Hatco MCH-10 Parts List

MINI

-

COMPACT

REPLACEMENT

PARTS LIST

HOBART MODELS MCH-10/MCH-11

HOBART MODELS MCH -10/MCH-11

MINI-COMPACT

HOBART MODELS MCH -10/MCH-11

MINI-COMPACT

No. Description Part No. Qty. No. Description Part No. Qty.

1 Tank (Stainless Steel) 01-05-001 1 8 Contactor Lug
2 Control Thermostat 02-16-024 1

3 High Limit Switch 02-16-025 1
4 Element

MCH-10 200V 10&208V30
3200W 200V 02-04-100 3 9 Transformer
MCH-11 230/240V 10&30
3800W 240V 02-04-102 3
MCH-11 460/480V 30
3800W 277V 02-04-103 3 10 Fuse Control Circuit
MCH-11 600V 30
3800W 346 V 02-04-105 3

4A Gasket (1 per element) 02-11-001 3

5 Low Water Cutoff Board 120V 02-01-006 1
6 Low Water Cutoff Probe 02-40-001 1 11 Remote Control-Relay 24V-1 OAM P 02-01 -039 1
7 Contactor (All Voltages 30)

25A 3P 120V 02-01-038 1

7A Contactor (All Voltages 10)

50A2P 120V 02-01-040 1 13 Temperature/Pressure

(A) 48D/600V-3 Pole-SLU -35 02-14-012 2
(B) 2 Pole-SAS-70 02-14-033 2
(C) 3 Pole-SLS-35 02-14-032 3
(D) 48D/600V-3 Pole-SLS-35 02-14-032 1

200/208/230/240-120V 40VA 02-17-006 1
460/480-120V 40VA 02-17-007 1
480/600-120V 40VA 02-17-008 1

(A) 200/230/240V
AGC-1 Fuse 1 AMP 02-03-001 2
(B) 460/480/600V
KDLR -1/FNQR-1 1AMP 02-03-021 2

12 Fuse Holder

(A) 200/230/240V 02-03-004 2
(B) 460/480/600V 02-03-016 2

Relief Valve (10L-2) 03-02-020, 1
