Harbor Freight Tools 95267 User Manual

1 HP DIRTY WATER

SUBMERSIBLE PUMP

95267

ASSEMBLY and OPERATING INSTRUCTIONS

Diagrams within this manual may not be drawn proportionally.

Due to continuing improvements, actual product may differ slightly from the product described herein.

Distributed exclusively by Harbor Freight Tools®.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Copyright© 2007 by Harbor Freight Tools®. All rights reserved. No portion of this manual
or any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

REV 08i

Specifications

Motor 120 V, 60 Hz, 4.7 A (run)
Pump Cord 18 Ft. - 3 Prong Plug
Discharge Size 1-1/2”
Discharge Fittings 1-1/4”, 1-1/2” and 1”
Delivery Height 28.3 Ft.
Flow Rate 3570 GPH
Horsepower 1HP

Warning: The pump should not be submerged in water deeper than the length of
the power cord, which is 18 feet long.

Operating Temp. 95 Deg. F.
Min. Switch Level 3”
Overall Dimensions 6.5” Dia. x 12.375” H
Housing Material PP Plastic
Pump Weight 13.1 Lbs
Motor Drive Magnetic Drive
Max. Particle Size 1”

Save This Manual

You will need the manual for the safety warnings and precautions, assembly instruc­tions, operating and maintenance procedures, parts list and diagram. Keep your invoice
with this manual. Write the invoice number on the inside of the front cover. Keep the
manual and invoice in a safe and dry place for future reference.

Safety Warnings and Precautions

WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment. Read all instructions
before using this tool!

1. Keep work area clean. Cluttered areas invite injuries.

2. Observe work area conditions. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.

3. Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, or extension cords. Always lock up tools and keep out of
reach of children.

4. Do not force pump. It will do the job better and more safely at the rate for which it
was intended. Do not use inappropriate attachments in an attempt to exceed the
pump capacity.

5. Use the right pump for the job. Do not attempt to force a small pump or attachment
to do the work of a larger industrial pump. There are certain applications for which this
pump was designed. Do not modify this pump and do not use this pump for a purpose
for which it was not intended.

SKU 95267

Page 2

6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically nonconductive clothes and nonskid footwear are
recommended when working. Wear restrictive hair covering to contain long hair.

7. Use eye and ear protection. Always wear ANSI-approved impact safety goggles.
Wear an ANSI-approved dust mask or respirator when working around metal, wood,
and chemical dusts and mists.

8. Do not overreach. Keep proper footing and balance at all times. Do not reach over or
across running machines.

9. Maintain pump with care. Inspect tool cords periodically and, if damaged, have them
repaired by an authorized technician. Disconnect electrical source before performing
any maintenance or troubleshooting.

10. Avoid unintentional starting. Dry running of the pump causes excess wear.

11. Stay alert. Watch what you are doing, use common sense. Do not operate any pump
when you are tired.

12. Check for damaged parts. Before using any pump, any part that appears damaged
should be carefully checked to determine that it will operate properly and perform its
intended function.

13. Guard against electric shock. Prevent body contact with grounded surfaces such
as pipes, radiators, ranges, and refrigerator enclosures. It is strongly recommended
that this pump be plugged into a Ground Fault Circuit Interrupter (GFCI). Ask a local
electrician for easy installation instructions. To avoid electrical shock, no person or

animal should be in contact with the water being pumped. Never walk on wet or
damp area when pump is running in the same room.

14. Replacement parts and accessories. When servicing, use only identical
replacement parts. Use of any other parts will void the warranty.

15. Do not operate pump if under the influence of alcohol or drugs. Read warning
labels on prescriptions to determine if your judgment or reflexes are impaired while
taking drugs. If there is any doubt, do not operate the pump.

16. Use proper size and type extension cord. If an extension cord is required, it must be
of the proper size and type to supply the correct current to the tool without heating up.
Otherwise, the extension cord could melt and catch fire, or cause electrical damage
to the tool. This tool requires use of an extension cord of 0 to 10 amps capability (up
to 50 feet), with wire size rated at 18 AWG. Longer extension cords require larger size
wire. If you are using the tool outdoors, use an extension cord rated for outdoor use.
(signified by “WA” on the jacket). Note: Do not make the extension cord connection

underwater.

17. Do not pump hazardous materials. Do not pump explosive or flammable materials
such as Fuel Oil, Kerosene, Gasoline etc. Do not pump in close proximity to
flammable or explosive materials. Do not pump fats, oils, salt or waste water. This
Pump is designed to move clean or dirty water. Do not pump hot liquid.
