Hatco GRMM-0399 User Manual

Glo-Ray

Mini-Merchandisers

GRDW-2
GRKW-1

Installation &

Operating Manual

®

I & W #07.05.081.00

Form No. GRMM-0399

i

INTRODUCTION

Hatco Glo-Ray Mini-Merchandisers are designed to
keep all foods at optimum serving temperatures without
affecting quality.

The Glo-Ray Mini-Merchandisers create impulse sales
by placing your fresh product at customer serving
points. These warmers feature a thermostatically
controlled heated base with prefocused infrared top heat
to extend the holding times of most food. The infrared
heating elements are guaranteed against breakage and
burnout for two years and the blanket heating elements
are guaranteed against burnout for one year. The Glo-Ray
Mini-Merchandisers are shipped with easy to install
breath protectors or acrylic enclosure, display lights, and
a cord and plug set.

This manual provides the installation, safety and
operating instructions for the Glo-Ray Mini­Merchandisers. We recommend all installation,
operating and safety instructions appearing in this
manual be read prior to installation or operation of your
Hatco Mini-Merchandiser. Safety instructions that appear
in this manual after a warning symbol and the words
WARNING or CAUTION printed in bold face are
important. Warning means there is the possibility of
personal injury to yourself or others. Caution means
there is the possibility of damage to the unit.

Your Hatco Glo-Ray Mini-Merchandiser is a product of
extensive research and field testing. The materials used
were selected for maximum durability, attractive
appearance and optimum performance. Every unit is
thoroughly inspected and tested prior to shipment.

CONTENTS

Important Owner Information..................................i

Introduction.................................................................i

Important Safety Instructions ..................................1

Model Descriptions

All Models............................................................1

GRDW-2 ..............................................................1

GRKW-1 ..............................................................2

Specifications

Electrical Rating Chart

GRDW-2...........................................................2

GRKW-1...........................................................2

Plug Configurations .............................................2

Dimensions

GRDW-2...........................................................2

GRKW-1...........................................................2

Installation

All Models............................................................3

Legs ......................................................................3

GRDW-2...........................................................3

Location................................................................4

Operation

All Models............................................................4

GRDW-2...........................................................4

GRKW-1...........................................................4

Maintenance

Cleaning ...............................................................5

Light Bulb Replacement .....................................5

Accessories..................................................................5

Hatco Limited Warranty...........................................6

Authorized Parts Distributors.................Back Cover

Record the model number, serial number (identification
plate located on top rear of unit), voltage and purchase
date of your Glo-Ray Mini-Merchandiser in the spaces
below. Please have this information available when call­ing Hatco for service assistance.

Model No. ____________________________________

Serial No. ____________________________________

Voltage ______________________________________

Date of Purchase ______________________________

IMPORTANT OWNER INFORMATION

Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time

(Summer Hours: June to September ­8:00 a.m. to 5:00 p.m. C.D.T.
Monday through Thursday
8:00 a.m. to 3:30 p.m. C.D.T. Friday)

Telephone: [phone]

Fax: [phone] (Parts & Service)

[phone] (International)

Form No. GRMM-0399

1

IMPORTANT SAFETY INSTRUCTIONS

Read the following important safety instructions to
avoid personal injury and/or damage to the equipment.

1. To avoid any injury, turn the power switch off,
unplug the unit from the power source and allow to
cool before performing any maintenance.

2. Some exterior surfaces on the unit will get hot. Use
caution when touching these areas to avoid injury.

3. Plug unit into a grounded electrical outlet of the
correct voltage, size and plug configuration. If the
plug and receptacle do not match, contact a
qualified electrician to determine the proper voltage
and size and install the proper electrical outlet.

4. For safe and proper operation, the unit must be
located a reasonable distance from combustible walls
and materials. If safe distances are not maintained,
discoloration or combustion could occur.

5. Locate the unit at the proper counter height, in an
area that is convenient for use. The location should
be level to prevent the unit or its contents from
accidentally falling, and strong enough to support the
weight of the unit and food.

6. Glo-Ray Mini-Merchandisers are not waterproof.
DO NOT submerge in water. Do not operate if unit
has been submerged in water.

7. Abrasive cleaners could scratch the finish of your unit.

8. Only light bulbs which meet or exceed N.S.F.
standards, specifically designed for food holding
areas must be used. Breakage of light bulbs not
specially coated could result in personal injury
and/or food contamination.

ALL MODELS

Hatco Glo-Ray Mini-Merchandisers are ideal for hold­ing hot food on a buffet line or at temporary serving
areas. These warmers feature a thermostatically con­trolled heated base and prefocused infrared top heat
along with a cord and plug set.

GRDW-2

The GRDW-2 features a metal sheathed heating element
above and a thermostatically controlled heated base. The
unit has a full front acrylic enclosure and comes equipped
with a merchandising sign holder for impulse sales (sign
not included).

GRKW-1

This model features a metal sheathed heating element
above and a thermostatically controlled heated base with
On/Off temperature control and adjustment. Acrylic side
panels and rear door provide a safe food environment.

WARNINGS/CAUTIONS

MODEL DESCRIPTIONS

Figure 1. Glo-Ray Model GRDW-2

Figure 2. Glo-Ray Model GRKW-1

HATCO CORPORATION, Milwaukee, WI

ON

OFF

HATCO

GLO-RAY

FOOD WARMER

Model Voltage Watts Amps Plug Configuration Shipping Weight

GRDW-2 120 1230 10.3 NEMA 5-15P 65 lbs. (30 kg)

220 1172 5.3 CEE 7/7 Schuko 65 lbs. (30 kg)

240 1270 5.3 BS 1363 65 lbs. (30 kg)

Shaded areas pertain to Export Models Only.

ELECTRICAL RATING CHART - GRDW-2

Model Voltage Watts Amps Plug Configuration Shipping Weight

GRKW-1 120 545 4.5 NEMA 5-15P 37 lbs. (17 kg)

ELECTRICAL RATING CHART - GRKW-1

PLUG CONFIGURATIONS

Units are supplied from the factory with an electrical
cord and plug installed. Plugs are supplied according to
the applications as shown in Figure 3.

CAUTION

Plug unit into a grounded electrical outlet of the cor­rect voltage, size and plug configuration. If the plug
and receptacle do not match, contact a qualified elec­trician to determine the proper voltage and size and
install the proper electrical outlet.

NEMA 5-15P

CEE 7/7 Schuko

BS 1363

Figure 3. Plug Configurations

DIMENSIONS

Model Width (A) Depth (B) Height (C)*

GRDW-2 31-5/8" 20" 21-1/4"

(80 cm) (51 cm) (54 cm)

C

B

A

* Includes sign holder

Model Width (A) Depth (B) Height (C)

GRKW-1 22-3/4" 13-3/8" 14-5/8"

(58 cm) (34 cm) (37 cm)

C

B

A

Form No. GRMM-0399

2
