dealer.

Ending Manufacturing Date: Active

Beginning Manufacturing Date: April 2008

EDV3633I, EDV3633IL

Service Parts

Service Parts Diagram

Ecilpse DV

3 Back Log Assembly

5 Glass Clip Support Assembly Qty 4 req.

7 Burner Pan Top

8 Burner Pan Gasket

9 Burner Pan Bottom

10 Glass/Frame Assembly 4049-039

11 Top Face

12 Screen

13 Bottom Face

14 Floor Cover

15 Air Shutter

16 Air Shutter Bracket

Log Set Assembly

Additional service part numbers on following page.

08/08

Heatilator • Eclipse • 4049-229 Rev F • 11/08 57

Page 58

C. Service Parts (continued)

Ending Manufacturing Date: Active

Stocked

at Depot

08/08

4049-050 N

4049-051 N

2090-012 Y

2090-013 Y

4021-042 N

4021-435 Y

4021-426 Y

4021-428 Y

17069 N

593-500 Y

593-501 Y

302-320A Y

4049-169 N

4021-429 N

593-593A Y

593-592 Y

593-590A Y

4018-018 Y

593-594A Y

Beginning Manufacturing Date: April 2008

EDV3633I, EDV3633IL

Service Parts

Valve Assembly Parts Diagram

Eclipse DV

IPI Valve Assembly

EDV3633

Valve Assembly NG

Valve Assembly LP

Pilot Assembly NG

Pilot Assembly LP

Oriﬁ ce NG, Threaded (.083)

Oriﬁ ce LP, Threaded (.053)

Valve NG

2 Pilot Gasket

4 Bulkhead

ITEM DESCRIPTION COMMENTS PART NUMBER

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement

parts for your appliance please provide model number and serial number. All parts listed

in this manual may be ordered from an authorized dealer.

Stocked

at Depot

5 Male connector Brass-Flex

Valve LP

7 Flex Ball Valve Assembly

8 Valve Bracket

9 Bulkhead Gasket

11 Control Module

10 3V Adapter Plug

12 Wire Assembly

Wall Switch Wire Assembly M/M

Battery Pack

08/08

Ending Manufacturing Date: Active

Beginning Manufacturing Date: April 2008

Service Parts

Valve Assembly Parts Diagram

Eclipse DV

Standing Pilot Valve Assembly

4049-048 N

4049-049 N

2103-010 Y

2103-011 Y

30494 Y

30495 Y

302-320A Y

291-513 Y

4049-169 N

17069 N

4021-429 N

4021-428 Y

4021-435 Y

4021-426 Y

4041-042 N

28602 Y

Valve Assembly NG

Valve Assembly LP

Pilot Assembly NG

Pilot Assembly LP

Valve NG

Valve LP

3 Flex Ball Valve Assembly

4 Piezo Ignitor

ITEM DESCRIPTION COMMENTS PART NUMBER

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement

parts for your appliance please provide model number and serial number. All parts listed

in this manual may be ordered from an authorized dealer.

5 Valve Bracket

Oriﬁ ce NG, Threaded (.083)

Oriﬁ ce LP, Threaded (.053)

Wall Switch Wire Assembly M/M

6 Male connector Brass-Flex

7 Bulkhead Gasket

8 Bulkhead

10 Pilot Gasket

Heatilator • Eclipse • 4049-229 Rev F • 11/0858

Page 59

D. Optional Components

• GFK10 Transaxial Fan Kit

• RC BATT-HTL Battery-operated Remote Control

• RC SMART-HTL Remote Control (Requires 110 volt)

• SCKP-EHS Standing Pilot Natural to Propane Gas Conversion Kit

• DCKP-EHS Intermittent Pilot Natural to Propane Gas Conversion Kit

• DCKN-EHS Intermittent Pilot Propane to Natural Gas Conversion Kit

• HEARTH-EHS Precasted Hearth Extension Kit

• ESUR33SS Precasted Surround Kit

Heatilator • Eclipse • 4049-229 Rev F • 11/08 59

Page 60

E. Contact Information

Please contact your Heatilator dealer with any questions or concerns.

For the location of your nearest Heatilator dealer,

please visit www.heatilator.com.

- NOTES -

________________________________________________________________________________

NOTICE

DO NOT DISCARD THIS MANUAL

• Important operating and maintenance instructions included.

• Read, understand and follow these instructions for safe installation and operation.

• Leave this manual with party responsible for use and operation.

This product may be covered by one or more of the following patents: (United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending.

Heatilator • Eclipse • 4049-229 Rev F • 11/0860

Hearth and Home Technologies EDV3633I, EDV3633, EDV3633L, EDV3633IL User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
