Harley-Davidson HDP66 User Manual

Model HDP66

Headlight Design Alarm Clock

Speaker System For iPhone

Questions? Visit www.ihomeaudio.com

Table of Contents

A Consumer Guide to Product Safety

Maintenance

Controls and Indicators

Getting Started

Install Clock Backup Batteries

Connecting the AC adaptor

Using The Optional Remote Control

Install/Replace the Remote Control Battery

Setting Up the HDP-66

Using the Alarm

Docking and Charging your iPhone/Pod

Listening to iPhone/iPod

Listening to non-docking iPod or other portable audio devices

Sleep Operation

Dimmer Operation

A Consumer Guide to Product Safety

Trouble Shooting

Solución De Problemas

Warranty Information

1

1

2

3

3

4

4

5

6

6

7

7

8

8

8

9

10

11

12

A Consumer Guide to Product Safety

This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits
provide reasonable protection against radio and TV interference in a residential area.

However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference
you can try one or more of the following corrective measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and the radio or TV.

• Use outlets on different electrical circuits for the equipment and the radio or TV.

• Consult your dealer or an experienced radio/television technician if the problem still exists.

Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s
warranty and void your FCC authorization to operate it.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Maintenance

• Place the unit away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine,
thinner or similar materials can mar the surface of the case.

1

Controls and Indicators

OFF/Alarm Reset Button

Play/Pause Button

Reverse Button

Decrease Volume Button

Top view

Dock Support

Forward Button

Increase Volume Button

Mute Button

Snooze/Dimmer Button

Sleep Button

Power Off/ Alarm

Reset Button

Play/Pause Button

Decrease Volume Button

Back panel

Increase Volume Button

Alarm Set/Alarm on/off Button

Sleep/Min. Button

Front view

Snooze/Dimmer Button

Time Set Button

Hour Button

-1

DST Switch

AC Adaptor Jack

dst

DC 12V

+1

line in

wake to

iPod SFX

Wake To Switch

Line-in Jack

2

Getting Started

Thank you for purchasing the iHome HDP-66 2.1 Speaker System for your iPhone/iPod. Designed specifically to
work with your iPhone and iPod, this system provides high quality audio that invites your music to come out and
play.
Please read this instruction carefully before operating the HDP66 and keep it for future reference.

Install Clock Backup Batteries

The HPD66 uses 2 x AA batteries for backup to provide continuous alarm
operation and clock settings in the event of a power failure.
Note:

You should replace backup batteries when the Battery Low Icon is
displayed.
If the Backup Battery has been installed and a power failure occurs or the AC
cord is accidentally disconnected, the display backlight will not remain lit, but
current time and alarm time settings will be temporarily maintained. Otherwise,
you must reset the time and alarm settings.

1. Please make sure the AC adaptor is connected. Otherwise all settings may

be lost during battery replacement.

2. Open backup battery compartment door located on the bottom of the unit.

3. Insert two “AA” batteries, checking the + and – ends of the batteries. We

recommend to use alkaline battery for longer life time. Do not mix alkaline,
standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.

4. Close the compartment cover.

Note: Make sure you dispose of batteries properly (see your local regulations).

Battery Low Indicator

The Battery Low Icon is located in the right hand side of display. When it lights
up it is time to replace backup batteries.

Warning

• Do not mix with used or other battery types/brands

• Replace all cells at the same time

• Do not open batteries

• Do not dispose of in fire

• Do not heat above 75C (167F)

• Do not expose contents to water

• Do not charge or recharge

• Do not install backwards

Installing Backup Batteries

3
