Harbor Freight Tools SDS MAX TYPE User Manual

Owner’s Manual & Safety Instructions

Save This Manual Keep this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.

ITEM 69334

1-9/16" VARIABLE SPEED
SDS MAX TYPE

ROTARY HAMMER

Visit our website at: http://www.harborfreight.com

REV 14f

When unpacking, make sure that the product is intact

and undamaged. If any parts are missing or broken,

please call 1-888-866-5797 as soon as possible.

Copyright© 2011 by Harbor Freight Tools®. All rights reserved.

No portion of this manual or any artwork contained herein may be reproduced in

any shape or form without the express written consent of Harbor Freight Tools.

Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein.

Tools required for assembly and service may not be included.

Email our technical support at: [e-mail]

Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Table of Contents

Safety ......................................................... 2

Specifications ............................................. 8

Setup .......................................................... 8

SAFETY OPERATION MAINTENANCESETUP

Operation .................................................... 9

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Maintenance .............................................. 12

Parts List and Diagram .............................. 14

Warranty .................................................... 16

WARNING SYMBOLS AND DEFINITIONS

Obey all safety messages that follow this symbol to avoid possible injury or death.

Indicates a hazardous situation which, if not avoided,

will result in death or serious injury.

Indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

Indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

Addresses practices not related to personal injury.

IMPORTANT SAFETY INFORMATION

General Power Tool Safety Warnings

Read all safety warnings and instructions.

Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term ″power tool″ in the warnings refers to your mains-operated (corded) power tool.

Work area safety

1. Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

3. Keep children and bystanders
away while operating a power tool.

Distractions can cause you to lose control.

Page 2 For technical questions, please call 1-888-866-5797. Item 69334

Electrical safety

1. Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with grounded
power tools. Unmodified plugs and matching

outlets will reduce risk of electric shock.

2. Avoid body contact with grounded surfaces
such as pipes, radiators, ranges and
refrigerators. There is an increased risk of

electric shock if your body is grounded.

3. Do not expose power tools to rain or wet
conditions. Water entering a power tool

will increase the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while operating

power tools may result in serious personal injury.

2. Use personal protective equipment. Always wear
eye protection. Safety equipment such as

dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.

3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to
power source, picking up or carrying the tool.

Carrying power tools with your finger on
the switch or energizing power tools that

have the switch on invites accidents.

4. Remove any adjusting key or wrench
before turning the power tool on.

A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.

4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled

cords increase the risk of electric shock.

5. When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor

use reduces the risk of electric shock.

6. If operating a power tool in a damp location
is unavoidable, use a Ground Fault Circuit
Interrupter (GFCI) protected supply.

Use of a GFCI reduces the risk of electric shock.

5. Do not overreach. Keep proper footing and
balance at all times. This enables better control

of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry

or long hair can be caught in moving parts.

7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of

these devices can reduce dust-related hazards.

8. Only use safety equipment that has been
approved by an appropriate standards agency.

Unapproved safety equipment may not provide
adequate protection. Eye protection must be
ANSI-approved and breathing protection
must be NIOSH-approved for the
specific hazards in the work area.

SAFETYOPERATIONMAINTENANCE SETUP

Page 3For technical questions, please call 1-888-866-5797.Item 69334

Power tool use and care

1. Do not force the power tool. Use the
correct power tool for your application.

The correct power tool will do the job better and

SAFETY OPERATION MAINTENANCESETUP

safer at the rate for which it was designed.

2. Do not use the power tool if the
switch does not turn it on and off.

Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.

3. Disconnect the plug from the power source
before making any adjustments, changing
accessories, or storing power tools.

Such preventive safety measures reduce the
risk of starting the power tool accidentally.

4. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are

dangerous in the hands of untrained users.

Service

Have your power tool serviced by a qualified repair
person using only identical replacement parts. This

will ensure that the safety of the power tool is maintained.

5. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the

power tool for operations different from those

intended could result in a hazardous situation.

Rotary Hammer Safety Warnings

1. Wear ear protectors with rotary hammers.

Exposure to noise can cause hearing loss.

2. Use auxiliary handles supplied with the tool.

Loss of control can cause personal injury.

3. Hold power tools by insulated gripping surfaces
when performing an operation where the cutting
tool may contact hidden wiring or its own cord.

Contact with a ″live″ wire will make exposed metal
parts of the tool ″live″ and shock the operator.

4. Let bit cool before touching, changing
or adjusting it. Bits heat up dramatically

while in use, and can burn you.

5. If the drill bit jams, release the

trigger immediately; drill torque
can cause injury or break bit.

6. Maintain labels and nameplates on the tool.
These carry important safety information.

If unreadable or missing, contact
Harbor Freight Tools for a replacement.

7. Avoid unintentional starting.
Prepare to begin work before turning on the tool.

8. Do not lay the tool down until it has come to
a complete stop. Moving parts can grab the
surface and pull the tool out of your control.

9. When using a handheld power tool,

maintain a firm grip on the tool with
both hands to resist starting torque.

10. Do not leave the tool unattended when it is
plugged into an electrical outlet. Turn off the tool,

and unplug it from its electrical outlet before leaving.

11. This product is not a toy.
Keep it out of reach of children.

12. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields
in close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure. In
addition, people with pacemakers should:

• Avoid operating alone.

• Do not use with power switch locked on.

• Properly maintain and inspect to avoid
electrical shock.

• Any power cord must be properly
grounded. Ground Fault Circuit Interrupter
(GFCI) should also be implemented –
it prevents sustained electrical shock.

Page 4 For technical questions, please call 1-888-866-5797. Item 69334

Rotary Hammer Safety Warnings (cont.)

13. WARNING: Some dust created by power sanding,
sawing, grinding, drilling, and other construction
activities, contains chemicals known to the State
of California to cause cancer and birth defects or
other reproductive harm. Some examples of these
chemicals are:

• Lead from lead-based paints

• Crystalline silica from bricks and cement or other
masonry products

• Arsenic and chromium from chemically
treated lumber
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well
ventilated area, and work with approved safety
equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
(California Health & Safety Code § 25249.5, et seq.)

Vibration Safety

This tool vibrates during use.

Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:

1. Anyone using vibrating tools regularly or for an

extended period should first be examined by a
doctor and then have regular medical check-ups
to ensure medical problems are not being caused
or worsened from use. Pregnant women or people

who have impaired blood circulation to the hand, past
hand injuries, nervous system disorders, diabetes,
or Raynaud’s Disease should not use this tool.
If you feel any symptoms related to vibration (such
as tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.

14. WARNING: The cord of this product contains
lead, a chemical known to the State of California
to cause cancer, and birth defects or other
reproductive harm. Wash hands after handling.
(California Health & Safety Code § 25249.5, et seq.)

15. The warnings, precautions, and instructions

discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the

operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.

2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.

3. Wear suitable gloves to reduce the

vibration effects on the user.

4. Use tools with the lowest vibration
when there is a choice.

5. Include vibration-free periods each day of work.

6. Grip tool as lightly as possible (while still keeping

safe control of it). Let the tool do the work.

7. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal

vibration occurs, stop use immediately.

SAFETYOPERATIONMAINTENANCE SETUP

SAVE THESE INSTRUCTIONS.

Page 5For technical questions, please call 1-888-866-5797.Item 69334

Grounding

SAFETY OPERATION MAINTENANCESETUP

the plug. Do not use the tool if the power cord or plug is damaged. If damaged, have it repaired by a service
facility before use. If the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.

TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING
WIRE CONNECTION:
Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded.
Do not modify the power cord plug provided with the tool. Never remove the grounding prong from

Grounded Tools: Tools with Three Prong Plugs

2. The grounding prong in the plug is connected through
the green wire inside the cord to the grounding
system in the tool. The green wire in the cord must
be the only wire connected to the tool’s grounding
system and must never be attached to an electrically
“live” terminal. (See 3-Prong Plug and Outlet.)

3. The tool must be plugged into an appropriate outlet,
properly installed and grounded in accordance with
all codes and ordinances. The plug and outlet should

3-Prong Plug and Outlet

1. Tools marked with “Grounding Required” have a three
wire cord and three prong grounding plug. The plug
must be connected to a properly grounded outlet.
If the tool should electrically malfunction or break
down, grounding provides a low resistance path to
carry electricity away from the user, reducing the risk
of electric shock. (See 3-Prong Plug and Outlet.)

look like those in the preceding illustration.

(See 3-Prong Plug and Outlet.)

Double Insulated Tools: Tools with Two Prong Plugs

1. Tools marked “Double Insulated” do not
require grounding. They have a special
double insulation system which satisfies
OSHA requirements and complies with
the applicable standards of Underwriters
Laboratories, Inc., the Canadian Standard
Association, and the National Electrical Code.

2. Double insulated tools may be used in either of the
120 volt outlets shown in the preceding illustration.

Outlets for 2-Prong Plug

Page 6 For technical questions, please call 1-888-866-5797. Item 69334

(See Outlets for 2-Prong Plug.)

Extension Cords

1. Grounded tools require a three wire extension cord.
Double Insulated tools can use either

a two or three wire extension cord.

2. As the distance from the supply outlet increases,
you must use a heavier gauge extension cord.
Using extension cords with inadequately sized
wire causes a serious drop in voltage, resulting
in loss of power and possible tool damage.

(See Table A on page 7.)

3. The smaller the gauge number of the wire, the
greater the capacity of the cord. For example,
a 14 gauge cord can carry a higher current
than a 16 gauge cord. (See Table A.)

4. When using more than one extension cord to make
up the total length, make sure each cord contains at
least the minimum wire size required. (See Table A.)

5. If you are using one extension cord for more
than one tool, add the nameplate amperes
and use the sum to determine the required
minimum cord size. (See Table A.)

6. If you are using an extension cord outdoors, make
sure it is marked with the suffix “W-A” (“W” in
Canada) to indicate it is acceptable for outdoor use.

7. Make sure the extension cord is properly wired
and in good electrical condition. Always replace
a damaged extension cord or have it repaired
by a qualified electrician before using it.

8. Protect the extension cords from sharp objects,
excessive heat, and damp or wet areas.

TABLE A: RECOMMENDED MINIMUM WIRE

GAUGE FOR EXTENSION CORDS* (120/240 VOLT)

NAMEPLATE

AMPERES

(at full load)

0 – 2.0 18 18 18 18 16

2.1 – 3.4 18 18 18 16 14

3.5 – 5.0 18 18 16 14 12

5.1 – 7.0 18 16 14 12 12

7.1 – 12.0 18 14 12 10 -

12.1 – 16.0 14 12 10 - -

16.1 – 20.0 12 10 - - -

* Based on limiting the line voltage drop to five volts at

150% of the rated amperes.

EXTENSION CORD

LENGTH

25´ 50´ 75´ 100´ 150´

SAFETYOPERATIONMAINTENANCE SETUP

Symbology

Double Insulated

Canadian Standards Association

Underwriters Laboratories, Inc.

VAC

A

n0 xxxx/min.

Volts Alternating Current

Amperes

No Load Revolutions per Minute (RPM)

WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.

Read the manual before
set-up and/or use.

WARNING marking concerning
Risk of Hearing Loss.
Wear hearing protection.

WARNING marking
concerning Risk of Fire.
Do not cover ventilation ducts.
Keep flammable objects away.

WARNING marking concerning
Risk of Electric Shock.
Properly connect power cord
to appropriate outlet.

Page 7For technical questions, please call 1-888-866-5797.Item 69334

Specifications

Electrical Rating 120VAC / 60Hz / 10.5A

SAFETY OPERATION MAINTENANCESETUP

Rotational Speed 0-500 RPM

Impact Rate 0-3780 BPM

Wood Capacity 1-5/8" (41 mm)

Concrete Capacity 1-9/16" (40 mm)

Steel Capacity 1/2" (13 mm)

Shank Style SDS Max Type

Note: This tool includes an internal safety clutch that helps prevent tool
damage by disengaging the drill function if the bit locks in place.

4003148

Setup - Before Use:

Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this

manual including all text under subheadings therein before set up or use of this product.

Note: For additional information regarding the parts listed in the following

pages, refer to Parts List and Diagram on page 14.

Functions

Auxiliary

Handle

(117)

Chuck (3)

Mode Selector (86)

Figure A

Grease Port

Trigger (108)

Page 8 For technical questions, please call 1-888-866-5797. Item 69334

Operating Instructions

Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this

manual including all text under subheadings therein before set up or use of this product.

Tool Set Up

TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Release the Trigger and unplug the tool from its electrical outlet before adjusting the tool or
installing accessories.

Adjusting the Auxiliary Handle

The Auxiliary Handle can be placed in a variety of positions.

To adjust the Auxiliary Handle, turn the Handle counterclockwise to
loosen the band. Slide the Handle to the desired position then turn
the Handle clockwise to secure it in place.

Adjusting the Functions

Adjust the Mode Selector to the desired function
before using the Rotary Hammer. Press the Release
Button and rotate the Mode Selector until it clicks in
place with the desired function at the Indicator.

CAUTION: Move the Mode Selector only when the Motor is stopped.
Attempting to move the Mode Selector while the Motor is engaged
will result in abrupt bit rotation and can cause property damage.

Hammer

Setting

Release Button

Auxiliary HandleBand Bracket

Figure B

Drill Setting

SAFETYOPERATIONMAINTENANCE SETUP

Hammer/

CAUTION: When moving the Mode Selector, make sure it
clicks into the desired position. If not actively engaged, the
Mode Selector could slip out of position resulting in tool damage.

To Hammer/Drill: Rotate the Mode Selector to
the Hammer/Drill setting. The Rotary Hammer
will revolve and hammer when powered.

To Chisel: Rotate the Mode Selector to the Hammer Setting.
The Rotary Hammer will hammer when powered.

To Adjust Chisel Angle: Rotate the Mode Selector to the Adjust Chisel Setting. You
can now rotate the bit to the desired angle for chiseling. When finished adjusting the
bit, rotate the Mode Selector to the Hammer Setting to begin chiseling.

Adjust Chisel Setting Indicator

Work Piece and Work Area Set Up

1. Designate a work area that is clean and well­lit. The work area must not allow access by
children or pets to prevent distraction and injury.

2. Route the power cord along a safe route to reach
the work area without creating a tripping hazard or
exposing the power cord to possible damage. The
power cord must reach the work area with enough
extra length to allow free movement while working.

3. Secure loose work pieces using a vise or clamps
(not included) to prevent movement while working.

4. There must not be objects, such as utility lines,
nearby that will present a hazard while working.

Figure C

Page 9For technical questions, please call 1-888-866-5797.Item 69334

Masonry Drilling

Changing Drill Bits

CAUTION! Wear heavy-duty work gloves to provide

SAFETY OPERATION MAINTENANCESETUP

protection when inserting and removing drill bits. Drill bits
become very hot during use. Do not remove drill bits until
the bit has cooled. Do not strike stuck bits with a hammer.

1. Grease the drill bit shank before installing.

2. Pull back on the Chuck and insert the drill bit.
Make sure it slides all the way into the opening.

Hammer Drill Operation

1. Adjust the Auxiliary Handle as needed.

2. Set the Function by adjusting the Mode
Selector to the desired setting.

3. Plug in the Power Cord.

4. Squeeze and hold the Trigger to
turn on the Rotary Hammer.

Concrete Drilling Tips

1. Do not add water to the drill hole.

2. Clean the bit flutes regularly while drilling.

3. Back the bit out of the hole often during drilling,
especially when drilling deep holes.

3. Release the Chuck.

4. Check that the drill bit is secured in place. It should
not be able to be pulled out of the Chuck.

Note: When drilling a hole larger than 1-1/4"
diameter, use a drill bit with four cutting edges.

5. Do not apply excessive force. allow
the tool to do the work..

6. When finished, to prevent accidents, release the
Trigger and disconnect its power supply after
use. Allow the bit to cool then pull back on the
Chuck and remove the bit from the Chuck and
wipe off the bit’s shank. Clean the tool, then
store the tool indoors out of children’s reach.

4. Grease the bit shank and bit holder and keep
the shank end of the bit dust and debris free.

5. Use the shortest bit practical.

6. When drilling deep holes, work in stages,
use a short bit for the beginning of the
hole, then change to a longer bit.

Page 10 For technical questions, please call 1-888-866-5797. Item 69334

Chiseling

Changing Chisel Bits

1. Grease the bit shank before installing.

2. Pull back on the Chuck and insert the Bit. Make
sure it slides all the way into the opening.

3. Release the Chuck.

Chisel Operation

1. Adjust the Auxiliary Handle as needed.

2. Plug in the Power Cord.

3. Squeeze and hold the Trigger to
turn on the Rotary Hammer.

4. Allow the Rotary Hammer to reach full speed
before contacting the work surface.

4. Rotate the Mode Selector so the Adjust
Chisel Setting is in the ON position. Rotate
the bit to the desired angle then rotate the
Mode selector to the Hammer setting.

5. Check that the bit is secured in place. It should
not be able to be pulled out of the Chuck.

5. When finished, to prevent accidents, release
the Trigger and disconnect its power supply
after use. Pull back on the Chuck then remove
the bit from the Chuck. Clean, then store
the tool indoors out of children’s reach.

SAFETYOPERATIONMAINTENANCE SETUP

Page 11For technical questions, please call 1-888-866-5797.Item 69334

Maintenance and Servicing

Procedures not specifically explained in this manual must

be performed only by a qualified technician.

SAFETY OPERATION MAINTENANCESETUP

TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Release the Trigger and unplug the tool from its electrical outlet before
performing any inspection, maintenance, or cleaning procedures.

TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.

Cleaning, Maintenance, and Lubrication

1. BEFORE EACH USE, inspect the general condition
of the tool. Check for loose hardware, misalignment
or binding of moving parts, cracked or broken
parts, damaged electrical wiring, and any other
condition that may affect its safe operation.

2. Monthly, open the Grease Port, clean out old
grease, and replace with new grease.

Grease Port Cover

Figure D: Grease Port

NOTICE: Warranty void if grease maintenance

(internal and bit shank) is not followed.

3. AFTER USE, wipe external surfaces
of the tool with clean cloth.

4. Lubricate the bit shank with grease
each time before installing to maintain
the life of the internal mechanism.

5.

WARNING! If the supply cord of this
power tool is damaged, it must be replaced
only by a qualified service technician.

Page 12 For technical questions, please call 1-888-866-5797. Item 69334

Troubleshooting

Problem Possible Causes Likely Solutions

Tool will not start. 1. Cord not connected.

2. No power at outlet.

3. Tool’s thermal reset breaker
tripped (if equipped).

4. Internal damage or wear.
(Carbon brushes or
switch, for example.)

Tool operates slowly. Extension cord too long or

cord diameter too small.

Performance
decreases over time.

Excessive noise
or rattling.

Overheating. 1. Forcing tool to work too fast.

1. Accessory dull or damaged.

2. Carbon brushes worn
or damaged.

Internal damage or wear. (Carbon
brushes or bearings, for example.)

2. Accessory misaligned.

3. Accessory dull or damaged.

4. Blocked motor housing vents.

5. Motor being strained by long or
small diameter extension cord.

1. Check that cord is plugged in.

2. Check power at outlet. If outlet is unpowered,
turn off tool and check circuit breaker. If breaker
is tripped, make sure circuit is right capacity
for tool and circuit has no other loads.

3. Turn off tool and allow to cool.
Press reset button on tool.

4. Have technician service tool.

Eliminate use of extension cord. If an extension
cord is needed, use one with the proper diameter
for its length and load. See Extension Cords
in Grounding section on page 6.

1. Keep cutting accessories sharp. Replace as needed.

2. Have qualified technician replace brushes.

Have technician service tool.

1. Allow tool to work at its own rate.

2. Check and correct accessory alignment.

3. Keep cutting accessories sharp. Replace as needed.

4. Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while
blowing dust out of motor using compressed air.

5. Eliminate use of extension cord. If an extension
cord is needed, use one with the proper diameter
for its length and load. See Extension Cords
in Grounding section on page 6.

SAFETYOPERATIONMAINTENANCE SETUP

Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power

supply before service.

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 13For technical questions, please call 1-888-866-5797.Item 69334

Parts List and Diagram

Parts List

SAFETY OPERATION MAINTENANCESETUP

Page 14 For technical questions, please call 1-888-866-5797. Item 69334

Part Description Qty

1 Front Cover 1
2 Clip Ring 1
3 Chuck 1
4 Steel Ball Rack Spring 1
5 Screw 4
6 Spring Washer 10
7 Front Housing 1
8 Oil Seal 1

9 Washer 2
10 Clip Ring 1
11 Bearing 1
12 Pulley 3
13 Rotary Sleeve 1
14 Steel Ball 3
15 O-Ring 2
16 O-Ring 2
17 Impact Hammer 1
18 Steel Ball 3
19 Cylinder 1
20 Flat Key 2
21 Rubber Ring 1
22 Circlip 2
23 Clutch Spring 1
24 Clutch Block 1
25 Plate 1
26 Spring 1
27 Clutch 1
28 Clutch Washer 1
29 Washer 1
30 O-Ring 1
31 Circlip 1
32 Pneumatic Hammer 1
33 O-Ring 2
34 Piston 1
35 Piston Pin 1
36 Rod 1
37 Needle Bearing 1
38 Circlip 1
39 Bearing 1
40 Gear Box 1
41 Cap 1
42 O-Ring 1
43 Flat Washer 1
44 Spring Washer 1
45 Upper Damper Sleeve 1
46 Damping Spring 1
47 Damping Plate 1
48 Damping Screw 1
49 Eccentric Shaft 1
50 Flat Key 2
51 Bearing 1
52 Circlip 1
53 Circlip 1
54 First Gear 1
55 Circlip 1
56 Needle Bearing 1
57 Steel Ball 8
58 Active Plate 1
59 Inner Spring 1

Part Description Qty

60 Outer Spring 1
61 Spring Holder 1
62 Circlip 1
63 Bearing 2
64 Pinion 1
65 Bearing 1
66 Pinion Bearing Plate 1
67 Second Gear 1
68 Fix Block 1
69 Circlip 1
70 Intermediate Cover Plate 1
71 Intermediate Cover 1
72 Handle Knob 1
73 O-Ring 1
74 Circlip 1
75 Bearing 1
76 Bearing Clamp 1
77 Screw 2
78 Armature 1
79 Fan Guide 1
80 Bearing Cover 1
81 Release Button 1
82 Button Spring 2
83 Screw 1
84 Spring Plate 1
85 Plate 1
86 Mode Selector 1
87 Guide Ring 1
88 Screw 2
89 Stator 1
90 Housing 1
91 Washer 4
92 Screw 4
93 Long Inductance 1
94 Short Inductance 1
95 Carbon Brush Holder 2
96 Carbon Brush 2
97 Spring 2
98 Bottom Cover 1

99 Screw 12
100 Lower Damper Sleeve 1
101 Spring Holder 1
102 Damping Spring 1
103 Cord Protector 1
104 Power Cord 1
105 Left Handle 1
106 Right Handle 1
107 Switch 1
108 Trigger 1
109 Cable Clamp 1
110 Binding Post 2
111 Capacitor 1
112 Light 1
113 Screw 1
114 Band 1
115 T-Screw 1
116 Side Handle Holder 1
117 Auxiliary Handle 1

Assembly Diagram

SAFETYOPERATIONMAINTENANCE SETUP

Record Product’s Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only,

and are not available individually as replacement parts.

Page 15For technical questions, please call 1-888-866-5797.Item 69334

Limited 90 Day Warranty

Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.

To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797
