TOASTER
Pop Up
TPT Series
TPT-120 TPT-208 TPT-240
TPT-120CA TPT-208CA TPT-230-4
REPLACEMENT
PARTS LIST
HATCO POP-UP TOASTER
Specification Label
on bottom of unit.
1
2
6
8
9
10
4
3
5
7
12
13
18
16
15
19
CAUTION
T P T - X X X C A
Toaster Pop-Up Type
CA = Canada
Voltage
TPT-120, TPT-120CAModels
Model Designation
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling (800) 558-0607.
Use of replacement parts other than those supplied by
HatcoCorporation may result in damageto the unit or injury
to personnel and will void all warranties.
2
Form No. TPTRP-1008
HATCO POP-UP TOASTER
Specification Label
on bottom of unit.
1
2
3
4
5
6
7
9
12
8
10
11
13
15
14
17
19
18
T P T - X X X C A
Toaster Pop-Up Type
CA = Canada
4 = Qty. of Toasting Slots
Voltage
TPT-208, TPT-208CA, TPT-240, TPT-230-4 Models
Model Designation
Form No. TPTRP-1008
3
PARTS COMMON TO ALL TPT MODELS
Week Thirty-Two
0732
Year 2007
Item Description Part No. Qty.
1 Knob, Color Control X05.30.115.00 2
2 Damping Spring X05.08.017.00 4
3 Return Spring, Solenoid X05.08.015.00 2
4 Solenoid X02.20.342.00 2
PARTS SPECIFIC TO MODEL TPT-120
Item Description 120V
9 Plunger, Solenoid (Qty. 2)
10 Carriage Handle Assembly (Qty. 2)
11 Damper Assembly
12
Potentiometer, Color Control (Qty. 2)
13 Crumb Tray Assembly (Qty. 2)
14 Printed Circuit Board
15 Screw
16 E-Ring (Qty. 2)
17 Heating Element Assembly
18 Power Cord and Plug
19 Rubber Foot (Qty. 4)
Item Description Part No. Qty.
5 Mirco Switch, DPDT X02.19.193.00 2
6 Carriage Spring X05.08.016.00 2
7 Shaft Bushing X05.02.028.00 8
8 Knob,Carriage HandleAssembly X05.30.125.00 2
X02.20.343.00
X04.05.546.00
--X02.13.334.00
X04.05.547.00
--X05.04.559.00
X05.04.558.00
---
02.18.154.00
X05.30.114.00
PARTS SPECIFIC TO MODEL TPT-120CA
Item Description 120V (Canada)
9 Plunger, Solenoid (Qty. 2)
10 Carriage Handle Assembly (Qty. 2)
11 Damper Assembly
12
Potentiometer, Color Control (Qty. 2)
13 Crumb Tray Assembly (Qty. 2)
14 Printed Circuit Board
15 Screw
16 E-Ring (Qty. 2)
17 Heating Element Assembly
18 Power Cord and Plug
19 Rubber Foot (Qty. 4)
NOTE: The last four digits in a ten digit numerical serial number are the manufacturing date code.
Example: Serial number 4140440732 has a date code of “0732”, which indicates the following:
X02.20.343.00
X04.05.546.00
--X02.13.334.00
X04.05.547.00
--X05.04.559.00
X05.04.558.00
---
02.18.089.00
X05.30.114.00
4
Form No. TPTRP-1008
PARTS SPECIFIC TO MODEL TPT-208
Item Description 208V
9 Plunger, Solenoid (Qty. 2)
10 Carriage Handle Assembly (Qty. 2)
11 Damper Assembly
12
Potentiometer, Color Control (Qty. 2)
13 Crumb Tray Assembly
14 Printed Circuit Board (Qty. 2)
15 Screw
16 E-Ring
17 Heating Element Assembly (Qty. 8)
18 Power Cord and Plug
19 Rubber Foot (Qty. 4)
X02.20.344.00
X04.05.548.00
X04.05.550.00
X02.13.335.00
X04.05.549.00
X02.01.258.00
X05.04.561.00
---
X02.09.273.00
02.18.036.00
X05.30.116.00
PARTS SPECIFIC TO MODEL TPT-208CA
Item Description 208V (Canada)
9 Plunger, Solenoid (Qty. 2)
10 Carriage Handle Assembly (Qty. 2)
11 Damper Assembly
12
Potentiometer, Color Control (Qty. 2)
13 Crumb Tray Assembly
14 Printed Circuit Board (Qty. 2)
15 Screw
16 E-Ring
17 Heating Element Assembly (Qty. 8)
18 Power Cord and Plug
19 Rubber Foot (Qty. 4)
X02.20.344.00
X04.05.548.00
X04.05.550.00
X02.13.335.00
X04.05.549.00
X02.01.258.00
X05.04.561.00
---
X02.09.273.00
02.18.259.00
X05.30.116.00
Form No. TPTRP-1008
5
PARTS SPECIFIC TO MODEL TPT-240
Item Description 240V
9 Plunger, Solenoid (Qty. 2)
10 Carriage Handle Assembly (Qty. 2)
11 Damper Assembly
12
Potentiometer, Color Control (Qty. 2)
13 Crumb Tray Assembly
14 Printed Circuit Board (Qty. 2)
15 Screw
16 E-Ring
17 Heating Element Assembly (Qty. 8)
18 Power Cord and Plug
19 Rubber Foot (Qty. 4)
X02.20.344.00
X04.05.548.00
X04.05.550.00
X02.13.335.00
X04.05.549.00
X02.01.258.00
X05.04.561.00
---
X02.09.274.00
02.18.036.00
X05.30.116.00
PARTS SPECIFIC TO MODEL TPT-230-4
Item Description 230V (CE)
9 Plunger, Solenoid (Qty. 2)
10 Carriage Handle Assembly (Qty. 2)
11 Damper Assembly
12
Potentiometer, Color Control (Qty. 2)
13 Crumb Tray Assembly
14 Printed Circuit Board (Qty. 2)
15 Screw
16 E-Ring
17 Heating Element Assembly (Qty. 8)
18 Power Cord and Plug
19 Rubber Foot (Qty. 4)
X02.20.344.00
X04.05.548.00
X04.05.550.00
X02.13.335.00
X04.05.549.00
X02.01.282.00
X05.04.561.00
---
X02.09.274.00
02.18.038.00
X05.30.116.00
Shaded area contains information for Export models only.
6
Form No. TPTRP-1008
HATCO CORPORATION
P.O. Box 340500
Milwaukee, WI 53234-0500 U.S.A.
(800) 558-0607 (414) 671-6350
Parts and Service Fax (800) 690-2966
International Fax (414) 671-3976
www.hatcocorp.com
